Honda Accord Sedan (2016 year). Manual - part 13





192

Features

Audio System Basic Operation

To use the audio system function, the ignition switch must be in ACCESSORY

(

q or

ON

(

w

*1

.

Use the selector knob or MENU button to
access some audio functions.

Press

 to switch between the normal and

extended display for some functions.

Selector knob: Rotate left or right to scroll
through the available choices. Press to set
your selection.
MENU button: Press to select any mode.
The available mode includes Change Source
Station ListSave PresetRadio Text
Music Search, and play modes. Play modes
can be also selected from ScanRandom/
Repeat
, and so on.
BACK button: Press to go back to the
previous display.

 button: Press to change the audio/

information screen brightness.
Press

 once and make an adjustment.

u

Each time you press

, the mode

switches between the daytime mode,
nighttime mode and OFF mode.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Models with one display

1

Audio System Basic Operation

These indications are used to show how to operate
the selector knob.

Rotate

 to select.

Press

to

enter.

Audio Menu Items

Station List P. 200
Radio text P. 200
Music Search P. 202, 205, 211
Scan P. 200, 203, 212
Random/Repeat P. 203, 206, 212

This product includes software codes licensed under
the conditions stated by the copyright holder.
For license conditions and the copy of the
corresponding source code, visit: http://
www.hondaopensource1.com/002

 Button

Selector Knob

MENU Button

BACK Button

193

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

Audio/Information Screen

Displays the audio status and wallpaper. From this screen, you can go to various
setup options.

Press the

 (display) button to change the display.

Switching the Display

 (Display) Button

Audio

Trip Computer
(Current Drive)

Clock/Wallpaper

Trip Computer

(History of Trip A)

Audio/Information Screen

194

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

Audio

Shows the current audio information.

Trip computer (Current Drive)

Shows the range, and instant and average fuel economy of the current trip, as well
as the average fuel economy from your last trip.

Trip computer (History of Trip A)

Shows the range, average fuel economy and distance traveled for the current trip,
as well as the average fuel economy and distances traveled during the last three
driving cycles.
Each time you reset the trip meter A, the information on the display updates. The
history of the previous three driving cycles is kept.

Clock/Wallpaper

Shows a clock screen or an image you import.

Continued

195

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

You can change, store, and delete the wallpaper on the audio/information screen.

Import wallpaper

You can import up to three images, one at a time, for wallpaper from a USB flash
drive.

1. Connect the USB flash drive to the USB

port.

USB Port(s

*

) P. 187

2. Press the SETTINGS button.
3. Rotate

 to select System Settings, then

press .

u

Repeat the procedure to select Clock
Clock/Wallpaper Type, then
Wallpaper.

4. Rotate

 to select Add New Wallpaper

then press

.

u

The preview of the imported data is
displayed.

5. Rotate

 to select a desired picture.

u

The preview is displayed on the left side
on the screen.

6. Press

 to save the data.

u

The confirmation message will appear.
Then the display will return to the
wallpaper list.

Wallpaper Setup

1

Wallpaper Setup

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

The file name must be fewer than 64 characters.

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

The individual file size limit is 2 MB.

The maximum image size is 1,680 x 936 pixels. If
the image size is less than 420 × 234 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.

Up to 255 files can be selected.

If the USB flash drive does not have any pictures,
the No files detected message appears.


Add new wallpaper



* Not available on all models

uu

Audio System Basic Operation

u

Audio/Information Screen

196

Features

Select wallpaper

1. Press the SETTINGS button.
2. Rotate

to

select

System Settings, then press

.

u

Repeat the procedure to select ClockClock/Wallpaper Type, then
Wallpaper.

u

The screen changes to the wallpaper list.

3. Rotate

 to select a desired wallpaper, then press

.

u

The pop-up menu appears on the screen.

4. Rotate

to

select

Set, then press

.

Delete wallpaper

1. Press the SETTINGS button.
2. Rotate

to

select

System Settings, then press

.

u

Repeat the procedure to select ClockClock/Wallpaper Type, then
Wallpaper.

u

The screen changes to the wallpaper list.

3. Rotate

 to select a wallpaper that you want to delete, then press

.

u

The pop-up menu appears on the screen.

4. Rotate

to

select

Delete, then press

.

u

The confirmation message will appear.

5. Rotate

to

select

OK, then press

 to delete completely.

1

Wallpaper Setup

From the pop-up menu, rotate

 to select Preview

and press

 to see a preview at full-size screen.

To go back to the previous screen, press

 to select

OK, or press the BACK button.

When the file size is large, it takes a while to be
previewed.

197

uu

Audio System Basic Operation

u

Adjusting the Sound

Features

Adjusting the Sound

1. Press the SETTINGS button.
2. Rotate

 to select Audio Settings, then

press .

