FILTERS
Lube Filtration Systems
To meet the performance demands of today’s tough
While the costs for repairing equipment breakdowns
off-road environments, your equipment is generating
are normally high, they are often miniscule compared
more usable horsepower than ever before. Tighter
to those associated with delayed harvests or missed
tolerances, higher temperatures, and severe duty cycles
project completion deadlines. Don’t jeopardize
are driving the requirement for high quality filtration
productivity by using “will-fit” filtration. New Holland
and increased durability without sacrificing filter life.
lube filters are designed specifically for your
Today’s low-emission engine designs make engine
equipment. They’re guaranteed to ensure peak
filtration extremely critical, especially particles in the
performance while providing maximum protection for
5-10 micron range, which are most damaging to
your investment.
modern engines.
Superior Media - New Holland filters are designed
to trap more of the small contaminants that are most
n Custom-designed filtration media
damaging to diesel engines. The media is uniformly
3 Synthetic
resin-impregnated and heat-cured to provide efficient
3 Cellulose
filtration, while resisting the effects of moisture. The
3 Blends
media used in many of our newer filters combines
3 Stacked Disk
microglass and cellulose fibers for doubled
efficiency over standard filters.
n Optimized filtration performance in
Plastisol Adhesive - New Holland filters use
capacity (life), efficiency
plastisol, a high quality adhesive, to uniformly bond
(cleanliness), and restriction to flow
the filter element to the end caps. Plastisol adhesive
3 Minimizes progressive wear
keeps the filter media from bunching and rupturing.
3 Reduces bearing and ring wear
Rubber Seals - Many filter manufacturers use
3 Removes sludge
cardboard seals at the ends of the filters; cardboard
3 Filters oil sooner during cold starts
seals can deteriorate or leak. New Holland filters
use a thin piece of rubber which provides a tight,
n Patented combination full-
even seal at the base of the filter. It prevents
flow/bypass filtration products
unfiltered oil from bypassing the filter media and
re-entering your system.
n Guaranteed to meet OEM
specifications
Metal End Caps - Solid metal end caps provide
additional strength to the filter element. Metal is
superior to the cardboard that many
manufacturers use.
OEM Specified - New Holland
filters meet all specifications
demanded by our design
engineers. When you buy a
New Holland filter, you’re
buying the confidence that
New Holland engineers have
placed in the filter to protect
your engine, and save you
repair costs.
8
2-stage filtration design
FLUIDS
Selecting Fluids
MASTERGOLD™ ENGINE OIL
Your engine takes a tremendous pounding day in and day out. But you can
protect and preserve it with the best engine oil available — MasterGold.
MasterGold is a premium, high-performance diesel engine oil designed to stand
up to the toughest operating conditions. Less susceptible to thermal and
chemical breakdown, MasterGold provides excellent oil-consumption control
and maximum engine-wear protection.
Compare before you buy. Use the engine oil specifically designed for your
equipment and field conditions. Prolong your hard working engine’s life with
MasterGold heavy-duty engine oil.
TG and TJ Series Tractor Engine Oil Capacity
Oil Viscosity/
Tractor Model
Engine Oil Capacity
Temperature Usage Recommendation
(gallon/liter)
Fahrenheit
TG210, TG230, TG255, TG285
5.5g/20.8l
TJ275
6.3g/23.8l
TJ325
7.25g/27.5l
TJ375, TJ425, TJ440, TJ450, TJ500
13g/49.2l
Celsius
*Use of an engine oil heater, or an engine coolant
heater, is required in gray area.
MASTERTRAN™ FLUID
Up to 70% of all transmission and hydraulic system failures are fluid
related. So protect and preserve your equipment with MasterTran and
prevent costly downtime.
n MasterTran is blended to provide optimum machine performance and
long life in the most severe operating conditions.
n It provides superior wear protection for hydraulic components, drive
train gears, and other transmission parts.
n Controlled frictional characteristics provide safe, smooth operation of
wet brakes and clutches.
n Excellent filterability provides extra protection against system
contamination.
DIESEL FUEL
n Use a good grade of fuel which meets SAE/ASTM EN 590 or
equivalent. The use of biodiesel blends is approved for New Holland
engines up to B5 (5% blend ratio).
9
DAILY SERVICE
Note: TG and TJ tractors require daily, weekly, and scheduled
maintenance intervals to keep equipment in top performing condition.
