Combine harvesters. PARTICULARS





PARTICULARS
PAGE NO.
INTRODUCTION
1
CLAAS DOMINATOR 100 -105
2
CLAAS DOMINATOR 56 - 66
2
CLAAS DOMINATOR 58
3
CLAAS DOMINATOR 68
3
CLAAS DOMINATOR 76
4
CLAAS DOMINATOR 78
4
CLAAS DOMINATOR 80 - 85
5
CLAAS DOMINATOR 86
5
CLAAS DOMINATOR 96
6
CLAAS DOMINATOR 98 S/SL
6
CLAAS MATADOR
7
CLAAS MERCATOR S70-75
7
CLASS MERCUR
8
CLAAS PROTECTOR
8
CLAAS SENATOR 80 - 85
9
NEW REFERENCES
9
NEW REFERENCES
10
NEW HOLLAND 8040 - 8055
10
NEW HOLLAND 8030
11
NEW HOLLAND 8050 - 8060
11
NEW HOLLAND 8070
12
NEW HOLLAND 8080
12
NEW HOLLAND TX30
13
NEW HOLLAND TX30 RH
13
NEW HOLLAND TX32
14
NEW HOLLAND TX32
14
NEW HOLLAND TF42
15
NEW HOLLAND TF44
15
NEW HOLLAND TF46
16
NEW HOLLAND TX34
16
NEW HOLLAND TX36
17
NEW HOLLAND TX36
17
NEW REFERENCES
18
JOHN DEERE 330 - 430
18
JOHN DEERE 530 - 630 - 730
19
JOHN DEERE 925
19
JOHN DEERE 930 - 940
20
JOHN DEERE 950 - 960 - 970
20
MASSEY FERGUSON 24
21
MASSEY FERGUSON 760/765/780/860/865
21
LAVERDA M100M120
22
LAVERDA 3350 ex.m112al
22
LAVERDA M132
23
LAVERDA 3350 exm112
23
LAVERDA 3450
24
LAVERDA 3300/3300al
24
LAVERDA 3600/3700/3790
25
LAVERDA 3900
25
DEUTZ FAHR TOPLINER 460
26
NEW REFERENCES-”CASE”
26
PREVENTIVE MAINTENANCE TIPS
27
PREVENTIVE MAINTENANCE TIPS
28
TYPES OF FAILURES
29
DO’S AND DON’TS
29
NOTES
30
PIX AGRI BELTS
PIX Agribelts are available in different types
e.g. Regular section, Hexagonal section,
Variable speed belts and Banded. They are
specially made to provide maximum service
life in the practical application.
Hexagonal section provides the stability and
support to transmit power on Agricultural
serpentine drives.
Agriculture Variable Speed Belts are
specially designed to withstand the high
ambient temperature and oily conditions
generally encountered in adjustable speed
applications. For heavy duty application
these belts are provided with special type of
fabric at bottom for the extra flexibility
required on small diameter pulleys and also
with fibre filled compound on top side to
impart extra rigidity in transverse direction.
This enables the belt to withstand the forces
and loads subjected during movement inside
split type of pulleys.
The notable feature of Agricultural Variable
Speed belts is that they transmit much
higher loads over a narrower speed range.
Therefore, Agricultural Variable Speed belts
require higher tensile strength and are
thicker with more reinforcement in the
tensile support than Industrial belts.
PIX Banded belts are more suitable in
conditions where high vibrations and shock
loads are expected.
Salient features of PIX Agribelts
• PIX Agribelts are designed for efficient power transmission with minimised heat generation.
• A special rubber compound with textile fibre oriented across the transverse direction of
length of the Cut Edge Belts provides high stability and minimizes deflection in the cross
section.
• The minimum stretch stiff polyester cords have been designed for heavy power
transmission, while at the same time ensuring a very high degree of length stability.
• The sides of the belts have excellent abrasion resistant properties contributing significantly
to long and useful belt life.
• Moulded cogs reduces bending stresses and improves heat dissipation in Cut Edge
construction.
1
LH
RH
1
2
4
5
6
7
13
14
15
16
9
3
10
13
11
8
17
18
19
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
670224.0
HC670224
Variable speed reel
11
672359.1
HC672359
Shaker shoe return
2
672353.0
HC672353
Cutting table
12
629081.1
HC629081
Grain auger
3
629000.1
HC629000
Threshing machine
13
629732.1
HC629732
Elevator
4
629001.0
HC629001
Hyd pump traction
14
501925.0
HC501925
Feeder elevator
5
629002.1
HC629002
Hyd pump
15
060306.2
HC060306
Countershaft
6
673614.0
HC673614
Grain tank
16
802931.0
HC802931
Air in-take
7
672358.0
HC672358
Shaker shoe
17
061253.1
HC061253
Straw chopper
8
629036.0
HC629036
Straw walker
18
629035.0
HC629035
Cylinder vari drive
9
629214.0
HC629214
Knife drive
19
629510.1
HC629510
Threshing machine
10
671209.0
HC671209
Variable speed fan
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
11
12
13
14
15
16
17
28
3
35
7
6
3
34
7
21
22
23
24
25
31
32
33
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
670224.0
HC670224
Variable speed
21
629436.0
HC629436
Drive
2
656028.0
HC656028
Hydraulic pump
22
629756.0
HC629756
Land drive
3
670224.0
HC670224
Variable speed
23
671209.0
HC671209
Fanning mill
6
603122.0
HC603122
Feed drive
24
603017.3
HC603017
Sieve drum drive
11
767057.0
HC767057
Hydraulic pump
25
635494.0
HC635494
Straw spreader
12
621903.0
HC621903
A/c compressor
35
629214.0
HC629214
Reel drive
13
673614.0
HC673614
Grain unload auger
35
056961.0
HC056961
Reel variator
14
671012.1
HC671012
Drum drive
28
783430.1
HC783430
Rotary screen
15
603337.0
HC603337
Fanning mill
31
061361.1
HC061361
Chopper drive
16
603336.1
HC603336
Shaker shoe drive
32
060306.2
HC060306
Counter shaft drive
17
506671.1
HC506671
Walker drive
33
603015.1
HC603015
Variator drum
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
2
LH
RH
3 4
5
6
8
10
+
+
+
+
1
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
16
17
2
11
12
14
13
9
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
778561.0
HC778561
Pick up reel
10
802931.0
HC802931
Air intake
2
724301.0
HC724301
Cutter table
11
724168.0
HC724168
Feed drive
3
724141.0
HC724141
Fanning mill
11
724339.0
HC724339
Feed drive
4
724100.0
HC724100
Threshing mech
12
629756.0
HC629756
Land drive
5
673614.0
HC673614
Grain tank unload
13
724247.0
HC724247
Impellor
6
767057.0
HC767057
Hydraulic pump
14
603380.0
HC603380
Cleaning fan
7
783268.1
HC783268
Compressor (set 2)
15
061902.0
HC061902
Chopper drive
8
724180.0
HC724180
Fan drive
16
061872.0
HC061872
Chopper drive final
8
724181.0
HC724181
Fan drive
17
603015.1
HC603015
Variator drum
9
785176.0
HC785176
Straw walker
17
628630.0
HC628630
Variator drum
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
1
2
3
10 11
14
27
28
4
16
17
18
19
20
21
24
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
603284.0
HC603284
Reel drive
17
629836.1
HC629836
Feeder drive (set 2)
2
056961.0
