Network Operations Roles and Responsibilities

Recommends general policy on the operation of a network based on detailed historical

information.

Establishes and monitors security by applying security standards IAW applicable regulations,

standards, and TNOSC.

Executes service desk capabilities for network operational problems and provides remote site

operations support.

Uses managed elements to enable a remote management capability.

Depending on the unit of assignment, performs activities, functions, and tasks in the areas of

network engineering, transmission management, frequency assignment, systems control, etc.

USER

3-74. The user is responsible for proper and acceptable use of his terminal devices. The user shall not

change the configuration or security of his terminal device except under the written conditions established

by the responsible NETOPS manager. Commanders and their staffs are the primary users of the networks

provided by the signal units located throughout all military operations. Along with staff duties and

responsibilities, the staff officer integrates and uses the warfighting function or other information systems to

support the mission. The staff officer coordinates with the S-6 or G-6 (depending on the operational level of

the unit) in all aspects of planning, implementing, integrating, operating, managing, and maintaining these

information systems. The user operates—

Warfighting function, information systems, and equipment under his/her control.

Command and control systems and associated peripherals.

The Standard Army Management Information System.

Office automation.

Radios.

Hardware and software applications.

Other user-owned devices.

3-75. The user is also responsible for the functional operation, troubleshooting, and maintenance IAW the

user’s limitations. If a system or device malfunctions, the situation should be reported to the support NOSC.

The NETOPS manager or system administrator will provide connectivity and configuration advice, where

needed. (For information outlining the responsibilities of the system administrator, refer to AR 25-2.)

19 November 2008

FM 6-02.71

3-23

FOR OFFICIAL USE ONLY

Chapter 4

Network Operations Control Centers

This chapter identifies and describes the organizations that perform NETOPS

functions to manage, control, and secure the GIG at the strategic to the theater

tactical level of operations. This chapter also identifies and describes the control

centers that perform NETOPS functions to manage, control, and secure tactical

networks and their interfaces into the GIG. With a thorough understanding of the

hierarchy of communications systems and network control, signal commanders and

staff can better manage and control communications systems operation support.

GLOBAL INFORMATION GRID NETWORK OPERATIONS

CONTROL CENTERS

4-1. Within the GIG, many organizations perform network and information systems management, security,

and operational direction and control functions. These organizations ensure the GIG is managed through an

established hierarchy of NETOPS control centers. These control centers are located at the global, theater,

and tactical levels. Each center performs integrated GEM, GND, and GCM functions supporting

communications system and information systems. USSTRATCOM, joint and unified commands, and

Service components operate, manage, and staff these centers to control their portion of the GIG.

4-2. The GIG NETOPS control centers, at all echelons, ensure that the Soldier and all DOD components

can obtain and sustain responsive, reliable, secure, and effective GIG services.

4-3. NETOPS architecture is focused on central management from higher-level echelons with overall

responsibility for joint NETOPS in each theater residing under the CCDR. The CCDR relies on support

from USSTRATCOM, JTF-GNO, and the numbered Army SC(T). The USSTRATCOM provides each

CCDR a TNC as an additional asset, and each TNC falls under the tactical control of the CCDR. Each

CCDR is required to establish a TNCC which assists them in maintaining SA and provides them with

operational and tactical control of their respective system and network environment.

4-4. Each TNC provides direct support to its TNCC, ensuring the effective operation and defense of the

GIG within the theater. The TNC is OPCON to JTF-GNO and offers onsite, theater support. Each TNC can

issue technical directives to the A-GNOSC. The TNC develops monitors and maintains a GIG SA view for

the theater. The theater GIG SA view is aggregated and segmented based on requirements provided by the

TNCC as derived from the GIG common SA standards. The GIG SA view will include pertinent theater,

operational, and tactical-level system and network, GND, and GCM status. Coordination with the TNCC is

paramount especially with regards to reporting requirements and SA.

4-5. Successful operations of NETOPS control centers rely on compatibility, interoperability, and the

integration of policies, procedures, standards, and tools. Shared USSTRATCOM, CCDR, and Service

component requirements and responsibilities for successful end-to-end management of the GIG include:

Identification of infrastructure dependencies and vulnerabilities.

Coordination of operational response and reporting.

End-to-end CM and review.

Identification of network and systems purpose, criticality, interdependencies, and information

flow.

Integration of policies, operations, and tools.

19 November 2008

FM 6-02.71

4-1

FOR OFFICIAL USE ONLY

Chapter 4

GLOBAL LEVEL

4-6. Organizations with NETOPS responsibilities at the global level include: Chairman of the Joint Staff,

National Military Command Center, USSTRATCOM, JTF-GNO, GNC, National Security Incident

Response Center, functional combatant commands, and Service and agency headquarters.

4-7. Figure

4-1 graphically portrays the command and control relationships for GNO.

CDRUSSTRATCOM is the supported commander for GNO. The other CCDRs are supporting commanders

to USSTRATCOM for GNO. This relationship gives CDRUSSTRATCOM the authority to direct the

CC/S/A to take action to ensure the availability and integrity of the GIG. While this relationship gives the

CDRUSSTRATCOM global authority, it does not take away the CCDRs’ authority over their assigned

NETOPS forces. For GNO issues, USSTRATCOM will issue orders and alerts through JTF-GNO to the

CCDR, Services, and agencies.

4-8. The CCDR, Services, and agencies will direct compliance with these directives within their AOR

using their inherent authority over assigned forces. This construct will allow USSTRATCOM to exercise its

global authority while strengthening the responsibilities of the other CCDRs. The TNCs will fall under the

OPCON of JTF-GNO for GNO issues. This allows the JTF-GNO to immediately direct action by the TNCs

when necessary to protect the GIG. JTF-GNO will ensure that the CCDRs are informed about all GNO

issues. This OPCON relationship gives JTF-GNO the authority to issue immediate directives when

necessary. The TNCs will provide direct support to the TNCCs and general support to the GNCCs in

executing JTF-GNO directives.

SECDEF

Supported

GCC

USSTRATCOM

FCC

Services

Agency

Title 10/32

NetOps Org

Net Org

(TNCC)

(GNCC)

JTF-GNO

Non-DoD

TNC

GNC

OPCON

Mission

Partner

GNSC

GSSC

GISMC

IC-IRC

Direct

Support

Service NetOps

SCC,FCC,JTF

NetOps Forces

Components

NOSC/CE(I)RT

ADCON

Command Relationship Legend

Supported

OPCON

DirectSupport

ADCON

ORG-----------------Organization

Figure 4-1. Global NETOPS command and control

4-9.

JTF-GNO exercises OPCON of Service GNO units through the ASCC. For the Army, The A-

GNOSC is OPCON to JTF-GNO through USARSTRAT. Defense agencies will follow the NETOPS orders

4-2

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Control Centers

and directives issued by USSTRATCOM and JTF-GNO. Service and Agency Systems Management

Centers and Central Design Authorities are in general support of JTF-GNO, ensuring that the systems they

operate and provide as parts of the GIG are compliant with JTF-GNO guidance.

COMMANDER, JOINT TASK FORCE-GLOBAL NETWORK OPERATIONS

4-10. The CJTF-GNO will lead and direct continuous GEM, GND, and GCM throughout the GIG. To

ensure global decision superiority, they will maintain near real-time SA, end-to-end management, and

dynamic GIG defense.

4-11. The CJTF-GNO will also exercise OPCON of the GIG for global network operations issues. global

network operations issues are those where action or inaction potentially affects multiple CCDR, Services,

and agencies. Under the authority of CDRUSSTRATCOM, JTF-GNO will issue the orders and directives

necessary to maintain the assured service of the GIG. This ensures that the President, SECDEF, CCDRs,

and Services and agencies can accomplish their missions. The CCDR, Services, and agencies will execute

JTF-GNO’s directives within their respective areas and report compliance. To achieve this mission, the

CDRUSSTRATCOM has assigned these tasks to the commander of JTF-GNO. The commander of JTF-

GNO has the following tasks:

Direct GIG NETOPS to ensure confidentiality, integrity, availability and efficiency of the GIG

infrastructure and information services.

Establish and maintain SA of the GIG and report readiness and defensive posture to HQ

USSTRATCOM, as required.

Coordinate with HQ USSTRATCOM staff and subordinate organizations, as required, during the

development, acquisition, implementation, promulgation and operation of NETOPS joint tactics

techniques procedures and tools intended for monitoring performance, threats, policy compliance

and controlling network access.

Assist in identifying, establishing and maintaining GIG NETOPS characteristics, capabilities,

standards and requisite measures of effectiveness for infrastructure and information services.

Direct and oversee NETOPS and defense capabilities. Synchronize network defense capabilities

with the Joint Functional Component Command Network Warfare (JFCC-NW), the joint IO

warfare command and other USSTRATCOM components, as necessary. Assume OPCON or

tactical control (TACON), where applicable, of NETOPS/CND forces and capabilities for day-

to-day and crisis response actions.

In collaboration with the joint IO warfare command and ICW JFCC-NW ensure that computer

NETOPS (computer network attack, CND and CND response action) are synchronized for crisis

and deliberate planning. These activities support USSTRATCOM JFCCs and other CCDRs'

mission objectives and courses of action; including integration with supporting operational and

tactical level plans, as directed by CDRUSSTRATCOM.

Develop course of action (COA) recommendations for NETOPS, including CND and CND

response action, in support of USSTRATCOM and national strategic objectives. Support the

JFCCs for the integration of NETOPS into USSTRATCOM mission areas. Provide an embedded

capability in the Global Operations Center to support JFCC global strike and integration mission

of operational level integration of USSTRATCOM missions and maintaining SA for the

commander.

Establish procedures to conduct CND response action IAW DOD policy and coordinate with

JFCC-NW for Tier 1 CND RAs. CDRUSSTRATCOM retains the execution authority and

responsibility for those procedures.

Oversee procedures to establish and provide measures of effectiveness and damage assessment as

a part of network defense operations.

Provide support for USSTRATCOM and other geographic and functional CCDRs’ exercises,

wargames and experimentation requirements involving NETOPS. Integrate and synchronize

efforts with USSTRATCOM Training and Exercise Division.

19 November 2008

FM 6-02.71

4-3

FOR OFFICIAL USE ONLY

Chapter 4

Provide network defense priority intelligence requirements, requests for intelligence, intelligence

production requirements and intelligence collection requirements with USSTRATCOM J-2 for

tasking, deconfliction and accomplishment.

Perform all-source analysis of threats to the GIG, including threat analysis of foreign malicious

activity, ICW USSTRATCOM J-2, JFCC ISR, and JFCC-NW. Provide assessments and

recommendations to CDRUSSTRATCOM and other CCDRs for changes dictated in network

threat warning and INFOCON procedures.

Establish a relationship with mission area experts in the applicable GCC Standing Joint Force

Headquarters to provide operational support for NETOPS with emphasis on CND capabilities.

This relationship will include the training and periodic qualification of NETOPS support in

Standing Joint Force Headquarters, as required.

Support USSTRATCOM development and execution of NETOPS assessments, research and

development efforts and advocacy of capability needs for the Joint Capabilities Integration

Development System process.

Support USSTRATCOM and JFCC's led efforts to create and maintain strategic-level operations

plans. Support development and coordination of NETOPS and command, control,

communications and computers portions of operations plans, concept plans, functional plans, and

supplemental plans as directed by headquarters. Support other combatant commands with

NETOPS and command, control, communications and computers operational planning and

execution, as directed by headquarters.

Develop and coordinate NETOPS CONOPS.

COMMANDER OF THE GLOBAL NETWORK OPERATIONS CENTER

4-12. The CJTF-GNO has established the GNC as a subordinate command responsible for executing the

daily operation and defense of the GIG. The GNC directs, manages, controls, monitors, and reports on

essential elements and applications of the GIG in order to ensure its availability to support the needs of the

President, SECDEF, CCDRs, Services, agencies, and business and intelligence domains. The GNC

coordinates through technical channels the overall management, control, and guidance for GIG NETOPS

and oversees a collaborative coordination process involving all CC/S/A. The GNC has the following

responsibilities:

Direct the operation and defense of the GIG.

Collaborate with the NETOPS community to ensure effective operation and defense of the GIG.

Advise CDR, JTF-GNO and CDRUSSTRATCOM on matters regarding the allocation and

adjudication of GIG resources.

Advise CDR, JTF-GNO and CDRUSSTRATCOM of any matters impacting the GIG’s integrity

and/or NETOPS issues affecting DOD missions.

ICW CC/S/A, establish and maintain the technical and operational standards by which the GIG

SA will be generated across the GIG.

Provide a consolidated global SA view to the GCCs/TNCCs and other NETOPs components.

Ensure close coordination between the global satellite communications support center (GSSC)

and the Joint Space Operations Center to ensure anomaly/incident management can support SA.

Perform global incident/intrusion monitoring and detection, strategic vulnerability

Analysis, media analysis, and responses to GND-related activity.

Direct COA and coordinate the CND incident RAs across DOD to defend networks under attack.

Determine COA and direct restoral of GIG capabilities and services when required.

Maintain GIG SA in support of each CCDRs current and near term operations as well as

deliberate plans.

Maintain visibility, to include security monitoring of the GIG, through an integrated GIG SA

view. This is achieved through the integration of the TNC and Service/agency collected and

4-4

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Control Centers

shared GIG SA data. This shared SA view includes wireless, terrestrial, SATCOM systems,

enterprise services, and limited logical and physical infrastructure views of the networks.

Identify, localize, and resolve GIG security anomalies that affect the GIG’s ability to support

senior military leadership at the national level, Joint Staff, and supported CCDR.

Coordinate GND support to the CCDR.

Coordinate with and receive support from the DOD law enforcement and counterintelligence

center.

4-13. The GNC establishes procedures facilitating the ability of geographic commanders who share

common GIG assets to:

Consider the impact of one’s own actions or inactions on adjacent commanders and related

business and intelligence communities.

Provide access to timely information among adjacent commanders regarding others’ intentions

and actions, as well as those of non-military agencies or the enemy, which may influence

adjacent activity.

Support adjacent commanders, as required, by establishing a common aim and monitoring the

unfolding situation.

Coordinate the support provided and received.

COMMANDER OF THE GLOBAL NETWORK OPERATIONS SUPPORT CENTER

4-14. The CJTF-GNO will create a subordinate command to provide the day-to-day technical operation,

control, and management of the portions of the GIG that support global operations but are not assigned to a

CCDR. The GNSC will conduct GIG backbone NETOPS, STEP mission support, provisioning of provided

services, network engineering, circuit implementation and inter-theater connectivity among the US Army

Northern Command; US Army, Pacific Command; US Army, European Command; USARSO; and US

Central Command AORs. The GNSC will provide general support to the GCCs and TNCs. The GNSC will

provide direct support to the functional CCDRs.

4-15. The GNSC will provide full-time (24 hours a day, seven days a week), near real-time, correlated

visibility, monitoring, coordination, control, and management support of the global backbone portions of

the GIG. The commander of the GNSC will develop, monitor, and maintain a GIG SA view for the global

backbone. To carry out its mission, the GNSC—

Operates and maintains GIG backbone services within the CONUS boundaries to include

services originating within CONUS to OCONUS locations.

Collaborates with the CC/S/As NETOPS centers to ensure effective operation and defense of the

GIG.

Advises the GNC on issues relative to the allocation and performance of GIG backbone

resources.

Advises the GNC of issues impacting the integrity of the GIG and/or NETOPS issues affecting

DOD missions.

Works collaboratively with the GNC and the CC/S/As to establish and maintain the technical and

operational standards by which information sharing and status reporting will be implemented to

fully enable NETOPS.

Ensures compliance with JTF-GNO issued directives and guidance within their respective areas

of responsibility.

Provides SA information for backbone services within their boundaries of the GIG.

Monitors and collects performance and trending data for those GIG resources deemed important

by JTF-GNO.

Provides system and network status (fault and performance) information for their portion of the

global SA view.

19 November 2008

FM 6-02.71

4-5

FOR OFFICIAL USE ONLY

Chapter 4

Assists in the correlation and analysis to determine the technical and operational mission impacts

caused by degradations, outages, and GND events.

Performs global, theater, and non-global incident/intrusion monitoring and detection, strategic

vulnerability analysis, media analysis, and coordinates responses to GND-related activities.

Directs the execution of CND incident RAs within their respective areas of responsibility to

defend networks under attack.

Determines COAs and directs the restoral of capabilities and services as required.

Maintains SA in support of each functional component commander's current, near term, and

deliberate planning operations, as required.

Maintains security monitoring through an integrated GIG sensor grid.

Coordinates with and receive support from the law enforcement/counter-intelligence community.

FUNCTIONAL COMBATANT COMMANDS (UNITED STATES STRATEGIC COMMAND, UNITED

STATES SPECIAL OPERATIONS COMMAND, UNITED STATES JOINT FORCES COMMAND, AND

UNITED STATES TRANSPORTATION COMMAND)

4-16. Functional CCDRs have a global mission, often providing support to the GCCs, and have a global

requirement for NETOPS support. Some functional CCDRs operate their own function-specific global

network, Joint National Training Capability, Global Transportation Network, and Ballistic Missile Defense.

The functional CCDRs will receive direct support from the GNSC and general support from

USSTRATCOM, JTF-GNO, and all TNCs. Functional CCDRs will exercise OPCON over their portions of

the GIG through their GNCC. The GNCC will coordinate the functional CCDR’s NETOPS requirements

with the GNSC and the TNCCs.

GLOBAL NETOPS CONTROL CENTER

4-17. The primary mission of a GNCC is to advise the functional CCDR and ensure the portion of the GIG

resources supporting the commander’s assigned missions and operations are optimized. To be effective,

each GNCC must remain cognizant of all current, future, or contemplated operations in which their portion

of the GIG will play a role.

4-18. The GNCCs monitor the CCDR’s GIG assets, determine operational impact of major degradations

and outages, and coordinate responses to degradations and outages that affect joint operations. Each GNCC

will coordinate with the GNC and support any TNC mission or operational impacts that are associated with

system and network anomalies or resource limitations. Additionally, the GNCC has direct liaison

authorization with the TNCCs. This authorization gives the GNCCs and TNCCs the ability to directly

coordinate scheduled changes in the GIG or troubleshoot outages.

SERVICES AND AGENCIES

4-19. The Services and defense agencies provide, operate, and maintain the vast majority of the equipment,

personnel, and other resources that make up the GIG. Execution of these functions requires the Services and

agencies to be actively engaged in NETOPS of the GIG. To execute these functions, the Services and most

agencies have established NOSCs, which maintain SA of their portions of the GIG. In this manual, these

organizations are called Service and agency global NOSCs.

4-20. These Service GNOSCs and agency GNOSCs serve as a central point of contact for matters

concerning the resources they provide to the GIG. JTF-GNO will exercise OPCON of the Service

GNOSCs. DOD agencies will align their agency GNOSCs to provide USSTRATCOM visibility and insight

of their GIG status and will follow the orders and directives issued by JTF-GNO. Services and agencies will

maintain a global perspective of their GIG assets and provide service specific support to the global network

operations mission. This global SA is necessary for the Service and agency to properly provide the

equipment, personnel, and other resources they contribute to the GIG. The Army executes its Service

GNOSC responsibilities via the A-GNOSC and the ACERT (also known as the A2TOC).

4-6

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Control Centers

ARMY GLOBAL NETWORK OPERATIONS AND SECURITY CENTER

4-21. The A-GNOSC is the Army's execution arm for Operations, Management and Defense of the LWN.

The A-GNOSC executes this responsibility using the NETOPS construct. The A-GNOSC uses the

NETOPS essential tasks of ESM/NM, IA/CND and IDM/CS to execute its responsibilities in order to

achieve LWN availability, LWN information protection and delivery. The A-GNOSC synchronizes,

coordinates and directs all Army LWN IT/information management service management, through the

TNOSC in each ASCC; the ACOMSs, the direct reporting units, and the PEOs. The A-GNOSC is

responsible for acquiring and providing NETOPS SA to the Army decision makers at all echelons.

Service Responsibilities

4-22. As the first step in achieving GNO, the SECDEF has approved the transfer of OPCON of the A-

GNOSC to CDRUSSTRATCOM through the designated Service component (ARSTRAT) headquarters for

CND per Headquarters Department of the Army Computer Network Operations Standing Execute Order.

CDRUSSTRATCOM will further delegate OPCON of the A-GNOSC to JTF-GNO. The A-GNOSC serves

as a part of the Service component to JTF-GNO. The A-GNOSC mission is to provide the Army-specific

NETOPS reporting and SA for the Army’s portion of the GIG. The A-GNOSC provides worldwide

operational and technical support to the Army’s portion of the GIG across the strategic, operational, and

tactical levels, leveraging collaboration of the established TNOSC. The Army NOSC is integrated with the

1st IO CMD ACERT to create a consolidated NETOPS center called A2TOC. This alignment of

organizations provides a critical synergism of effectiveness and efficiency to receive, distribute, and analyze

information in order to integrate, synchronize, and coordinate Army NETOPS.

Note. To enhance the A-GNOSC support to the CDRUSSTRATCOM in CND, Appendix F will

provide the CND view of the LandWarNet information assurance architecture (LIAA).

THEATER LEVEL

4-23. The theater portion of the GIG, from the operational perspective, is comprised of that portion of the

GIG operated by a Geographic Unified Command, its sub-unified and component commands, its joint and

single-service task forces, and installations and activities within the AOR. From a technical perspective, it is

a subset of GIG assets, resources, and services.

4-24. Figure 4-2 depicts the command and control relationships for theater NETOPS. The theater CCDR

exercises OPCON of all assigned NETOPS forces and their portion of the GIG. The USSTRATCOM TNC

is under the tactical control of the theater CCDR for theater NETOPS issues. The CCDR’s TNCC is

responsible for the operation of their portion of the GIG and issues directives to the TNC and component

NETOPS organizations to ensure that the GIG supports the theater mission. USSTRATCOM and JTF-GNO

are in support of the theater CCDR and ensure that the GIG is capable of supporting the theater CCDR’s

requirements.

4-25. When there are conflicts or resource contention between CCDRs’ requirements, JTF-GNO will

deconflict resource requirements. Competing resource requirements that cannot be resolved will be

forwarded through CDRUSSTRATCOM to the CJCS for adjudication. The Service and agencies may

establish theater-level NOSCs or provide 24 hours a day, seven days a week theater level SA to support the

requirements of the CCDRs and their Service components. Either the global or theater NOSC will provide

theater GIG visibility to the TNC and other DOD component NOSCs as required. This Service or agency

NOSC will also serve as a central point of contact for operational matters and emergency provisioning for a

supported CCDR. This will enable improved GIG SA at all levels of the command structure and facilitate

end-to-end GIG management.

19 November 2008

FM 6-02.71

4-7

FOR OFFICIAL USE ONLY

Chapter 4

SECDEF

Supported

GCC

FCC

USSTRATCOM

Services

Agency

Title

10/32

NETOPS Org

GNCC

TNCC

COCOM

JTF-GNO

Non-DoD

TNC

GNSC

GISMC

GNC

Mission

GSSC

Partner

IC-IRC

SUC,SCC,FCC,JTF

Service NETOPS

SCC,FCC,JTF

NETOPS Forces

Components

NETOPS Forces

NOSC/CE(I)RT

ADCON

Command Relationship Legend

Supported

OPCON

DirectSupport

ADCON

General Support

TACON

Coordination

Figure 4-2. Theater NETOPS command and control

GEOGRAPHIC COMBATANT COMMANDS (UNITED STATES CENTRAL COMMAND, UNITED

STATES EUROPEAN COMMAND, UNITED STATES PACIFIC COMMAND, UNITED STATES

NORTHERN COMMAND, UNITED STATES SOUTHERN COMMAND)

4-26. The GCC exercises OPCON over the GIG and component NETOPS forces, and exercises tactical

control over the TNC for theater NETOPS matters. To accomplish this, all GCCs will establish a TNCC,

through which they will maintain SA and exercise OPCON and tactical control of their apportioned,

allocated, or assigned system and network environment. The CCDR’s main operations responsibility at the

theater level is to direct, establish, and control the systems and networks used to conduct command and

control of the CCDR’s mission.