Although service requirements for each New Holland tractor model
may be similar, please refer to the equipment’s Operator’s Manual for
lubrication information, service intervals, and component locations.
Daily Service
Service should be performed every 10 hours or daily (whichever comes first) to keep your New Holland tractor
running at its best.
TG Tractor - Daily service functions can be
TJ Tractor - Daily service required:
performed in a single location to get you to the field
Check engine oil level
faster each day.
Check hydraulic/axle oil level
Check engine oil level
Check transmission oil level
Check hydraulic/transmission oil level
Check coolant level (reservoir & deaeration tank)
Check engine coolant reservoir level
Check fuel level
Check fuel level
50 hours (or Weekly) -
In severe dusty or wet conditions, grease rear
• Drain water from fuel filter drain plug and fuel tank
hitch & front axle every 10 hours; otherwise
• Grease articulation/oscillation hinges, articulation
every 300 hours
& three point hitch (TPH) cylinders, and center
50 hours (or Weekly) -
link fittings
• Drain water from fuel filter drain plug
10
• Grease SuperSteer Axle linkage pins
SERVICE POINTS
Engine Oil and Coolant Filters
Radiator/Coolers
Vertically mounted engine oil filters permit easy, clean,
During regular service, clean the radiator, hydraulic
no-spillage service.
oil coolers, fuel cooler and air conditioning
equipment as conditions warrant.
New Holland coolant filters are specially designed to
protect the cooling system from contamination and
condition the coolant to prevent erosion and cavitation.
TG Tractor -
3 Engine oil and filter - 300 hours
3 Coolant filter - 600 hours
3 Coolant and conditioner - 2100 hours
TJ Tractor -
3 Engine oil and filter - 500 hours
3 Coolant (check SCA level) - 500 hours
3 Coolant filter - 1500 hours
3 Coolant (drain & flush) - 6000 hours
Transmission, Hydraulic, and
Axle Filters
TG Tractor -
The combined transmission and hydraulic system are
protected from contamination by two high-performance
spin-on filters on the right hand side of the
transmission.
3 Transmission oil and filters - 1500 hours
TJ Tractor -
Fuel Filters
The transmission and hydraulic systems are
independent. The hydraulic system shares its circuit
Fuel filters protect the fuel system from dirt and
with the axle lube system.
water damage. Use clean fuel, keep the fuel tank full
to prevent water condensation, and drain the water
3 Hydraulic oil and filter - 1500 hours
separator section at regular service intervals.
3 Axle lube filter - 1500 hours
TG Tractor -
3 Engine fuel filters - 600 hours
TJ Tractor -
3 Engine fuel filters - 500 hours (or when service
icon is displayed)
11
SERVICE POINTS
Engine Air Filters
Cab Clean Air & Recirculation
To maintain engine power and performance, clean the
Filters
primary filter when notified by tractor instrumentation. Do
Proper heating and cooling performance depends on
not clean the secondary (inner) filter element. The
proper air flow through the cab clean air and
secondary (inner) filter element should only be replaced.
recirculation filters. Recirculation air filters should be
TG Tractor -
cleaned with mild soap and water as required by
conditions during regular service. Clean cab air
3 Primary & secondary engine air filters - as required
recirculation filters improve air conditioning system
(recommend 1200 hours or annually)
efficiency and make cab comfort easier to maintain.
TJ Tractor -
Note: Be sure cab recirculation filters are not
3 Primary & secondary
ENG
blocked. A clear flow path must be maintained for
engine air filters -
optimum cab comfort.
AIR FLTR
1500 hours
TG Tractor -
The clean air filter is located below the cab door. The
recirculation filters are located on both sides of the
operator’s seat near the floor mat.
3 Cab air & recirculation filters - As required
(recommended 1500 hours)
TJ Tractor -
The clean air filter is located underneath the left rear
corner of the cab. The recirculation filter is located
directly behind the operator’s seat.
3 Cab air & recirculation filters - 1500 hours
Fuses & Relays
TG Tractor -
Engine circuit protection fuses are located inside the
engine service door below the engine air filter assembly.
The tractor circuit fuses and relays are located below the
floor mat behind the operator’s seat.
TJ Tractor -
All fuses and relays are located under the removable
panel to the left of the operator’s seat.
