MG3. Touch User Instruction - part 1

MG Motor UK Ltd

User Instruction

iGO primo

Navigation software for the [DEVICE]

UK English

October 2012, ver. 1.0

MG Motor UK Ltd

Table of contents

1 Warnings and Safety information ......................................................................... 6

2 Getting started ......................................................................................................... 7

2.1 Navigation menu ............................................................................................................ 9

2.2 Buttons and other controls on the screen ..................................................................... 10

2.2.1 Using keyboards ................................................................................................................ 11

2.2.2 Beyond single screen tap ................................................................................................... 12

2.3 Map screen ................................................................................................................... 13

2.3.1 Navigating on the map ....................................................................................................... 13

2.3.2 Position markers ................................................................................................................ 15

2.3.2.1 Vehimarker and Lock-on-Road .................................................................................................. 15

2.3.2.2 Selected map location (Cursor) and selected map object .......................................................... 15

2.3.3 Objects on the map ............................................................................................................ 15

2.3.3.1 Streets and roads ....................................................................................................................... 15

2.3.3.2 Turn preview and Next street ..................................................................................................... 16

2.3.3.3 Lane information and Signposts................................................................................................. 17

2.3.3.4 Junction view ............................................................................................................................. 18

2.3.3.5 Motorway exit services .............................................................................................................. 18

2.3.3.6 3D object types........................................................................................................................... 19

2.3.3.7 Elements of the active route ....................................................................................................... 19

2.3.3.8 Traffic events ............................................................................................................................. 20

2.3.4 Manipulating the map ........................................................................................................ 21

2.3.5 Quick menu ........................................................................................................................ 23

2.3.6 Checking the details of the current position (Where Am I?) ............................................. 26

3 On-road navigation ............................................................................................... 28

3.1 Selecting the destination of a route .............................................................................. 28

3.1.1 Combined Search ............................................................................................................... 28

3.1.1.1 Combined Search - Navigating to a recent destination (History) .............................................. 31

3.1.1.2 Combined Search - Navigating to a Favourite destination ........................................................ 32

3.1.1.3 Combined Search - Navigating to an address ............................................................................ 32

3.1.1.4 Search Centre - Navigating to an intersection ........................................................................... 33

3.1.1.5 Combined Search - Navigating to a Place of Interest ................................................................ 34

3.1.1.6 Combined Search - Navigating to a Place of Interest by its category ........................................ 35

3.1.2 Entering an address or a part of the address ....................................................................... 37

3.1.2.1 Entering an address ................................................................................................................... 37

3.1.2.2 Entering the midpoint of a street as the destination ................................................................... 39

3.1.2.3 Selecting an intersection as the destination ............................................................................... 41

3.1.2.4 Selecting a city/town centre as the destination........................................................................... 42

3.1.2.5 Entering an address with a postal code ..................................................................................... 43

3.1.2.6 Tips on entering addresses quickly ............................................................................................ 45

3.1.3 Selecting the destination from the Places of Interest ......................................................... 46

3.1.3.1 Quick search for a Place of Interest........................................................................................... 46

MG Motor UK Ltd

3.1.3.2 Searching for a Place of Interest using preset categories .......................................................... 48

3.1.3.3 Searching for a Place of Interest by category ............................................................................ 50

3.1.3.4 Searching for a Place of Interest by name ................................................................................. 52

3.1.3.5 Selecting nearby assistance from 'Where Am I?' ....................................................................... 55

3.1.4 Searching for a Place using Google Local Search ............................................................. 57

3.1.5 Selecting a map location as the destination ....................................................................... 58

3.1.6 Selecting the destination from your Favourites ................................................................. 59

3.1.7 Selecting one of the most likely destinations (Smart History) ........................................... 60

3.1.8 Selecting a recent destination from the History ................................................................. 61

3.1.9 Entering the coordinate of the destination ......................................................................... 62

3.1.10 Navigate to a location stored in a photo ........................................................................... 63

3.1.11 Building a route from the list of destinations (Create Route) .......................................... 64

3.2 Viewing the entire route on the map ............................................................................ 65

3.3 Checking route parameters and accessing route related functions ............................. 65

3.4 Modifying the route ...................................................................................................... 66