THEATER NETWORK OPERATIONS CONTROL CENTER

4-27. The primary mission of the TNCC is to lead, prioritize, and direct GIG resources to ensure they are

optimized to support the GCC’s assigned missions and operations. The TNCC is also required to advise the

4-8

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Control Centers

CCDR of the ability of the GIG to support current and future operations. In performing its mission, the

TNCC exercises OPCON over all theater systems and networks operated by forces assigned to the CCDR.

The TNCC also exercises tactical control over the TNC for theater NETOPS issues. The specific roles of

the TNCC include monitoring of the GIG, determining operational impact of major degradations and

outages, coordinating responses to degradations and outages that affect joint operations, and coordinating

GIG actions in support of changing operational priorities. The TNCC also responds to JTF-GNO direction

when required to correct or mitigate a GNO issue.

4-28. The TNCC, in advising the CCDR of the GIG’s ability to support assigned missions and operations,

must remain cognizant of all current, future, or contemplated operations involving the GIG. This requires

continual contact and coordination with the CCDR’s Joint Operations Center. Serving as an operational

extension to the CCDR’s command center, the TNCC provides GIG SA and operational impact assessments

to the commander and the Joint Operations Center.

4-29. The TNCC will use the GIG SA view provided by their TNC, component NETOPS organizations,

and theater JNCCs to maintain SA over the portion of the GIG necessary for the success of their CCDR’s

assigned missions. Although the NETOPS SA software application will be a part of an enterprise-wide

software toolset, the input data requirements and output products (picture or view reports, etc.) will be user

customizable, based on built-in options, to meet the needs of each CCDR.

4-30. The TNCC is responsible for coordinating the definition and development of the content and scope of

the GIG SA information view for the theater based on DOD parameters to assure complete integration. This

will be based on the commander’s guidance and requirements submitted by subordinate commands. The

specifications will be submitted to the TNC, which is responsible for producing and disseminating the GIG

SA view. Some level of minimum SA view shall be defined to ensure that all NETOPS facilities provide a

consistent set of information and to make it easier to integrate and roll-up SA views generated by different

theaters or organizations.

4-31. The TNCCs will direct and prioritize required operational actions through their supporting TNC and

assigned NETOPS forces. System and network management activities, in response to NETOPS decisions

made by the TNCC, are accomplished through the CCDR’s tactical control authority over the TNC and

through OPCON over forces assigned to the CCDR. In order to carry out it’s mission, the TNCC will:

Establish uniform 24 hours a day, seven days a week visibility into the status of the GIG SA view

to/from the TNC and assigned NETOPS organizations.

Collaborate with the NETOPS community of interest to ensure effective operation and defense of

the GIG.

Establish and retain visibility of system and network outages and customer service shortfalls.

Receive, consolidate, and analyze all available reports from the components, agencies, JTFs, and

deployed units.

Direct reporting of NETOPS events, conduct analysis of the impact of such events on the

operational mission, develop alternate COAs, and advise the commander and other senior

decision makers on the status of GIG degradations, outages, GND events, and areas requiring

improvement.

Prioritize the installation and restoration of system and network services for the TNC and

subordinate organizations in the form of a critical customer (i.e., decision-maker) listing.

Direct, coordinate, and integrate response actions to computer network attacks and significant

intrusions affecting the CCDR’s portion of the GIG.

Direct the theater’s response to JTF-GNO directives for correcting or mitigating GNO issues.

Coordinate with JTF-GNO to deconflict the CCDR’s theater NETOPS priorities with the global

network operations priorities of JTF-GNO and USSTRATCOM.

Deconflict issues between the TNC and TNOSC/A-GNOSC.

19 November 2008

FM 6-02.71

4-9

FOR OFFICIAL USE ONLY

Chapter 4

THEATER NETWORK OPERATIONS CENTER

4-32. The TNCs OPCON to the JTF-GNO provide full-time (24 hours a day, seven days a week), near real-

time, correlated visibility, monitoring, coordination, control, and management support of the CCDR,

Service, and agency portions of the GIG. For example, the TNC provides the view of the GIG within a

CCDR’s AOR. This type of capability will include reciprocal, shareable "look-up" and "look-down" near

real-time correlated views of component, sub-unified, and JTF elements of the GIG.

4-33. The commander of each TNC will develop, monitor, and maintain a GIG SA view for the theater.

The theater GIG SA view will be aggregated and segmented based on requirements provided by the TNCC

or GNCC. It will include pertinent theater, operational, and tactical-level system and network GND and

GCM status. To carry out its mission, the TNC will—

Operate and maintain the backbone services of the GIG assets located in their theater.

Collaborate with the NETOPS community of interest to ensure effective operation and defense of

the GIG.

Issue technical directives to STNOSCs and agency TNOSCs to ensure compliance with TNCC

and JTF-GNO direction.

Receive SA information in order to monitor all theater service or Service component and agency

systems and networks designated as mission critical.

Support the CCDR, Services, and agencies by creating and disseminating the NETOPS SA views

for the theater Service or Service component and agency. This is accomplished by integrating

NETOPS event and status information received from those elements within the TNC AOR that

have NETOPS reporting requirements. This shared SA view includes wireless, terrestrial, space

based systems, and enterprise services.

Coordinate with the TNCC regarding reporting requirements (input data) and view specifications

for NETOPS SA.

Continuously monitor and collect performance data for those information resources deemed

important by the CCDR’s TNCC or GNCC.

Provide system and network status (fault and performance) information as part of the SA view.

Provide the TNCC or GNCC with information security products and services to include: the

monitoring and reporting of intrusions, physical threats and analysis, correlation of intrusion

incidents with components, sub-unified commands, and JTFs.

Assist in determining the technical and operational mission impacts caused by degradations,

outages, and GND events.

Perform incident and intrusion monitoring and detection, strategic vulnerability analysis,

computer forensics, and responses to GND-related activity. Direct COAs and coordinate the

GND incident response actions across DOD to defend networks under attack.

Determine COAs and direct restoration of capabilities and services when required.

Maintain SA in support of each CCDR's current and near term operations as well as deliberate

plans.

Maintain security monitoring through an integrated GIG SA view. This is achieved through

integration of TNC and Service or agency collected and shared GIG SA data. This shared SA

view includes wireless, terrestrial, and space-based systems and enterprise services.

Identify and resolve computer security anomalies that affect the GIG assets located in their

theater.

Coordinate theater GND support as directed by the TNCC.

Coordinate with and receive support from law enforcement and counterintelligence center.

Manage theater radio frequency interference resolution, satellite anomaly resolution, and

SATCOM systems.

4-10

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Control Centers

SERVICE AND AGENCY THEATER NETWORK OPERATIONS AND

SECURITY CENTERS

4-34. Service components supporting a geographical combatant command may establish TNOSCs based on

the size and topology of their NETOPS responsibilities in order to provide and manage systems and

network services. The TNOSC will serve as a single point of contact for their theater elements for systems

and network services; ESM/NM, IA/CND, and IDM/CS capabilities; and operational reporting. The

TNOSC provides GIG SA information to the TNC and the TNCC. In the absence of a TNOSC, the A-

GNOSC will perform the function of the TNOSC. To facilitate end-to-end management and maintain the

accuracy of the GIG SA view, each TNOSC will—

Sub-exercise routine, day-to-day management, control, and defense of system and network

services provided as part of the GIG.

Collaborate with the NETOPS community of interest to ensure effective operation and defense of

the GIG.

Comply with GIG SA (visibility and status) reporting requirements for their portion of the GIG

as determined by the CCDR.

Provide GIG SA information specifically from the TNC points of presence to the component’s

deployed forces.

Provide the TNCC or GNCC and TNC current (near real-time) SA of systems and networks

under their control and within their portion of the GIG for retrieval and use by other NETOPS

centers.

Assist the TNC and the TNCC or GNCC in tracking the status of NETOPS events and

determining the technical and operational mission impacts caused by NETOPS events.

Respond to a variety of threats using a range of response measures to preclude, detect, and

counter any threat.

Exercise tactical control over the system and network resources of their assigned NOSCs,

divisions, and brigades and systems administrators.

ARMY FORCES NETWORK OPERATIONS AND SECURITY CENTER

4-35. The ARFOR NOSC is provided by the SC(T)’s TNOSC. The ARFOR G-6, as a staff officer, should

establish an Army NETOPS Control Center.

4-36. The Army NETOPS Control Center provides the commander’s intent and direction to the TNOSC

that is responsible to operate, manage, and defend the theater’s portion of the LWN and GIG. The TNOSC

executes the command’s intent and direction for the LWN. The SC(T) or its deployed element is OPCON to

the ARFOR. Thus the TNOSC or its deployed element is OPCON to the ARFOR.

THEATER NETWORK OPERATIONS AND SECURITY CENTER

4-37. The TNOSC operates, manages, and defends LWN in order to deliver seamless communications

system information management capabilities in support of all in-theater Army entities in its AOR. The

TNOSC executes its NETOPS responsibilities ICW the numbered Army G-6. The responsibilities of the

TNOSC include the oversight of both fixed theater infrastructure as well as tactical Army units within the

theater AOR. Figure 4-3 represents the TNOSC structure.

UNIFIED COMMANDS

4-38. CCDRs may organize a sub-unified command and assign tailored forces from among the four Service

components and special operations forces to the sub-unified commander. The CCDR assigns the sub-unified

commander OPCON of designated forces.

19 November 2008

FM 6-02.71

4-11

FOR OFFICIAL USE ONLY

Chapter 4

4-39. Sub-unified commands may establish sub-unified NETOPS control centers with responsibilities and

relationships similar to a Service TNOSC. The sub-unified command’s NOSC will serve as a single point of

contact for their subordinate elements for systems, network services, and reporting.

SUB-UNIFIED NETOPS CONTROL CENTER

4-40. Sub-unified NETOPS control centers will provide GIG visibility and status information to the

geographical combatant command’s TNCC and TNC to facilitate end-to-end management and maintain

accuracy of the NETOPS.

JOINT NETOPS CONTROL CENTER

4-41. The JNCC manages the tactical communications of the joint force, serving as the NOSC for the

deployed portion of the GIG supporting a JTF. It exercises staff supervision over the communications

system signal company belonging to deployed components and subordinate commands. The JNCC provides

the appropriate TNCC with:

GIG SA information (directly to TNCC and TNC).

Mission impact assessments of system and network events.

GIG requirements beyond the JTF’s current assets or authority.

THEATER NETWORK OPERATIONS AND SECURITY CENTER DEPLOYMENT SUPPORT

DIVISION

4-42. In conjunction with the modular restructuring of the Army, the SC(T) is undergoing revision in order

to support emerging requirements of the new modular force. One revision is the addition of a new

deployment support division within the TNOSC. The deployment support division has primary

responsibility for all NETOPS support to deployed forces. It is comprised of two branches: the tactical

network team (TNT) and the tactical integration cell (TIC). Refer to Figure 4-3 for an illustration.

Office of the

Directorate

TNOSC

Ops Div

Info

Deplymt

IDM/CS

Enterpr

Network

Enterpr System

Assur

Support

DIV

Serv Div

Mgt Div

Div

Mission

Support Br

Data

Sys Spt

Tactical

Config

Infostruct

NW & SYS

Network

& Integr

Integrat’n

Mgt Br

Serv Br

Monitor BR

Cell

Action

Request

Center

Service

Voice

Database

Info

Tactical

IDM

Level Mgt

Systems

Mgt&

Assur

Network

Applic Br

Tm(TNT)

Transmsn

Systems

Figure 4-3. TNOSC structure

4-12

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Control Centers

Tactical Network Team

4-43. The TNT is an authoritative NETOPS cell for a joint or Army component command. It is a fully

deployable (but based on mission, enemy, terrain and weather, troops and support available-time available,

it is not necessarily fully or always deployed) NETOPS entity that can provide a complement of NETOPS

capabilities to a deployed headquarters. For example, the TNT could deploy to implement or augment the

ARFOR NOSC supporting the JFLCC.

Tactical Integration Cell

4-44. The TIC is a body of tactical network personnel within the deployment support division of the

TNOSC that is dedicated to the integration and support of tactical units. This would include oversight and

management of tactical numbered Army NETOPS support services, such as the network service center

regional and tactical NETOPS systems. It also includes the formation of temporary tactical liaison team

(TLT), which is dedicated to support a specific tactical unit.

4-45. Other divisions under the TNOSC structure include a TNOSC Operations Division, IDM/CS

Division, Enterprise Services Division, Network Management Division, Enterprise Systems Division, and

the Information Assurance Division. Each division is structured with several branches reporting to the

division which reports to the directorate.

TNOSC OPERATIONS DIVISION

4-46. The TNOSC Operations Division is the analog of the S-3 in a regular battalion. It has oversight of the

day-to-day operations of all divisions, focusing on larger systemic problems that require directed focus or

resolution. The division consist of the following branches:

Mission Support Branch. This branch provides all the administrative and logistic support for

the TNOSC. Included here are the budget, personnel, and training activities. Contracting

Officer’s Representative duties and oversight of other contracts (for which the TNOSC is not the

Contracting Officer’s Representative) that affect the TNOSC. Responsible for procurements,

Unfunded Requirements, Program Objective Memorandum submissions, IMPAC card, military

interdepartmental purchase request tracking and coordination with resource managers. This

branch operates 8 hours a day, 5 days a week.

Action Request Center. This branch operates 24 hours a day, seven days a week to provide SA

of all NETOPS activities that the TNOSC controls or interacts with. The staffing for the watch

officers is in the action request center. This branch does all reporting to higher and lateral

agencies. It provides overall direction of troubleshooting and reporting of subordinate units. This

branch operates 24 hours a day, seven days a week.

INFORMATION DISSEMINATION MANAGEMENT DIVISION

4-47. The IDM Division provides the CM for the theater operations. It also determines customer info

source/sink and provides immediate feedback of the accuracy of the CM documents and products providing

the best feedback loop. The division consist of the following branches:

Configuration Management Branch. This branch runs the theater level NETOPS CM program.

It chairs the theater NETOPS CCB. It maintains the CM database and network level drawings.

This branch manages the program for the theater and monitors and measures the effectiveness of

subordinate CM programs. Coordinates with the theater Army G-6 and signal command theater

program managers to insure projects are included in the CM process. This branch works 8 hours

a day, 5 days a week.

IDM Branch. This branch manages the theater IDM program, establishing the architecture and

overseeing the IDM efforts of subordinate NOSCs. Coordinates IDM with other divisions and

teams. Provides expertise to incorporate IDM into communications planning, optimizes IDM

infrastructure resources, analyzes and documents IDM requirements and implements IDM

enabling technology to include CS. This branch works 8 hours a day, 5 days a week.

19 November 2008

FM 6-02.71

4-13

FOR OFFICIAL USE ONLY

Chapter 4

ENTERPRISE SERVICES DIVISION

4-48. The Enterprise Services Division operates the applications (as opposed to the networks) that provide

the enterprise network services and enable the management of the enterprise ―down to the desktop‖. This

division also tracks and monitors operation of the area processing centers (APC) in theater. The division

consist of the following branches:

Infostructure Services Branch. This branch manages the services that the networks provide to

enable the customers to utilize the enterprise. These services would include DNS, Remote

Authentication Dial-In User Server (RADIUS), and remote access services (VPN program). It

includes management of the AD theater root and domain controllers/catalogs. It includes

messaging services and management of Defense Message Service and Exchange.

Service Management Branch. This branch implements the Service Management program for

the TNOSC and the theater. It manages the Service Level and Operational Level Agreements that

the TNOSC enters into. It monitors the theater Service level delivery program for the

TNOSC/SC(T) and the subordinate units providing the SC(T) and commanders with SA of the

service delivery across all disciplines of NETOPS. It provides performance management

monitoring and reporting on the Information Technology Infrastructure Library

capacity/availability areas and trending. The plans and engineering sections of the theater army

G-6 and the signal command theater assistant chief of staff, operations (G-3) are customers of the

performance analysis. This branch works 8 hours a day, 5 days a week.

NETWORK MANAGEMENT DIVISION

4-49. The Network Management Division operates and/or manages the underlying ―transport‖ networks

that other applications and services use. It is the focus on the underlying network that distinguishes it from

the Enterprise Services Division. In some cases, the TNOSC operates a theater backbone and directs the

operation of subordinate agencies in their operation of lower portions of the network. In other cases, it

entirely directs the operations of subordinate units. A good example of this dichotomy is (the current day)

DISA RNOSC/SC(T). It operates an IP backbone, but the Service/agencies operate the DSN backbone

(OCONUS). The division consist of the following branches:

Data Networks Branch. This branch provides oversight of the IP router networks (classified

and unclassified). Operates the theater IP backbone. Provides oversight to operation of the IP

networks by subordinate organizations. Provides theater level analyst functions, theater designs

and access list architecture. Implements theater level IP reach back, to include routing plans,

when the reach back is not to a STEP site. Reporting and SA of theater IP network capabilities.

This branch operates 24 hours a day, seven days a week.

Switched Systems Branch. This branch manages/operates the voice networks in theater, to

include DSN and Defense Red Switch Network (DRSN). Actions performed by this branch

include oversight of subordinate operating activities, validation of DISA implementation

directives, CM of switches, integrating voice reach back and trunking, reporting and SA for

voice capabilities within the theater. This branch operates 24 hours a day, seven days a week.

Transmission Systems Branch. This branch operates/manages the transmission systems

backbone, and oversees the operations of transmission systems by subordinate units. Examples of

backbone systems operated include Fiber infrastructure, synchronous optical network, dense

wavelength division multiplexing, asynchronous transfer mode (ATM), and integrated digital

network exchange. Coordinates theater wide COMSEC re-keys. Oversees/tracks operation of

satellite facilities by subordinate units. SA reporting for all transmission systems, to include

deployed units. Depending on theater may also monitor circuits on STEP facilities (via ―copy‖

feed of native management system). Implements routing plans. This branch operates 24 hours a

day, seven days a week.

4-14

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Control Centers

ENTERPRISE SYSTEMS MANAGEMENT DIVISION

4-50. This division manages the internal systems of the TNOSC (LAN, power, servers and operating

systems) and devices distributed throughout the theater controlled by the TNOSC (such as DNS/RADIUS).

The division consist of the following branches:

Systems Support and Integration Branch. This branch provides support for the infrastructure

and servers, with their accompanying operating systems. Notionally, this branch has a UNIX

team, and Windows team, and a team that supports the infrastructure (switches, routers, virtual

LAN configurations) as well as environmental concerns (power, A/C, server room management).

The system administrators perform backups and coordinate this part (server restoral) of the

COOP. Support for various operating system related tools, such as Citrix. They centrally manage

patches and upgrades for the TNOSC controlled servers. This branch operates 8 hours a day, 5

days a week with on-call support.

Database and Applications Branch. This branch operates and maintains the applications used

by the TNOSC and distributed throughout the theater. A notional list would include: Remedy,

Spectrum (or other network management systems), Formula, Tivoli, Oracle, Cricket/MRTG,

ATM manager (supporting Remedy, as well as other applications such as CiscoWorks,

CiscoSecure, et al). This team also integrates programs and provides interfaces to other agencies’

systems (e.g. feeding status from Spectrum to DISA’s integrated network management system).

This branch also establishes the technical architecture for distributing these products and views

throughout the theater. This branch operates 8 hours a day, 5 days a week with on-call support.

INFORMATION ASSURANCE DIVISION

4-51. The IA Division provides operational oversight of the IA aspects of the network. The division consist

of the following branches:

Network and Systems Monitoring Branch. This branch monitors the theater network sensor

grid, including the IDS, other Top Level Architecture sensors, DID IDS sensors, host based IDS,

(theater level) firewalls, etc. It provides detection, first level analysis (triage) and initial response,

to include coordinating for blocking actions, trouble ticket initiation and dispatch. This branch is

staffed 24 hours a day, seven days a week.

Information Assurance Branch. This branch does the follow up, tracking, and reporting of

incident tickets. Performs internal and directed external scans and reports. Designs and verifies

ACL/firewall rule set. IAVA reporting for the TNOSC. Manages the theater software update

services program

(or other update service). Manages theater Anti-Virus update programs.

Manages theater CAP registration. Oversees accreditation and security actions of subordinate

units’ IA personnel. Crosschecks patch levels and IAVA compliance for all TNOSC systems.

This branch is staffed for 8 hours a day, 5 days a week with on-call support.

4-52. The TLT performs a liaison function to a corps, division, or brigade NETOPS cell that already exists.

The TLT provides essential integration services between the tactical unit and the respective TNOSC. It also

provides valuable technical NETOPS augmentation to the unit’s organic NETOPS capability. When

supporting a corps or division and a corps or division-based command, a TLT would typically collocate

with appropriate personnel at the assigned sanctuary. TLT personnel in support of an expeditionary BCT

may perform these functions from the TNOSC, or they may relocate to other locations as the mission

dictates. A typical scenario for these elements is depicted in Figure 4-4.

19 November 2008

FM 6-02.71

4-15

FOR OFFICIAL USE ONLY

Chapter 4

TNT

REAR

TIC

STEP

TNOSC

TLT

Division Signal

Company

DIV

JTF/JFLCC

TNT

FWD

SBDE

BCT

SBDE

BCT

BDE Control

DIV Control

ASCC Control

Joint Control

Robust Transmission

Tactical Transmission

Figure 4-4. TNOSC deployment support division elements: TNT, TIC, and TLT

TACTICAL SIGNAL BRIGADE NETOPS

4-53. The SB(T) S-3 performs NETOPS functions for all subordinate ITSB/ESBs and other supported

units. It also serves as the NETOPS interface to higher headquarters (e.g., it acts as a tactical NOSC). This

includes operational planning in conjunction with the theater G-6 as well as detailed engineering of

ITSB/ESB provisioned NETOPS capabilities.

INTEGRATED THEATER SIGNAL BATTALION NETOPS

4-54. The battalion S-3 element of the ITSB/ESB headquarters provides a NETOPS span of control

function for the ITSB/ESB. The S-3 performs all NOSC functions necessary to manage and secure the

ITSB/ESB network assets, and provide NETOPS capabilities and SA to the supported commander.

DIVISION NETOPS AND SECURITY CENTER

4-55. The division G-6 employs a fully integrated NOSC that provides NETOPS functions for the division

G-6. The division signal elements must coordinate with the NOSC during the engineering, installation,

operation, maintenance, and defense of the division information network.

4-56. Habitually, the division NOSC is co-located with one or more division TOCs. Due to recent

enhancements to tactical reach operations capability, the division G-6 may elect to perform some or all

NOSC functions from remote sanctuary locations such as the division tactical UHN or a division-controlled

cell within the network service center regional. Performing NOSC functions at unit-controlled sanctuary

locations is generally most effective during deployment and decisive operations. During these phases, the

division TOC is highly mobile and cannot provide a stable high-speed environment to host AOR services.

4-16

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Control Centers

4-57. The division NOSC, under the direction of the division G-6, has overall responsibility for establishing

the division information network and provides the operational and technical support to all of the division

signal elements in its AOR. The division NOSC performs the NETOPS activities, functions, and tasks

required to quickly shift priorities in order to support the division commander’s intent. Division NOSC

responsibilities include:

ICW the TNOSC, monitors, manages, and ensures implementation of ESM/NM, IA/CND, and

IDM/CS activities (performed by the division G-6 and subordinate organizations).

Provides near real-time awareness of division networks and systems to the division G-6 and

higher headquarters’ NOSC.

Coordinates actions to resolve attacks or incidents on the division network with the TNOSC and

subordinate organizations.

Coordinates operational procedures and requirements for IA/CND and information systems

security with the supporting TNOSC.

ICW the TNOSC, monitors, manages, and controls intra-division information network

components (performed by the division G-6).

Monitors the operation of the networks in the division’s subordinate brigades.

Provides support and assistance to the subordinate NOSCs as required.

