Seat Exeo. Instruction - part 9

-------------------------------------------------------------------------------------------------------------------------------------------------------------

134

Seats and stowage

Adjusting the contour of lumbar support

Memory for driver’s seat*

- Press the front part of the adjuster switch ⇒ page 133, fig. 108

to increase the contour of the lumbar support.

Description

- Press the rear part of the adjuster switch to decrease the contour

The recall buttons in the driver's door can be used to store

of the lumbar support.

and recall up to four different positions for the driver's seat

Adjusting the height of lumbar support

and exterior mirrors.

- Press the top part of the adjuster switch to move the lumbar

support upwards.

- Press the bottom part of the adjuster switch to move the lumbar

support down.

The lumbar support provides effective support for the natural curvature of the

spine to give a more relaxed seating position, especially on long journeys.

Fig. 109 Driver's door:

Memory system

Memory buttons

Using the recall buttons 1, 2, 3 and 4 ⇒ fig. 109, you can store and recall the

seat and exterior mirror positions for up to four different drivers.

STOP

button

The seat memory will be disabled if the

STOP

button is in the up position

(press and release). The word  will light up next to the

STOP

button (only

visible when the lights are switched on).

The stored settings will all remain in the memory. However, the seat and the

exterior mirrors can now only be adjusted using the conventional electrical

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

136

Seats and stowage

Assigning remote control keys

Head restraints

The key must be assigned to a memory button so that the

positions stored in the memory can also be recalled using the

Front head restraints

remote control key.

In combination with properly worn seat belts, the head

Assigning the remote control key to a memory button

restraints offer effective protection, provided they are prop-

erly adjusted to suit the height of the occupant.

- Using the memory button, recall the settings that are to be

programmed onto the key.

- Keeping the memory button pressed down, press the unlock

button on the remote control key within 10 seconds.

- Wait for about 2 seconds before releasing the memory button.

Deleting assignment of the remote control key to the memory

button

- Press and hold the

MEMO

button and press the unlock button on

the remote control key within 10 seconds.

- Wait for about 2 seconds before releasing the

MEMO

button.

Fig. 110 Front seats:

Head restraints

The previous settings are automatically cancelled when the keys are re-

assigned to different memory buttons.

Raising the head restraint

- Take hold of the sides of the head restraint with both hands.

- Pull up the head restraint.

Lowering the head restraint

- Press button

A

and lower the head restraint.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and stowage

137

Removing the head restraints

Raising the head restraint

- Pull up the head restraint as far as it will go.

- Take hold of the sides of the head restraint with both hands.

- Press button

A

and pull out the head restraint.

- Pull up the head restraint as far as it will go.

Fitting the head restraint

Lowering the head restraint

- Insert the head restraint in its guides until it clicks into place.

- Press button

A

⇒ fig. 111 and lower the head restraint.

Press button

A

and lower the head restraint.

Removing the head restraint

The height of the head restraints is adjustable. They should be set to suit the

– Pull up the head restraint as far as it will go.

height of the occupant. In combination with the seat belts, the head

restraints offer effective protection, provided they are properly adjusted.

- Press button

A

⇒ fig. 111 and pull out the head restraint.

For best protection, the top of the head restraint should be at least at eye level

Fitting the head restraint

or higher.

- Insert the head restraint in its guides until it clicks into place.

Press button

A

and lower the head restraint.

Head restraints of the side rear seats

When the rear seats are not occupied, the head restraints should be moved

to the lowest position so that they do not obstruct the driver's field of

vision.

Fig. 111 Outer rear seats:

Head restraints

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

138

Seats and stowage

Central head restraint of the rear seat

When the rear seats are not occupied the head restraints should be moved to

the lowest position so that they do not obstruct the driver's field of vision.

Armrests

The armrest can be adjusted to several positions and incorpo-

rates a storage compartment.

Fig. 112 Centre rear seat:

Head restraints

Raising the head restraint

- Take hold of the sides of the head restraint with both hands.

