DB2 Server for VSE. Operations Guide / Handbooks (2004-2007)

ddname, CMS FILEDEF command information for DATALOAD

command processing must be identical to the information in the

FILEDEF command used when DATAUNLOAD command processing

created the file. See Appendix B, “FILEDEF Command Syntax and

Notes,” on page 249 for more information about undefined (U) record

format usage.

The length of the output record supplied by the FILEDEF must be long enough

to contain column data selected for unload (including intervening data field

blanks if the default format is used). If it is not, a Database Services Utility

processing error occurs. If the length of the output record is greater than the

length required to unload the data, the remaining positions of the output

record are set to blanks (hex 40).

If variable length output records are used, the data fields referenced by DFI

subcommands appear in the same positions on each output data record.

Do not specify SYSIN or SYSPRINT as the ddname.

in DB2 Server for VSE: this is the TLBL or DLBL job control statement file name

for the sequential (SAM) output file. This parameter must be the first parameter

specified; you cannot specify BLKSZ before the ddname. The other keyword

parameters can be specified in any order.

BLKSZ (size)

is an optional parameter that specifies the block size of the sequential output

file.

If a tape output file is used, performance can be improved by using a large

block size value (greater than 8244).

The default block size values depend upon the output file record format:

v If RECFM = F or FB, the default block size is equal to the highest data field

end-position value

v If RECFM = V or VB, the default block size is equal to the highest data field

end-position value plus four

v If RECFM = S or SB, the default block size is 2048 bytes.

PDEV (TAPE or DASD)

is an optional parameter that specifies the device type (DASD or TAPE) of the

sequential (SAM) output file. If PDEV(DASD) is specified, the file resides on

any device supported by the VSE DTFSD macro. An exception to this is

VSAM-managed SAM files. VSAM-managed SAM does not support spanned

records. If PDEV(TAPE) is specified, the file resides on any device supported

by the VSE DTFMT macro. The default is PDEV(TAPE).

NOREWIND or REWIND

controls tape file rewind processing performed during CLOSE processing.

This parameter is valid only if you specify TAPE for PDEV. The default is

NOREWIND.

NOREWIND

specifies that the tape file will not be rewound by CLOSE processing.

REWIND

specifies that the tape file is rewound by CLOSE processing.

RECFM (format)

is an optional parameter that specifies the format of the records in the output

data file. For format, substitute one of the following values:

178

Database Services Utility

Value

Meaning

fixed, unblocked

fixed, blocked

variable length, unblocked

variable length, blocked

variable spanned, unblocked

variable spanned, blocked

If the length of the logical record (RECSZ) is equal to or less than 32760, the

default is RECFM(F). Otherwise, the default is RECFM(SB). The output record

format is identified in a Database Services Utility informational message.

Note: If variable-length output records are used, the data fields referenced by

the DFI subcommands will be in the same position for each occurrence

of a data record. Positions 1-4 of each variable-length record contain

record length control information.

RECSZ (size)

is an optional parameter that specifies the length of a logical record for the

output data file. The length of the output record must be long enough to

contain column data selected for DATAUNLOAD processing (including

intervening data field blanks if the default format is used). If it is not, a

Database Services Utility processing error occurs.

The default record size values depend upon the output file record format:

v If RECFM = F or FB, the default record size is the block size.

v If RECFM = V or VB, the default record size is the block size minus four.

v If RECFM = S or SB, the default record size is equal to the highest data field

end-position value.

DATAUNLOAD Output Data Field Defaults

If no DFI commands are supplied, the output data fields appear in the output

record in the same order as the associated columns in the select-list. The output

data field associated with the first select-list column starts in position 1 of the fixed

length output records or position 5 of variable length (or variable length spanned)

output records. Positions 1-4 of variable length or variable length spanned records

are reserved for the record length control field. In DB2 Server for VSE, if the record

format (RECFM) is not supplied by the OUTFILE subcommand, DATAUNLOAD

processing writes either fixed length or variable length spanned output records.

Fixed length records are written if the required logical record length is less than

32760 positions; otherwise, variable length spanned records (RECFM=S) are

written.

In DB2 Server for VM, the DFI subcommand will refer to the first data position as

startpos 5. The FILEDEF command that defines the output file always supplies the

record format information.

One blank (hex 40) position separates each output record data field. The output

data field associated with the next select-list column starts two positions after the

trailing (low-order) position of the data field derived from the preceding select-list

column.

Chapter 8. Command Reference

179

data from

blank

data from

blank

data from

select-list

column 1

column 2

column n

Position 1

Figure 91. Default Fixed-Length Output Logical Record Content

record

data from

blank

data from

blank

data from

length

select-list

control

column 1

column 2

column n

field

Position 5

Position 1

Figure 92. Default Variable-Length Spanned Logical Output Record Content

Default Output Data Field Formats: Table 10 on page 181 summarizes the default

output field formats generated by the DATAUNLOAD processing if no DFI

subcommands are supplied. The default data type of the output data field is

CHAR (or GRAPHIC if the source column contains DBCS data). The format of the

data in the output data field depends on the data type, length, or maximum length

of the select-list column from which the data is derived.

180

Database Services Utility

Table 10. Default Output Formats

Default Database Services Utility DATAUNLOAD Output Data Fields

Source Column Data Type

Default Data Type = CHAR

CHAR

Length: Defined length of source column.

VARCHAR length <= 254

Length: Defined maximum length of column.

Note: If the actual length of an occurrence of the column data is less than

the defined maximum length of the column, the data is left-justified in the

output data field and padded with trailing (low-order) blanks.

VARCHAR length > 254 or LONG

Length: 512 positions (bytes).

VARCHAR

Notes: If the actual length of an occurrence of the column data is greater

than 512, the column data is truncated.

If the actual length of an occurrence of the column data is less than 512, the

column data is left-justified and padded with trailing (low-order) blanks.

SMALLINT

Length: 6 Format: snnnnn

INTEGER

Length: 11 Format: snnnnnnnnnn

DECIMAL

Length: Precision of source column + 2.

Format: Examples:

Column Precision=7, Scale=2: snnnnn.nn

Column Precision=5, Scale=5: s.nnnnn

Note: NUMERIC is a synonym for DECIMAL.

REAL or FLOAT (N) 1 <= N <= 21

Length: 12 (single precision float).

Format: sn.nEsnbbbbb (minimum value) sn.nnnnnEsnn (maximum value)

Note: The value is left-justified and, if necessary, padded with trailing

(low-order) blanks in the output data field.

FLOAT or DOUBLE PRECISION or

Length: 20 (double precision float).

FLOAT (N) 22 <= N <= 53

Format: sn.nEsnbbbbbbbbbbbbb (minimum value) sn.nnnnnnnnnnnnnEsnn

(maximum value)

Note: The value is left-justified and, if necessary, padded with trailing

(low-order) blanks in the output data field.

Legend For FLOAT:

= EBCDIC SIGN: Plus (+) sign (hex 4E)

Minus (-) sign (hex 60)

Blank (hex 40) if null value.

n = EBCDIC numeric character (hex F0-F9)

= EBCDIC decimal point (hex 4B)

b = Blank (hex 40)

Chapter 8. Command Reference

181

Default Database Services Utility DATAUNLOAD Output Data

Source Column Data Type

Fields Default Data Type = CHAR

DATE

Default

DATE

length

format

ISO

yyyy-mm-dd

JIS

yyyy-mm-dd

EUR

dd.mm.yyyy

USA

mm/dd/yyyy

LOCAL

installation defined

yyyy

is the year

is the month

is the day

Note: The length and format of the output data field depends on

the default DATE for the database. You can query the

SYSTEM.SYSOPTIONS catalog to determine the output format for

DATE.

TIME

Default

TIME

length

format

ISO

hh.mm.ss

JIS

hh:mm:ss

EUR

hh.mm.ss

USA

hh.mm AM

(or hh.mm PM)

LOCAL

Installation defined

is the hour

0 <= hh <= 24 for ISO, JIS, EUR formats

0 <= hh <= 12 for USA format

mm is the minute

is the second

Note: The length and format of the output data field depends on

the default TIME for the database. You can query the

SYSTEM.SYSOPTIONS catalog to determine the output format for

TIME.

TIMESTAMP

Length: 26 Format: yyyy-mm-dd-hh.mm.ss.nnnnnn

yyyy-mm-dd

is the date (ISO format)

hh.mm.ss

is the time (ISO format)

nnnnnn

is the microsecond

GRAPHIC

Length: (Defined length of column * 2) + 2.

Note: The first position of the output record DBCS data field

contains an SO delimiter and the last position contains an SI

delimiter.

182

Database Services Utility

Default Database Services Utility DATAUNLOAD

Source Column Data Type

Output Data Fields Default Data Type = CHAR

VARGRAPHIC with defined length <= 127

Length: (Defined maximum length of column * 2) + 2.

Notes: The first position of the output record DBCS data

field contains an SO delimiter and the last position

contains an SI delimiter.

If the actual length of an occurrence of the DBCS column

data is less than the defined maximum length of the

column, the data is left-justified and padded with trailing

blanks in the second through n-1 positions of the output

record field.

VARGRAPHIC with defined length >127 or LONG

Length: 512 positions.

VARGRAPHIC

Notes: The first position of the output record DBCS field

contains an SO delimiter and the last position contains

an SI delimiter.

If the actual length of an occurrence of the DBCS column

data is greater than 510 (255 DBCS characters), the

column data is truncated.

If the actual length of an occurrence of the DBCS column

data is less than 510 (255 DBCS characters), the data is

left-justified and padded with trailing blanks in the

second through n-1 positions of the output record field.

