Honda Civic Hatchback (2018 year). Manual - part 10





144

145

Controls

This chapter explains how to operate the various controls necessary for driving.

Clock .................................................. 146
Locking and Unlocking the Doors

Key Types and Functions .................. 147
Low Smart Entry Remote Signal Strength

*

.. 148

Locking/Unlocking the Doors from the

Outside .......................................... 149

Locking/Unlocking the Doors from the

Inside ............................................. 158

Childproof Door Locks ..................... 160
Auto Door Locking/Unlocking .......... 161

Opening and Closing the Hatch....... 165
Security System

Immobilizer System .......................... 168
Security System Alarm...................... 169

Opening and Closing the Windows ... 172
Opening and Closing the Moonroof

*

.. 175

Operating the Switches Around the

Steering Wheel

Ignition Switch

*

............................... 176

ENGINE START/STOP Button

*

........... 177

Ignition Switch and Power Mode

Comparison ................................... 180

Turn Signals ..................................... 181
Light Switches.................................. 181
Fog Lights

*

...................................... 184

Daytime Running Lights ................... 184
Auto High-Beam

*

............................ 185

Wipers and Washers ........................ 188

Brightness Control ........................... 191
Rear Defogger/Heated Door Mirror

*



Button ........................................... 192

Adjusting the Steering Wheel .......... 193

Adjusting the Mirrors

Interior Rearview Mirror ................... 194
Power Door Mirrors ......................... 195

Adjusting the Seats .......................... 196
Interior Lights/Interior Convenience

Items ................................................ 204

Climate Control System

Using Automatic Climate Control .... 220
Automatic Climate Control Sensors......227

* Not available on all models

146

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time in the clock display with the ignition switch in ON

(

w

*1

.

Using the MENU/CLOCK button

1. Press and hold the MENU/CLOCK button.

u

Adjust Clock is selected.

2. Rotate

 to change hour, then press

.

3. Rotate

 to change minute, then press

.

4. To enter the selection, rotate

 and select

Set, then press

.

Using the Settings menu on the audio/
information screen

1. Select Settings.
2. Select Clock.
3. Select Clock Adjustment.
4. Select

 or

 to change hour.

5. Select

 or

 to change minute, then

select OK.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Adjusting the Time

1

Adjusting the Clock

The clock is automatically updated through the audio
system, so the time does not need to be adjusted.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

Customized Features P. 348

Models with navigation system

All models

Models without navigation system

1

Using the MENU/CLOCK button

These indications are used to show how to operate
the selector knob.
Rotate

 to select.

Press

 to enter.

1

Using the Settings menu on the audio/information screen

You can turn the clock display on and off.

Customized Features P. 348

You can also adjust the clock by touching the clock
displayed on the upper right corner of the display.
1. Touch the clock on the display for a few seconds.
2. Select Clock Adjustment.
3. Select

 or

 to change hour.

4. Select

 or

 to change minute, then select OK.

You cannot adjust the time while the vehicle is
moving.

3

4

3

4

Models with color audio system

Models with Display Audio

3

4

3

4

147

Continued

Co
ntrols

Locking and Unlocking the Doors

Key Types and Functions

This vehicle comes with the following keys:

Use the keys to start and stop the engine, and to lock and unlock the doors and
hatch. You can also use the remote transmitter to lock and unlock the doors and
hatch.

The built-in key can be used to lock/unlock the
doors when the smart entry remote battery
becomes weak and the power door lock/
unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
smart entry remote until it clicks.

1

Key Types and Functions

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

Immobilizer System P. 168

Follow the advice below to prevent damage to the
keys:

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

Do not drop the keys or set heavy objects on them.

Keep the keys away from liquids, dust and sand.

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the smart
entry remote with remote engine starter.

Remote Engine Start with Vehicle

Feedback

*

 P. 454

Models with remote engine starter

Built-in Key

*

Ignition key with
remote transmitter

Smart entry remote

Smart entry remote with
remote engine starter

Built-in Key

Release Knob

* Not available on all models

uu

Locking and Unlocking the Doors

u

Low Smart Entry Remote Signal Strength

*

148

Co
ntrols

Contains a number that you will need if you
purchase a replacement key.

Low Smart Entry Remote Signal Strength

*

The vehicle transmits radio waves to locate the smart entry remote when locking/
unlocking the doors and hatch, or to start the engine.

In the following cases, locking/unlocking the doors and hatch, or starting the engine
may be inhibited or operation may be unstable:
• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the smart entry remote together with telecommunications

equipment, laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the smart entry remote.