- Pull up the head restraint as far as it will go.

Fig. 113 Armrest

between the driver's seat

and front passenger's

Lowering the head restraint

seat

- Press button

A

⇒ fig. 112 and lower the head restraint.

Adjusting the armrest

Removing the head restraint

- To adjust the position of the armrest, fold the armrest all the way

- Pull up the head restraint as far as it will go.

down.

- Press button

A

⇒ fig. 112 and pull out the head restraint.

- Then lift the armrest gradually until it engages in the desired

position.

Fitting the head restraint

- Insert the head restraint in its guides until it clicks into place.

Opening the storage compartment

Press button

A

and lower the head restraint.

- Press the release lever ⇒ fig. 113.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and stowage

139

Please note that the armrest can restrict the driver's movements when it is

- Secure the load with the stretch net* or with non-elastic straps

lowered. The armrest should therefore be raised when driving in city traffic.

secured to the fastening rings ⇒ page 140.

WARNING

Luggage compartment

Unsecured objects in the luggage compartment can suddenly shift and

•

cause changes in the handling of the vehicle.

Loading the luggage compartment

• In an accident or a sudden manoeuvre, loose objects in the passenger

compartment can be flung forward and might injure vehicle occupants.

Loads in the luggage compartment should be safely secured.

• Always keep all objects in the luggage compartment and use appro-

priate grips to secure them, particularly in the case of heavy objects.

• When you transport heavy objects, always bear in mind that a change

of the centre of gravity can also cause changes in vehicle handling.

• Please refer to the notes in ⇒ page 7.

Note

The tyre pressure must be adjusted according to the load. Consult the label

containing the pressure values inside the fuel tank flap where required

⇒ page 208, fig. 160.

Fig. 114 Position heavy

items as far forward as

possible.

To maintain safe handling on the road, please observe the following

points:

- Distribute the load evenly.

– Position heavy items as far forward as possible ⇒ fig. 114.

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

140

Seats and stowage

Fastening rings

Stretch/retaining net*

There are four fastening rings in the luggage compartment,

The stretch/retaining net can be used to secure and retain

which can be used to secure loads.

light objects in the luggage compartment.

Fig. 115 Location of

fastening rings in luggage

Fig. 116 Stretch net laid

compartment

out

– Use the fastening rings to secure the load ⇒ fig. 115 -arrows-.

– Please refer to the safety notes ⇒ page 139.

Fig. 117 Stretch net

attached in position as

retaining net

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and stowage

141

Stretch net

Extending the luggage compartment

- Secure the stretch net in the four fastening rings ⇒ page 140,

The two sections of the backrest can be folded forwards either

fig. 116.

together or separately to increase the capacity of the luggage

Retaining net

compartment.

- Secure the hooks of the retaining net to the fastening rings at the

bottom of the luggage compartment panel ⇒ page 140,

fig. 117.

- Take hold of the handles and pull down the retaining hooks

A

⇒ page 140, fig. 117 at the top of the luggage compartment.

Pull up the net and attach the loops onto the retaining hooks.

You can also use the hooks to secure light items of luggage, such as shop-

ping bags and handbags, etc.

The hooks will fold up again by themselves when not in use.

Fig. 118 Backrest release

lever

WARNING

The retaining net should only be used to hold objects weighing up to 5 kg.

Heavier objects cannot be safely secured (injury risk).

Fig. 119 Locking the

backrest

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and stowage

143

Ski bag*

Loading

- Open the tailgate.

You can use the "ski bag" to transport skis or other extra-long

objects safely inside the vehicle without soiling or damaging

- Press the release catch for the ski bag cover ⇒ fig. 120 -arrow-

the upholstery.

and swivel the cover downwards.

- Pull down the centre rear armrest.

- From the passenger compartment, press down the release catch

for the ski bag cover and pull out the cover.

- Pull out and unfold the ski bag.