3.4.1 Selecting a new destination when already having a route: New Route, Waypoint or Final

Destination.................................................................................................................................... 66

3.4.2 Setting a new starting position for the route ...................................................................... 67

3.4.3 Editing the list of destinations (Edit Route) ....................................................................... 68

3.4.4 Pausing the active route ..................................................................................................... 69

3.4.5 Cancelling the active route ................................................................................................ 69

3.4.6 Checking route alternatives when planning the route ........................................................ 70

3.4.7 Checking route alternatives for an existing route .............................................................. 71

3.4.8 Changing the vehicle used in route planning ..................................................................... 72

3.4.9 Changing the road types used in route planning ................................................................ 73

3.5 Saving a location as a Favourite destination ............................................................... 74

3.5.1 Editing the details of a Favourite destination ..................................................................... 75

3.6 Saving a map location as an alert point....................................................................... 76

3.7 Saving the current location as an alert point ............................................................... 77

3.8 Editing an alert point ................................................................................................... 77

3.9 Watching the simulation of the route ........................................................................... 78

4 Off-road navigation ............................................................................................... 80

4.1 Selecting the destination of the route ........................................................................... 80

4.2 Navigating in off-road mode ........................................................................................ 80

5 Lorry navigation .................................................................................................... 81

5.1 Setting up vehicle parameters ...................................................................................... 81

5.2 Setting up waiting time at waypoints ........................................................................... 83

5.3 Setting up driving time alerts ....................................................................................... 84

6 Reference Guide .................................................................................................... 86

6.1 Concepts ....................................................................................................................... 86

6.1.1 Smart Zoom ....................................................................................................................... 86

MG Motor UK Ltd

6.1.2 Daytime and night colour themes ...................................................................................... 86

6.1.3 Tunnel view ....................................................................................................................... 86

6.1.4 Route calculation and recalculation ................................................................................... 87

6.1.5 Green routing ..................................................................................................................... 89

6.1.6 Road safety cameras and other proximity alert points ....................................................... 90

6.1.7 Speed limit warning ........................................................................................................... 91

6.1.8 Battery and GPS position quality indicators ...................................................................... 91

6.1.9 Traffic information in route planning ................................................................................ 92

6.1.9.1 Historical traffic ........................................................................................................................ 93

6.1.9.2 Real-time traffic information (TMC) .......................................................................................... 93

6.1.9.3 Online traffic information .......................................................................................................... 95

6.2 'More' menu .................................................................................................................. 96

6.3 Settings menu ............................................................................................................... 97

6.3.1 Sound and Warnings .......................................................................................................... 99

6.3.2 Customise Quick menu .................................................................................................... 102

6.3.3 Driving time management................................................................................................ 103

6.3.4 Traffic settings ................................................................................................................. 103

6.3.5 Route settings ................................................................................................................... 104

6.3.6 User profiles ..................................................................................................................... 108

6.3.7 Map settings ..................................................................................................................... 108

6.3.8 Visual guidance settings .................................................................................................. 110

6.3.9 Display settings ................................................................................................................ 111

6.3.10 Regional settings ............................................................................................................ 112

6.3.11 Trip monitor settings ...................................................................................................... 112

6.3.12 Log on to receive community content ............................................................................ 113

6.3.13 Bandwidth management ................................................................................................ 113

6.3.14 Log collection settings ................................................................................................... 114

7 Glossary ................................................................................................................ 115

8 End User Licence Agreement ............................................................................. 117

9 Copyright note ..................................................................................................... 117

MG Motor UK Ltd

1 Warnings and Safety information

The navigation system helps you find your way to your destination with the built-in GPS
receiver. iGO primo does not transmit your GPS position; others cannot track you.

If  you  accept  it  when  first  using  the  application,  iGO  primo  collects  usage  information  and
GPS  logs  that  may  be  used  for  improving  the  application  and  the  quality  and  coverage  of
maps.  The  data  is  processed  anonymously;  no  one  will  be  able  to  track  any  personal
information.  If  you  change  your  mind  later,  you  can  enable  or  disable  the  log  collection  in
Settings (page 114).

It is important that you look at the display only when it is safe to do so. If you are the driver of
the vehicle, we recommend that you operate iGO primo before you start your journey. Plan
the route before your departure and stop if you need to change the route.

