Honda Accord (2019 year). Manual - part 8





112

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears after you set the power mode to
ACCESSORY or ON.

Appears after you unlock and open the driver’s
door.

Starting the Engine P. 465

Appears when the steering wheel is locked.

Move the steering wheel left and right while pressing the
ENGINE START/STOP button.

Automatic transmission/
Continuously variable
transmission models

Manual transmission
models

Canadian models

Continuously variable transmission models
for Canadian models

Manual transmission models

113

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the power mode is in ACCESSORY.

Appears after the driver’s door is opened when the
power mode is in ACCESSORY.

Change the power mode to VEHICLE OFF.

ENGINE START/STOP Button P. 190

Appears when you close the door with the power
mode in ON without the remote inside the vehicle.

Disappears when you bring the remote back inside the
vehicle and close the door.

Remote Reminder P. 192

Appears when the remote battery becomes weak.

Replace the battery as soon as possible.

Replacing the Button Battery P. 653

114

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears if you try to start the engine when the
transmission is in

(

N and the parking brake is

disengaged.

Put the transmission into

(

P, then start the engine in

the normal procedure.

Starting the Engine P. 465

Appears when the parking brake is disengaged while
the power mode is in ON.

Set the parking brake, then start the engine in the
normal procedure.

Parking Brake P. 571
Starting the Engine P. 465

Automatic transmission
models

Continuously variable
transmission models

Automatic transmission/Continuously variable
transmission models

Manual transmission models

115

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears if the remote battery is too weak to start the
engine or the key is not within operating range to
start the engine.
A beeper sounds six times.

Bring the remote in front of the ENGINE START/STOP
button to be touched with.

If the Remote Battery is Weak P. 672

Appears when the starter system has a problem.

As a temporary measure, press and hold the ENGINE
START/STOP
 button for up to 15 seconds while
pressing the brake pedal and clutch pedal (manual
transmission only), manually start the engine.
Have your vehicle checked by a dealer.

Appears as soon as a problem is detected in the
smart entry system

*

 or push button starting system.

Have your vehicle checked by a dealer.

U.S.

Canada

* Not available on all models

116

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if you press the ENGINE START/STOP

button while the vehicle is moving.

• The message will disappear after six seconds or when

the power mode is set to VEHICLE OFF.

• Appears if the vehicle is being driven in a manner

consistent with drowsy or inattentive driving.

Driver Attention Monitor P. 152

117

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when the temperature of the transmission

is starting to get too hot.

• The performance of the vehicle may be reduced.

• Until the message disappears, reduce your speed and

allow the system to cool down.

• Appears when you attempt to change to another

gear position with the transmission in

(

P and the

engine OFF.

• To select another gear position while in

(

P, the engine

must be ON.

• Appears when you set the power mode to OFF while

driving.

• Immediately stop in a safe place, set the parking brake,

then restart the engine. If the message disappears,
continue driving.

Automatic transmission models

118

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if the vehicle is stopped and the driver’s seat

belt is unfastened, as there is a possibility that the
vehicle may roll.

• When the vehicle is idling or when you are parking or

exiting the vehicle, put the transmission into

(

P before

releasing the brake pedal.

Shift Operation P. 476

• Appears when you put the transmission into

(

N,

then release the

(

N button.

If you want to keep the transmission in

(

N



position [car wash mode] P. 478

• Appears when car wash mode is not available due to

the transmission being too hot.

• When the transmission is too hot, car wash mode may

not be available. Let the engine idle until the
transmission has cooled down.

If you want to keep the transmission in

(

N



position [car wash mode] P. 478

Automatic transmission models

119

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when you try to change the gear position

without releasing your foot off the accelerator pedal.

• Release your foot off the accelerator pedal, then select

a shift button.

• Appears when the

(

P button is pressed while the

vehicle is moving.

• Appears if you put the transmission into

(

R while

the vehicle is moving forward, or into

(

D while the

vehicle is reversing.

• Make sure that the vehicle comes to a stop before

operating the select button.

• Appears when you set the power mode to ON

without fastening the driver’s seat belt.

• Appears when you change the gear position after

(

P has been automatically selected with the driver’s

door open, the driver’s seat belt unfastened, then
the brake pedal is released.

• Fasten the seat belt properly before you start to drive.

Shift Operation P. 476

• Appears when you try to change the gear position

without depressing the brake pedal.

• Depress the brake pedal, then select a shift button.

Automatic transmission models

120

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if you depress the accelerator pedal when

the transmission is in

(

N.

