feature. Children 12 years old and under should always
be properly restrained in a vehicle with a rear seat.

WARNING!

• Never place a rear-facing child restraint in front of

an air bag. A deploying Passenger Advanced Front
Air Bag can cause death or serious injury to a child
12 years or younger, including a child in a rear-
facing child restraint.

• Only use a rear-facing child restraint in a vehicle

with a rear seat.

How To Engage The Automatic Locking Mode

1. Buckle the combination lap and shoulder belt.

2. Grasp the shoulder portion and pull downward until

the entire seat belt is extracted.

3. Allow the seat belt to retract. As the seat belt retracts,

you will hear a clicking sound. This indicates the seat
belt is now in the Automatic Locking Mode

How To Disengage The Automatic Locking Mode

Unbuckle the combination lap/shoulder belt and allow it
to retract completely to disengage the Automatic Locking
Mode and activate the vehicle sensitive (emergency)
locking mode.

WARNING!

• The seat belt assembly must be replaced if the

switchable Automatic Locking Retractor (ALR) fea-
ture or any other seat belt function is not working
properly when checked according to the proce-
dures in the Service Instruction.

(Continued)

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING! (Continued)

• Failure to replace the seat belt assembly could

increase the risk of injury in collisions.

• Do not use the Automatic Locking Mode to restrain

occupants who are wearing the seat belt or children
who are using booster seats. The locked mode is
only used to install rear-facing or forward-facing
child restraints that have a harness for restraining
the child.

Supplemental Restraint System (SRS)

Air Bag System Components

Your vehicle may be equipped with the following air bag
system components:

• Occupant Restraint Controller (ORC)
• Air Bag Warning Light

• Steering Wheel and Column
• Instrument Panel
• Knee Impact Bolsters
• Advanced Front Air Bags
• Supplemental Side Air Bags
• Seat Belt Pretenioners
• Seat Belt Buckle Switch
• Seat Track Position Sensors
• Front and Side Impact Sensors
• Occupant Classification System

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Advanced Front Air Bags

This vehicle has Advanced Front Air Bags for both the
driver and front passenger as a supplement to the seat
belt systems. The driver’s Advanced Front Air Bag is
mounted in the center of the steering wheel. The passen-
ger’s Advanced Front Air Bag is mounted in the instru-
ment panel, above the glove compartment. The words
SRS AIRBAG are embossed on the air bag covers.

Advanced Front Air Bag And Knee Impact Bolster

Locations

1 — Driver And Passenger Advanced Front Air Bags
2 — Driver And Passenger Knee Impact Bolster

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

• Being too close to the steering wheel or instrument

panel during Advanced Front Air Bag deployment
could cause serious injury, including death. Air
bags need room to inflate. Sit back, comfortably
extending your arms to reach the steering wheel or
instrument panel.

• Never place a rear-facing child restraint in front of

an air bag. A deploying Passenger Advanced Front
Air Bag can cause death or serious injury to a child
12 years or younger, including a child in a rear-
facing child restraint.

• Only use a rear-facing child restraint in a vehicle

with a rear seat.

Advanced Front Air Bag Features

The Advanced Front Air Bag system has multistage
driver and front passenger air bags. This system provides

output appropriate to the severity and type of collision as
determined by the Occupant Restraint Controller (ORC),
which may receive information from the front impact
sensors or other system components.

The first stage inflator is triggered immediately during an
impact that requires air bag deployment. A low energy
output is used in less severe collisions. A higher energy
output is used for more severe collisions.

This vehicle may be equipped with driver and/or front
passenger seat track position sensors that may adjust the
inflation rate of the Advanced Front Air Bags based upon
seat position.

This vehicle may be equipped with a driver and/or front
passenger seat belt buckle switch that detects whether
the driver or front passenger seat belt is buckled. The seat
belt buckle switch may adjust the inflation rate of the
Advanced Front Air Bags.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Advanced Air Bag Features

This vehicle has an Occupant Classification System
(“OCS”) in the right front passenger seat. The OCS is
designed to deactivate the front Passenger Advanced
Front Air Bag for an unoccupied seat and for occupants
classified in a category other than a properly seated
adult. This could be a child, teenager, or even an adult.

