Chevrolet Silverado / GMC Sierra. Service manual - part 1245

Fig. 37: View Of Rear Hood Seal
Courtesy of GENERAL MOTORS CORP.

FRONT SIDE DOOR BOTTOM AUXILIARY SEALING STRIP REPLACEMENT

Callout

Component Name

1

Rear Hood Seal



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Bolted Exterior Body Panels and Closures - Cab & Chassis Sierra, Cab & Chassis

Silverado, Sierra & Silverado



Fig. 38: View Of Front Side Door Bottom Auxiliary Sealing Strip & Retainers
Courtesy of GENERAL MOTORS CORP.

REAR SIDE DOOR BOTTOM AUXILIARY SEALING STRIP REPLACEMENT (EXTENDED CAB)

Callout

Component Name

1

Front Side Door Bottom Auxiliary Sealing Strip Retainer (Qty: 6)

2

Front Side Door Bottom Auxiliary Sealing Strip



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Bolted Exterior Body Panels and Closures - Cab & Chassis Sierra, Cab & Chassis

Silverado, Sierra & Silverado



Fig. 39: View Of Rear Side Door Bottom Auxiliary Sealing Strip & Retainers
Courtesy of GENERAL MOTORS CORP.

REAR SIDE DOOR BOTTOM AUXILIARY SEALING STRIP REPLACEMENT (CREW CAB)

Callout

Component Name

1

Rear Side Door Bottom Auxiliary Sealing Strip Retainers (Qty: 4)

2

Rear Side Door Bottom Auxiliary Sealing Strip



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Bolted Exterior Body Panels and Closures - Cab & Chassis Sierra, Cab & Chassis

Silverado, Sierra & Silverado



Fig. 40: View Of Rear Side Door Bottom Auxiliary Sealing Strip & Retainers
Courtesy of GENERAL MOTORS CORP.

REAR SIDE DOOR FRONT AUXILIARY WEATHERSTRIP REPLACEMENT (CREW CAB)

Callout

Component Name

1

Rear Side Door Bottom Auxiliary Sealing Strip Retainers (Qty: 5)

2

Rear Side Door Bottom Auxiliary Sealing Strip



2008 Chevrolet Silverado 1500

2008 ACCESSORIES & EQUIPMENT Bolted Exterior Body Panels and Closures - Cab & Chassis Sierra, Cab & Chassis

Silverado, Sierra & Silverado