DATAUNLOAD Default Output Record Format Example: This example unloads

data for the columns EMPNO, PROJNO, and EMPTIME in the tables EMP_ACT

and EMPLOYEE, based on the selection criteria specified in the WHERE clause.

The output records are generated in EMPNO value ascending sequence. Because

no DFI subcommands are present, the default DATAUNLOAD output record data

field format is used.

The DATAUNLOAD command sequence is:

DATAUNLOAD

SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME

FROM EMP_ACT,EMPLOYEE

WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

ORDER BY EMP_ACT.EMPNO;

OUTFILE(OUTPUT1)

Figure 93. DATAUNLOAD Command without DFI Subcommands

The Database Services Utility message file output that results is shown in the

following examples.

Chapter 8. Command Reference

183

ARI0801I DBS Utility started: 11/13/89 16:48:16.

AUTOCOMMIT = OFF ERRORMODE = OFF

ISOLATION LEVEL = REPEATABLE READ

——————>

——————> DATAUNLOAD

——————> SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME

——————> FROM EMP_ACT,EMPLOYEE

——————> WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

——————> ORDER BY EMP_ACT.EMPNO;

——————> OUTFILE(OUTPUT1)

ARI0852I DATAUNLOAD processing started.

┌────────┐

ARI0868I DNAME=OUTPUT1 RECFM=F RECSZ=80 BLKSIZE=80

◄──────┤See Note│

ARI0836I Default output record data field positions:

└────────┘

ARI0837I EMPNO 1-6

ARI0837I PROJNO 8-13

ARI0837I EMPTIME 15-21

ARI0835I 74 record(s) written to the output data file.

ARI0855I DATAUNLOAD processing successful.

ARI0802I End of command file input.

ARI8997I ...Begin COMMIT processing.

ARI0811I ...COMMIT of any database changes sucessful.

ARI0809I ...No error(s) occurred during command processing.

ARI0808I DBS processing completed: 11/13/89 16:48:20.

Figure 94. DB2 Server for VM Database Services Utility Message File Output

Note: The RECFM, RECSZ, and BLKSIZE information displayed in the message

ARI0868I depends on the CMS FILEDEF command specifications for the

output file with ddname=OUTPUT1.

ARI0801I DBS Utility started: 11/13/89 16:48:16.

AUTOCOMMIT = OFF ERRORMODE = OFF

ISOLATION LEVEL = REPEATABLE READ

-----—> CONNECT "SQLDBA " IDENTIFIED BY ********;

ARI8004I User SQLDBA connected to database SQLDBA.

ARI0500I SQL processing was successful.

ARI0505I SQLCODE = 0 SQLSTATE = 00000 ROWCOUNT = 0

-----—>

-----—> DATAUNLOAD

-----—> SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME

-----—> FROM EMP_ACT,EMPLOYEE

-----—> WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

-----—> ORDER BY EMP_ACT.EMPNO;

-----—> OUTFILE(OUTPUT1)

ARI0852I DATAUNLOAD processing started.

ARI0868I DNAME=OUTPUT1 RECFM=F RECSZ=80 BLKSIZE=80

ARI0836I Default output record data field positions:

ARI0837I EMPNO 1-6

ARI0837I PROJNO 8-13

ARI0837I EMPTIME 15-21

ARI0835I 74 record(s) written to the output data file.

ARI0855I DATAUNLOAD processing successful.

ARI0802I End of command file input.

ARI8997I ...Begin COMMIT processing.

ARI0811I ...COMMIT of any database changes sucessful.

ARI0809I ...No error(s) occurred during command processing.

ARI0808I DBS processing completed: 11/13/89 16:48:20.

Figure 95. DB2 Server for VSE Database Services Utility Report Output

184

Database Services Utility

The format of the records in the output file identified by the ddname OUTPUT1 is

shown in Table 11:

Table 11. Default Output Record Format

Data Value Source (Column or

Record Position

Other)

Output Record Field Data Type

1-6

EMPNO

CHAR

blank

CHAR

8-13

PROJNO

CHAR

blank

CHAR

15-21

EMPTIME

CHAR

DATAUNLOAD User-Specified Output Record Format Example: Figure 96

selects data for the columns EMPNO, PROJNO, and EMPTIME in the table

EMP_ACT, and data for the column JOB in the EMPLOYEE table based on the

selection criteria specified in the WHERE clause. Only data for the columns

EMPNO, PROJNO, and EMPTIME is unloaded because JOB does not have a DFI

subcommand. The output records are generated in EMPNO sequence.

The Database Services Utility DATAUNLOAD command sequence is:

DATAUNLOAD

SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME,JOB

FROM EMP_ACT,EMPLOYEE

WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

ORDER BY EMP_ACT.EMPNO;

EMPNO

1-6

PROJNO

8-13

EMPTIME

15-21

DECIMAL

IF NULL SET POS(22) = ’?’

OUTFILE(OUTPUT1)

Figure 96. DATAUNLOAD Command with DFI Subcommands

The Database Services Utility report or message file output generated as a result of

these commands is shown in the following:

Chapter 8. Command Reference

185

ARI0801I DBS Utility started: 10/05/89 14:54:41.

AUTOCOMMIT = OFF ERRORMODE = OFF

ISOLATION LEVEL = REPEATABLE READ

-----—> CONNECT "SQLDBA " IDENTIFIED BY ********;

ARI8004I User SQLDBA connected to database SQLDBA.

ARI0500I SQL processing was successful.

ARI0505I SQLCODE = 0 SQLSTATE = 00000 ROWCOUNT = 0

-----—>

ARI8003I ...Extended DBCS (DBCS=YES) processing was in effect.

-----—> DATAUNLOAD

-----—> SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME

-----—> FROM EMP_ACT,EMPLOYEE

-----—> WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

-----—> ORDER BY EMP_ACT.EMPNO;

-----—> EMPNO 1-6

-----—> PROJNO 8-13

-----—> EMPTIME 15-21

DECIMAL

IF NULL SET POS(22) = ’?’

-----—> OUTFILE(OUTPUT1)

ARI0831I Column JOB data will not be unloaded.

ARI0868I DNAME=OUTPUT1 RECFM=F RECSZ=80 BLKSIZE=80

ARI0835I 74 record(s) written to the output data file.

ARI0855I DATAUNLOAD processing successful.

ARI0802I End of command file input.

ARI8997I ...Begin COMMIT processing.

ARI0811I ...COMMIT of any database changes sucessful.

ARI0809I ...No error(s) occurred during command processing.

ARI0808I DBS processing completed: 10/05/89 14:54:44.

Figure 97. DB2 Server for VSE Database Services Utility Report Output

1ARI0801I DBS Utility started: 10/05/89 14:54:41.

AUTOCOMMIT = OFF ERRORMODE = OFF

ISOLATION LEVEL = REPEATABLE READ

ARI8003I ...Extended DBCS (DBCS=YES) processing was in effect.

0——————> DATAUNLOAD

——————> SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME,JOB

——————> FROM EMP_ACT,EMPLOYEE

——————> WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

——————> ORDER BY EMP_ACT.EMPNO;

——————> EMPNO 1-6

——————> PROJNO 8-13

——————> EMPTIME 15-21

DECIMAL IF NULL SET POS(22) = ’?’

——————> OUTFILE(OUTPUT1)

ARI0852I DATAUNLOAD processing started.

ARI0831I Column JOB data will not be unloaded.

┌───────────┐

ARI0868I DNAME=OUTPUT1 RECFM=F RECSZ=80 BLKSIZE=80

◄────┤ See Note │

ARI0835I 74 record(s) written to the output data file.

└───────────┘

ARI0855I DATAUNLOAD processing successful.

ARI0802I End of command file input.

ARI8997I ...Begin COMMIT processing.

ARI0811I ...COMMIT of any database changes sucessful.

ARI0809I ...No error(s) occurred during command processing.

ARI0808I DBS processing completed: 10/05/89 14:54:44.

Figure 98. DB2 Server for VM Database Services Utility Message File Output

Note: The RECFM, RECSZ, and BLKSIZE information displayed in the message

ARI0868I depends on the CMS FILEDEF command specifications for the

output file with ddname=OUTPUT1.

186

Database Services Utility

The format of the records in the output file identified by the ddname OUTPUT1 is

shown in Table 12.

Table 12. User-Defined Output Record Format

Record Position

Data Value Source (Column or Other)

Output Record Field Data Type

1-6

EMPNO

CHAR

blank

CHAR

8-13

PROJNO

CHAR

blank

CHAR

15-21

EMPTIME

DECIMAL

EMPTIME

CHAR

null indicator

DATAUNLOAD Data Conversion Summary

Table 13 summarizes the data conversion performed by Database Services Utility

DATAUNLOAD processing. Yes means that the utility performs the conversion. No

means that the utility cannot convert the source column data type into the data

type specified for the output record data field and that any attempt to do so results

in a Database Services Utility processing error. The numbers in the chart refer to

the notes below the figure.

Table 13. DATAUNLOAD Data Conversion Table

Source Column Data Type

CHAR,

DBCS,

VAR-

GRAPHIC,

CHAR,

VAR-

GRAPHIC,

LONG

DATE, TIME,

or LONG

Output Field

VAR-

SMALL-

Double

VAR-

Data Type

CHAR

DECIMAL⁸

INT

INTEGER

REAL¹²

Precision¹³

TIMESTAMP

GRAPHIC

CHAR

Yes¹

Yes^2,3

Yes^2,4

Yes^2,5

Yes¹

Yes

GRAPHIC (G)

Yes⁹

1-Byte FIXED

Yes⁶

2-Byte FIXED

Yes⁶

4-Byte FIXED

Yes⁶

4-Byte FLOAT

Yes

Yes⁷

8-Byte FLOAT

Yes¹¹

Yes

DECIMAL

Yes¹⁴

ZONED

Yes

Yes⁶

DATE, TIME,

Yes¹⁰

or TIMESTAMP

Notes for Table 13:

1. The CHAR, VARCHAR, and long field column data may be truncated if the

length of the source data is greater than the length of an output CHAR data

field. For TIME and DATE, an error occurs if the length of the source data is

greater than the length of an output CHAR data field. For TIMESTAMP, if the

output data field length is less than 19 bytes, an error occurs; if the output

data field length is less than 26 bytes but greater than or equal to 19 bytes,

Chapter 8. Command Reference

187

trailing digits of the microseconds part of the timestamp is truncated. If the

length of the output record data field is greater than the length of the source

column data, all trailing (low-order) positions of the data field are padded

with a blank (hex 40) value. Occurrences of null character column data result

in an all blank output record data field.