• Release the accelerator pedal. After that, depress the

brake pedal and change the transmission position.

Appears when the shift is repeatedly changed
between

(

P and any other position.

Wait for a while then change the gear position.

• Appears when you try to take the transmission out

of

(

P immediately after you start engine.

• Try to take the transmission out of

(

P again.

Automatic transmission models

121

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears when you press and hold

(

N button for

more than two seconds.

• Disappears when you set the gear position to a gear

other than

(

N.

If you want to keep the transmission in

(

N



position [car wash mode] P. 478

Message

Condition

Explanation

• Appears if you press the ENGINE START/STOP

button to turn the engine off without the shift lever
in

(

P.

Move the shift lever to

(

P. The power mode changes to

VEHICLE OFF.

Move the shift lever to

(

P, then press the ENGINE

START/STOP button twice.

Automatic transmission models

Continuously variable transmission models

U.S. models

Canadian models

122

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if there is a problem with the automatic

lighting control system.

• Appears while driving - Manually turn the lights on,

and have your vehicle checked by a dealer.

• Appears if there is a problem with the headlights.

• Appears while driving - The headlights may not be

on. When conditions allow you to drive safety, have
your vehicle checked by a dealer as soon as possible.

• Appears if there is a problem with the parking sensor

system.

• Check if the area around the sensor(s) is covered with

mud, ice, snow, etc. If the indicator(s) stays on or the
beeper does not stop even after you clean the area,
have the system checked by a dealer.

• Appears if there are obstacles around the sensors.

• Check for obstacles near your vehicle to make sure it is

safe to park.

Models with parking sensor system

Models with parking sensor system

123

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

• Appears if there is a problem with the auto high-

beam.

• Manually operate the headlight switch.
• If you are driving with the high-beam headlights when

this happens, the headlights are changed to low beams.

Appears when ACC with LSF

*

/ACC

*

 has been

automatically canceled.

You can resume the set speed after the condition that
caused ACC with LSF

*

/ACC

*

 to cancel improves. Press

the RES/+ button.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

Flashes when the system senses a likely collision with
a vehicle in front of you.

Take the appropriate means to prevent a collision (apply
the brakes, change lanes, etc.)

Collision Mitigation Braking System

TM

 (CMBS

TM

)

P. 510

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

* Not available on all models

124

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when ACC with LSF

*

/ACC

*

 is canceled due

to excessive high vehicle speed.

Reduce the speed, then reset ACC with LSF

*

/ACC

*

.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

Appears when the speed of the vehicle is too high for
you to set ACC with LSF

*

/ACC

*

.

Reduce the speed, then set ACC with LSF

*

/ACC

*

.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

Appears when ACC is canceled due to excessive low
vehicle speed.

Raise the speed, then reset ACC.

Adaptive Cruise Control (ACC)

*

 P. 535

Appears when the speed of the vehicle is too low for
you to set ACC.

Raise the speed, then set ACC.

Adaptive Cruise Control (ACC)

*

 P. 535

Manual transmission models

Manual transmission models

* Not available on all models

125

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when the distance between your vehicle
and the vehicle ahead of you is too close while ACC
with LSF

*

/ACC

*

 is in operation.

ACC with LSF

*

/ACC

*

 has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

Appears when pressing the SET/ button while the
distance between your vehicle and the vehicle
ahead of you is too close.

ACC with LSF

*

/ACC

*

 cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

Appears when the parking brake is applied
automatically while ACC with LSF

*

/ACC

*

 is in

operation.

ACC with LSF

*

/ACC

*

 has been automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

Parking Brake P. 571

Appears when pressing the SET/ button while the
parking brake is applied.

ACC with LSF

*

/ACC

*

 cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

Parking Brake P. 571

* Not available on all models

126

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears when pressing the SET/ button while the
vehicle is moving and the brake pedal is depressed.

ACC with LSF

*

/ACC

*

 cannot be set.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

Automatic
transmission/
Continuously variable
transmission models

Manual transmission
models

* Not available on all models

127

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Message

Condition

Explanation

Appears just before the ACC with LSF

*

/ACC

*

 is

automatically canceled when you are descending a
long hill etc (The following interval is automatically
set to extra long).

Appears when the ACC with LSF

*

/ACC

*

 has been

automatically canceled.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

Appears when you are descending a long hill etc and
you press the RES/+ or SET/ button.

Adaptive Cruise Control (ACC) with Low Speed

Follow (LSF)

*

 P. 519

Adaptive Cruise Control (ACC)

*

 P. 535

* Not available on all models















Content   ..  6  7  8  9   ..
