Citroen Berlingo Dag (2011 year). Manual

9.25

CONFIGURATION

SETTING THE DATE AND TIME

The SETUP function gives access to the following options: System

language, Date & Time, Display (Brightness, Colour, Map colour), Vehicle,

Units, System.

Adjust the settings one by one using

the direction arrows and conﬁ rm by

means of the dial.

Select the "Date format" function and

press the dial to conﬁ rm.

Select the "Set date & time" function

and press the dial to conﬁ rm.

Conﬁ rm the format required using the dial.

Pressing the SETUP button for more than 2 seconds gives

access to:

These settings must be entered again if the battery has been

disconnected.

Press the SETUP button.

Conﬁ rm the format required using

the dial.
Select the "Time format" function and

press the dial to conﬁ rm.

Set date & time

Select the "Date & Time" function

and press the dial to conﬁ rm.

Demo mode

GPS coverage

Description of the unit

Date & Time

9.26

TRIP COMPUTER

Press the MODE button several

times in succession until the trip
computer is displayed.

Range: displays the distance which can travelled with the

remaining fuel detected in the tank, based on the average fuel

consumption over the last few miles (kilometres).

This displayed value may vary signiﬁ cantly following a change in

the vehicle speed or the relief of the route.
When the range falls below 20 miles (30 km), dashes are

displayed. After ﬁ lling with at least 5 litres of fuel, the range is

recalculated and is displayed when it exceeds 60 miles (100 km).

If, whilst driving, dashes are displayed continuously in place of the

digits, contact a CITROËN dealer.

If, whilst driving, dashes are displayed continuously in place of the

Each press of the button at the end of the wiper stalk displays

the different trip computer information in succession, according to

the screen.

A FEW DEFINITIONS

The "vehicle" tab:

The range, the current fuel

consumption and the distance

remaining.

- The "1" (trip 1) tab with:

The average speed, the average

fuel consumption and the
distance travelled calculated
over route "1".

- The "2" (trip 2) tab with the same

functions for a second route.

Current fuel consumption: only calculated and displayed above

20 mph (30 km/h).
Average fuel consumption:

this is the average fuel consumption

since the last trip computer zero reset.

Distance travelled: calculated since the last trip computer zero
reset.

Distance remaining to the destination: calculated with reference

to the ﬁ nal destination, entered by the user. If guidance is activated,

the navigation system calculates it as a current value.

Average speed:

this is the average speed calculated since the last

trip computer zero reset (ignition on).

9.27

RADIO

SCREEN MENU MAP

"Traffic" Menu

Messages on route

Only warnings on route

All warning messages

All messages

Within 2 miles (3 km)

Geo. Filter

Within 3 miles (5 km)

Within 6 miles (10 km)

Within 30 miles (50 km)

Within 60 miles (100 km)

"Music" Menu

Select music

Sound settings

Balance/Fader

Bass/Treble

Linear

Equalizer

Classic

Jazz

Rock/Pop

Techno

Vocal

Loudness

Speed dependent volume

Reset sound settings

"Radio" Menu

Waveband

Linear

Manual tune

Sound settings

Balance/Fader

Bass/Treble

Equalizer

MAIN FUNCTION

OPTION A

option A1

option A2

OPTION B...

9.28

Abort guidance/Resume guidance

Destination input

Geo position

Map

Stopovers

Add stopover

Navigate HOME

Choose from address book

Rearrange route

Choose from last destinations

Replace stopover

Delete stopover

Recalculate

Fast route

Short route

Optimized route

POI search

POI nearby

Route options

Route type

Short route

Fast route

"Navigation" Menu

City

Street

Enter new address

Country

Navigate HOME

City district

House number

Start route guidance

Postal code

Save to address book

Intersection

Address input

POI near destination

POI in city

POI in country

POI near route

Choose from address book

Choose from last destinations

TMC station information

Loudness

Speed dependent volume

Reset sound settings

Classic

Jazz

Rock/Pop

Techno

Vocal

9.29

Avoid ferries

Recalculate

Settings

Navi volume

POI categories on Map

Set parameters for risk areas

Display on map

Visual alert

Sound alert

Dial from address book

"Phone" Menu

Search phone

Call lists

Connect phone

Select ring tone

Phone/Ring tone volume

Phones connected

Enter mailbox number

Settings

Disconnect phone

Rename phone

Delete pairing

Delete all pairings

Show details

"SETUP" menu

System language *

English

Español

Deutsch

Italiano

Français

Nederlands

Polski

Portuguese

Date & Time *

Set date & time

Date format

Time format

Avoid motorways

Route dynamics

Trafﬁ c independent

Semi-dynamic

Avoidance criteria

Avoid toll roads

Optimized route

* Available according to model.

9.30

* Available according to model.