HC056961
Reel variator
18
673638.0
HC673638
Straw elevator
3
670224.0
HC670224
Variable speed
19
629756.0
HC629756
Land drive
4
603283.0
HC603283
Knife drive up to 3 MT
20
603380.0
HC603380
Fan variator
4
731506.2
HC731506
Knife drive 3.6 - 5.10 MT
21
724247.0
HC724247
Drum impellor
10
673614.0
HC673614
Grain tank unload
24
603015.1
HC603015
Drum variator
11
767057.0
HC767057
Hydraulic pump
27
061902.0
HC061902
Straw chopper
14
802931.0
HC802931
Air intake
28
061872.0
HC061872
Straw chopper
16
629214.0
HC629214
Knife drive
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
3
LH
RH
30
11
1
2
3
4
5
6
7
8
18
21
22
24
25
26
27
33
34
35
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
603625.0
HC603625
Hydro pump traction drive
20
629214.0
HC629214
Knife drive
2
767057.0
HC767057
Hydraulic pump
21
673638.0
HC673638
Straw elevator
3
621903.0
HC621903
A/c compressor drive
22
629436.0
HC629436
Traction drive
4
673614.0
HC673614
Grain tank unload
24
671209.0
HC671209
Fanning mill vari speed
5
671012.0
HC671012
Main drive
25
603017.3
HC603017
Returns auger
6
603337.0
HC603337
Fanning mill
26
506671.1
HC506671
Straw walker
6
672358.0
HC672358
Fanning mill
27
623427.1
HC623427
Straw spreader
7
603336.1
HC603336
Shaker drive
30
783430.0
HC783430
Rotary screen
7
672359.1
HC672359
Shaker drive
33
061360.0
HC061360
Straw chopper
8
629732.1
HC629732
Elevator drive
34
060306.0
HC060306
Counter shaft
11
670224.0
HC670224
Reel vari speed
35
603015.1
HC603015
Drum variator
18
603122.0
HC603122
Feeder drive
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
10
1
2
3
4
5
6
7
8
21
19
9
11 12
13
14
15
16
17
18
20
22
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
603625.0
HC603625
Hydro pump traction drive
11
629836.0
HC629836
Feed drive
2
767057.0
HC767057
Hydraulic pump
12
673638.0
HC673638
Cutting table clutch
3
629908.1
HC629908
A/C Compressor drive
13
603427.0
HC603427
Traction drive
4
673614.0
HC673614
Grain tank unload
14
603317.0
HC603317
Variator traction drive
5
671012.0
HC671012
Main drive
15
671209.0
HC671209
Variable speed fanning mill
6
603337.0
HC603337
Fanning mill
16
603017.3
HC603017
Returns auger
6
672358.0
HC672358
Fanning mill
17
506671.0
HC506671
Straw walker
7
603336.1
HC603336
Shaker drive
18
623427.1
HC623427
Straw spreader
7
672359.1
HC672359
Shaker drive
19
603341.0
HC603341
Rotary screen
8
629732.1
HC629732
Elevator drive
20
061360.0
HC061360
Straw chopper
9
670224.0
HC670224
Reel vari speed
21
060306.0
HC060306
Counter shaft
10
778717.0
HC778717
Cutting table
22
628630.0
HC628630
Drum Variator
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
4
16
17
18
LH
RH
1
2
4
5
6
3
7
8
9
10
11
12
13
14
15
19
20
21
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
670224.0
HC670224
Reel speed
13
671209.0
HC671209
Variable speed
2
560562.0
HC560562
Cylinder drive
14
672359.0
HC672359
Shaker shoe
3
671012.1
HC671012
Main drive
15
673690.1
HC673690
Grain auger
4
673625.0
HC673625
Hydraulic pump traction
16
501925.0
HC501925
Feeder auger
5
532011.1
HC532011
Hydraulic pump
17
060306.2
HC060306
Counter shaft
6
656028.0
HC656028
Hydraulic pump
18
802931.0
HC802931
Air intake
7
672358.0
HC672358
Shaker drive
19
060949.1
HC060949
Straw chopper
8
673601.0
HC673601
Straw walker
20
671015.0
HC671015
Vari speed cylinder
9
769202.0
HC769202
Knife drive
21
671012.1
HC671012
Threshing
8
778717.0
HC778717
Table drive
N/I
629035.1
HC629035
Cylinder drive
11
720866.0
HC720866
Traction drive
N/I
629214.1
HC629214
Knife drive
12
671083.0
HC671083
Traction drive
* The text in italics indicates part numbers that belongs to RHS of the image.
10
1
2
3
4
5
6
7
18
LH
RH
13
14
15
16
17
18 19
20
21
29
20
21
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
767057.0
HC767057
Hydraulic pump
16
603427.0
HC603427
Traction drive
2
621903.0
HC621903
Air con compressor
17
603317.0
HC603317
Land wheel
3
673614.0
HC673614
Grain tank
19
603017.0
HC603017
Returns auger
4
671012.0
HC671012
Drum drive
24
603341.0
HC603341
Rotary screen
5
603337.0
HC603337
Fanning mill
27
060306.2
HC060306
Counter drive shaft
6
603336.1
HC603336
Shaker drive
28
603015.1
HC603015
Drum variator
7
629732.1
HC629732
Elevator
18
671209.0
HC671209
Returns auger
10
670224.0
HC670224
Reel vari
20
506671.1
HC506671
Straw walker
13
629214.0
HC629214
Knife drive
21
635494.0
HC635494
Straw spreader
14
603122.0
HC603122
Feed drive
29
061361.1
HC061361
Straw chopper
15
673638.0
HC673638
Drive power band
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
5
LH
12
1
2
3
4
5
6
7
8
9
RH
26
28
29
30
15
16 17 18
19
20 21
22
23
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
176543.0
HC176543
Hydrostatic drive
17
673638.0
HC673638
Straw elevator
2
767057.0
HC767057
Hydraulic pump
18
609822.0
HC609822
Land wheel
3
629903.1
HC629903
A/C Comp upto 09002764
19
609823.0
HC609823
Variator drive
3
629908.1
HC629908
A/C Comp from 09002765
20
671209.0
HC671209
Variable speed
4
673614.0
HC673614
Grain tank unload
21
603017.0
HC603017
Returns auger
5
671012.1
HC671012
Drum drive
22
506671.1
HC506671
Straw walker
6
603337.0
HC603337
Fanning mill
23
623427.1
HC623427
Straw walker
7
603336.1
HC603336
Shaker drive
26
603341.0
HC603341
Rotary screen
8
629732.1
HC629732
Elevator
28
061360.0
HC061360
Straw chopper
9
802931.0
HC802931
Air intake
29
060306.2
HC06306
Counter shaft
12
670224.0
HC670224
Variable reel
30
603015.1
HC603015
Drive variator
15
629214.0
HC629214
Knife drive
N/I
673625.0
HC673625
Hyd. Pump traction drive
16
603122.0
HC603122
Feed drive
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
10
1
2
3
4
5 6
7
8
9
22
23
13
14 15 16
17
18
19
20
21
25
26
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
629001.0
HC629001
Hydro pump with merc eng
13
671013.1
HC671013
Knife drive
1
629133.0
HC629133
Hyd pump merc eng
14
061872.0
HC061872
Feed drive set 1
1
673625.0
HC673625
Hyd pump merc/perk eng
14
629836.0
HC629836
Feed drive set 2
2
603378.0
HC603378
Hyd pump merc eng
15
673628.0
HC673628
Straw elevator
2
767057.1
HC767057
Hyd pump
16
609822.0
HC609822
Land drive mechanical
3
629908.1
HC629908
A/c compressor
17
609823.0
HC609823
