Honda Civic Hybrid (2015 year). Manual - part 2





16

Quick

 Referenc

e Guide

Controls

(P101)

Clock

(P102)

The navigation system receives signals from
GPS satellites, updating the clock
automatically.

Models with navigation system

ENGINE START/STOP
Button

● Press the button to change the vehicle’s

power mode.

Turn Signals

(P124)

Turn Signal Control Lever

Right

Left

Lights

(P124)

Wipers and Washers

(P128)

Light Control Switches

Low Beam

High Beam

Flashing

Wiper/Washer Control Lever

Adjustment Ring

: Long Delay
: Short Delay

MIST
OFF
INT:
Low speed with intermittent
LO: Low speed wipe
HI: High speed wipe

Pull toward
you to spray
washer fluid.

17

Quick

 Referenc

e Guide

Steering Wheel

(P131)

● To adjust, pull the adjustment lever

towards you, adjust to the desired
position, then lock the lever back in place.

Unlocking the Front
Doors from the Inside

(P111)
● Pull either front door inner handle to

unlock and open it at the same time.

Trunk

(P114)

● To unlock and open the trunk:

Pull the trunk release.

Press the trunk release button on the
smart entry remote.

Press the trunk release button on the
trunk lid.

Power Door Mirrors

(P132)
● With the power mode in ON, move the

selector switch to L or R.

● Push the appropriate edge of the

adjustment switch to adjust the mirror.

Trunk Release

Selector Switch

Adjustment Switch

Power Windows

(P119)

● With the power mode in ON, open and

close the power windows.

● If the power window lock button is in the

off position, each passenger’s window
can be opened and closed with its own
switch.

● If the power window lock button is in the

on position (indicator is on), each
passenger’s window switch is disabled.

Power Window Lock Button

Window
Switch

Indicator

18

Quick

 Referenc

e Guide

Climate Control System

(P144)

● Press the AUTO button to activate the climate control system.

● Press the

 button to turn the system on or off.

● Press the

 button to defrost the windshield.

The climate control system is voice operable. See the Navigation System Manual for complete details.

 (Mode Control) Button

 (Windshield Defroster) Button

A/C (Air Conditioning) Button

Air flows from floor and
windshield defroster vents.

Air flows from floor vents.

Air flows from floor and
dashboard vents.

Air flows from dashboard
vents.

 (Recirculation) Button

Temperature Control Dial

AUTO Button

 (On/Off) Button

Fan Control Dial

Models with navigation system

19

Quick

 Referenc

e Guide

Features

(P147)

002300

75°

F

miles

Audio System

(P148)

For navigation system operation

() See the Navigation System Manual

MENU

VOL

HOME

BACK

i-MID

CD Slot

HOME Screen

 (Power)

Button

 (CD Eject)

Button

 Button

Audio Remote Controls

(P152)

(

+ /

(

- Button

Press to adjust the volume up/down.

● SOURCE Button

Press to change the audio mode: FM1/
FM2/AM/SiriusXM

*

/CD/USB/iPod/

Pandora®

*

/aha

TM*

/Apps

*

/Bluetooth®

Audio/AUX HDMI.

 /

 Button

Radio:Press to change the preset station.

Press and hold to select the next or
previous strong station.

CD/USB device:

Press to skip to the beginning of
the next song or return to the
beginning of the current song.
Press and hold to change a folder.

(

+ /

(

- Button

SOURCE
Button

 /

 Button

* Not available on all models

20

Quick

 Referenc

e Guide

Driving

(P231)

Release Button

Shift Lever

Depress the brake pedal and press the
release button to move out of

(

P.

Move the shift lever without
pressing the release button.

Press the release button to
move the shift lever.

Automatic Transmission (CVT)

(P243)

● Shift to

(

P and depress the brake pedal when starting the engine.

● Shifting

Park
Turn off or start the engine.
Transmission is locked.

Reverse
Used when reversing.
Neutral
Transmission is not locked.

Drive
Normal driving.

Drive (S)

Better acceleration.

Increased engine braking.

Going up or down hills.

Low

Further increased engine
braking.

Used when going up or down
hills.

Used when IMA battery is
low.

21

Quick

 Referenc

e Guide

VSA® OFF Button

(P260)

● The vehicle stability assist (VSA®) system

helps stabilize the vehicle during
cornering, and helps maintain traction
while accelerating on loose or slippery
road surfaces.

