Table 34. Rear Fuel Injector [85]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
A
R/GN
System power
B
GY/Y
Front fuel injector
Figure 34. Rear Fuel Injector [85]
Table 35. ET Sensor [90]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
GN
ET sensor
2
BK/W
5V sensor ground
Figure 35. ET Sensor [90]
Table 36. DLC [91]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
W/R
CAN high
2
BK
Ground
3
W/BK
CAN low
4
-
N/C
5
R/Y
Accessory power
6
-
N/C
Figure 36. DLC [91]
Table 37. Stop Tail Lamp [94]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
-
N/C
2
BE/BN
Right rear turn signal
3
BE
Running lights power
4
BE/R
Brake lamp power
5
BE/V
Left rear turn signal
6
BK
Ground
Figure 37. Stop Tail Lamp [94]
Table 38. Purge Solenoid [95]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
A
R/GN
System power
B
LGN/BK
Purge solenoid
Figure 38. Purge Solenoid [95]
Table 39. Tachometer [108]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
-
N/C
2
W/R
CAN +
3
-
N/C
4
-
N/C
5
R/O
Battery power
6
-
N/C
7
BK/GN
Ground
8
W/BK
CAN -
9
-
N/C
10
-
N/C
11
-
N/C
12
-
N/C
Figure 39. Tachometer [108] Table
40. Oil Pressure Switch [120]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
BK/W
5V sensor ground
2
R/W
5V sensor power
3
W/O
Oil pressure
Figure 40. Oil Pressure Switch [120] Table
41. Rear Brake Switch [121-1] [121-2]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
BE/GN
Rear brake switch
1
BK
Ground
Figure 41. Rear Brake Switch [121-1] [121-2]
Table 42. Horn [122-1] [122-2]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/V
Horn power
1
BK
Ground
Figure 42. Horn [122-1] [122-2]
Table 43. Starter Solenoid [128]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/BK
Starter solenoid power
Figure 43. Starter Solenoid [128] Table
44. Neutral Switch [131-1] [131-2]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
W
Neutral switch input
1
BK
Ground
Figure 44. Neutral Switch [131-1] [131-2]
Table 45. Jiffy Stand [133]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/W
5 Volt sensor power
2
LGN/GY
JSS signal
3
BK/GN
Sensor ground
Figure 45. Jiffy Stand [133]
Table 46. HO2S Rear [137]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
V/GN
Fuse system power
2
BK/PK
Rear HO2S heater ground
3
GY/BN
Rear HO2S
4
BK/W
5 Volt sensor ground
Figure 46. HO2S Rear [137]
Table 47. HO2S Front [138]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
V/GN
Fuse system power
2
BK/O
Front HO2S heater ground
3
GN/BN
Front HO2S
4
BK/W
5 Volt sensor ground
Figure 47. HO2S Front [138]
Table 48. Fuel Pump [141]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/BN
Fuel pump power
2
W/Y
Fuel level sender
3
BK/W
5V sensor ground
4
BK
Ground
Figure 48. Fuel Pump [141]
Table 49. Security Siren (Optional) [142]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/O
Power
2
W/GN
Security siren
3
BK
Ground
Figure 49. Security Siren (Optional) [142]
Table 50. Engine Harness [145]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/O
Battery power
2
R/GN
System power
3
W/R
CAN +
4
W/BK
CAN -
5
BK/GN
Ground
Figure 50. Engine Harness [145]
Table 51. ABS [166]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
BK/GN
Ground
2
W/R
CAN high
3
O/BK
Front WSS low
4
BE/BK
Switched aux lamp PWR
5
-
N/C
6
-
N/C
7
-
N/C
8
-
N/C
9
R
Battery power
10
BK
Ground
11
W/BK
CAN low
12
O/BE
Front WSS high
13
O/PK
Rear WSS high
14
O/BN
Rear WSS low
15
-
N/C
16
-
N/C
17
-
N/C
18
R
Battery power
Figure 51. ABS [166]
Table 52. Front WSS [167]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
O/BE
Front WSS high
2
O/BK