Land drive variator
4
629769.0
HC629769
Grain tank unload
18
671209.0
HC671209
Variable speed fanning mill
5
629000.0
HC629000
Engine coupling merc
19
603017.3
HC603017
Returns auger
5
671012.1
HC671012
Eng coupling perkins
20
506671.1
HC506671
Straw walker
6
603337.0
HC603337
Drive to fanning mill
21
623427.1
HC623427
Straw spreader
7
603336.1
HC603336
Shaker drive
22
060306.2
HC060306
Counter shaft
8
629732.1
HC629732
Elevator
23
603341.0
HC603341
Rotary sieve
9
802931.0
HC802931
Air intake
25
061360.0
HC061360
Straw chopper
10
670224.0
HC670224
Reel vari speed
26
628630.0
HC628630
Dresser
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
6
LH
RH
7
4
10
9
3
11
13
12
6
1
5
8
2
17
14
15
16
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
500863
HC500863
Cutting table
9
630025
HC630025
Main drive
2
500868
HC500868
Straw bailer
9
630043
HC630043
Drum drive
3
551068
HC551068
Counter shaft
10
767057
HC767057
Hydraulic pump
4
630144
HC630144
Traction drive
11
772658
HC772658
Shaker shoe
4
505051
HC505051
Traction drive
12
778561
HC778561
Reel variator
5
653121
HC653121
Elevator fan
13
800309
HC800309
Pick up
5
610196
HC610196
Elevator fan
14
636021
HC636021
Tank auger
6
610833
HC610833
Table drive
15
630156
HC630156
Variator
7
617039
HC617039
Cylinder
16
750294
HC750294
Turning drum
8
623252
HC623252
Shaker shoe
17
801222
HC801222
Straw walker set 4
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
4
6
7
1
2
10
12
15
13
11
14
5
8
3
9
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
653060
HC653060
Main drive
9
653120
HC653120
Shaker shoe drive
2
656028
HC656028
Hydraulic pump
10
634019
HC634019
Grain tank
3
630144
HC630144
Main drive
11
750294
HC750294
Turning drum
4
778561
HC778561
Variable speed reel
12
755070
HC755070
Straw walker (2)
5
630833
HC630833
Knife drive (set 2)
12
750294
HC750294
Turning drum
6
610830
HC610830
Knife drive (set 2)
13
654354
HC654354
Tank unloader
7
617309
HC617309
Cylinder vari drive
14
655408
HC655408
Traction drive
8
653380
HC653380
Fanning mill
15
687046
HC687046
Shaker
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
7
LH
RH
2
8
4
16
15
14
13
9
5
3
7 6
1
10
17
11
12
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
500863
HC500863
Cutting table
9
800309
HC800309
Pick up
2
758719
HC758719
Cooling fan
10
551190
HC551190
Straw chopper
2
758662
HC758662
Cooling fan
11
751112
HC751112
Traction vari drive
3
778717
HC778717
Knife drive
12
755070
HC755070
Hydraulic pump
3
770214
HC770214
Knife drive
13
750316
HC750316
Driving wheel vari
4
775689
HC775689
Grain spreader
14
758854
HC758854
Threshing clutch
5
778561
HC778561
Reel variator
15
773313
HC773313
Straw walker set 2
6
779039
HC779039
Cylinder
16
779212
HC779212
Straw walker screen
7
779214
HC779214
Traction
17
779213
HC779213
Shaker shoe
8
780419
HC780419
Grain tank
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
14
4
9
3
8
12
11
13
10
1
5
2
7
6
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
610830.0
HC610830
Feed auger pick up
7
653121.0
HC653121
Fan variator shaft
1
610833.0
HC610833
Feed auger pick up
8
653450.0
HC653450
Screen drive
2
617309.0
HC617309
Drum variator
9
656028.0
HC656028
Hydraulic pump
3
653062.0
HC653062
Main drive
10
778561.0
HC778561
Variable speed
3
653059.0
HC653059
Main drive
11
653779.0
HC653779
Tank discharge
4
653060.0
HC653060
Main drive powerband
12
653933.0
HC653933
Straw walker
5
656063.0
HC656063
Feed elevator variator
13
655408.0
HC655408
Driving wheel
6
653120.0
HC653120
Fan screen drive
14
750294.0
HC750294
Rear beater
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
8
LH
RH
5
4
3
12
9
1
6
2
8
7
13
11
10
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
610830.0
HC610830
Feed auger pick up
8
653380.1
HC653380
Fan variator > 77001807
1
610833.0
HC610833
Feed auger pick up
8
653121.0
HC653121
Fan variator < 77000100
2
617309.0
HC617309
Drum variator
9
778561.0
HC778561
Reel variator
3
630144.0
HC630144
Engine shaft
10
631904.0
HC631904
Variator <77000100
3
653059.0
HC653059
Main drive
10
655408.0
HC655408
Variator >77000101
3
653062.0
HC653062
Main drive
11
654013.0
HC654013
Intermediate shaft
4
633030.0
HC633030
Hydraulic pump
12
750294.0
HC750294
Rear beater
5
653060.0
HC653060
Main drive multi V
13
653933.0
HC653933
Straw walker
6
653063.0
HC653063
Feed shaft variator
*
13
801222.0
HC801222
Straw walker
7
653120.0
HC653120
Screen drive
*N/I
653450.0
HC653450
Grain tank
* The text in italics indicates part numbers that belongs to RHS of the image.
ITEM
OEM REF.
PIX REF.
Description
1
XX077276.0
GMC077276
Rotary Screen Drive Jaguar 820-840
2
XX661245.0
HC661245
Engine Shaft Drive Dominator 208 - 218 Mega
3
XX661345.0
HC661345
Cooler Fan Drive Dominator 203 - 218 Mega
4
XX821734.2
HC821734
Rotary Screen Drive Dominator 108 - 118
5
XX052393.1
GMC052393
Air Conditioning Drive Jaguar 820 - 840
6
XX644781.0
HC644781
Fan Drive Lexion 415 - 460
7
XX750193.2
GMC750193
Hydraulic Pump Drive Jaguar 675 - 680
8
XX667242.0
HC667242
Fan & Rotary Screen Drive Lexion Range
9
XX077400.0
GMC077400K
Axial Flow Fan Drive Jaguar 820 - 840
10
XX667798.2
HC667798
Straw Spreader Drive - 1st Stage Lexion 480
11
XX667477.0
HC667477
Straw Walker Drive Lexion Range
12
XX644447.0
HC644447
Air Intake Drive Dominator 203 - 218 Mega
13
XX742206.0
GMC742206
Axial Flow Fan Drive Jaguar 860 - 880
14
LL667684.0
HC667684
Straw Chopper Drive -Fourth Stage Lexion 415 -430
15
XX742025.0
HC742025
Knife Drive Lexion 480
16
XX644209.0
HC644209
Sieve Pan Drive - Primary Lexion range
17
LL061353.1
HC061353
Straw Chopper Drive Dominator 203 - 218 Mega
18
XX644419.0
HC644419
Cutter Bar Clutch Drive Commander 116 - 228
19
XX603430.0
HC603430
Cutter Bar Clutch Drive Dominator 108 - 228 Mega
20
XX667454.0
HC667454
Intake Drive Lexion range
21
XX667249.0
HC667249
Impellor Drum Drive Lexion range
22
LL667251.0
HC667251
Speed Reducing Gearbox Drive Lexion Range
23
LL644538.0
HC644538
Drum V/S Drive Dominator 203 - 204 Mega
24
XX667681.0
HC667681
Grain Tank Unloader Drive Lexion 405 - 430
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
9
ITEM
OEM REF.
PIX REF.