If a CHAR output record data field is potentially too small to contain all

significant digits, the sign, and the decimal point for a value derived from a

column defined with a numeric (SMALLINT, INTEGER, DECIMAL, or

FLOAT) data type, then:

v An error message is written to the Database Services Utility message file

identifying the column name.

v The output record CHAR data field associated with a numeric column

contains asterisks (*) if a data overflow condition actually occurs.

A CHAR output data field derived from a column with a DECIMAL data type

contains an EBCDIC plus sign (hex 4E) or minus sign (hex 60) in the leading

(high-order) position. The data value is right-justified in the low-order

positions of the output data field and represented using the values hex F0

through hex F9 in each position except for the decimal point position. A

decimal point (hex 4B) precedes the low-order scale value positions in the

output data field. The leading (high-order) positions of the output data field

(except for the first position) contain zeros (hex F0) if the number of

significant positions of the data value is less than the length of the output

data field minus 2.

Occurrences of null column data result in an unsigned output data field value

of 0. The leading position of the field contains a blank (hex 40) and the

remainder of the data field contains the value hex F0 (except for the decimal

point position).

For example, the hexadecimal values in each position of an eight-position

CHAR output record data field derived from a DECIMAL (5,2) column

containing the value +11.11 are:

Hexadecimal Value

EBCDIC Character

Field Position

Note: The minimum length of a CHAR output data field derived from a

DECIMAL select-list column is the column scale length plus 2.

4. A CHAR output data field derived from a column with a SMALLINT or

INTEGER data type contains a minus sign (hex 60) in the leading (high-order)

position for negative column values. If the column value is positive, the

leading (high-order) position of the data field contains a blank (hex 40). The

data value is right-justified in the low-order positions of the output data field

and represented using the values hex F0 through hex F9 in each position. The

leading (high-order) positions of the output data field (except for the first

position) contain zeros (hex F0) if the number of significant positions of the

data value is less than the length of the output data field minus 1.

Occurrences of null column data result in an unsigned output data field value

of 0. The leading position of the field contains a blank (hex 40) and the

remainder of the data field positions contains the value hex F0.

For example, the hexadecimal values contained in each position of an

eight-position CHAR output record data field derived from a SMALLINT

column containing the value +32767 are:

188

Database Services Utility

Hexadecimal Value

EBCDIC Character

Field Position

Note: The minimum length of a CHAR output data field derived from a

SMALLINT or INTEGER column is 2.

5. A CHAR output data field derived from a column with a FLOAT data type is

left-justified in the leading (high-order) positions of the output data field. The

format of the output data field value ranges from:

sn.nEsn to sn.nnnnnnnnnnnnnEsnn (for 8-byte float)

sn.nEsn to sn.nnnnnEsnn (for 4-byte float)

where:

s = EBCDIC sign: Plus (+) sign (hex 4E)

Minus (-) sign (hex 60)

n = EBCDIC numeric character (hex F0-F9)

. = EBCDIC decimal point (hex 4B)

E = EBCDIC character E (hex C5)

The trailing (low-order) positions of the output data field contain blanks

(hex 40) if the length of the field is greater than the EBCDIC representation of

the column value.

Occurrences of null column data result in an unsigned output data field value

(0.0E+0). The leading position of the data field contains a blank (hex 40).

For example, the hexadecimal values contained in each position of a

10-position CHAR output record data field derived from an 8-byte FLOAT

column containing the value +1.11E+02 are:

Hexadecimal Value

EBCDIC Character

Field Position

Note: The minimum length of a CHAR output data field derived from a

column with FLOAT data type is 7.

6. Leading (high-order) zero-value positions of column data are truncated if the

length of a numeric (FIXED, DECIMAL, or ZONED) output data field is less

than the length of the numeric (SMALLINT, INTEGER, or DECIMAL) column

value. A null column value results in a numeric output record data field value

of 0.

If a numeric output record data field is too small to contain all significant

digits of the data value from a numeric column:

v The message ARI0833E is written to the Database Services Utility message

file identifying the column name and the SQL SELECT row count.

v No data for the row is written to the output data file.

7. A null column value results in a numeric output record data field value of 0.

An 8-byte float column unloaded into a 4-byte output record FLOAT data

field results in the loss of a number of digits of precision. The fraction

(mantissa) is reduced from 14 to 6 digits of precision. During the conversion

process, if the exponent value exceeds a value of +63, the message ARI0833E

is generated and no data for the row is unloaded.

Chapter 8. Command Reference

189

The minimum length of an output data field derived from a DECIMAL

column is the (scale value/2+1). The scale of output data derived from a

DECIMAL column is the same as that for the source column.

If the length of the output data field is greater than the value of (column

precision/2)+1, the column value is extended with high-order zeros in the

output data field.

If the length of the output data field is less than the value of (column

precision/2)+1, nonsignificant high-order zeros to the left of the implied

decimal point are not reflected in the data field value.

Only fixed-length DBCS (data type of GRAPHIC) output data fields are

produced by DATAUNLOAD processing. The startpos of the output data field

contains a shift-out delimiter (hex 0E). The endpos of the output data field

contains a shift-in delimiter (hex 0F).

DBCS column data is truncated if the length of the column data plus 2 is

greater than the length of the output GRAPHIC data field. The length of the

column data is the number of DBCS characters times 2.

If the length of the output data field minus 2 is greater than the column data

length, the output data field is padded with trailing (low-order) DBCS blank

(hex 4040) characters in the unused low-order data field positions. The last

position of the data field always contains a shift-in delimiter (hex 0F).

If the column data value is all blanks or null, startpos+1 to endpos−1 of the

output DBCS data field contains DBCS blank characters (hex 4040).

10.

The datetime data type input and target type must match; for example, the

input data type of TIME is valid only for the target column data type of

TIME.

11.

A 4-byte float column unloaded into an 8-byte float data field is padded with

hex 0000 0000.

12.

REAL represents single precision floating point data and is synonymous with

FLOAT(n) where 1 is less than or equal to n is less than or equal to 21.

13.

DOUBLE PRECISION represents double precision floating point data and is

synonymous with FLOAT or FLOAT(n) where 22 is less than or equal to n is

less than or equal to 53.

14.

If the length of the output record data field is greater than the length of the

source column data, all leading (high-order) positions of the data field are

padded with hex zeros.

190

Database Services Utility

RELOAD DBSPACE

RELOAD DBSPACE Format

VM Format:

►► RELOAD DBSPACE

(dbspace_name)

NEW

INFILE

(ddname)

►

PURGE

►

COMMITCOUNT

(

ccount

)

RESTARTTABLE

( table_name

)

►

►◄

RESTARTCOUNT

( rcount

)

VSE Format:

►► RELOAD DBSPACE

(dbspace_name)

NEW

►

PURGE

► INFILE

( ddname

►

2048

BLKSZ

(

size

)

►

)

►

REWIND

COMMITCOUNT

( ccount

)

(TAPE)

NOREWIND

PDEV

(DASD)

►

►◄

RESTARTTABLE

( table_name

)

RESTARTCOUNT

( rcount

)

Examples:

RELOAD DBSPACE(JOHNS.SPACE1) PURGE INFILE(TEMP)

RELOAD DBSPACE(PUBLIC.SPACE2) NEW INFILE(TEMP)

RELOAD DBSPACE(DBS1) PURGE INFILE(IFILE) COMMITCOUNT(300)

RESTARTTABLE(EMPLOYEE) RESTARTCOUNT(600)

Authorization:

You must have the INSERT privilege on the tables affected by the command. Additional

authority is required depending on the keywords specified:

RESOURCE-if NEW is specified.

SELECT, DELETE, and INSERT- if PURGE is specified.

DBA-if PURGE is specified, and if any indexes defined on an affected table are

owned by someone else. DBA authority is also required if NEW is specified, and any

tables are to be created for another user.

Before you reload tables into a dbspace, it must already exist.

Chapter 8. Command Reference

191

Note: The RELOAD DBSPACE command is not supported if you are using DRDA

flow.

DBSPACE (dbspace-name)

identifies a RELOAD DBSPACE request and identifies the dbspace to be

loaded. The Database Services Utility loads the tables into the dbspace in the

order that they occur in the input data. If you do not own a private dbspace

with the dbspace-name identified, the data is loaded into a public dbspace (if

one having that name exists). The owner of a public dbspace is PUBLIC.

NEW

instructs the Database Services Utility to create each table contained in the

input file before loading the data. Tables represented in the input data file that

already exist in the database are not processed. The tables are created for the

current Database Services Utility user. You must have RESOURCE

authorization to use this keyword.

If either the RESTARTCOUNT or RESTARTTABLE parameters appear on the

RELOAD DBSPACE command, the NEW parameter will not cause the restart

table to be created. The RESTARTCOUNT and RESTARTTABLE parameters

indicate that the RELOAD DBSPACE operation is being restarted, therefore,

NEW processing must have already occurred, so it is not required to create the

restart table again. Note that NEW processing is performed on all tables to be

reloaded before any rows are reloaded to any table. This means that NEW

processing will have already occurred for all tables to be reloaded.