The Passenger Air Bag Disable (“PAD”) Indicator Light
(an amber light located in the center of the instrument
panel) tells the driver and front passenger when the
Passenger Advanced Front Air Bag is deactivated. The
PAD Indicator Light illuminates the words “PASSENGER
AIR BAG OFF” to show that the Passenger Advanced
Front Air Bag will not inflate during a collision.

WARNING!

• No objects should be placed over or near the air

bag on the instrument panel or steering wheel,
because any such objects could cause harm if the
vehicle is in a collision severe enough to cause the
air bags to inflate.

• Do not put anything on or around the air bag

covers or attempt to open them instructionly. You may
damage the air bags and you could be injured
because the air bags may no longer be functional.
The protective covers for the air bag cushions are
designed to open only when the air bags are
inflating.

(Continued)

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING! (Continued)

• Relying on the air bags alone could lead to more

severe injuries in a collision. The air bags work
with your seat belt to restrain you properly. In
some collisions, air bags won’t deploy at all. Al-
ways wear your seat belts even though you have air
bags.

Advanced Front Air Bag Operation

Advanced Front Air Bags are designed to provide addi-
tional protection by supplementing the seat belts. Ad-
vanced Front Air Bags are not expected to reduce the risk
of injury in rear, side, or rollover collisions. The Ad-
vanced Front Air Bags will not deploy in all frontal
collisions, including some that may produce substantial
vehicle damage — for example, some pole collisions,
truck underrides, and angle offset collisions.

On the other hand, depending on the type and location of
impact, Advanced Front Air Bags may deploy in crashes
with little vehicle front-end damage but that produce a
severe initial deceleration.

Because air bag sensors measure vehicle deceleration
over time, vehicle speed and damage by themselves are
not good indicators of whether or not an air bag should
have deployed.

Seat belts are necessary for your protection in all colli-
sions, and also are needed to help keep you in position,
away from an inflating air bag.

When the ORC detects a collision requiring the Ad-
vanced Front Air Bags, it signals the inflator units. A large
quantity of non-toxic gas is generated to inflate the
Advanced Front Air Bags.

The steering wheel hub trim cover and the upper right
side of the instrument panel separate and fold out of the

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

way as the air bags inflate to their full size. The Advanced
Front Air Bags fully inflate in less time than it takes to
blink your eyes. The air bags then quickly deflate while
helping to restrain the driver and front passenger.

Occupant Classification System (OCS) - Front
Passenger Seat

The OCS is part of a Federally regulated safety system for
this vehicle. It is designed to deactivate the front passen-
ger Advanced Front Air Bag for an unoccupied seat and
for occupants classified in a category other than a prop-
erly seated adult. This could be a child, teenager, or even
an adult.

WARNING!

• Never place a rear-facing child restraint in front of

an air bag. A deploying Passenger Advanced Front
Air Bag can cause death or serious injury to a child
12 years or younger, including a child in a rear-
facing child restraint.

• Only use a rear-facing child restraint in a vehicle

with a rear seat.

The Occupant Classification System (OCS) consists of the
following:

• Occupant Restraint Controller (ORC)
• Occupant Classification Module (OCM) located under-

neath the front passenger seat

• Bladder located beneath the passenger seat cushion

foam

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

• Passenger Air Bag Disabled (PAD) Indicator Light – an

amber light located in the center of the instrument
panel

• Air Bag Warning Light

Occupant Classification Module (OCM)

The Occupant Classification Module (OCM) is located
underneath the front passenger seat. The OCM uses
input from the Bladder to determine the front passen-
ger’s most probable classification. The OCM communi-
cates this information to the ORC. The ORC may deacti-
vate the Passenger Advanced Front Air Bag deployment
based on occupant classification.