Manages the organizational messaging system of record (Defense Message System, Tactical

Message System) in the division, including managing network addresses and sub-domains.

Coordinates operation and maintenance support of communications systems attached to support

deployed division forces with the split-base and reach operations capability to the home base.

Shares ESM/NM information with other management or monitoring centers.

Provides the supporting TNOSC with near real-time information on the status and performance

of inter-division networks.

Orders and accounts for all forms of COMSEC material. This includes storing keys in encrypted

form and performing key generation and automatic key distribution.

Performs COMSEC material accounting functions and communicates with other COMSEC

elements.

Performs IDM/CS functions to support all aspects of relevant information dissemination.

Provides near real-time awareness of all networks and systems within the division AOR.

BRIGADE NOSC

4-58. The brigade NOSC is the control center for the brigade network that manages all current operations

and network configuration. The brigade NOSC reports directly to the brigade G-6. The brigade NOSC

operates closely with the TOC nodal platoon, utilizing the JNN’s organic network management capability to

configure, monitor, and manage the WAN. The brigade NOSC supports the G-6 section in the planning,

configuration, management, and monitoring of the TOC LANs as well as prioritizes the dissemination of

information across the WAN. ICW the brigade G-6, the brigade NOSC—

Coordinates, plans, and manages brigade frequency assignments.

Plans and manages the brigade information network.

Plans and manages all IA/CND operations to include, but not limited to, IA systems (firewalls,

IDSs, and ACLs), key management distribution, IAVA compliance, and IDM and operations,

and compliance with all directives outlined in AR 25-2.

Plans and manages brigade IDM/CS procedures (user profiles, file and user priorities, and

dissemination policies) (at higher headquarters’ NOSC and supporting TNOSC).

Evaluates network requirements to determine needs for brigades and communications relay

requirements.

Aides in the execution of all NETOPS responsibilities in support of the unit mission.

19 November 2008

FM 6-02.71

4-17

FOR OFFICIAL USE ONLY

Chapter 4

Note. To support the information in this chapter, Appendix G and H provides deployment

scenarios for the division, BCT, and ASCC.

NETWORK OPERATIONS COMMAND AND CONTROL

RELATIONSHIPS

4-59. The senior ARFOR mission commander commands and controls the tactical Army network in

compliance with joint, Army, and theater NETOPS policy and direction. To ensure that a seamless and

autonomous network is achieved, the mission commander delegates the authority to control and configure

the network to the G-6 through the telecommunications service order (TSO) process.

4-60. For current operations, the G-6 coordinates network reconfigurations through technical channels

based on the TSO process mentioned above and as specified by the commander in the operations order.

These changes include frequency modification, router configurations, or equipment settings. When

reconfiguration involves the movement of personnel and equipment within the current operation, the G-6

coordinates that adjustment with the G-3 and the G-3 issues the appropriate fragmentary order (FRAGO) in

support of that reconfiguration.

4-61. For future operations, the G-6 participates in the military decision making process. He identifies the

correct placement of network equipment and personnel on the battlefield in support of the mission. This

information is then vetted through COA development and published in the unit OPORD and requisite signal

annex.

4-62. The TSO process and technical channels are used for coordinating the configuration of the network.

This process flows from the GCC J-6 through the JTF, combined joint force land component command,

ARFOR, corps, division, BCT, and the battalion J-6, G-6, and S-6 structure to facilitate the establishment

and health of the enterprise network and theater network.

4-63. NETOPS control is the authority granted to a senior signal officer and his staff from their immediate

operational commander in compliance with joint, Army, and theater NETOPS policy and direction. This

ensures the day-to-day compliance of their network with their associated LWN and GIG requirements. In

addition, the fast moving nature of NETOPS, which is inherently a 24-hour/7-day operation, requires quick

decisions and adjustments that exceed the responsiveness of the traditional orders process.

4-64. Through technical channels coordination and the TSO process, the signal officer and staff execute the

commander’s directives to maintain and secure their network. This process involves policy, guidance, and

directives issued to subordinate signal organizations along the NETOPS channels. The TSO does not allow

the commander’s signal staff to move equipment or personnel but it does allow them to coordinate CM of

network devices within their area of operations. If there is a need to move equipment or personnel in order

to meet network requirements, the signal staff needs to coordinate with their respective G-3 or S-3 and issue

a FRAGO to the existing signal annex of the operations order for movement.

4-65. It is important to remember the TSO is a current operations process. The TSO is designed to give the

commander, through his signal staff, a means to adjust and modify the existing network plan to meet

unexpected circumstances that can range from outright network attacks to system failures and service

interruptions. Any future NETOPS control issues must be planned and executed through the orders process

(military decision making process) performed by the chain of command.

4-66. Lastly, any time the signal staff receives a TSO from a higher signal entity, they conduct a review to

determine if that TSO is potentially detrimental to their commander’s mission priorities. If it is determined

that the impact is not relevant to the mission, the signal staff then executes that TSO and informs the

commander. If the potential exists, the implementation of that TSO will affect the mission; the signal staff

coordinates with the command chain and requests guidance. If the decision is made by the commander not

to execute the TSO, then the necessary coordination to deconflict any issues is performed between the

command chain and the higher headquarters that issued the TSO.

4-18

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Chapter 5

Network Operations Activities

This chapter provides the conceptual framework for the execution of NETOPS. It

links organizations described in Chapter 3 and the phases and relationships described

in Chapter 4. It also addresses methods to reduce forward-deployed NETOPS and

global NETOPS policies and standards.

OVERVIEW

5-1. NETOPS activities were derived from the AENIA. They address the activities associated with the

provisioning and management of NETOPS capabilities. The activities are organized into four major areas:

NETOPS policies, standards, planning, and design. NETOPS policies and standards provide a

common foundation and general guidance for the provisioning and management of NETOPS

capabilities in support of the Soldier. NETOPS capabilities require planning and design to be

effective regardless of the affected organization, system, or technology. Planning and design of

NETOPS capabilities is especially important in the tactical environment with its potential for

limited connectivity and the ―fog of war‖ that can be experienced in the tactical environment.

Tactical operation of the network. The activities in this area directly support the Soldier with

NETOPS capabilities. This support spans all phases of operations. The NETOPS operational

activity area comprises the majority of this chapter. These activity categories represent the best

practices of NETOPS capability providers (both Army and industry) and provide a means of

categorizing NETOPS capabilities that is not specific to any technology or organizational

structure.

NETOPS evaluation. The evaluation of NETOPS capabilities extends the infrastructure

monitoring found in the operations activity area. It supports the monitoring and reporting of

capacity, availability, and IA compliance. It is focused on the health and protection of the

network and its services. It also provides the capability to support proactive management of

NETOPS capabilities.

NETOPS training. Effective use of NETOPS capabilities requires continuous training. As new

or updated NETOPS capabilities enter the tactical environment, the skills of the Soldiers require

enhancement or refreshment.

5-2. The descriptions of the activities in this chapter follow a common template. First, the NETOPS

functional activity itself is defined and described. Next, the echelon(s) and organization(s) that support the

specific activity are identified and details are provided on how organizations support the specific NETOPS

activity. This support information includes the inter-organizational relationships associated with the specific

NETOPS activity. Lastly, any joint implications related to the execution and support of the activities is

identified.

NETWORK OPERATIONS POLICIES, STANDARDS, PLANNING,

AND DESIGN

5-3. NETOPS policies and standards provide a common foundation and guidance for the provisioning of

NETOPS capabilities to the Soldier. The NETOPS planning and design process encompasses the

preparation required for the fielding and the continued support for NETOPS capabilities. Both global and

temporary mission-specific policies and standards are addressed in this section.

19 November 2008

FM 6-02.71

5-1

FOR OFFICIAL USE ONLY

Chapter 5

GLOBAL NETOPS POLICIES AND STANDARDS

5-4. Global tactical NETOPS policies and standards, while approved and issued from the global Army and

joint levels, apply to the provisioning of NETOPS capabilities at all tactical echelons. These policies and

standards define general NETOPS-related system configurations, procedures, protocols, and information

exchange requirements.

Note. Temporary changes to network policies can be more stringent or strict than the global

policies but cannot be less stringent or strict.

5-5. Global NETOPS policies and standards enable compatibility between tactical elements and minimize

the disruption caused by task organization. Global policies and standards are also critical in order to provide

tactical units with strategic support services and to help ensure compatibility between units that come

together from different geographical areas and different commands. Tactical units are partially dependent

on support from non-tactical echelons due to physical and manpower limitations. To effectively provide

strategic NETOPS support, the provisioning of tactical NETOPS capabilities must be performed in a

uniform and well-defined manner. While global tactical NETOPS policies and standards define and support

standardized NETOPS capabilities within tactical echelons, they do not impair the tactical commander’s

ability to dynamically manage and allocate NETOPS capabilities.

5-6. Some examples of global NETOPS policies and standards include:

Protocols and port configuration guidelines.

Inter-organization information exchange requirements.

Change approval and change implementation responsibilities.

Reportable CM information.

Note. Appendix C outlines a scenario of how policy management may occur.

Global NETOPS Policies and Standards in Echelons and Organizations

5-7. The primary responsibility of establishing global Army NETOPS policies and standards resides with

the CIO G-6. Both NETCOM/9^th SC(A) and the US Army Signal Center support the CIO G-6. Refinement

of global policies with respect to tactical echelons is performed via direct interaction between theater

policy-makers and the tactical echelons. Global policies and standards are continually reviewed and

periodically updated based on policy and standards recommendations from tactical organizations, Army

enterprise modularity and efficiency requirements, and relevant technological advancements.

Global Policies and Standards Joint Implications

5-8. A working relationship must be in place between Army NETOPS policymakers and the joint

NETOPS community. Global tactical NETOPS policies initiated from the joint level require incorporation

into global Army policy. Policies arising within the Army tactical community must also be considered by

Army NETOPS policymakers through joint channels. This prevents policy conflicts when Army tactical

elements are operating in a joint environment.

TEMPORARY EXCEPTIONS TO NETOPS POLICIES AND STANDARDS

5-9. Isolated changes or additions to NETOPS policies and standards threaten Army enterprise modularity

and efficiency and should be minimized. NETOPS policies and standards in the tactical environment, due to

the time-sensitive and volatile nature of tactical operations, cannot always adhere to the lengthy policy

change process that is normally required in the fixed-station environment. Mission-specific factors may

necessitate temporary additions or changes to policy.

5-2

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

5-10. Additions, changes, or exceptions to tactical NETOPS policy are approved via the chain of command

as previously described in Chapter 4. Prior approval must be granted from the next higher headquarters if

any particular echelon wishes to add, change, or circumvent tactical NETOPS policy. For example, if a

BCT commander wishes to issue a policy stating that all subordinate units must block a particular network

protocol, prior approval must be obtained from its higher headquarters, which will typically be a division.

This approval process decreases the likelihood that a unit will issue guidance that will impair the

functionality of the assets under its control or impact the broader NETOPS state of affairs. If the policy

addition or change is likely to cause a decrease in overall network health or modularity, the approving

headquarters will carefully consider whether the requirement for the policy change outweighs the potential

impacts.

5-11. In some cases, a policy change or addition requires approval by an echelon higher than the requesting

organization’s parent headquarters. This is expected to occur when the policy change may cause immediate

network-wide security or functionality ramifications. In the general case, echelons above the organization’s

parent headquarters only require notification when there is policy modification.

5-12. Exceptions to policy are forwarded through, and accumulated by, the chain of command. This data

should be reviewed and used to provide recommendations for global Army NETOPS policy and standard

changes and additions.

5-13. In any tactical scenario, there may be urgent situations where there is no time for an approval process

before policy guidance must be issued. The unit commander (advised by the S-6, G-6, and J-6) will make

this decision and take responsibility for any potential impact to the Army enterprise, both fixed and tactical.

Temporary Exceptions to NETOPS Policies and Standards in Echelons and Organizations

5-14. For the BCT and below, temporary exceptions to policies and standards are defined and maintained

by the BCT S-6 personnel. These short-term exceptions to policies and standards are based on BCT mission

requirements and refined from Army global policies and standards, as well as any other temporary mission-

specific policies and standards implemented by echelons within the BCTs chain of command. The BCT

provides policies and standards guidance to its AOR.

5-15. The corps and division G-6 personnel define and maintain temporary exceptions to policies and

standards in support of the corps and division. These exceptions to policies and standards are based on the

corps or division mission requirements and further refined from Army global policies and standards, as well

as any other temporary mission-specific policies and standards implemented by echelons within the corps or

division’s chain of command. The corps and division provide exceptions to policies and standard guidance

to its assigned AOR, including BCTs, ITSBs, ESBs and support brigades. The corps and division should

also consider how changes might affect lateral or supporting organizations and the modularity of

subordinate organizations.

5-16. The numbered Army NETOPS temporary exceptions to policies and standards are defined and

maintained by the numbered Army G-6 personnel. These exceptions to policies and standards are based on

the numbered Army’s mission requirements from Army global, and potentially joint, policies and standards

applicable within their theater. The numbered Army provides policies and standards guidance to its

assigned corps and division, directly reporting BCTs and other theater assets. The ASCC must consider how

any changes could affect NETOPS with other ASCC organizations and should be guided by policies and

direction from the A2TOC.

Temporary Exceptions to NETOPS Policies and Standards Joint Implications

5-17. The ARFOR NETOPS mission specific policies and standards are defined and maintained by

ARFOR G-6 personnel. These mission-specific policies and standards are based on ARFOR mission

requirements and further refined from Army global standards as well as any other temporary mission-

specific policies and standards implemented by echelons within the ARFORs chain of command. The

ARFOR provides mission-specific policies and standards guidance to its assigned corps and division,

BCTs, and other signal elements within its AOR. The ARFOR must carefully consider how policy changes

19 November 2008

FM 6-02.71

5-3

FOR OFFICIAL USE ONLY

Chapter 5

might affect lateral or supporting signal organizations and the modularity of subordinate corps, division, and

BCTs.

5-18. Joint organizations within an Army organization’s chain of command are expected to define and

maintain organizational and mission-specific NETOPS policies and standards. Joint organizational and

mission-specific policies and standards are created and approved through the joint operational environment

chain of command.

5-19. Army tactical organizations will incorporate joint and global Army tactical NETOPS policies and

standards just as they would if their parent headquarters was an Army organization. If Army and joint

NETOPS policies or standards conflict, the organizational S-6, G-6, and J-6 will notify their joint and Army

parent headquarters. The clarification of conflicting policies and standards is the responsibility of their

chain of command.

NETOPS MISSION PLANNING

5-20. NETOPS mission planning is the collection of current and future user requirements, requirements

validation and prioritization, mission alignment to the commander’s intent, the allocation of technical and

organizational resources, and the publication of operation orders. Major NETOPS mission planning is

normally performed during the first phase of the operation. Because of some system transmission delays

that are inherent in some SATCOM equipment, one example of mission planning is to allocate tropospheric

scatter capability to a user instead of a SATCOM. Smaller scale mission planning is performed in all phases

of operations as dictated by mission requirements.

Mission Planning Echelons and Organizations

5-21. All organizations in the tactical chain of command are involved in the NETOPS mission planning

process. As each echelon of the tactical chain of command performs mission planning, guidance is given to

subordinate echelons. This guidance is then used to create or refine NETOPS mission planning at the lower

echelon. Mission planning is a continual process that is performed by the organization’s S-6, G-6, and J-6

staff.

5-22. For the BCT and below, NETOPS mission planning is performed by the BCT S-6. The BCT provides

mission planning support to subordinate maneuver battalions.

5-23. The corps and division G-6 performs NETOPS mission planning in support of the corps and division.

The corps and division provide mission planning guidance to assigned BCTs and support brigades as well

as coordinating mission planning efforts between its subordinate BCTs and support brigades.

5-24. For the numbered Army, NETOPS mission planning is performed by the numbered Army G-6. The

numbered Army provides mission planning guidance to assigned corps and divisions, directly reporting

BCTs, and support brigades. The numbered Army also coordinates mission planning efforts between its

subordinate organizations. The numbered Army G-6 also coordinates with the signal command (theater)

(SC[T]) during this planning process.

5-25. During mission planning and especially during Phase One, coordination may be required between

theaters. The numbered Army will perform inter-theater coordination in support of deploying or re-

deploying organizations.

Mission Planning Joint Implications

5-26. Mission planning is performed by the joint and Army operational environment chain of command.

The joint chain of command will participate in the activities as described. Army tactical organizations will

incorporate joint mission planning guidance as they would should their parent headquarters be an Army

organization. If the Army and joint NETOPS mission planning guidance conflict, the organizational S-6, G-

6, and J-6 will notify their joint and Army parent headquarters. The clarification of conflicting guidance is

the responsibility of their chain of command.

5-4

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

NETOPS CAPABILITY DESIGN

5-27. NETOPS capability employment configuration is usually performed in response to the receipt of

planning information in the form of OPORDs and annexes related to the accomplishment of a specific

mission. NETOPS capability employment configuration supports and provides feedback to the mission

planning activity described in this chapter. NETOPS employment configuration is defined to include—

Development of operational configurations to provide the required IT mission support capability.

Tactical NETOPS capability employment configuration includes development of configurations

for communications, networks, systems, and security capabilities in support of Soldier NETOPS.

Development of operational configurations required to facilitate the internetworking of

NETOPS-related applications, systems, networks, and communications infrastructure.

Capability Employment Configuration Echelons and Organizations

5-28. The tactical environment where NETOPS capability employment configuration is performed depends

on the echelon providing the NETOPS capability, the means by which the capability is provided, the

echelon to which the capability is being provided, and the NETOPS capability being employed. For

example, in electromagnetic spectrum operations, most echelons are required to identify what frequency

resources will be required and where they will be used within frequency management (sometimes referred

to as spectrum management), most echelons are required to identify what frequencies will be used and

where they will be used within their AOR. In other scenarios, electronic messaging may not require

capability employment configuration below the corps or division level.

5-29. All organizations in the tactical chain of command are involved in the NETOPS capability

employment configuration, either directly or in a coordinating or supporting role. As each echelon of the

tactical chain of command performs NETOPS capability employment configuration, information is

provided to subordinate echelons. The echelon that begins the employment configuration process for a

particular system is the highest echelon that must integrate the system across multiple subordinate units. The

employment configuration process then extends down to the echelon that maintains operational management

of the system in question (refer to operational control and management process for further details). This

information is then used to create or refine NETOPS capability employment configuration at the lower

echelon. NETOPS capability employment configuration is performed by the organization’s S-6, G-6, and J-

6 staff.

5-30. For the BCT and below, NETOPS capability employment configuration is performed by the BCT

S-6. The BCT provides capability employment configuration support to subordinate maneuver battalions.

5-31. For the corps and division, NETOPS capability employment configuration is performed by the corps

and division G-6. The corps and division provide capability employment configuration guidance to its

AOR, including assigned ITSBs/ESBs, BCTs, and support brigades. The corps and division coordinate

capability employment configuration efforts between their subordinate BCTs and support brigades. Corps

and division capability employment configuration is focused on facilitating the interoperability of the

NETOPS capabilities between echelons.

5-32. For the numbered Army, NETOPS capability employment configuration is performed by the

numbered Army G-6. The numbered Army provides capability design guidance to assigned corps, divisions,

and directly reporting BCTs. The numbered Army coordinates capability employment configuration efforts

between its subordinate organizations. The numbered Army G-6 also coordinates with the SC(T) in this

capability employment configuration process. The numbered Army’s capability employment configuration

is focused on facilitating the interoperability of the NETOPS capabilities between echelons.

5-33. During capability employment configuration, and especially during Phase One, coordination may be

required between theaters. The numbered Army will perform inter-theater coordination in support of

deploying or redeploying organizations.

19 November 2008

FM 6-02.71

5-5

FOR OFFICIAL USE ONLY

Chapter 5

Capability Employment Configuration Joint Implications

5-34. The ARFOR NETOPS capability employment configuration is performed by the ARFOR G-6. The

ARFOR provides capability employment configuration guidance to its AOR. This includes assigned corps,

division, ITSB/ESB, BCTs, and support brigades. The ARFOR also coordinates capability employment

configuration efforts between subordinate assets within its AOR. ARFOR capability employment

configuration is focused on facilitating the interoperability of the NETOPS capabilities between echelons

and provisioning services to meet mission requirements.

5-35. Tactical NETOPS capability employment configuration is performed by the joint and Army

operational environment chain of command. The joint chain of command will participate in the NETOPS

capability employment configuration in support of assigned Army organizations. Army tactical

organizations will incorporate joint capability employment configuration guidance as they would should

their parent headquarters be an Army organization. If the Army and joint NETOPS capability employment

configuration guidance conflict, the organizational S-6, G-6, and J-6 will notify their joint and Army parent

headquarters. The clarification of conflicting guidance is the responsibility of their chain of command.

TACTICAL OPERATIONS

5-36. Tactical operations are the NETOPS activities that frame the management, support, execution, and

evaluation processes required to provide a stable NETOPS infrastructure to support the tactical LWN.

These activity categories represent the best practices of NETOPS capability providers (both Army and

industry). They also provide a general means of categorizing NETOPS capabilities that are not specific to

any technology or organizational structure. The following paragraphs discuss these NETOPS activities.

NETOPS REPORTING

5-37. The corps, division, and numbered Army level organizations are required to provide day-to-day SA

of Army network and system reports in their AOR to the senior tactical commander and the TNOSC.

NETOPS reporting identifies critical network outages, availability, integrity, and confidentiality of the

LWN.

5-38. The A-GNOSC will publish Army NETOPS reporting requirement in an OPORD. Army NETOPS

OPORD 05-01, dated 20 April 2005, delineates NETOPS reporting threshold guidelines for post, camp, and

station service providers (tactical and strategic); TNOSCs; and the A-GNOSC. The thresholds identified are

considered baseline criteria only; service providers or unit commanders may modify the baseline to allow

for more stringent reporting criteria as deemed necessary.

Reporting Joint Implications

5-39. When the numbered Army is not acting as the joint operational area ARFOR, the ARFOR has a dual

NETOPS reporting requirement to its joint command and to its local numbered Army. NETOPS reporting

responsibilities to a joint command are determined by the joint community (reference JP 6-0). NETOPS

reporting responsibilities between the ARFOR and the numbered Army should be performed according to

the guidelines listed above.

NETOPS SHARED SA PICTURE

5-40. The requirement for NETOPS shared SA was established in the August 2000 Deputy Secretary of

Defense-DOD CIO Guidance and Policy Memorandum No. 10-8460 Network Operations, which mandated

a network common operating picture (NETOPS shared SA). Detailed descriptions of the execution of this

requirement are found in the current joint NETOPS concept of operations (CONOPS), which directs a

shared, single integrated network SA view for the GIG and, specifically, for the Army. The Army NETOPS

CONOPS further directs a NETOPS shared SA that will display relevant NETOPS information to Army

commanders to assist in identifying

―...outages and degradations, network attacks, mission impacts,

communications system shortfalls, operational requirements, and problem resolutions at the strategic,

5-6

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

operational, and tactical levels.‖ This integrated, near-real-time picture tracks critical systems and

designated high priority applications via views that are relevant to the specific information consumer (e.g.,

A-GNOSC, CCDR, numbered Army, TNOSC, corps, and division).

5-41. The NETOPS shared SA activity involves the collection of data from various LWN sources. These

sources provide OPORD 05-01 defined reportable situations (outages, hazardous conditions information

records, aggregated near real-time network event data from multiple network management toolsets, and data

from other NETOPS shared SA systems). The collected data is then transformed into relevant information

for a specific consumer or set of consumers and published as a view. Each consumer requesting a NETOPS

shared SA view has the ability to customize the presented information to make it relevant to their situational

requirements. In this manner it is envisioned that this common source of theater NETOPS shared SA

information will allow any user on the network to pull only what is needed at the time. Figure 5-1 provides a

high-level overview of the current NETOPS shared SA architecture developed and shared by the

AGNOSC/TNOSC.