- The extra-long items can now be loaded through the luggage

compartment into the ski bag ⇒

Securing

Fig. 120 Detailed view of

- Insert the fastening belt

A

⇒ fig. 121 of the ski bag into the

the rear of the rear back-

centre seat belt buckle

B

rest: Ski bag cover

– Pull the free end of belt

C

to tighten.

Storing

- Close the cover of the load-through hatch in the luggage

compartment.

- Carefully fold away the ski bag.

- Close the inside cover of the load-through hatch from the

passenger compartment.

Fig. 121 Securing the ski

bag on the centre seat

belt buckle on the rear

seat bench

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

144

Seats and stowage

Attachment points

WARNING

The roof carrier must be attached at the marked points only.

The ski bag must be secured in place with the fastening belt after it has

been loaded.

Note

Do not fold away the ski bag after use if it is still damp.

Roof carrier

Description

Fig. 122 Attachment

Additional luggage can be carried on the roof carrier.

points for carrier units

Note the following points if you intend to carry loads on the roof:

Installation

• There are aerodynamic drainage channels on the roof of the vehicle and,

The feet of the carrier units must be fitted exactly between the points marked

therefore, normal roof racks cannot be used. We recommend using the carrier

with arrows on the roof sealing strip ⇒ fig. 122. The arrows are only visible

units from the range of original SEAT accessories.

with the doors open.

• These carrier units are the basis of a complete roof carrier system. For

safety reasons, however, the corresponding additional fastenings must be

fitted to carry luggage, bicycles, surfboards, skis and boats. All the parts of

this system are available from SEAT Dealers.

Roof load

Loads carried on the roof must be securely attached. The car's

Caution

handling is affected whenever you carry loads on the vehicle.

Any damage to the vehicle caused by the use of other types of roof rack or

incorrect installation will not be covered by the factory warranty. The roof

The authorised load on the roof of your vehicle is 75 kg. Use the weight of the

carrier system must therefore be installed exactly according to the instruc-

roof carrier system and that of the load as a basis to calculate the roof load.

tions provided.

If less resistant systems are used, the roof carrier must not be loaded to the

maximum weight permitted. If less resistant systems are used, these must

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and stowage

145

only be loaded to the maximum weight permitted indicated in the assembly

Drink holders

instructions.

Front drink holders 

WARNING

• Loads carried on the roof must be securely attached. Failure to do so

could result in an accident.

• Do not exceed the maximum roof load for the vehicle, the maximum

axle loads or the maximum gross vehicle weight. Failure to do so could

result in an accident.

• When transporting heavy or bulky loads on the roof, bear in mind that

the car's handling is affected by the extra weight on the roof and a possible

susceptibility to cross winds. Adjust your speed and driving style accord-

ingly to avoid accidents.

For the sake of the environment

Fig. 123 Detailed view of

instrument panel: Drink

Roof carriers are often left attached for convenience, even when they are not

holders

being used. However, the increased air resistance means that the vehicle

uses more fuel. For this reason you should always take off the roof carrier

when it is not in use.

- To open the drink holder, press the symbol  on the drink holder

lid ⇒ fig. 123

- To close the drink holder, press it in until it engages.

WARNING

• Do not put any hot drinks in the drink holder while the vehicle is

moving. You can be scalded if the hot liquid is spilt.

• Do not use hard china cups or glasses. These could cause injury in the

event of an accident.

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

146

Seats and stowage

Drink holder in the rear armrest

WARNING (continued)

• Do not use hard china cups or glasses. These could cause injury in the

event of an accident.

Ashtray*, cigarrette lighter* and power

points

Front ashtray*

Fig. 124 Drink holder in

the rear armrest

Opening the drink holder

- Press the symbol 

A

⇒ fig. 124.

Adjusting the retainer arm

- To adjust one of the retainer arms

B

, release it by pressing in

the direction indicated (arrow) and move it as required.

The retainer arm should be positioned against the drinks holder so that it is

Fig. 125 Centre console:

held securely.

Open ashtray

One or two drinks holders can be held in the centre armrest.