Front WSS low
Figure 52. Front WSS [167]
Table 53. Rear WSS [168]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
O/PK
Rear WSS high
2
O/BN
Rear WSS low
Figure 53. Rear WSS [168]
Table 54. ACR [203]
TERMINAL WIRE COLOR CIRCUIT DESCRIPTION
1
R/GN
System power
2
LGN/R
ACR enable
Figure 54. ACR [203]
Table 55. TGS [204A]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/W
5V sensor power 1
2
GN/W
TGS 1
3
BK/W
5V sensor ground 1
4
R/GY
5V sensor power 2
5
GY/W
TGS 2
6
BK/GY
5V sensor ground 2
Figure 55. TGS [204]
Table 56. TGS [204B]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R
5V sensor power 1
2
W
TGS 1
3
BK
5V sensor ground 1
4
R
5V sensor power 2
5
W
TGS 2
6
BK
5V sensor ground 2
Figure 56. TGS [204B]
Table 57. Security Antenna [209]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R
Security antenna high
2
BK
Security antenna low
Figure 57. Security Antenna [209]
Table 58. TCA [211]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
A
GY/O
ETC low
B
BK/W
5V sensor ground 1
C
GN/V
TPS 1
D
R/W
5V sensor power 1
E
GY/V
TPS 2
F
GN/O
ETC high
Figure 58. TCA [211]
Table 59. BCM [242]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
A1
-
N/C
A2
R
Security antenna high
A3
-
N/C
A4
BK
Security RF antenna
B1
-
N/C
B2
BK
Security antenna low
B3
-
N/C
B4
-
N/C
C1
-
N/C
C2
-
N/C
C3
-
N/C
C4
W/GY
Engine stop switch input
D1
-
N/C
D2
W/R
CAN high
D3
W
Neutral switch input
D4
-
N/C
E1
-
N/C
E2
W/BK
CAN low
E3
W/O
Oil pressure switch input
E4
R/V
Horn power
F1
-
N/C
F2
-
N/C
F3
BE/GN
Brake switch input
F4
R/BN
Fuel pump power
G1
-
N/C
G2
O/W
ABS wake
G3
-
N/C
G4
BK/GN
Sensor ground
H1
-
N/C
H2
W/GN
Security siren
H3
-
N/C
H4
-
N/C
J1
-
N/C
J2
BE/O
Right front turn signal
J3
BE
Running lights
J4
BE/PK
Left front turn signal
K1
-
N/C
K2
BE/BN
Right rear turn signal
K3
BE/R
Brake lamp power
K4
BE/V
Left rear turn signal
L1
-
N/C
L2
R/BK
Starter solenoid power
L3
R/GN
System power
L4
BE/BK
Front running/Fog light power
M1
-
N/C
M2
R/Y
Accessory power
M3
BE/W
High beam power
M4
BE/Y
Low beam power
Figure 59. BCM [242]
Table 60. BCM Power [259]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R
Battery power
Figure 60. BCM Power [259]
Table 61. USB Interconnect [264]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/Y
Accessory power
2
BK
Ground
Figure 61. USB Interconnect [264]
Table 62. Battery Tender [281]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R
Battery power
2
BK
Ground
Figure 62. Battery Tender [281]
Table 63. Front Knock Sensor [315]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
LGN/W
Front knock sensor LO
2
BN/W
Front knock sensor HI
Figure 63. Knock Sensor
Table 64. Rear Knock Sensor [316]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
LGN/V
Rear knock sensor LO
2
BN/V
Rear knock sensor HI
Figure 64. Knock Sensor
Table 65. Termination Resister [319]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
A
W/R
CAN High
B
W/BK
CAN Low
Figure 65. Termination Resister [319]
Table 66. P&A Accessory [325]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/Y
Accessory power
2
BK
Ground
3
-
N/C
Figure 66. P&A Accessory [325]
Table 67. Backbone Harness Interconnect [327A]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/BN
Fuel pump power
2
R/V
Horn power
3
R/Y
Accessory power
4
R/O
Battery fuse
5
BE
Position lamp
6
BE/BK
AUX/fog lamps
7
BK/GN
Ground
8
BK
Ground
9
-
N/C
10
BE/Y
Low beam
11
BE/W
High beam
12
W/R
CAN +
13
W/BK
CAN -
14
-
N/C
15
-
N/C
16
O/BE
Front WSS +
17
O/BK
Front WSS -
18
BE/O
Front right turn
19
BE/PK
Front left turn
20
W/GY
Run/stop switch
