Citroen Jumpy (2016 year). Manual

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Unlocking

To unlock the vehicle, remote control on

your person and in the recognition zone A,
pass your hand behind one of the door
handles (front doors, manual sliding side
doors and side-hinged doors).

Pull the handle to open the corresponding

door.

With electric sliding slide door(s)

To unlock the vehicle, remote control

on your person and in the recognition
zone A, pull and release the door handle to
trigger the electric powered opening of the
corresponding door.

With tailgate

To unlock the vehicle, remote control on

your person and in the recognition zone A,
pull the tailgate handle.

Raise the tailgate.

Unlocking is signalled by the rapid
flashing of the direction indicators for
about two seconds.
Depending on version, the door mirrors
unfold, the alarm is deactivated.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

With electric sliding side door(s)

Locking

F To

totally

lock the vehicle, with the remote

control in the recognition zone A, press
with a finger or thumb at the markings on
one of the front or manual sliding side door
handles.

If a door is not properly closed
(except the right-hand door with side-
hinged rear doors):
- vehicle stationary and the engine

running, this warning lamp
comes on, accompanied by an
alert message for a few seconds,

- vehicle moving (speed above

6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an audible signal and an alert
message for a few seconds.

With side-hinged doors

F To

totally

lock the vehicle, with the remote

control in the recognition zone A, press
with a finger or thumb at the markings on
one of the front

door handles.

To lock the vehicle, with the remote control

in the recognition zone A, press the left-
hand door locking control.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Driving with the doors locked may
render access for the emergency
services difficult in an emergency.

If your vehicle is not fitted with an
alarm, locking is confirmed by fixed
illumination of the direction indicators
for about two seconds.
Depending on version, the door mirrors
fold at the same time.

Deadlocking

Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
locking button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.

F To

totally

lock the vehicle, with the remote

control in the recognition zone A, press
with a finger or thumb at the markings on
one of the front or manual sliding side door
handles.

To deadlock the vehicle, press the marking

again within five seconds.

Ensure that no one might prevent the
correct operation of the windows.
Be particularly aware of children when
operating the windows.

If fitted to your vehicle, pressing and
holding the locking controls allows
the windows to be opened. The
window stops when you release the
button.

With a tailgate

To lock the vehicle, with the remote control

in the recognition zone A, press the
tailgate locking control.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

F To

totally

lock the vehicle, with the remote

control in the recognition zone A, press
with a finger or thumb at the markings on
one of the front

door handles.

To deadlock the vehicle, press the marking

again within five seconds.

If your vehicle is not fitted with an alarm,
deadlocking is confirmed by fixed
illumination of the direction indicators
for about two seconds.

With electric sliding side door(s)

With a tailgate

With side-hinged doors

To lock the vehicle, with the remote control

in the recognition zone A, press the
tailgate locking control.

To deadlock the vehicle, press the control

again within five seconds.

To lock the vehicle, with the remote control

in the recognition zone A, press the left-
hand door locking control.

To deadlock the vehicle, press the control

again within five seconds.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Locating your vehicle

This function allows you to identify your vehicle
from a distance, particularly in poor light. Your
vehicle must have been locked for more than
five seconds.

F Press this button

This switches on the courtesy lamps and the
direction indicators flash for about ten seconds.

Remote operation of lighting

If fitted to your vehicle.

A short press on this button switches
on the lighting remotely (sidelamps,
dipped beam headlamps and number
plate lamps).

A second press on this button before
the end of the timed period cancels
the remote lighting.

Anti-theft protection

Electronic engine immobiliser

The remote control contains an electronic chip
which has a special code. When the ignition is
switched on, this code must be recognised in
order for starting to be possible.
This electronic engine immobiliser locks the
engine management system a few moments
after the ignition is switched off and prevents
starting of the engine by anyone who does not
have the key.

In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal and
a message in the screen.

In this case, your vehicle will not start; contact
a CITROËN dealer as soon as possible.

Keep safely, away from your vehicle,
the label attached to the keys given to
you on acquisition of the vehicle.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Back-up control(s)

If the alarm is activated, the audible
signal triggered on opening a door
with the key (integral with the remote
control) will stop when the ignition is
switched on.

Integral key

Locking the driver's door

Unlocking

Insert the integral key into the door lock,

then turn it to the front.

If your vehicle has an alarm, it will not
be deactivated/activated on unlocking/
locking the vehicle.
Opening a door will trigger the alarm,
which can be stopped by switching the
ignition on.
To deadlock the vehicle, turn the key
again within five seconds of locking.

Locking the front passenger door

Open the door.

Unlocking

Use the interior door handle.

It is used to lock and unlock the vehicle when
the remote control cannot operate:
- cell battery flat, vehicle battery discharged

or disconnected, ...

- vehicle located in an area with strong

electromagnetic signals.

F Press and hold button 1 to extract the

integral key 2.

Insert the integral key into the door lock,

then turn it to the rear.

