Fig. 309: Removing Screw
Courtesy of FORD MOTOR CO.

6. Unclip the J-clips then remove the upholstery and seat pad.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 310: Removing Upholstery And Seat Pad
Courtesy of FORD MOTOR CO.

7. Remove the upholstery from the seat pad.

8. Remove the seat riser.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 311: Removing Seat Riser
Courtesy of FORD MOTOR CO.

9. Rod latch control to latch is a slip-fit, pull to separate.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 312: Identifying Rod Latch Control To Latch Is Slip-Fit
Courtesy of FORD MOTOR CO.

10. Remove the bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