Batteries
Current models of New Holland equipment use
maintenance-free batteries. Terminals should be
cleaned as necessary. On
older models without
maintenance-free
batteries, clean terminals
as necessary and check
electrolyte levels before
and after winter storage.
12
kmanualshub.com/
TG PERFORMANCE Ihttps://truc
TerraGlide™ and SuperSteer™
Dual Speed PTO
FWD Axles
TG Tractor models offer a dual speed PTO with
interchangeable 540 and 1000 (large and small) speed
A TerraGlide FWD axle is optional on TG model
shafts. The dual speed PTO capability allows you to
tractors. The TerraGlide axle helps keep the front
connect to a variety of implements without changing
wheels on the ground. This keeps the tractor stable
tractors. The PTO shafts interchange easily, requiring
under the variety of conditions tractors encounter on a
only small hand tools.
regular basis. The TerraGlide axle provides a smoother
ride over rough terrain. TG models also offer an
TJ models use a 1000 rpm, 1-3/4˝ shaft.
optional SuperSteer FWD axle which steers in
conjunction with the wheels to a maximum of 20
degrees. This, added to the 45 degree maximum turn
angle of the wheel ends, gives an effective steer angle
of 65 degrees.
True Ground Speed Signal
TG and TJ models have an in-cab, true ground speed
signal socket. Using the socket simplifies connection of
Drawbar Positioning/PTO
the true ground speed signal to spraying and planting
Driveline Adjustment
systems. Order cable part number 324847A2.
When switching PTO shaft speeds on TG models, you
must reposition the drawbar to meet SAE dimensions.
Failure to adjust the drawbar length could result in
damage to either the tractor or the implement PTO drive
line. Use the implement PTO driveline height adjustment
to ensure a minimum vertical
angle of the implement PTO
Shaft
Distance
shaft. The horizontal distance
540
14˝
from end of shaft to center of
Small 1000
16˝
Large 1000
20˝
drawbar pin should be:
Foot Throttle
The optional foot throttle available on TG tractors frees
the operator’s hands for other functions. A foot throttle
can be a valuable enhancement for loader, planting, and
general tillage operations.
TJ models have an optional decelerator pedal available.
13
PERFORMANCE ITEMS
High-Capacity Drawbar
A high-capacity drawbar option is available for applications where
heavy drawbar loads are expected. The high-capacity drawbar should
be used for applications like front folding planters, liquid manure
wagons, and large grain carts. Three swing positions, one on each
side of center, are obtainable by moving bolts which extend up
through the drawbar hanger on both sides of the drawbar. Six
drawbar mounting positions are available just like on the standard
drawbar. The high-capacity drawbar allows equal angle hitching
when necessary. The high-capacity drawbar has a vertical tongue
load rating of 4990 kg (11,000 lbs). The “auto pin” clevis is standard.
Heavy Duty Drawbar kit is available for all TG tractors.
Drawbar kit part number - 435788A1 (includes the auto-pin hitch
and mounting hardware).
Drawbar part number - 426511A1.
Motor Return and Power Beyond
An optional motor return kit mounts to the top of
Note: The motor return kit is required for some
the couplers on the left side. Motor return port
planting and seeding implements.
installation reduces back pressure in hydraulic
Power beyond provides a hydraulic supply port, a low
circuit return lines. This results in more efficient
pressure return port, a sensing port, and a case drain
hydraulic system operation. The motor return
coupler (ported to reservoir). Power beyond provides a
consists of one return coupler (3/4˝) and one
versatile connection point for specialty hydraulic
case drain coupler (1/4˝). The motor return
applications.
housing is the same housing used for power
beyond applications without the lines,
IMPORTANT: The case drain coupler should only be
connections, and couplers required for power
used for low flow, case drain applications. Transmission
beyond functions.
lube pressure could be adversely affected if the case
drain coupling is used for other applications.
Note: For maximum performance, use only ISO Tips.