Description
25
XX667252.0
HC667252
Sieve Pan Drive - Second Stage Lexion Range
26
XX644866.0
HC644866
Sieve Pan Drive Third Stage Lexion 480
27
XX749712.0
HC749712
Straw Chopper Drive - 3rd Stage Lexion 480
28
LL661093.0
HC661093
Straw Copper Drive - Final Lexion 440 - 460
29
XX667250.0
HC667250
Unloader Drive Lexion 440 - 460 & 480
30
XX667427.0
HC667427
Hybrid Drive 2nd Stage Lexion 480
31
XX176442.1
HC176442
Drum Drive Lexion 415 -430 and some 440 - 460
32
XX667554.0
HC667554
Hybrid Drive - 1st Stage Lexion 480
33
LL644685.1
HC644685
Straw Copper Drive - Primary Lexion 480
34
XX073204.0
GMC073204
Corn Cracker Drive Jaguar 682 - 685
35
XX067789.0
GMC067789K
Corn Cracker Drive Jaguar 830 - 900
36
LL077797.0
GMC077797K
Engine Output Drive 228kW Jaguar 820 - 840 (alt)
37
LL070952.2
GMC1085K
Cutting Cylinder Drive Jaguar 685L - 690
38
XX074771.2
GMC1083K
Cutting Cylinder Drive Jaguar 685SL (alt) 695SL
39
XX074803.2
GMC1082K
Cutting Cylinder Drive Jaguar 685SL (alt) 690SL
40
XX667453.0
HC667453
Drum Drive Lexion 440 - 460
41
XX077796.0
GMC077796K
Engine Output Drive Jaguar 860 - 880 820 - 840 (alt) 265kW
42
XX067746.0
GMC067746K
Aux Gearbox / Engine Output Jaguar 870 - 850
43
XX076401.0
GMC076401K
Engine Output Drive Jaguar 860
44
XX067747.1
GMC067747K
Aux Gearbox / Engine Output Jaguar 890 - 900
45
XX 667456.0
HC667456
Rotary Screen Drive Lexio 440 - 460 & 480
46
XX 667248.0
HC667248
Drum Drive Lexion 440 - 460 and some 415 - 430
47
LL-176542.1
HC176542
Hydrostatic Pump Drive Dominator 106 - 108
48
LL-176543.1
HC176543
Hydrostatic Pump Drive Dominator 76 - 96
& Traction Drive Jaguar 675 - 680
LH
18
19
3
2
1
RH
10 21
4
6
16
11
20
15
7
12
17
14
13
9
8
5
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80116140
Chain
10
80422281
HN422281
Main drive
2
80443634
HN443634
Fan, alternator, water pump
11
80356024
HN356024
Upper ground speed
3
80427455
HN427455
Radiator fan drive
12
80116140
Chain
4
80223589
Chain
13
80422731
HN422731
Grain elevator bottom auger
5
80336784
HN336784
Drum vari drive
14
80439129
HN439129
Lower ground speed
6
80116140
Chain
15
80387469
HN387469
Eccentric shaft drive
7
80230057
HN230057
Upper cleaning fan drive
16
80066232
HN066232
1HB straw elevator drive
8
80395955
HN395955
Lower cleaning fan drive
16
80424563
HN424563
2HB straw elevator drive
9
80431784
HN431784
Straw walker drive
17
80330715
HN330715
Header drive 8040
18
80422441
HN422441
Rotary dust screen drive
17
80394426
HN394426
Header drive 8055
19
80427456
HN427456
Fan & rotary dust screen
21
80230164
HN230164
Grain tank auger 8040
20
80393519
HN393519
Hydraulic pump drive
21
80447041
HN447041
Grain tank auger 8055
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
10
LH
RH
22
21
3
2
1
10
19
18
5
4
16
11
15
20
7
12
9
8
6
17
14
13
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80395313
Chain grain tank
21
80427455
HN427455
Radiator fan drive
2
80443634
HN443634
Alternator & water pump
22
80422441
HN422441
Rotary dust screen
2
80444045
HN444045
Alternator & water pump
10
80422281
HN422281
Powerband main drive *Ford
2
80443636
HN443636
Alternator & water pump
10
80447031
HN447031
Powerband main drive *Merc
3
80393519
HN393519
Hydraulic pump
11
80356024
HN356024
Ground speed vari-drive
4
80422725
HN422725
Grain tank unloading
12
80116140
Chain tailings elevator
5
80116140
Chain tailings top auger
13
80422731
HN422731
Elevator drive
6
80336784
HN336784
Drum vari drive
14
80356024
HN356024
Ground speed vari-drive
7
80230057
HN230057
Fan vari drive
15
80387469
HN387469
Eccentric shaft drive
8
80395955
HN395955
Fan vari drive
16
80066232
HN066232
2HC straw elevator drive
9
80431784
HN431784
Straw walker drive
17
80330715
HN330715
Header drive
18
80450600
HN450600
Chain grain tank
19
80427456
HN427456
Rotary dust screen drive
20
80427456
HN427456
Rotary dust screen
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
1
7
2
3
4
RH
2
1
11 10 12
9
3
4
5
5
7
8
6
9
8
10
6
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80451481
HN451481
Beater drive
1
80432802
HN432802
Alt.& Water pump 8060 only
2
80397297
HN397297
Drum variator
2
80399058
HN399058
Dust screen drive
3
80230151
HN230151
Hydraulic pump
3
80457643
HN457643
Rotary dust screen drive
4
80389245
HN389245
Interim dust screen drive
4
80350418
Chain
5
80230076
HN230076
Ground speed-stnd
5
80387469
HN387469
Top tailings auger drive
5
80420606
HN420606
Ground speed-low speed
6
80395313
HN395313
Chain
6
80605529
HN605529
Straw walker drive
7
80378989
HN378989
Fan drive
7
80410896
HN410896
Intermediate shaft grain auger
8
80388280
HN388280
Fan drive
8
80393326
HN393326
Straw elevator drive
9
80336784
HN336784
Drum vari-drive
9
80643353
HN643353
Knife drive 8050
10
80396750
HN396750
Set beater drive 8050
9
80394426
HN394426
Knife drive 8060
10
80437033
HN437033
Set beater drive 8060
10
80356024
HN356024
Ground speed vari-drive
11
80395955
HN395955
Intermediate shaft beater
1
80421173
HN421173
Alt. & water pump Eng.-Merc
12
80410962
HN410962
Chain
*
1
81540767
HN540767
Alt.& Water pump Eng. Ford
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
11
LH
1
9
2
3
5
RH
2
1
11 10 12
9
3
4
11
4
5
7
8
6
6
8
7
10
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80451481
HN451481
Power band-rethresher
1
81540767
HN540767
Alt.& Water pump Ford engine
2
80391650
HN391650
Drum variator
2
80384397
HN384397
Fan drive
3
80230151
HN230151
Hydraulic pump
3
80457643
HN457643
Rotary dust screen drive
4
80321559
HN321559
Ground speed-stnd
4
80350418
Chain
4
80417643
HN417643
Ground speed-low speed
5
80387469
HN387469
Top tailings auger drive
5
80389245
HN389245
Intermediate drive shaft
6
80395313
Chain
6
80394426
HN394426
Header drive
7
80378989
HN378989
Fan drive
7
80356025
HN356025
Ground speed vari-drive
8
80388280
HN388280
Fan drive
8
80393326
HN393326
Straw elevator drive
9
80336784
HN336784
Drum vari-drive
9
80410896
HN410896
Intermediate shaft grain auger
10
80396750
HN396750
Counter shaft drive
10
80605529
HN605529
Straw walker drive
10
80437033
HN437033
Counter shaft drive (modi)
11
80411543
HN411543
Power band hydrostatic drive
11
80395955
HN395955
Variator drive
1
80421173
HN421173
Alt. & water pump Merc engine
12
80410962
Chain
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
10
4
9
8
7
RH
2
1
11 10
12
9
6
3
4
11
5
7
8
6
1
2
3
12
5
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80387931
HN387931
Header drive
1
80432642
HN432642
Alternator drive Merc eng
2
80391143
HN391143
Header drive
2
80384397
HN384397
Fan drive
3
80393326
HN393326
Straw elevator drive
3
80457643
HN457643
Rotary dust screen
4
80410896
HN410896
Intermediate shaft
4
80350418
Chain grain elevator
5
80605529
HN605529
Straw walker drive
5
80387469
HN387469
Tailings elevator
6
80411543
HN411543
Power band hydrostatic drive
6
80395313
Chain-tailings elevator
7
80389245
HN389245
Intermediate drive shaft
7
80378989
HN378989
Fan vari-drive
8
80230151
HN230151
Hydraulic pump
8
80388280
HN388280
Fan vari-drive
9
80391650
HN391650
Power band drum variator
9
80387460
HN387460
Drum vari-drive
10
80451481
HN451481
Power band re-thresher drive
10
80396750
HN396750
Counter shaft drive
11
80321559
HN321559
Ground speed **stnd speed
10
80437033
HN437033
Counter shaft drive
11
80417643
HN417643
Ground speed **low speed
11
80395955
HN395955
Variator drive
12
80356025
HN356025
Ground speed
12
80410962
HN410962
Grain tank auger drive
*
1
80393519
HN393519
Alternator drive Merc eng.
