KIA Cadenza (2019 year). Manual

4 11

Features of your vehicle

1. Pry open the smart key center

cover.

2. Replace the battery with a new

battery (CR2032). When replacing
the battery, make sure the battery
position.

3. Install the battery in the reverse

order of removal.

Mechanical key operations

• Used to lock and unlock the glove

box.

• Lock and unlock the doors when

the vehicle or smart key battery is
discharged.

Smart key

To remove the mechanical key, press
and hold the release button and
remove the mechanical key.
To reinstall the mechanical key, put
the key into the hole and push it until
a click sound is heard.

OYG046057N

OVG043401L

Features of your vehicle

Restrictions in Handling Keys

When leaving keys with parking lot
and valet attendants, the following
procedures will ensure your vehicle’s
trunk and glove box compartment
can not be opened in your absence.

To activate the trunk lock system so
that the trunk can only be opened with
the main key, perform the following:
1. Unlock the glove box by using the

main key (1) then open it (2).

2. Set the trunk lid control button to

the LOCK position.

3. Close and lock the glove box using

the main key.

When leaving your keys with a park-
ing lot or valet attendant, perform
steps 1 to 3 above, and leave the sub
key with the attendant. In this manner
the sub key can only be used to start
the engine and operate door locks.

Lock release
To release the trunk lock feature,
open the glove box with the main key
and set the trunk lid control button to
the UNLOCK position.

Immobilizer system

Your vehicle is equipped with an
electronic engine immobilizer system
to reduce the risk of unauthorized
vehicle use.
Whenever the ENGINE START/STOP
button is changed to the ON position,
the immobilizer system checks and
verifies if the key is valid or not.
If the key is valid, the engine will
start.
If the key is invalid, the engine will
not start.

✽

NOTICE

In order to prevent theft of your
vehicle, do not leave spare keys any-
where in your

vehicle. Your

Immobilizer password is a customer
unique password and should be kept
confidential. Do not leave this num-
ber anywhere in your vehicle.

OYG046003

4 13

Features of your vehicle

To deactivate the immobilizer
system

Change the ENGINE START/STOP
button to the ON position.

To activate the immobilizer sys-
tem

Change the ENGINE START/STOP
button to the OFF position. The
immobilizer system activates auto-
matically. Without a valid smart key
for your vehicle, the engine will not
start.

In order to prevent theft of your vehi-
cle, do not leave spare keys any-
where in your vehicle.

Your immobilizer password is a cus-
tomer unique password and should
be kept confidential. Do not leave this
number anywhere in your vehicle.

✽

NOTICE

Keep each key separate in order to
avoid a starting malfunction.

Do not put metal accessories near
the smart key.
Metal accessories may interrupt the
transponder signal and may prevent
the engine from being started.
If you need additional keys or lose
your keys, consult an authorized Kia
dealer.

This device complies with Part
15 of the FCC rules.

Operation is subject to the following
two conditions:
1. This device may not cause harmful

interference, and

2. This device must accept any inter-

ference received, including inter-
ference that may cause undesired
operation.

✽

NOTICE

Changes or

modifications not

expressly approved by the party
responsible for compliance could
void the user's authority to operate
the equipment.

CAUTION -

Immobilizer
damage

Do not expose your immobilizer
system to moisture, static elec-
tricity and rough handling. This
may damage your immobilizer.

CAUTION -

Immobilizer
alterations

Do not change, alter or adjust
the immobilizer system because
it could cause the immobilizer
system to malfunction.

Features of your vehicle

This system is designed to provide
protection from unauthorized entry
into the vehicle. This system is oper-
ated in three stages: the first is the
“Armed” stage, the second is the
“Theft-alarm” stage, and the third is
the “Disarmed” stage. If triggered,
the system provides an audible
alarm with blinking of the hazard
warning lights.

Armed stage

Park the vehicle and stop the engine.
Arm the system as described below.
1. Turn off the engine.
2. Make sure that all doors (and

trunk) and engine hood are closed
and latched.

3. Lock the doors by depressing the

door lock button on the smart key.

After completion of the steps above,
the hazard warning lights will blink
(for smart key, the chime also
sounds) once to indicate that the
system is armed.
If any door (or trunk) or engine hood
remains open, the hazard warning
lights and the chime will not operate
and the theft-alarm will not arm. If all
doors and trunk and engine hood are
closed after the lock button is
pressed, the hazard warning lights
blink once.

The system can also be armed by
locking the doors with the key from
the front doors; however, the hazard
warning lights will not blink using this
method.

✽

NOTICE

The theft-alarm system can be deac-
tivated by an authorized Kia dealer.
If you want this feature, consult an
authorized Kia dealer.