Remove the cap on on the edge of the

door.

Insert the key into the latch aperture

(without forcing) and turn the assembly.

Remove the key and refit the cap.

Close the door and check from the outside

that the vehicle has locked correctly.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

For more information on the child lock,
refer to the corresponding section.

Locking a sliding side door

If fitted to your vehicle, check that the

electric child lock is not on.

Open the door.

Locking the side-hinged doors

If fitted to your vehicle, check that the

electric child lock is not on.

Open the left-hand side-hinged door.

Unlocking

Use the interior door handle.

Unlocking

Use the interior door handle.

Remove the cap on the edge of the door.

Insert the key into the latch aperture

(without forcing) and turn the assembly.

Remove the key and refit the cap.

Close the door and check from the outside

that the vehicle has locked correctly.

Insert the key (without forcing) into the

latch aperture located on the edge of the
door and slide the assembly upward.

Remove the key.

Close the door and check from the outside

that the vehicle has locked correctly.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Changing the battery

Battery ref.: CR2032 / 3 volts.
This replacement battery is available from a
CITROËN dealer or a qualified workshop.
A message appears in the instrument panel
screen when replacement of the battery is needed.

Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
Take them to an approved collection
point.

Place the remote control against the

reader.

Keeping it in place, switch on the ignition

by pressing "START/STOP".

The remote control is fully operational again.

Reinitialisation

Remote control problem

Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
vehicle.
F

First, use the integral key in the door lock

to unlock or lock your vehicle.

Then, reinitialise the remote control.

If the problem persists, contact
a CITROËN dealer or a qualified
workshop as soon as possible.

Unlock the driver's door using the

integral key.

F Press one of the remote control

buttons.

Place the integral key in the lock to unlock

your vehicle.

Unclip the cover using a small screwdriver

at the cutout.

Lift off the cover.

Remove the flat battery from its location.

F Fit the new battery into its location

observing the original direction of fitment.

Clip the cover onto the casing.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Lost keys, remote control

Visit a CITROËN dealer with the vehicle's
registration certificate, your personal
identification documents and if possible, the
label bearing the key code.
The CITROËN dealer will be able to retrieve
the key code and the transponder code
required to order a new key.

Locking the vehicle

Driving with the doors locked may make
access to the passenger compartment by
the emergency services more difficult in an
emergency.
As a safety precaution (with children on
board), remove the key from the ignition
or take the remote control with you when
leaving the vehicle, even for a short time.

When purchasing a second-
hand vehicle

Have the key codes memorised by a
CITROËN dealer, to ensure that the keys in
your possession are the only ones which can
start the vehicle.

Electrical interference

The Keyless Entry and Starting remote
control may not operate if close to certain
electronic devices: telephone, laptop
computer, strong magnetic fields, ...

Accumulations (water, dust, grime,
salt...) on the inner surface of the door
handle may affect detection.
If cleaning the inner surface of the door
handle using a cloth does not restore
detection, contact a CITROËN dealer or
a qualified workshop.
A sudden splash of water (stream of
water, high pressure jet washer, …) may
be identified by the system as the desire
to open the vehicle.

Remote control

The high frequency remote control is a
sensitive system; do not operate it while it is
in your pocket as there is a possibility that
it may unlock the vehicle, without you being
aware of it.
Do not repeatedly press the buttons of your
remote control out of range and out of sight
of your vehicle. You run the risk of stopping
it from working and the remote control would
have to be reinitialised.
The remote control does not operate when
the key is in the ignition, even when the
ignition is switched off.

Anti-theft protection

Do not make any modifications to the
electronic engine immobiliser system; this
could cause malfunctions.
Do not forget to turn the steering to engage
the steering lock.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Locking the vehicle

This button is inoperative if the vehicle
has been locked or deadlocked from
outside (using the key, remote control or
Keyless Entry and Starting, according
to equipment) or if one of the doors is
still open.

Automatic

The cabin doors lock automatically while
driving (speed above 6 mph (10 km/h)); the
indicator lamp comes on.

When carrying long objects with the
tailgate or rear doors open, you can
press this button to lock just the cabin
doors.
When locking from inside, the door
mirrors do not fold.

The indicator lamp also goes off when
unlocking one or more doors.

Driving with the doors locked may make
access to the passenger compartment
by the emergency services more
difficult in an emergency.

F To activate or deactivate this

function, with the ignition on,
press this button until a message
appears in the screen.

Press this button.

If the vehicle is deadlocked or locked
with the remote control or the door
handles, the button is not active. In this
case, use the key or the remote control
to unlock.

Manual

The indicator lamp comes on to confirm the
locking.

The indicator lamp goes off to confirm the
unlocking.

Unlocking the vehicle

Locking / unlocking from inside

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Vehicle unlocked, press this

button.

F Loading area

locked, press this

button.

For more information on the Key,
Remote control or Keyless Entry
and Starting, and in particular,
programming the selective locking
of the loading area, refer to the
corresponding section.