Dark blue

Map colour

Night mode for map

Units

Day mode for map

Vehicle *

Vehicle information

Alert log

Status of functions

Temperature

Celsius

Fahrenheit

Metric/Imperial

Kilometres (Consumption: l/100)

Kilometres (Consumption: km/l)

Miles (Consumption: MPG)

System

Auto. Day/Night for map

Factory reset

Software version

Automatic scrolling

Colour

Pop titanium

Toffee

Blue steel

Technogrey

Display

Brightness

9.31

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

There is a difference in
sound quality between
the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the Linear musical ambience and
set the loudness correction to the "Active" position

in CD mode or to the "Inactive" position in radio

mode.

The CD is ejected

automatically or is not
played by the player.

The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

- Check that the CD is inserted in the player the

right way up.

- Check the condition of the CD: the CD cannot

be played if it is too damaged.

Check the content in the case of a recorded

CD: consult the advice in the Audio section.

- The audio equipment's CD player does not

play DVDs.

Because of their quality level, certain writeable

CDs will not be played by the audio system.

The CD player sound is

poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable

conditions.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

9.32

QUESTION

ANSWER

SOLUTION

The stored stations do
not function (no sound,

87.5 Mhz is displayed...)

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

The quality of reception
of the radio station

listened to gradually

deteriorates or the stored
stations do not function
(no sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate
a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a CITROËN dealer.

Sound cut-outs of 1 to
2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

With the engine off,

the audio equipment
switches off after a few
minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.
The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

9.33

QUESTION

ANSWER

SOLUTION

TA is selected. However,

certain trafﬁ c jams

along the route are not

indicated in real time.

On starting, it is several minutes before the system begins to receive the

trafﬁ c information.

Wait until the trafﬁ c information is being received

correctly (displaying of the trafﬁ c information

symbols on the map).

In certain countries, only major routes (motorways...) are listed for the

trafﬁ c information.

This phenomenon is normal. The system is

dependent on the trafﬁ c information available.

I receive a speed camera
alert for a camera which
is not on my route.

The system announces all speed cameras located in a conical zone
forward of the vehicle. It may detect speed cameras on nearby or parallel
roads.

Zoom the map to view the exact position of the
speed camera.

The audible speed
camera alert is not

working.

Audible alerts are not active.

Activate audible alerts in Navigation Menu,

Settings, Set parameters for risk areas.

The alert volume level is set to minimum.

Increase the speed camera alert volume.

The altitude is not
displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to

receive more than 3 satellites correctly.

Wait until the system has started up completely.

Check that there is a GPS coverage of at least

3 satellites (long press on the SETUP button, then

select GPS coverage).

Depending on the geographical environment (tunnel...) or the weather,

the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system is
dependent on the conditions of reception of the

GPS signal.

The route is not
calculated successfully.

The exclusion criteria may conﬂ ict with the current location (exclusion of

toll roads on a motorway with tolls).

Check the exclusion criteria.

9.34

QUESTION

ANSWER

SOLUTION

There is a long waiting

time after inserting a CD.

When a new medium is inserted, the system reads a certain amount of

data (directory, title, artist, etc.). This may take a few seconds.

This phenomenon is normal.

I cannot connect my
Bluetooth telephone.

The telephone's Bluetooth function may be deactivated or the equipment
may not be visible.

Check that your telephone's Bluetooth
function is activated.

Check that your telephone is visible.

A telephone connected
by Bluetooth is inaudible.

The volume level depends on both the system and the telephone.

Increase the MyWay volume setting, possibly to

maximum, and increase the telephone volume
level if necessary.

9.35

AUDIO SYSTEM

Your Audio system is coded in such a way that it will
only operate in your vehicle. If it is to be installed in
another vehicle, contact your CITROËN dealer for

only operate in your vehicle. If it is to be installed in

conﬁ guration of the system.

For safety reasons, the driver must carry out operations

which require prolonged attention while the vehicle is

stationary.
When the engine is switched off and to prevent

discharging of the battery, the audio equipment may

switch off after a few minutes.

AUDIO SYSTEM/BLUETOOTH

  01  First steps
  02  Steering mounted controls
  03  Main menu
  04  Audio
  05  USB Box
  06  Bluetooth functions
  07  Configuration
  08  Trip computer
  09  Screen menu map

p.
p.
p.
p.
p.
p.
p.
p.
p.

9.36
9.37
9.38
9.39
9.42
9.45
9.47
9.48
9.49

CONTENTS

Frequently asked questions

9.54

9.36

FIRST STEPS

1.   On/Off and volume adjustment.
  2.   CD eject.
  3.   Selection of the display on the screen from

the following modes:

3. Selection of the display on the screen from

Audio (AUDIO), Trip Computer (TRIP) and

Telephone (TEL) functions.

