Honda Accord Hybrid (2019 year). Manual

Quick

Referenc

e Guide

Eco Assist® System

(P 475)

Range

200

miies

Ambient Meter

With SPORT mode off, the
color of the ambient meter
changes to green to indicate
that the vehicle is being driven
in a fuel efficient manner.

ECON Button

(P 475)

Helps maximize fuel economy.

ECON Mode Indicator

(P 100)

Comes on when the ECON button is
pressed.

The message is
displayed for a few
seconds when the
ECON button is
pressed.

Ambient Meter

*1 : Models without adaptive damper system
*2 : Models with adaptive damper system

Quick

Referenc

e Guide

Drive Cycle Score/Lifetime Points

● Comes on when the power mode is in VEHICLE OFF.

Eco Drive Display

(P154)

● Keep the vehicle icon near the center of the circle.

Aggressive
Deceleration

Fuel economy is:

Best

Drive Cycle
Score

Lifetime Points

Worse

Better

Moderate
Deceleration

Slow Acceleration/
Deceleration

Aggressive
Acceleration

Moderate
Acceleration

Quick

Referenc

e Guide

Safe Driving

(P 37)

Airbags

(P 49)

● Your vehicle is fitted with airbags to help protect you and

your passengers during a moderate-to-severe collision.

Child Safety

(P 65)

● All children 12 and younger should be seated in the rear seat.

● Smaller children should be properly restrained in a forward-facing child seat.

● Infants must be properly restrained in a rear-facing child seat.

Exhaust Gas Hazard

(P 78)

● Your vehicle emits dangerous exhaust gases that contain carbon

monoxide. Do not run the engine in confined spaces where carbon
monoxide gas can accumulate.

Before Driving Checklist

(P 41)

● Before driving, check that the front seats, head

restraints, steering wheel, and mirrors have been
properly adjusted.

Seat Belts

(P 42)

● Fasten your seat belt and sit upright well

back in the seat.

● Check that your passengers are wearing

their seat belts correctly.

Fasten your lap belt as
low as possible.

Quick

Referenc

e Guide

Instrument Panel

(P 81)

Indicators

(P 82)

/Driver Information Interface

(P 135)

/Gauges

(P 133)

Head-Up Display

(P 157)

Speedometer

Fuel Gauge

Driver Information Interface

High Voltage Battery
Charge Level Gauge

POWER/CHARGE Gauge

Head-Up Display

Immobilizer System Indicator/
Security System Alarm Indicator

Shift Position Indicator/
Transmission System Indicator

Deceleration Paddle Selector
Indicator

* Not available on all models

Quick

Referenc

e Guide

Controls

(P 163)

Clock

(P 164)

Press and hold the MENU/CLOCK
button.

Rotate

to change hour, then press

Rotate

to change minute, then

press .

Select Set, then press

These indications are used to show how to
operate the selector knob.

•

Rotate

to select.

•

Press

to enter.

Models with color audio

To adjust time

To adjust date

Press the

(HOME) button, then

select Settings.

Select System, then Day & Time.

Select Set Date & Time.

Select Automatic Date & Time, then
select OFF.

Select Set Date or Set Time.

Adjust the dates, hours and minutes by
selecting /

Select Save to set the date or time.

Models with Display Audio

3 4

The navigation system receives signals from
GPS satellites, updating the clock
automatically.

POWER Button

(P 188)

Press the button to change the vehicle’s
power mode.

Models with navigation system

Quick

Referenc

e Guide

Turn Signals

(P 191)

Lights

(P 191)

Turn Signal Control Lever

Right

Left

Light Control Switches

Low Beam

High Beam

Flashing

Wipers and Washers

(P 198)

*1:Models with automatic intermittent

wipers

*2:Models without automatic intermittent

wipers

Wiper/Washer Control Lever

Adjustment Ring

(

-: Low Sensitivity

(

- : Lower speed, fewer sweeps

(

+: High Sensitivity

(

: Higher speed, more sweeps

MIST
OFF
AUTO

: Wiper speed varies automatically

INT

: Low speed with intermittent

LO: Low speed wipe
HI: High speed wipe

Pull toward
you to spray
washer fluid.

AUTO should always be turned OFF before
the following situations in order to prevent
severe damage to the wiper system:
● Cleaning the windshield

● Driving through a car wash

● No rain

Steering Wheel

(P 205)

● To adjust, push the adjustment lever

down, adjust to the desired position, then
lock the lever back in place.

Models with automatic intermittent wipers

To lock

To adjust

Quick

Referenc

e Guide

Unlocking the Front
Doors from the Inside

(P 175)
● Pull either front door inner handle to

unlock and open it at the same time.