This button is inoperative if the vehicle
has been locked or deadlocked from
outside (using the key, remote control or
Keyless Entry and Starting, depending
on equipment) or if one of the doors is
still open.

Driving with the doors locked may make
access to the passenger compartment
by the emergency services more
difficult in an emergency.

The indicator lamp goes off when one
or more of the loading area doors is
unlocked.
To save energy, with the ignition off and
the vehicle totally locked, the indicator
lamp goes off.

To deactivate this automatic locking,
go to a CITROËN dealer or a qualified
workshop.

Automatic

The loading area

doors always lock while

driving.

Locking / unlocking
the loading area

Manual

The indicator lamp comes on to confirm the
locking of the vehicle.

Vehicle locked, press this button.

The indicator lamp goes off to confirm the
unlocking of the vehicle.

Cab and loading area selectivity
deactivated.

Cab and loading area selectivity
activated.

F Loading area

unlocked, press

this button.

The indicator lamp comes on to confirm the
locking of the loading area.

The indicator lamp goes off to confirm the
unlocking of the loading area.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Front doors

Opening

From outside

F Pull the interior control lever of a door to

totally

unlock the vehicle and open the

door.

F Pull the interior control lever of a door to

unlock the cab and open the door.

F Pull the interior control lever on a door to

totally

unlock the vehicle and open the

door.

After unlocking the vehicle (using the

key, remote control or Keyless Entry and
Starting, depending on equipment), pull the
door handle.

Cab and loading area selectivity
deactivated and the vehicle locked.

Cab and loading area selectivity
activated and the vehicle locked.

Vehicle locked.

For more information on the Key,
Remote control or Keyless Entry and
Starting

and in particular unlocking

the vehicle, refer to the corresponding
section.

From inside

The interior door controls do not
operate when the vehicle is deadlocked.

If the door is unlocked, pull the handle
to open the door.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Closing

F Push or pull the door to close it, then

lock it.

For more information on the Key,
Remote control or Keyless Entry
and Starting

and in particular locking

the vehicle, refer to the corresponding
section.

When a door is not fully closed:
- vehicle stationary and engine

running, this warning lamp
comes on, accompanied by an
alert message for a few seconds,

- vehicle moving (speed above

6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an audible signal and an alert
message for a few seconds.

Manual sliding side door(s)

From outside

After unlocking the vehicle (using the

key, remote control or Keyless Entry and
Starting, depending on equipment) pull the
door handle.

Take care not to block the guide space
on the floor to allow the door to slide
correctly.
As a safety measure and for functional
reasons, do not drive with the sliding
side door open.

For more information on the Key,
Remote control or Keyless Entry and
Starting

and in particular unlocking

the vehicle, refer to the corresponding
section.

To hold the sliding side door in the open
position, open the door fully to engage
the latch (located at the bottom of the
door).

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

For more information on the Child lock,
refer to the corresponding section.

From inside

Cab and loading area selectivity
deactivated.

Pull the interior opening control of a door

to unlock the loading area and open the
door.

Cab and loading area selectivity
deactivated and child lock off
(deactivated).

Pull the interior opening control of a door

to unlock the loading area and open the
door.

Cab and loading area selectivity
activated.

Vehicle unlocked

Pull the interior opening control of a door

to totally

unlock the vehicle and open the

door.

Cab and loading area selectivity
activated and child lock off
(deactivated).

Pull the interior opening control of a door

to totally

unlock the vehicle and open the

door.

Pull the interior opening control of a door

to totally

unlock the vehicle and open the

door.

Child lock off (deactivated).

F Pull the handle towards the rear to open

the door.

Vehicle locked

F Pull the handle towards the rear to open

the door.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

If a sliding side door is not fully
closed:
- vehicle stationary and engine

running, this warning lamp
comes on, accompanied by an
alert message for a few seconds,

- vehicle moving (speed above

6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an audible signal and an alert
message for a few seconds.

For more information on the Key,
Remote control or Keyless Entry
and Starting

and in particular locking

the vehicle, refer to the corresponding
section.

Closing

From outside

F Pull the handle toward you, then to the

front, and if necessary lock the vehicle.

From inside

F Push the handle forward to close the door,

and if necessary lock the vehicle.

Access

Jumpy_en_Chap02_ouvertures_ed01-2016

Electric sliding side door(s)

The exterior and interior door handles and the interior buttons allow the electrically powered
movement of the door to be started.
Opening and closing of the doors is accompanied by an audible signal.

The remote controls buttons are not
active with the ignition switched on.

Opening
From outside

Using the remote control

Press this button again to

reverse the movement of the
door.

Using the handle

Door unlocked, press and

hold this button until the
corresponding sliding side door
has opened.

Door unlocked, pull and release the handle

to start the electrically powered opening of
the door.

Pull the handle again to reverse the

movement of the door.

Citroen Jumpy (2016 year). Manual - part 5