PURGE

instructs the Database Services Utility that existing tables within the dbspace

are to be loaded. The rows for all dbspace tables to be processed are deleted

before the first table is loaded. The tables that are processed are those that are

in the input file; that is, if table JONES.PROJECT exists in the dbspace, but the

input file contains only JONES.EMPLOYEE and JONES.DEPARTMENT, then

JONES.PROJECT is unaffected by RELOAD processing. Even if the input file

contains SMITH.PROJECT, JONES.PROJECT is unaffected. The Database

Services Utility uses fully qualified table names when determining the tables to

reload. You must have the DELETE privilege to use this keyword if you do not

own the affected tables. You must also have DBA authority if any indexes

defined on an affected table are owned by someone else.

If either the RESTARTCOUNT or RESTARTTABLE parameters appear on the

RELOAD DBSPACE command, the PURGE parameter will not cause all rows

of the restart table to be deleted. The RESTARTCOUNT and RESTARTTABLE

parameters indicate that the RELOAD DBSPACE operation is being restarted,

therefore, PURGE processing must have already occurred, so it is not required

to delete all rows from the restart table again. Note that PURGE processing is

performed on all tables to be reloaded before any rows are reloaded to any

table. This means that PURGE processing will have already occurred for all

tables to be reloaded.

Note: You must specify either NEW or PURGE in the RELOAD DBSPACE

statement. Because existing tables might be greatly affected by the choice

of these parameters, there is no default specification.

INFILE (ddname)

in DB2 Server for VSE, this identifies and describes the sequential (SAM) file

containing the input dbspace data. The default record format in a DB2 Server

for VSE system is variable-length blocked, spanned (SB), with

LRECL=(BLKSIZE−4) for variable and spanned records or LRECL=BLKSIZE

for fixed and undefined records.

192

Database Services Utility

The default record format in a DB2 Server for VM system is variable-length

blocked, spanned (VBS). Block size and record format information is specified

using a CMS FILEDEF command; the LRECL parameter is not applicable.

Note: The RECFM, RECSZ, and BLKSIZE information displayed in the

message ARI0868I depends on the CMS FILEDEF command

specifications for the RELOAD input file. However, RELOAD processing

in a DB2 Server for VM environment always opens the input data file as

a VB file. The RECFM, RECSZ, and BLKSIZE information displayed in

the message ARI0868I indicates this change.

ddname

In DB2 Server for VSE: this is the TLBL or DLBL job control statement file

name for the sequential input file.

In DB2 Server for VM: this is the name of the sequential input file defined

with a CMS FILEDEF command. Except for the ddname, use the same CMS

FILEDEF command information for RELOAD command processing that

you used when UNLOAD command processing created the file. Define the

CMS file used for RELOAD command input with the file-mode number 4.

Do not specify SYSIN or SYSPRINT as the ddname.

COMMITCOUNT (ccount)

identifies the frequency of COMMIT action during RELOAD processing.

ccount is a number from 1 to 2,147,483,647 indicating that a COMMIT

statement should be executed after the number of input table rows equal to

ccount are processed by RELOAD for each table. A COMMIT statement will

also be executed after the last row of each table has been reloaded.

Note: Database Services Utility AUTOCOMMIT ON processing must be in

effect when you use RELOAD COMMITCOUNT processing. If

AUTOCOMMIT is OFF and the COMMITCOUNT parameter is

used, an error message is written and RELOAD command

processing is not performed.

RESTARTTABLE (table_name)

identifies at which table the RELOAD DBSPACE processing will be

restarted. If a RELOAD DBSPACE operation ended normally, and the

RELOAD DBSPACE statement included the COMMITCOUNT parameter,

the RELOAD DBSPACE operation can be restarted by using the

RESTARTTABLE and RESTARTCOUNT parameters. table_name identifies

the table where RELOAD processing should begin. If RESTARTTABLE is

omitted, RELOAD DBSPACE processing will begin reloading the first table,

and the RESTARTCOUNT parameter, if specified, will apply to the first

table.

Note: If the table does not exist in the database when RELOAD DBSPACE

with RESTARTCOUNT or RESTARTTABLE is issued, an error

message is displayed.

RESTARTCOUNT (rcount)

identifies the restart point for RELOAD processing. rcount is a number

from 1 to 2,147,483,647 that identifies the number of input table rows in the

restart table to be skipped before RELOAD command processing begins. If

RESTARTCOUNT is omitted, no table rows are skipped and RELOAD

processing begins with the first table row of the restart table.

Chapter 8. Command Reference

193

Note: If an end-of-table condition occurs before rcount rows of the restart

table are read, an error message is written before RELOAD

processing ends.

BLKSZ (size) (DB2 Server for VSE Only)

is an optional parameter that specifies the block size of the sequential

output file. The default block size is 2048 bytes per block.

PDEV (TAPE or DASD)

is an optional parameter that specifies the device type (DASD or TAPE) of

the sequential (SAM) input file. Specify PDEV(DASD) if the input file

resides on any device supported by the VSE DTFSD macro. An exception

to this is VSAM-managed SAM files. VSAM-managed SAM does not

support spanned records. Specify PDEV(TAPE) if the input file resides on a

device supported by the VSE DTFMT macro. The default is PDEV(TAPE).

BLKSZ and PDEV can be specified in any order but must occur after the

ddname parameter.

REWIND or NOREWIND

controls tape file rewind processing performed during OPEN

processing. This parameter is valid only if you specify TAPE for PDEV.

The default processing is REWIND.

REWIND

specifies that the tape file is rewound by OPEN processing.

NOREWIND

specifies that the tape file is not rewound by OPEN processing. If

NOREWIND is specified for input tape files referenced by a series

of RELOAD commands, you must ensure that the tape files being

referenced are in ascending sequence. For example, if NOREWIND

is specified in a sequence of two RELOAD commands and the first

command reads tape file 2, then the second command must

reference tape file 3 or higher number. If it references tape file 1, an

OPEN error occurs.

Selective dbspace file reloads may be performed by specifying the file sequence

number in the TLBL statement. The following JCL is an example of how this can

be accomplished:

// JOB RELOAD DBSPACE

// ASSGN SYS005,181

// MTC REW,SYS005

* RELOAD 1 DBSPACE FROM TAPE FILE SEQ# 1

// TLBL DBSP,’PUBLIC.CRP01’,,,1

// EXEC ARIDBS,SIZE=AUTO

RELOAD DBSPACE (PUBLIC.CRP01)

INFILE (DBSP BLKSZ(24720) PDEV(TAPE) );

* RELOAD 2 DBSPACES FROM TAPE FILE SEQ# 2

// TLBL DBSP,’PUBLIC.CRPXX’,,,2

// EXEC ARIDBS,SIZE=AUTO

RELOAD DBSPACE (PUBLIC.CRP02)

INFILE (DBSP BLKSZ(24720) PDEV(TAPE) );

RELOAD DBSPACE (PUBLIC.CRP03)

INFILE (DBSP BLKSZ(24720) PDEV(TAPE) );

194

Database Services Utility

RELOAD TABLE

RELOAD TABLE Format

VSE Format:

►► RELOAD TABLE

(table_name)

PURGE

►

NEW

(dbspace_name)

►

INTABLE

(table_name)

► INFILE

( ddname

►

2048

BLKSZ

(

)

size

►

)

►

REWIND

COMMITCOUNT

( ccount

)

(TAPE)

NOREWIND

PDEV

(DASD)

►

►◄

RESTARTCOUNT

( rcount

)

VM Format:

►► RELOAD TABLE

(table_name)

PURGE

►

NEW

(dbspace_name)

►

INFILE

(ddname)

►

INTABLE

(table_name)

►

►◄

COMMITCOUNT

( ccount

)

RESTARTCOUNT

( rcount

)

VSE Examples:

RELOAD TABLE(SALARY)

NEW(DBSPACE1)

INTABLE(SMITH.SALARY)

INFILE(CIPHER3 PDEV(TAPE))

RELOAD TABLE(SALARY)

NEW(DBSPACE1)

INTABLE(SMITH.SALARY)

INFILE(CIPHER3)

COMMITCOUNT(300)

RESTARTCOUNT(600)

196

Database Services Utility

VM Example:

RELOAD TABLE(SALARY)

NEW(DBSPACE1)

INTABLE(SMITH.SALARY)

INFILE(CIPHER3)

COMMITCOUNT(300)

RESTARTCOUNT(600)

Authorization:

You must have the INSERT privilege on the "target" table.

Additional authority is required depending on the keywords specified.

RESOURCE-if NEW is specified.

DELETE and INSERT-if PURGE is specified and the table is owned by another

user.

DBA-if PURGE is specified, and if any indexes defined on an affected table

are owned by someone else.

Note: The RELOAD TABLE command is not supported if you are using DRDA

flow.

TABLE (table_name)

identifies a RELOAD TABLE request and the table to be loaded. You can

further identify the table by specifying the owner of the table (see “Qualifying

Object Names” on page 110 for details). You cannot use a synonym for a

table_name. If you specify the NEW option, a table called table_name is created

for that user. If you specify the PURGE option, you can specify a view name

instead of a table name if the view meets the following requirements:

v The view is defined on a single table.

v The view definition includes all the NOT NULL columns in the table. That

is, all columns outside of the view definition must permit the insertion of

nulls.

v The view has no column definitions based on functions (virtual data

columns).

When reloading data into a view that was created using the WITH CHECK

OPTION clause, the database manager checks all inserts and updates to the

view against the view definition and rejects them if the row to be inserted or

updated does not conform to the view definition.

