Fig. 40: Adjusting Clutch Pressure Plate
Courtesy of FORD MOTOR CO.

REMOVAL & INSTALLATION



2003 Ford Pickup F150

2003 TRANSMISSIONS Manual Transmission, Clutch & Transfer Case - General Information - F150 Pickup



DOWELS - FLYWHEEL

Removal

NOTE:

Take care not to damage the flywheel dowel holes or surface areas around
the flywheel dowel during removal.



2003 Ford Pickup F150

2003 TRANSMISSIONS Manual Transmission, Clutch & Transfer Case - General Information - F150 Pickup



Fig. 41: Locating Flywheel Dowels
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 TRANSMISSIONS Manual Transmission, Clutch & Transfer Case - General Information - F150 Pickup



1. Remove the flywheel dowels by using a drift pin where the flywheel dowel is installed in an open hole

and locking pliers where the flywheel dowel is installed in a blind hole.

Installation

1. Install all flywheel dowels by driving them into place using a brass or plastic mallet.

DOWELS - FLYWHEEL HOUSING TO BLOCK

Removal

1. Remove the flywheel housing to block dowel (6397) using a drift pin where the flywheel housing to

block dowel is installed in an open hole and locking pliers where the flywheel housing to block dowel is
installed in a blind hole.

Installation

1. Install all flywheel housing to block dowels by driving them into place using a brass or plastic mallet.

NOTE:

Care should be taken to drive the flywheel dowel squarely into place until
fully seated and to not damage surrounding surface areas.

NOTE:

Take care not to damage the flywheel housing to block dowel holes or
surface areas around the flywheel housing to block dowel hole during
removal.

NOTE:

Care should be taken to drive the flywheel housing to block dowel
squarely into place until fully seated without damaging the surrounding
surface areas.