3. Rotate

 to select Sound, then press

.

Rotate

 to scroll through the following

choices:

1

Adjusting the Sound

The SVC has four modes: OffLowMid, and High.
SVC adjusts the volume level based on the vehicle
speed. As you go faster, audio volume increases. As
you slow down, audio volume decreases.

Selector Knob

SETTINGS Button

Speed-sensitive
Volume
Compensation

Bass

Treble

Fader

Balance

SVC

198

uu

Audio System Basic Operation

u

Display Setup

Features

Display Setup

You can change the brightness or color theme of the audio/information screen.

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

u

Repeat the procedure to select Display.

3. Rotate

 to select Brightness, then press

.

4. Rotate

 to adjust the setting, then press

.

1. Press the SETTINGS button.
2. Rotate

 to select System Settings, then

press .

u

Repeat the procedure to select Other.

3. Rotate

 to select Background Color

then press

.

4. Rotate

 to select the setting you want,

then press

.

Changing the Screen Brightness

1

Changing the Screen Brightness

You can change the Contrast and Black Level
settings in the same manner.

Changing the Screen’s Color Theme

199

uu

Audio System Basic Operation

u

Playing AM/FM Radio

Continued

Features

Playing AM/FM Radio

Audio/Information Screen

FM/AM Button
Press to select a band.

Preset Buttons (1-6)
To store a station:
Tune to the selected station.
Pick a preset button and hold it until you hear a beep.
To listen to a stored station, select a band, then press the preset button.

Seek/Skip Buttons
Press

 and

 to search up and

down the selected band for a
station with a strong signal.

MENU Button
Press to display the menu items.

Selector Knob
Turn to tune the radio frequency.
Press and turn to select an item,
then press to set your selection.

VOL/

 (Power/volume)

Knob
Press to turn the audio system
on and off.
Turn to adjust the volume.

BACK Button
Press to go back to the
previous display or cancel a
setting.

uu

Audio System Basic Operation

u

Playing AM/FM Radio

200

Features

Provides text data information related to your selected RDS-capable FM station.

To find an RDS station from Station List

1. Press

 while listening to an FM station.

2. Rotate

 to select the station, then press

.

Manual update

Updates your available station list at any time.
1. Press

 while listening to an FM station.

2. Rotate

to

select

Refresh, then press

.

Radio text

Displays the radio text information of the selected RDS station.
1. Press the MENU button.
2. Rotate

to

select

Radio Text, then press

.

Scan

Samples each of the strongest stations on the selected band for 10 seconds.
1. Press the MENU button.
2. Rotate

to

select

Scan, then press

.

To turn off scan, press

 to select Stop, or press the BACK button.

Radio Data System (RDS)

1

Playing AM/FM Radio

The ST indicator appears on the display indicating
stereo FM broadcasts.
Stereo reproduction in AM is not available.

Switching the Audio Mode
Press the SOURCE button on the steering wheel.

Audio Remote Controls P. 190

You can also switch the mode by pressing the MENU
button and selecting Change Source on the MENU
screen.

You can store 6 AM stations and 12 FM stations into
the preset memory.

1

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

201

uu

Audio System Basic Operation

u

Playing a CD

Continued

Features

Playing a CD

Your audio system supports audio CDs, CD-Rs and CD-RWs in either MP3, WMA, or
AAC

*1

 format. With the CD loaded, press the CD button.

*1:Only AAC format files recorded with iTunes are playable on this unit.

Audio/Information Screen

CD Button
Press to play a CD.

Seek/Skip Buttons
Press

 or

 to change tracks

(files in MP3, WMA, or AAC).
Press and hold to move rapidly
within a track/file.

MENU Button
Press to display the menu items.

Selector Knob
Turn to change tracks/folders.
Press and turn to select an item,
then press to set your selection.

VOL/

 (Power/volume)

Knob
Press to turn the audio system
on and off.
Turn to adjust the volume.

BACK Button
Press to go back to the
previous display or cancel a
setting.

CD Slot
Insert a CD about halfway into the
CD slot.

 (CD Eject) Button

Press to eject a CD.

uu

Audio System Basic Operation

u

Playing a CD

202

Features

1. Press the MENU button.
2. Rotate

 to select Music Search, then

press .

3. Rotate

 to select a folder.

4. Press

 to change the display to a list of

files in that folder.

5. Rotate

 to select a file, then press

.

How to Select a File from the Music Search List
(MP3/WMA/AAC)

1

Playing a CD

NOTICE

Do not use CDs with adhesive labels. The label can
cause the CD to jam in the unit.

WMA files protected by digital rights management
(DRM) cannot be played.
The audio system displays Unplayable File, then
skips to the next file.