Bladder

The Bladder is located beneath the passenger seat cush-
ion foam. The Bladder sends signals to the OCM for
classifying the occupant in the front passenger seat. Any
weight on the seat will be sensed by the Bladder. In order
for the OCS to operate as designed, it is important for the
front passenger to be seated properly and properly
wearing the seat belt. Properly seated passengers are:

• Sitting upright
• Facing forward
• Sitting in the center of the seat with their feet comfort-

ably on or near the floor

• Sitting with their back against the seat back and the

seat back in an upright position

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The Passenger Advanced Front Air Bag may be deacti-
vated if the OCS estimates that:

• The front passenger seat is unoccupied or has very

light objects on it

• The front passenger seat is occupied by a rear-facing

child restraint

• The front passenger seat is occupied by a child,

including a child seated in a forward-facing child
restraint or booster seat

• The front passenger seat is occupied by a small pas-

senger, including a small adult

• The front passenger is not properly seated or his/her

weight is taken off of the seat for a period of time

Seated Properly

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Passenger Air Bag Disable (PAD) System

Passenger Seat
Occupant
Status

Passenger
Advanced Air
Bag Disabled
Indicator Light
(“PAD”) Status

Passenger Air
Bag Status

Unoccupied
seat *

NOT ILLUMI-
NATED

DEACTIVATED

Grocery bags,
heavy brief-
cases, and other
relatively light
objects

“PASSENGER
AIR BAG OFF”

DEACTIVATED

Rearward facing
infant seat**

“PASSENGER
AIR BAG OFF”

DEACTIVATED

Passenger Seat
Occupant
Status

Passenger
Advanced Air
Bag Disabled
Indicator Light
(“PAD”) Status

Passenger Air
Bag Status

Child, including
a child seated in
a forward-
facing child re-
straint or
booster seat**

“PASSENGER
AIR BAG OFF”

DEACTIVATED

Small adult

“PASSENGER
AIR BAG OFF”

DEACTIVATED

Properly seated
adult

NOT ILLUMI-
NATED

ACTIVATED

* When the right front passenger seat is empty or when
very light objects are placed on the seat, the passenger

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Advanced Front Air Bag will not inflate even though the
Passenger Air Bag Disable (PAD) System Indicator Light
is NOT illuminated.

** It is possible for a child to be classified as an adult,
allowing the deployment of the passenger Advanced
Front Air Bag. Never allow children to ride in the front
passenger seat and never install a child restraint system,
including a rear-facing child restraint, in this vehicle.

Passenger Advanced Front Air Bag Disabled (PAD)
Indicator Light

The PAD Indicator Light (an amber light located in the
center of the instrument panel) tells the driver and front
passenger when the passenger Advanced Front Air Bag is
deactivated. The PAD Indicator light illuminates the
words “PASSENGER AIR BAG OFF” to show that the
Passenger Advanced Front Air Bag will not inflate during
a collision. When the right front passenger seat is empty
or when very light objects are placed on the seat, the

Passenger Advanced Front Air Bag will not inflate even
though the PAD Indicator Light is not illuminated.

The PAD Indicator Light should not be illuminated when
an adult passenger is properly seated in the front passen-
ger seat. Drivers and adult passengers should verify that
the PAD Indicator Light is not illuminated when an adult
is riding in the front passenger seat. If an adult is not
seated properly the Passenger Advanced Front Air Bag
may be deactivated and the PAD Indicator Light will be
illuminated.

The PAD Indicator Light should be illuminated and the
Passenger Advanced Front Air Bag should be deactivated
for most properly seated and restrained children in the
passenger seat and for most properly installed child
restraint systems. However, under certain conditions,
even with a properly installed child restraint system, the
PAD Indicator Light may not be illuminated, even
though the Advanced Front Air Bag is deactivated. This

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

can occur if the child restraint is lighter than the lightest
weight necessary to illuminate the PAD Indicator Light.
NEVER assume the Passenger Advanced Front Air Bag is
deactivated unless the PAD Indicator Light is illuminated
with the words “PASSENGER AIR BAG OFF.”

If The Pad Indicator Light Is Illuminated For An
Adult Passenger:

If an adult passenger is seated in the passenger seat and
the PAD Indicator Light is illuminated, the passenger
may be sitting improperly. Follow the steps below to
allow the OCS to detect the adult passenger’s seated
weight to activate the Passenger Advanced Front Air Bag:

1. Turn off the vehicle and have the adult passenger step

out of the vehicle.

2. Remove any extra materials from the passenger seat,

such as cushions, pads, seat covers, seat massagers,
blankets, extra clothing, etc.

3. Place the seatback in the full upright position.

4. Have the adult passenger sit upright in the passenger

seat, sitting in the center of the seat cushion, with the
passenger’s legs fully extended.