TNC

A-GNOSC

Army

NETOPS Shared

Theater

NETOPS Shared

JTF-GNO

Infostructure

Regional

Infostructure

NETOPS Shared

Monitoring

Performance Data

TNOSC

RCIO

Installation

Oerational Environment

NETOPS Shared

Installation

Operational Environment

Figure 5-1. NETOPS shared SA system overview

Shared SA Echelons and Organizations

5-42. The BCT is responsible for ensuring the relevant systems within its AOR are equipped and

configured to report OPORD 05-01 required NETOPS shared SA data to the TNOSC. A BCT may be a

consumer of NETOPS shared SA information, but the NETOPS shared SA view would be provided by the

TNOSC.

5-43. The corps and division is responsible for ensuring the relevant systems within its AOR are equipped

and configured to report OPORD 05-01 required NETOPS shared SA data to the TNOSC. A corps and

division may be a consumer of NETOPS shared SA information, but the NETOPS shared SA view would

be provided by the TNOSC. The larger a corps or division’s AOR, the more likely it would be a NETOPS

shared SA consumer.

19 November 2008

FM 6-02.71

5-7

FOR OFFICIAL USE ONLY

Chapter 5

5-44. The numbered Army is responsible for ensuring the relevant systems within its AOR are equipped

and configured to report OPORD 05-01 required NETOPS shared SA data to the TNOSC. The TNOSC

will aggregate the data for the entire theater AOR and transform the data into presentable NETOPS shared

SA information. The TNOSC then publishes a NETOPS shared SA view for consumer organizations. The

TNOSC also reports aggregated NETOPS shared SA data for the theater to the A-GNOSC.

5-45. It is within the TNOSC’s purview to provide a NETOPS shared SA to any eligible consumer that

makes the request. In this respect, the TNOSC is the sole provider of the theater NETOPS shared SA.

NETOPS shared SA support for the theater will come from the TNOSC due to the centralization of

NETOPS shared SA activities at the TNOSC.

Shared SA Joint Implications

5-46. Upon request, the TNOSC will provide a NETOPS shared SA picture to ARFOR NOSCs, joint force

land component commanders (JFLCCs), JTFs, JNCCs, theater NETOPS centers, and TNCCs. It is

important to note that the deployed joint and Army communities will have different focuses and be

interested in tracking different information. For example, while the Army is interested in the overall health

of its NETOPS capabilities, the joint community will be focused on the warfighting situation. NETOPS

shared SA will be essential to the JTF’s ability to quickly assess and react to capability degradations that

potentially impact its warfighting ability.

NETOPS CHANGE MANAGEMENT

5-47. The goal of change management is to ensure that standardized methods and procedures are used for

efficient and prompt handling of all modifications. This will help facilitate necessary changes and minimize

the negative impacts of change-related events. The process encompasses the identification, documentation,

approval, and implementation of variances from configuration baselines requirements.

5-48. Change management activities concerning user systems and NETOPS capabilities are generally

performed by the unit’s S-6, G-6, and J-6. Some of the activities concerning the network and basic network

capabilities are provided by the supporting signal unit such as the division, brigade, and BCT signal

company, the TLTs (BCT, corps, and division), or the ITSB ESB and TNT (numbered Army, ARFOR, and

above).

5-49. The change management process is initiated by a request for change. A request for change may

originate from any organization within the tactical chain of command, as well as the A-GNOSC or

numbered Army. Requests for changes may be initiated as a resolution to an incident or problem, to request

temporary exceptions to policies, or to support other emerging mission requirements.

5-50. Once a request for change is submitted, it enters the change processing state and is sent up through

the tactical chain of command until it reaches the appropriate echelon to approve the change. As the change

request is forwarded, it must pass through each intermediate echelon of tactical command. This ensures that

the chain of command is aware of all requests and that approved changes are implemented in an orderly

manner. At each echelon, the change must be examined by plans and engineering personnel. The reviewing

stage is necessary to ensure that the change is feasible, justified, and does not violate network, system, or

security policy guidance.

5-51. Change approval authority is based upon operational management responsibilities as defined in the

NETOPS Operational Control and Management section later in this chapter. If an echelon has operational

management of a particular system, it also has the authority to approve changes to that system, as long as

these changes do not violate policy or guidance. If the request for change violates current policies or

guidance, the change request must be processed as a temporary exception to policy (refer to the Temporary

Exceptions to NETOPS Policies and Standards Section earlier in this chapter).

5-52. The unit commander will generally delegate the authority to approve or deny network change

requests to the S-6, G-6, and J-6 command staff. This authority may be institutionalized or delegated to

5-8

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

technical network personnel within the unit. Qualified personnel include members of a signal company,

ITSB/ESB, or supporting TLT.

5-53. After the echelon with the necessary authority has approved the change, the validated change request

will pass to the echelon(s) with change implementation responsibility for the system(s) affected. This

echelon will then coordinate the change with all necessary organizations before execution. An organization

requires prior change coordination if the change may result in failure or the compromise of services within

the organization’s AOR.

5-54. Changes may also be initiated by high level echelons such as the CCDR or A2TOC. For example, a

system may urgently require a patch based upon a newly identified vulnerability. Change requests

originating at the CCDR are not required to go through the change approval process, but coordination with

the ARFOR and affected tactical units is necessary to determine when and how the change should be

implemented. Change requests originating from the A2TOC must be passed via the numbered Army to the

ARFOR for approval. If the ARFOR determines that a change originating from the CCDR or A2TOC will

have an unacceptable risk of disrupting user services, it can request to delay or defer the change through its

chain of command.

5-55. Change implementation should always be performed by the echelon with operational management of

the system in question. The NETOPS Operational Change and Management section in this chapter contains

a general definition and delineation of operational management. In the tactical networking environment,

situations will commonly arise that require immediate action to be taken. In these emergency situations,

personnel may need to perform change implementation activities that are outside of their normal scope of

responsibility.

5-56. Changes made to user systems, NETOPS capabilities, and network capabilities often involve

configuration changes. These changes include updates to software, modifications to configuration

parameters, and the replacement of hardware. Changes that are made within the network are recorded as

they occur in an automated CM system. This system will provide notification to the appropriate

organizations regarding any configuration modifications resulting from change requests. All units, BCT and

above within the tactical network chain of command will have access to this system. Army organizations

such as the numbered Army and A-GNOSC will also receive notification of configuration changes in order

to maintain Army-based awareness across the enterprise.

Note. Change and CM are integrated activities. Specifically, changes to a configuration must be

recorded through the CM activity. Appendix C contains scenarios that serve as examples of how

change and CM occur.

Change Management Echelons and Organizations

5-57. NETOPS change management operations for assets within the BCT AOR are performed by the BCT

S-6, supported by the BCT signal company, and assigned or attached signal personnel. At the BCT and

below, each change request is approved, denied, or escalated to the next higher headquarters for further

processing. The BCT performs change implementation on all systems for which it has operational

management responsibility as defined in the Operational Control and Management Section of this chapter.

5-58. NETOPS change management operations for assets within the corps and division AOR are performed

by the corps and division G-6, supported by the corps and division signal company, supporting TLT, and

assigned or attached signal personnel. Each change request is approved, denied, or escalated to the next

higher headquarters for further processing. The corps and division perform change implementation on all

systems for which it has operational management responsibility as defined in the Operational Control and

Management section of this chapter.

5-59. The ITSB/ESB performs designated change management functions in support of the echelon to which

it is currently assigned. It will process and initiate change requests regarding the active NETOPS

19 November 2008

FM 6-02.71

5-9

FOR OFFICIAL USE ONLY

Chapter 5

capabilities it provides. The ITSB/ESB may also be delegated the authority to approve certain change

requests from the supported S-6, G-6, or J-6.

5-60. The numbered Army and A-GNOSC perform all change management functions listed above for the

support Services which are provided to the tactical forces via the TNOSC and A-GNOSC. The numbered

Army or A-GNOSC receives and approves change requests regarding Army supporting services through the

chain of command. The implementation of this change must be coordinated through all affected

organizations as defined in the change implementation process. For example, a BCT under the OPCON of a

corps or division may directly request a change to TNOSC support services through its corps or division.

Change Management Joint Implications

5-61. Joint guidance governs change management operations within joint organizations or between Army

and joint organizations. Army personnel supporting these functions will operate within joint guidance while

also utilizing Army change management procedures.

5-62. NETOPS change management operations for assets within the ARFOR AOR are performed by the

ARFOR G-6, supporting ITSB/ESBs, and assigned or attached signal personnel. At the ARFOR, each

change request is approved, denied, or escalated to the next higher headquarters J-6 for further processing.

The JFLCC and commander, joint task force (CJTF) perform change approval activities for all joint-

managed systems that require approval above the corps and division level. The ARFOR performs change

implementation on all systems for which it has operational management responsibility as defined in the

Operational Control and Management section of this chapter. The ARFOR, JFLCC, and CJTF will also be

fully involved in the change notification process for all assets within their respective AORs.

NETOPS CONFIGURATION MANAGEMENT

5-63. NETOPS CM supports the identification, control, maintenance, and verification of systems and

devices associated with the provisioning of NETOPS capabilities. Configuration item (CI) information

includes hardware, software, device configurations, and version information. Activities associated with CM

include:

Identification of all CIs.

Control of CIs.

Maintenance of current and past CI status.

Verification of CI status.

5-64. Policy dictates what qualifies as a CI and what information regarding each CI must be collected and

stored. Policy also dictates how often CI information must be updated based upon mission factors including

operational tempo and bandwidth constraints.

5-65. CM concerning user systems and capabilities are primarily performed by the unit’s S-6, G-6, and J-6

staff. CM activities concerning the network and basic network capabilities are delegated to a supporting

signal unit such as the signal company or the ITSB/ESB.

Configuration Management Echelons and Organizations

5-66. It is the responsibility of each echelon to ensure that all subordinate assets within its AOR perform

the necessary CM activities. Each echelon in the tactical chain of command will ensure that CIs within

subordinate echelons are accurately reflected within the CI database. To facilitate this process, read-only

access of all network resources will be shared between designated network management personnel within

each echelon.

5-67. An authoritative theater Army CI database (in support of the global Army CI database) will be

maintained in a distributed fashion by the numbered Army TNOSCs.

5-68. For the BCT and below, CM operations are performed by the S-6 personnel, the signal company,

supporting ITSB/ESBs, and supporting signal organizations. During the operational phases, all personnel

5-10

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

supporting NETOPS functions are required to ensure that CIs under their operational management are

accurately identified and maintained within the CI database. When the BCT is task organized under a

particular corps, division, or ARFOR, the BCT CI information is made available to the joint operational

area chain of command and the gaining numbered Army. The BCT and below is also responsible for

ensuring that all changes to systems under the operational control and management of the BCT are

accurately reflected within the CI database.

5-69. Within the corps and division, CM operations will be performed by G-6 personnel, the signal

company, supporting ITSB/ESBs, the TIC, and supporting signal organizations. During the operational

phases, all personnel supporting NETOPS functions are required to ensure that CIs under their operational

management are accurately identified and maintained within the CI database. This information can then be

made available to the joint operations area ARFOR and the numbered Army as the corps or division

deploys. The corps, division, and subordinate units are also responsible for ensuring that all changes to

systems under their operational control and management are accurately reflected within the CI database.

5-70. Tactical CM operations are also performed by the ITSB/ESB on behalf of the supported tactical

organizations. ITSB/ESBs will ensure that CIs under their operational management and those of their

supported organization are identified and maintained accurately within the CI database throughout all

operational phases. This information can then be passed from the owning numbered Army to various

tactical echelons as the ITSB/ESB is task reorganized.

5-71. For the numbered Army’s tactical support services, CM operations will be performed by the SC(T)

and TNOSC. All personnel supporting NETOPS functions are required to ensure that CIs under their

control are identified and maintained accurately within the CI database throughout all operational phases.

The numbered Army is also responsible for ensuring that all changes to systems under the operational

control and management of the numbered Army are accurately reflected within the CI database.

5-72. It is important to remember that one echelon may be responsible for a physical CI but not the CI’s

device configuration. For example, the BCT is responsible for ensuring that all its routers are entered or

removed from the CI database. The BCT’s higher headquarters, as the echelon with operational

management of the BCT routers, is responsible for maintaining the status of router configurations within the

CI database.

Configuration Management Joint Implications

5-73. The ARFOR, JFLCC, and CJTF CM operations are governed by joint guidance. Army personnel

supporting these organizations will operate within this guidance while also utilizing Army CM procedures

to the fullest possible extent. Army assets within these organizations will utilize the Army-provided CI

database unless otherwise directed. Joint organizations will have the ability to view information from this

database as required.

5-74. CM functions within the ARFOR, JFLCC, and CJTF are anticipated to be performed by the G-6, J-6,

TNT, the supporting ITSB/ESB, and supporting signal organization. During the operational phases, all

personnel supporting Army-based NETOPS functions should ensure that CIs under their operational

management are accurately identified and maintained within the CI database. The ARFOR is also

responsible for ensuring that all NETOPS changes to systems under the operational management of the

ARFOR or subordinate Army elements are accurately reflected within the CI database.

NETOPS INCIDENT AND PROBLEM MANAGEMENT

5-75. The incident and problem management process involves the processing and resolution of any event

that is not part of the standard operation of a NETOPS capability, and that causes or may cause an

interruption to or a reduction in the quality of that capability.

5-76. The goal of the incident and problem management process is to restore normal operation of the

capability as quickly as possible, and minimize the adverse impact on tactical operations, therefore ensuring

that the best possible levels of capability quality, availability, and security are maintained.

19 November 2008

FM 6-02.71

5-11

FOR OFFICIAL USE ONLY

Chapter 5

5-77. Management of network related incidents and problems concerning user systems and capabilities are

the responsibility of the unit S-6, G-6, and J-6 staff. Incidents and problems concerning the network and

basic network capabilities may be delegated to a supporting signal unit such as the signal company, TLT

(BCT, corps, and division), or the ITSB/ESB and TNT (numbered Army or ARFOR).

Note. Appendix C outlines a scenario that serves as an example of how the incident and problem

management activity might occur.

Incident and Problem Management Echelons and Organizations

5-78. For the BCT and below, incident and problem management operations are performed by the S-6,

signal company, supporting ITSB/ESBs, and supporting signal organization. When an incident is identified

within the BCT, it is first analyzed within the BCT to identify if an immediate resolution can be found. In

the echelons BCT and below, the ability to locally analyze incidents is very limited. If a solution cannot be

locally identified, the problem escalates to the next higher headquarters.

5-79. Within the corps and division, incident and problem management operations are performed by the G-

6, signal company, supporting ITSB/ESB, TLT, and supporting signal organization. When an incident is

identified within or escalates to the corps or division from a subordinate organization, it is first analyzed

within the corps or division to identify if an immediate resolution can be found. If a solution cannot be

locally identified, the problem escalates to the next higher headquarters within the tactical chain of

command.

5-80. The ITSB/ESB personnel perform incident and problem functions for network capabilities and

infrastructure provided by the ITSB/ESB. When an incident or problem is identified, it is first analyzed by

ITSB/ESB NETOPS personnel to identify if an immediate resolution can be found. If a solution cannot be

locally identified, the problem escalates to the supporting tactical echelon.

5-81. The numbered Army performs incident and problem management activities for all NETOPS

capabilities provided by the numbered Army. If a tactical incident or problem cannot be resolved through

local numbered Army resources, the numbered Army may escalate the problem to the A-GNOSC, material

developer, or vendor subject matter experts.

5-82. The ultimate responsibility for tactical incident and problem management resides within the

operational chain of command. Army organizations such as the TNOSC and the A-GNOSC play an

important supporting role in this process. The deployment support division, within the TNOSC, supports

tactical troubleshooting functions by leveraging a database of problems, incidents, and fixed-station subject

matter experts. Tactical Army organizations may request support from the TNOSC or A-GNOSC through

the chain of command.

Incident and Problem Management Joint Implications

5-83. Within the ARFOR, incident and problem management operations will be performed by the G-6,

supporting ITSB/ESB, TNT, and supporting signal organization. When an incident is identified within or

escalates to the ARFOR via a subordinate organization, it is first analyzed to identify if an immediate

resolution can be found. The ARFOR will normally be supplemented by a numbered Army TNT in order to

augment its ability to analyze incidents and problems. If a solution cannot be locally identified, the problem

then escalates to the numbered Army TNOSC or the joint NETOPS cell within the JFLCC or CJTF.

5-84. The ARFOR will generally request assistance from the numbered Army’s TNOSC to resolve

problems related to Army-specific systems and procedures. Problems related to systems and procedures

directly managed by the operational environment joint command will generally escalate to the joint NOSC.

These problems can also be referred to the TNOSC at the discretion of the ARFOR. Regardless of

escalation sequence, both the TNOSC and the combat chain of command will be notified of all incidents

and problems as they occur.

5-12

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

5-85. The ARFOR, JFLCC, and CJTF incident and problem management operations are governed by joint

guidance. Army personnel supporting these organizations will operate within this guidance while also

participating in Army incident and problem management procedures to the fullest extent.

NETOPS RELEASE MANAGEMENT

5-86. Release management deals with the planning, design, construction, configuration, and testing of

hardware and software to create a set of release components for a live environment. Release management

activities also cover the planning, preparation, and scheduling of a release to various subscribers and

locations.

5-87. The initiation, planning, and testing of releases are primarily performed in the fixed-station, non-

tactical environment. It is critical that release building and testing are performed with the tactical

environment in mind. This section provides details regarding those activities which are specific to the

tactical echelons: release rollout planning, installation, and training.

5-88. The activities associated with release rollout planning are executed according to the change

management and planning processes. When a release is issued, it is initiated as a change request. This

request is then coordinated and planned through the tactical chain of command and all affected

organizations.

5-89. The activities associated with release installation are executed according to change management

guidelines. The echelon responsible for change management of the effected system(s) will execute the

release.

NETOPS SERVICE DESK MANAGEMENT

5-90. Tactical service desk management encompasses all activities involved with tracking NETOPS

activities, gathering NETOPS status or performance information, and interfacing with the tactical

subscriber. This includes incident and problem processing, change request processing, availability

management, user interaction, and collection of user satisfaction data. These activities are often associated

with a user help desk.

5-91. Service desk management functions concerning user systems and NETOPS capabilities are the

responsibility of the unit’s S-6, G-6, and J-6 staff and functional areas. Service desk management functions

are assigned, as necessary, by the S-6, G-6, and J-6 to a supporting signal unit such as the signal company

or the ITSB/ESB.

Service Desk Management Echelons and Organizations

5-92. At the BCT and below, service desk management functions are performed in support of local

subscribers. The service desk management information is collected, analyzed, and made available to the

G-6 or J-6 within the next higher echelon.

5-93. Within the corps and division, service desk management functions are performed in support of local

subscribers. The service desk management information is collected, analyzed, and made available to the

G-6 or J-6 of the next higher commanding echelon.

5-94. Personnel performing service desk management functions within the corps, division, and below are

likely to be network design, engineering, or incident management personnel with additional service desk

management duties. In the upper echelons such as the ARFOR, numbered Army, and joint commands,

service desk management functions will often be performed by dedicated personnel from a service

management desk or help desk.

5-95. The ITSB/ESB will perform service desk management functions for the NETOPS infrastructure and

all related capabilities provided by the ITSB/ESB. This information will be made available to the supported

echelon and the local numbered Army.

19 November 2008

FM 6-02.71

5-13

FOR OFFICIAL USE ONLY

Chapter 5

5-96. The numbered Army will perform service desk management functions for all tactical support services

provided by the SC(T) or TNOSC. This information will be made available to tactical Army units and the

JTF.

Service Desk Management Joint Implications

5-97. Within the ARFOR, service desk management operations will be performed by the G-6, supporting

ITSB/ESB, TNOSC TNT, and supporting signal organizations.

5-98. The JFLCC and CJTF service desk management operations are governed by joint guidance. Army

personnel supporting these organizations will operate within this guidance while also performing Army

service desk management procedures.

NETOPS INFRASTRUCTURE MONITORING/MANAGEMENT

5-99. NETOPS infrastructure monitoring is the monitoring of all IT components that are providing

NETOPS-related capabilities to the Soldier. Monitoring is focused on the health of NETOPS capabilities.

Some of these components include radios, multiplexers, cryptographic devices, routers, switches, firewalls,

IDSs, enabling protocols, capability providing hosts, and critical applications.

5-100. NETOPS infrastructure monitoring is performed continuously throughout all phases of operations.

It supports and enables other NETOPS operational activities such as NETOPS shared SA, service desk

management, and incident and problem management.

5-101. Due to the complex nature of the Army’s modular infrastructure, which consists of multiple Army

NETOPS provisioning organizations, the monitoring of Army infrastructure components will be distributed

among those organizations. Critical information collected by distributed NETOPS monitoring systems will

be forwarded to a higher level NETOPS monitoring system. The concept of distributed monitoring is

facilitated through the establishment of distinct monitoring domains, which are purposely aligned with the

Army theaters’ NETOPS provisioning organizations. The ARFOR, numbered Army, corps, division, BCT,

and battalion organizations monitor their own domain as established in the NETOPS mission plan.

5-102. Each organization’s monitoring domain consists of both the IT components within their AOR and

the distant end of the WAN links to directly higher and directly subordinate organizations. For example, a

corps or division monitoring domain would consist of all the IT components within its AOR as well as the

distant ends of WAN links to the ARFOR (higher organization), adjacent units, ITSB/ESBs, and its BCTs

(subordinate organization). In most situations, there will be line of sight and other WAN connections within

an organization’s monitoring domain that provide connectivity to distant entities of that organization. In this

situation, all the IT components on the distant end of a particular WAN link are still under the monitoring

responsibility of that organization.

5-103. In a dynamic combat scenario, there may be ad hoc Army, joint, coalition, or civilian assets

attached to a BCT, corps, division, or ARFOR AOR. When this occurs, monitoring functions for these

attached assets are the responsibility of the supported command. If the attached asset has the capability to

perform independent monitoring activities, such as an ITSB/ESB or Marine expeditionary force, this asset

would simply forward the monitoring data to the supported command. If not, the supported command would

assume active, real-time monitoring of the attached asset.

5-104. Tactical units also require limited visibility of adjacent and higher networks for SA and

troubleshooting purposes. A high-level view of the network as a whole can be obtained via remote network

views provided by higher headquarters. For example, if a BCT needs to identify why communications to a

remote ITSB/ESB are not functioning, it could access the Web view of the theater AOR which is available

as a service via the TIC of the numbered Army’s supporting TNOSC. Figure 5-2 illustrates the concept of

distributed monitoring and the flow of the monitoring information.

5-14

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

Infrastructure Monitoring/Management Echelons and Organizations

5-105. For the BCT and battalion, infrastructure monitoring activities are performed by the S-6, signal

company, supporting ITSB/ESBs, and other supporting signal organizations. These organizations will use

their NETOPS monitoring system to monitor, manage, and troubleshoot the network infrastructure within

their AOR. The battalion will provide all monitoring information from its AOR to the BCT. This

information will consist of network topology, as well as event and alarm data. This provides the BCT with a

read-only view of the battalion’s infrastructure that will facilitate troubleshooting and analysis activities.

Figure 5-2. Distributed infrastructure monitoring example

5-106. The BCT will provide all monitoring information from its AOR and its subordinate battalion's

AORs to the corps and division’s NETOPS monitoring system. This information will consist of network

topology and event and alarm data. This will provide the corps and division with a read-only view of the

BCT’s and battalion’s infrastructure. The information received will facilitate troubleshooting and analysis

activities.

19 November 2008

FM 6-02.71

5-15

FOR OFFICIAL USE ONLY

Chapter 5

5-107. Within the corps and division, infrastructure monitoring is performed by the G-6, signal company,

supporting ITSB/ESB, TLT, and supporting signal organizations. The corps and division will use their

NETOPS monitoring system to monitor, manage, and troubleshoot the network infrastructure within their

AOR. The corps and division will provide all monitoring information from their AOR and subordinate

BCT’s, and battalion’s AORs to the ARFOR NETOPS monitoring system. This information will consist of

network topology and event and alarm data that will provide the ARFOR with a read-only view of the

corps’, division’s, BCT’s, and battalion’s infrastructure, thereby facilitating troubleshooting and analysis

activities. The corps and division is also responsible for making consolidated AOR monitoring information

accessible to subordinate assets for SA and troubleshooting purposes.