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
12
LH
1
2
Engine
3
6
8
7
4
5
9
Mechanical drive
Straw Elevator
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80455865
HN455865
Powerband-rethresher
2
80922872
HN922872
Engine to beater shaft (hydr)
2
80922911
HN922911
Engine to beater shaft (mech)
3
89512971
HN9512971
Unloading auger
4
80433746
HN433746
Straw elevator drive
4
89514989
HN9514989
2HB straw elevator
5
80350236
HN350236
3HB beater to straw elevator
6
80448794
HN448794
Cleaning shoe drive
7
80451356
Chain
8
84000317
Chain
9
80440780
HN440780
Ground speed variator
1
2
3
8
9
11
10
Drum shaft
Interm shaft
12
5
4
13
7
14
Engine
6
Dust Screen
15
Interm. Shaft
Hydr. Pump
Straw walker shaft
16
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80913151
HN913151
Belt cooling fan
8
80321797
Chain
2
80443634
HN443634
Water pump drive
9
80267157
Chain
3
80913153
HN913153
Rotary dust screen drive
10
89513984
HN89513984
Beater drive
4
89501182
HN9501182
Alternator drive
11
89817439
HN9817439
Rotary separator
4
80747177
HN747177
Alternator drive >8110999
12
84015852
HN84015852
Grain storage drive
5
89506748
HN9506748
Compressor drive
13
89832601
HN9832601
Drum to intermediate shaft
6
80923019
HN923019
Dust screen
14
80754389
HN754389
Straw walker shaft drive
7
89508558
HN9508558
Hyd. Pump
15
80754388
HN754388
Straw walker drive
16
89502654
HN9502654
Cleaning fan vari drive
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
13
LH
RH
1
2
1
2
3
Engine
3
6
8
7
Interm shaft
4
5
4
7
5
9
Engine
6
Dust Screen
Hydr. Pump
Mechanical drive
Straw Elevator
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80455865
HN455865
Power band beater drive
9
80440780
HN440780
Ground speed variator
2
80922911
HN922911
Power band engine
10
80230164
HN230164
Ecentric shaft drive
3
89512971
HN89512971
Unloading auger drive
1
80913151
HN913151
Cooling fan drive
4
80433746
HN433746
Straw elevator drive (>1799)
2
80443634
HN443634
Water pump drive
4
89514989
HN89514989
2HB straw elevator drive
3
80913153
HN913153
Rotary dust screen drive
5
80434222
HN434222
2HB beater to straw elevator
3
89514311
HN89514311
Rotary dust screen drive
5
80350236
HN350236
3HB beater to straw elevator
3
89817454
HN89817454
Rotary dust screen drive
6
80448794
HN448794
Cleaning shoe
4
89501182
HN89501182
Alternator drive
6
80446780
HN446780
Cleaning shoe > 7703001
4
80747177
HN747177
Alternator drive >7717001
7
80451356
Chain
5
89506748
HN89506748
Compressor drive
7
84000317
Chain
6
80923019
HN923019
Dust screen
8
84000317
Chain
6
89817814
HN89817814
Dust screen >7720001
8
80451356
Chain
7
89508558
HN89508558
Hydraulic pump
* The text in italics indicates part numbers that belongs to RHS of the image.
RH
8
9
11
10
Drum shaft
12
13
14
15
Interm. Shaft
Straw walker shaft
16
ITEM
OEM REF.
PIX REF.
DESCRIPTION
8
80321797
Chain
9
80267157
Chain
10
89513984
HN89513984
Beater drive
11
89817439
HN817439
Rotary separator drive
12
84015852
HN84015852
Grain tank drive
13
89832601
HN9832601
Drum to intermediate shaft
14
80754389
HN754389
Straw walker drive
15
80754388
HN754388
Straw walker drive
16
80439832
HN439832
Cleaning fan (self levelling)
16
89502654
HN89502654
Cleaning fan
16
80919739
HN80919739
Cleaning fan (fixed shoe)
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
14
2
LH
RH
1
Rear beater
2
1
Engine
Rotary separator
4
3
Drum shaft
8
5
3
4
6
8
7
6
7
Rotor
5
9
Interm. Shaft
Undershoot beater
10
10
Straw Elevator
Mechanical drive
9
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80455865
HN455865
Beater to interm drive
9
80440780
HN440780
Ground speed variator
2
80750290
HN750290
4HB engine to beater shaft
1
80434154
Chain
2
80922911
HN922911
4HB engine to beater shaft
2
80267157
Chain
3
89512971
HN9512971
Unloading auger engaging
3
89513984
HN9513984
Beater drive
4
80433746
HN433746
2HB-straw elevator
4
80919681
HN919681
Rotary separator drive
4
89514990
HN9514990
2HB-straw elevator
5
84015852
HN4015852
Grain storage drive
5
80434222
HN434222
2HB-beater to straw elevator
6
89832601
HN9832601
Drum to interm shaft
5
80350236
HN350236
3HB-beater to straw elevator
7
80434046
HN434046
Rotary separator to rotor
5
80743877
HN743877
4HB-beater to straw elevator
8
80427456
HN427456
Rotor to undershot beater
6
80448794
HN448794
Cleaning shoe drive
9
89502654
HN9502654
Fan belt
7
80116140
Chain
10
80451356
HN451356
Chain
8
80216820
Chain
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
1
2
Rear beater
2
1
Engine
Rotary separator
4
3
Drum shaft
3
8
5
6
8
7
4
6
7
5
Rotor
9
Interm. Shaft
Undershoot beater
10
10
Straw Elevator
Mechanical drive
9
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80455865
HN455865
Beater to interm drive
1
80434154
Chain
2
80750290
HN750290
Engine to beater shaft
2
80267157
Chain
2
80922911
HN922911
4HB engine to beater shaft
3
89513984
HN9513984
Beater drive
3
89512971
HN9512971
Unloading auger engaging
4
80919681
HN919681
Rotary separator drive
4
80433746
HN433746
2HB-straw elevator
5
84015852
HN84015852
Grain storage drive
5
80434222
HN434222
2HB beater to straw elevator
6
89832601
HN89832601
Drum to intermediate shaft
5
80350236
HN350236
3HB beater to straw elevator
7
80434046
HN434046
Rotary separator to rotor
6
80448794
HN448794
Cleaning shoe drive
8
80427456
HN427456
Rotor to undershot beater
7
80116140
Chain
9
80439832
HN439832
Fan drive
8
80451356
Chain
10
80116140
HN80116140
Chain
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
15
LH
RH
1
2
Alternator
3
Engine
2
3
6
8
7
Anti Dust Fan
4
6
5
9
Dust Screen
1
5
Engine
Compressor
10
Straw Elevator
Mechanical drive
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80750166
HN750166
Beater to interm drive
7
80451356
Chain
2
80750290
HN750290
Engine to beater shaft
8
80451356
Chain
2
80922911
HN922911
4HB engine to beater shaft
1
80439496
HN439496
Cooling fan drive
3
89512971
HN9512971
Unloading auger engaging
2
80748003
HN748003
Water pump & alternator
4
80433746
HN433746
2HB-straw elevator
3
80439495
HN439495
Rotary dust screen
5
80434222
HN434222
2HB beater to straw elevator
5
80381237
HN381237
Compressor drive
5
80350236
HN350236
3HB beater to straw elevator
6
80436304
HN436304
Dust screen
6
80448794
HN448794
Cleaning shoe drive
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
1
2
Engine
3
6
8
7
4
5
9
10
Straw Elevator
Mechanical drive
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80455865
HN455865
Beater to intermediate shaft
2
80922911
HN922911
Engine to beater shaft
2
89831571
HN9831571
4HB Engine to beater shaft
3
89512971
HN9512971
Unloading auger engaging
4
80433746
HN433746
2HB straw elevator drive
4
89504547
HN9504547
2HB straw ele drv - lateral floatation
4
89513386
HN9513386
3HB straw elevator drive
5
80434222
HN434222
2HB beater to straw elevator
5
80350236
HN350236
3HB beater to straw elevator
6
80448794
HN448794
Cleaning shoe (self level)
6
80446780
HN446780
Cleaning shoe (fixed shoe)
7
80451356
Chain
8
84000317
Chain
9
80440780
HN440780
Ground speed variator
10
80230164
HN230164
Eccentric shaft drive
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
16
LH
1
2
Engine
3
6
7
7
4
5
8
Straw Elevator
ITEM OEM REF.