Do not arm the system until all
passengers have left the vehicle. If
the system is armed while a pas-
senger(s) remains in the vehicle,
the alarm may be activated when
the remaining passenger(s) leave
the vehicle. If any door (or trunk)
or engine hood is opened within
30 seconds after the system
enters the armed stage, the sys-
tem is disarmed to prevent an
unnecessary alarm.

THEFT-ALARM SYSTEM

Armed

stage

Theft-alarm

stage

Disarmed

stage

4 15

Features of your vehicle

Theft-alarm stage

The alarm will be activated if any of
the following occurs while the system
is armed.
• A front or rear door is opened with-

out using the smart key.

• The trunk is opened without using

the smart key.

• The engine hood is opened.
The horn will sound and the hazard
warning lights will blink continuously
for approximately 27 seconds, and
repeat the horn 2 times unless the
system is disarmed. To turn off the
system, unlock the doors with the
smart key.

Disarmed stage

The system will be disarmed when
• The doors (and trunk) are unlocked

with the smart key.

After depressing the unlock button,
the hazard warning lights will blink
and the chime will sound twice (in
smart key) to indicate that the sys-
tem is disarmed.
After depressing the unlock button, if
any door (or trunk) is not opened
within 30 seconds, the system will be
rearmed.
• Avoid trying to start the engine

while the alarm is activated. The
vehicle starting motor is disabled
during the theft-alarm stage.
If the system is not disarmed with
the smart key, open the doors by
using the mechanical key and start
the engine by directly pressing the
engine Start/Stop button with the
smart key.

• If you lose your keys, consult your

authorized Kia dealer.

✽

NOTICE

Malfunctions caused by improper
alterations, adjustments or modifi-
cations to the theft-alarm system are
not covered by your vehicle manu-
facturer warranty.

CAUTION -

Adjusting

alarm system

Do not change, alter or adjust
the theft-alarm system because
it could cause the theft-alarm
system to malfunction.

Features of your vehicle

DOOR LOCKS

Operating door locks from
outside the vehicle

• After removing the cover (2) while

pressing the hole (1) using
mechanical key or screw driver (-),
turn the key toward the front of the
vehicle to unlock and toward the
rear of the vehicle to lock.

• If you lock/unlock the driver’s door

with a key, only the driver’s door
will lock/unlock.

• Once the doors are unlocked, they

may be opened by pulling the door
handle.

• Once the doors are unlocked, they

may be opened by pulling the door
handle.

• When closing the door, push the

door by hand. Make sure the doors
are closed securely.

✽

NOTICE

• In cold and wet climates, door lock

and door mechanisms may not
work properly due to freezing con-
ditions.

• If the door is locked/unlocked

multiple times in rapid succession
with either the vehicle key or door
lock switch, the system may stop
operating temporarily in order to
protect the circuit and prevent
damage to system components.

OYG046006L

■ Type A

■ Type B

CAUTION

Do not unnecessarily open and
close the door repeatedly or
with excessive force.

Such

action can damage the vehicle
door.

WARNING

If people must spend a longer
time in the vehicle while it is very
hot or cold outside, there is rick
of injuries or danger to life. Do
not lock the vehicle from the out-
side when there are people in it.

4 17

Features of your vehicle

• To lock a door without the key,

push the inside door lock button (1)
or central door lock switch (2) to
the “Lock” position and close the
door (3).

• If you lock the door with the central

door lock switch (2), all vehicle
doors will lock automatically.

✽

NOTICE

Always place the Engine Start/Stop
button is in the OFF position,
engage the parking brake, close all
windows, and lock all doors when
leaving your vehicle unattended.

Operating door locks from
inside the vehicle

With the door lock button

• To unlock a door, push the door

lock button (1) to the “Unlock” posi-
tion. The red mark on the button
will be visible.

• To lock a door, push the door lock

button (1) to the “Lock” position. If
the door is locked properly, the red
mark on the door lock button will
not be visible.

• To open a door, pull the door handle

(2) outward.

• If the inner door handle of the dri-

ver’s (or front passenger’s) door is
pulled when the door lock button is
in the lock position, the button will
unlock and the door will open. (if
equipped)

• Front doors cannot be locked if the

smart key is in the vehicle and any
front door is opened.

• Doors cannot be locked if the smart

key is in the vehicle and a door is
open.

If a power door lock ever fails to func-
tion while you are in the vehicle, try
one or more of the following tech-
niques to exit:
• Operate the door unlock feature

repeatedly (both electronic and
manual) while simultaneously
pulling on the door handle.

• Operate the other door locks and

handles, front and rear.