Key Number Tag

1

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

1

Low Smart Entry Remote Signal Strength

*

Communication between the smart entry remote and
the vehicle consumes the smart entry remote’s
battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the smart entry
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

* Not available on all models

149

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the smart entry remote, you
can lock/unlock the doors and hatch.
You can lock/unlock the doors and hatch
within a radius of about 32 inches (80 cm) of
the outside door handle or hatch release
button.

Using the Smart Entry with Push Button Start System

*

1

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior light comes on when you unlock
the doors.
No doors opened: The light fades out after 30
seconds.
Doors relocked: The light goes off immediately.

Interior Lights P. 204

1

Using the Smart Entry with Push Button Start System

*

If you do not open a door or the hatch within 30
seconds of unlocking the vehicle with the smart entry
system, the doors and hatch will automatically relock.

You can lock or unlock doors using the smart entry
system only when the power mode is in VEHICLE OFF.

* Not available on all models

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

150

Co
ntrols

Locking the doors and hatch

Press the door lock button on the front door
or on the hatch.

u

Some exterior lights flash; the beeper
sounds; all the doors and hatch lock; and
the security system sets.

1

Using the Smart Entry with Push Button Start System

*

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

Even if you are not carrying the smart entry remote,
you can lock/unlock the doors and hatch while
someone else with the remote is within range.

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the smart entry remote is within range.

If you grip a front door handle wearing gloves, the
door sensor may be slow to respond or may not
respond by unlocking the doors.

After locking the door, you have up to two seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least two seconds before gripping the handle,
otherwise the door will not unlock.

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors and hatch
with the smart entry remote if it is above or below
the outside handle.

The smart entry remote may not operate if it is too
close to the door and door glass.

The light flash, beep and door unlock mode settings
can be customized using the audio/information
screen or driver information interface.

Customized Features P. 133, 348

Door Lock Button

Lock Button

* Not available on all models

Continued

151

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

Locking the doors and hatch (Walk
away auto lock)

When you walk away from the vehicle while
carrying the smart entry remote, the doors
and hatch will automatically lock.
The auto lock function activates when all
doors and hatch are closed, and the smart
entry remote is within about 5 feet (1.5 m)
radius of the outside door handle.
Exit vehicle while carrying smart entry remote
and close door(s).

1. While within about 5 feet (1.5 m) radius of

the vehicle.

u

The beeper sounds; the auto lock
function will be activated.

2. Carry the smart entry remote beyond about

5 feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

u

Some exterior lights flash; the beeper
sounds; all doors and hatch will then
lock.

1

Locking the doors and hatch (Walk away auto lock)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the audio/information screen or driver
information interface.
If you set the auto lock function to ON using the
audio/information screen or the driver information
interface, only the remote transmitter that was used
to unlock the driver’s door prior to the setting change
can activate auto lock.

Customized Features P. 133, 348

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the smart entry
remote will continue to flash until the doors are
locked.

When you stay beside the vehicle within the
operation range, the doors and hatch will
automatically lock approximately 30 seconds after
the auto lock function activating beeper sounds.

When you open a door or the hatch after the auto
lock function activating beeper sounds, the auto lock
function will be delayed until all doors and hatch are
closed.

When all doors and hatch have been closed and the
smart entry remote is inside the vehicle, or if the
smart entry remote is not detected within about 5
feet (1.5 m) of the vehicle, auto lock function will not
be activated.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

152

Co
ntrols

To temporarily deactivate the function:
1. Set the power mode to OFF.
2. Open the driver’s door.
3. Using the master door lock switch, operate

the lock as follows:
Lock

Unlock

Lock

Unlock.

u

The beeper sounds and the function is
deactivated.

To restore the function:
• Set the power mode to ON.
• Lock the vehicle without using the auto lock

function.

• With the smart entry remote on you, move

out of the auto lock function operation
range.

• Open any door.

1

Locking the doors and hatch (Walk away auto lock)

The auto lock function does not operate when any of
the following conditions are met.

The smart entry remote is inside the vehicle.

A door, hatch or the hood is not closed.

The power mode is set to any mode other than
OFF.

The smart entry remote is not located within a
radius of about 5 feet (1.5 m) from the vehicle
when you get out of the vehicle and close the
doors.

Auto lock function operation stop beeper
After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

The smart entry remote is put inside the vehicle
through a window.

You are located too close to the vehicle.

The smart entry remote is put inside the hatch.

If the warning beeper sounds, check that you are
carrying the smart entry remote. Then, open/close a
door and confirm the auto lock activation beeper
sounds once.