Text data appears on the display under the following
circumstances:

When you select a new folder, file, or track.

When you change the audio mode to CD.

When you insert a CD.

If you eject the CD but do not remove it from the slot,
the system reloads the CD automatically after several
seconds.

File Selection

Folder Selection

203

uu

Audio System Basic Operation

u

Playing a CD

Features

You can select scan, repeat, and random modes when playing a track or file.

1. Press the MENU button.
2. Rotate

 to select Scan or Random/

Repeat, then press

.

3. Rotate

 to select a mode, then press

.

To turn off a play mode

1. Press the MENU button.
2. Rotate

 to select the mode you want to turn off, then press

.

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Scan
Scan Folders
 (MP3/WMA/AAC): Provides 10-second
sampling of the first file in each of the main folders.
Scan Tracks: Provides 10-second sampling of all
tracks on the CD (all files in the current folder in MP3,
WMA, or AAC).

Random/Repeat
Repeat Folder
 (MP3/WMA/AAC): Repeats all files in
the current folder.
Repeat Track: Repeats the current track/file.
Random in Folder (MP3/WMA/AAC): Plays all files
in the current folder in random order.
Random All Tracks: Plays all tracks/files in random
order.

Random/Repeat
is selected.

204

uu

Audio System Basic Operation

u

Playing an iPod

Features

Playing an iPod

Connect the iPod using your dock connector to the USB Port, then press the AUX
button.

USB Port(s

*

) P. 187

Audio/Information Screen

AUX Button
Press to select iPod (if connected).

Seek/Skip Buttons
Press

 or

 to change songs.

Press and hold to move rapidly
within a song.

MENU Button
Press to display the menu items.

Selector Knob
Turn to change songs.
Press and turn to select an item,
then press to set your selection.

VOL/

 (Power/volume)

Knob
Press to turn the audio system
on and off.
Turn to adjust the volume.

BACK Button
Press to go back to the
previous display or cancel a
setting.

Album Art

USB Indicator
Appears when an iPod is connected.

* Not available on all models

Continued

205

uu

Audio System Basic Operation

u

Playing an iPod

Features

1. Press the MENU button.
2. Rotate

 to select Music Search, then

press .

3. Rotate

 to select a menu.

4. Press

 to display the items on that menu.

5. Rotate

 to select an item, then press

.

How to Select a Song from the Music Search List

1

Playing an iPod

Available operating functions vary on models or
versions. Some functions may not be available on the
vehicle's audio system.

If there is a problem, you may see an error message
on the audio/information screen.

iPod/USB Flash Drive P. 287

uu

Audio System Basic Operation

u

Playing an iPod

206

Features

You can select repeat and shuffle modes when playing a file.

1. Press the MENU button.
2. Rotate

 to select Shuffle/Repeat, then

press .

3. Rotate

 to select a mode, then press

.

To turn off a play mode

1. Press the MENU button.
2. Rotate

 to select the mode you want to turn off, then press

.

How to Select a Play Mode

1

How to Select a Play Mode

Play Mode Menu Items
Repeat Song: Repeats the current file.
Shuffle Album: Plays all available albums in a
selected list (playlists, artists, albums, songs, genres,
or composers) in random order.
Shuffle All Songs: Plays all available files in a
selected list (playlists, artists, albums, songs, genres,
or composers) in random order.

Continued

207

uu

Audio System Basic Operation

u

Playing Internet Radio

Features

Playing Internet Radio

Connect a compatible phone through Bluetooth®.

You can also connect the phone using your dock connector to the USB port.
Press the AUX button to select Pandora mode.

U.S. models

Compatible phones only

1

Playing Internet Radio

Pandora®, the Pandora logo, and the Pandora trade
dress are trademarks or registered trademarks of
Pandora Media, Inc., used with permission. Pandora®,
the Pandora logo, and the Pandora trade dress are
trademarks or registered trademarks of Pandora Media,
Inc. Used with permission. Pandora® is only available in
certain countries. Please visit
http://www.pandora.com/legal for more information.

To find out if your phone is compatible with this
feature, visiwww.handsfreelink.honda.com, or call
1-888-528-7876.

To use this service in your vehicle, the Pandora® app
must first be installed on your phone. Visit
www.pandora.com. for more information.

Pandora® is free personalized radio that offers
effortless and endless music and comedy. Just start
with the name of one of your favorite artists, songs,
genres, composers, or comedians and it will do the
rest.

If you cannot operate Pandora® through the audio
system, it may be streaming through Bluetooth®
Audio. Make sure Pandora® mode on your audio
system is selected.

Changing Stations
To change stations, activate the Pandora® menu,
select Station List, and then select a new station.

iPhone















Content   ..  11  12  13  14   ..