5-108. The numbered Army will use its NETOPS monitoring system to monitor, manage, and troubleshoot

the network infrastructure within its AOR. In addition to supporting these activities, the numbered Army’s

NETOPS monitoring system will be used to assist in the troubleshooting activities within the combat AOR,

as required (see below for incident and problem management). The numbered Army is also responsible for

making consolidated Army theater monitoring information accessible to the CCDR, A-GNOSC, and tactical

Army assets within the theater for SA and troubleshooting purposes.

Infrastructure Monitoring/Management Joint Implications

5-109. The ARFOR is responsible for the management of the NETOPS capabilities and infrastructure

within its AOR. Within the ARFOR, infrastructure monitoring and management activities will be performed

by the G-6, supporting ITSB/ESB, TNT, and supporting signal organizations. The ARFOR conducts this

mission through the monitoring and management activities conducted by subordinate ITSB/ESBs, corps,

divisions, BCTs, and any other monitoring domains within the Army combat AOR. The ARFOR will

provide all monitoring and management information from the Army combat AOR to the numbered Army’s

NETOPS monitoring system, which will consist of network topology and event and alarm data from its

subordinate organizations. The ARFOR is also responsible for making consolidated AOR monitoring and

management information accessible to subordinate assets for SA and troubleshooting purposes. For more

information regarding troubleshooting and trouble ticketing, see Appendix C.

5-110. According to joint guidance, the CJTF and JFLCC will direct NETOPS monitoring and

management within their respective AORs. Army assets supporting joint commands will perform

monitoring and management functions according to the processes listed above, unless these processes

conflict with joint guidance. Any conflict between joint guidance and army requirements will be adjudicated

by the Army G-6.

NETOPS OPERATIONAL CONTROL AND MANAGEMENT

5-111. There are two distinct and complementary NETOPS activities discussed in this section: operational

control and operational management. Operational control of a NETOPS system, capability, or component

involves the day-to-day activities involved in keeping the system, capability, or component running. Some

of these activities include providing power, environmental controls, cleaning, preventative maintenance,

installation, deinstallation, physical inventory, and touch labor. Operational management activities include

configuration, reconfiguration, monitoring, patching, and upgrading. Some of the devices include

computing platforms, routers, switches, multiplexers, uninterruptible power sources, encryption devices,

and IDSs.

5-112. Operational control and management responsibilities are determined by global policy and the

network topology. Even though the transmission system is relatively flat, the interconnection of IP networks

is organized in a hierarchy. The demarcation points between the tiers (refer to Appendix I for tier detailed

information) of the hierarchy in conjunction with tactical unit boundaries are natural borders for OPCON

and management. Operational control of NETOPS capabilities, systems, and components is the

responsibility of the unit that has physical control of the item. Operational management of NETOPS

capabilities, systems, and components falls into the following three categories:

Unit managed component systems. The operational management of a component or system, not

capable of being remotely managed, falls to the echelon that physically controls the component

5-16

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

or system. One example of such a system is the squad level radio. Although all components and

systems require a certain amount of touch labor, many components or systems may be under the

operational management of a remote echelon. A limited set of touch labor functions such as

installation, disaster recovery, troubleshooting, and deinstallation may be performed by local

personnel under the direction of an echelon with remote operational management responsibility.

Echelons above corps and division capabilities. Some systems are managed and operated as a

capability by echelons above the corps or division. These systems may be more efficiently

provisioned from a higher echelon, or may require centralized management. These systems are

designed and implemented to provide flexible capabilities and do not require frequent

reconfiguration in response to tactical mission requirements. Some examples of echelons above

corps capabilities include the Army DNS system and the joint router network. Operational

management of these systems resides at the echelon which provides the supporting capability.

Echelon above brigade managed systems. The remaining NETOPS capabilities, systems, or

components are both remotely manageable and require a distributed management structure to

ensure that configurations are dynamically aligned with command requirements. Operational

management of these systems within the corps or division and below falls to the tactical echelon

directly above the brigade. In most cases, this will be a division. In some scenarios, the echelon

above brigade may be a corps, numbered Army, ARFOR, or a joint command. The corps and

division are augmented by the TIC to perform these functions. The ARFOR or joint command is

augmented by a TNT to perform the same functions. Operational management of these types of

systems within the echelons above corps generally falls to the supported echelons above corps

command. For example, all remotely manageable systems within an ITSB/ESB-supported

ARFOR TOC, as well as the ITSB/ESB itself, fall under the operational management of the

ARFOR command. The only exception to this rule is when the SB(T) itself is operationally

controlled to echelons above corps command in order to provide an additional span of control for

echelons above corps networks. When this occurs, the signal brigade

(theater) assumes

operational management of the supported command’s ITSB/ESB systems. Some examples of

echelon above brigade managed systems could be called managers, VOIP gateways, private

branch exchanges, routers, firewalls, collaboration tools, and unit directory services.

Note. Any echelon with operational management may delegate this responsibility to subordinate

echelons or organizations as needed.

Operational Control and Management Echelons and Organizations

5-113. Operational control and management are executed at all echelons. The component types in the

NETOPS infrastructure are the same regardless of whether they are located in a numbered Army, corps,

division, BCT, or battalion. These include, but are not limited to, routers, data switches, voice switches,

private branch exchanges, multiplexers, satellite terminals, line of sight transmission equipment, and

computing platforms. Location and ownership of a NETOPS capability, system, or component will often

affect which echelon or organization has operational control. For example, a unit-managed radio within the

corps or division signal company is operated and managed by the corps or division, whereas the same type

of radio within a brigade signal company is managed by the brigade.

5-114. The numbered Army is responsible for the operation and management of capabilities, systems, and

components for its entire AOR. The TNOSC OPCON to the numbered Army executes OPCON and

management in support of the G-6 and SC(T). In addition to managing and operating capabilities, systems,

and components to conduct business on its portion of the NETOPS infrastructure, it has the responsibility to

operate and manage support services for the tactical AOR. Some of these capabilities include Army DNS,

IDSs, and Tier-1 routing domains. See Appendix I paragraph I-41 for an explanation of Tier 0, Tier 1, and

Tier 2.

5-115. The deployment of an IDS to an organization is a good example to illustrate the operation and

management responsibilities of several devices within multiple organizations. For this example, assume that

19 November 2008

FM 6-02.71

5-17

FOR OFFICIAL USE ONLY

Chapter 5

a pre-configured IDS is shipped to an organization. The receiving organization installs the IDS and

connects it to the IP network (operational activity). A precoordinated IP address was configured on the IDS,

which is immediately active on the LAN. Some of the activities that the local organization may have to

perform to provide end-to-end connectivity is to create a reservation in their Dynamic Host Configuration

Protocol (DHCP) server (manage DHCP activity) and reconfigure the local firewall(s) to permit the

protocols and IP address of the IDS (manage firewall activity). The TNOSC will have to reconfigure their

firewall(s) and reconfigure their IDS management station to complete the deployment. There are a number

of operational and management activities on several devices in the respective organizations to successfully

deploy the IDS capability. The receiving organization could be a corps, division, brigade, BCT, or a

battalion.

Operational Control and Management Joint Implications

5-116. The ARFOR delegates responsibility for the operation and management of capabilities, systems, or

components within its AOR to the corps, division, and directly reporting BCTs as appropriate.

5-117. The numbered Army will perform OPCON and management of Army Service components

operationally controlled to the JTF in support of the joint mission. The TNOSC OPCON to the numbered

Army executes OPCON and management in support of the G-6 and SC(T). The CJTF and JFLCC will

orchestrate and coordinate the operation and management of NETOPS capabilities, systems, and

components.

NETOPS NETWORK DEFENSE MANAGEMENT

5-118. The management of security is integral to and included in each of the NETOPS activities described

in this chapter. This section is focused on security-specific activities that support the other NETOPS

activities described throughout the chapter.

5-119. NETOPS security management includes the defensive components of IO that serve to protect and

defend information and information systems by ensuring their availability, integrity, authentication,

confidentiality, and non-repudiation. The provisioning of many IA capabilities is implemented as Army

enterprise capabilities. For example, Microsoft Windows AD is expected to provide enterprise-wide

identification and authentication for Windows platforms.

5-120. Fundamental to the provisioning of the defensive components of NETOPS is the concept of DID.

DID identifies three network-accessible areas that require defensive measures:

Perimeter defense includes protections for both public and extranet access. Extranet access

includes those ports and protocols that are external to and specifically identified by the tactical

unit. Extranet A private network that uses IPs and the public telecommunications system to

securely share information among selected external users. An Extranet requires the use of

firewalls, authentication, encryption, and VPNs that tunnel through the public network (see AR

25-2).

Enclaves are usually contiguous networks that support a specific geographical location,

organization, or unit.

Hosts are the final layer of defense. Protection at this layer consists of host-based configuration

parameters and host-based intrusion detection and prevention software.

5-121. To support these defensive components, security information management tools are employed to

support security event collection, data reduction, and correlation.

Security Management Echelons and Organizations

5-122. NETOPS security management is centralized to the greatest extent possible. Centralization ensures

consistency and minimizes the number of personnel with the highly specialized skills needed to perform

NETOPS security analysis. For NETOPS security management to be effective, it must be performed in near

real time. This includes the ability for near real-time 24 hours a day, seven days a week operational control

5-18

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

and management of NETOPS security components and sensors. Security information management tools

may be employed by the TNOSC in support of tactical organizations to efficiently aggregate and analyze

NETOPS security event information.

5-123. Centralized management of NETOPS security perimeter protection components and sensors is

performed by the TNOSCs within each theater. The operational tempo may require support from the

TNOSC deployment support division to ensure that the commander’s needs are met with respect to

NETOPS security for deployed forces.

5-124. The TNOSC also manages NETOPS security enclave protection components and sensors. At the

discretion of the chain of command, this responsibility may be delegated to the corps, division, or BCT

level organizations. Enclave protection will also be performed at the corps, division, or BCT level if

connectivity to the TNOSC is interrupted.

5-125. Local commanders at all levels have responsibility for host protection. ITSB/ESB and signal

company personnel will provide assistance to local commanders as requested or directed.

Security Management Joint Implications

5-126. ARFOR, JFLCC, and CJTF NETOPS security management operations are governed by joint

guidance. Army personnel supporting these organizations will operate within this guidance while also

participating in Army security management procedures to the fullest possible extent.

5-127. Within the ARFOR, JFLCC, and CJTF, NETOPS security management operations are performed

by the G-6, supporting ITSB/ESB, TNT, and the supporting signal organization. When a potential security

incident is identified within or escalates to the ARFOR via a subordinate organization, its potential local

impact is determined and it is escalated to both the appropriate NETOPS cell within the JFLCC or CJTF

and the TNOSC. Appropriate responses or defensive measures are then directed via the chain of command.

INTERRELATIONSHIP OF NETOPS ACTIVITIES

5-128. It is important to note that the successful execution of the identified NETOPS activities requires a

high degree of coordination and cooperation within and between responsible organizations at all echelons.

The NETOPS activities described in this chapter are interrelated and dependent upon one another. For

example, the incident and problem management activity relies upon the change management activity in

order to implement corrective actions. This activity also relies on the infrastructure monitoring activity in

order to detect anomalies. Appendix C provides more examples of the interrelationships between NETOPS

activities and the organizations that carry them out. Figure 5-3 depicts the most common interrelationships

that exist between the NETOPS activities.

NETWORK OPERATIONS EVALUATION CAPABILITIES

5-129. Within the operational environment, NETOPS capabilities must be evaluated to ensure that they

are adequately supporting the Soldier. The evaluation activity is focused on the proactive maintenance of

the health and protection of the NETOPS capabilities. Evaluation activities are grouped into two areas: IA

compliance and NETOPS capacity and availability.

5-130. A NETOPS capability itself has requirements that must be met in order for the capability to operate

normally. These requirements are characterized by key parameters that, when evaluated against a threshold,

provide useful information about the health of the capability. For example, a key parameter of a T-1 circuit

is the instantaneous transmission rate. When the instantaneous transmission rate exceeds 1.536 megabits per

second (Mbps), the maximum transmission rate threshold has been exceeded and users of the transmission

system can expect dropped packets and slow application performance (e.g., degraded availability).

19 November 2008

FM 6-02.71

5-19

FOR OFFICIAL USE ONLY

Chapter 5

Network

Infrastructure

Data

Service

Infrastructure

Network

Event

Monitoring

Events

Security

Events

Service Desk

Security

Incident/Problem

Management

Request

for

Request

for

Change

for

Hardware/

Change

Software

Releases

Infrastructure

Change

Status

Management

Status of

Change Plan

Service

Configuration

Incident

Management

Reports

Incident

Reports

Release Planning

Information

Release

Management

NETOPS Shared

Figure 5-3. NETOPS operational activities process flowchart

5-131. NETOPS capability evaluation provides the information needed to identify degraded availability,

capacity shortfalls, and IA compliance deficiencies. The result of the evaluation activities is information

required for NETOPS capability planners, IA analysts, and engineers to apply remediation or isolation

actions, reallocate resources, and identify upgrades to NETOPS capabilities supporting the Soldier.

5-20

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

5-132. The evaluation activities presented so far have focused on the health, maintenance, and protection

of the NETOPS capabilities. The evaluation of trends over a long period of time provides information on

the overall health of the NETOPS systems. The evaluation of trends illuminates training deficiencies and

weaknesses in individual components or systems. It also provides valuable information to evaluate the

effectiveness of doctrine, organization, training, materiel, leader education, personnel, and facilities.

IA COMPLIANCE

5-133. IA compliance relates to security management, which specifies the performance of vulnerability

assessments. The evaluation of IA compliance, through CM, is the verification that the activities described

in the Systems Maintenance Section of this chapter have been performed and any deficiencies have been

identified. These assessments will be evaluated to ensure timely and adequate vulnerability remediation.

The evaluation should be scheduled as part of the overall IA security plan.

5-134. A few of the NETOPS capabilities requiring IA compliance are represented by computing

platforms, client applications, server applications, routers, and data switches that provide capabilities to the

Soldier.

IA Compliance Echelons and Organizations

5-135. The A2TOC will provide IAVM messages for distribution to the theater teams, RCIOs, and

DOIMs, and via AKO Knowledge Management bulk mail distribution. The RCIOs and DOIMs will ensure

that corps, division(s), and BCTs comply with the IA updates. Compliance with IAVMSs and IA

vulnerability bulletins must be reported in the Asset and Vulnerability Tracking Resource database. The

updates are pushed to the organization with operational management for action. The corps and division G-6

has SA of echelons in the AOR and determines the appropriate time to apply the IA updates. In some

instances, there are many baselines for a given NETOPS capability or there are too many to be supported by

the numbered Army. In this situation, the tactical operations staff will have to modify, recreate, and test IA

updates for distribution.

5-136. The corps/division G-6 has the responsibility to execute IA compliance IAW the commander’s

intent. The corps and division G-6 will use the appropriate resources (e.g., ITSB/ESB, signal company,

corps and division sanctuary, TIC, and TNT) to accomplish this mission. The organization that executes IA

compliance will be the organization with operational management of the system. The variety and

complexity of the NETOPS capabilities requires specialized groups to operate and maintain the systems.

For instance, the application of an IA package to a telecommunications component is best suited to the

signal company or the ITSB/ESB. The organization that is chosen to perform the activity depends on the

location of the component and which organization has OPCON. In another instance, the corps and division

sanctuary would be the appropriate location to modify and apply a patch for a computing platform. Lastly,

the organization with OPCON or management has the responsibility to provide compliance reports to the

corps and division G-6 via the signal company or the corps and division sanctuary. The numbered Army

will compile the compliance reports from the corps and division G-6.

IA Compliance Joint Implications

5-137. The ARFOR G-6 has the responsibility to execute IA compliance within its AOR IAW the ARFOR

commander’s intent. The ARFOR G-6 will use the appropriate resources (e.g., ITSB/ESBs, TIC, TNT, and

subordinate G-6 or S-6) to accomplish this mission.

5-138. Upon request of the ARFOR, the numbered Army will evaluate IA compliance of Army Service

components operationally controlled to the JTF in support of the CJTF. The CJTF and JFLCC will

orchestrate and coordinate the evaluation of IA compliance of NETOPS capabilities, systems, and

components.

19 November 2008

FM 6-02.71

5-21

FOR OFFICIAL USE ONLY

Chapter 5

NETOPS CAPACITY AND AVAILABILITY

5-139. There is a close correlation between NETOPS infrastructure capacity and availability of NETOPS

capabilities. While the functions are different, the organizational responsibilities are identical. It should be

noted that there is synchronization between the NETOPS capacity and availability and NETOPS

infrastructure monitoring. Infrastructure monitoring is a short-term activity that will feed the long-term

planning activity for such things as reallocation of resources with regards to IT capacity and availability.

5-140. The objectives of NETOPS infrastructure capacity evaluation are effective support to the Soldier

and efficient use of NETOPS capabilities. The NETOPS capacity evaluation results in information to aid

planners in forecasting capability degradation and making recommendations on capability reallocation and

upgrades, and a host of other items to maintain the health and protection of the NETOPS infrastructure.

Capacity evaluation encompasses all networking equipment, computing platforms, peripherals, and

software. It involves monitoring the performance or operating level(s) of key parameters and comparing

them against thresholds to forecast problems. The capacity evaluation activity provides critical, proactive

information for infrastructure planners to better allocate resources and identify potential bottlenecks.

5-141. As previously mentioned, capability availability is closely tied to infrastructure capacity. The

objective of availability evaluation seeks to ensure a sustained level of availability, reliability, and

maintainability of NETOPS capabilities. The availability evaluation measures key parameters against

thresholds to forecast service degradations. Availability evaluation encompasses all networking equipment,

computing platforms, peripherals, and software. The results are used by NETOPS capability planners to

improve the overall availability of the capabilities; ultimately resulting in a reduction of the frequency and

duration of adverse incidents.

Capacity and Availability Echelons and Organizations

5-142. It is the primary responsibility of the corps, division, and ARFOR, with technical assistance from

the numbered Army, to evaluate the capacity and availability of NETOPS capabilities. In addition, the

mission, enemy, terrain and weather, troops and support available-time available may dictate that lower

echelons, such as the BCT, perform this activity. The combined capacity and availability metrics and

evaluations will then be reported to the corps or division.

5-143. The corps and division will monitor data under their control to evaluate capacity and availability

metrics associated with NETOPS capabilities and enabling devices. The corps and division will also

evaluate capacity and availability metrics from the BCT in order to form an assessment scoped to its AOR.

The combined capacity and availability metrics and evaluations will then be reported to the numbered

Army.

5-144. The numbered Army is responsible for evaluating the capacity and availability metrics associated

with the NETOPS capabilities and enabling devices under their control as well as those provided by other

service providers (e.g., DISA). The results of the evaluations are used to make capacity and availability

improvements locally as well as to other NETOPS capability providers in support of the Soldier. The

numbered Army will also evaluate its entire AOR based on capacity and availability metrics and evaluations

collected from lower echelons. This investigation will help formulate an appropriate scoped assessment.

This allows for the identification of issues that might not be seen when taking a narrower view from a lower

echelon.

5-145. All capacity and availability improvement changes made to the NETOPS infrastructure at any

echelon will be done through the established change management process. This ensures the proper level of

coordination in keeping with the overarching goal of improved efficiency.

Capacity and Availability Joint Implications

5-146. The ARFOR will evaluate capacity and availability metrics associated with the NETOPS

capabilities and enabling devices under its control. The ARFOR will also direct capacity and availability

functions within the corps, division, BCTs, ITSB/ESBs, and any other subordinate signal organizations to

5-22

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Network Operations Activities

form an assessment scoped to its AOR. These metrics are then reported to the local numbered Army.

Capacity and availability metrics are also evaluated and reported to its joint command as directed by joint

policy.

NETWORK OPERATIONS TRAINING AND EXERCISE

5-147. As the capabilities and dependencies of the network evolve, the complexities of NETOPS and the

management of the LWN and the GIG increase. NETOPS spans the entire enterprise and is no longer

limited to just a local network, a small enclave, or a tactical battlefield, or the strategic environment. The

Soldier is reliant on NETOPS capabilities continually being available. NETOPS capabilities are not just

dependent upon the proper mix of equipment and processes. They demand a finely tuned, technically

competent force that is continually being trained. Training and readiness responsibility is the driver for

ensuring properly trained NETOPS forces. The Army provides a trained and ready force. It manages

training from Army learning centers through the integrated command post exercise to support the CCDRs in

exercising their Title 10 responsibilities.

5-148. Exercising these NETOPS activities has multiple impacts. First, it exposes many of the challenges

that will be addressed by tools, technologies, and processes if the enterprise is to be fully leveraged as a war

fighting platform. Second, it opens communications and exposes expertise and capabilities so that they may

be leveraged across the enterprise. Only through exercising NETOPS activities will organizations learn the

capabilities, challenges, and expertise that are required at each echelon to effectively provision NETOPS

capabilities.

5-149. The activities Soldiers must perform in training are the same as when performed in an actual

operational environment. The training environment should replicate as closely as possible the conditions,

circumstances, and influences of an actual operational environment, except potentially in a physical location

and that they may be augmented by simulation or stimulation. Detailed examples of NETOPS activities and

their inter-dependant nature are provided in Appendix C.

TRAINING AND EXERCISE JOINT IMPLICATIONS

5-150. The Army must be ready to execute its mission as part of a joint force conducting joint operations.

To accomplish this goal the Army must perform joint, interagency, intergovernmental, and multinational

training. Some training must also be performed in the area of coalition network support.

5-151. To achieve joint operational interoperability, that being the joint tactics, techniques, and

procedures as well as the processes associated with installation, operation, maintenance, and defense and

NETOPS of LWN communications systems, joint operational interoperability must become an integral part

of training requirements from Army learning centers to the integrated command post exercise. The joint

operational interoperability training requirement should become a part of the training and readiness

responsibility cycle for the CCDR. This will enhance the training of Army units on the interdependent

activities and organizational relationships needed to perform joint NETOPS. It will also make it easier for

Army units to integrate into the joint enterprise and to adhere to joint NETOPS standards and doctrine.

METHODS TO REDUCE FORWARD-DEPLOYED NETWORK

OPERATIONS

5-152. The effort to migrate tactical NETOPS functions from the operational environment to a fixed-

station location decreases the forward-deployed operational environment footprint, greatly facilitates

coordination and data exchange between tactical units, and drastically increases the supportability of

NETOPS functions. This can be approached via two distinct but complimentary methods: the migration of

selected support services to the TNOSC and A-GNOSC, and the migration of tactical command functions to

a unit-owned fixed station NETOPS cell.

19 November 2008

FM 6-02.71

5-23

FOR OFFICIAL USE ONLY

Chapter 5

METHOD 1: THE MIGRATION OF SELECTED SUPPORT SERVICES TO THE TNOSC AND THE

A-GNOSC

5-153. As the physical network connectivity between the Soldier and sustaining base improves, it becomes

advantageous to identify target opportunities for the extension of garrison and theater-based NETOPS

capabilities to the Soldier. Consistent with Title 10 functions and responsibilities, these capabilities will be

available to the Soldier wherever they deploy.

5-154. The evolution of tactical support services must be designed with the purpose of not impairing the

flexibility or responsiveness of the ARFOR, corps, division, or BCT. Operational management

responsibilities of the combat echelons are discussed in further detail within the NETOPS Operational

Control and Management section.

5-155. For example, consider the AKO e-mail account and portal. The AKO e-mail address and portal are

available wherever a Soldier or organization deploys. The organization does not have to worry about the

operation and maintenance of this capability, and total cost of ownership is reduced. Additional examples of

tactical support services are IAVA guidance, anti-virus updates, capacity and availability data collection

and reports, and router configuration backups. The Soldier can access and manipulate these services by

logging into an AKO or a TNOSC site.

