WORKSHOP MANUAL

DIESEL ENGINE

DIESEL PARTICULATE FILTER

HANDLING MANUAL

TO THE READER

This Workshop Manual tells the servicing personnel about the servicing and maintenance of the

Diesel Particulate Filter. It contains 2 parts: "Information" and "Servicing".



Information
This section contains information below.

• Safety First



Servicing
This section contains information below.

• Servicing

All illustrations, photographs and specifications contained in this manual are of the newest

information available at the time of publication.

Click this mark

 to open the attached file.

KUBOTA reserves the right to change all information at any time without notice.
Since this manual includes many models, information or illustrations and photographs can show

more than one model.

August, 2012

© KUBOTA Corporation 2012

Record of Revisions

For pdf, use search function {Search word} to find the all revised locations.

Last digit

of the

Code No.

Issue

month

Main Revised Point and Corrective Measures {Search word}

Reference

Page

2

2013.09

• Correction of Workshop Manual

The following are the changes from 9Y121-07331 to 9Y121-07332.
1. Information for V6108 was deleted.
2. Information for 03-CR-E4 was added.
3. Information for 07-CR-E4 was added.

All pages

INFORMATION

DIESEL PARTICULATE FILTER HANDLING MANUAL, WSM

I-1

1. SAFETY FIRST

BEFORE YOU START SERVICE

• Read all instructions and safety instructions in this

manual and on your engine safety decals.

• Clean the work area and engine.
• Park the machine on a stable and level ground.
• Let the temperature of the engine decrease before

you start a job.

• Stop the engine, then remove the key.
• Disconnect the battery negative cable.
• Hang a "DO NOT OPERATE" tag in the operator

station.

START SAFELY

• Do not do the procedures below when you start the

engine.
–

short across starter terminals

–

bypass the safety start switch

• Do not make unauthorized modifications to the

engine. This can cause damage and decrease the
engine life.

 SAFETY FIRST

• This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on labels on the

machine itself to warn of the possibility of personal injury. Read these instructions carefully.

• It is essential that you read the instructions and safety regulations before you attempt to repair or use

this unit.

 DANGER

• Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

 WARNING

• Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

 CAUTION

• Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate

injury.

IMPORTANT

• Indicates that equipment or property damage could result if instructions are not followed.

NOTE

• Gives helpful information.