Figure 67. Backbone Harness Interconnect [327A]
Figure 68. Backbone Harness Interconnect [327B]
Table 68. Engine Harness Interconnect [328]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
R/W
5V sensor power 1
2
GN/W
TGS 1
3
BK/W
5V sensor ground 1
4
R/GY
5V sensor power 2
5
GY/W
TGS 2
6
BK/GY
5V sensor ground 2
7
GN
Engine temperature
8
Y/W
Fuel level
Figure 69. Engine Harness Interconnect [328]
Table 69. USB Caddy Interconnect [329]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
BK
Ground
2
BK/W
5V sensor ground 1
3
GN
Engine temperature
4
R/Y
Accessory power
5
R/V
Horn power
6
BK/W
5V sensor ground 1
7
Y/W
Fuel level
8
R/BN
Fuel pump power
Figure 70. USB Caddy Interconnect [329]
Table 70. Light Bar Interconnect [331]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
1
BE/BN
Right rear turn signal
2
BK
Ground
3
BE/V
Left rear turn signal
4
BK
Ground
Figure 71. Light Bar Interconnect [331]
Table 71. Fuse Block [332]
TERMINAL
WIRE COLOR
CIRCUIT DESCRIPTION
A
R/GN
System power
B
V/GN
Fused system power
Figure 72. Fuse Block [332]
Table 1. Acronyms and Abbreviations
ACRONYM OR ABBREVIATION
DESCRIPTION
A
Amperes
AAT
Ambient air temperature
ABS
Anti-lock braking system
AC
Alternating current
ACC
Accessory position on ignition switch
ACR
Automatic compression release
AGM
Absorbed glass mat (battery)
Ah
Ampere-hour
AIS
Active intake solenoid
AWG
American wire gauge
B+
Battery voltage
bar
Bar
BAS
Bank angle sensor
BCM
Body control module
BOB
Breakout box
BTDC
Before top dead center
°C
Celsius (Centigrade)
CA
California
CAL
Calibration
CAN
Controller area network
CB Tx
CB send transmission
CB Rx
CB receive transmission
cc
Cubic centimeters
CCA
Cold cranking amps
CCW
Counterclockwise
CKP
Crankshaft position
cm
Centimeters
Cubic centimeters
cm3
CW
Clockwise
DC
Direct current
DLC
Data link connector
DOM
Domestic
DOT
Department of Transportation
DTC
Diagnostic trouble code
DVOM
Digital volt ohm meter
ECM
Electronic control module
ECT
Engine coolant temperature
ECU
Electronic control unit
EEPROM
Electrically erasable programmable read only memory
EFI
Electronic fuel injection
EHCU
Electro hydraulic control unit
ET
Engine temperature
ETC
Electronic throttle control
EVAP
Evaporative emissions control system
°F
Fahrenheit
fl oz
Fluid ounce
FPS
Fuel pressure sensor
ft
Feet
ft-lbs
Foot pounds
FTP
Flash to pass
g
Gram
gal
Gallon
GAWR
Gross axle weight rating
GND
Ground (electrical)
GPS
Global positioning system
GVWR
Gross vehicle weight rating
HCU
Hydraulic control unit
HDI
Harley-Davidson International
HD-Link
Networking system
H-DSSS
Harley-Davidson smart security system
HFM
Hands-free mode
HFSM
Hands-free security module
Hg
Mercury
H02S
Heated oxygen sensor
hp
Horsepower
hr
Hour
IAC
Idle air control
IAT
Intake air temperature
IC
Instrument cluster
ID
Inside diameter
IGN
Ignition light/key switch position
IM
Instrument module
in
inch
Cubic inch
in3
INJ PW
Injector pulse width
INTCM
Intercom
in-lbs
Inch pounds
JSS
Jiffy stand sensor
kg
Kilogram
km
Kilometer
km/h
Kilometers per hour
kPa
Kilopascal
kW
Kilowatt
KS
Knock sensor
L
Liter
lb
Pounds
LCD
Liquid crystal display
LED
Light emitting diode
LH
Left hand
LHCM
Left hand control module
LP
License plate
LT
Left
mA
Milliampere
MAP
Manifold absolute pressure
max
Maximum
mi
Mile
min
Minimum
mL
Milliliter
mm
Millimeter
mph
Miles per hour
ms
Millisecond
Nm
Newton-meter
NIM
Navigation interface module
NiMH
Nickel metal hydride
N/A
Not applicable
O2
Oxygen
OD
Outside diameter
OEM
Original equipment manufacturer
oz
Ounce
P&A
Parts and Accessories
Part No.
