Honda Civic Coupe (2019 year). Manual

Bluetooth® HandsFreeLink®

HFL Menus

400

Features

■

To change the currently paired phone

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select Bluetooth Device List.
3. Select a phone to connect.

HFL disconnects the connected phone
and starts searching for another paired
phone.

4. Select Connect

, Connect ,

Connect

■

To change the pairing code setting

1. Press the

button.

2. Select Settings.
3. Select Bluetooth/Wi-Fi.
4. Select the Bluetooth tab.
5. Select Edit Pairing Code.

6. Select Random or Fixed.

To change the currently paired phone

If no other phones are found or paired when trying to
switch to another phone, HFL will inform you that the
original phone is connected again.

To pair other phones, select Add Bluetooth Device
from the Bluetooth device list screen.

To change the Bluetooth® connection priority device
setting, select Priority Device Settings from the
Bluetooth Device List screen.

To change the pairing code setting

The default pairing code is 0000 until you change the
setting.
To create your own, select Fixed, and delete the
current code, then enter a new one.

For a randomly generated pairing code each time you
pair a phone, select Random.

401

Bluetooth® HandsFreeLink®

HFL Menus

Continued

Features

■

To delete a paired phone

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select Bluetooth Device List.
3. Select a phone you want to delete.

4. Select Delete.
5. A confirmation message appears on the

screen. Select Yes.

Bluetooth® HandsFreeLink®

HFL Menus

402

Features

■

To turn on or off the text/e-mail
function

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select the Text/Email tab, then Enable

Text/Email.

A pop-up menu appears on the screen.

3. Select On or Off.

■

To turn on or off the text/e-mail notice

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select the Text/Email tab, then New

Message Notification.

A pop-up menu appears on the screen.

3. Select On or Off.

■

To Set Up Text/E-mail Message Options

To Set Up Text/E-mail Message Options

To use the text/e-mail message function, it may be
necessary to set up on your phone.

To turn on or off the text/e-mail notice

On: A pop-up notification comes on every time you
receive a new message.
Off: The message you receive is stored in the system
without notification.

Continued

403

Bluetooth® HandsFreeLink®

HFL Menus

Features

You can change the ring tone setting.

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select Ring Tone.
3. Select Fixed or Mobile Phone.

■

Ring Tone

Ring Tone

Fixed: The fixed ring tone sounds from the speakers.
Mobile Phone: For certain connected phones, the
ring tone stored in the phone sounds from the
speakers.

Bluetooth® HandsFreeLink®

HFL Menus

404

Features

■

When Automatic Phone Sync is set to
On:

When your phone is paired, the contents of its
phonebook and call history are automatically
imported to the system.

■

Changing the Automatic Phone Sync
setting

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select Automatic Phone Sync.

3. Select On or Off.

■

Automatic Import of Cellular Phonebook and Call History

Automatic Import of Cellular Phonebook and Call History

When you select a name from the list in the cellular
phonebook, you can see up to three category icons.
The icons indicate what types of numbers are stored
for that name.

On some phones, it may not be possible to import the
category icons to the system.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Home

Mobile

Work

Pager

Fax

Car

Other

Voice

Pref

Continued

405

Bluetooth® HandsFreeLink®

HFL Menus

Features

Up to 20 speed dial numbers can be stored per phone.

To store a speed dial number:
1. Go to the Phone menu screen.

2 Phone menu screen P. 397

2. Select Speed Dial.
3. Select New Entry.

From Import from Call History:

Select a number from the call history.

From Manual Input:

Input the number manually.

From Import from Phonebook:

Select a number from the connected cell
phone’s imported phonebook.

4. When the speed dial is successfully stored,

you are asked to create a voice tag for the
number. Select Yes or No.

5. Select Record, or use the

button and

follow the prompts to complete the voice
tag.

■

Speed Dial

Speed Dial

When a voice tag is stored, press the

button to

call the number using the voice tag. Say the voice tag
name.

Bluetooth® HandsFreeLink®

HFL Menus

406

Features

■

To add a voice tag to a stored speed
dial number

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

From the pop-up menu, select Edit.

4. Select Voice Tag.

From the pop-up menu, select Record.

5. Select Record, or use the

button and

follow the prompts to complete the voice
tag.

■

To delete a voice tag

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

From the pop-up menu, select Edit.

4. Select Voice Tag.

From the pop-up menu, select Clear.

5. A confirmation message appears on the

screen. Select Yes.

Speed Dial

Avoid using duplicate voice tags.
Avoid using “home” as a voice tag.
It is easier for the system to recognize a longer name.
For example, use “John Smith” instead of “John.”

407

Bluetooth® HandsFreeLink®

HFL Menus

Continued

Features

■

To edit a speed dial

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

From the pop-up menu, select Edit.

4. Select a setting you want.

■

To delete a speed dial

1. Go to the phone settings screen.

2 Phone settings screen P. 394

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

From the pop-up menu, select Delete.

4. A confirmation message appears on the

screen. Select Yes.

Bluetooth® HandsFreeLink®

HFL Menus

408

Features

Add phonetic modifications or a new voice tag to the phone’s contact name so that
it is easier for HFL to recognize voice commands.

■

To add a new voice tag

1. Press the

button.

2. Select Settings.
3. Select System.
4. Select the Voice Recog tab.
5. Select Phonebook Phonetic

Modification.

