Lincoln Aviator (2020 year). Instruction - part 27

Materials

Specification

Name

WSL-M2C192-A

Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant (U.S.)
Motorcraft® SAE 75W-140 Synthetic Rear Axle Lubricant / Lubrifiant synthétique
pour pont arrière SAE 75W-140 Motorcraft® (Canada)
XY-75W140-QL (U.S.)
CXY-75W140-1L (Canada)

Rear Axle

Capacities

Quantity

Variant

1.9 qt (1.8 L)

All.

425

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Capacities and Specifications

Materials

Specification

Name

WSS-M2C942-A

Motorcraft® SAE 75W-85 Premium Synthetic Hypoid Gear Lubricant (U.S.)
Motorcraft® SAE 75W-85 Premium Synthetic Hypoid Gear Lubricant / Huile
synthétique de haute qualité pour engrenages hypoïdes SAE 75W-85 Motorcraft®
(Canada)
XY-75W85-QL (U.S. & Canada)

Washer Reservoir

Capacities

Quantity

Variant

Fill as required.

All.

426

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Capacities and Specifications

Materials

Specification

Name

WSS-M14P19-A

Motorcraft® Premium Windshield Wash Concentrate with Bitterant (U.S.)
Motorcraft® Premium Quality Windshield Washer Fluid / Liquide lave-glace de haute
qualité Motorcraft® (Canada)
ZC-32-B2 (U.S.)
CXC-37-A/B/D/F (Canada)

BULB SPECIFICATION CHART

All exterior and interior lamps are LED.

Note: LED lamps are not serviceable. See
an authorized dealer if they fail.

427

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Capacities and Specifications

INSTALLING THE VEHICLE
IDENTIFICATION CARD

Install any devices that use radio frequency
identification, for example, toll readers or
vehicle identification cards, to the specified
area on the windshield.

Note: Follow the manufacturer’s installation
instructions.

Note: When installing the radio frequency
identification device, do not block objects
such as the rain sensor and the
auto-dimming sensor.

E291100

Dimension

Dimension Description

Item

2 in (40 mm)

The top edge of the windshield to the top

edge of the identification card.

A

4 in (100 mm)

The center of the windshield to the right edge

of the identification card.

B

428

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Vehicle Identification

CONNECTING THE VEHICLE TO A
MOBILE NETWORK

About the Modem

The modem allows you to connect your
vehicle to the Internet to use when you are
on the road.

If you enable the modem using the Lincoln
Way app, you can access the following
services:
•

Locating and remotely starting, locking
and unlocking your vehicle. See the
information in the Lincoln Way app.

•

Automatic system updates.

Note: We may need to update operating
system software on your vehicle to keep
connected services updated without prior
notice to you.

Enabling the Modem Using The Lincoln
Way

1. Open the Lincoln Way app on your

device and log in.

2. Select your vehicle.

3. Select the option for vehicle details.

4. Select the option to activate your vehicle.

5. Switch the ignition on.

6. Make sure that the name on the screen

matches the name shown in your Lincoln
Way account.

7. Confirm the association of your vehicle

with your Lincoln Way account.

Enabling the Modem Using the
Touchscreen

E280315

Select the settings option on the
feature bar.

1. Select Lincoln Connect .

2. Select Connectivity Settings.

3. Switch connectivity features on.

429

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Network Connectivity

NETWORK CONNECTIVITY – TROUBLESHOOTING

Wi-Fi Network

Possible Cause and Resolution

Symptom

I cannot connect to a Wi-Fi network.

– Password error.

•

Enter the correct network password.

– Weak network signal.

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

– Multiple access points in range with the same SSID.

•

Use a unique name for your SSID,. Do not use the default name unless it contains a
unique identifier, for example as part of the MAC address.

The Wi-Fi connection disconnects after
successful connection.

– Weak network signal.

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

I am close to a Wi-Fi hotspot but the network
signal strength is weak.

– Obstructed network signal.

•

If your vehicle has a heated windshield, position your vehicle so that the windshield
is not facing the Wi-Fi hotspot.

•

If your vehicle has metallic tinting on the windows but not on the windshield, position
your vehicle so that the windshield is facing the Wi-Fi hotspot or open the windows
that are facing the hotspot.

430

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Network Connectivity

Possible Cause and Resolution

Symptom

•

If your vehicle has metallic tinting on the windows and the windshield, open the
windows that are facing the hotspot.

•

If your vehicle is in a garage and you have the garage door closed, open the garage
door.

I cannot see a network in the list of available
networks that I expect to see.

– Hidden network.

•

Make the network visible and try again.

I cannot see the Wi-Fi Hotspot name when I
search for Wi-Fi networks on my cell phone
or other device.

– System limitation.

•

Make sure Wi-Fi hotspot visibility is on.

