37–

7

37

 When vehicle is in lock mode, following features will occur:

- Turn signal lights blink once, anti-theft horn sounds once and anti-theft indicator on the front left

door protector blinks normally to indicate that vehicle is in lock state.

- In lock state, if no door is opened within 30 seconds after unlocking the doors by wireless key, the

doors will lock again automatically.

Lock failure mode
 System will enter lock failure mode under the following conditions and will show the following

features:
- When any door is not closed fully, turn signal lights blink twice and anti-theft horn does not

sound.

- When engine hood is not closed fully, turn signal lights blink twice, doors are locked and horn

does not sound.

- When back door is not closed fully, turn signal lights blink twice, doors are locked and horn does

not sound.

Lock deactivation mode
 In lock mode, the locking mode of entire vehicle will be deactivated if the following condition occurs:

- Press the unlock button on the wireless key.

 The following features occur in lock deactivation mode (by wireless key):

- All doors are unlocked.
- Turn signal lights blink twice, anti-theft horn does not sound and anti-theft indicator stops

blinking.

- Within 30 s after the doors are unlocked by wireless key, when no further operation is performed

(opening a door, turning the key or opening engine hood and back door), the vehicle will return to
the locking state.

 If the following conditions occur within 30 s after the doors are unlocked by wireless key, the vehicle

will not return to the locking state and the doors will not lock automatically:
- Turn ignition switch to ON.
- Any door is opened.
- Engine hood is opened.
- Back door is opened.

Alarm mode
 When vehicle is in lock mode, the alarm will be triggered if the following occurs:

- Open any door, engine hood and back door manually.
- Turn ignition switch to ON.

 When vehicle is in alarm mode, the following occurs:

- After the alarm is triggered, turn signal lights blink and anti-theft horn sounds for 25 seconds. The

condition will occur again after an interval of 5 seconds. This process will repeat for 3 times. At
the same time, the security indicator blinks quickly to indicate system is in a non-secure state. If
all doors/engine hood are fully closed or ignition switch is turned off during the cycle, the turn
signal lights will complete the cycle and all doors will lock again automatically after an interval of
5 seconds. At this time, the vehicle anti-theft system will be reactivated.

Alarm deactivation mode
 The following operation will deactivate the alarm mode:

- Press the unlock button on wireless key.

Back door open mode
 In lock mode, if the back door opener switch on remote controller is pressed for more than 1.5

seconds, turn signal lights will come on for 1 second. After that, if the back door opener switch is
pressed with 30 seconds, BCM will open the back door, but the anti-theft horn will not alarm. After 30
seconds, the back door cannot be opened.

37–

8

37

2. Power door lock system function description (w/ passive entry & passive start)

a. Power door lock system can lock/unlock all doors by remote controller, mechanical key, central controls

and contact switch on handle operation.
 Remote controller sends lock/unlock request signals to Passive Entry & Passive Start (PEPS)

controller to control the Body Control Module (BCM) by CAN. Then, Body Control Module (BCM)
sends these request signals to the lock fastener of each door in order to lock/unlock all doors
simultaneously.

 After inserting the mechanical key into the driver side door key cylinder, all doors can be locked/

unlocked by turning the key clockwise or counterclockwise, but anti-theft function cannot be set.

 When the remote controller is outside vehicle, in an operation range of 1.5 m from front door handle,

the door can be locked/unlocked by pressing door handle contact switch.

 When the remote controller is outside back door, in a operation range of 1.5 m from back door

handle, the door can be locked/unlocked by pressing back door handle contact switch.

 Function active: effective at any time, even when engine starts.
 Lock success: when all doors are closed fully, lock signal from the center controls is input to execute

the lock command.

 Lock failure: when at least one door is not closed fully, lock signal from the center controls is input to

execute the lock command, and then lock command is executed after 1 second delay.

 Unlock success: unlock signal from the center controls is input to execute the lock command,

regardless of whether the doors are closed fully.

 Door lock response: when the protection is not activated, Body Control Module (BCM) responses to

each input of lock or unlock.

b. Function (w/ passive entry & passive start)

Component

Function

Remote Controller Lock/Unlock

Lock/unlock all doors.
Remote controller inputs lock/unlock request to
Passive Entry & Passive Start (PEPS), which
controls Body Control Module (BCM) by CAN to
output lock/unlock signals to lock/unlock each door.