14
nualshub.com/
ELECTRONIC SERVIChttps://truckma
The Power of Technology
CAN Systems Put the Latest Technology to Work for You
New Holland service professionals use an Electronic Service Tool
(EST) to service New Holland tractors. The latest New Holland
tractors are equipped with a Controller Area Network (CAN),
that allows all the tractor systems to communicate on one
network. No longer is your New Holland service technician tied
to the shop. The EST makes in-field diagnosis easy.
n Provide Information to the Operator
n Improve Tractor Operation
n Enhance Tractor Performance
n Prevent System Failures
n Provide Quick and Accurate Troubleshooting
Service technicians connect the Electronic Service Tool into the tractors CAN system to communicate using the
CAN network. Fault based diagnostics are used to quickly identify problems. Detailed photographs, diagrams and
component locators on the EST screen provide complete information about related wiring and connectors. Repairs
can be made quickly, assuring maximum productivity. In addition to service diagnostics, the EST can be used to
download new software to upgrade the functions performed by the controller networks. It can also be used to change
the default transmission gears.
Consider several examples of how controllers and other devices within the CAN work together. As the tractor moves
through the field, the controllers in the CAN system continually check a variety of inputs:
n Operator Commands
n Engine Torque
n Gear Selection
n Tractor Speed
n Wheel Slip
n Hitch Position
As conditions vary, this information is used by the system to adjust engine power to the transmission. The
transmission responds to commands from the operator to complete functions that previously required individual
actions by the operator. Therefore, the operator’s time is available to make corrections in the field. As the operator
moves the hand throttle lever or signals other operations, the tractor identifies the change and sends the new
command to the required systems via the CAN system. New Holland tractors are designed as a platform for evolving
technology to provide more usable information.
15
ckmanualshub.com/
New Holland EZ-Guide® Plus Lightbar
The new EZ-Guide Plus is the second generation of lightbar to be offered by New Holland. It is also the first lightbar
in the industry to combine easy-to-read guidance LED’s with a graphical LCD screen, and a high-end GPS receiver
all in one unit. The LED’s display how far to the left or right of center you are, making it easy to follow your swath
guidance, while the added LCD screen displays your vehicle orientation, to help you follow contours easier. By
combining LED guidance with a graphical display, you get the best of both worlds to help you stay on track.
The EZ-Guide Plus is not only easy to learn but it can be installed in any vehicle in minutes. Use it in any field
application that requires parallel swaths including field preparation, chemical or fertilizer applications, and air seeding
applications. Tough working conditions are no problem either—the system works consistently day or night, in wind,
rain, dust or fog with no deterioration in performance. Lightbar guidance technology can help you accomplish more by
extending your hours of operation, making each working day more productive. You can improve your coverage, while
reducing your cost of chemicals, fertilizers, fuel and other input materials, by eliminating costly skips and overlaps. The
EZ-Guide Plus is not just a lightbar, it’s also a fully functioning GPS receiver. The system outputs “NMEA” position
data that enables it to feed position data to other GPS-enabled equipment such as yield monitors, variable rate planters
and field computers. See your New Holland specialist about making this technology work in your operation.
Features
•
35 LEDs for guidance
•
160x120 pixel LCD screen
• Perspective and plan view map
• Integrated 12 channel GPS receiver
• Free WAAS differential correction
• FreeDIFF firmware technology
• High quality antenna resistant to interference
• Optional six button remote control with integrated alarm
• Multiple guidance patterns
• U.S. or Metric units
• Pause/Resume function
• User-definable swath width
• On-board GPS diagnostics
• NMEA output for other applications such as yield monitoring
See your local New Holland dealer for a demonstration.
EZ-Guide and FreeDIFF are trademarks of Trimble Navigation Limited.
16
Gross Vehicle Weight
Maximum gross weight - A tractor’s maximum gross
Many tire manufacturers recommend using cast iron
weight is referred to as the combined static weight of the
weights. If liquid ballast must be used, New Holland
tractor and any added ballast. This value must not
requires it be placed in the inside duals only if the
exceed the rating of the ROPS structure or the maximum
wheels are spacer band type. Flange style duals or hub
gross vehicle weight as specified in the Operator’s
style duals may be lightly filled. Spacer band duals
Manual. When adding ballast to a tractor, the tractor
should never have liquid ballast installed in the outside
should be ballasted as light as possible to minimize soil
dual wheel.
compaction and still maintain performance.
Matching the tractor to the load
Over Inflated
Proper Inflation
Your tractor has been designed for continuous field
operation at the rated horsepower while traveling at a
speed of 5 mph or faster. If the engine lugs continuously
at slow speeds you can be sure that the load is not
correctly matched to the tractor. This could result in
damage to the tractor drive train as well as wasted fuel,
increased tire wear, and soil compaction.