• Lower a front window and use the

key to unlock the door from outside.

OYG046008

OYG048007N

Features of your vehicle

With central door lock switch

Operate by pressing the central door
lock switch.
For Driver’s door:
• When pushing down on the right

portion (1) of the switch, all vehicle
doors will lock.

• When pushing down on left portion

(2) of the switch, all vehicle doors
will unlock.

For Passenger’s door:
• When pushing down on the front

portion (1) of the switch, all vehicle
doors will lock.

• When pushing down on the rear

portion (2) of the switch, all vehicle
doors will unlock.

• If the smart key is in the vehicle

and any front door is opened, the
doors will not lock even though the
right portion(1, driver`s door) of the
central door lock switch is pressed.

WARNING

Do not pull the inner door handle
while the vehicle is moving.

OYG046009

OYG046010

■ Driver side

■ Passenger side

WARNING

Do not pull the inner door handle
of driver’s(or passenger’s) door
while the vehicle is moving.

4 19

Features of your vehicle

Impact sensing door unlock
system

In the event of air bag deployment
resulting from a vehicle impact, all
doors will automatically unlock.

Auto door lock/unlock feature

• All doors will automatically lock

when the transaxle shift lever is
shifted out of P(Park).

• All doors will automatically unlock

when the transaxle shift lever is
shifted into P (Park).

✽

NOTICE

You can select some auto door
lock/unlock features in “User Settings”
For more information, refer to
“User Settings” in this chapter.

Child-protector rear door lock

The child safety lock is provided to
help prevent children from acciden-
tally opening the rear doors from
inside the vehicle. The rear door
safety locks should be used whenev-
er children are in the vehicle.
1. Open the rear door.
2. Push the child safety lock (1)

located on the rear edge of the
door to the lock (

) position.

When the child safety lock is in the
lock position, the rear door will not
open even when the inner door
handle is pulled.

WARNING -

Doors

The doors should always be
fully closed and locked while the
vehicle is in motion to prevent
accidental opening of the door.

WARNING -

Unattended

children/animals

Never leave children or animals
unattended in your vehicle. An
enclosed vehicle can become
extremely hot, causing death or
severe injury to unattended
children or animals who cannot
escape the vehicle.

OYG046011

Features of your vehicle

3. Close the rear door.
To open the rear door, pull the out-
side door handle (2).
Even though the doors may be
unlocked, the rear door will not open
by pulling the inner door handle until
the rear door child safety lock is
unlocked.

WARNING

- Rear door

locks

Use the rear door safety locks
whenever children are in the
vehicle. If a child accidently
opens the rear doors while the
vehicle is moving, they may fall
out.

4 21

Features of your vehicle

Non-Powered Trunk

To open:

1.Make sure the shift lever is in P

(Park).

2.Perform one of the following :

- Press the smart key trunk unlock

button for more than one second.

- Press the button on the trunk

itself with the smart key in your
possession.

- Use the mechanical key.

3.Lift the trunk lid to open.

To close:

Lower the trunk lid and press down
until it locks.

✽

NOTICE

In cold and wet climates, trunk lock
and trunk mechanisms may not
work properly due to freezing condi-
tions.

TRUNK

OYG046012

OYG046013

WARNING

- Exhaust

fumes

The trunk lid should always be
kept completely closed while
the vehicle is in motion. If it is
left open or ajar, exhaust gases
may enter the car and serious
illness or death may result.

WARNING

The trunk swings upward. Make
sure no objects or people are
near the rear of the vehicle
when opening the trunk.

Features of your vehicle

Power Trunk

The power trunk can be opened and
closed automatically as follows.
- Power trunk main button (Type A) :

Open and close

- Smart key and trunk handle switch

(Type B) : Open only

- Close button on the trunk lid

(Type C) : Close only

If you depress the power trunk main
button, trunk handle button or close
button while operating the power
trunk, you could stop operating the
power trunk.
If that happens, to operate the power
trunk again, push any button or switch.

Opening the trunk

The power trunk will open automati-
cally by doing one of the following:
• Press the trunk open button on the

smart key more than 1 second. The
chime will sound twice.

• Press and hold the open button of

the power trunk main switch. The
chime will sound twice.

• Press the trunk handle switch car-

rying the smart key with you. If all
doors have unlocked, you can
open the trunk by pressing the
trunk handle switch without the
smart key.

OYG046014

OYG046015

OYG046016

■

Type B

■

Type A

■

Type C

4 23

Features of your vehicle

Closing the trunk

To close the power trunk, do one of
the following:
• Push the close button of the power

trunk main button, until the power
trunk is closed securely. The chime
will sound twice.