You must obey the traffic signs and follow the road geometry. If you deviate from the
recommended route, iGO primo changes the instructions accordingly.

Never place [DEVICE] where it obstructs the driver's view, where it is in the deployment zone
of an airbag or where it might cause injuries in an accident.

For more information, consult the End User Licence Agreement (page 117).

MG Motor UK Ltd

2 Getting started

iGO primo is optimised for in-car or pedestrian use. There is no need to use a stylus. You can
use it easily by tapping the screen buttons and the map with your fingertips.

When using the navigation software for the first time, an initial setup process starts
automatically. Do as follows:

Select the written language of the application interface. Later you can change it in
Regional settings (page 112).

Read the End User Licence Agreement. Tap

to continue.

You are now asked whether you allow the software to collect usage information and
GPS logs that may be used for improving the application and the quality and coverage

of maps. Tap

to allow the anonymous statistics or disable this

function. Later you can turn them on or off individually in Log collection settings (page
114).

The Configuration wizard starts. Tap

to continue.

Select the language and speaker used for voice guidance messages. Later you can
change it in Sound and Warnings settings (page 112).

MG Motor UK Ltd

If needed, modify the time format and unit settings. Later you can change them in
Regional settings (page 112).

If needed, modify the default route planning options. Later you can change them in
Route settings (page 104).

*8.

If an Internet connection is available, the application will check your licenses for the

online services. This may take a few seconds. When finished, you will be asked to
activate these services. You can choose to activate them later or do it right away.

*9.

Enter the activation code. You can find it under the scratch surface on the card you

purchased or received with your device. Tap

to continue.

*10. The code is now checked online and after a while you receive the activation success

message. Tap

to continue.

11. The initial setup is now complete. The Configuration wizard can be restarted later from

the Settings menu (page 97).

After the initial setup, the Navigation menu appears and you can start using iGO primo.

* Items 8, 9 and 10 are not applicable to the MG3 Touch. The map data is already licensed on the SD card
and contains no feature updates. Map updates can be purchased via NaviExtras website

MG Motor UK Ltd

2.1 Navigation menu

You can reach all parts of iGO primo from the Navigation menu.

You have the following options:

x Tap

to select your destination by entering an address or selecting

a place of interest, a location on the map or one of your Favourite destinations. You
can also look up your recent destinations from the Smart History, enter a coordinate or
use the location saved in a photo. When internet connection is available, Google Local
Search can be a further help to find your destination.

x Tap

to display the route parameters and the route in its full length

on the map. You can also perform route-related actions such as editing or cancelling
your route, setting a start point for the route, picking route alternatives, avoiding parts
of the route, simulating navigation or adding the destination to your Favourites.

x Tap

to customise the way the navigation software works, to

simulate demo routes or to run some additional applications.

x Tap

to customise the way the navigation software works.

x Tap

to start navigating on the map. The button itself is a miniature

live map that shows your current position, the recommended route and the surrounding
map area. Tap the button to enlarge the map to the full screen.

x Tap

to open the Traffic Summary screen.

x Tap

to stop navigation and exit the software.

MG Motor UK Ltd

2.2 Buttons and other controls on the screen

When you are using iGO primo, you usually tap buttons on the touch screen.

You only need to confirm selections or changes if the application needs to restart, it needs to
perform a major reconfiguration, or you are about to lose some of your data or settings.
Otherwise, iGO primo saves your selections and applies the new settings without confirmation
as soon as you use the controls.

Type

Example

Description

How to use it

Button

Tap it to initiate a function,
to open a new screen, or
to set a parameter.

Tap it once.

Button
with
value

Some buttons display the
current value of a field or
setting. Tap the button to
change the value. After the
change, the new value is
shown on the button.

Tap it once.

Icon

Shows status information.

Some icons also function
as a button. Tap them
once.

List

When you need to select
from several options, they
appear in a list.

Grab the list anywhere
and slide your finger up
or down. Depending on
the speed of the sliding,
the list will scroll fast or
slow, only a bit or till the
end.

Alternatively, move
between pages with the

and

buttons

and tap the value that
you want.

Radio
button

When there are only a few
choices, radio buttons may
be used instead of lists.
Only one value can be
selected.