Tire Inflation
Top 10 Ways to Reduce Soil
Radial tires achieve their high level of tractive
Compaction With Tires
performance as a result of the high contact area between
the rubber and the soil.
1.
Use radial tires. They can operate at lower psi than
Proper adjustment of radial tire pressure means using
bias ply tires, have a larger footprint and reduce
the correct tire inflation pressure to support the static
soil disturbance.
load carried by the tire and still maintain the high
2.
Use the widest and largest diameter tires possible for
contact area between the tire and soil.
the application that allows the minimum air pressure
A tire can be inflated to safely support a wide range
(example 6 PSI).
of loads.
3.
Use the proper tire pressure for the load, speed,
• An 18.4R42 tire used as a dual, supports
and application.
approximately 3200 lbs. of static load when inflated
4.
Check tire pressures regularly.
to 8 PSI
5.
Add duals or triples to help distribute the load and
• An 18.4R42 tire will support 6950 lbs. when inflated
optimize the air pressure.
to 24 PSI
6.
Add large tires to the implement being used.
In both instances, the tire deflects approximately the
(Many times the implement actually causes more
same amount. This is known as “Rated Deflection” of
compaction than the tractor!)
the tire. When the Rated Deflection is correct, the tire
achieves its best performance.
7.
Run the tractor at the lightest ballasted weight possible.
The correct tire pressure for a given tractor is found by
8.
Always ballast with iron, not fluid in the tires.
weighing the unit and then dividing the weight per axle
by the number of tires. This weight is then compared to
9.
Utilize precision traffic. (For example, drive in the same
the values on the Tire Inflation vs. Weight Table to find
tire tracks and keep major traffic on the headlands.)
the correct tire pressure. Tire Inflation vs. Weight Tables
10. Use the correct tires to improve fuel efficiency.
should be used for proper inflation pressures.
Less slip over lots of acres can add up to big savings
in fuel usage.
17
m/
RIDE, TRACTION & PERhttps://truckmanualshub.co
TG Tractors
Refer to Load/Inflation Chart for inflation and tire size information (starting on
page 26 or in the tire manufacturers’ guide).
Tall, wide, soft radial tires provide:
• The best traction.
• The best ride.
• The least amount of maintenance required to control a powerhop condition.
Definitions
Rolling Circumference - Rolling circumference is the distance a tire travels in one revolution
Interaxle Ratio - A FWD tractor uses both the front and rear tires to do the work. Since the front tires are smaller
than the rear tires, the front tires must rotate faster to travel the same distance as the rear. The mechanical gear
combination used to allow the front axle to move the tires at a faster speed is referred to as the interaxle ratio. The
tractor manufacturer establishes the interaxle ratio.
18
FWD Dual Wheel Field Test Results
The University of Nebraska conducted field tests in the
Proper ballasting minimizes compaction and enhances
summer of 1999 to compare the effect of traction on
tractor performance. Front duals increase the tire-to-
tractors equipped with and without front dual wheels.
ground contact area and reduce the ground contact
The results showed, when pulling drawbar implements,
pressure under the front axle. The tractor used for the
generally a 65/35 rear/front weight split performed the
field test was equipped with 520/85R46 rear and
best for tractive efficiency with single or front dual
480/70R34 front tires. With these tires, the use of front
wheels. Hitch mounted implements generally performed
duals increases the tire-to-ground contact area by 25%.
best with a 60/40 rear/front weight split. The test
Lower air pressure (see Load/Inflation Charts) improves
emphasizes the importance of proper ballasting.
the tire footprint, while reducing the tire to ground
contact pressure and compaction in the field.
During tractor ballasting, pay attention to:
• The front to rear weight split on the tractor
• Pounds of weight per PTO hp and drawbar hp
• Tire load/inflation values
Ground Pressure Diagram
TOO MUCH BALLAST
CORRECT BALLAST
TOO LITTLE BALLAST
Easy Ballasting Options
Two different front weight frames are available
depending on FWD on SuperSteer options. The
weight frames increase front end vehicle weight and
the weights wrap under the chassis providing greater
ground clearance. The front wheels turn behind the
weights and frame for increased visibility and tighter
turning radius.
Two suitcase weight options are available, weighing
40 kg (88 lb) and 100 kg (220 lb).