NEW (dbspace_name)

instructs the Database Services Utility that the table to be loaded does not exist

and must first be created. You can identify the dbspace by the owner. If you do

not specify the owner of the dbspace (see “Qualifying Object Names” on page

110 for information about owner), a private dbspace that you own with

dbspace_name specified is loaded. If no such private dbspace exists, a public

dbspace with dbspace_name is loaded. The owner of a public dbspace is

PUBLIC, for example, NEW (PUBLIC.PRODUCTION). If owner is specified for

the table name and owner is not specified for the dbspace name, the Database

Services Utility does not use the owner specified for the table name to identify

the private dbspace.

If the RESTARTCOUNT parameter appears on the RELOAD TABLE command,

the NEW parameter will not cause the table to be created. The

RESTARTCOUNT parameter indicates that the RELOAD TABLE operation is

being restarted, therefore, NEW processing must have already occurred, so it is

not required to create the table again.

Chapter 8. Command Reference

197

PURGE

identifies that the output table (table to be loaded) exists and that all existing

table rows should be deleted by RELOAD TABLE processing before loading.

You must have the DELETE privilege on the output table. If you are not the

owner of the output table, you require DELETE and INSERT authority for the

table. If any indexes for the table are owned by another user, you require DBA

authority.

If the RESTARTCOUNT parameter appears on the RELOAD TABLE command, the

PURGE parameter will not cause all row to be deleted. The RESTARTCOUNT

parameter indicates that the RELOAD TABLE operation is being restarted,

therefore, PURGE processing must have already occurred, so it is not required to

delete all rows from the table again.

Note: You must specify either NEW or PURGE in the RELOAD TABLE statement.

Because existing tables might be greatly affected by the choice of these

parameters, there is no default specification.

INTABLE (table_name)

is optional. If omitted, the Database Services Utility loads data from the first

table it finds in the input file. INTABLE identifies data in the input file to be

used for RELOAD TABLE processing. Because the input file must be created

by UNLOAD processing, the data is organized by the tables from which it was

unloaded. Thus, the table_name that you specify here is the name of a table that

was unloaded at an earlier time. This parameter is useful if your input file was

created by an UNLOAD DBSPACE command. The UNLOAD DBSPACE

command can unload many tables into a sequential file. The INTABLE

parameter merely identifies which of those tables you now want to reload.

You can use owner to specify the user ID of the person who created the table in

the input file. If you omit the owner (see “Qualifying Object Names” on page

110 for more information about owner), the utility uses the data of the first

table encountered in the input file with the table_name specified. In this

instance, owner does not default to the user ID of the current Database Services

Utility user.

INFILE (ddname)

identifies and describes the sequential (SAM) input file containing the data to

be loaded into the table. The file must be created with UNLOAD processing.

The default record format in a DB2 Server for VSE system is variable-length

blocked, spanned (SB), with LRECL=(BLKSIZE−4) for variable and spanned

records or LRECL=BLKSIZE for fixed and undefined records.

The default record format in a DB2 Server for VM system is variable-length

blocked, spanned (VBS), with block size and record format information

specified by a CMS FILEDEF command; the LRECL parameter is not

applicable.

Note: The RECFM, RECSZ and BLKSIZE information displayed in the message

ARI0868I depends on the CMS FILEDEF command specifications for the

RELOAD input file. However, RELOAD processing in a DB2 Server for

VM environment always opens the input data file as a VB file. The

RECFM, RECSZ and BLKSIZE information displayed in the message

ARI0868I indicates this change.

COMMITCOUNT (ccount)

identifies the frequency of COMMIT action during RELOAD processing. ccount

198

Database Services Utility

is a number from 1 to 2,147,483,647 indicating that a COMMIT statement

should be executed after the number of input table rows equal to ccount are

processed by RELOAD TABLE.

Note: Database Services Utility AUTOCOMMIT ON processing must be in

effect when you use RELOAD COMMITCOUNT processing. If

AUTOCOMMIT is OFF and the COMMITCOUNT parameter is used, an

error message is written and RELOAD command processing is not

performed.

RESTARTCOUNT (rcount)

identifies the restart point for RELOAD processing. rcount is a number from 1

to 2,147,483,647 that identifies the number of input table rows to be skipped

before RELOAD command processing begins. Row rcount + 1 will be the first

row to be reloaded. If RESTARTCOUNT is omitted, no rows are skipped and

RELOAD processing begins with the first input row.

Note: If an end-of-table condition occurs before rcount rows are read from the

input UNLOAD file, an error message is written before RELOAD

processing ends.

ddname

in DB2 Server for VSE: this is the TLBL or DLBL job control statement file

name for the sequential input file.

In DB2 Server for VM: this is the name of the sequential input file defined

with a CMS FILEDEF command. Except for the ddname, CMS FILEDEF

command information for RELOAD command processing should be

identical to the information in the FILEDEF command used when the file

was created by UNLOAD command processing. You must define a CMS

file used for RELOAD command input with the file-mode number 4. Do

not specify SYSIN or SYSPRINT as the ddname.

BLKSZ (size)

is an optional parameter that specifies the block size of the sequential

output file. The default block size is 2048 bytes per block.

PDEV (TAPE or DASD)

is an optional parameter that specifies the device type (DASD or TAPE) of

the sequential (SAM) input file. Specify PDEV(DASD) if the input file

resides on any device supported by the VSE DTFSD macro. An exception

to this is VSAM-managed SAM files. VSAM-managed SAM does not

support spanned records. Specify PDEV(TAPE) if the input file resides on a

device supported by the VSE DTFMT macro. The default is PDEV(TAPE).

BLKSZ and PDEV can be specified in any order but must occur after the

ddname parameter.

REWIND or NOREWIND

controls tape file rewind processing performed during OPEN processing.

This parameter is valid only if you specify TAPE for PDEV. The default

processing is REWIND.

REWIND

specifies that the tape file is rewound by OPEN processing.

NOREWIND

specifies that the tape file is not rewound by OPEN processing. If

NOREWIND is specified for input tape files referenced by a series of

RELOAD commands, you must ensure that the tape files being

Chapter 8. Command Reference

199

referenced are in ascending sequence. For example, if NOREWIND is

specified in a sequence of two RELOAD commands and the first

command reads tape file 2, then the second command must reference

tape file 3 or higher. If it references tape file 1, an OPEN error occurs.

Release Coexistence Considerations for DB2 Server for VM

Changes were required in Version 7 Release 1 to handle file I/O correctly when

using CMS 15 and later. These changes affect the format of data that is unloaded

and reloaded by the UNLOAD and RELOAD commands of the DBS Utility. If you

use the DBS Utility’s UNLOAD and RELOAD commands with databases at

different release levels, you must ensure that the code changes have been applied

at all release levels. For releases prior to Version 7 Release 1, you must apply the

following APARs:

Release

APAR

3.5

PQ28584

5.1

PQ28583

6.1

PQ27957

200

Database Services Utility

UNLOAD DBSPACE

UNLOAD DBSPACE Format

VM Format:

►► UNLOAD DBSPACE

(dbspace_name) OUTFILE

(ddname)

►◄

VSE Format:

►► UNLOAD DBSPACE

(dbspace_name)

►

► OUTFILE

( ddname

►

2048

BLKSZ

(

size

)

►

)

►◄

NOREWIND

(TAPE)

REWIND

PDEV

(DASD)

VM Example:

UNLOAD DBSPACE(THOMPSON.SPACE1) OUTFILE(HISTORY)

VSE Example:

UNLOAD DBSPACE(MIKE.SP2) OUTFILE(SAVE BLKSZ(2048))

Authorization:

You must have the SELECT privilege on the table(s) being unloaded.

UNLOAD DBSPACE unloads all tables of the specified dbspace to a sequential output

file.

Note: The UNLOAD DBSPACE command is not supported if you are using DRDA

flow.

Following are the descriptions for each portion of the command:

DBSPACE (dbspace_name)

identifies an UNLOAD DBSPACE request and the dbspace to be unloaded. The

utility unloads the tables of the dbspace in an unpredictable order. The

dbspace_name is the name of the dbspace to be unloaded. If you do not specify

owner, the utility unloads one of your dbspaces. See “Names and Identifiers”

on page 110 for more information about naming conventions for data objects. If

you do not own a dbspace called dbspace_name, the utility unloads a public

dbspace having that name. If there is no public dbspace having that name,

UNLOAD processing is unsuccessful, and an error message is written to the

Database Services Utility message file.

For example, suppose your user ID is GENE and you specify:

UNLOAD DBSPACE(SPACE1) ...

Chapter 8. Command Reference

201

The Database Services Utility unloads the private dbspace named

GENE.SPACE1. If there is no such dbspace, the utility unloads the public

dbspace named PUBLIC.SPACE1. If there is no PUBLIC.SPACE1, no dbspace is

unloaded, and you receive an error message in the message file.

If you own a private dbspace with the same name as a public dbspace, and

you want to unload the public dbspace, you must specify

PUBLIC.dbspace_name. If owner is omitted, the private dbspace is unloaded.

OUTFILE|OUTFILE (ddname)

identifies and describes the sequential (SAM) output file that is to contain the

data unloaded from the dbspace. The default record format is variable-length

blocked, spanned (VBS). A minimum logical record length (LRECL) of 8240

bytes is the default in DB2 Server for VSE. A block size greater than 8244 is

recommended for tape output files to improve performance.

ddname

DB2 Server for VSE

This is the TLBL or DLBL job control statement file name for the sequential

output file.

Note: If the message ARI0868I generated during Database Services Utility

UNLOAD command processing identifies RECFM=VS for an output

file defined with RECFM VBS, the file can be read by Database

Services Utility RELOAD command processing using RECFM VBS.