Part number
PIN
Personal identification number
PND
Personal navigation device
psi
Pounds per square inch
PWM signal
Pulse width modulated signal
qt
Quart
RAD
Radio
RCM
Reverse control module
RDS
Radio data system
RES
Reserve mark on fuel supply valve
RH
Right hand
RHCM
Right hand control module
rpm
Revolutions per minute
RT
Right
s
Seconds
SCFH
Cubic feet per hour at standard conditions
SDARS
Satellite digital audio radio service
SPDO
Speedometer
SPKR
Speaker
STT
Stop/tail/turn
TA
Traffic announcement
TCA
Throttle control actuator
TDC
Top dead center
TGS
Twist grip sensor
TPMS
Tire pressure monitoring system
TPS
Throttle position sensor
TSM
Turn signal module
TSSM
Turn signal/security module
TT
Telltale
USB
Universal serial bus
V
Volt
VAC
Volts of alternating current
VDC
Volts of direct current
VIN
Vehicle identification number
VR
Voice recognition
VSS
Vehicle speed sensor
W
Watt
WA
Weather alert
WHIM
Wireless headset interface module
WSS
Wheel speed sensor
0
(75,& &219(56,21
&219(56,21 7$%/(
0HWU
&RQYHUVLRQV
0,//,0(7(56 WR ,1&+(6
,1&+(6 WR 0,//,0(7(56
00 [
,1
,1 [
00
PP
LQ
PP
LQ
PP
LQ
PP
LQ
LQ
PP
LQ
PP
LQ
PP
LQ
PP
Unless otherwise specified, all fluid volume measurements in this manual are expressed in United States (U.S.) units-of-
measure. See below:
1 pint (U.S.) = 16 fluid ounces (U.S.)
1 quart (U.S.) = 2 pints (U.S.) = 32 fl. oz. (U.S.)
1 gallon (U.S.) = 4 quarts (U.S.) = 128 fl. oz. (U.S.)
Fluid volume measurements in this manual include the metric system equivalents. In the metric system, 1 liter (L) = 1,000
milliliters (mL). To convert between U.S. units-of-measure and metric units-of-measure, refer to the following:
fluid ounces (U.S.) x 29.574 = milliliters
pints (U.S.) x 0.473 = liters
quarts (U.S.) x 0.946 = liters
gallons (U.S.) x 3.785 = liters
milliliters x 0.0338 = fluid ounces (U.S.)
liters x 2.114 = pints (U.S.)
liters x 1.057 = quarts (U.S.)
liters x 0.264 = gallons (U.S.)
Fluid volume measurements in this manual do not include the British Imperial (Imp.) system equivalents. The following
conversions exist in the British Imperial system:
1 pint (Imp.) = 20 fluid ounces (Imp.)
1 quart (Imp.) = 2 pints (Imp.)
1 gallon (Imp.) = 4 quarts (Imp.)
Although the same unit-of-measure terminology as the U.S. system is used in the British Imperial (Imp.) system, the actual
volume of each British Imperial unit-of-measure differs from its U.S. counterpart. The U.S. fluid ounce is larger than the
British Imperial fluid ounce. However, the U.S. pint, quart, and gallon are smaller than the British Imperial pint, quart, and
gallon, respectively. To convert between U.S. units and British Imperial units, refer to the following:
fluid ounces (U.S.) x 1.042 = fluid ounces (Imp.)
pints (U.S.) x 0.833 = pints (Imp.)
quarts (U.S.) x 0.833 = quarts (Imp.)
gallons (U.S.) x 0.833 = gallons (Imp.)
fluid ounces (Imp.) x 0.960 = fluid ounces (U.S.)
pints (Imp.) x 1.201 = pints (U.S.)
quarts (Imp.) x 1.201 = quarts (U.S.)
gallons (Imp.) x 1.201 = gallons (U.S.)