Tap one of the buttons to
select a new value.

Switch

When there are only two
choices, a checkmark
shows whether the feature
is enabled.

Tap it to turn the switch
on or off.

MG Motor UK Ltd

Slider

When a feature can be set
to different values in a
range, iGO primo shows
an indicator on a gauge
that displays and sets the
value.

x Drag the handle to

move the slider to
its new position.

x Tap the slider

where you want
the handle to
appear; the thumb
jumps there.

Virtual
keyboard

Alphabetic and
alphanumeric keyboards
to enter text and numbers.

Each key is a touch
screen button.

2.2.1 Using keyboards

You only need to enter letters or numbers when you cannot avoid it. You can type with your
fingertips on the full-screen keyboards and you can switch between various keyboard layouts,
for example English, Greek or numerical.

Task

Instruction

Switching to another
keyboard layout, for example
from an English keyboard to
a Greek keyboard

Tap the

button and select the new

keyboard layout from the list.

Correcting your entry on the
keyboard

Tap

to remove the unneeded character(s).

Tap and hold the button to delete several characters or the
entire input string.

Entering a space, for
example between a first
name and a family name or
in multi-word street names

Tap the

button at the bottom centre of the screen.

Entering upper and lower
case letters

When entering a text, the first character appears in upper case

while the rest of the text is in lower case. Tap

to enter an

upper case letter or tap twice to turn on Caps Lock. Tap again
and lower case letters return.

Entering numbers and
symbols

Tap

to switch to a keyboard offering numeric and symbol

characters.

Finalising the keyboard entry
(accepting the suggested
search result)

Tap

MG Motor UK Ltd

Task

Instruction

Finalising the keyboard entry
(opening the list of search
results)

Tap

Finalising the keyboard entry
(saving your input)

Tap

Cancelling the keyboard
entry (returning to the
previous screen)

Tap

2.2.2 Beyond single screen tap

You usually need to tap the screen only once. However, some useful features can be
accessed with combined touch screen tapping. Those are the following:

Action

Details

Tapping and holding
the screen

Tap and keep pressing the following buttons to reach extra functions:

x Tap and hold

on list and menu screens: the

Map screen appears.

x Tap and hold any of the

and

buttons on the Map screen: you can rotate, tilt or

scale the map continuously.

x Tap and hold

on keyboard screens: you can delete

several characters quickly.

x Tap and hold

in long lists: you can scroll pages

continuously.

Gestures (drag&drop)

You need to drag and drop the screen only in cases like:

x Moving the handle on a slider.
x Scrolling the list: grab the list anywhere and slide your finger up

or down. Depending on the speed of the sliding, the list will
scroll fast or slow, only a bit or till the end.

x Moving the map in map browsing mode: grab the map, and

move it in the desired direction.

MG Motor UK Ltd

2.3 Map screen

2.3.1 Navigating on the map

The Map screen is the most frequently used screen of iGO primo.

A small live map is displayed on the Navigation menu, as a part of the
button.

To enlarge this small map and open the Map screen, tap

This map shows the current position (the Vehimarker, a blue arrow by default), the
recommended route (an orange line), and the surrounding map area.

When there is no GPS position, the Vehimarker is transparent. It shows your last known
position.

You see coloured dots circling around a satellite symbol in the top left corner. The more green
dots you see, the closer you are to get the valid GPS position.

When GPS position is available, the Vehimarker is displayed in full colour, now showing your
current position.

There are screen buttons and data fields on the screen to help you navigate. During
navigation, the screen shows route information.

The

button gives quick access to frequently used functions. You can change the

available functions in Settings.

By default, only one data field is displayed in the bottom right corner. Tap this field to see all
route data fields. Tap any of the data fields to suppress others and display only the selected
one.

MG Motor UK Ltd

The data fields are different when you are navigating an active route and when you have no
specified destination (the orange line is not displayed).

Default data fields when cruising without a destination (tap and hold any of the fields to
change its value):

Field

Description

Shows your current speed given by the GPS receiver.

Shows the speed limit of the current road if the map contains it.

Shows the current time corrected with time zone offset. The accurate
time comes from the GPS satellites, and the time zone information
comes from the map or it can be set instructionly in Regional settings.