Audio (AUDIO), Trip Computer (TRIP) and

4. Selection of source:

radio, audio CD/MP3 CD, USB, Jack

connection, Streaming.

5. Selection of FM1, FM2, FMast and AM

wavebands.

6. Setting audio options: front/rear fader, left/

right balance, loudness, sound ambience.

7. Display the list of local stations, of the

tracks on the CD or of the MP3 folders.

8. Abandon current operation.
9. TA (Trafﬁ c Announcement) function on/off.

Long press: access to the PTY (Types of

radio programme) mode.

10. Conﬁ rmation.

11. Automatic search for a lower/higher

frequency.

Selection of previous/next CD, MP3 or USB
track.

12. Selection of a lower/higher radio frequency.

Selection of the previous/next MP3 folder.

Selection of the previous/next USB device

folder/genre/artist/playlist.

13. Display the main menu.
14. Buttons 1 to 6:

Selection of a stored radio station.

Long press: store a station.

15. The DARK button changes the display on

the screen to improve driving comfort at

night.

1st press: lighting the upper band only.

2nd press: display of a black screen.

3rd press: return to the standard display.

9.38

03 MAIN MENU

AUDIO FUNCTIONS

: radio,

CD, USB, options.

> MONOCHROME SCREEN C

For a detailed global view of the

menus available, refer to the
"Screen menu map" section.

TELEPHONE

: Bluetooth

hands-free, pairing,

management of a call.

PERSONALISATION-
CONFIGURATION

: vehicle

parameters, display, languages.

TRIP COMPUTER

: entering

of distances, alerts, status of
functions.

> MONOCHROME SCREEN A

9.37

02 STEERING MOUNTED CONTROLS

RADIO: selection of the next stored station.

USB: selection of the next genre/artist/folder from

the classiﬁ cation list.
Selection of the next item on a menu.

RADIO: selection of the previous stored station.

USB: selection of the previous genre/artist/folder

from the classiﬁ cation list.
Selection of the previous item on a menu.

RADIO: automatic search for a higher frequency.

CD/MP3/USB: selection of the next track.

CD/USB: continuous press: fast forwards play.
Selection of the previous item.

RADIO: automatic search for a lower frequency.

CD/MP3/USB: selection of the previous track.

CD/USB: continuous press: fast reverse.
Selection of the next item.

- Change of sound source.

- Conﬁ rmation of a selection.

- Pick up/Hang up the telephone.

- Press for more than 2 seconds:

access to the telephone menu.

Volume increase.

Volume decrease.

Mute: press the volume

increase and decrease
buttons simultaneously.
The sound is restored by

pressing one of the two

volume buttons.

9.39

AUDIO

Press the SOURCE button several
times in succession and select the
radio.

Press the BAND AST button to select

a waveband: FM1, FM2, FMast, AM.

Brieﬂ y press one of the buttons to

carry out an automatic search of the
radio stations.

Press one of the buttons to carry
out a manual search of the radio
stations.

Press the LIST REFRESH button to
display the list of stations received
locally (30 stations maximum).
To update this list, press for more
than two seconds.

The external environment (hills, buildings, tunnels, basement car parks, ...)

may block reception, including in RDS mode. This is a normal effect of the

way in which radio waves are transmitted and does not indicate any failure
of the audio system.

RDS

RADIO

SELECTING A STATION

Press the MENU button.

Select AUDIO FUNCTIONS then
press OK.

Select the FM WAVEBAND
PREFERENCES function then
press OK.

Select ACTIVATE RDS then press
OK. RDS appears on the screen.

The RDS, if displayed, enables you to continue listening to the same

station by automatic retuning to alternative fequencies. However, in

certain conditions, coverage of an RDS station may not be assured

throughout the country as radio stations do not cover 100 % of the

territory. This explains the loss of reception of the station during a journey.

9.40

AUDIO

Insert circular compact discs only.
Some anti-pirating systems, on original discs or CDs copied using a

personal recorder, may cause faults which are no reﬂ ection on the

quality of the original player.

Without pressing the EJECT button, insert a CD in the player, play

begins automatically.

PLAYING A CD

To play a disc which has already been
inserted, press the SOURCE button
several times in succession and
select CD.

Press one of the buttons to select a
track on the CD.

Press the LIST REFRESH button to display the list of tracks
on the CD.

Press and hold one of the buttons for
fast forward or backward.

RECEIVING TA MESSAGES

Press the TA button to activate or

deactivate trafﬁ c messages.

The TA (Trafﬁ c Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a trafﬁ c

report is transmitted, the current audio source (Radio, CD, ...) is

interrupted automatically to play the TA message. Normal playback

of the audio source resumes at the end of the transmission of the

message.

Citroen Berlingo Dag (2011 year). Manual - part 13
