Citroen C3 (2017 year). Manual - part 22

Audio and Telematics

Select the audio source.

Press

Radio Media to display the

primary page.

Press "

Band " to select the " DAB "

waveband.

Press

Radio Media to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

DAB-FM auto tracking

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB-FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station
(if there is one).

If "DAB-FM auto tracking" is activated,
there is a difference of a few seconds
when the system switches to "FM"
analogue radio with sometimes a
variation in volume.
Once the digital signal is restored, the
system automatically changes back to
"DAB".

Digital radio provides higher quality
reception.
The different multiplexes offer a
choice of radio stations arranged in
alphabetical order.

If the "DAB" station being listened to
is not available on "FM" ("

DAB-FM "

option greyed out), or "DAB/FM auto
tracking" is not activated, the sound
will cut out while the digital signal is too
weak.

Select "

Radio settings ".

Select "

General ".

Activate / Deactivate "

Station

follow ".

Press "

OK ".

DAB radio (Digital Audio Broadcasting)

Terrestrial Digital Radio

Audio and Telematics

Media

USB port

Selecting the source

Select "

Source ".

Press

Radio Media to display the

primary page.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or connection of a USB
memory stick. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Insert the USB memory stick into the USB port
or connect the USB device to the USB port
using a suitable cable (not supplied).

Auxiliary (AUX) socket

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

This source is only available if "Auxiliary input"
has been checked in the audio settings.

(depending on equipment)

Connect the portable device (MP3 player…) to
the auxiliary Jack socket using an audio cable
(not supplied).

Choose the source.

Bluetooth

Bluetooth audio streaming

  Streaming allows you to listen to music from
your  telephone.
  The Bluetooth profile must be activated. First
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your audio system.

If play does not start automatically, it may be
necessary to start the audio playback from the
telephone.
Control is from the portable device or by using
the system's touch buttons.

Once connected in streaming mode,
the telephone is considered to be a
media source.

To protect the system, do not use a
USB hub.

CD player

(depending on equipment)
Insert the CD in the player.

Audio and Telematics

Connecting Apple

Connecting Apple players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts).
The default classification used is by
artist. To modify the classification used,
return to the first level of the menu
then select the desired classification
(playlists for example) and confirm
to go down through the menu to the
desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

The audio equipment will only play audio
files with ".wma, .aac, .flac, .ogg and .mp3"
file extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of file (.mp4, ...) can be played.
".wma" files must be of the standard wma 9
type.
The sampling rates supported are 32, 44 and
48 KHz.

In order to be able to play a burned CDR or
CDRW, when burning it is preferable to select
standards ISO 9660 level 1, 2 or Joliet.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same burning
standard is always used on an individual disc,
with as low a speed as possible (4x maximum)
for the best sound quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

It is advisable to restrict file names to
20 characters, without using of special
characters (e.g.: " " ? ; ù) to avoid any playing
and displaying problems.

Information and advice

Use only USB memory sticks formatted FAT 32
(file allocation table).

The system supports USB mass
storage devices, BlackBerry

devices

or Apple

players via USB ports. The

adaptor cable is not supplied.
Control of the peripheral device is with
the audio system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied) or via Bluetooth streaming,
depending on compatibility.

It is recommended that the original USB
cable for the portable device is used.

To protect the system, do not use a
USB hub.

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

Audio and Telematics

Telephone

According to version

Level 1

Level 2

Level 3

12
13

5
6
7

8
9

10
11

Audio and Telematics

Level 1

Level 2

Level 3

Comments

Telephone

Bluetooth

Contact

All

View contacts according to presentation choices.
Select a contact or a favourite saved in the
system via the profile selected to start the call.

Telephone

Address

Favourites

Sort the contacts by Surname-First name or First
name-Surname.

Update the contacts from the telephone.

Search

Search for a contact in the directory.

Create

Telephone

Create a new contact in the system.

Address

Telephone

Bluetooth

Calls

All

View calls according to choice of presentation.
Select a contact to start the call.

Incoming

Outgoing

Missed

View details for the contact.

Audio and Telematics

Level 2

Level 3

Audio and Telematics

Level 2

Level 3

Comments

Telephone

OPTIONS

Bluetooth

connection

All

Display all telephones detected and saved.

Connected

Display all connected telephones.

Search

Start the search for a device to connect.

Telephone

OPTIONS

Messages

All

Display messages according to the choice made.

Received

Sent

Telephone

OPTIONS

Email

Received

Display emails according to the choice made.

Sent

Not read

Mailbox

Audio and Telematics

Level 2

Level 3

Audio and Telematics

Level 2

Level 3

Comments

Telephone

OPTIONS

Settings

Security

Make driving safe.

Voicemail

Enter and save the number for the telephone
voicemail.

Ringtone

Adjust the ringtone volume.

Statistics

Display data for the telephone connected.

Save the options.