DB2 Server for VM

This is the name of the sequential output file defined with a CMS FILEDEF

command. The FILEDEF command should contain the record format

specification RECFM VBS or a block size (BLOCK or BLKSIZE) value or

both. You must define a CMS file used for UNLOAD command output

with the file mode number 4.

If the row length (sum of defined column lengths) for any table in the

dbspace being unloaded exceeds 8 240 bytes, the largest row length value

is used as the minimum logical record length.

Notes:

1. Always specify a record format (RECFM) of VBS for UNLOAD

processing. UNLOAD processing changes the record format to U if the

system-required logical record length is greater than the specified block

size (BLOCK) value minus 4. Otherwise, UNLOAD processing changes

the record format to VB. This change will be indicated in the ARI0868I

message, generated by the UNLOAD processing. See Appendix B,

“FILEDEF Command Syntax and Notes,” on page 249 for more

information about undefined (U) record format usage.

2. If the message ARI0868I, generated using DBS UNLOAD processing,

identifies RECFM=U or RECFM=VB for an output file defined with

RECFM=VBS, the CMS FILEDEF command that defines the RELOAD

input data files must still specify RECFM=VBS. Except for the ddname,

CMS FILEDEF information for RELOAD command processing must be

identical to the information in the FILEDEF command used when

UNLOAD command processing created the file. See Appendix B,

“FILEDEF Command Syntax and Notes,” on page 249 for more

information about undefined (U) record format usage.

3. If the message ARI0868I indicates RECFM=U for a tape output file,

significant performance improvements can be obtained by increasing

202

Database Services Utility

the block size (BLOCK) value for the file. A block size greater than 8244

bytes is recommended for tape output files created by UNLOAD

processing.

Do not specify SYSIN or SYSPRINT as the ddname.

BLKSZ (size) (DB2 Server for VSE Only)

is an optional parameter that specifies the block size of the sequential output

file. The default block size is 2048 bytes per block.

PDEV (TAPE or DASD) (DB2 Server for VSE Only)

is an optional parameter that specifies the device type (DASD or TAPE) for the

sequential output file. Specify PDEV(DASD) for files that reside on any device

supported by the VSE DTFSD macro. An exception to this is VSAM-managed

SAM files. VSAM-managed SAM does not support spanned records. Specify

PDEV(TAPE) for files that reside on any device supported by the VSE DTFMT

macro. The default is PDEV(TAPE).

BLKSZ and PDEV can be specified in any order but must occur after the

ddname parameter.

NOREWIND or REWIND (DB2 Server for VSE Only)

controls tape file rewind processing performed during CLOSE processing. This

parameter is valid only if you specified TAPE for PDEV. The default is

NOREWIND.

NOREWIND

specifies that the tape file will not be rewound by CLOSE processing.

REWIND

specifies that the tape file is rewound by CLOSE processing.

Selective dbspace file unloads may be performed by specifying the file sequence

number in the TLBL statement. The following JCL is an example of how this can

be accomplished:

// JOB UNLOAD DBSPACE

* UNLOAD 1 DBSPACE INTO TAPE FILE SEQ# 1

// TLBL DBSP,’PUBLIC.CRP01’,,,,1

// ASSGN SYS005,181

// MTC REW,SYS005

// EXEC ARIDBS,SIZE=AUTO

UNLOAD DBSPACE (PUBLIC.CRP01)

OUTFILE (DBSP BLKSZ(24720) PDEV(TAPE) );

* UNLOAD 2 DBSPACES INTO TAPE FILE SEQ# 2

// TLBL DBSP,’PUBLIC.CRPXX’,,,,2

// EXEC ARIDBS,SIZE=AUTO

UNLOAD DBSPACE (PUBLIC.CRP02)

OUTFILE (DBSP BLKSZ(24720) PDEV(TAPE) );

UNLOAD DBSPACE (PUBLIC.CRP03)

OUTFILE (DBSP BLKSZ(24720) PDEV(TAPE) );

Release Coexistence Considerations for DB2 Server for VM

Changes were required in Version 7 Release 1 to handle file I/O correctly when

using CMS 15 and later. These changes affect the format of data that is unloaded

and reloaded by the UNLOAD and RELOAD commands of the DBS Utility. If you

use the DBS Utility’s UNLOAD and RELOAD commands with databases at

different release levels, you must ensure that the code changes have been applied

at all release levels. For releases prior to Version 7 Release 1, you must apply the

Chapter 8. Command Reference

203

following APARs:

Release

APAR

3.5

PQ28584

5.1

PQ28583

6.1

PQ27957

UNLOAD TABLE

UNLOAD TABLE Format

VSE Format:

►► UNLOAD TABLE

(table_name)

►

► OUTFILE

( ddname

►

2048

BLKSZ

(

size

)

►

)

►◄

NOREWIND

(TAPE)

REWIND

PDEV

(DASD)

VM Format:

►► UNLOAD TABLE

(table_name) OUTFILE

(ddname)

►◄

VSE Example:

UNLOAD TABLE (EMPLOYEE) OUTFILE(SAVE13 PDEV(DASD))

VM Example:

UNLOAD TABLE (EMPLOYEE) OUTFILE(SAVE13)

Authorization:

You must have the SELECT privilege on the table being unloaded.

The UNLOAD TABLE command unloads a specific table or view to an output file.

Note: The UNLOAD TABLE command is not supported if you are using DRDA

flow.

Following are descriptions of each portion of the command:

TABLE (table_name)

identifies an UNLOAD TABLE request and the table to be processed. You can

UNLOAD a view merely by specifying a view name instead of a table name.

You can further identify the table or view by specifying the owner of the table

or view (see “Qualifying Object Names” on page 110 for details). A synonym

cannot be used for table_name.

204

Database Services Utility

OUTFILE|OUTFILE (ddname)

identifies and describes the sequential (SAM) output file that is to contain the

data unloaded from the table. The default record format is variable-length

blocked, spanned (VBS). A minimum logical record length (LRECL) of 8 240

bytes is the default in a VSE system. To improve performance, a block size

greater than 8 244 bytes is recommended for tape output files.

ddname

in DB2 Server for VSE: this is the TLBL or DLBL job control statement file

name for the sequential output file.

Note: If the message ARI0868I generated during Database Services Utility

UNLOAD command processing identifies RECFM=VB for an output file

defined with RECFM VBS, the file can be read by Database Services

Utility RELOAD command processing using RECFM VBS.

In DB2 Server for VM: this is the name of the sequential output file defined

with a CMS FILEDEF command. The FILEDEF command should contain the

record format specification RECFM VBS or a block size (BLOCK or BLKSIZE)

value or both. You must define a CMS file used for UNLOAD command

output with the file mode number 4. UNLOAD processing writes

variable-length spanned records with a minimum logical record length

(LRECL) of 8 240 bytes.

Notes:

1. Always specify a record format (RECFM) of VBS for UNLOAD processing.

UNLOAD processing changes the record format to U if the system-required

logical record length is greater than the specified block size (BLOCK) value

minus 4. Otherwise, UNLOAD processing changes the record format to VB.

This change will be indicated in the ARI0868I message generated by the

UNLOAD processing. See Appendix B, “FILEDEF Command Syntax and

Notes,” on page 249 for more information about undefined (U) record

format usage.

2. If the message ARI0868I, generated using DBS UNLOAD processing,

identifies RECFM=U or RECFM=VB for an output file defined with

RECFM=VBS, the CMS FILEDEF command that defines the RELOAD input

data files must still specify RECFM=VBS. Except for the ddname, CMS

FILEDEF information for RELOAD command processing must be identical

to the information in the FILEDEF command used when UNLOAD

command processing created the file. See Appendix B, “FILEDEF Command

Syntax and Notes,” on page 249 for more information about undefined (U)

record format usage.

3. If the message ARI0868I indicates RECFM=U for a tape output file,

significant performance improvements can be obtained by increasing the

block size (BLOCK) value for the file. A block size greater than 8244 is

recommended for tape output files created by UNLOAD processing.

Do not specify SYSIN or SYSPRINT as the ddname.

BLKSZ (size)

is an optional parameter that specifies the block size of the sequential output

file. The default block size is 2048 bytes per block.

PDEV (TAPE or DASD)

is an optional parameter that specifies the device type (DASD or TAPE) for the

sequential output file. Specify PDEV(DASD) for files that reside on any device

supported by the VSE DTFSD macro. An exception to this is VSAM-managed

Chapter 8. Command Reference

205

SAM files. VSAM-managed SAM does not support spanned records. Specify

PDEV(TAPE) for files that reside on any device supported by the VSE DTFMT

macro. The default is PDEV(TAPE).

BLKSZ and PDEV can be specified in any order but must occur after the

ddname parameter.

NOREWIND or REWIND

controls tape file rewind processing performed during CLOSE processing.

This parameter is valid only if you specify TAPE for PDEV. The default is

NOREWIND.

NOREWIND

specifies that the tape file is not rewound by CLOSE processing.

REWIND

specifies that the tape file is rewound by CLOSE processing.