6. Select the phone you want to add

phonetic modification to.

■

Phonebook Phonetic Modification

Phonebook Phonetic Modification

You can store up to 20 phonetic modification items.

409

Bluetooth® HandsFreeLink®

HFL Menus

Continued

Features

7. Select New Voice Tag.
8. Select a contact name you want to add to.

The pop-up menu appears on the
screen.

9. Select Modify.

10. Using Record or the

button, follow

the prompts to complete the voice tag.

11. You will receive a confirmation message

on the screen, then select OK.

Bluetooth® HandsFreeLink®

HFL Menus

410

Features

■

To modify a voice tag

1. Press the

button.

2. Select Settings.
3. Select System.
4. Select the Voice Recog tab.
5. Select Phonebook Phonetic

Modification.

6. Select the phone you want to modify

phonetic modification.

7. Select a contact name you want to

modify.

The pop-up menu appears on the
screen.

8. Select Modify.
9. Using Record or the

button, follow

the prompts to complete the voice tag.

10. You will receive a confirmation message

on the screen, then select OK.

Phonebook Phonetic Modification

You can only modify or delete contact names for the
currently connected phone.

411

Bluetooth® HandsFreeLink®

HFL Menus

Continued

Features

■

To delete a modified voice tag

1. Press the

button.

2. Select Settings.
3. Select System.
4. Select the Voice Recog tab.
5. Select Phonebook Phonetic

Modification.

6. Select the phone you want to delete

phonetic modification.

7. Select a contact name you want to delete.

The pop-up menu appears on the screen.

8. Select Delete.

The selected contact name has been
selected.

9. Select OK.

Bluetooth® HandsFreeLink®

HFL Menus

412

Features

■

To delete all modified voice tags

1. Press the

button.

2. Select Settings.
3. Select System.
4. Select the Voice Recog tab.
5. Select Phonebook Phonetic

Modification.

6. Select the phone you want to delete

phonetic modification.

The contact name list appears.

7. Select Delete All.
8. You will receive a confirmation message on

the screen, then select Yes.

You can make calls by inputting any phone
number, or by using the imported
phonebook, call history, speed dial entries, or
redial.

■

Making a Call

Making a Call

Any voice-tagged speed dial entry can be dialed by
voice from most screens.

Press the

button and say the voice tag name.

Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.

While there is an active connection with Apple
CarPlay, phone calls cannot be made with
HandsFreeLink® and are only made from Apple
CarPlay.

413

Bluetooth® HandsFreeLink®

HFL Menus

Continued

Features

■

To make a call using the imported
phonebook

1. Go to the Phone menu screen.

2 Phone menu screen P. 397

2. Select Phonebook.
3. Select a name.

You can also search by letter. Select
Search.

Use the keyboard on the touch screen for
entering name, if multiple numbers exist
select a number.

4. Select a number.

Dialing starts automatically.

■

To make a call using a phone number

1. Go to the Phone menu screen.

2 Phone menu screen P. 397

2. Select Dial.
3. Select a number.

Use the keyboard on the touch screen for
entering numbers.

4. Select .

Dialing starts automatically.

Bluetooth® HandsFreeLink®

HFL Menus

414

Features

■

To make a call using redial

1. Go to the Phone menu screen.

2 Phone menu screen P. 397

2. Select Redial.

Dialing starts automatically.

■

To make a call using the Call History

Call history is stored by All, Dialed,
Received, and Missed.
1. Go to the Phone menu screen.

2 Phone menu screen P. 397

2. Select Call History.
3. Select All, Dialed, Received, or Missed.
4. Select a number.

Dialing starts automatically.

■

To make a call using a Speed Dial entry

1. Go to the Phone menu screen.

2 Phone menu screen P. 397

2. Select Speed Dial.
3. Select a number.

Dialing starts automatically.

To make a call using the Call History

The call history displays the last 20 all, dialed,
received, or missed calls.
(Appears only when a phone is connected to the
system.)

To make a call using a Speed Dial entry

When a voice tag is stored, press the

button to

call the number using the voice tag.

2 Speed Dial P. 405

Any voice-tagged speed dial entry can be dialed by
voice from any screen.
Press the

button and follow the prompts.

Continued

415

Bluetooth® HandsFreeLink®

HFL Menus

Features

When there is an incoming call, an audible
notification sounds (if activated) and the
Incoming call screen appears.

Press the

button to answer the call.

Press the

button to decline or end the

call.

The following options are available during a call.
Mute: Mute your voice.
Transfer: Transfer a call from the system to your phone.
Touch Tones: Send numbers during a call. This is useful when you call a menu-
driven phone system.

The available options are shown on the lower
half of the screen.

Select the option.

The mute icon appears when Mute is
selected. Select Mute again to turn it off.

■

Receiving a Call

Receiving a Call

Call Waiting

Press the

button to put the current call on hold to

answer the incoming call.

Press the

button again to return to the current

call.
Select Ignore to ignore the incoming call if you do
not want to answer it.
Press the

button if you want to hang up the

current call.

You can select the icons on the audio/information
screen instead of the

and

buttons.

■

Options During a Call

Options During a Call

Touch Tones: Available on some phones.

You can select the icons on the audio/information
screen.

Mute Icon

Honda Civic Coupe (2019 year). Manual - part 26