•

The system does not provide a Wi-Fi hotspot at this time.

– Weak network signal

•

Move your vehicle closer to the Wi-Fi hotspot or to a place where the network signal
is not obstructed.

– Wi-Fi hotspot in high demand or has a slow Internet connection.

•

Use an more reliable Wi-Fi hotspot.

Software downloads take too long.

– No software update available.
– Wi-Fi network requires a subscription or acceptance of terms and conditions.

•

Test the connection using another device. If the network requires a subscription or
acceptance of terms and conditions, contact the network service provider.

The system seems to connect to a Wi-Fi
network and the signal strength is excellent
but the software does not update.

431

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Network Connectivity

Mobile Network

Possible Cause and Resolution

Symptom

– Modem is not enabled.

•

Enable the modem through Lincoln Way.

– Weak network signal.

•

Move your vehicle closer to a place where the network signal is not obstructed.

I cannot confirm association with Lincoln Way
when trying to enable the modem.

432

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Network Connectivity

CREATING A WI-FI HOTSPOT

You can create a Wi-Fi hotspot in your
vehicle and allow devices to connect to it for
access to the Internet.

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect.
2. Select Vehicle Hotspot.
Note: The vehicle hotspot default setting is
on.

Finding the Wi-Fi Hotspot Name and
Password

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect.

2. Select Vehicle Hotspot.

3. Select Settings.

Note: The SSID is the hotspot name.

4. Select View Password.

Connecting a Device to the Wi-Fi
Hotspot

1. On your device, turn on Wi-Fi and select

the hotspot from the list of available Wi-Fi
networks.

2. When prompted, enter the password.

Purchasing a Data Plan

1. Connect a device to the hotspot.
Note: The vehicle network carrier’s portal
opens on your device.

2. If the portal does not open on your

device, open a website and it redirects
to the vehicle network carrier’s portal.

Note: Secure websites do not redirect.

3. Follow the instructions on the carrier

portal to purchase a plan.

Note: If you have an active plan, the system
does not redirect to the vehicle network
carrier’s portal when you connect a device.
Visit the vehicle network carrier’s website to
purchase more data.

Note: If data usage information is available
in the vehicle hotspot menu, it is
approximate.

Note: If you carry out a master reset, the
system does not remove your vehicle from
your vehicle network carrier’s account. To
remove your vehicle from the account,
contact your vehicle network carrier.

Note: The vehicle network carrier provides
Vehicle Hotspot services, subject to your
vehicle network carrier agreement, coverage
and availability.

CHANGING THE WI-FI HOTSPOT
NAME OR PASSWORD

E280315

Press the button to enter the
settings menu.

1. Select Lincoln Connect .

2. Select Vehicle Hotspot.

3. Select Settings.

4. Select Edit .

5. Select Change SSID Name.

433

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Wi-Fi Hotspot

6. Enter your required SSID.

7. Select Done.
8. Select Change Password .

9. Enter your required password.

10.

Select Done.

434

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Wi-Fi Hotspot

GENERAL INFORMATION

Radio Frequencies and Reception
Factors

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any

device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

Note: Listening to loud audio for long
periods of time could damage your hearing.

Radio Reception Factors

The further you travel from an AM or FM station, the weaker the signal and the weaker the reception.

Distance and strength

Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree foliage and
thunderstorms can interfere with the reception.

Terrain

When you pass a ground-based broadcast repeating tower, a stronger signal may overtake a weaker one and
result in the audio system muting.

Station overload

435

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Audio System

AUDIO UNIT

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

E286905

Note: Depending on your vehicle option
package, the controls may look different
from what you see here.

Note: Some features, such as satellite radio,
may not be available in your location. Check
with an authorized dealer.

Note:  The touchscreen system controls most
of the audio features.

Adjusting the Volume

E265373

Turn to adjust the volume.

Changing Radio Stations

E265696

In radio mode, turn to search through the
radio frequency band.

In satellite radio mode, turn to find the
previous or next available satellite radio
station.

436

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Audio System

Locking the Rear Audio Controls

 (If

Equipped)

E270448

Press and release the button to
lock the rear passenger audio
controls.

Selecting the Audio Modes

E265276

Press and release the button to
access different audio modes such
as AM, FM and CD.

Switching the Audio Unit On and Off

Press and release the button.

Switching the Display On and Off

 (If

Equipped)

E272035

Press and release the button.

Using Seek, Fast Forward and Reverse

In radio mode, select a frequency band and
press and release either button. The system
stops at the first station it finds in that
direction.

In satellite radio mode, press and release to
select the next or previous satellite radio
station. If you select a specific category, such
as jazz, rock or news, press to find the next
or previous station in that category.

Rear Passenger Audio Controls

Use the rear passenger touchscreen to
select the following:

E100027

Touch the audio button on the
feature bar.