● Unlocking and opening the driver’s door

from the inner handle unlocks all the
other doors and fuel fill door.

Trunk

(P 178)

● Press and hold the trunk opener on the

driver’s door unlocks and opens the
trunk.

● Press the trunk release button on the

smart entry remote to unlock and open
the trunk.

● Press the trunk release button on the

trunk lid to unlock and open the trunk.

Power Door Mirrors

(P 207)
● With the power mode in ON, move the

selector switch to L or R.

● Push the appropriate edge of the

adjustment switch to adjust the mirror.

Trunk Opener

Selector Switch

Adjustment Switch

Power Windows

(P 184)

● With the power mode in ON, open and

close the power windows.

● If the power window lock button is in the

off position, each passenger’s window
can be opened and closed with its own
switch.

● If the power window lock button is in the

on position (indicator on), each
passenger’s window switch is disabled.

Power Window
Lock Button

Window
Switch

Indicator

Quick

Referenc

e Guide

Climate Control System

(P 232)

● Press the AUTO button to activate the climate control system.

● Press the

button to turn the system on or off.

● Press the button to defrost the windshield.

Driver’s Side
Temperature Control
Dial

(Windshield Defroster) Button

SYNC (Synchronization) Button

Floor and
defroster
vents

Floor vents

Dashboard and floor
vents, and back of
the center console

Dashboard vents
and back of the
center console

AUTO Button

(On/Off) Button

(Recirculation) Button

MODE Control Button

Fan Control Dial

A/C (Air Conditioning) Button

Passenger’s Side
Temperature Control
Dial

* Not available on all models

Quick

Referenc

e Guide

Features

(P 237)

Audio Remote Controls

(P 242)

● VOL

(

+/VOL

(

- (Volume) Buttons

Press to adjust the volume up/down.

● SOURCE Button

Press to change the audio mode:
FM1FM2AMUSB/
iPodPandora®Bluetooth® Audio.

●

(Seek/Skip) Buttons

Radio: Press

to change the

preset station.

iPod, USB device, or Bluetooth® Audio:

Press

to skip to the

beginning of the next song or
return to the beginning of the
current song.

USB device or Bluetooth® Audio:

Press and hold

change a folder/group.

Models with color audio

(Seek/

Skip) Buttons

SOURCE
Button

VOL

(

+/VOL

(

- (Volume) Buttons

● VOL

(

+/VOL

(

- (Volume) Buttons

Press to adjust the volume up/down.

● Left Selector Wheel

When selecting the audio mode
Press the

(home) button, then roll up

or down to select Audio on the driver
information interface, and then press the
left selector wheel.

Models with Display Audio

(Seek/

Skip) Buttons

Left Selector
Wheel

VOL

(

+/VOL

(

- (Volume) Buttons

(home) Button

SiriusXM®

USB1

USB2

Bluetooth® Audio

Smartphone Connection

(Apple CarPlay/Android Auto)

Roll up or down: To cycle through the
audio modes, roll up or down and then
press the left selector wheel:

Quick

Referenc

e Guide

●

(Seek/Skip) Buttons

Radio: Press

to change the

preset station.

iPod, USB device, Bluetooth® Audio or
Smartphone Connection:

Press

to skip to the

beginning of the next song or
return to the beginning of the
current song.

USB device:

Press and hold

change a folder.

* Not available on all models

Quick

Referenc

e Guide

Audio System

(P 246, 267)

(P 246)

Models with color audio

(Seek/Skip) Button

Selector Knob

(Day/Night) Button

VOL/

(Volume/Power) Knob

RADIO Button

(Sound) Button

Preset Buttons (1-6)

(Seek/Skip) Button

MEDIA Button

MENU/CLOCK Button

(Phone) Button

(Back) Button

Audio/Information Screen

Quick

Referenc

e Guide

(Home) Button

(Audio) Button

(Back) Button

Audio/Information Screen

(P267)

For navigation system operation

() See the Navigation System Manual

Models with Display Audio

(Phone) Button

(Day/Night) Button

(Seek/Skip) Button
(Seek/Skip) Button

VOL/

(Volume/Power)

Knob

Selector Knob

SOURCE Button

(Clock) Button

(Map) Button

* Not available on all models

Quick

Referenc

e Guide

Driving

(P 451)

Transmission

(P 464)

● Select

(

P and depress the brake pedal when turning on the power.

● Shift selection

Park
Press the

(

P button.

Used when parking or before turning the power on or off.
Transmission is locked.