● VSA® comes on automatically every time

you start the engine.

● To turn VSA® on or off, press and hold

the button until you hear a beep.

Cruise Control

(P249)

● Cruise control allows you to maintain a

set speed without keeping your foot on
the accelerator pedal.

● To use cruise control, press the CRUISE

button, then press the –/SET button once
you have achieved the desired speed
(above 25 mph or 40 km/h).

Tire Pressure Monitoring
System (TPMS)

(P263)

● Detects a change in tire conditions and

overall dimensions due to decrease in tire
pressures.

● The TPMS is turned on automatically

every time you start the engine.

● A calibration procedure must be

performed when certain conditions arise.

U.S. models only

Refueling

(P273)

Fuel recommendation: Unleaded gasoline with a pump octane number 87 or

higher required

Fuel tank capacity: 13.2 US gal (50 L)

a

Push the fuel fill door
release handle.

b

Turn the fuel fill cap
slowly to remove the
cap.

c

Place the cap in the
holder on the fuel fill
door.

d

After refueling, screw
the cap back on until it
clicks at least once.

22

Quick

 Referenc

e Guide

Maintenance

(P279)

Under the Hood

(P288)

● Check engine oil, engine coolant, and windshield washer

fluid. Add when necessary.

● Check brake fluid.

● Check the 12-volt battery condition monthly.

a

Pull the hood release handle under the corner of the
dashboard.

b

Locate the hood latch lever, pull the lever up, and lift up
the hood.

c

When finished, close the hood and make sure it is firmly
locked in place.

Lights

(P300)

● Inspect all lights regularly.

Wiper Blades

(P306)

● Replace blades if they leave streaks

across the windshield.

Tires

(P308)

● Inspect tires and wheels regularly.

● Check tire pressures regularly.

● Install snow tires for winter driving.

Quick

 Referenc

e Guide

23

Handling the Unexpected

(P325)

Flat Tire

(P327)

● Park in a safe location and repair the flat

tire using the temporary tire repair kit.

● Park in a safe location and replace the

flat tire with the compact spare tire in the
trunk.

Indicators Come On

(P349)
● Identify the indicator and consult the

owner’s manual.

Models with an optional compact spare tire

Engine Won’t Start

(P341)

● If the battery is dead, jump start using a

booster battery.

Blown Fuse

(P353)

● Check for a blown fuse if an electrical

device does not operate.

Overheating

(P347)

● Park in a safe location. If you do not see

steam under the hood, open the hood,
and let the engine cool down.

Emergency Towing

(P356)

● Call a professional towing service if you

need to tow your vehicle.

24

Quick

 Referenc

e Guide

What to Do If

The power mode does not
change from VEHICLE OFF
(LOCK) to ACCESSORY.
Why?

The steering wheel may be locked.

Move the steering wheel left and right while
pressing the ENGINE START/STOP button at
the same time.

The power mode does not
change from ON to
VEHICLE OFF (LOCK). Why?

The shift lever should be moved to

(

P

.

Why does the brake pedal
pulsate slightly when
applying the brakes?

This can occur when the ABS activates, and does not indicate a
problem. Apply firm, steady pressure on the brake pedal. Never
pump the brake pedal.

The rear door cannot be
opened from inside the
vehicle. Why?

Check if the childproof lock is in the
lock position. If so, open the rear
door with the outside door handle.
To cancel this function, push the lever
to the unlock position.

Canadian models

25

Quick

 Referenc

e Guide

Why do the doors lock
after I unlocked the doors
using a remote
transmitter?

If you do not open the doors within 30 seconds, the doors are
relocked automatically for security.

Why does the beeper
sound when I open the
driver’s door?

The beeper sounds when:

The power mode is in ACCESSORY.

The exterior lights are left on.

The Auto Idle Stop is in operation.

Why does the beeper
sound when I start driving?

The beeper sounds when:

Driver and/or front passenger are not wearing their seat belts.

The parking brake lever is not fully released.

Why do I hear a screeching
sound when I apply the
brake pedal?

The brake pads may need to be replaced. Have your vehicle
inspected by a dealer.

26

28

Safe Driving

For Safe Driving

The following pages explain your vehicle’s safety features and how to use them
properly. The safety precautions below are ones that we consider to be among the
most important.

