Ford Contour (1999 year). Manual - part 21





Seating and safety restraints

82

Care of safety belts

Periodically check the belts for
damage or fraying. Check the
security of the anchorage points
and the locking action of the inertia
reels by giving each belt a sharp
tug.

Belts subjected to strain, as in the
result of an accident, should be
replaced and the anchorages
checked by your dealer or a
qualified technician.

Failure to follow these
instructions will affect the

performance of the safety belts
and increase the risk of personal
injury.

Safety belt warning label

A warning label has been placed on
the buckle of each of your vehicle’s
front seat safety belts.

In a collision of sufficient severity
while the safety belt is in use, the
safety belt buckle will pull out of
the sleeve so that all or part of the
orange portion of the label is
visible.

Whenever the orange
portion of the label is visible,

the safety belt must be replaced.

      WARNING Replace buckle
assembly if this vehicle is in a collision
or if any orange portion of this label
is visible. (See Owner Guide). Failure
to replace this buckle assembly under
the above conditions could result in
severe personal injuries in the event
of collision.

      AVERTISSEMENT Remplacer
l'ensemble de boucle de ceinture en
cas de collision avec ce véhicule, ou si
la partie orange de cette étiquette
est visible (Voir le Guide du
proprietare). Faute de remplacer cet
ensemble de boucle, des blessures
graves pourraient être encourues en
cas de collision.

REPLACE BUCKLE/REMPLACER BOUCLE

14CSSen  3/25/99  1:59 PM  Page 82

Seating and safety restraints

83

Important supplemental
restraint system (SRS)
precautions

The supplemental restraint system
(SRS) is designed to:

• work with the safety belt to
protect the driver and right front
passenger.

• reduce certain upper body
injuries.

AIR BAG SUPPLEMENTAL
RESTRAINT SYSTEM (SRS)

M

IRRORS

OFF

LO

PNL/FLR

PANEL

A/C

FLOOR

DEF

FLR

       DEF

MAX

A/C

HI

/

POWER

AUDIO

AM/FM

SCAN

SEEK

3

1

2

4

5

ANS

SIDE

1-2

EJECT

VOLUME

0 0 0 1 2 3

0 0 0 0

10

20

30

40

50

60 70 80

90

100

110

120

130

MPH

20

40

60

55

80

120

100

140

160

180

200

E

F

1

2

0

3

x 1000

4

5

6

7

8

BRAKE

CHECK
ENGINE

O/D
OFF

CLOCK

TRACTION
       TROL

C

H

14CSSen  3/25/99  1:59 PM  Page 83

Seating and safety restraints

84

Do not attempt to service,
repair, or modify the air bag

Supplemental Restraint System
(SRS) or its fuses. See your Ford
or Lincoln-Mercury dealer.

When installing forward-
facing child seats in the

front seat, always move the
passenger seat as far back from
the instrument panel as possible.
Never install rear-facing child
seats or rear-facing infant seats in
the front seat.

Children and air bags

For additional important safety
information, read all information on
safety restraints in this guide.

Children should always wear safety
belts. Failure to follow these
instructions may increase the risk
of injury in a collision.

Do not place objects or
mount equipment on or near

the air bag covers that may come
into contact with an inflating air
bag.

14CSSen  3/25/99  1:59 PM  Page 84

Seating and safety restraints

85

How does the air bag
supplemental restraint system
(SRS) work?

The SRS is designed to activate
when the vehicle is in a collision,
similar to hitting a fixed barrier
head-on at 12-24 km/h (8-14 mph).

The fact that the air bags did not
inflate in a collision does not mean
that something is wrong with the
system. Rather, it means the forces
were not of the type sufficient to
cause activation.

The air bags inflate and deflate
rapidly upon activation.

After air bag deployment, it is
normal to notice a smoke-like,
powdery residue or smell the
burned propellant. This may
consist of cornstarch, talcum
powder (to lubricate the bag), or
sodium compounds (e.g., baking
soda) that result from the
combustion process that inflates
the air bag. Small amounts of
sodium hydroxide may be present,
which may irritate the skin and
eyes, but none of the residue is
toxic.

14CSSen  3/25/99  1:59 PM  Page 85