Opening the ashtray

- Lightly press the front part of the ashtray

A

⇒ fig. 125.

WARNING

• Do not put any hot drinks in the drink holder while the vehicle is

Removing the ashtray

moving. You can be scalded if the hot liquid is spilt.

- Take hold of the sides of the ashtray

B

⇒ fig. 125 and lift it out.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and stowage

147

Fitting the ashtray casing

Fitting the ashtray casing

- Insert the casing and press it into its mountings.

- Open the lid on the ashtray and press the casing into the

mounting as far as it will go.

WARNING

WARNING

Never put waste paper in the ashtray, as this could cause a fire.

Never put waste paper in the ashtray, as this could cause a fire.

Rear ashtray

Cigarette lighter*

The 12-volt socket for the cigarette lighter can also be used as

a power source for other electrical appliances.

Fig. 126 Rear ashtray

Opening the ashtray

Fig. 127 Cigarette lighter

- Lift the lid.

in the centre console

Removing the ashtray

Using the cigarette lighter

- Take hold of the lid ⇒ fig. 126 and lift out the ashtray.

- Press in the cigarette lighter knob.

- Wait for the lighter to pop out slightly.

Safety First

Operating instructions

Practical tips

Technical Data

-------------------------------------------------------------------------------------------------------------------------------------------------------------

148

Seats and stowage

– Pull out the cigarette lighter immediately.

Electrical socket*

- Use the glowing heater element of the cigarette lighter to light

Electrical equipment can be connected to the 12 Volt socket.

your cigarette.

- Put the cigarette lighter back in its socket.

Operating the socket

- Take out the cigarette lighter.

- Insert the plug of the electrical appliance into the cigarette

lighter socket.

The cigarette lighter ⇒ page 147, fig. 127 employs a standard 12-volt

Fig. 128 Detailed view of

socket, which can also be used as a power source for electrical appliances.

the side trim in the

The appliances connected to the socket must not exceed a power rating of

luggage compartment:

100 W.

12-volt socket

WARNING

- Lift the socket cover ⇒ fig. 128.

• Be careful when using the electric cigarette lighter. Carelessness or

- Insert the plug of the electrical appliance into the socket.

negligence when using the cigarette lighter can cause burns.

• The lighter will only work when the ignition is switched on.

Electrical equipment can be connected to the 12-volt socket. The appliances

• The electrical sockets and, therefore, any appliances connected to

connected to the socket must not exceed a power rating of 100 W.

them will only work when the ignition is switched on.

WARNING

Caution

The electrical sockets and, therefore, any appliances connected to them

Always use the correct type of plugs to avoid damaging the sockets.

will only work when the ignition is switched on.

Note

Caution

The use of electrical appliances with the engine switched off will cause a

Always use the correct type of plugs to avoid damaging the sockets.

battery discharge.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seats and stowage

149

Glove compartment

Note

The use of electrical appliances with the engine switched off will cause a

The glove compartment is equipped with a lock* and a light.

battery discharge.

Compartments

Overview

There are several storage compartments at various points in

the vehicle.

Your vehicle has the following storage compartments:

Fig. 129 Glove compart-

ment

First-aid kit*

Emergency triangle*

Opening the glove compartment

Glove compartment (glove compartment cool-

⇒ page 149

- Pull the handle on the lid in the direction indicated (arrow)

ing)

⇒ fig. 129 and open the lid.

Storage compartment in the centre console

Vehicle wallet compartment*

Closing the glove compartment

Compartments in the door trims

⇒ page 150

- Close the lid and push it in until it engages.

Coat hooks

⇒ page 151

If the side lights or headlights are switched on, the light in the glove compart-

Storage shelf

⇒ page 142

ment comes on when it is opened.

Side storage compartment in luggage com-

The lid has separate holders for a pen and a note pad.

partment

Some of the compartments listed are only provided in certain models / model

years or are optional extras.

Safety First

Operating instructions

Practical tips

Technical Data

Content      ..     7      8      9      10     ..
