Fig. 132: Removing Covers And Bolts
Courtesy of FORD MOTOR CO.

2. Fold the seat, then remove the six bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 133: Removing Bolts
Courtesy of FORD MOTOR CO.

3. Remove the seat from the vehicle.

4. To install, reverse the removal procedure.

z

Check the active restraint system for correct operation. Refer to SAFETY BELT SYSTEM .

REAR SEAT - 40 PERCENT AND QUAD BUCKET, SUPERCREW

Removal and Installation

1. Remove the bolts.

z

Remove the covers and the bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 134: Removing Covers And Bolts
Courtesy of FORD MOTOR CO.

2. Fold down the seat.

3. Remove the four bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 135: Removing Four Bolts
Courtesy of FORD MOTOR CO.

4. To install, reverse the removal procedure.

z

Check the active restraint system for correct operation. Refer to SAFETY BELT SYSTEM .

SEAT CONTROL SWITCH - SEAT REGULATOR CONTROL

Removal and Installation

1. Disconnect the battery ground cable.

2. Remove the front seat back recliner handle (61736).

1. Remove the screw.

2. Remove the front seat back recliner handle.
