Honda Accord Sedan (2016 year). Manual - part 5





64

Safe Driving

Exhaust Gas Hazard

Carbon Monoxide Gas

The engine exhaust from this vehicle contains carbon monoxide, a colorless,
odorless, and highly toxic gas. As long as you properly maintain your vehicle, carbon
monoxide gas will not get into the interior.

Have the exhaust system inspected for leaks whenever

• The exhaust system is making an unusual noise.
• The exhaust system may have been damaged.
• The vehicle is raised for an oil change.

When you operate a vehicle with the trunk open, airflow can pull exhaust gas into
the interior and create a hazardous condition. If you must drive with the trunk open,
open all the windows and set the climate control system as shown below.

1. Select the fresh air mode.

2. Select the

 mode.

3. Set the fan speed to high.
4. Set the temperature control to a comfortable setting.

Adjust the climate control system in the same manner if you sit in your parked
vehicle with the engine running.

1

Carbon Monoxide Gas

An enclosed area such as a garage can quickly fill up
with carbon monoxide gas.
Do not run the engine with the garage door closed.
Even when the garage door is open, drive out of the
garage immediately after starting the engine.

3

WARNING

Carbon monoxide gas is toxic.
Breathing it can cause unconsciousness and
even kill you.

Avoid any enclosed areas or activities that
expose you to carbon monoxide.

65

Safe Driving

Safety Labels

Label Locations

These labels are in the locations shown. They warn you of potential hazards that can cause serious injury or death. Read these labels
carefully.

If a label comes off or becomes hard to read (except for the U.S. dashboard label which may be removed by the owner), contact a dealer
for a replacement.

Sun Visor

U.S. models

Canadian models

Radiator Cap

U.S. models only

Dashboard

66

68

In

strum

e

nt Pa

nel

Indicators

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Parking Brake
and Brake
System Indicator
(Red)

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off if the parking

brake has been released.

Comes on when the parking brake
is applied, and goes off when it is
released.

Comes on when the brake fluid
level is low.

Comes on if there is a problem
with the brake system.

The beeper sounds and the
indicator comes on if you drive
with the parking brake not fully
released.

Comes on while driving - Make sure
the parking brake is released. Check the
brake fluid level.

What to do when the indicator

comes on while driving P. 576

Comes on along with the ABS
indicator
- Have your vehicle checked by
a dealer.

If the Brake System Indicator (Red)

Comes On P. 576

Brake System
Indicator
(Amber)

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Comes on if there is a problem
with a system related to braking
other than the conventional brake
system.

Stays on constantly - Have your vehicle
checked by a dealer.

U.S.

Canada

(Red)

U.S.

Canada

(Amber)

* Not available on all models

69

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Low Oil Pressure
Indicator

Comes on when you turn the
ignition switch to ON

(

w

*1

, and

goes off when the engine starts.

Comes on when the engine oil
pressure is low.

Comes on while driving - Immediately
stop in a safe place.

If the Low Oil Pressure Indicator

Comes On P. 574

Malfunction
Indicator Lamp

Comes on when you turn the
ignition switch to ON

(

w

*1

, and

goes off either when the engine
starts or after several seconds if the
engine did not start. If “readiness
codes” have not been set, it blinks
five times before it goes off.

Comes on if there is a problem
with the emissions control system.

Blinks when a misfire in the
engine’s cylinders is detected.

Readiness codes are part of the on board
diagnostics for the emissions control
systems.

Testing of Readiness Codes P. 591

Comes on while driving - Have your
vehicle checked by a dealer.

Blinks while driving - Stop in a safe
place where there are no flammable
objects. Stop the engine for 10 minutes
or more, and wait for it to cool down.
Then, take the vehicle to a dealer.

If the Malfunction Indicator Lamp

Comes On or Blinks P. 575

Charging System
Indicator

Comes on when you turn the
ignition switch to ON

(

w

*1

, and

goes off when the engine starts.

Comes on when the battery is not
charging.

Comes on while driving - Turn off the
climate control system and rear defogger
in order to reduce electricity
consumption.