Release Coexistence Considerations for DB2 Server for VM

Changes were required in Version 7 Release 1 to handle file I/O correctly when

using CMS 15 and later. These changes affect the format of data that is unloaded

and reloaded by the UNLOAD and RELOAD commands of the DBS Utility. If you

use the DBS Utility’s UNLOAD and RELOAD commands with databases at

different release levels, you must ensure that the code changes have been applied

at all release levels. For releases prior to Version 7 Release 1, you must apply the

following APARs:

Release

APAR

3.5

PQ28584

5.1

PQ28583

6.1

PQ27957

206

Database Services Utility

RELOAD PACKAGE

RELOAD PACKAGE Format

VM Format:

►► RELOAD PACKAGE

(package_name)

NEW

►

KEEP

REPLACE

REVOKE

►

INFILE

(ddname)

►◄

▼

(

server_name

)

VSE Format:

►► RELOAD PACKAGE

(package_name)

NEW

►

KEEP

REPLACE

REVOKE

►

(

▼

server_name

)

► INFILE

( ddname

►

2000

BLKSZ

(

size

)

►

)

►◄

REWIND

(TAPE)

NOREWIND

PDEV

(DASD)

VM Example:

RELOAD PACKAGE(JONES.PROG4) REPLACE KEEP TO(RDB2,RDB3)

INFILE(IN1)

VSE Example:

RELOAD PACKAGE(JONES.PROG4) REPLACE KEEP INFILE(IN1)

Authorization: You must be the owner of the package that you want to reload. To

reload another user’s package, you must have DBA authority. In VM, you must also have

CONNECT authority to all named databases.

PACKAGE (package_name)

identifies a RELOAD PACKAGE request and the package to be loaded.

You can further qualify the package_name with the owner, separating the two

names with a period. The name of the package is package_name. If you do not

specify the owner, owner defaults to the connected authorization ID. (See

208

Database Services Utility

“Qualifying Object Names” on page 110 for details on accessing data objects

that are owned by other users.) The authorization ID is either:

v The authorization ID specified in a previous explicit connect (when TO is

not used)

v The VM user ID (when TO is used) because it is the user ID used to connect

to server_name.

REPLACE

is specified if an existing package is to be replaced by the reload. If the

package does not exist, a new package is created without an error or warning

message.

NEW

instructs the Database Services Utility that the package to be loaded does not

exist and is to be created. If a package with the same name and owner already

exists in the database, the reload fails.

KEEP

causes the grants of RUN privilege to remain in effect when the package is

reloaded. The KEEP and REVOKE parameters apply if the package has

previously been created and the owner of the package has granted the RUN

privilege on the resulting package to other users. The KEEP and REVOKE

parameters are allowed only with REPLACE; KEEP is the default.

REVOKE

if the REVOKE parameter is specified, or if the owner of the package is not

entitled to grant all privileges embodied in the package, all existing grants of

the RUN privilege are revoked. The KEEP and REVOKE parameters are

allowed only with REPLACE; KEEP is the default.

TO (server-name)

in DB2 Server for VSE, this identifies the application server or servers onto

which the package is to be reloaded. The Database Services Utility connects to

each application server in turn, and if the connection is successful, the package

is reloaded. If an LUW is active when the RELOAD command begins,

processing is unsuccessful and an error occurs.

In DB2 Server for VM, this can be specified when you must load the package

onto more than one database. To reload the package, the Database Services

Utility connects to each specified server-name in turn (using database switching,

which requires APPC/VM in multiple user mode). If an LUW is active when

the RELOAD command begins, processing is unsuccessful and an error occurs.

When the TO clause is specified, the CONNECT statement is processed with

no user ID or password. The attempted connection fails if implicit connections

are not allowed on server-name. After the RELOAD is performed on each

database, a COMMIT RELEASE (or ROLLBACK RELEASE) is done, releasing

the connection to that server-name. The default user ID (the VM user ID) and

the default database (as specified to SQLINIT) are reestablished for a new

LUW. Any explicit connections done before the RELOAD are therefore lost and

must be reissued if required.

If owner was not specified, the VM user ID is assumed, because it is the ID

used to connect to each server-name.

When you use TO, the Database Services Utility ignores preceding CONNECT

statements and uses the VM user ID as a default. If you do not want to use

your VM user ID, issue the explicit CONNECT statements as required, and use

Chapter 8. Command Reference

209

the RELOAD command without a TO clause. If you do not specify the TO

clause, the Database Services Utility reloads the package onto only the

currently connected database.

There is no specific limit on the number of database names typed; however,

there is an implied limit in that the maximum length of a Database Services

Utility command is 8192 characters.

INFILE (ddname)

identifies and describes the sequential (SAM) tape or disk input file containing

the package to be loaded into the database. The file must be created by

UNLOAD PACKAGE processing, and its contents must not be changed in

any way. RELOAD package processing uses a record format of fixed-length

blocked (FB) and a record length of 80. The block size should be identical to

that used for UNLOAD processing; that is, it must be a multiple of 80.

ddname

in DB2 Server for VSE: this is the TLBL or DLBL job control statement file

name for the sequential input file.

Alternatively, RELOAD PACKAGE can read its input from SYSIPT by using a

READ MEMBER. You use the READ MEMBER NOCONT option to properly

close the SYSIPT file. An example of using READ MEMBER with NOCONT is:

RELOAD PACKAGE (package_name) REPLACE INFILE(SYSIPT);

READ MEMBER package_member (NOCONT

In DB2 Server for VM: this is the name of the sequential input file defined

with a CMS FILEDEF command. Do not specify SYSIN or SYSPRINT as the

ddname.

BLKSZ (size) (DB2 Server for VSE Only)

is an optional parameter that specifies the block size of the sequential output

file. It should be identical to that used for UNLOAD processing; that is, it must

be a multiple of 80. The default block size is 2000 bytes per block.

PDEV (TAPE or DASD)

is an optional parameter that specifies the device type (DASD or TAPE) of the

sequential (SAM) input file. Specify PDEV(DASD) if the input file resides on

any device supported by the VSE DTFSD macro. Specify PDEV(TAPE) if the

input file resides on a device supported by the VSE DTFMT macro. The default

is PDEV(TAPE).

REWIND or NOREWIND

controls tape file rewind processing performed during OPEN processing. This

parameter is valid only if you specify TAPE for PDEV. The default processing

is REWIND.

REWIND

specifies that the tape file is rewound by OPEN processing.

NOREWIND

specifies that the tape file is not rewound by OPEN processing. If NOREWIND

is specified for input tape files referenced by a series of RELOAD commands,

you must ensure that the tape files being referenced are in ascending sequence.

For example, if NOREWIND is specified in a sequence of two RELOAD

commands and the first command reads tape file 2, then the second command

must reference tape file 3 or higher. If it references tape file 1, an OPEN error

occurs.

210

Database Services Utility

UNLOAD PACKAGE

UNLOAD PACKAGE Format

Format:

►► UNLOAD PACKAGE

(package_name)

►

FROM

(server_name)

► OUTFILE

( ddname

►

2000

BLKSZ

(

size

)

►

)

►◄

NOREWIND

(TAPE)

REWIND

PDEV

(DASD)

VM Example:

UNLOAD PACKAGE(PROG1) FROM(DB1) OUTFILE(OUT1)

VSE Example:

UNLOAD PACKAGE(PROG1) OUTFILE(OUT1)

Authorization:

You must be the owner of the package you want to unload. To unload another user’s

package, you must have DBA authority.

In VM, you must also have CONNECT authority to a specified database.

The UNLOAD PACKAGE command unloads a specific package to a file. You can

unload packages flagged as invalid in the database because RELOAD command

processing automatically preprocesses the package again, thus revalidating it. Any

unresolved dependencies in the package are then flagged when the RELOAD

command preprocesses it again.

Note: The UNLOAD PACKAGE command is not supported if you are using

DRDA flow.

Following are descriptions of each part of the command:

PACKAGE (package_name)

identifies an UNLOAD PACKAGE request and the package to be processed.

In DB2 Server for VSE, you can further qualify the package_name with the

owner, separating the two names with a period.

The name of the package is package_name. If you do not specify the owner (see

“Qualifying Object Names” on page 110 for details), owner defaults to the

currently connected authorization ID.

The DB2 Server for VM authorization ID is either:

Chapter 8. Command Reference

211

v The authorization ID specified in a previous explicit CONNECT (when

FROM is not used)

v The VM user ID (when FROM is used) because it is the user ID used to

connect to server_name.

FROM (server-name)

in DB2 Server for VSE, this identifies the application server against which the

UNLOAD PACKAGE command should be issued. If an LUW is active, the

UNLOAD command is unsuccessful and an error occurs.

In DB2 Server for VM, this identifies the application server containing the

package. To unload the package, the Database Services Utility connects to the

specified server_name (using application server switching, which requires

APPC/VM in multiple user mode). If an LUW is active, the UNLOAD

command fails with an error. When FROM is specified, the CONNECT is

attempted with no user ID or password. The attempted connection fails if

implicit connects are not allowed on server_name.

After the package is unloaded, a COMMIT (or ROLLBACK) RELEASE is done,

releasing the connection to server_name. The default user ID (the VM user ID),

and the default database (as specified to SQLINIT) are reestablished for a new

LUW. Any explicit CONNECT statements that you issued before the UNLOAD

command are therefore lost and must be reissued, if required. When you use

FROM, the Database Services Utility ignores any preceding CONNECT

statements and uses the VM user ID as a default. If you do not want to use

your VM user ID, issue the explicit CONNECT statements as needed, and use

the UNLOAD command without a FROM clause.

OUTFILE (ddname)

identifies and describes the sequential (SAM) tape or disk output file that is to

contain the unloaded package. UNLOAD program processing uses a record

format of fixed-length blocked (FB) and a record length of 80. The block size,

in a VM environment, must be a multiple of 80 and defaults to 80 if not

specified. This file contains only one unloaded package. If the file already

exists, its contents are replaced; otherwise, the file is created.

ddname

in DB2 Server for VM, this is the name of the sequential output file defined

with a CMS FILEDEF command. Do not specify SYSIN or SYSPRINT as

the ddname.

In DB2 Server for VSE, this is the TLBL or DLBL job control statement file

name for the sequential output file.

BLKSZ (size) (DB2 Server for VSE only)

is an optional parameter that specifies the block size of the sequential output

file. It must be a multiple of 80. The default block size is 2000 bytes per block.