5. Restart the vehicle and have the passenger remain in

this sitting position for two to three minutes after
restarting the vehicle.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

• If the PAD Indicator Light remains illuminated for

an adult passenger, have an authorized dealer ser-
vice the air bag system immediately. Failure to do
so may cause serious injury or death. If the PAD
Indicator Light is illuminated with the words
“PASSENGER AIR BAG OFF” the Passenger Ad-
vanced Front Air Bag will not inflate in the event of
a collision.

• Never place a rear facing infant seat in front of a

Passenger Advanced Front Air Bag. A deploying
passenger Advanced Front Air Bag can cause death
or serious injury to a child 12 years or younger,
including a child in a rear-facing child restraint.

• Only use a rear-facing child restraint in a vehicle

with a rear seat.

Lighter Weight Passengers (Including Small
Adults)

When a lighter weight passenger, including a small adult,
occupies the passenger seat, the Passenger Advanced
Front Air Bag may be deactivated. Therefore, the Passen-
ger Advanced Front Air Bag may or may not deploy for
a lighter weight passenger, including a small adult (de-
pending on size), who is seated in the front passenger
seat. This does not mean that the OCS is working
improperly.

The driver and passenger must always pay attention to
the Passenger Air Bag Disable (PAD) System. The PAD
Indicator Light tells you whether the Passenger Ad-
vanced Front Air Bag is activated or deactivated. If the
PAD Indicator Light is illuminated with the words “PAS-
SENGER AIR BAG OFF,” the Passenger Advanced Front
Air Bag may not inflate in the event of a collision. If the

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

PAD Indicator Light is illuminated with the words “PAS-
SENGER AIR BAG OFF” when an adult is in the front
passenger seat, the front passenger must reposition his/
her body in the seat until the PAD Indicator Light goes
out. This means that the Passenger Advanced Front Air
Bag is activated. Failure to be properly seated in the
passenger seat may prevent the passenger air bag from
deploying.

WARNING!

Occupants in the front passenger seat sitting improp-
erly may deactivate the Passenger Advanced Front
Air Bag. This may result in serious injury or death in
a collision. Always wear your seat belt and sit prop-
erly, with the seat back in an upright position, your
back against the seat back, sitting upright, facing
forward, in the center of the seat, with your feet
comfortably on or near the floor.

Do Not Decrease The Passenger’s Total Seated
Weight On The Passenger Seat

The front passenger’s seated weight must be properly
positioned on the front passenger seat. Failure to do so
may result in serious injury or death. The OCS deter-
mines the most probable classification of the occupant
that it detects. The OCS bladder will detect the front
passenger’s decreased seated weight, which may result
in deactivation of the Passenger Advanced Front Air Bag
in a collision and serious injury or death may result. This
does not mean that the OCS is working improperly.
Decreasing the front passenger’s seated weight on the
front passenger seat may result in deactivation of the
Passenger Advanced Front Air Bag. Examples of im-
proper front passenger seating include:

• The front passenger’s weight is transferred to another

part of the vehicle (like the door, arm rest or instru-
ment panel)

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

• The front passenger leans forward, sideways, or turns

to face the rear of the vehicle

• The front passenger’s seatback is not in the full upright

position

• Objects are lodged under the front passenger seat
• Objects are lodged between the front passenger seat

and center console

• Anything that may decrease the front passenger’s

seated weight

Do Not Increase The Passenger’s Total Seated
Weight On The Passenger Seat

passenger’s increased seated weight, which may result in
activation of the Passenger Advanced Front Air Bag in a
collision and serious injury or death may result. This
does not mean that the OCS is working improperly.
Increasing the front passenger’s seated weight on the
front passenger seat may result in activation of the
Passenger Advanced Front Air Bag under certain condi-
tions, for example:

• The front passenger leans forward, sideways, or turns

to face the rear of the vehicle

• The front passenger seatback is not in the full upright

position

• The front passenger carries or holds an object while

seated (e.g., backpack, box, etc.)

• Objects are lodged under the front passenger seat
• Objects are lodged between the front passenger seat

and center console

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

• Accessories that may increase the seated weight on the

front passenger seat are attached to the front passenger
seat

• Anything that may increase the front passenger’s

seated weight

Not Seated Properly

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Dodge Viper SRT (2015 year). Instruction - part 3
