Fig. 8: Removing Fuel Tube Clip
Courtesy of FORD MOTOR CO.

3. Install the Disconnect Tool.

2003 Ford Pickup F150

2003 GENERAL INFORMATION Fuel System - General Information - F150 Pickup

Fig. 9: Installing Disconnect Tool
Courtesy of FORD MOTOR CO.

4. Close and push the Disconnect Tool into the open side of the cage.

2003 Ford Pickup F150

2003 GENERAL INFORMATION Fuel System - General Information - F150 Pickup

Fig. 10: Pushing Disconnect Tool Into Open Side Of Cage
Courtesy of FORD MOTOR CO.

5. Separate the fitting.

2003 Ford Pickup F150

2003 GENERAL INFORMATION Fuel System - General Information - F150 Pickup

Fig. 11: Separating Fitting
Courtesy of FORD MOTOR CO.

6. Remove the Disconnect Tool.