PIX REF.
DESCRIPTION
1
80455865
HN455865
Beater to intermediate shaft
2
80922911
HN922911
Engine to beater shaft
2
89831571
HN9831571
4HB engine to beater shaft
3
89512971
HN9512971
Unloading auger engaging
4
80433746
HN433746
2HB straw elevator drive
4
89504547
HN9504547
2HB straw elevator drive
5
80434222
HN434222
2HB beater to straw elevator
5
80350236
HN350236
3HB beater to straw elevator
6
80448794
HN448794
Cleaning shoe drive
7
80451356
HN451356
Chain
8
80230164
HN230164
Eccentric shaft drive
RH
RH
8
1
2
3
9
11
10
Drum shaft
12
Interm shaft
5
4
13
7
14
Engine
6
Dust Screen
15
Interm. Shaft
Hydr. Pump
Straw walker shaft
16
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
80913151
HN913151
Cooling fan drive
8
80434154
Chain
2
80443634
HN443634
Water pump drive
9
80267157
Chain
3
80913153
HN913153
Rotary dust screen drive
10
89513984
HN9513984
Beater drive
3
89817959
HN9817959
Rotary dust screen drive
11
89817439
HN9817439
Rotary separator drive
4
89501182
HN9501182
Belt alternator drive
12
84015852
HN4015852
Grain storage drive
4
80747177
HN747177
Belt alternator drive
13
89832601
HN9832601
Drum to intermediate shaft
5
89506748
HN9506748
Belt compressor drive
14
80754389
HN754389
Straw walker interm drive
6
80923019
HN923019
Belt dust screen
15
80754388
HN754388
Straw walker drive
7
89508557
HN9508557
Belt set hyd pump to engine
16
89502654
HN9502654
Cleaning fan vari-drive
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
17
ITEM
OEM REF.
PIX REF.
Description
1
80923019
HN80923019
Dust Screen Drive (alt) TX 32 - 36
2
9817814
HN89817814
Dust Screen Drive (alt) TX 32 - 36
3
9818830
HN89818830
Dust Screen Drive TX 66 - 68
4
84015852
HN84015852
"Bubble Up" Box Drive TX 62 - 67
5
80913151
HN80913151
Cooling Fan Drive TX 32 - 36
6
80754389
HN80754389
Straw Walker Intermediate Drive TX range
7
89513984
HN89513984
Beater Drive TX range
8
9850770
HN89850770
Rotary Separator Drive TX 62 - 68
9
84015531
HN84015531
Rotary Separator Drive TX 62 - 67
10
89817439
HN89817439
Rotary Screen TX 32
11
9514989
HN89514989
Straw Elevator Drive TX 32 - 36
12
80434222
HN80434222
Beater to Front Elevator TF and TX range
13
80443634
HN80443634
Water Pump Drive TX Range with Ford Engine
14
80913153
HN80913153
Rotary Screen Drive TX 32 - 36
15
9501182
HN89501182
Alternator Drive (alt) TX 32
16
89501182
HN89501182
Alternator Drive (alt) TX 32
17
80747177
HN80747177
Alternator Drive (alt) TX 32
18
754165
HN80754165
Compressor Drive Tx34
19
9831515
HN89831515
Cooling Fan Drive TC range
20
84078581
HN84078581
Drum Drive TF & TX ranges
21
9833619
HN89833619
Rotary Screen Drive TX 62
22
84041518
HN84041518
Rotary Screen Drive TX 67
23
9514311
HN89514311
Rotary Screen Drive TX 64 - 65 and some TX 32
24
919739
HN80919739
Cleaning Fan Drive TX 32 - 36
25
840 23278
HN84023278
Fan Variator Drive (alt) TX range
26
840 23277
HN84023277
Fan Variator Drive (alt) TX range
27
950 2654
HN89502654
Fan Variator Drive (alt) TX range
28
84036070
HN84036070
R H Drives TX 67
LH
RH
2
6
5
4
13
12
3
1
7
8
8
10
9
11
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
Z41178
HJZ41178
Reel drive
8
Z36120
HJZ36120
Wheel land drive
2
Z20460
HJZ20460
Straw elevator
9
Z41178
HJZ41178
Fan variator
3
Z20562
HJZ20562
Pick up reel drive
10
Z20703
HJZ20703
Fan drive
4
Z21171
HJZ21171
Hydraulic pump
11
Z20823
HJZ20823
Thresher drum
5
Z21400
HJZ21400
Tank discharge auger
12
Z20743
HJZ20743
Tailings auger drive
6
Z31191
HJZ31191
Thresher drum drive
13
T23505
HJT23505
Fan drive water pump
* The text in italics indicates part numbers that belongs to RHS of the image.
7
Z23693
HJZ23693
Sickle knife drive
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
18
LH
RH
13
11
7
5
4
3
2
1
6
8
8
10
9
12
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
Z20459
HJZ20459
Reel drive
6
Z25670
HJZ25670
Knife drive
2
Z20562
HJZ20562
Reel drive
7
Z21501
HJZ21501
Cutter unit drive
3
Z21254
HJZ21254
Hydraulic pump 630-730
8
P40058
HJP40058
Wheel drive
3
Z21171
HJZ21171
Hydraulic pump 530
9
Z20459
HJZ20459
Air fan
4
Z21400
HJZ21400
Tank discharge auger 630-730
10
Z20703
HJZ20703
Rear beater straw walker
4
Z21398
HJZ21398
Tank discharge 530
11
Z20743
HJZ20743
Tailings auger
5
Z21403
HJZ21403
Rear beater drive
12
Z20823
HJZ20823
Threshing drum
6
Z21500
HJZ21500
Knife drive
13
T23505
HJT23505
Fan drive water pump
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
7
6
13
11
1
2
3
4
5
12
5
9
8
10
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
Z20562
HJZ20562
Reel drive
8
Z20459
HJZ20459
Air fan
2
Z36813
HJZ36813
Reel variator drive
9
Z20703
HJZ20703
Fan drive
3
Z23693
HJZ23693
Knife drive
11
Z20743
HJZ20743
Rotary screen
4
Z20460
HJZ20460
Straw elevator
13
T20334
HJT20334
Fan drive
* The text in italics indicates part numbers that belongs to RHS of the image.