5-156. It is essential that the numbered Army and theater Army stand up to this service paradigm so that

opportunities to capitalize on economy of scale, standardization, and overall NETOPS value added are fully

realized. This will help to meet the vision of a single integrated Army enterprise that is capable of

projecting NETOPS capabilities in full support of the Soldier.

METHOD 2: THE MIGRATION OF TACTICAL COMMAND FUNCTIONS TO A UNIT-OWNED

FIXED STATION NETOPS CELL

5-157. Many NETOPS functions require a distributed management structure which parallels the combat

chain of command to ensure that activities are dynamically and quickly aligned with command guidance and

user requirements. These functions are not candidates for migration to the TNOSC or A-GNOSC. Some

examples of these functions are policy development, change management processing and approval, tactical

engineering functions, tactical planning functions, and operational management of specific devices.

5-158. In order for these functions to take place at a fixed station location, it is necessary to stage a unit-

controlled NETOPS cell within the fixed station. Robust lines of communication between the fixed station

and the operational environment TOCs can then be utilized for intra-unit coordination and data exchange.

The corps or division sanctuary serves this purpose for the corps and division. The TNT (rear) serves this

purpose for the ARFOR, JFLCC, or the JTF.

5-159. Some NETOPS functions require direct physical interaction with equipment or personnel within

the operational environment. Examples of these operational environment-linked NETOPS functions are

touch labor troubleshooting, device installation, manual recovery and teardown, site reconnaissance, and

physical interaction with unit subscribers or command personnel. These functions cannot be migrated to the

corps or division sanctuary, the ARFOR, JFLCC, or the JTF TNT (rear). All other unit-based NETOPS

functions for the corps, division, and above will be migrated to these locations.

5-160. There are few NETOPS tasks in the BCT and below that are not operational environment linked.

For this reason, the BCT and below will not generally operate a unit controlled NETOPS cell within the

fixed station. The BCT and below has the option of staging unit NETOPS services at the numbered Army-

hosted fixed UHN. They can also place unit personnel at a corps or division sanctuary or a TNT (rear) in

order to facilitate unit integration and provide remote NETOPS services from the fixed-station.

5-24

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Appendix A

Active Directory

This appendix describes the AD concept for command and staff elements that

deployable Army units will use to implement and operate AD in CONUS, OCONUS,

and across all theaters of operations. This information is not meant to provide the

technical procedures required to install, operate, and maintain networks in an AD

environment. This document establishes that tactical unit guidance is provided by the

US Army Signal Center and the US Army NETCOM/9^thSC(A). They will provide

the overall guidance for the standards, responsibilities, and processes necessary to

migrate from the current IT environment to an AD based environment.

OVERVIEW

A-1. To meet the operational philosophy of training and working-as-you-fight, the deployable units should

operate the same way in garrison as they would when they are deployed. This ―deployed-in-garrison‖

concept helps to support modularity and achieve a ―plug-&-play‖ functionality for the deployable units.

Deployable force users will be able to leverage local DOIM or TNOSC expertise, as available. The users

will increase and maintain automation proficiency by practicing the skills learned while providing service in

garrison.

A-2. Introduction of AD into the Army will provide both a new capability plus satisfy the Army mandate

for a technology replacement of the old NT 4.0 LAN operating system.

ACTIVE DIRECTORY OPERATIONAL FEATURES

A-3. The AD architecture and associated features introduce a more granular management capability with

the introduction of structures such as forests, and organizational units. The enabling technology for all of

these new structures is AD, which is the directory service for Windows 2003 server capabilities. AD

implementation is both necessary and beneficial in that current disparate architectures and personnel

responsibilities at each installation can be combined to form an Army Windows IT enterprise. Approved

deployed forest information is in the approved Technical Authority 2006-006, 14 May 2007.

ENTERPRISE MANAGEMENT FEATURES

A-4. The enterprise management features include:

Extensible schema—AD lets developers and administrators extend the directory schema and

create new properties and objects. Using the directory as a data store, developers can create their

own data structures for applications. Users on the network can publish important information in

the directory so other users can easily locate the material.

Centralized management—allows enterprise level management of Windows users, clients, and

servers through a single consistent interface, reducing redundancy and maintenance costs.

Group policy—allows administrators to define and control the policies governing groups of

computers and users within their organization. Administrators can set group policy for any of the

sites, domains, or organization unit in AD. Once the policy is set, the system maintains group

policy without further intervention.

Global catalog—provides a way to centrally maintain information about users and universal

groups for access control. The information is managed by using one or more domain controllers

19 November 2008

FM 6-02.71

A-1

FOR OFFICIAL USE ONLY

Appendix A

that contain subset attribute information for most entries in a Windows 2000 domain forest.

These controllers also replicate domain schema, configuration, and partial user or other resource

entries.

Automated software distribution—provides the capabilities for administrators to automatically

distribute applications to users based on their functional requirements.

AD service interfaces—simplifies the development of directory enabled applications and the

administration of distributed systems. Developers and administrators use this single set of

interfaces to manage the resources in a direct support, regardless of the network environment that

contains the resource.

Delegated administration—provides administrators the ability to delegate a selected set of

administrative privileges to appropriate individuals within the organization and specify the

specific rights they have over different containers and objects in the directory.

Multi-master replication—ensures changes made to any one domain controller will replicate to

all the other direct currents in the same domain, and assures that the directory is available for

changes 100 percent of the time.

Security

A-5. AD security features include:

Kerberos authentication—provides fast, single sign-on to Windows-based resources and to

other environments that support this protocol.

Transitive Domain Trust—reduces the number of trust relationships to manage between the

Windows domains.

PKI x.50—ensures interoperability with and deployment of extranet and e-commerce

applications.

Attribute-level security—enforces object and attribute-level security for detailed control of

access to information stored in the directory.

Spanning security groups—permits central management of groups.

Lightweight Directory Access Protocol ACL support—ensures interoperability for secure

extranets and e-commerce applications.

Smart Card support—allows logon via smart cards for strong authentication to sensitive

resources.

Group policy—allows administrators to define and control the security policies governing

groups of computers and users within their organization and filter the effects by using

membership in security groups.

ACTIVE DIRECTORY MULTI-FOREST AND OPERATIONAL

CONSIDERATIONS

A-6. The current approved AD architecture represents a multi-forest approach that divides the Army

enterprise into element permanent AD forests and allows for tactical forests.

A-7. Since the security boundary is at the forest level, a single forest approach produces a security

vulnerability that is not acceptable. Single forest architecture would allow someone with access to the

forest’s domain controller or administrative rights in a domain to exceed their authority and obtain

enterprise administrative rights. Objects stored in the AD represent all of the users, systems, and services

within that forest. A person with these rights could destroy the validity of the data causing enterprise wide

consequences. The global catalog contains a partial copy of every object in the AD forest. If the system that

hosts AD for a forest is compromised, there is a risk of exposing a portion of the Army’s infrastructure

information. A larger forest makes more infrastructure information vulnerable at a central location. The

multi-forest operational concept limits the consequences of an attack. The smaller the forest, the more

readily problems associated with the global catalog can be discovered. The single forest has a limited ability

A-2

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Active Directory

to compartmentalize. This circumstance presents an unacceptably high risk for secure information

distributed into potentially hostile areas.

A-8. In addition to security considerations, scalability is an operational risk associated with a single forest

deployment. The larger the forest size in terms of number of supported users and desktops, the larger the

directory must be that supports the forest. Since the Army has in excess of 1,000,000 users, a single

directory and the associated global catalog would be extremely large and would impose potentially

excessive replication loads on available network bandwidth. The architecture of each forest will have a top

level AD domain that forms a contiguous name space from the top level Army enterprise forest root

domain; and a contiguously named management domain that is a placeholder domain to manage the

enterprise administrator accounts and processes.

A-9. Organizations’ geographic ―regions‖ are included in a designated regional forest. Examples of

regional forests are CONUS, Pacific, Korea, and Europe. In addition to the standard regional forests, some

organizations require autonomy due to sensitive or specialized business practice or geographic region that

does not adequately represent its mission support needs. For these cases, a

―virtual region‖ and

corresponding forest exists. Examples of organizations with their own ―virtual region‖ include Army

Medical Command, Corps of Engineers, and National Guard. Given the multiple forest configurations of

AD, the A-GNOSC uses the CONUS-TNOSC operation and maintenance resources and capabilities to

fulfill its Windows server or AD enterprise management role. The current list of forests are:

North America forest: five child domains representing information management area regions.

Europe forest: three child domains.

Global catalog forest: three child domains.

National Guard forest: four child domains.

Pacific forest: three child domains.

Southwest Asia forest: one child domain.

Korea forest: one child domain.

Corps of Engineers forest: three child domains.

Education forest: to be determined.

Enterprise Application forest: one child domain.

Deployed forest information can be found in Technical Authority 2006-006, dated 14 May 2007.

ACTIVE DIRECTORY IMPLEMENTATION CONSIDERATIONS

A-10. When implementing AD the commander and staff must consider:

Implementing, managing, and maintaining IP addressing as related to the DHCP.

Name resolution as related to the DNS.

Network security as related to overall security templates to include parameter security and CND

oversight.

Routing and remote access as related to remote access authentication protocols.

Managing network architecture as related to connectivity to the Internet and troubleshooting

network services.

A-11. A global catalog server is required to communicate between domains. There must also be a sufficient

amount of automation materiel (hardware or software) for the deployable force. AD implementation needs

an information system platform that meets or exceeds the performance requirements to run Microsoft

Advanced Server 2000/2003 software domain controller, a DNS, DHCP server, and a global catalog server.

The DNS may be co-hosted on the domain controller provided it does not adversely impact system

performance.

19 November 2008

FM 6-02.71

A-3

FOR OFFICIAL USE ONLY

Appendix A

FLEXIBLE SINGLE MASTER OPERATION

A-12. The enterprise flexible single master operation roles for each forest will be physically located on the

domain controllers. Flexible single master operation roles will include the schema and domain naming

masters. The root or management domain specific roles are—

Primary domain controller emulator.

Relative identifier master.

Infrastructure master.

A-13. All domains in an AD forest share a single schema, configuration naming context, and a global

catalog containing selected information about each object in the forest. The Army will maintain consistent

schemas across all forest implementations. This is accomplished through strict adherence to published Army

Enterprise Infrastructure (AEI) standards and tightly controlled change management through the CCB

process. NETCOM chairs the AEI Tech CCB, which adjudicates modifications to the currently

implemented AD schema in an operational environment.

Note. CCDR participation in and input to the AEI Tech CCB will aid future CCDR AD

migration.

MANAGEMENT ROLES AND RESPONSIBILITIES

A-14. This section addresses the roles and responsibilities of Army organizations within the Windows

server or AD enterprise. AD is a key component of any future enterprise-wide directory service. Therefore,

the management and configuration control of AD implementations and maintenance requires strict central

control and well-defined roles and responsibilities across the enterprise. The role of schema or enterprise

administration is the responsibility of the local enterprise administrator, which delegates operation and

maintenance responsibility to selected support and helpdesk personnel. NETCOM has been tasked by the

CIO G-6 to establish technical guidance, procedures, and standards for AD implementation and operations.

The current version of the AEI Directory Services Naming Conventions and Standards (NETC-EST-G-

0306-009-STD), published by NETCOM Enterprise Systems Technology Activity is the authoritative

document governing AD. This and other documents can be found at the following URL

https://www.us.army.mil/suite/folder/626256. Figure A-1 shows the interface relationships by

organizational level. Table A-1 shows the organizations by level with their associated operational roles.

A-4

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Appendix A

Table A-1. AD operational concepts by NETOPS organizational level

NETOPS Level

GARRISON

DEPLOYED

AD Operational Roles

Has specific responsibilities for:

Exchange e-mail.

Unit Level

Web hosting and collaboration (information dissemination

management-tactical [IDM-T]).

Corp, Division, and

Brigade Unit

AD and user account management.

Patch management to defend the tactical network.

File, print, and store.

Installation and numbered

The site or installation will be a top-level organizational unit.

Army level

Has specific responsibilities for:

Collaboration services (Defense Collaboration Tool Suite and

information warfare support).

Record messaging services (Defense Message System and

Automated Message Handling System).

Major

Perimeter security; CND oversight.

DOIM

Subordinate

Command

Trouble ticketing services.

Global address list synchronization.

Level 2 and 3 technical support and operational CM.

Provides NETOPS shared SA data to respective TNOSC.

Manages and administers AD forest and domains for the respective

Theater Level

theaters; delegates top-level organizational units’ administrative roles to

ensure efficient, effective distributed operations for lower level

organizations.

Provides expertise to support the expanded enterprise operation and

maintenance of critical domain and theater level AD equipment

DOIM

TNOSCs

Monitors network common relevant operational picture (NETOPS shared

SA) for installations in region.

Provides all Army users enterprise-wide visibility and access to ―yellow

and white‖ pages.

Establishes technical guidance, procedures, and standards for AD

support.

Global Level

Has specific responsibilities for:

NETCOM (A-GNOSC)

SA.

Domain naming service master.

Circuit management.

Provides top level configuration control through AEI Tech CCB.

KEY AD MANAGEMENT ROLES IN THE MULTI-FOREST ARCHITECTURE

A-15. The multi-forest architecture provides the foundation for the operation and maintenance support of

the Army AD community. AD provides the capability, at the enterprise level, to support the mission to

manage, operate, maintain, monitor, and defend the AEI. The master forest (ds.army.mil for NIPRNET and

A-6

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Active Directory

ds.army.smil.mil for SIPRNET) provides the framework for Army enterprise management using Microsoft’s

Windows 2003 AD services across all approved forests. The key aspects of the AD environment requiring

central control are—

Schema and naming standards throughout the multiple forests.

Administration of the domain controllers precludes the delegation of specific privileges below

the central management organization.

AD and Windows 2000/2003 server administration capabilities do not preclude the delegation of

specific privileges required by local support staff. This delegation of responsibilities may be

handled via third-party software tools.

Execution of administrative roles.

Forest level administration of the AD forest includes responsibilities related to managing the AD

schema and those tasks requiring enterprise administrator privileges.

Domain level administration of the AD domain includes responsibilities of domain management

and maintenance of the domains within the forest, to include all tasks requiring domain

administrator privileges.

Administration of the top-level organization unit includes responsibilities of organization unit

management and maintenance to include user, group, resource, and data administration.

UNIT LEVEL

A-16. Units may operate and maintain specialized IT resources such as specialized software or hardware

devices required to perform the unit’s mission. These resources remain the operation and maintenance

responsibility of the unit. These organizations use standard Army support to the greatest extent possible,

thus minimizing differences.

Corps, Division, and Brigade Mission-Critical Services

A-17. Corps, division, and brigade mission-critical services include:

Organizational messaging (Defense Message System).

Exchange e-mail.

Web hosting or collaboration (IDM-T).

Managing user accounts within their unit based on the AD policies and administrative

capabilities.

Patch management to defend their network.

Hosting and maintaining local print servers, local file servers, and local storage.

DNS management.

AD replication; DHCP authorization.

Trust management.

Local exchange message tracking and troubleshooting.

Perimeter security and CND oversight.

Managing and creating domain local groups.

Managing NETOPS.

Trouble ticketing and helpdesk services.

Additional Corps, Division, and Brigade Required Services

A-18. Additional corps, division, and brigade required services include:

Providing group policy object policy administration to include domain and domain controller

polices.

Providing level 2/3 technical support and operational CM.

19 November 2008

FM 6-02.71

A-7

FOR OFFICIAL USE ONLY

Appendix A

Maintaining the approved configuration of core AD equipment on the installation or region as

directed by its TNOSC related to the initialization or termination of operations and to the

establishment or maintenance of configuration.

Populating and managing organization units provided, and delegating authority for subordinate

level organization units.

Applying security necessary to prevent unauthorized individuals any physical access to enterprise

resources geographically located at the installation.

Notifying appropriate higher command of physical security compromised of any system.

Executing global catalog server roles.

Executing schema master role for the unit forest.

Executing domain naming master role for the forest.

INSTALLATION AND NUMBERED ARMY LEVEL

A-19. Organizations at the installation or numbered Army level may operate and maintain specialized IT

resources such as specialized software or hardware devices required to perform their mission as well as their

subordinate unit’s missions. These organizations include TNOSC, DOIM, and major subordinate

commands (e.g., CCDRs). These resources remain the operation and maintenance responsibility of the unit,

and the organization’s commander will act as the designated approval authority (DAA). These organizations

use standard Army support to the greatest extent possible to minimize differences. Critical tasks include all

the tasks required at the unit level as well as the tasks requiring AD enterprise, domain administration, and

exchange rights. These tasks include:

DNS CM.

Collaboration services (Defense Collaboration Tool Suite and information warfare support).

AD replication; DHCP authorization.

Group policy object policy administration to include domain and domain controller polices.

Trust management.

Exchange installation and message tracking and troubleshooting to include:

Trouble ticketing services.

Record messaging services

(Defense Message System and Automated

Message Handling System).

Enabling global address list synchronization.

Perimeter security; CND oversight.

Level 2/3 technical support/operational CM.

DOIM AND MAJOR SUPPORT COMMANDS

A-20. The DOIM and the major subordinate commands in the US Army theaters have two basic functions:

one of operational support and one of administration and management. These organizations provide

infrastructure IT services to all Army users on the installation, consistent with the concept established by the

NETOPS CONOPS. In addition, they provide access to IT services based on support agreements with other

non-Army organizations and activities. From a Windows server or AD perspective, DOIM and major

subordinate command activities include:

Conducting Windows server and AD implementation, and coordinating the necessary

implementation planning actions with NETCOM and its TNOSC.

Hosting and maintaining local print servers, local file servers, and local Windows servers for

legacy systems interaction.

Ensuring that noncritical member servers provided by the installation meet the minimum server

requirements to join the enterprise.

Providing troubleshooting support for core AD servers in support of the TNOSC operation and

maintenance responsibilities.

A-8

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Active Directory

Performing necessary hands-on maintenance of AD assets ICW its TNOSC.

Managing user accounts within their installation or region based on the AD policies and

administrative capabilities.

Maintaining the approved configuration of core AD equipment on the installation or region as

directed by its TNOSC related to the initialization or termination of operations and to the

establishment or maintenance of configuration.

Managing and creating domain local groups.

Populating and managing top-level organization units provided as part of the installation

resources and delegation authority for subordinate level organization units.

Validating and forwarding, through the RCIO, all configuration change requests from local

organizations.

Maintaining installation member servers and applications.

Applying security necessary to prevent unauthorized individuals any physical access to enterprise

resources geographically located at the installation.

Notifying the TNOSC of physical security compromised of any system.

THEATER LEVEL

A-21. At each theater level, the TNOSC has the key management role for the Windows server and AD

operations within that theater. In general, these roles are the forest and domain administrative related roles

as delegated by the A-GNOSC.

TNOSC

A-22. The TNOSC is the highest-level organization with IT operations responsibilities. They interact with

the RCIOs and with the A-GNOSC. Within a given theater of operation, the TNOSC has the responsibility

for IT assets that span its theater. It is responsible for ensuring that IT assets operate correctly, and for

creating policy on a theater-by-theater basis. The TNOSC currently manages the public side of the

demilitarized zone. Note that the demilitarized zone currently starts at the installation Army DISN router

program. The TNOSC supplies technical support (e.g., tool sets to ensure the local health of AD) to the

installations. The TNOSC proactively monitors all systems within the child domains. Each TNOSC is

responsible for the performance management to support AD operations in theater. TNOSC performs the

appropriate monitoring for those systems within their child domains. They use the information to affect root

level configuration change request through the A-GNOSC to the AEI technical CCB.

A-23. The TNOSC is responsible for ensuring standard configuration, CONOPS, and centralized

management of domain controllers within the Windows server or AD enterprise. It ensures the systems

located in these domains are capable of providing those services detailed in the Army enterprise, AD

architecture, and any subsequent AEI technical CCB additions. The TNOSC maintains the necessary system

configuration, conducts theater level Configuration Control Review Board, and implements system changes

authorized by the AEI technical CCB. The TNOSC ensures proper configuration of external devices and

provides the backup and recovery processes relative to child domains. Under the AD enterprise concept, the

TNOSC’s responsibilities will expand and include the administrative management of the domain for the

theater’s respective AD. These responsibilities include:

Operating and maintaining the domain controllers for all domains and the critical member servers

in the theater.

Maintaining and disseminating enterprise management and directory management tools.

Hosting and maintaining:

DNS server for the theater’s domains (DNS server is a secondary for the

root zone).

Infrastructure master role for theater respective domains.

Primary domain controller emulator role for theater domains.

19 November 2008

FM 6-02.71

A-9

FOR OFFICIAL USE ONLY

Appendix A

A-24. TNOSC executes security related guidance from the A-GNOSC by implementing security programs,

procedures, policies, and IAVA patches as directed. It is imperative that the TNOSC take all actions to

protect its domain level systems from compromise. TNOSC provides a level of physical security ensuring

that only authorized individuals have access to their child level domains. TNOSC will notify the appropriate

organizations if systems are compromised within their domains and will provide the organizations with all

the information relative to the compromise. TNOSC will implement best security practices by controlling

accounts relative to administrative functions within respective domains.

A-25. The respective TNOSC also has regional level responsibilities for the domain hub domain controllers

that are established in a region. Each TNOSC will have the administrative rights for the child domains

affected by these domain controllers for that region. The NETCOM domain design document provides the

technical guidelines for the functions of these domain controllers. The respective TNOSC has site level

responsibilities for the domain replicas on each site. The TNOSC has the administrative rights for the top

level organization units for the site. The NETCOM domain design document provides the technical

guidelines for the functions of these domain controllers.

REGIONAL CHIEF INFORMATION OFFICER

A-26. The RCIO acts as the CIO for an assigned region. The RCIO ensures all personnel operating on an

Army installation are provided the IT resources they require in a manner that is consistent with policies,

regulations, and other guidelines developed in or by the RCIOs management chain. The RCIO provides

administrative and managerial IT support to any DOIM located within its regional director geographic

region.

GLOBAL MANAGEMENT ROLES

A-27. This section addresses the role of those global level organizations that affect Windows server and AD

operations. Refer to the Army Knowledge Management NETOPS CONOPS for a complete description

from a NETOPS perspective of all organizations for the global level.

ARMY GLOBAL NETWORK OPERATIONS AND SECURITY CENTER

A-28. The A-GNOSC’s prime responsibility for Windows server and AD operations is to establish and

exercise strict control over the AD forests at all levels within the enterprise. The proactive centralized

monitoring of enterprise systems within the Army AD environment provides organizations responsible for

those assets the valuable information necessary to achieve a stable and productive enterprise environment.

The A-GNOSC provides operational and management policy input to NETCOM. The A-GNOSC delegates

AD administrative roles by:

Assigning the responsibilities for schema and enterprise administration at the forest level to the

appropriate TNOSC.

Assigning operating responsibilities for cross-forest meta-directory services to the appropriate

TNOSC.

Assigning responsibilities for administration at the top-level organization unit and delegation of

administrative authority to the installation DOIM or major subordinate command organization

unit administrators.

Assigning responsibility for administration at the second-level organization unit or below by the

major subordinate command or DOIM to other lower-level organizations.

A-29. At present, the A-GNOSC uses the CONUS-TNOSC capabilities and resources to conduct its AD

enterprise management functions. The A-GNOSC has the following roles and responsibilities relative to the

Army AD enterprise:

Delegates, to the TNOSC, the responsibility to perform the appropriate monitoring for all

systems within TNSOCs respective domains. The scope of this responsibility includes hardware,

operating systems, services (to include the Army AD), networking services, third party tools,

Windows 2003 policies, sites, organizational units, and enterprise accounts.

A-10

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Active Directory

Delegates to the TNOSC operation and maintenance support actions, to include:

Management of the enterprise management and directory tools in the

management and services domains of the master forest.

Global catalog server at the root level.

Schema master role for the forest.

Domain naming master role for the forest.

