Chery Tiggo 5 (T21). Service manual - part 324

30–

28

1

31

AIR CONDITIONING

GENERAL INFORMATION

31-3

Description 31-3
Specifications 31-5
Tools 31-7
Circuit Diagram

31-8

DIAGNOSIS & TESTING

31-15

Problem Symptoms Table

31-15

Diagnosis Procedure

31-17

A/C System Function

31-19

DTC Confirmation Procedure

31-21

Intermittent DTC Troubleshooting

31-21

Ground Inspection

31-21

Diagnostic Trouble Code (DTC)



Chart 31-22
B2133 31-23
B2134 31-23
B2120 31-28
B2121 31-28
B2126 31-32
B2127 31-37
B2135 31-41
B2160 31-45
B2163 31-45
B2166 31-50
B2169 31-54
B2172 31-59

ON-VEHICLE SERVICE

31-63

On-vehicle Inspection

31-63

Compressor Assembly Noise



Inspection 31-63
Refrigerant Leakage Inspection

31-64

Refrigerant Recovering/Draining

31-66

Vacuum Pumping

31-67

Refrigerant Recharging

31-67

Refrigerant Oil Recovering

31-68

Refrigerant Oil Charging

31-69

A/C Control Panel Assembly

31-70

Removal 31-70
Inspection 31-71
Installation 31-71

A/C Element

31-72

Removal 31-72
Installation 31-72

Blower Assembly

31-73

Removal 31-73
Inspection 31-73
Installation 31-73

Blower Speed Resistor

31-74

Removal 31-74
Installation 31-74

Inner/Outer Circulation Damper



Motor 31-75

Removal 31-75
Installation 31-75

Mode Damper Servo Motor

31-76

Removal 31-76
Installation 31-76

Mix Damper Servo Motor

31-77

Removal 31-77
Installation 31-77

HVAC Assembly

31-78

Removal 31-78
Disassembly 31-80
Inspection 31-90
Assembly 31-93
Installation 31-93

A/C Low Pressure Line

31-94

Removal 31-94
Installation 31-95

A/C High Pressure Line

31-96

Removal 31-96
Installation 31-98

Compressor Assembly

31-99

Removal 31-99
Installation 31-101

Condenser Assembly



(w/Receiver Drier)

31-102

Removal 31-102
Inspection 31-103
Installation 31-104

Mix Damper Servo Motor



(Left - Automatic A/C)

31-105

Removal 31-105
Installation 31-105

Room Temperature Sensor



(for Automatic A/C)

31-106

Removal 31-106
Inspection 31-107
Installation 31-108

2

31

Outside Temperature Sensor



(for Automatic A/C)

31-109

Inspection 31-109

Heater Core Sensor



(for Automatic A/C)

31-112

Inspection 31-112

31–

3

31

AIR CONDITIONING

GENERAL INFORMATION

Description

1 - Condenser Assembly (w/Receiver Drier)

2 - O-ring

3 - Condenser to Evaporator Line Assembly

4 - HVAC Assembly

5 - A/C Control Panel Assembly

6 - Evaporator to Compressor Line Assembly

7 - Compressor Assembly

8 - Compressor to Condenser Line Assembly

RT21310010

8

7

2

3

6

4

5

1