• Push the power trunk close button.
• Push the power trunk lock button

when all doors and engine hood
are closed with the smart key in
your possession. After closing, all
doors and trunk lock automatically.

✽

NOTICE

The power trunk lock button will
not work if you press the button
when:
- Any door is open.
- The engine start/stop button is not

in the OFF position.

- The smart key is in the vehicle.

Do not leave the power trunk open
for a long period of time. This may
drain the battery.

✽

NOTICE

In cold and wet climates, trunk lock
and trunk mechanisms may not
work properly due to freezing condi-
tions.

WARNING

Make sure there are no people
or objects around the trunk
before opening or closing the
power trunk. Wait until the trunk
is open fully and stopped
before loading or unloading
cargo from the vehicle.

CAUTION

• Do not close or open the

power trunk manually. This
may cause damage to the
power trunk. If it is necessary
to close or open the power
trunk manually when the bat-
tery is drained or disconnect-
ed, do not apply excessive
force.

• To prevent damage to the

trunk lift cylinders and the
attached hardware, always
close the trunk before driving.

Features of your vehicle

Power Trunk Non-Opening or
Closing Conditions:

• The power trunk will not open or

close automatically, when the vehi-
cle is moving more than 1.8 mph (3
km/h).

• The power trunk can be operated

when the engine is not running.
However, the power trunk opera-
tion consumes large amounts of
the vehicles battery power. To pre-
vent the battery from draining, do
not operate it excessively (e.g.,
more than approximately 10 times
repeatedly).

• Do not modify or repair any part of

the power trunk by yourself. This
must be done by an authorized Kia
dealer.

• Before jacking up the vehicle to

change a tire or repair the vehicle,
open the power trunk. Do not oper-
ate the power trunk when the vehi-
cle is raised or this could cause the
power trunk to operate improperly.

• If there are obstacles such as

snow on the power trunk, it may
not open automatically.

After

removing the obstacle, try to open
it again.

Automatic stop and Reverse

If during power opening or closing,
the trunk is blocked by an object or
part of someone’s body, the power
trunk will detect the resistance and it
will stop movement or move to the
full open position to allow the object
to be cleared.
However, if an object is thin or soft,
or the trunk is near the latched posi-
tion, the automatic stop and reversal
may not detect the resistance and
the closing operation will continue. If
the power trunk is forced by a strong
impact, the automatic stop and rever-
sal may operate.

OYG046018

4 25

Features of your vehicle

If the automatic stop and reverse fea-
ture operates more than twice during
one opening or closing operation, the
power trunk may stop at that posi-
tion.
If this occurs, close the trunk manu-
ally and operate the trunk automati-
cally again.

To Reset the Power Trunk

If the battery has been discharged or
disconnected, or if the related fuse
has been replaced or disconnected,
reset the power trunk as follows:
1. Move the shift lever to the P (Park)

position.

2. Close the trunk manually.
If the power trunk doesn't work prop-
erly after performing the above pro-
cedure, have the system checked by
an authorized Kia dealer.

Trunk Lid Control Button

When the trunk lid control button is in
UNLOCK, the power trunk can be
controlled with the power trunk main
control button, power trunk open,
close button, and the smart key.
When this trunk lid control button is
in LOCK, the power trunk can be
controlled using the mechanical key
of the smart key only.

WARNING

To prevent serious injury and
damage take the following pre-
cautions when operating the
power trunk:
- Keep all faces, hands, arms,

body parts and other objects
away from the path of the
power trunk.

- Do not intentionally place any

body parts or objects in the
path of the power trunk to
make sure the automatic stop
and reversal operates.

- Do not allow children to play

with the power trunk.

OYG046005

Features of your vehicle

Even though the trunk lid control but-
ton is in LOCK, the trunk will still be
propelled upward by mechanical
force if the trunk is manually opened
more than 10 degrees beyond the
fully closed position.
In addition, if the trunk is manually
closed to the secondary latch posi-
tion, the trunk will be electrically
moved to the fully latched position.

✽

NOTICE

Close the trunk, and keep the trunk
lid control button in the unlock posi-
tion before washing the vehicle in an
automatic car wash.

Emergency Trunk Safety
Release

Your vehicle is equipped with an
Emergency Trunk Safety Release
lever located inside the trunk. When
someone is inadvertently locked in
the trunk, the trunk can be opened
by moving the lever in the direction of
the arrow and pushing the trunk
open.

WARNING

Always keep the Trunk Lid
Control Button in the unlock
position when not in use.
Serious injury or death can
result from unintentional opera-
tion by a child.

OYG046020

KIA Cadenza (2019 year). Manual - part 6