Note: Depending on the source selected,
some options may not be available.

Accessing the Source Menu

E287123

Touch the button to access the
source menu.

Selecting a Preset

Touch Presets to select a preset station.

Switching Repeat Mode On and Off

E287125

Touch the button to cycle through
the various repeat modes and off.

Switching Shuffle Mode On and Off

Touch the button to play music on
the selected source in random
order.

Playing or Pausing Media

Touch the button to either play or
pause the audio.

437

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Audio System

Switching the Audio Control On and
Off

Adjusting the Volume

Touch the arrow buttons to adjust the
volume.

Using Seek, Fast Forward and Reverse

In radio mode, select a frequency band and
touch either button. The system stops at the
first station it finds in that direction.

In satellite radio mode, touch to select the
next or previous satellite radio station. If you
select a specific category, such as jazz, rock
or news, touch to find the next or previous
station in that category.

Rear Audio Control Lock Message

A message displays when the controls are
locked through the front and you try to
operate them.

Note: The controls also lock when a voice
session or phone call is active.

DIGITAL RADIO

 (IF EQUIPPED)

Note: HD Radio broadcasts are not available
in all markets.

HD Radio technology is the digital evolution
of analog AM/FM radio. Your system has a
special receiver that allows it to receive
digital broadcasts, where available, in
addition to the analog broadcasts, it already
receives. Digital broadcasts provide a better
sound quality than analog broadcasts with
free, crystal-clear audio and no static or
distortion. For more information, and a guide
to available stations and programming,
please visit www.hdradio.com.

When HD Radio is on and you tune to a
station broadcasting HD Radio technology,
you may notice the HD Radio logo on your
screen. When this logo is available, you may
also see Title and Artist fields on-screen.

The multicast indicator appears in FM mode,
only, if the current station is broadcasting
multiple digital broadcasts. The highlighted
numbers signify available digital channels
where new or different content is available.
HD1 signifies the main programming status
and is available in analog and digital
broadcasts. Other multicast stations, HD2
through HD7, are only available digitally.

When HD Radio broadcasts are active, you
can access the following functions:
•

Memory presets allow you to save an
active channel as a memory preset.
Touch and hold a memory preset slot
until the sound returns. There is a brief
mute while the radio saves the station.
Sound returns when finished. When
switching to an HD2 or HD3 memory
preset, the sound mutes before the
digital audio plays, because the system
has to reacquire the digital signal.

438

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Audio System

Note: As with any saved radio station, you
cannot access the saved station if your
vehicle is outside the station’s reception
area.

HD Radio Reception and Station Troubleshooting

Potential reception issues

If you are listening to a multicast station and you are on the fringe of the reception area, the station may mute
due to weak signal strength.

Reception area

If you are listening to HD1, the system switches back to the analog broadcast until the digital broadcast is
available again. However, if you are listening to any of the possible HD2-HD7 multicast channels, the station
mutes and stays muted unless it is able to connect to the digital signal again.

When the system first receives a station, aside from HD2-HD7 multicast stations, it first plays the station in the
analog version. Once the receiver verifies the station is an HD Radio station, it shifts to the digital version.
Depending on the station quality, you may hear a slight sound change when the station changes from analog
to digital. Blending is the shift from analog to digital sound or digital back to analog sound.

Station blending

439

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Audio System

In order to provide the best possible
experience, use the contact form to report
any station issues found while listening to a
station broadcasting with HD Radio

technology. Independent entities own and
operate each station. These stations are
responsible for the accuracy of all audio
streams and data fields.

Potential station issues

Action

Cause

Issues

No action required.  This is a broadcast issue.

This is poor time alignment by the radio
broadcaster.

Echo, stutter, skip or repeat in audio.
Increase or decrease in audio volume.

No action required.  The reception issue may
clear up as you continue to drive.

The radio is shifting between analog and
digital audio.

Sound fading or blending in and out.

No action required.  This is normal behavior.
Wait until the audio is available.

The digital multicast is not available until the
HD Radio broadcast is decoded. Once
decoded, the audio is available.

There is an audio mute delay when selecting
HD2 or HD3, multicast preset or Direct Tune.

No action required.  The station is not avail-
able in your current location.

The previously stored multicast preset or
direct tune is not available in your current
reception area.

Cannot access HD2 or HD3 multicast channel
when recalling a preset or from a direct tune.

Fill out the station issue form at website listed

below.

1

Data service issue by the radio broadcaster.

Text information does not match currently
playing audio.

Fill out the station issue form at website listed

below.

1

Data service issue by the radio broadcaster.

There is no text information shown for
currently selected frequency.

1

http://hdradio.com/stations/feedback

440

Aviator (CTV) Canada/United States of America, enUSA, Edition date: 201902, Second-Printing

Audio System