If the Charging System Indicator

Comes On P. 574

* Not available on all models

70

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

*

Shift Lever
Position
Indicator

*

Indicates the current shift lever
position.

Shifting P. 430432436

M (7-speed
manual shift
mode) Indicator/
Shift Indicator

*

Comes on when 7-speed manual
shift mode is applied.

7-Speed Manual Shift Mode P. 434

Models with
information
display

Models with
multi-
information
display

Models with
information
display

Models with
multi-
information
display

* Not available on all models

71

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Transmission
Indicator

*

Blinks if the transmission system has
a problem.

Blinks while driving - Avoid sudden
starts and acceleration and have your
vehicle checked by a dealer
immediately.

Seat Belt
Reminder
Indicator

Comes on and the beeper sounds if
you are not wearing a seat belt when
you turn the ignition switch to ON

(

w

*1

.

If the front passenger is not wearing
a seat belt, the indicator comes on a
few seconds later.

Blinks while driving if either you or
the front passenger has not fastened
a seat belt. The beeper sounds and
the indicator blinks at regular
intervals.

The beeper stops and the indicator goes
off when you and the front passenger
fasten their seat belts.

Stays on after you or the front
passenger has fastened the seat
belt
 - A detection error may have
occurred in the sensor. Have your
vehicle checked by a dealer.

Seat Belt Reminder P. 33

Models with
information
display

Models with
multi-
information
display

* Not available on all models

72

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Low Fuel
Indicator

Comes on when the fuel reserve is
running low (approximately 2.6 U.S.
gal./9.7 Liter left).

Blinks if there is a problem with the
fuel gauge.

Comes on - Refuel your vehicle as soon
as possible.

Blinks - Have your vehicle checked by a
dealer.

Anti-lock Brake
System (ABS
Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

If it comes on at any other time,
there is a problem with the ABS.

Stays on constantly - Have your
vehicle checked by a dealer. With this
indicator on, your vehicle still has
normal braking ability but no anti-lock
function.

Anti-lock Brake System (ABS)

P. 481

Supplemental
Restraint System
Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Comes on if a problem with any of
the following is detected:
- Supplemental restraint system
- Side airbag system
- Side curtain airbag system
- Seat belt tensioner

Stays on constantly or does not
come on at all
 - Have your vehicle
checked by a dealer.

* Not available on all models

73

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Vehicle Stability
Assist (VSA®)
System Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Blinks when VSA® is active.

Comes on if there is a problem with
the VSA® system or hill start assist
system.

Stays on constantly - Have your
vehicle checked by a dealer.

Vehicle Stability Assist (VSA®), aka

Electronic Stability Control (ESC),
System
 P. 471

Vehicle Stability
Assist (VSA®) OFF
Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Comes on when you deactivate
VSA®.

VSA® OFF Button P. 472

* Not available on all models

74

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Door and Trunk
Open Indicator

Comes on for a few seconds if you
turn the ignition switch to ON

(

w

*1

then goes off.

Comes on if any door or the trunk is
not completely closed.

The beeper sounds and the indicator
comes on if any door or the trunk is
opened while driving.

Goes off when all doors and the trunk
are closed.

Parking Sensor
System Indicator

*

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Comes on if there is a problem with
the parking sensor system.

Check if the area around the sensor(s) is
covered with mud, ice, snow, etc. If the
indicator stays on even after you clean
the area, have the system checked by a
dealer.

Electric Power
Steering (EPS)
System Indicator

Comes on when you turn the
ignition switch to ON

(

w

*1

, and goes

off when the engine starts.

Comes on if there is a problem with
the EPS system.

Stays on constantly or does not
come on at all
 - Have your vehicle
checked by a dealer.

If the Electric Power Steering (EPS)

System Indicator Comes On P. 576

Models with
information
display

Models with
multi-
information
display

* Not available on all models

75

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Low Tire
Pressure/
TPMS
Indicator

Comes on for a few seconds when you
turn the ignition switch to ON

(

w

*1

, then

goes off.

May come on briefly if the ignition switch
is turned to ON

(

w

*1

 and the vehicle is not

moved within 45 seconds, to indicate the
calibration process is not yet complete.

