You can also adjust the clock by touching the clock
displayed on the upper right corner of the display or
the Clock icon on the home screen.
1. Touch the clock on the display.

The clock screen of the select face-type appears.

2. Select Settings.
3. Select Date & Time.
4. Select Set Date & Time.
5. Select Automatic Date & Time, then select OFF.
6. Select Set Date or Set Time.
7. Adjusting the dates, hours and minutes by

selecting /

8. Select Save to set the time.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2 Customized Features P. 378

You can customize the date display to MM/DD/
YYYY, DD/MM/YYYY or YYYY/MM/DD.

2 Customized Features P. 378

Models with Display Audio

3 4

Models with Display Audio

3 4

166

Co
ntrols

Locking and Unlocking the Doors

Key Type and Functions

This vehicle comes with the following key:

Use the keys to turn on and off the power
system, and to lock and unlock all the doors,
fuel fill door and to open the trunk. You can
also use the smart entry system to lock and
unlock all the doors, fuel fill door and to open
the trunk.

The built-in key can be used to lock/unlock the
doors when the smart entry remote battery
becomes weak and the power door lock/
unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
smart entry remote until it clicks.

Key Type and Functions

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

2 Immobilizer System P. 181

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust and sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the power
system may not activate, and the remote transmitter
may not work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely turn the power system on using the
remote engine start.

2 Remote Engine Start with Vehicle

Feedback P. 460

■

Built-in Key

Built-in Key

Release Knob

167

Locking and Unlocking the Doors

Low Smart Entry Remote Signal Strength

Co
ntrols

Contains a number that you will need if you
purchase a replacement key.

Low Smart Entry Remote Signal Strength

The vehicle transmits radio waves to locate the smart entry remote when locking/
unlocking the doors, and fuel fill door, opening the trunk, or to activate the power
system.

In the following cases, locking/unlocking the doors, and fuel fill door, opening the
trunk, or activating the power system may be inhibited or operation may be
unstable:
• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the smart entry remote together with telecommunications

equipment, laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the smart entry remote.

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot activate the
power system, contact a dealer.

Low Smart Entry Remote Signal Strength

Communication between the smart entry remote and
the vehicle consumes the smart entry remote’s
battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the smart entry
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

168

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the smart entry remote, you
can lock/unlock the doors, fuel fill door and
open the trunk.
You can lock/unlock the doors and fuel fill
door within a radius of about 32 inches (80
cm) of the outside door handle. You can open
the trunk within about 32 inches (80 cm)
radius from the trunk release button.

■

Locking the doors and the trunk

Touch the door lock sensor on the front door.

Some exterior lights flash; the beeper
sounds; all the doors and trunk lock; and
the security system sets.

■

Using the Smart Entry with Push Button Start System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior lights come on when you unlock
the doors.
No doors opened: The light fades out after 30
seconds.
Doors relocked: The light goes off immediately.

2 Interior Lights P. 217

Using the Smart Entry with Push Button Start System

If you do not open a door within 30 seconds of
unlocking the vehicle with the smart entry system,
the doors and trunk will automatically relock.

You can lock or unlock doors using the smart entry
system only when the power mode is in VEHICLE OFF.

•

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

•

Even if you are not carrying the smart entry remote,
you can lock/unlock the doors while someone else
with the remote is within range.

•

The door may be locked or unlocked if the door
handle is covered with water in heavy rain or in a
car wash if the smart entry remote is within range.

•

If you grip a front door handle or touch a door lock
sensor wearing gloves, the door sensor may be
slow to respond or may not respond by locking or
unlocking the doors.

•

After locking the door, you have up to two seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least two seconds before gripping the handle,
otherwise the door will not unlock.

Door Lock
Sensor

Continued

169

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Unlocking the doors and the trunk

Grab the driver’s door handle:

The driver’s door and fuel fill door
unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

All the doors unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the trunk release button:

The trunk unlocks and opens.

Some exterior lights flash and the beeper
sounds.

2 Using the Trunk Release Button P. 179

Using the Smart Entry with Push Button Start System

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors with the smart
entry remote if it is above or below the outside
handle.

•

The smart entry remote may not operate if it is too
close to the door and door glass.

The light flash, beep and door unlock mode settings
can be customized using the audio/information
screen.

2 Customized Features P. 367, 378

Trunk Release
Button

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

170

Co
ntrols

■

Locking the doors and trunk (Walk
away auto lock®)

When you walk away from the vehicle while
carrying the smart entry remote, the doors will
automatically lock.
The auto lock function activates when all
doors are closed, and the smart entry remote
is within about 5 feet (1.5 m) radius of the
outside door handle.
Exit vehicle while carrying smart entry remote
and close door(s).
1. While within about 5 feet (1.5 m) radius of

the vehicle.

The beeper sounds; the auto lock
function will be activated.

2. Carry the smart entry remote beyond about

5 feet (1.5 m) from the vehicle and remain
outside this range for 2 or more seconds.

Some exterior lights flash; the beeper
sounds; all doors will then lock.

Locking the doors and trunk (Walk away auto lock®)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the audio/information screen.
If you set the auto lock function to ON using the
audio/information screen, only the smart entry
remote that was used to unlock the driver’s door
prior to the setting change can activate auto lock.