2018 HARLEY-DAVIDSON® ELECTRICAL DIAGNOSTIC
MANUAL: SOFTAIL® MODELS
Foreword
Foreword
General
How To Use Your Manual
Preparation For Service
Service Bulletins
Use Genuine Replacement Parts
Warnings and Cautions
Product References
Product Registered Marks
H-D U.S.A., LLC Trademark Information
Contents
Initial Diagnostics
Specifications
Specifications
Initial Diagnostics
Description and Operation
Initial Diagnostics
Diagnostics
Retrieving Trouble Codes
Odometer Self-Diagnostics
Code Types
Multiple Trouble Codes
Clearing DTCs
Security Lamp
Check Engine Lamp
Symptoms
DIAGNOSTIC TOOLS
How To Use Diagnostic Tools
DIAGNOSTICS AND TROUBLESHOOTING
Voltage Drop
Wiggle Test
Serial Data
CAN COMMUNICATION
Description and Operation
Components
Communication DTCs and Error Messages
Odometer Self-Diagnostic Inoperative: DTC U0001, U0011, B2274
Description and Operation
Odometer Self-Diagnostic Inoperative: DTC U0001, U0011, B2274
NO VEHICLE POWER OR LOST COMMUNICATION DTCS
Description and Operation
DTC U0100
DTC U0121
No Vehicle Power: DTC U0140
Left Hand Controls Inoperative: DTC U0141
DTC U0142
IM Inoperative: DTC U0156
Tachometer Inoperative: DTC U0157
DTC U0300
Starting and Charging
BATTERY TESTING
General
Voltmeter Test
Battery Diagnostic Test
Load Test
STARTING SYSTEM
Description and Operation
Components
Starter Troubleshooting
Starter Testing
Nothing Clicks
Starter Solenoid Clicks
Starter Spins But Does Not Engage
Starter Stalls or Spins Too Slowly
STARTER OUTPUT DTCS
Description and Operation
DTC B2121
DTC B2122
DTC B2123
DTC B2124
TESTING STARTER ON MOTORCYCLE
Starter Current Draw Test
TESTING STARTER ON BENCH
Free Running Current Draw Test
CHARGING SYSTEM
Description and Operation
Troubleshooting
Low or No Charging
Overcharging
Low Battery After Extended IGN OFF
Battery Runs Down During Use
Battery Charging Tests
ABS VOLTAGE DIAGNOSTICS
Description and Operation
Diagnostics
DTC C0562
DTC C0563
BATTERY AND SYSTEM VOLTAGE DIAGNOSTICS
Description and Operation
DTC P0562
ENGINE STOP SWITCH DTCS
Description and Operation
DTC B2206
DTC B2208
BCM VOLTAGE DTCS
Description and Operation
DTC B2271
DTC B2272
Instruments
Instruments
Description and Operation
IM Theory of Operation
Instrument Diagnostics
FUEL LEVEL DIAGNOSTICS
Description and Operation
DTC P0462
DTC P0463
Trip Odometer Functions Inoperative, DTC B2255
Description and Operation
Trip Odometer Functions Inoperative: DTC B2255
NO INSTRUMENT POWER DIAGNOSTICS
Description and Operation
No Instrument Power
DTC B1200, B1201
INDICATOR LAMPS
Description and Operation
DTC B1214, B1215, B1216
Oil Pressure Lamp Always On, DTC P0522
DTC P0523
Neutral Lamp Always On
Neutral Lamp Inoperative
High Beam Indicator Always On
High Beam Indicator Inoperative
Low Fuel Lamp Inoperative
Turn Signal Indicator Inoperative
Turn Signal Indicator Always On
Accessories, Horn, Lighting and Security
ACC CIRCUIT DIAGNOSTICS
Description and Operation
DTC B2112
DTC B2113, B2114
HORN DIAGNOSTICS
Description and Operation
DTC B2127
DTC B2128, B2129
Horn Inoperative
Cruise Control
Description and Operation
System Operation
Troubleshooting
Cruise Control Inoperative Conditions
Cruise Control
DTC P0577
Turn Signals
Description and Operation
Will Not Cancel Upon Turn Completion, No DTCs
FRONT TURN SIGNAL DIAGNOSTICS
Description and Operation
DTC B2141
DTC B2143, B2144