Comes on and stays on when:
- One or more tires’ pressures are

determined to be significantly low.

- The system has not been calibrated.

Comes on while driving - Stop in a
safe place, check tire pressures, and
inflate the tire(s) if necessary.

Stays on after the tires are inflated
to the recommended pressures
 - The
system needs to be calibrated.

TPMS Calibration P. 475

Blinks for about one minute, and then
stays on if there is a problem with the
TPMS, or when a compact spare tire is
temporarily installed.

Blinks and remains on - Have your
vehicle checked by a dealer. If the
vehicle is fitted with a compact spare,
get your regular tire repaired or
replaced and put back on your vehicle
as soon as you can.

* Not available on all models

76

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

System
Message
Indicator

*

Comes on for a few seconds when you
turn the ignition switch to ON

(

w

*1

, then

goes off.

Comes on along with a beep when a
problem is detected. A system message on
the multi-information display appears at
the same time.

While the indicator is on, press the

 (information) button to see the

message again.

Refer to the Indicators information in
this chapter when a system message
appears on the multi-information
display. Take the appropriate action for
the message.

The multi-information display does not
return to the normal screen unless the

warning is canceled, or the



button is pressed.

Turn Signal
and Hazard
Warning
Indicators

Blinks when you operate the turn signal
lever.

Blink along with all turn signals when you
press the hazard warning button.

Does not blink or blinks rapidly - A
turn signal light bulb has blown.
Change the bulb immediately.

Replacing Light Bulbs P. 531, 533,

534

High Beam
Indicator

Comes on when the high beam headlights
are on.

Lights On
Indicator

Comes on whenever the light switch is on,
or in AUTO when the exterior lights are
on.

If you remove the key from the ignition
switch

*1

 while the exterior lights are on,

a chime sounds when the driver's door
is opened.

* Not available on all models

77

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Fog Light
Indicator

*

Comes on when the fog lights are
on.

Immobilizer
System Indicator

Comes on briefly when you turn the
ignition switch to ON

(

w

*1

, then

goes off.

Comes on if the immobilizer system
cannot recognize the key
information.

Blinks - You cannot start the engine.
Turn the ignition switch to LOCK

(

0

*1

pull the key out, and then insert the key
and turn it to ON

(

w

*1

 again.

Repeatedly blinks - The system may
be malfunctioning. Have your vehicle
checked by a dealer.

Do not attempt to alter this system or
add other devices to it. Electrical
problems can occur.

Security System
Alarm Indicator

Blinks when the security system
alarm has been set.

Security System Alarm P. 132

Indicator

* Not available on all models

78

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

ECON Mode
Indicator

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Comes on when you press the
ECON button.

ECON Button P. 441

CRUISE MAIN
Indicator

*

Comes on when you press the
CRUISE button.

Cruise Control P. 442

CRUISE
CONTROL

Indicator

*

Comes on if you have set a speed for
cruise control.

Cruise Control P. 442

Washer Level
Indicator

*

Comes on when the washer fluid
gets low.

Refill the washer fluid.

Refilling Window Washer Fluid

P. 528

Maintenance
Minder Indicator

*

Comes on when the scheduled
maintenance is due soon.

Maintenance Minder

TM

 P. 505

* Not available on all models

79

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

*

Smart Entry
System
Indicator

*

Comes on for a few seconds when
you change the power mode to ON.

Comes on as soon as a problem is
detected in the smart entry system
or push button starting system.

Stays on constantly or does not come
on at all
 - Have your vehicle checked by a
dealer.

Starter System
Indicator

*

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

Comes on if the starter system has a
problem.

As a temporary measure, press and hold
the ENGINE START/STOP button for up to
15 seconds while pressing the brake pedal
and manually start the engine. Have your
vehicle checked by a dealer.

Light Control
Indicator

*

Comes on if there is a problem with
the automatic lighting control
system or low beam headlights

*

.

Comes on while driving - Turn the lights
on manually and have your vehicle checked
by a dealer.

U.S.

Canada

* Not available on all models















Content   ..  3  4  5  6   ..