Mechanical Key Lock/Unlock

Lock/unlock all doors.
Mechanical key lock/unlock request is input Body
Control Module (BCM), which outputs lock/unlock
signal to lock/unlock each door.

Contact Switch on Handle Lock/Unlock Button

Lock/unlock all doors.
Contact switch on handle inputs lock/unlock request
to Passive Entry & Passive Start (PEPS), which
controls Body Control Module (BCM) by CAN to
output lock/unlock signals to lock/unlock each door.

Center Controls Lock/unlock Button

Lock/unlock all doors.
Center Controls input lock/unlock request to Passive
Entry & Passive Start (PEPS), which controls Body
Control Module (BCM) by CAN to output lock/unlock
signals to lock/unlock each door.

Front Left Door Lock Assembly

Lock/unlock front left door with a fastener.
Built-in door lock/unlock switch sends lock/unlock
signal to Body Control Module (BCM) to lock/unlock
each door.

37–

9

37

c. Wireless key match (w/ passive entry & passive start)

 Connect X-431 3G diagnostic tester (the latest

software) to Data Link Connector (DLC), and make
it communicate with vehicle electronic module by
the data network. Then select corresponding
model (T21) from X-431 3G diagnostic tester (the
latest software) to enter the system and select
"IMMO" system.

 Please select [After sale function] on SELECT

FUNCTION screen.

 Please select [Key match] on After sale function

screen.

 Please select [Add the old keys] on Perform

routine program screen.

Front Right Door Lock Assembly
Rear Left Door Lock Assembly
Rear Right Door Lock Assembly

Lock/unlock front right door with a fastener.
Lock/unlock rear left door with a fastener.
Lock/unlock rear right door with a fastener.

Component

Function

ICM

PEPS

IMMO

AT

BCM

SRS

ABS

ENG

Menu

RT21370020

After sale function

Write data

Read data stream

Erase fault code

Read fault code

SELECT FUNCTION

RT21370030

Reprogramming IMMO

Key match

Erase keys

Reprogramming ECM

Programming IMMO(learn SK from TCU)

Programming IMMO(learn SK from EMS)

Programming ECM

Match all the systems

After sale function

RT21370040

Add the old keys.

Add new keys.

Perform routine program

RT21370042

37–

10

37

 When "Please enter a PIN with 8 digits" is

displayed on Input screen, input PIN code and
click "OK".

 When "Please enter again" is displayed on Input

screen, input PIN code again and click "OK".

 When "Please Input Repair Shop Code. The length

is 10 digits from 0 to 9, A-Z, a-z" is displayed, click
"Cancel".

 When "Please Input programming. The length is 8

digits from 0 to 9" is displayed, click "Cancel".

Input

Please enter a PIN with 8 digits.

1

2

3

4

5

6

7

8

9

0

-

=

bs

Q

W

E

R

T

Y

U

I

O

P

[

]

\

A

S

D

F

G

H

J

K

L

;

Z

`

X

Tab

Caps

OK

Cancel

Space

Ins

Del

C

V

B

N

M

,

.

/

lt

rt

‘

ENTER

X X X X X X X X

RT21370043

Input

Please enter again.

1

2

3

4

5

6

7

8

9

0

-

=

bs

Q

W

E

R

T

Y

U

I

O

P

[

]

\

A

S

D

F

G

H

J

K

L

;

Z

`

X

Tab

Caps

OK

Cancel

Space

Ins

Del

C

V

B

N

M

,

.

/

lt

rt

‘

ENTER

X X X X X X X X

RT21370044

Input

Please Input Repair Shop Code.
The length is 10 digits from 0 to 9. A~z. a~z

1

2

3

4

5

6

7

8

9

0

-

=

bs

Q

W

E

R

T

Y

U

I

O

P

[

]

\

A

S

D

F

G

H

J

K

L

;

Z

`

X

Tab

Caps

OK

Cancel

Space

Ins

Del

C

V

B

N

M

,

.

/

lt

rt

‘

ENTER

RT21370045

Input

Please Input programming.
The length is 8 digits from 0 to 9

1

2

3

4

5

6

7

8

9

0

-

=

bs

Q

W

E

R

T

Y

U

I

O

P

[

]

\

A

S

D

F

G

H

J

K

L

;

Z

`

X

Tab

Caps

OK

Cancel

Space

Ins

Del

C

V

B

N

M

,

.

/

lt

rt

‘

ENTER

RT21370046