CM support responsibilities.

Ensures maintenance of a standard system baseline, and overall administration of systems located

within all approved forests supporting the actions of the AEI technical CCB. The AEI technical

CCB has overall responsibility for CM of the Army IT enterprise.

Establishes processes with the respective TNOSCs for a theater level CCB to implement

processes for the following call manager actions:

Implement CCB approved system changes for the root domains.

Ensure that approved configuration changes are propagated to child domains

within the Army AD domain structure.

Maintain the system configuration for the hardware, software, and

applications necessary for the CONOPS of systems in the root level domains

based on standard server configuration document.

Ensure proper configuration of external peripheral devices and provide the

management of the backup and recovery systems within the root domain.

Ensure consistency across the enterprise for AD supporting tools sets via

requirements developed ICW NETCOM product engineers.

Participate in an advisory role to the AEI technical CCB to provide operational expertise.

A-30. A-GNOSC identifies, tracks, and manages all security areas relative to enterprise servers for all

forests. A-GNOSC directs the respective TNOSC implementation of security programs, procedures,

policies, and IAVA patches. A-GNOSC administers control over accounts relative to administrative

functions within the root domains, and uses whatever means necessary and reasonable to ensure security of

the root systems. A-GNOSC is responsible for notifying the appropriate organizations if systems within the

root level are compromised. They also provide that organization with all the information relative to that

compromise.

A-31. The greatest level of protection must be exercised in guarding the Army AD data. Given the existence

of host-based IDS, the A-GNOSC directs the respective TNOSC to configure the software in such a way as

to maximize the efficiency of the software while balancing system performance. Security management

duties include:

Managing the settings for encryption level between root and child-level domains.

Coordinating with the TNOSC in order to implement encryption levels.

Establishing the accounts and access permissions to the file systems located within the root

domains.

Ensuring that user and administrative accounts within the root domain have proper password

security.

Ensuring user and administrative accounts have not been compromised.

NETWORK ENTERPRISE TECHNOLOGY COMMAND

A-32. NETCOM was designated as the Army's authority to operate (ATO) and manage the enterprise level

infrastructure. NETCOM is also in charge of implementing Army IT operational and management policies.

Through operational review and coordination, NETCOM agencies establish standards and evaluate devices

that impact upon the Army enterprise level infrastructure.

19 November 2008

FM 6-02.71

A-11

FOR OFFICIAL USE ONLY

Appendix A

A-33. NETCOM delegates the management of Windows server and AD operational services by assigning

administrative roles to the Army organizations. From the Windows server or AD perspective, NETCOM

responsibilities are:

Integrating, operating, and maintaining the Army’s protected (public) and AD (private) DNS.

Providing processing platform management and administration of all AD enterprise level servers.

Managing the Windows server and AD top-level architecture (this includes domain management

of all consolidated Windows 2003/2000 domains and domain controllers).

Managing the root and services domain (ds.army.mil) for the enterprise.

Providing support for organizational unit managers.

Providing policy and technical guidance to installations or sites for migration to the Windows

server and AD.

Integrating directory services.

Integrating AD with TNOSC COOP.

Integrating Windows server and AD developed backup and restore technology.

Operating, managing, and maintaining Windows server and AD root and regional footprints.

Managing COOP and backup and restore technology for Windows server and AD systems.

Expanding security monitoring to support enterprise Windows server or AD servers.

Testing and applying all security patches and validating IAVA compliance for all AD and

consolidated servers.

Assisting with the installation DOIM as necessary during the execution of the approved plan.

Validating compliance IAW AEI technical CCB.

Accommodating issues that prevented routine migration of installation users or organizations.

ARMY CHIEF INFORMATION OFFICER G-6

A-34. The CIO G-6 is responsible to the secretary of the Army and responsive to the chief of staff of the

Army for all information management area activities of the Department of the Army. The information

management area includes automation, communications, records management, publications and printing,

visual information disciplines, and library activities throughout the Army theater and strategic (tactical and

sustaining base) environments. From a Windows server or AD perspective, the CIO G-6 activities include:

Providing high level (global) Windows server or AD policies.

Establishing high level (global) Windows server or AD operating rules and guidelines.

TACTICAL INTERNET NAMING CONVENTIONS

A-35. The naming standards described in this document apply to all Army networks of all classifications,

strategic and tactical. This appendix covers the specifics that apply to all tactical and deployable Army units

(active and reserve) and is intended to be used in conjunction with the entire Naming Convention document,

making it interoperable with the naming convention of the DISN and the tactical naming conventions of

other tactical forces. It is not intended to be used as a stand alone document. This appendix incorporates

data networks at theater, corps, division, BCT, combat aviation brigades, fires brigades, combat support

brigades, sustainment brigades, battlefield surveillance brigades, and battalion/small command posts. This

naming convention applies to both tactical SIPRNET and tactical NIPRNET addressing with the difference

in domains of ―.army.smil.mil‖ for SIPRNET and ―.army.mil‖ for NIPRNET.

Note. This guidance document is based on current policies and procedures at the time it was

written. Any changes in policy or guidance could impact this guidance and will be reviewed as

needed.

A-12

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Active Directory

A-36. NETCOM and the US Army Signal Center agree to support the following SECRET Internet Protocol

Router

(SIPR)/Non-Secure Internet Protocol Router

(NIPR) DNS structure for autonomous units.

Autonomous units are defined as any unit that satisfies the Joint Expeditionary Mindset (Task Force

Modularity) and can be deployed without regard to any habitual relationship or task organization, CONUS

or otherwise. Notable examples include the reorganized BCT or other brigade unit, division, and corps

and/or theater.

A-37. The autonomous unit maintains its SIPRNET/NIPRNET AD forest and only one AD domain. If the

autonomous unit desires additional domains, they must be approved by NETCOM ICW the US Army

Signal Center.

ACTIVE COMPONENT TACTICAL/DEPLOYABLE AD FORESTS NAMES

A-38. Tables A-2 through A-4 are the standardized names to be used upon approval of AD

tactical/deployable forests. Inclusion in this list does not constitute an approval for implementation. All

forests must be approved by the CIO/G-6 prior to implementation based on current policies and procedures.

No deviations are authorized. Any additions to this list must be requested from the proponent for this

publication. Current information (Army guidance) is in Appendix M of the AEI directory services naming

conventions and standards document. For the most current Appendix M please click the URL listed below.

https://www.us.army.mil/suite/collaboration/folder_V.do?foid=807867

DOMAIN NAME

A-39. Each tactical/deployable forest will initially have only one AD domain. Its name has been assigned

according to Tables A-2, A-3, and A-4 below. In the event that additional domains are required, requests

must be coordinated, through the unit’s parent G-6/S-6, with the Global Database Manager at the US Army

Signal Center (Concepts, Requirements and Doctrine Division, Material Requirements Branch), DSN: 780-

6920) for concurrence; and then must receive approval from NETCOM.

Note. The ―.DS‖ appears only in the root domain name; the nameserver record pointing to the

tactical DNS servers IP will be for public presence namespace and is the same as the existing

namespace but without the DS. The unit does not include the ―.DS‖ in its request for a

nameserver record (with its DNS IP) to be added. Example: A server is installed using the DNS

namespace 3BCT82AB.ds.army.mil or 3BCT82AB.ds.army.smil.mil. The nameserver IP is

registered with 3BCT82AB.army.mil or 3BCT82AB.army.smil.mil for external resolution. If a

system on the internal network needs to be publicly accessible then an alias record would be

created in the 3BCT82AB nameserver pointing to the internal machine. This ensures that only

authorized systems are resolved from outside of the unit’s network.

Table A-2. Forest names, domain names, and exchange organization names

of active component tactical deployable units

Exchange

NIPR Domain name (one per

SIPR Domain name (one per

Forest Name

Organization name

forest only)

SIPR and NIPR

Corps

ICorps

ICORPS.DS.ARMY.MIL

ICORPS.DS.ARMY.SMIL.MIL

ICORPS

IIICorps

IIICORPS.DS.ARMY.MIL

IIICORPS.DS.ARMY.SMIL.MIL

IIICORPS

VCorps

VCORPS.DS.ARMY.MIL

VCORPS.DS.ARMY.SMIL.MIL

VCORPS

XVIIICorps

XVIIICORPS.DS.ARMY.MIL

XVIIICORPS.DS.ARMY.SMIL.MIL

XVIIICORPS

Divisions

1AD

1AD.DS.ARMY.MIL

1AD.DS.ARMY.SMIL.MIL

1AD

1BCT1AD

1BCT1AD.DS.ARMY.MIL

1BCT1AD.DS.ARMY.SMIL.MIL

1BCT1AD

19 November 2008

FM 6-02.71

A-13

FOR OFFICIAL USE ONLY

Appendix A

2BCT1AD

2BCT1AD.DS.ARMY.MIL

2BCT1AD.DS.ARMY.SMIL.MIL

2BCT1AD

Table A-2. Forest names, domain names, and exchange organization names

of active component tactical deployable units (continued)

Exchange

NIPR Domain name (one per

SIPR Domain name (one per

Forest Name

Organization name

forest only)

SIPR and NIPR

Divisions

3BCT1AD

3BCT1AD.DS.ARMY.MIL

3BCT1AD.DS.ARMY.SMIL.MIL

3BCT1AD

4BCT1AD

4BCT1AD.DS.ARMY.MIL

4BCT1AD.DS.ARMY.SMIL.MIL

4BCT1AD

1CAB1AD

1CAB1AD.DS.ARMY.MIL

1CAB1AD.DS.ARMY.SMIL.MIL

1CAB1AD

1CD

1CD.DS.ARMY.MIL

1CD.DS.ARMY.SMIL.MIL

1CD

1BCT1CD

1BCT1CD.DS.ARMY.MIL

1BCT1CD.DS.ARMY.SMIL.MIL

1BCT1CD

2BCT1CD

2BCT1CD.DS.ARMY.MIL

2BCT1CD.DS.ARMY.SMIL.MIL

2BCT1CD

3BCT1CD

3BCT1CD.DS.ARMY.MIL

3BCT1CD.DS.ARMY.SMIL.MIL

3BCT1CD

4BCT1CD

4BCT1CD.DS.ARMY.MIL

4BCT1CD.DS.ARMY.SMIL.MIL

4BCT1CD

1CAB1CD

1CAB1CD.DS.ARMY.MIL

1CAB1CD.DS.ARMY.SMIL.MIL

1CAB1CD

1ID

1ID.DS.ARMY.MIL

1ID.DS.ARMY.SMIL.MIL

1ID

1BCT1ID

1BCT1ID.DS.ARMY.MIL

1BCT1ID.DS.ARMY.SMIL.MIL

1BCT1ID

2BCT1ID

2BCT1ID.DS.ARMY.MIL

2BCT1ID.DS.ARMY.SMIL.MIL

2BCT1ID

3BCT1ID

3BCT1ID.DS.ARMY.MIL

3BCT1ID.DS.ARMY.SMIL.MIL

3BCT1ID

4BCT1ID

4BCT1ID.DS.ARMY.MIL

4BCT1ID.DS.ARMY.SMIL.MIL

4BCT1ID

1CAB1ID

1CAB1ID.DS.ARMY.MIL

1CAB1ID.DS.ARMY.SMIL.MIL

1CAB1ID

2ID

2ID.DS.ARMY.MIL

2ID.DS.ARMY.SMIL.MIL

2ID

1BCT2ID

1BCT2ID.DS.ARMY.MIL

1BCT2ID.DS.ARMY.SMIL.MIL

1BCT2ID

2BCT2ID

2BCT2ID.DS.ARMY.MIL

2BCT2ID.DS.ARMY.SMIL.MIL

2BCT2ID

3BCT2ID

3BCT2ID.DS.ARMY.MIL

3BCT2ID.DS.ARMY.SMIL.MIL

3BCT2ID

4BCT2ID

4BCT2ID.DS.ARMY.MIL

4BCT2ID.DS.ARMY.SMIL.MIL

4BCT2ID

2CAB2ID

2CAB2ID.DS.ARMY.MIL

2CAB2ID.DS.ARMY.SMIL.MIL

2CAB2ID

3ID

3ID.DS.ARMY.MIL

3ID.DS.ARMY.SMIL.MIL

3ID

1BCT3ID

1BCT3ID.DS.ARMY.MIL

1BCT3ID.DS.ARMY.SMIL.MIL

1BCT3ID

2BCT3ID

2BCT3ID.DS.ARMY.MIL

2BCT3ID.DS.ARMY.SMIL.MIL

2BCT3ID

3BCT3ID

3BCT3ID.DS.ARMY.MIL

3BCT3ID.DS.ARMY.SMIL.MIL

3BCT3ID

4BCT3ID

4BCT3ID.DS.ARMY.MIL

4BCT3ID.DS.ARMY.SMIL.MIL

4BCT3ID

3CAB3ID

3CAB3ID.DS.ARMY.MIL

3CAB3ID.DS.ARMY.SMIL.MIL

3CAB3ID

4ID

4ID.DS.ARMY.MIL

4ID.DS.ARMY.SMIL.MIL

4ID

1BCT4ID

1BCT4ID.DS.ARMY.MIL

1BCT4ID.DS.ARMY.SMIL.MIL

1BCT4ID

2BCT4ID

2BCT4ID.DS.ARMY.MIL

2BCT4ID.DS.ARMY.SMIL.MIL

2BCT4ID

3BCT4ID

3BCT4ID.DS.ARMY.MIL

3BCT4ID.DS.ARMY.SMIL.MIL

3BCT4ID

4BCT4ID

4BCT4ID.DS.ARMY.MIL

4BCT4ID.DS.ARMY.SMIL.MIL

4BCT4ID

4CAB4ID

4CAB4ID.DS.ARMY.MIL

4CAB4ID.DS.ARMY.SMIL.MIL

4CAB4ID

7ID

7ID.DS.ARMY.MIL

7ID.DS.ARMY.SMIL.MIL

7ID

10ID

10ID.DS.ARMY.MIL

10ID.DS.ARMY.SMIL.MIL

10ID

1BCT10ID

1BCT10ID.DS.ARMY.MIL

1BCT10ID.DS.ARMY.SMIL.MIL

1BCT10ID

2BCT10ID

2BCT10ID.DS.ARMY.MIL

2BCT10ID.DS.ARMY.SMIL.MIL

2BCT10ID

3BCT10ID

3BCT10ID.DS.ARMY.MIL

3BCT10ID.DS.ARMY.SMIL.MIL

3BCT10ID

A-14

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Active Directory

4BCT10ID

4BCT10ID.DS.ARMY.MIL

4BCT10ID.DS.ARMY.SMIL.MIL

4BCT10ID

Table A-2. Forest names, domain names, and exchange organization names

of active component tactical deployable units (continued)

Exchange

NIPR Domain name (one per

SIPR Domain name (one per

Forest Name

Organization name

forest only)

SIPR and NIPR

Divisions

10CAB10ID

10CAB10ID.DS.ARMY.MIL

10CAB10ID.DS.ARMY.SMIL.MIL

10CAB10ID

24ID

24ID.DS.ARMY.MIL

24ID.DS.ARMY.SMIL.MIL

24ID

25ID

25ID.DS.ARMY.MIL

25ID.DS.ARMY.SMIL.MIL

25ID

1BCT25ID

1BCT25ID.DS.ARMY.MIL

1BCT25ID.DS.ARMY.SMIL.MIL

1BCT25ID

2BCT25ID

2BCT25ID.DS.ARMY.MIL

2BCT25ID.DS.ARMY.SMIL.MIL

2BCT25ID

3BCT25ID

3BCT25ID.DS.ARMY.MIL

3BCT25ID.DS.ARMY.SMIL.MIL

3BCT25ID

4BCT25ID

4BCT25ID.DS.ARMY.MIL

4BCT25ID.DS.ARMY.SMIL.MIL

4BCT25ID

25CAB25ID

25CAB25ID.DS.ARMY.MIL

25CAB25ID.DS.ARMY.SMIL.MIL

25CAB25ID

82AB

82AB.DS.ARMY.MIL

82AB.DS.ARMY.SMIL.MIL

82AB

1BCT82AB

1BCT82AB.DS.ARMY.MIL

1BCT82AB.DS.ARMY.SMIL.MIL

1BCT82AB

2BCT82AB

2BCT82AB.DS.ARMY.MIL

2BCT82AB.DS.ARMY.SMIL.MIL

2BCT82AB

3BCT82AB

3BCT82AB.DS.ARMY.MIL

3BCT82AB.DS.ARMY.SMIL.MIL

3BCT82AB

4BCT82AB

4BCT82AB.DS.ARMY.MIL

4BCT82AB.DS.ARMY.SMIL.MIL

4BCT82AB

82CAB82AB

82CAB82AB.DS.ARMY.MIL

82CAB82AB.DS.ARMY.SMIL.MIL

82CAB82AB

101AA

101AA.DS.ARMY.MIL

101AA.DS.ARMY.SMIL.MIL

101AA

1BCT101AA

1BCT101AA.DS.ARMY.MIL

1BCT101AA.DS.ARMY.SMIL.MIL

1BCT101AA

2BCT101AA

2BCT101AA.DS.ARMY.MIL

2BCT101AA.DS.ARMY.SMIL.MIL

2BCT101AA

3BCT101AA

3BCT101AA.DS.ARMY.MIL

3BCT101AA.DS.ARMY.SMIL.MIL

3BCT101AA

4BCT101AA

4BCT101AA.DS.ARMY.MIL

4BCT101AA.DS.ARMY.SMIL.MIL

4BCT101AA

101CAB101AA

101CAB101AA.DS.ARMY.MIL

101CAB101AA.DS.ARMY.SMIL.MIL

101CAB101AA

159CAB101AA

159CAB101AA.DS.ARMY.MIL

159CAB101AA.DS.ARMY.SMIL.MIL

159CAB101AA

Separate Brigades

173ABBCT

173ABBCT.DS.ARMY.MIL

173ABBCT.DS.ARMY.SMIL.MIL

173ABBCT

2ACRCT

2ACRCT.DS.ARMY.MIL

2ACRCT.DS.ARMY.SMIL.MIL

2ACRCT

3ACRCT

3ACRCT.DS.ARMY.MIL

3ACRCT.DS.ARMY.SMIL.MIL

3ACRCT

11ACRCT

11ACRCT.DS.ARMY.MIL

11ACRCT.DS.ARMY.SMIL.MIL

11ACRCT

12CAB

12CAB.DS.ARMY.MIL

12CAB.DS.ARMY.SMIL.MIL

12CAB

Fires Brigades

4FSBDE

4FSBDE.DS.ARMY.MIL

4FSBDE.DS.ARMY.SMIL.MIL

4FSBDE

17FSBDE

17FSBDE.DS.ARMY.MIL

17FSBDE.DS.ARMY.SMIL.MIL

17FSBDE

18FSBDE

18FSBDE.DS.ARMY.MIL

18FSBDE.DS.ARMY.SMIL.MIL

18FSBDE

75FSBDE

75FSBDE.DS.ARMY.MIL

75FSBDE.DS.ARMY.SMIL.MIL

75FSBDE

212FSBDE

212FSBDE.DS.ARMY.MIL

212FSBDE.DS.ARMY.SMIL.MIL

212FSBDE

214FSBDE

214FSBDE.DS.ARMY.MIL

214FSBDE.DS.ARMY.SMIL.MIL

214FSBDE

CS Brigades (ME) (On 07 Nov 07, HQDA approved the re-designation of the Combat

Support Brigade (Maneuver Enhancement) to the "Maneuver Enhancement Brigade

(MEB)).

1CSBDEME

1CSBDEME.DS.ARMY.MIL

1CSBDEME.DS.ARMY.SMIL.MIL

1CSBDEME

2CSBDEME

2CSBDEME.DS.ARMY.MIL

2CSBDEME.DS.ARMY.SMIL.MIL

2CSBDEME

19 November 2008

FM 6-02.71

A-15

FOR OFFICIAL USE ONLY

Appendix A

3CSBDEME

3CSBDEME.DS.ARMY.MIL

3CSBDEME.DS.ARMY.SMIL.MIL

3CSBDEME

Table A-2. Forest names, domain names, and exchange organization names

of active component tactical deployable units (continued)

Exchange

NIPR Domain name (one per

SIPR Domain name (one per

Forest Name

Organization name

forest only)

SIPR and NIPR

Sustainment Brigades

1CSBDE

1CSBDE.DS.ARMY.MIL

1CSBDE.DS.ARMY.SMIL.MIL

1CSBDE

3CSBDE

3CSBDE.DS.ARMY.MIL

3CSBDE.DS.ARMY.SMIL.MIL

3CSBDE

4CSBDE

4CSBDE.DS.ARMY.MIL

4CSBDE.DS.ARMY.SMIL.MIL

4CSBDE

7CSBDE

7CSBDE.DS.ARMY.MIL

7CSBDE.DS.ARMY.SMIL.MIL

7CSBDE

10CSBDE

10CSBDE.DS.ARMY.MIL

10CSBDE.DS.ARMY.SMIL.MIL

10CSBDE

15CSBDE

15CSBDE.DS.ARMY.MIL

15CSBDE.DS.ARMY.SMIL.MIL

15CSBDE

16CSBDE

16CSBDE.DS.ARMY.MIL

16CSBDE.DS.ARMY.SMIL.MIL

16CSBDE

29CSBDE

29CSBDE.DS.ARMY.MIL

29CSBDE.DS.ARMY.SMIL.MIL

29CSBDE

43CSBDE

43CSBDE.DS.ARMY.MIL

43CSBDE.DS.ARMY.SMIL.MIL

43CSBDE

45CSBDE

45CSBDE.DS.ARMY.MIL

45CSBDE.DS.ARMY.SMIL.MIL

45CSBDE

64CSBDE

64CSBDE.DS.ARMY.MIL

64CSBDE.DS.ARMY.SMIL.MIL

64CSBDE

82CSBDE

82CSBDE.DS.ARMY.MIL

82CSBDE.DS.ARMY.SMIL.MIL

82CSBDE

101CSBDE

101CSBDE.DS.ARMY.MIL

101CSBDE.DS.ARMY.SMIL.MIL

101CSBDE

501CSBDE

501CSBDE.DS.ARMY.MIL

501CSBDE.DS.ARMY.SMIL.MIL

501CSBDE

507CSBDE

507CSBDE.DS.ARMY.MIL

507CSBDE.DS.ARMY.SMIL.MIL

507CSBDE

593CSBDE

593CSBDE.DS.ARMY.MIL

593CSBDE.DS.ARMY.SMIL.MIL

593CSBDE

Table A-3. Forest names, domain names, and exchange organization names

of National Guard tactical deployable units

Exchange

NIPR Domain name (one

SIPR Domain name (one per

Forest Name

Organization name

per forest only)

forest only)

SIPR and NIPR

Divisions

28ID

28ID.DS.ARMY.MIL

28ID.DS.ARMY.SMIL.MIL

28ID

2BCT28ID

2BCT28ID.DS.ARMY.MIL

2BCT28ID.DS.ARMY.SMIL.MIL

2BCT28ID

55BCT28ID

55BCT28ID.DS.ARMY.MIL

55BCT28ID.DS.ARMY.SMIL.MIL

55BCT28ID

56BCT28ID

56BCT28ID.DS.ARMY.MIL

56BCT28ID.DS.ARMY.SMIL.MIL

56BCT28ID

28CAB28ID

28CAB28ID.DS.ARMY.MIL

28CAB28ID.DS.ARMY.SMIL.MIL

28CAB28ID

29ID

29ID.DS.ARMY.MIL

29ID.DS.ARMY.SMIL.MIL

29ID

116BCT29ID

116BCT29ID.DS.ARMY.MIL

116BCT29ID.DS.ARMY.SMIL.MIL

116BCT29ID

29CAB29ID

29CAB29ID.DS.ARMY.MIL

29CAB29ID.DS.ARMY.SMIL.MIL

29CAB29ID

34ID

34ID.DS.ARMY.MIL

34ID.DS.ARMY.SMIL.MIL

34ID

1BCT34ID

1BCT34ID.DS.ARMY.MIL

1BCT34ID.DS.ARMY.SMIL.MIL

1BCT34ID

2BCT34ID

2BCT34ID.DS.ARMY.MIL

2BCT34ID.DS.ARMY.SMIL.MIL

2BCT34ID

34CAB34ID

34CAB34ID.DS.ARMY.MIL

34CAB34ID.DS.ARMY.SMIL.MIL

34CAB34ID

35ID

35ID.DS.ARMY.MIL

35ID.DS.ARMY.SMIL.MIL

35ID

35CAB35ID

35CAB35ID.DS.ARMY.MIL

35CAB35ID.DS.ARMY.SMIL.MIL

35CAB35ID

36ID

36ID.DS.ARMY.MIL

36ID.DS.ARMY.SMIL.MIL

36ID

A-16

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Active Directory

56BCT36ID

56BCT36ID.DS.ARMY.MIL

56BCT36ID.DS.ARMY.SMIL.MIL

56BCT36ID

Table A-3. Forest names, domain names, and exchange organization names

of National Guard tactical deployable units (continued)