DTC B2146
DTC B2148, B2149
REAR TURN SIGNAL DIAGNOSTICS
Description and Operation
DTC B2151
DTC B2153, B2154
DTC B2156
DTC B2158, B2159
HEADLAMP DIAGNOSTICS
Description and Operation
Auxiliary Lamps Inoperative: Except Japan
DTC B2106, B2107
Auxiliary Lamps Inoperative: Japan
DTC B2108, B2109
DTC B2132
DTC B2133, B2134
High Beam Headlamp Inoperative, DTC B2131
DTC B2137
DTC B2138, B2139
Low Beam Headlamp Inoperative, DTC B2136
STOP LAMP DIAGNOSTICS
Description and Operation
Stop Lamp Always On: DTC B2223
DTC B2161
DTC B2163, B2164
SWITCH DIAGNOSTICS
Description and Operation
DTC B1103, B1153
DTC B2210, B2212, B2250, B2251, B2253, B2254, B2260, B2261, B2262, B2263
DTC B2259
DTC B2270
Any Hand Control Switch Inoperative
BRAKE SWITCH DIAGNOSTICS
Description and Operation
DTC P0572
RUNNING LAMP DIAGNOSTICS
Description and Operation
Front Running Lamps Inoperative
Rear Running Lamps Inoperative
License Plate Lamp Inoperative
DTC B2168, B2169
SECURITY SYSTEM
Security Lamp
Security Immobilization
Security System Features
Security System Warnings
Arming
Disarming
Alarm
KEY FOB
Description and Operation
Fob Assignment
SIREN
Description and Operation
Siren Chirp Mode Confirmation
SERVICE AND EMERGENCY FUNCTIONS AND CONFIGURATIONS
General
Actuation
Selecting a PIN
Initial PIN Entry
Changing the PIN
Transport Mode
Service Mode
Four-Way Flasher
ALARM DIAGNOSTICS
Description and Operation
DTC B2172
DTC B2173
SECURITY ANTENNA DIAGNOSTICS
Description and Operation
DTC B2176
DTC B2177
DTC B2178
Fails to Disarm
DTC B2183, B2188, B2193, B2198
Description and Operation
DTC B2183
DTC B2188, B2193, B2198
NEUTRAL SWITCH DIAGNOSTICS
Description and Operation
DTC B2218
Engine Management
EFI SYSTEM
General
Electronic Control Module
General
SENSORS AND DRIVERS
Description and Operation
Sensors
Drivers
SYSTEM POWER CIRCUIT DIAGNOSTICS
Description and Operation
DTC B2102
DTC B2103, B2104
FUEL PUMP DIAGNOSTICS
Description and Operation
DTC B2116
DTC B2117
DTC B2118, B2119
TMAP SENSOR DIAGNOSTICS
Description and Operation
DTC P0107
DTC P0108
DTC P0112
DTC P0113
TCA DIAGNOSTICS
Description and Operation
DTC P0120
DTC P0122
DTC P0123
DTC P0220
DTC P0222
DTC P0223
ET SENSOR DIAGNOSTICS
Description and Operation
DTC P0117
DTC P0118
HO2S DIAGNOSTICS
Description and Operation
DTC P0031
DTC P0032
DTC P0051
DTC P0052
DTC P0131
DTC P0132
DTC P0134
DTC P0151
DTC P0152
DTC P0154
FUEL INJECTOR DIAGNOSTICS
Description and Operation
DTC P0261
DTC P0262
DTC P0264
DTC P0265
CKP SENSOR DIAGNOSTICS
Description and Operation
DTC P0371, P0374
KNOCK SENSOR DIAGNOSTICS
Description and Operation
DTC P0325
DTC P0327, P0328
DTC P0330
DTC P0332, P0333
PURGE SOLENOID DIAGNOSTICS
Description and Operation
DTC P0444
DTC P0445
VSS DIAGNOSTICS
Description and Operation
DTC P0502
DTC P0503
IDLE SPEED CONTROL DIAGNOSTICS
Loss of Idle Speed Control
DTC P0505
5V REFERENCE DIAGNOSTICS
Description and Operation
DTC P0641
DTC P0651
ECM INTERNAL DIAGNOSTICS
Description and Operation
DTC P1270
Description and Operation
DTC P1270
DTC P1009
General
DTC P1009
JSS DIAGNOSTICS
Description and Operation
DTC P1501
DTC P1502
Side Stand Displayed on Speedometer
ETC MANAGEMENT DIAGNOSTICS
Description and Operation
DTC P1510, P1511, P1512
ETC ERROR DIAGNOSTICS
Description and Operation
DTC P1514
DTC P1600
ACR Diagnostics
Description and Operation