2 Customized Features P. 367, 378

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the smart entry
remote will continue to flash until the doors are
locked.

When you stay beside the vehicle within the
operation range, the doors will automatically lock
approximately 30 seconds after the auto lock
function activating beeper sounds.

When you open a door after the auto lock function
activating beeper sounds, the auto lock function will
be delayed until all doors are closed.

Under the following circumstances, the auto-lock
function will not activate:

•

The smart entry remote is inside the vehicle.

The beeper will not sound.

•

The remote is taken out of its operational range
before all the doors are closed.

The beeper will sound.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

Continued

171

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

To temporarily deactivate the function:
1. Set the power mode to OFF.
2. Open the driver’s door.
3. Using the master door lock switch, operate

the lock as follows:
Lock

Unlock

Lock

Unlock.

The beeper sounds and the function is
deactivated.

To restore the function:
• Set the power mode to ON.
• Lock the vehicle without using the auto lock

function.

• With the smart entry remote on you, move

out of the auto lock function operation
range.

• Open any door.

Locking the doors and trunk (Walk away auto lock®)

The auto lock function does not operate when any of
the following conditions are met.

•

The smart entry remote is inside the vehicle.

•

A door or the hood is not closed.

•

The power mode is set to any mode other than
OFF.

•

The smart entry remote is not located within a
radius of about 5 feet (1.5 m) from the vehicle
when you get out of the vehicle and close the
doors.

Auto lock function operation stop beeper
After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

•

The smart entry remote is put inside the vehicle
through a window.

•

You are located too close to the vehicle.

•

The smart entry remote is put inside the trunk.

If the warning beeper sounds, check that you are
carrying the smart entry remote. Then, open/close a
door and confirm the auto lock activation beeper
sounds once.

In the case that the smart entry remote is out of
operating range when you close a door or the trunk,
a beeper will sound to indicate that the auto lock
function has been canceled.

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

172

Co
ntrols

■

Locking the doors

Press the lock button.
Once:

Some exterior lights flash, all the doors
and fuel fill door lock, and the security
system sets.

Twice (within five seconds after the first
push):

The beeper sounds and verifies the
security system is set.

■

Unlocking the doors

Press the unlock button.
Once:

Some exterior lights flash twice, and the
driver’s door and fuel fill door unlocks.

Twice:

The remaining doors unlock.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door within 30 seconds of
unlocking the vehicle with the remote transmitter,
the doors will automatically relock.
You can change the relock timer setting.

2 Customized Features P. 367, 378

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

You can lock or unlock doors using the remote
transmitter only when the power mode in VEHICLE
OFF.

The remote will not lock the vehicle when a door is
open.

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

2 Replacing the Button Battery P. 613

You can customize the door unlock mode setting.

2 Customized Features P. 367, 378

LED

Unlock Button

Lock
Button

173

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

If the lock or unlock button of the remote
does not work, use the key instead.

Fully insert the key and turn it.

If you do not have the key on you, or if for
some reason you cannot lock a door using the
key, you can lock the door without it.

■

Locking the front doors

Push the lock tab forward

or push the

master door lock switch in the lock direction

, and close the door.

■

Locking the rear doors

Push the lock tab forward and close the door.

■

Lockout prevention system

The doors cannot be locked when the smart entry remote is inside the vehicle.

■

Locking/Unlocking the Doors Using a Key

Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, all the
other doors lock at the same time. When unlocking,
the driver’s door unlocks first. Turn the key a second
time within a few seconds to unlock the remaining
doors.

You can customize the door unlock mode setting.

2 Customized Features P. 367, 378

Lock

Unlock

■

Locking a Door Without Using a Key

Locking a Door Without Using a Key

When you lock the driver’s door, all the other doors
lock at the same time.
Before locking a door, make sure that the key is not
inside the vehicle.

174

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Inside

Co
ntrols

Locking/Unlocking the Doors from the Inside

■

Locking a door

Push the lock tab forward.

■

Unlocking a door

Pull the lock tab rearward.

■

Using the Lock Tab

Using the Lock Tab

When you lock the door using the lock tab on the
driver’s door, all the other doors and the fuel fill door
lock at the same time.
When you unlock the door using the lock tab on the
driver’s door, only the driver’s door will unlock.

To Unlock

Lock Tab

To Lock

Continued

175

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Inside

Co
ntrols

Pull the front door inner handle.

The door unlocks and opens in one
motion.

Unlocking and opening the driver’s door from the inner handle unlocks all the other
doors and fuel fill door.

To avoid all the doors to be unlocked, use the lock tab on the driver’s door to unlock,
then lock again before opening the door.

This setting works for one time only. If you do not want all the doors to be
unlocked all the time, customize the Auto Door Unlock setting to Off

/OFF

using the audio/information screen.

2 Customized Features P. 367, 378

*1: Models with color audio
*2: Models with Display Audio

■

Unlocking Using the Front Door Inner Handle

Unlocking Using the Front Door Inner Handle

The front door inner handles are designed to allow
front seat occupants to open the door in one motion.
However, this feature requires that front seat
occupants never pull a front door inner handle while
the vehicle is in motion.

Children should always ride in a rear seat where
childproof door locks are provided.

2 Childproof Door Locks P. 176

Inner Handle

Content .. 9 10 11 12 ..