Exchange

NIPR Domain name (one

SIPR Domain name (one per

Forest Name

Organization name

per forest only)

forest only)

SIPR and NIPR

72BCT36ID

72BCT36ID.DS.ARMY.MIL

72BCT36ID.DS.ARMY.SMIL.MIL

72BCT36ID

36CAB36ID

36CAB36ID.DS.ARMY.MIL

36CAB36ID.DS.ARMY.SMIL.MIL

36CAB36ID

38ID

38ID.DS.ARMY.MIL

38ID.DS.ARMY.SMIL.MIL

38ID

38CAB38ID

38CAB38ID.DS.ARMY.MIL

38CAB38ID.DS.ARMY.SMIL.MIL

38CAB38ID

40ID

40ID.DS.ARMY.MIL

40ID.DS.ARMY.SMIL.MIL

40ID

2BCT40ID

2BCT40ID.DS.ARMY.MIL

2BCT40ID.DS.ARMY.SMIL.MIL

2BCT40ID

40CAB40ID

40CAB40ID.DS.ARMY.MIL

40CAB40ID.DS.ARMY.SMIL.MIL

40CAB40ID

42ID

42ID.DS.ARMY.MIL

42ID.DS.ARMY.SMIL.MIL

42ID

27BCT42ID

27BCT42ID.DS.ARMY.MIL

27BCT42ID.DS.ARMY.SMIL.MIL

27BCT42ID

42CAB42ID

42CAB42ID.DS.ARMY.MIL

42CAB42ID.DS.ARMY.SMIL.MIL

42CAB42ID

Separate Brigades

116ACRCT

116ACRCT.DS.ARMY.MIL

116ACRCT.DS.ARMY.SMIL.MIL

116ACRCT

149BCT

149BCT.DS.ARMY.MIL

149BCT.DS.ARMY.SMIL.MIL

149BCT

155BCT

155BCT.DS.ARMY.MIL

155BCT.DS.ARMY.SMIL.MIL

155BCT

207BCT

207BCT.DS.ARMY.MIL

207BCT.DS.ARMY.SMIL.MIL

207BCT

218BCT

218BCT.DS.ARMY.MIL

218BCT.DS.ARMY.SMIL.MIL

218BCT

256BCT

256BCT.DS.ARMY.MIL

256BCT.DS.ARMY.SMIL.MIL

256BCT

26BCT

26BCT.DS.ARMY.MIL

26BCT.DS.ARMY.SMIL.MIL

26BCT

278ACRCT

278ACRCT.DS.ARMY.MIL

278ACRCT.DS.ARMY.SMIL.MIL

278ACRCT

29BCT

29BCT.DS.ARMY.MIL

29BCT.DS.ARMY.SMIL.MIL

29BCT

30BCT

30BCT.DS.ARMY.MIL

30BCT.DS.ARMY.SMIL.MIL

30BCT

32BCT

32BCT.DS.ARMY.MIL

32BCT.DS.ARMY.SMIL.MIL

32BCT

33BCT

33BCT.DS.ARMY.MIL

33BCT.DS.ARMY.SMIL.MIL

33BCT

37BCT

37BCT.DS.ARMY.MIL

37BCT.DS.ARMY.SMIL.MIL

37BCT

39BCT

39BCT.DS.ARMY.MIL

39BCT.DS.ARMY.SMIL.MIL

39BCT

41BCT

41BCT.DS.ARMY.MIL

41BCT.DS.ARMY.SMIL.MIL

41BCT

45BCT

45BCT.DS.ARMY.MIL

45BCT.DS.ARMY.SMIL.MIL

45BCT

48BCT

48BCT.DS.ARMY.MIL

48BCT.DS.ARMY.SMIL.MIL

48BCT

50BCT

50BCT.DS.ARMY.MIL

50BCT.DS.ARMY.SMIL.MIL

50BCT

53BCT

53BCT.DS.ARMY.MIL

53BCT.DS.ARMY.SMIL.MIL

53BCT

58BCT

58BCT.DS.ARMY.MIL

58BCT.DS.ARMY.SMIL.MIL

58BCT

76BCT

76BCT.DS.ARMY.MIL

76BCT.DS.ARMY.SMIL.MIL

76BCT

81BCT

81BCT.DS.ARMY.MIL

81BCT.DS.ARMY.SMIL.MIL

81BCT

86BCT

86BCT.DS.ARMY.MIL

86BCT.DS.ARMY.SMIL.MIL

86BCT

92BCT

92BCT.DS.ARMY.MIL

92BCT.DS.ARMY.SMIL.MIL

92BCT

19 November 2008

FM 6-02.71

A-17

FOR OFFICIAL USE ONLY

Appendix A

Table A-3. Forest names, domain names, and exchange organization names

of National Guard tactical deployable units (continued)

Exchange

NIPR Domain name (one

SIPR Domain name (one per

Forest Name

Organization name

per forest only)

forest only)

SIPR and NIPR

Fires Brigades

45FSBDE

45FSBDE.DS.ARMY.MIL

45FSBDE.DS.ARMY.SMIL.MIL

45FSBDE

65FSBDE

65FSBDE.DS.ARMY.MIL

65FSBDE.DS.ARMY.SMIL.MIL

65FSBDE

138FSBDE

138FSBDE.DS.ARMY.MIL

138FSBDE.DS.ARMY.SMIL.MIL

138FSBDE

142FSBDE

142FSBDE.DS.ARMY.MIL

142FSBDE.DS.ARMY.SMIL.MIL

142FSBDE

169FSBDE

169FSBDE.DS.ARMY.MIL

169FSBDE.DS.ARMY.SMIL.MIL

169FSBDE

197FSBDE

197FSBDE.DS.ARMY.MIL

197FSBDE.DS.ARMY.SMIL.MIL

197FSBDE

CS Brigades (ME)

110CSBDEME

110CSBDEME.DS.ARMY.MIL

110CSBDEME.DS.ARMY.SMIL.MIL

110CSBDEME

111CSBDEME

111CSBDEME.DS.ARMY.MIL

111CSBDEME.DS.ARMY.SMIL.MIL

111CSBDEME

130CSBDEME

130CSBDEME.DS.ARMY.MIL

130CSBDEME.DS.ARMY.SMIL.MIL

130CSBDEME

136CSBDEME

136CSBDEME.DS.ARMY.MIL

136CSBDEME.DS.ARMY.SMIL.MIL

136CSBDEME

142CSBDEME

142CSBDEME.DS.ARMY.MIL

142CSBDEME.DS.ARMY.SMIL.MIL

142CSBDEME

157CSBDEME

157CSBDEME.DS.ARMY.MIL

157CSBDEME.DS.ARMY.SMIL.MIL

157CSBDEME

225CSBDEME

225CSBDEME.DS.ARMY.MIL

225CSBDEME.DS.ARMY.SMIL.MIL

225CSBDEME

Sustainment Brigades

34CSBDE

34CSBDE.DS.ARMY.MIL

34CSBDE.DS.ARMY.SMIL.MIL

34CSBDE

36CSBDE

36CSBDE.DS.ARMY.MIL

36CSBDE.DS.ARMY.SMIL.MIL

36CSBDE

38CSBDE

38CSBDE.DS.ARMY.MIL

38CSBDE.DS.ARMY.SMIL.MIL

38CSBDE

40CSBDE

40CSBDE.DS.ARMY.MIL

40CSBDE.DS.ARMY.SMIL.MIL

40CSBDE

67CSBDE

67CSBDE.DS.ARMY.MIL

67CSBDE.DS.ARMY.SMIL.MIL

67CSBDE

108CSBDE

108CSBDE.DS.ARMY.MIL

108CSBDE.DS.ARMY.SMIL.MIL

108CSBDE

230CSBDE

230CSBDE.DS.ARMY.MIL

230CSBDE.DS.ARMY.SMIL.MIL

230CSBDE

287CSBDE

287CSBDE.DS.ARMY.MIL

287CSBDE.DS.ARMY.SMIL.MIL

287CSBDE

369CSBDE

369CSBDE.DS.ARMY.MIL

369CSBDE.DS.ARMY.SMIL.MIL

369CSBDE

371CSBDE

371CSBDE.DS.ARMY.MIL

371CSBDE.DS.ARMY.SMIL.MIL

371CSBDE

Table A-4 Forest names, domain names, and exchange organization names

of US Army Reserve tactical deployable units

Exchange

NIPR Domain name (one

SIPR Domain name (one per

Forest Name

Organization name

per forest only)

forest only)

SIPR and NIPR

CS Brigades (ME)

301CSBDEME

301CSBDEME.DS.ARMY.MIL

301CSBDEME.DS.ARMY.SMIL.MIL

301CSBDEME

302CSBDEME

302CSBDEME.DS.ARMY.MIL

302CSBDEME.DS.ARMY.SMIL.MIL

302CSBDEME

303CSBDEME

303CSBDEME.DS.ARMY.MIL

303CSBDEME.DS.ARMY.SMIL.MIL

303CSBDEME

Sustainment Brigades

55CSBDE

55CSBDE.DS.ARMY.MIL

55CSBDE.DS.ARMY.SMIL.MIL

55CSBDE

158CSBDE

158CSBDE.DS.ARMY.MIL

158CSBDE.DS.ARMY.SMIL.MIL

158CSBDE

A-18

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Active Directory

Table A-4 Forest names, domain names, and exchange organization names

of US Army Reserve tactical deployable units (continued)

Exchange

NIPR Domain name (one

SIPR Domain name (one per

Forest Name

Organization name

per forest only)

forest only)

SIPR and NIPR

162CSBDE

162CSBDE.DS.ARMY.MIL

162CSBDE.DS.ARMY.SMIL.MIL

162CSBDE

164CSBDE

164CSBDE.DS.ARMY.MIL

164CSBDE.DS.ARMY.SMIL.MIL

164CSBDE

300CSBDE

300CSBDE.DS.ARMY.MIL

300CSBDE.DS.ARMY.SMIL.MIL

300CSBDE

304CSBDE

304CSBDE.DS.ARMY.MIL

304CSBDE.DS.ARMY.SMIL.MIL

304CSBDE

321CSBDE

321CSBDE.DS.ARMY.MIL

321CSBDE.DS.ARMY.SMIL.MIL

321CSBDE

474CSBDE

474CSBDE.DS.ARMY.MIL

474CSBDE.DS.ARMY.SMIL.MIL

474CSBDE

A-40. Tables A-5 through A-7 are the abbreviations used in Tables A-2 through A-4, respectively.

Table A-5. Abbreviations for Table A-2

Active Component

Abbreviation

1st Armored Division

1AD

1st Cavalry Division

1CD

1st Infantry Division

1ID

2d Infantry Division

2ID

3d Infantry Division

3ID

4th Infantry Division

4ID

7th Infantry Division

7ID

10th Infantry Division

10ID

24th Infantry Division

24ID

25th Infantry Division

25ID

82d Airborne Division

82AB

101st Air Assault Division

101AA

Table A-6. Abbreviations for Table A-3

Army National Guard/Reserve

Abbreviation

28th Infantry Division

28ID

29th Infantry Division

29ID

34th Infantry Division

34ID

35th Infantry Division

35ID

36th Infantry Division (old 49AD)

36ID

38th Infantry Division

38ID

40th Infantry Division

40ID

42d Infantry Division

42ID

19 November 2008

FM 6-02.71

A-19

FOR OFFICIAL USE ONLY

Appendix B

NETWORK OPERATIONS SYSTEMS AND TOOLS

This appendix addresses the different systems and tools available to perform the

required NETOPS functions. It is separated by the tools used in the A-GNOSC and

TNOSC and into three other distinct areas: ESM/NM, IA/CND, and IDM/CS.

APPROVED NETWORK OPERATIONS TOOLS FOR NETWORK

OPERATIONS AND SECURITY CENTERS.

B-1. The list in Table B-1 defines the minimum approved NETOPS tools for use in the AGNOSCs and

TNOSCs with respect to capabilities outlined in the AENIA. This list will be reviewed on a quarterly basis

or sooner, if required.

B-2. The NETCOM Chief, NETOPS Planning Division will establish an action officer level NOSC

working group under the AEI Technical Configuration Control Board. The NOSC working group will

include representation from the requirements, material development and user communities. The NOSC

working group will establish specific CIs; manage specific changes and updates to the listed set of tools via

a CM process.

B-3. NOSCs not operating on these standard tools will develop migration plans ICW the NOSC working

group to comply with the stated standard.

B-4. Functional Proponent for the AENIA and NOSC NETOPS tools is the chief, NETOPS planning

division NETCOM at commercial: (520) 533-1 852, DSN: 821-1852.

Table B-1. A-GNOSC and TNOSC NETOPS tools list

AENIA Capability

Capability Description

NOSC Standard

Comments

Anti-Virus (Anti-

This system provides an

Three DOD Anti-Virus

McAfee ePolicy

Malware)

enterprise view and

standards: Symantec,

Orchestrator

management capability

McAfee, and TrendMicro.

Entercept is

for anti-virus and anti-

undergoing

malware.

DISA/Army pilot.

DOD CND enterprise-wide

solutions steering group has

selected McAfee ePolicy

Orchestrator Entercept as

standard for Host-Based

Security System which

includes anti-virus

management and Computer

Associates Pest Patrol to

provide a standard

Adware/Spyware capability.

19 November 2008

FM 6-02.71

B-1

FOR OFFICIAL USE ONLY

Appendix B

Table B-1. A-GNOSC and TNOSC NETOPS tools list (continued)

AENIA Capability

Capability Description

NOSC Standard

Comments

Capacity,

This system provides the

eHealth (Computer

Additional

Availability and

capability to monitor and

Associates)

capacity,

Performance

analyze capacity and

availability and

Monitoring

availability information

performance

System

collected by other

monitoring tool

systems and stored in

standards are

this system.

anticipated to

support this

capability.

This system provides a

Remedy Information

Database/Support

great deal of

Technology Service

System

functionality. The

Management

functionality can be

broken down into 4

broad areas:

incident/problem/service

request management,

operational asset

management, change

management and other

supporting features.

Host IDS

This system provides the

Symantec Intruder

The current

capability for an agent to

Alert/Enterprise Security

standard for Host

monitor host activities

Manager DOD CND

IDS/ Host

and identify those

enterprise-wide solutions

Intrusion

activities that have been

steering group has selected

Prevention

identified as being

McAfee ePolicy

System is

potentially hostile. The

Orchestrator/Entercept as

Symantec Intruder

potentially hostile

standard under the Host-

Alert/Enterprise

activities are reported to

Based Security System

Security Manager.

a management console

initiative to provide a standard

for analysis.

host intrusion detection and

NETCOM will

host-based firewall capability.

migrate to the

DISA/Army Host-

Based Security

System standard

upon successful

completion of the

DISN/Army pilot.

B-2

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

NETWORK OPERATIONS SYSTEMS AND TOOLS

Table B-1. A-GNOSC and TNOSC NETOPS tools list (continued)

AENIA Capability

Capability Description

NOSC Standard

Comments

Host Intrusion

This system provides the

Symantec Intruder

The current

Prevention

capability for an agent to

Alert/Enterprise Security

standard for Host

System

monitor host activities

Manager DOD CND

IDS/Host Intrusion

and identify potentially

enterprise-wide solutions

Prevention

hostile activities.

steering group has selected

System is

Predefined remedial

McAfee ePolicy

Symantec Intruder

actions are then taken to

Orchestrator/Entercept as

Alert/Enterprise

mitigate the impact of

standard under the Host-

Security Manager.

these activities on the

Based Security System

operational system. The

initiative to provide a standard

NETCOM will

identification and

host intrusion prevention and

migrate to the

mitigation of potentially

host-based firewall capability.

DISA/Army Host-

hostile activities are

Based Security

reported to a

System standard

management console for

upon successful

analysis.

completion of the

DISA/Army pilot.

IP Network

This system provides a

Spectrum Network

Management

network monitoring and

Management System

System

graphical display

(Computer Associates)

capability. It is the only

system that collects

Simple Network

Management Protocol

data from devices

connected to the

network.

This system provides the

Formula (Managed Objects)

capability for non-IT staff

to understand the impact

of IT services on the

theater's operational

mission. It receives

status information from

sources external to the

Army from the Army

level situation

awareness System. The

situation awareness at

the Army level receives

status information from

sources external to the

Army and passes this

external status

information to the

theater situation

awareness.

19 November 2008

FM 6-02.71

B-3

FOR OFFICIAL USE ONLY

Appendix B

Table B-1. A-GNOSC and TNOSC NETOPS tools list (continued)

AENIA Capability

Capability Description

NOSC Standard

Comments

Network IDS

This system provides the

Internet Security Systems

NETCOM has

capability for an agent or

SiteProtector; Snort

initiated a plan to

device to monitor

replace existing

network traffic and to

Network IDS with

identify traffic that has

Network Intrusion

been identified as being

Prevention

potentially hostile. The

Systems.

potentially hostile traffic

is reported to a

management console for

analysis.

Network Intrusion

This system provides the

To Be Determined

NETCOM has

Prevention

capability for an agent or

initiated a plan to

System

device to monitor

replace existing

network traffic and to

Network IDSs with

identify and mitigate

Network Intrusion

traffic that has been

Prevention

identified as being

Systems.

potentially hostile. The

potentially hostile traffic

is reported to a

management console for

analysis

Secure

This system provides the

Citadel Hercules

Configuration

capability to define

selected by DOD

Remediation

configuration conditions

CND enterprise-

Windows Environment-

(Patch)

and responses. It may

wide solutions

Microsoft Systems

Management

change system

steering group.

Management Server

configuration or install

DOD acquisition

patches to existing

includes

software.

Enterprise

License for

software, and on-

line training.

Systems

Management

Server 3rd Party

Bolt-on being

considered for

Non-Windows

Environment

Enterprise

solution.

B-4

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

NETWORK OPERATIONS SYSTEMS AND TOOLS

Table B-1. A-GNOSC and TNOSC NETOPS tools list (continued)

AENIA Capability

Capability Description

NOSC Standard

Comments

Security

This system provides the

Arcsight (Arcsight)

DOD CND

Information

capability to receive

enterprise-wide

Management

events from a large

solutions steering

System

number of other

group is currently

commercial operations

researching a Tier

and security related

3 Systems

products. These events

Management

are then correlated to all

Server solution to

of the other events it has

support

received from all of its

post/camp/station

other sources.

and enclaves.

Systems

This system provides the

Windows Desktop

Systems

Management

capability to monitor and

Environment-Microsoft

Management

manage various aspects

Systems Management Server

Server/Microsoft

of computing platforms

Operations

(both servers and

Management 3rd

Windows Server

desktops). It provides an

Party Bolt-on

Environment-Microsoft

inventory and

being considered

Systems Management Server

configuration capability,

for Non-Windows

and Microsoft Operations

a software distribution

Environment

Management

capability, and a

Enterprise

condition monitoring

solution.

capability.

IP Network

This system provides the

eEye Retina

Vulnerability

capability to define a

selected by DOD

Scanner

number of different

CND enterprise-

scanning profiles. These

wide solutions

scanning profiles should

steering group.

be related to the

DOD acquisition

compliance baselines

includes

established in the

Enterprise

compliance manager.

License for

The system then

software, and on-

interrogates systems

line training.

using a number of

different means to

determine how

vulnerable the system is

to the scanning criteria.

GLOBAL INFORMATION GRID ENTERPRISE MANAGEMENT AND

LANDWARNET SYSTEMS AND TOOLS

B-5. The ESM/NM and LWN systems and tools will be available to the management personnel. Many of

the systems and tools may be listed more than once due to the tool being a subsystem to other management

systems as well as a stand alone tool used for other functions in the networks. The NM/ESM and LWN

systems and tools are:

CISCO Call Manager is a software-based call processing component providing signaling and call

control services to Cisco integrated telephony applications (e.g., VG-248 subscribers, Cisco IP

Phones, or Cisco IP softphones). The Call Manager also registers with the Vantage as a gateway.

19 November 2008

FM 6-02.71

B-5

FOR OFFICIAL USE ONLY

Appendix B

The JNN Call Manager is physically associated to a particular security domain by keyboard

video monitor and Ethernet connectivity to that domain. The JNN Call Manager software

function is hosted on a rack mounted computer and has a single Ethernet connection to the Tier 2

router Ethernet switch module. There are two Call Managers in the shelter: one dedicated for

NIPR and another for SIPR.

Cisco Call Manager Version 3.3(2) software provides the call management function. The Cisco

Call Manager’s primary functions are: call processing, signaling and device control, dial plan

administration, and phone feature administration. The Cisco Call Manager is a main component

in the shelter voice architecture.

B-6. Network Management-Element and Node Planning and Management platform is present within each

security domain

(NIPR and SIPR). The node manager provides monitoring and control capabilities

reporting on the condition of the router and network components. In addition, the node manager platform

provides the capability to build and save Cisco device configurations (router's and firewall) based upon

mission specific criteria. A Denika Multi-Router Traffic Grapher application shall be provided for the

purpose of monitoring bandwidth utilization. The JNN manager platform is designed to operate on a laptop

computer with the following software installed:

Ciscoworks for Small Network Management Systems includes:

Resource Manager Essentials 3.3.

CiscoView 5.3.

WhatsUp Gold.

Multi-Router Traffic Grapher v3.0.1.210.

Warfighter Machine Interface.

B-7. CiscoWorks for Small Network Management Systems is an end-to-end network management

solution. It is ideal for small networks that may include two or three branches. It also provides management

capabilities that simplify network administration. CiscoWorks for Small Network Management Systems

enables network operators to efficiently and effectively manage the network through a simplified browser-

based interface that can be accessed anytime and anywhere within the network. CiscoWorks for Small

Network Management Systems provides tools that make the job of configuring, monitoring, and

troubleshooting routers and switches quicker in order to reduce the likelihood of human errors.

B-8. The functionality of CiscoWorks for Small Network Management Systems can be categorized under

three functional areas: network discovery and policy management, device configuration, and device

management. Network discovery and policy management is performed using the WhatsUp Gold software

package. Device configuration tasks are performed using the CiscoView software package, and device

management is performed using the Resource Manager Essentials software package.

B-9. Resource Manager Essentials 3.3 is a suite of Web-based applications offering network management

solutions for Cisco switches, access servers, and routers. Resource Manager Essentials is comprised of

several applications which are discussed below.

B-10. The inventory manager, is responsible for—

Up-to-date inventory of all Cisco devices in the network.

Hardware and software summary information as well as detailed reports for groups of devices,

including device name, chassis type, memory, flash, and software version or characteristics.

Capacity planning information by identifying the total number of free and used slots in many

Cisco devices.

Multi-service port report on the number and location of Catalyst® switches that are multi-service

port-enabled.

B-11. The device configuration manager maintains an active archive and simplifies deployment of

configuration changes to multiple devices. It consists of the following subcomponents:

Configuration Archive—

B-6

FM 6-02.71

19 November 2008

FOR OFFICIAL USE ONLY

Military reference books and manuals (2009-2023, Volume 7) - page 32