DTC P1655
DTC P1656
ENGINE PERFORMANCE DIAGNOSTICS
Description and Operation
DTC P1505
Hesitation or Loss of Power Test
Starts Hard or Emits Black Smoke
ETC ACTUATOR DIAGNOSTICS
Description and Operation
DTC P2100
DTC P2101
DTC P2102
DTC P2103
DTC P2105, P2107
Description and Operation
DTC P2105, P2107
STARTS, THEN STALLS
Description and Operation
STARTS, THEN STALLS
IGN COIL DRIVER DIAGNOSTICS
Description and Operation
DTC P2300
DTC P2301
DTC P2303
DTC P2304
DTC P2119
Description and Operation
DTC P2119
Engine Cranks But Will Not Start
Description and Operation
Engine Cranks But Will Not Start
Misfire at Idle or Under Load
Description and Operation
Inline Spark Tester
Misfire at Idle or Under Load
TGS DIAGNOSTICS
Description and Operation
DTC P2122
DTC P2123
DTC P2127
DTC P2128
DTC P2176
Description and Operation
DTC P2176
CORRELATION ERROR DIAGNOSTICS
Description and Operation
DTC P2135
DTC P2138
Erratic Idle
Description and Operation
Erratic Idle
HESITATION OR LOSS OF POWER
Description and Operation
DTC P1505
Hesitation or Loss of Power Test
ABS
ANTI-LOCK BRAKE SYSTEM (ABS) GENERAL INFORMATION
Description and Operation
INTERNAL FAULT DIAGNOSTICS
Description and Operation
DTC C1014, C1040, C1055, C1061, C1062, C1065, C1066
WSS DIAGNOSTICS
Description and Operation
DTC C1021, C1023, C1025, C1027, C1029
DTC C1032
DTC C1034
INVALID VIN DIAGNOSTICS
Description and Operation
DTC C1159, C1178, C1184
ABS INDICATOR ALWAYS ON, FLASHING OR INOPERATIVE
Description and Operation
ABS Indicator Continuously Flashing, No DTCs
ABS Indicator Always On or Inoperative
Wiring
Wiring Diagrams
General
Wiring Diagrams
Wire Harness Connectors
General
Connector End Views
Connector Locations
Connector Repair
BOSCH COMPACT 1.1M SEALED CONNECTORS
Repair
DELPHI GT SEALED CONNECTORS
Repair
DELPHI METRI-PACK SEALED CONNECTORS
Repair
DELPHI MICRO 64 SEALED CONNECTORS
Repair
DEUTSCH DT AND DTM SEALED CONNECTORS
Repair
JAE MX19 SEALED CONNECTOR
Repair
JST JWPF SEALED CONNECTORS
Repair
Kostal MLK 1.2 Sealed Connector
Repair
MOLEX CMC SEALED CONNECTOR
Repair
MOLEX MX SEALED CONNECTORS
Repair
SEALED SPLICE CONNECTORS
Repair
TYCO GET 64 SEALED CONNECTORS
Repair
TYCO MCON SEALED CONNECTORS
Repair
TYCO MCP SEALED CONNECTORS
Repair
TYCO MULTILOCK UNSEALED CONNECTOR
Repair
TYCO SUPERSEAL 1.5 SEALED CONNECTORS
Repair
Reference
GLOSSARY
Acronyms and Abbreviations
METRIC CONVERSION
Conversion Table
FLUID CONVERSIONS
United States System
Metric System
British Imperial System
TORQUE CONVERSION
United States System
Metric System
WARNING
The rider's safety depends upon proper motorcycle service and maintenance. If a procedure in this manual is not
within your capabilities or you do not have the correct tools, have a Harley-Davidson dealer perform the procedure.
Improper service or maintenance could result in death or serious injury. (00627b)
This electrical diagnostic manual has been prepared with two purposes in mind. First, it will acquaint the user with the
construction of the Harley-Davidson product and assist in the performance of repair. Secondly, it will introduce to the
professional Harley-Davidson Technician the latest field-tested and factory-approved diagnostic methods. We sincerely
believe that this manual will make your association with Harley-Davidson products more pleasant and profitable.
