Chery Tiggo 5 (T21). Service manual - part 181

15–

59

15

a. Turn ignition switch off.
b. Disconnect the instrument panel fuse and relay box

connectors I-007 and I-031.

c. Check the wire harness between terminal E10 of

instrument panel fuse and relay box connector I-031 and
terminal J101 of PEPS controller connector I-029.
Check for Open

Check for Short

d. Check the wire harness between terminal 7 of instrument

panel fuse and relay box connector I-007 and terminal
J111 of PEPS controller connector I-029.
Check for Open

Check for Short

5

Check PEPS controller power supply circuit

NG

-

+

RT21150430

J101

J102

J103

J104

J105

J106

J107

J108

J109

J110

J111

J112

J113

J114

J115

J116

I-029

E20

E19

E18

E17

E12

E11

E10

E9

E4

E3

E2

E1

E8

E7

E6

E5

E16

E15

E14

E13

I-031

Multimeter

Connection

Condition

Specified

Condition

I-031 (E10) -

I-029 (J101)

Always

Continuity

Multimeter

Connection

Condition

Specified

Condition

I-031 (E10) or

I-029 (J101) -

Body ground

Always

No continuity

I-031 (E10) or

I-029 (J101) -

Battery positive

Always

No continuity

-

+

RT21150440

J101

J102

J103

J104

J105

J106

J107

J108

J109

J110

J111

J112

J113

J114

J115

J116

I-029

1

2

3

4

5

6

7

8

9 10 11 12

13

85

85

87

87 30

87 30

30

86

86

85

86

14 15 16 17 18 19 20 21 22 23 24

25

27

26

I-007

Multimeter

Connection

Condition

Specified

Condition

I-007 (7) - I-029

(J111)

Always

Continuity

Multimeter

Connection

Condition

Specified

Condition

I-007 (7) or I-029

(J111) - Body

ground

Always

No continuity

I-007 (7) or I-029

(J111) - Battery

positive

Always

No continuity

15–

60

15

a. Disconnect the CVT connector A (arrow).

b. Check the CVT connector A.

Repair or replace related wire harness or
connector (instrument panel fuse and
relay box - PEPS controller)

NG

6

Check CVT connector A

OK

RT21150451

Gearshift Position

Terminal No.

Specified Condition

P

1 - 7, 9 - 10

Continuity

R

7 - 8

N

2 - 7, 9 - 10

D

3 - 7

L

4 - 7

Repair or replace CVT connector A

NG

OK

15–

61

15

a. Disconnect the engine compartment wire harness

connector E-067.

b. Check the wire harness between PEPS controller

connector I-029 and engine compartment fuse and relay
box connector E-067.
Check for Open

Check for Short

c. Check the wire harness between PEPS controller

connector I-029 and CVT connector A E-050.
Check for Open

Check for Short

7

Check wire harness (instrument panel - engine compartment)

-

+

RT21150450

J101

J102

J103

J104

J105

J106

J107

J108

J109

J110

J111

J112

J113

J114

J115

J116

I-029

E-067

H8

H16

H7

H15

H6

H14

H5

H13

H4

H12

H3

H11

H2

H10

H1

H9

Multimeter

Connection

Condition

Specified

Condition

I-029 (J110) -

E-067 (H5)

Always

Continuity

Multimeter

Connection

Condition

Specified

Condition

I-029 (J110) or

E-067 (H5) - Body

ground

Always

No continuity

I-029 (J110) or

E-067 (H5) -

Battery positive

Always

No continuity

-

+

RT21150460

J101

J102

J103

J104

J105

J106

J107

J108

J109

J110

J111

J112

J113

J114

J115

J116

I-029

E-050

6

4

2

1

5

3

8

7

9

10

Multimeter

Connection

Condition

Specified

Condition

I-029 (J110) -

E-050 (9)

Always

Continuity

I-029 (J113) -

E-050 (10)

Always

Continuity

Multimeter

Connection

Condition

Specified

Condition

I-029 (J110) or

E-050 (9) - Body

ground

Always

No continuity

I-029 (J113) or

E-050 (10) - Body

ground

Always

No continuity

I-029 (J110) or

E-050 (9) -

Battery positive

Always

No continuity

I-029 (J113) or

E-050 (10) -

Battery positive

Always

No continuity

15–

62

15

a. Disconnect the starter control connector E-014 and engine

compartment fuse and relay box connector E-022.

b. Check the starter field wire harness.

Check for Open

Check for Short

a. Connect related wire harness connectors.
b. Connect the negative battery cable.
c. Turn ignition switch ON.
d. Connect X-431 3G diagnostic tester to Data Link Connector (DLC) to check if any DTC is detected.

Repair or replace wire harness
(instrument panel - engine compartment)

NG

8

Check starter field wire harness

OK

-

+

RT21150470

1

L2

L1

E-014

E-022

Multimeter

Connection

Condition

Specified

Condition

E-014 (1) - E-022

(L1)

Always

Continuity

Multimeter

Connection

Condition

Specified

Condition

E-014 (1) or

E-022 (L1) - Body

ground

Always

No continuity

E-014 (1) or
E-022 (L1) -

Battery positive

Always

No continuity

Repair or replace starter field wire
harness

NG

9

Confirm DTCs

OK

System operates normally

OK

NG