Reverse
Press back the

(

R button.

Used when reversing.

Neutral
Press the

(

N button.

Transmission is not locked.

Drive
Press the

(

D button.

Used for normal driving.
The deceleration paddle selector can be used temporarily.
The deceleration paddle selector can be used when SPORT mode is on.

Shift Position Indicator
The shift position indicator
and the shift button indicator
indicate the current shift
selection.

Shift Position Indicator

Shift Button
Indicator

READY Indicator
On: You can start to drive.

Quick

Referenc

e Guide

Deceleration Paddle Selector

(P472)

When you release the accelerator pedal, you can control the rate of
deceleration without removing your hands from the steering wheel. Using
the deceleration paddle selector situated on the steering wheel, you can
sequentially shift through four stages of deceleration.
Pull the

(

+ selector for a few seconds when you want to cancel the

deceleration paddle selector.
● When SPORT mode is OFF

If you pull back the paddle selector, the rate of deceleration will change
temporarily, and the stage will appear in the instrument panel.

● When SPORT mode is ON

If you pull back the paddle selector, the rate of deceleration will change
and the stage along with M will appear in the instrument panel.

(

- Paddle

Selector

(

+ Paddle

Selector

Deceleration
stage

When SPORT
mode is OFF,
the
deceleration
stage appears.

When SPORT
mode is ON, the
deceleration
stage and M
appear.

Quick

Referenc

e Guide

VSA® On and Off

(P 478)

● The Vehicle Stability Assist® (VSA®) system

helps stabilize the vehicle during
cornering, and helps maintain traction
while accelerating on loose or slippery
road surfaces.

● VSA® comes on automatically every time

you turn on the power system.

● To partially disable or fully restore VSA®

function, press and hold the button until
you hear a beep.

CMBS

On and Off

(P 497)
● When a possible collision is likely

unavoidable, the CMBS

can help you to

reduce the vehicle speed and the severity
of the collision.

● CMBS

comes on automatically every

time you turn on the power system.

● To turn the CMBS

on or off, use the

safety support switch.

Tire Pressure Monitoring
System (TPMS)

(P 480)

● Detects a change in tire conditions and

overall dimensions due to decrease in tire
pressures.

● The TPMS is turned on automatically

every time you turn on the power system.

● A calibration procedure must be

performed when certain conditions arise.

Refueling

(P 563)

Fuel recommendation:

Unleaded gasoline, pump octane number 87 or higher

Fuel tank capacity: 12.81 US gal (48.5 L)

Unlock the driver’s
door using the
master door lock
switch.

2 Using the Master

Door Lock Switch
(P176)

Press on the edge of
the fuel fill door to
make it pop up
slightly.

After refueling, wait
for about five
seconds before
removing the filler
nozzle.

Quick

Referenc

e Guide

Honda Sensing®

(P 491)

Honda Sensing® is a driver support system
which employs the use of two distinctly
different kinds of sensors, a radar sensor
located at the lower part of the front
bumper and a front sensor camera mounted
to the interior side of the windshield,
behind the rearview mirror.

Front Sensor
Camera

The camera is located
behind the rearview
mirror.

Radar Sensor

The radar sensor is at
the lower part of the
front bumper.

Collision Mitigation
Braking System

(CMBS

)

(P 494)

Can assist you when there is a possibility of
your vehicle colliding with a vehicle or a
pedestrian detected in front of yours. The
CMBS

is designed to alert you when a

potential collision is determined, as well as
to reduce your vehicle speed to help
minimize collision severity when a collision is
deemed unavoidable.

Adaptive Cruise Control
(ACC) with Low Speed
Follow (LSF)

(P 503)

Helps maintain a constant vehicle speed and
a set following interval behind a vehicle
detected ahead of yours and, if the detected
vehicle comes to a stop, can decelerate and
stop your vehicle, without you having to
keep your foot on the brake or the
accelerator.

Lane Keeping Assist
System (LKAS)

(P 519)

Provides steering input to help keep the
vehicle in the middle of a detected lane and
provides tactile and visual alerts if the
vehicle is detected drifting out of its lane.

Road Departure
Mitigation (RDM) System

(P 527)

Alerts and helps to assist you when the
system detects a possibility of your vehicle
unintentionally crossing over detected lane
markings and/or leaving the roadway
altogether.

Traffic Sign Recognition
System

(P531)

Reminds you of road sign information, such
as the current speed limit, your vehicle has
just passed through, showing it on the
driver information interface and the head-
up display

* Not available on all models

Honda Accord Hybrid (2019 year). Manual - part 2