5
Z36120
HJZ36120
Traction vari drive
6
Z30593
HJZ30593
Hydraulic pump
7
Z21400
HJZ21400
Tank discharge
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
19
LH
RH
7
8
15
16
14
1
2
3
4
5
6
5
9
10
11 12 13
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
Z20562
HJZ20562
Reel drive
9
Z25473
HJZ25473
Straw walker
2
Z20459
HJZ20459
Reel variator drive
10
Z31283
HJZ31283
Purify drive
3
Z23693
HJZ23693
Knife drive
11
Z20703
HJZ20703
Fan drive
4
Z31816
HJZ31816
Straw elevator
12
Z20459
HJZ20459
Fan vari drive
5
Z31367
HJZ31367
Traction vari drive
13
Z20823
HJZ20823
Cylinder vari drive
6
Z31191
HJZ31191
Threshing drum
14
Z28458
HJZ28458
Rotary screen
7
Z21400
HJZ21400
Tank discharge
15
T20334
HJT20334
Water pump
8
Z30593
HJZ30593
Hydraulic pump
16
Z30920
HJZ30920
Straw walker
N/I
Z21403
HJZ21403
Main drive
N/I
Z20743
HJZ20743
Tailings auger
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
7
15
16
14
9
10
1112
13
1
2
3
4
5
6
5
8
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
Z20562
HJZ20562
Reel drive
9
Z30920
HJZ30920
Straw walker
2
Z20459
HJZ20459
Reel variator drive
10
Z31283
HJZ31283
Purify drive
3
Z30130
HJZ30130
Knife drive
11
Z20703
HJZ20703
Fan drive
4
Z21501
HJZ21501
Straw elevator
12
Z20459
HJZ20459
Fan vari drive
5
P40058
HJP40058
Traction vari drive
13
Z20823
HJZ20823
Cylinder vari drive
6
Z29962
HJZ29962
Threshing drum
14
Z28458
HJZ28458
Rotary screen
7
Z21400
HJZ21400
Tank discharge
15
T20334
HJT20334
Water pump
8
Z30593
HJZ30593
Hydraulic pump
16
Z25473
HJZ25473
Straw walker
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
20
LH
RH
1
2
3
4
5
11
12
13 14
15
16
18
17
19
6
7
8
9
10
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
D41964300
HMD41964300
Returns auger (set 2)
11
D41978500
HMD41978500
Awner shaft
2
D41972100
HMD41972100
Counter shaft
12
D41912300
HMD41912300
Rotary screen
3
D41991600
HMD41991600
Selector drive
13
D41927800
HMD41927800
Intermediate shaft
4
D41991400
HMD41991400
Hyd. Pump
14
D41935700
HMD41935700
Grain elevator
5
D41958500
HMD41958500
Straw Chopper
15
D41988700
HMD41988700
Discharge auger
6
D41929400
HMD41929400
Feed auger
16
D41926300
HMD41926300
Fan variator
7
D41989100
HMD41989100
Feed elevator
17
D41930300
HMD41930300
Main fan drive
8
D41988900
HMD41988900
Upper feed shaft
18
D41935500
HMD41935500
Eccentric shaft
9
D41955900
HMD41955900
Straw chopper
19
D41980800
HMD41980800
Threshing drum
10
D41972800
HMD41972800
Eccentric shaft
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
1
2
6
7
8
18
17
15 &16
14
4
3
5
9
13
10
12
11
23
22
24
21
19
20
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
834140M1
HM834140
Reel drive
14
222882M2
HM222882
Hydraulic pump
2
8333768M1
HM833768
Reel variator drive
14
842413M1
HM842413
Hydraulic pump
3
834139M1
HM834139
Reel drive
15
274252M91
HM274252
Generator drive
4
834058M1
HM834058
Wobble box
16
273837M91
HM273837
Generator drive
4
842809M1
HM842809
Wobble box
17
274339M91
HM274339
Fan drive
5
833566M1
HM833566
Hydro traction X2
17
833870M1
HM833870
Fan drive
6
833858M2
HM833858
Traction Drive X2
18
843045M1
HM843045
Air conditioning
7
833374M1
HM833374
Main drive
19
842845M1
HM842845
Hydrostat reel
8
833867M1
HM833867
Intake air
20
833868M2
HM833868
Cylinder vari drive
9
833862M1
HM833862
Discharge/collector
21
833871M1
HM833871
Straw chopper
10
274015M91
HM274015
Fan drive
22
832866M2
HM832866
Chopper drive
11
833860M1
HM833860
Straw walker X2
23
833872M1
HM833872
Chopper final drive
12
273757M91
HM273757
Shaker shoe
24
833854M2
HM833854
Returns elevator
13
833863M1
HM833863
Fanning mill
* The text in italics indicates part numbers that belongs to RHS of the image.
13
842419M1
HM842419
Fanning mill
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
21
LH
RH
7
5
4
3
13
11
10
9
12
2
1
6
8
8
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
432232
HL432232
Hyd pump
7
433430
HL433430
Central return drive M100
2
432250
HL432250
Fan drive
8
433537
HL433537
Central return drive M120
3
432433
HL432433
Grain& tailings auger
9
434140
HL434140
Reel variator speed M120
4
432436
HL432436
De-awner paddle drive
10
434250
HL434250
Threshing drive M120
5
432437
HL432437
De-awner beater drive
11
435127
HL435127
Traction drive
6
433435
HL433435
Reel drive M120
432244
HL432244
Grain tank discharge drive
433430
HL433430
Reel drive M100
435117
HL435117
Beater drum drive
433430
HL433430
Straw walker M120
007108
007108
Alternator/water pump
433531
HL433531
Upper elevator drive M120
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
7
5
4
3
13
11
10
9
12
2
1
6
8
8
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
433182
HL433182
Fan
7
433409
HL433409
Main feed primary
2
433531
HL433531
Feed elevator
8
433430
HL433430
Grain shaker
3
431122
HL431122
Threshing drive
9
433236
HL433236
4
433417
HL433417
Grain tank discharge
10
433456
HL433456
De awning return
5
432244
HL432244
Hyd pump
11
433134
HL433134
Rotary filter secondary
6
311212
HL311212
Hyd pump
433162
HL433162
Rotary filter primary
433289
HL433289
Corn elevator
435146
HL435146
433455
HL433455
Straw walker
434140
HL434140
Reel variator
433537
HL433537
Main drive
433456
HL433456
Reel drive
433410
HL433410
Main feed
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
22
LH
RH
7
5
4
3
13
11
10
9
12
2
1
6
8
8
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
433435
HL433435
Reel drive
7
433537
HL433537
Central return drive
2
433316
HL433316
Reel drive1978
8
433289
HL433289
Grain tank fan
3
434140
HL434140
Reel variator speed
9
433455
HL433455
Straw walker
4
434138
HL434138
Reel variator speed 1978
10
433430
HL433430
Grain&tailings auger
5
433182
HL433182
Fan
11
433409
HL433409
Fan drive
6
433531
HL433531
Upper shaft elevator drive
433418
HL433418
Fan drive 1978
431122
HL431122
Threshing drive
433410
HL433410
Fan drive
4311316
HL4311316
Threshing drive 1978
433236
HL433236
Selector auger
433417
HL433417
Grain tank discharge
433456
HL433456
De awning returns
432243
HL432243
Hyd pump
433134
HL433134
Rotary filter returns
432244
HL432244
Hyd pump
433162
HL433162
Rotary filter returns
435127
HL435127
Traction drive
435125
HL435125
Cylinder variator
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
7
5
4
3
13
11
10
9
12
2
1
6
8
8
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
434138
HL434138
Reel variator
7
433455
HL433455
Straw walker
2
434140
HL434140
Reel variator
8
433430
HL433430
Grain tailings elevator
3
433182
HL433182
Fan variator
9
433409
HL433409
Fan regulator drive
4
431122
HL431122
Drum variator
10
433410
HL433410
Fan drive
5
433418
HL433418
Conveyor
11
433531
HL433531
Elevator drive
6
311222
HL311222
Threshing drive
433316
HL433316
Reel drive
433417
HL433417
Grain tank discharge
433435
HL433435
Reel drive
435127
HL435127
Traction drive
433456
HL433456
De-awning return
432243
HL432243
Oil pump
433236
HL433236
Selector auger
433244
HL433244
Hyd pump
433134
HL433134
Rotary filter
433537
HL433537
Central return
433162
HL433162
Rotary filter primary
433289
HL433289
Grain elevator
351146
HL351146
Drum variator
