Fig. 19: Installing Pushpins
Courtesy of FORD MOTOR CO.

8. Connect the clutch pedal position switch.



2003 Ford Pickup F150

2003 TRANSMISSIONS Clutch Controls - F150 Pickup



Fig. 20: Connecting Clutch Pedal Position Switch
Courtesy of FORD MOTOR CO.

9. Connect the clutch master cylinder push rod and retainer bushing.



2003 Ford Pickup F150

2003 TRANSMISSIONS Clutch Controls - F150 Pickup



Fig. 21: Connecting Clutch Master Cylinder Push Rod & Retainer Bushing
Courtesy of FORD MOTOR CO.

10. Raise and support the vehicle. For additional information, refer to JACKING & HOISTING .

11. Connect the clutch hydraulic line to the transmission.

WARNING:

The electrical power to the air suspension system must be shut off
prior to hoisting, jacking, or towing an air suspension vehicle. This
can be accomplished by turning off the rh kick panel area. Failure to
inflation of deflation of the air springs which may result in shifting of
the vehicle during these operations.



2003 Ford Pickup F150

2003 TRANSMISSIONS Clutch Controls - F150 Pickup



Fig. 22: Connecting Clutch Hydraulic Line To Transmission
Courtesy of FORD MOTOR CO.

12. Lower the vehicle.

13. Turn on the air suspension switch, if equipped.

14. Bleed the clutch hydraulic system. For additional information, refer to MANUAL TRANSMISSION,

CLUTCH & TRANSFER CASE - F150 PICKUP .

SLAVE CYLINDER

Removal

1. Raise the vehicle on a hoist. For additional information, refer to JACKING & HOISTING .

2. Remove the hydraulic line from the slave cylinder.

WARNING:

The electrical power to the air suspension system must be shut off
prior to hoisting, jacking, or towing an air suspension vehicle. This
can be accomplished by turning off the rh kick panel area. Failure to
inflation of deflation of the air springs which may result in shifting of
the vehicle during these operations.



2003 Ford Pickup F150

2003 TRANSMISSIONS Clutch Controls - F150 Pickup