PDEV (TAPE or DASD)

is an optional parameter that specifies the device type (DASD or TAPE) for the

sequential output file. Specify PDEV(DASD) for files that reside on any device

supported by the VSE DTFSD macro. Specify PDEV(TAPE) for files that reside

on any device supported by the VSE DTFMT macro. The default is

PDEV(TAPE).

BLKSZ and PDEV can be specified in any order but must occur after the

ddname parameter.

212

Database Services Utility

NOREWIND or REWIND

controls tape file rewind processing performed during CLOSE processing. This

parameter is valid only if you specify TAPE for PDEV. The default is

NOREWIND.

NOREWIND

specifies that the tape file is not rewound by CLOSE processing.

REWIND

specifies that the tape file is rewound by CLOSE processing.

REBIND PACKAGE

REBIND PACKAGE Format

Format:

EXPLAIN (NO)

►► REBIND PACKAGE

(package_name)

EXPLAIN (YES)

►◄

Example:

REBIND PACKAGE(SMITH.PROG)

Authorization:

You must be the owner of the package you want to rebind. To rebind another user’s

package, you must have DBA authority.

The REBIND PACKAGE command allows you to repreprocess an existing package

immediately without unloading and reloading the package. You can use the

REBIND PACKAGE command with single or multiple user mode.

Note: The REBIND PACKAGE command is not supported if you are using the

DRDA protocol.

Following is the description of the command:

PACKAGE (package_name)

identifies the package that you want to rebind.

You can qualify the name of the package by specifying the owner of the

package; you must, however, have DBA authority to repreprocess a package

belonging to another user. If you do not specify the owner, owner defaults to

the connected authorization ID. See “Qualifying Object Names” on page 110

for details on accessing data objects that are owned by other users.

EXPLAIN(YES or NO)

determines if explain processing should be performed.

If EXPLAIN(YES) is specified, then EXPLAIN ALL processing will be done and

the explain tables will be updated. See EXPLAIN in the DB2 Server for VSE &

VM SQL Reference for details on EXPLAIN processing.

If EXPLAIN is not specified, the default is NO.

Chapter 8. Command Reference

213

Set-Item Commands

SET AUTOCOMMIT

SET AUTOCOMMIT Format

Format:

(

OFF

)

►►

SET AUTOCOMMIT

►◄

The SET AUTOCOMMIT command allows you to activate or suppress the

execution of SQL COMMIT statements by the Database Services Utility. This

command cannot span input records.

OFF

identifies that you do not want the utility to commit database changes after

control commands are successfully processed. You must supply SQL COMMIT

statements in the Database Services Utility input stream at the points at which

you commit the changes.

In this mode of operation, the only execution of an SQL COMMIT by the

utility is at the end-of-program after all control commands have been

successfully processed.

ON or OFF must be specified in this command. If you do not supply a SET

AUTOCOMMIT command in the input records, the utility operates as if you

had issued SET AUTOCOMMIT OFF.

identifies that you want the utility to run an SQL COMMIT command after the

successful processing of any control command (that is, Database Services

Utility commands or SQL statements) except those noted below. The utility

ensures that any database changes made before the receipt of the

AUTOCOMMIT ON command are committed before processing continues.

In AUTOCOMMIT ON mode, the Database Services Utility does not run an

SQL COMMIT command after the successful processing of these commands:

SQL Statements

Database Services Utility Commands

COMMIT

COMMENT

CONNECT

SET AUTOCOMMIT OFF

LOCK

SET ERRORMODE

ROLLBACK

SET FORMAT

SET ISOLATION

SET LINECOUNT

SET LINEWIDTH

SET UPDATE STATISTICS

214

Database Services Utility

SET ERRORMODE

SET ERRORMODE Format

Format:

(

OFF

)

►►

SET ERRORmode

►◄

CONTINUE

The SET ERRORMODE command allows you to:

v Suspend the normal Database Services Utility actions taken after a command

processing error is detected and cause the utility to continue processing

commands after an error has occurred.

v Force the Database Services Utility to enter error mode processing.

v Resume normal Database Services Utility command processing.

This command cannot span input records. If you do not supply a SET

ERRORMODE command in the input records, the utility operates as if you had

issued SET ERRORMODE OFF.

OFF

causes the utility to resume execution of Database Services Utility commands

and SQL statements after a command processing error has occurred or to

terminate error mode CONTINUE processing.

Any subsequent command processing errors cause the utility to execute an

SQL ROLLBACK statement and enter Database Services Utility error mode

processing.

Notes:

1. The SET ERRORMODE OFF command also terminates the processing mode

established by the Database Services Utility SET AUTOCOMMIT ON

command.

2. A SET ERRORMODE OFF command is not used:

a. If the error mode is already off.

b. If a serious database error has previously occurred. A serious error, by

definition, causes all subsequent SQL statements to terminate. Thus, a

SET ERRORMODE OFF command in this case has no effect.

causes the utility to suspend execution of following Database Services Utility

commands and SQL statements. A SET ERRORMODE ON command

terminates:

v The normal command processing mode that was established by default

when the utility was run or by a previous SET ERRORMODE OFF command

v The processing mode established by a SET ERRORMODE CONTINUE

command.

When a SET ERRORMODE ON command is processed, the utility initiates

error mode processing. While in error mode, the Database Services Utility

displays commands in the report or message file listing and performs syntax

Chapter 8. Command Reference

215

checking on Database Services Utility commands. No SQL statements or

Database Services Utility commands (except SET ERRORMODE OFF or SET

ERRORMODE CONTINUE) are executed during error mode processing.

Therefore, any errors that result from command execution (for example, SQL

syntax errors and data file errors) are not detected.

Database Services Utility error mode processing is also entered when the utility

detects a command processing error, and the utility is operating in normal

command processing mode. If the processing mode established by a SET

ERRORMODE CONTINUE command is in effect, and a command processing

error is detected, Database Services Utility error mode processing is entered

only when the error is a serious database error.

Notes:

1. A SET ERRORMODE ON command also terminates the processing mode

established by the SET AUTOCOMMIT ON command.

2. A SET ERRORMODE ON command is not used if Database Services Utility

error mode processing is already in effect.

CONTINUE

suppresses the normal Database Services Utility error processing after an error

is detected; that is, Database Services Utility error mode processing is not

performed. An SQL ROLLBACK statement is not executed, and the utility

continues to process Database Services Utility commands and SQL statements

after a command processing error occurs. If any errors occur, and they occur

only while SET ERRORMODE CONTINUE is in effect, the Database Services

Utility issues error message ARI8007I when the Database Services Utility

command processing ends.

Notes:

If a serious database error occurs while the processing mode established by

a SET ERRORMODE CONTINUE command is in effect, an SQL

ROLLBACK is executed, and the utility enters error mode processing. A

serious database error, by definition, causes all subsequent SQL statements

to terminate.

After a SET ERRORMODE CONTINUE command is processed, because the

Database Services Utility does not execute an SQL ROLLBACK command

does not mean that the logical unit of work is always in progress. Certain

SQL statement errors cause the logical unit of work to be terminated by the

database manager. If one of these errors occurs, all database changes made

during the logical unit of work or since the last SQL COMMIT statement

are lost.

To control the logical unit of work after a SET ERRORMODE CONTINUE

command is processed, you can use SQL COMMIT statements or the

Database Services Utility SET AUTOCOMMIT ON command.

The SET ERRORMODE CONTINUE command is not used:

a. If the processing mode established by a previous SET ERRORMODE

CONTINUE command is still in effect

b. If a serious database error has previously occurred.

If the Database Services Utility is not in error mode when a SET

ERRORMODE CONTINUE command is encountered, the Database Services

Utility AUTOCOMMIT processing status is not changed.

If the Database Services Utility is in error mode when a SET ERRORMODE

CONTINUE command is encountered, the Database Services Utility

AUTOCOMMIT processing status is set to off.

216

Database Services Utility

5. Database Services Utility end-of-program COMMIT processing is based on

the current status of the command processing. That is, if Database Services

Utility error mode processing and the SET AUTOCOMMIT ON command

processing mode are not in effect, Database Services Utility end-of-program

COMMIT processing is performed.

6. All SQL statements are treated as one LUW when running the database

with LOGMODE=N and Database Services Utility with

AUTOCOMMIT=OFF and ERRORMODE=CONTINUE. If an error occurs,

ALL statements are rolled back.

Note: The ERRORMODE setting has an effect on the final Database Services Utility

return code. For more information, see Chapter 9, “Error Handling and

Debugging,” on page 223.

SET FORMAT

SET FORMAT Format

Format:

(

)

►►

SET FORMAT

►◄

This command allows you to identify whether the Database Services Utility should

use column or block format, column or list format, or only list format for SQL

SELECT statement results. If the format is not specified, Database Services Utility

processing uses column or block format for SQL SELECT statement output. This

command cannot span input records.

The SET FORMAT command overrides the formats specified by either a parameter

list format control parameter or the default column or block format. This command

specification remains in effect until another SET FORMAT command is

encountered and successfully processed, or when Database Services Utility

processing ends.

identifies that either column or block format should be used. The column

format is used when a report or message file record can contain all column

names or column data for a selected row. The block format is used when a

report or message file record cannot contain all column names or column data

for a selected row. Column or block format is the default if you do not

override it by supplying either a format control parameter—FORMAT(CL) or

FORMAT(LO)—or a SET FORMAT command.

identifies that either column or list format should be used. The column format

is used when a report or message file record can contain all column names or

column data for a selected row. The list format is used when a report or

message file record cannot contain all column names or column data for a

selected row.

Chapter 8. Command Reference

217

DB2 Server for VSE. Operations Guide / Handbooks (2004-2007) - page 38