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
23
LH
RH
7
5
4
3
13
11
10
9
12
2
1
6
8
8
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
433316
HL433316
Reel drive
7
433537
HL433537
Variator drive
2
433435
HL433435
Reel drive
8
433289
HL433289
Fan
3
434138
HL434138
Reel variator
9
433455
HL433455
Straw walker
4
434140
HL434140
Reel variator
10
433430
HL433430
Grain & tailings
5
433182
HL433182
Fan
11
433409
HL433409
Main feed
6
433531
HL433531
Elevator
433410
HL433410
Main feed secondary
431122
HL431122
Threshing drive
433418
HL433418
Conveyor
311316
HL311316
Threshing drive 1978
433236
HL433236
433417
HL433417
Grain tank discharge
433456
HL433456
De awning return
432243
HL432243
Hyd pump
433134
HL433134
Rotary filter return
432244
HL432244
Hyd pump
433162
HL433162
Rotary filter return primary
435127
HL435127
Variator drive
435125
HL435125
Drum drive
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
7
5
4
3
13
11
10
9
12
2
1
6
8
8
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
433458
HL433458
Reel drive
7
433970
HL433970
Straw walker/sieve drive
2
311217
HL311217
Thresher drive
8
433283
HL433283
3
433252
HL433252
9
433432
HL433432
Elevator
4
433239
HL433239
Hyd pump
10
435138
HL435138
Drum drive
5
311212
HL311212
Drive variator
11
433176
HL433176
Fan
6
433412
HL433412
433188
HL433188
Fan drive
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
24
LH
RH
7
5
4
3
13
11
10
9
12
2
1
6
8
8
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
311127
HL311127
Feed elevator not 3790
7
433467
HL433467
Shaker shoe
2
433983
HL433983
Feed elevator not 3790
8
433540
HL433540
Drive
3
435130
HL435130
Drum variator
9
311318
HL311318
Drum variator
4
433424
HL433424
Fan
10
434138
HL434138
Reel variator
5
311134
HL311134
Grain shaker
11
433418
HL433418
Auger drive
6
433458
HL433458
Straw walker
433144
HL433144
Rotary filter secondary
311217
HL311217
Hyd pump
433184
HL433184
Rotary filter primary
432243
HL432243
Oil pump
435124
HL435124
Drum variator
433129
HL433129
Compressor drive
* The text in italics indicates part numbers that belongs to RHS of the image.
LH
RH
7
5
4
3
13
11
10
9
12
2
1
6
8
8
ITEM
OEM REF.
PIX REF.
DESCRIPTION
ITEM
OEM REF.
PIX REF.
DESCRIPTION
1
434138
HL434138
Reel variator
7
433457
HL433457
Straw elevator
2
311418
HL311418
Drum drive
8
433418
HL433418
Conveyor drive
3
433038
HL433038
Compressor
9
433424
HL433424
Fan
4
311314
HL311314
Hyd. Pump
10
311134
HL311134
Grain shaker
5
433540
HL433540
Traction drive
11
433143
HL433143
Rotary filter
6
433256
HL433256
Oil pump
* The text in italics indicates part numbers that belongs to RHS of the image.
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
25
LH
16
17
24
18
19
23
20 21
22
ITEM
OEM REF.
PIX REF.
DESCRIPTION
16
01145093
HDF01145093
Grain tank unload
17
01145051
HDF01145051
Straw walker set
18
01143412
HDF01143412
Feeder
19
01141608
HDF01141608
Feed drive
20
01143413
HDF01143413
Walker drive
21
01145087
HDF01145087
Shaker drive
22
01145025
HDF01145025
Walker drive
23
01141944
HDF01141944
Variator drive
24
01145102
HDF01145102
Engine drive
N/I
01145050
HDF01145050
Stripper drum
ITEM
OEM REF.
PIX REF.
Description
1
244420A1
HI244420
Rotor Drive 1660, 2166, 2365, 2366
2
244422A1
HI244422
Rotor Drive 1680, 2188
3
191241C3
HI191241
Separator Drive 1660, 2166, 2365, 2366
4
1330499C1
HI1330499
Separator Drive 1680 up to 114634
5
1541702C1
HI1541702
Separator Drive 1680 from 114635
All OEM part numbers are for reference only - There is no intention to imply that they are original equipments
26
PREVENTIVE MAINTENANCE TIPS
Problems
Causes
Remedies
Belt turnover in pulleys
• Poor drive alignment
• Realign
• Incorrect pulley groove or
• Renew or replace pulleys
excessive wear in grooves
• Excessive belt flap
• Use an idler on slack side
• Low belt tension
• Retension
• Worn out belts
• Replace with new belts
• Ingress of foreign material
• Use more effective drive guard
Excessive wear
• Incorrect pulley section
• Renew or replace pulleys
• Excessive wear in pulley
• Renew or re-machine pulleys
groove
• Poor drive alignment
• Realign
• Small pulley diameter than
• Redesign using correct pulley
recommended
diameter.
• Belt catching on protruding
• Remove protrusion or move drive
parts
away
Excessive noise
• Poor drive alignment
• Realign
• Incorrect belt tension
• Retension
• Overloaded
• Check drive details and redesign
• Unbalanced pulleys
• Redesign, if necessary balance the
pulleys
Belt swelling or softening
• Contamination by oil or
• Protect the drive from contamination,
other chemicals
clean pulley grooves.If contamination
cannot be prevented use PIX AOH
V- Belts.
Unusual belt stretch
• Worn out badly damaged
• Re-machine or renew pulleys
grooves
• Used belts & new belts are
• Replace with completely new set of
mixed up on drive
V-Belts
• Belts from different
• For using a matched set, belts must
manufacturers
be from one manufacturer
Belt breaking after fitment
• Forcing belt over pulleys
• Reduce drive centre distance to fit
when fitting, damaging the
belt
cord and cover
• Ingress of foreign material
• Fit an effective guard
• Insufficient belt or wrong
• Check drive design and fit correct
section or drive
number or section of belts
• Drive stalled
• Ascertain cause and rectify
Cannot be re-tensioned
• Insufficient allowance for
• Give sufficient allowance for take-up
stretch in drive design
• Excessive stretch caused
• Recalculate drive design and modify
by insufficient belts or
wrong belt section for drive
• Incorrect belt length
• Use belt of proper length
• Belts from different
• Use belts from one manufacturer
manufacturers used on the
same drive
27
PREVENTIVE MAINTENANCE TIPS
Problems
Causes
Remidies
Excessive slippage
• Too low belt tension
• Increase belt tension
• Too small area of contact
• Increase shaft centre distance
• Overload
• Redesign belt drive
• Worn belt or pulley
• Change to new belt or pulley
Transversal cracking
• Too small pulleys
• Use standard size pulley.
• Outside idler pulleys
• Use inside idler pulley in slack side
• Ambient temperature too
• Ensure good ventilation and protect
high
from direct heat.
• Ambient temperature too
• Warm area surrounding the drive
low
• Abnormal belt slip
• Check drive tension and drive design
to ensure correct number of belts
Bottom & side of belt burnt
• Belt slipping under starting
• Replace belt and tighten drive until
or stalling load
slipping stops
• Worn sheaves
• Replace sheaves
Belt pulled apart (snapped)
• Extreme shock load
• Remove cause of load
• Misaligned drive
• Check drive alignment
• Foreign particle in the drive
• Use drive guard
TYPES OF FAILURES
Bottom crack
Belt snapped due to
cord break while fitment
Belt snapped
Envelope wear
(side, bottom & top wear-out)
Shining surface due to high slippage
Belt twisted due to
Stuck up and burnt
belt turnover in pulley
28
DO’S & DON’TS OF PIX V-BELTS
Right
Wrong
Wrong
Align groove like this
Shafts parallel
Not like this
29























///////////////////////////////////////