Important Safety Precautions

Always wear your seat belt

A seat belt is your best protection in all types of collisions. Airbags are designed to
supplement seat belts, not replace them. So even though your vehicle is equipped
with airbags, make sure you and your passengers always wear your seat belts, and
wear them properly.

Restrain all children

Children ages 12 and under should ride properly restrained in a back seat, not the
front seat. Infants and small children should be restrained in a child seat. Larger
children should use a booster seat and a lap/shoulder seat belt until they can use the
belt properly without a booster seat.

Be aware of airbag hazards

While airbags can save lives, they can cause serious or fatal injuries to occupants
who sit too close to them, or are not properly restrained. Infants, young children,
and short adults are at the greatest risk. Be sure to follow all instructions and
warnings in this manual.

Don’t drink and drive

Alcohol and driving don’t mix. Even one drink can reduce your ability to respond to
changing conditions, and your reaction time gets worse with every additional drink.
So don’t drink and drive, and don’t let your friends drink and drive, either.

1

Important Safety Precautions

Some states, provinces and territories prohibit the use
of cell phones other than hands-free devices by the
driver while driving.

29

uu

For Safe Driving

u

Important Safety Precautions

Safe Driving

Pay appropriate attention to the task of driving safely

Engaging in cell phone conversation or other activities that keep you from paying
close attention to the road, other vehicles, and pedestrians could lead to a crash.
Remember, situations can change quickly, and only you can decide when it is safe to
divert some attention away from driving.

Control your speed

Excessive speed is a major factor in crash injuries and deaths. Generally, the higher
the speed, the greater the risk, but serious injuries can also occur at lower speeds.
Never drive faster than is safe for current conditions, regardless of the maximum
speed posted.

Keep your vehicle in safe condition

Having a tire blowout or a mechanical failure can be extremely hazardous.
To reduce the possibility of such problems, check your tire pressures and condition
frequently, and perform all regularly scheduled maintenance.

30

uu

For Safe Driving

u

Your Vehicle’s Safety Features

Safe Driving

Your Vehicle’s Safety Features

The following checklist will help you take an active role in protecting yourself and
your passengers.

1

Your Vehicle’s Safety Features

Your vehicle is equipped with many features that
work together to help protect you and your
passengers during a crash.

Some features do not require any action on your part.
These include a strong steel framework that forms a
safety cage around the passenger compartment,
front and rear crush zones, a collapsible steering
column, and tensioners that tighten the front seat
belts in a sufficient crash.

However, you and your passengers cannot take full
advantage of these features unless you remain seated
in the correct position and always wear your seat
belts. In fact, some safety features can contribute to
injuries if they are not used properly.

6

7

8

9

10

11

Safety Cage
Crush Zones
Seats and Seat-Backs
Head Restraints
Collapsible Steering Column
Seat Belts
Front Airbags

Side Curtain Airbags

Seat Belt Tensioners

Side Airbags

6

7

7

8

8

9

9

10

11

Door Locks

10

31

uu

For Safe Driving

u

Your Vehicle’s Safety Features

Safe Driving

For the safety of you and your passengers, make a habit of checking these items
each time before you drive.
• After everyone has entered the vehicle, be sure all doors are closed and locked.

Locking the doors helps prevent an occupant from being ejected and an outsider
from unexpectedly opening a door.

Locking/Unlocking the Doors from the Inside P. 110

• Adjust your seat to a position suitable for driving. Be sure the front seats are

adjusted as far to the rear as possible while allowing the driver to control the
vehicle. Sitting too close to a front airbag can result in serious or fatal injury in a
crash.

Adjusting the Seats P. 134

• Adjust head restraints to the proper position. Head restraints are most effective

when the center of the head restraint aligns with the center of your head. Taller
persons should adjust their head restraint to the highest position.

Adjusting the Head Restraints P. 136

• Always wear your seat belt, and make sure you wear it properly. Confirm that any

passengers are properly belted as well.

Fastening a Seat Belt P. 35

• Protect children by using seat belts or child seats according to a child’s age, height

and weight.

Child Safety P. 52

Safety Checklist

1

Safety Checklist

If the door open indicator is on, a door is not
completely closed. Close all doors tightly until the
indicator goes off.

Door Open Indicator P. 72















Content   ..   1  2  3   ..