(The current time is always displayed in the top left corner of menu
screens.)

Default data fields when navigating a route (tap and hold any of the fields to change its value):

Field

Description

Shows the distance you need to travel on the route before reaching
your final destination.

Shows the time needed to reach the final destination of the route
based on information available for the remaining segments of the
route.

If [DEVICE] is capable of receiving live traffic information, the
calculation takes into account traffic delays affecting your route if they
are received. However, this calculation is rarely accurate.

Historical traffic data can also be taken into account if data is
available.

Shows the estimated arrival time at the final destination of the route
based on information available for the remaining segments of the
route.

Historical traffic data can also be taken into account if data is
available.

MG Motor UK Ltd

2.3.2 Position markers

2.3.2.1 Vehimarker and Lock-on-Road

When your GPS position is available, iGO primo marks your current position with the
Vehimarker. By default, this marker is a blue arrow, but you can change this icon in Settings.

The exact location of the Vehimarker depends on the vehicle type used for route calculation
and the navigation mode. Both can be set in Route settings (page 104).

x If you choose pedestrian and/or off-road navigation: The Vehimarker is at your exact

GPS position. The direction of the icon shows your current heading.

x In all other cases: The Vehimarker may not show your exact GPS position and

heading. If roads are near, it is aligned to the nearest road to suppress GPS position
errors, and the direction of the icon is aligned to the direction of the road.

2.3.2.2 Selected map location (Cursor) and selected map object

You can mark a map location in the following ways:

x  Tap the map when navigating,
x  Tap the map when you are asked to confirm the destination at the end of a search, or
x  Tap the map in Find on Map (page 58)

When a map location is selected, the Cursor appears at the selected point on the map. The

Cursor is displayed with a radiating red dot (

) to make it visible at all zoom levels.

The location of the Cursor can be used as the destination of the route, a new alert point, you
can search for Places around it, or you can save this location as one of your Favourite
destinations.

You can also select some of the objects on the map. If you tap the map at the icon of a Place
of Interest or an alert point, the object will be selected (you see a red circling border around
the object), and you can get information about this object or use it as a route point.

2.3.3 Objects on the map

2.3.3.1 Streets and roads

iGO primo shows the streets in a way that is similar to how the paper road maps show them.
Their width and colours correspond to their importance: you can easily tell a motorway from a
small street.

MG Motor UK Ltd

2.3.3.2 Turn preview and Next street

When navigating a route, the top section of the Map screen shows information about the next
route event (manoeuvre) and the next street or the next city/town.

There is a field in the top left corner that displays the next manoeuvre. Both the type of the
event (turn, roundabout, exiting motorway, etc.) and its distance from the current position are
displayed.

A smaller icon shows the type of the second next manoeuvre if it is near the first one.
Otherwise, only the next manoeuvre is displayed.

Most of these icons are very intuitive. The following table lists some of the frequently shown
route events. The same symbols are used in both fields:

Icon

Description

Turn left.

Turn right.

Turn back.

Bear right.

Turn sharp left.

Keep left.

Continue straight in the intersection.

Go left on the roundabout, 3rd exit (next
manoeuvre).

Enter roundabout (second next manoeuvre).

MG Motor UK Ltd

Enter motorway.

Exit motorway.

Board ferry.

Leave ferry.

Approaching a waypoint.

Approaching the destination.

2.3.3.3 Lane information and Signposts

When  navigating  on  multilane  roads,  it  is  important  to  take  the  appropriate  lane  in  order  to
follow  the  recommended  route.  If  lane  information  is  available  in  the  map  data,  iGO  primo
displays  the  lanes  and  their  directions  using  small  arrows  at  the  bottom  of  the  map.
Highlighted arrows represent the lanes and direction you need to take.

Where additional information is available, signposts substitute arrows. Signposts are
displayed at the top of the map. The colour and style of the signposts are similar to the real
ones you can see above road or by the roadside. They show the available destinations and
the number of the road the lane leads to.

All signposts look similar when cruising (when there is no recommended route). When
navigating a route, only the signpost that points to the lane(s) to be taken is displayed in vivid
colours; all others are darker.

If you want to hide the currently displayed signposts, tap any of them and the normal Map
screen returns until new signpost information is received.

Content .. 1 2 ..