153

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Unlocking the doors and hatch

Grab the driver’s door handle:

u

The driver’s door unlocks.

u

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

u

All doors and the hatch unlock.

u

Some exterior lights flash twice and the
beeper sounds twice.

Press the hatch release button.

u

The hatch unlocks.

u

Some exterior lights flash twice and the
beeper sounds twice.

Using the Hatch Release Button P. 166

Hatch Release Button

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

154

Co
ntrols

Locking the doors and hatch

Press the lock button.
Once:

u

Some exterior lights flash, all the doors
and hatch lock, and the security system
sets.

Twice (within five seconds after the first
push):

u

The beeper sounds and verifies the
security system is set.

Using the Remote Transmitter

1

Using the Remote Transmitter

If you do not open a door or the hatch within 30
seconds of unlocking the vehicle with the remote
transmitter, the doors and hatch will automatically
relock.

You can change the relock timer setting.

Customized Features P. 133, 348

The remote transmitter will not work when the key is
in the ignition switch.

You can lock or unlock doors using the remote
transmitter only when the power mode is in VEHICLE
OFF.

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote will not lock the vehicle when a door is
open.

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

Replacing the Button Battery P. 615

Models with driver information interface

Models without smart entry system

Models with smart entry system

All models

LED

Unlock Button

Lock Button

Continued

155

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

Unlocking the doors and hatch

Press the unlock button.
Once:

u

Some exterior lights flash twice, and the driver’s door unlocks.

Twice:

u

The remaining doors and hatch unlock.

1

Using the Remote Transmitter

You can customize the door unlock mode setting.

Customized Features P. 133, 348

Models with driver information interface

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

156

Co
ntrols

If the lock or unlock button of the remote transmitter does not work, use the key
instead.

Replacing the Button Battery P. 615

Fully insert the key and turn it.

Locking/Unlocking the Doors Using a Key

1

Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, all the
other doors and hatch lock at the same time. When
unlocking, the driver’s door unlocks first. Turn the
key a second time within a few seconds to unlock the
remaining doors and the hatch.

You can customize the door unlock mode setting.

Customized Features P. 133, 348

Models with driver information interface

Lock

Unlock

157

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

If you do not have the key on you, or if for some reason you cannot lock a door using
the key, you can lock the door without it.

Locking the front doors

Push the lock tab forward

a

 or push the

master door lock switch in the lock direction

b

, and close the door.

Locking the rear doors

Push the lock tab forward and close the door.

Lockout prevention system

The doors and hatch cannot be locked when the key is in the ignition switch.

The doors and hatch cannot be locked when the smart entry remote is inside the
vehicle.

Locking a Door Without Using a Key

1

Locking a Door Without Using a Key

When you lock the driver’s door, all the other doors
and hatch lock at the same time.
Before locking a door, make sure that the key is not
inside the vehicle.

Models without smart entry system

Models with smart entry system

158

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

Co
ntrols

Locking/Unlocking the Doors from the Inside

Locking a door

Push the lock tab forward.

Unlocking a door

Pull the lock tab rearward.

Using the Lock Tab

1

Using the Lock Tab

When you lock the door using the lock tab on the
driver’s door, all of the other doors and the hatch
lock at the same time.
When you unlock the door using the lock tab on the
driver’s door, only the driver’s door will unlock.

To Unlock

Lock Tab

To Lock

Continued

159

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Inside

Co
ntrols

Pull the front door inner handle.

u

The door unlocks and opens in one
motion.

Unlocking and opening the driver’s door from the inner handle unlocks all the other
doors.
To avoid all the doors to be unlocked, use the lock tab on the driver’s door to unlock,
then lock again before opening the door.

u

This setting works for one time only.

If you do not want all the doors to be unlocked all the time, customize the
Auto Door Unlock setting to OFF using the driver information interface.

Customized Features P. 133

If you do not want all the doors to be unlocked all the time, customize the auto
door unlocking setting to off using the master door lock switch.

Customizing Flow for Auto Door Unlocking Options P. 164

If you do not want all the doors to be unlocked all the time, customize the
Auto Door Unlock setting to Off using the audio/information screen.

Customized Features P. 348

Unlocking Using the Front Door Inner Handle

1

Unlocking Using the Front Door Inner Handle

The front door inner handles are designed to allow
front seat occupants to open the door in one motion.
However, this feature requires that front seat
occupants never pull a front door inner handle while
the vehicle is in motion.

Children should always ride in a rear seat where
childproof door locks are provided.

Childproof Door Locks P. 160

Inner
Handle

Models with driver information interface and color audio system

Models with Information Display

Models with Display Audio















Content   ..  8  9  10  11   ..