Telephone

OPTIONS

Quick messages

Delayed

Select a quick message from the categories, as
required.

My arrival

Not available

Other

Audio and Telematics

Pairing a Bluetooth

Pairing a Bluetooth telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with theBluetooth hands-free
system of your audio system must be
done with the

vehicle stationary and

the ignition on.

Procedure from the telephone

Select the system name in the list of
devices detected.

In the system, accept the connection request
from the telephone.

Procedure from the system

Press on

Telephone to display the

primary page.

Press on "

Bluetooth search ".

Select "

Search ".

The list of telephones detected is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
"Bluetooth" function in your telephone.

The system offers to connect the telephone
with 3 profiles:
-

Telephone (hands-free kit, telephone

only),

Streaming (wireless play of audio files on

the telephone),

Mobile internet data .

Depending on the type of telephone,
you may be asked to accept or not
the transfer of your contacts and
messages.

Select the name of the chosen
telephone in the list.

Press "

OK " to confirm.

Select one or more profiles.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

The "

Mobile internet data " profile

must be activated for connected
navigation, having first activated
sharing of the connection on your
smartphone.

Connection sharing

Audio and Telematics

Press

Telephone to display the

primary page.

Select "

Bluetooth connection " to

display the list of paired devices.

On return to the vehicle, if the last
telephone connected is present again,
it is automatically recognised and
within about 30 seconds of switching
on the ignition, the connection is
established without any action on your
part (Bluetooth activated).

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check in your telephone's
manual and with your service provider
for the services available to you.

The ability of the system to connect
with just one profile depends on the
telephone.
All three profiles may connect by default.

Go to the Brand's website for more information
(compatibility, additional help, ...).

To modify the connection profile :

Automatic reconnection

Press the "details" button.

Press the "

OPTIONS " button to go to

the secondary page.

Press "

OK " to confirm.

Select one or more profiles.

The profiles compatible with the system
are HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

Audio and Telematics

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted

TEL button to accept an

incoming call.

Make a long press

on the steering mounted

TEL button

to reject the call.

And

Select "

End call ".

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Select the basket at top right of the
screen to display a basket alongside
the telephone chosen.

Press the basket alongside the
telephone chosen to delete it.

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press

Telephone to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Bluetooth connection " to

display the list of paired peripheral
devices.

Deleting a telephone

Audio and Telematics

on the steering mounted button.

Using the telephone is not
recommended while driving.
Park the vehicle.
Make the call using the steering
mounted controls.

Making a call

Calling a new number

Press

Telephone to display the

primary page.

Enter the phone number using the
digital keypad.

Press "

Call " to start the call.

Calling a contact

Press

Telephone to display the

primary page.

Or make a long press

on the steering mounted

TEL button.

Select "

Contact ".

Select the desired contact from the list offered.

Select "

Call ".

Calling a recently used number

Press

Telephone to display the

primary page.

Make a long press

Select "

Calls ".

Select the desired contact from the list offered.

It is always possible to make a call
directly from the telephone; as a safety
measure, first park the vehicle.

12
13
14

Audio and Telematics

The access to "

Messages " depends on

the compatibility of the smartphone and
the integral system.
Depending on the smartphone, access
to your messages or email may be
slow.

Managing messages

The "

Email " function allows email

addresses to be entered for a contact,
but the system is not able to send
emails.

Managing contacts / entries

Press

Telephone to display the

primary page.

Select "

Contact ".

Select "

Create " to add a new contact.

In the "

Telephone " tab, enter the

telephone numbers for the contact.

In the "

Address " tab, enter the

addresses for the contact.

In the "

Email " tab, enter the email

addresses for the contact.

Press "

Answer " to send a quick

message stored in the system.

Press

Telephone to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Messages " to display the list

of messages.

Select the "

All " or " Received " or

Sent " tab.

Select the detail of the message
chosen in one of the lists

Press "

Call " to start the call.

Press "

Play " to hear the message.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used.
Check in the manual for your
smartphone and with your service
provider for the services available to
you.

Audio and Telematics

Managing email

Press

Telephone to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Email " to display the list of

messages.

Select the "

Received " or " Sent " or

Not read " tab.

Select the email chosen in the list.

Press "

Play " to start playing the

email.

Access to "

Email " depends on the

compatibility of the smartphone and the
integral system.

Managing quick messages

Press

Telephone to display the

primary page.

Press on the "

OPTIONS " button to

go to the secondary page.

Select "

Quick messages " to display

the list of messages.

Select the "

Delayed " or " My arrival "

or "

Not available " or " Other " tab

with the possibility of creating new
messages.

Select the message chosen in one of
the lists.

Press "

Create " to write a new

message.

Press "

Transfer " to select the

addressee(s).

Press "

Play " to start playing the

message.

12:13

18,5

21,5

23 °C

Audio and Telematics

Settings

According to version

Level 1

Level 2

Content .. 20 21 22 23 ..