• When using the large suitcase weights, a
maximum of 16 weights can be installed
• When using the small suitcase weights, a
maximum of 22 weights can be installed
19
m/
RIDE, TRACTION & PERhttps://truckmanualshub.co
Interaxle Ratio - Front/Rear
*Front Axle Reduction Ratio
TG210 & TG230 (Standard)
1.3228
*21.525
TG210 & TG230 (TerraGlide)
1.3228
*21.525
TG210 & TG230 (SuperSteer)
1.3228
*21.525
TG255 (Standard)
1.3222
*21.535
TG255 (TerraGlide)
1.3222
*21.535
TG255 (SuperSteer)
1.3222
*21.535
TG285 (Standard)
1.3250
*21.535
TG285 (TerraGlide)
1.3250
*21.535
TG285 (SuperSteer)
1.3250
*21.535
Note: *This ratio number (1) can be found on the axle serial number plate.
Lead/Lag
Tires and Tractor Performance
The relationship between the front and rear tires is
To optimize tractor performance, tires should be selected
referred to as Lead/Lag and is stated as a
to suit the intended application. Key options like tire size
percentage. New Holland has established a
and cast weight packages, combined with proper tire
Lead/Lag range that provides the operator with
pressure, determine actual tractor performance.
acceptable tire wear, front tire steering, and front
tire pulling power. Any tire combination that falls
Front Tire Selection
within this range is acceptable. Lead/Lag
Choose the largest front tire or front dual option with
percentages can be calculated using the formula:
the highest weight-carrying capacity that matches the
row spacing. Selection of a larger tire results in reduced
compaction and permits heavier loads on the front axle
(Rolling Circum. of Front Tire x Interaxle Ratio)
without exceeding the tire load-carrying capacity.
ear Tire
- Rolling Circum. of R
X 100 = Lead/Lag %
Rolling Circum. of Rear Tire
Rear Tire Selection
Choose rear tires that are large enough to carry the
total ballasted weight of the tractor with an inflation
pressure in the 6 - 14 psi range. Larger tires require
less inflation pressure to support a given axle load
than narrow tires do. Use only approved tire
combinations. The Lead/Lag should be between 0 -
5%, with a value of 1 - 3% being best. Negative
Lead/Lag is not recommended.
20
TJ Tractors
Tire manufacturers have found practices and procedures developed for bias ply tires may actually reduce the
performance of radial ply tires. Minor adjustments in the tractor weight split (front/rear), ballast, and tire inflation
pressure can dramatically improve performance of the tractor.
Proper weight split, ballast, and tire inflation can:
• Improve Traction
• Increase Powertrain Life
• Reduce Compaction
• Reduce Tire Wear
• Reduce Occurrence of Powerhop
• Improve Ride
TOO MUCH BALLAST
CORRECT BALLAST
TOO LITTLE BALLAST
21
m/
RIDE, TRACTION & PERhttps://truckmanualshub.co
Ballasting 4WD Tractors - Drawbar Applications
Tractors used in drawbar work only.
Generally these tractors are not equipped with
a 3-point hitch or PTO and are used to pull
standard pull type implements such as disks,
chisel plows, field cultivators, rippers, etc.
Tractors in this type of application should be
ballasted with no more than 55% of the weight
on the front axle.
Front 55%
Rear 45%
Drawbar Towed High Draft Implements
Ballasting 4WD Tractors - 3-Point Hitch Applications
Tractors used for 3-point hitch work only.
Tractors in this type of application should
be ballasted with 60% of the weight on the
front axle.
Front 60%
Rear 40%
Hitch Mounted IImpllementts
Ballasting 4WD Tractors - High Vertical Load Applications
Tractors used for scrapers or other
implements with high vertical loads.
Tractors in this type of application should be
ballasted with 65% of the weight on the front
axle. This should allow the tractor to achieve a
50/50 weight split while operating under load.
If the tractor is equipped with a 3-point hitch
or PTO it may not be possible to achieve this
level of balance and still stay within the
Front 65%
Rear 35%
maximum operating weight limitations. If this
Implements Wiitth Heavy Verttiicall Drawbar Loads
is the case, adjust as close as possible to the
65%-35% specification, and stay within the
maximum operating weight limitation.
22
Front and Rear Suitcase Weights
Front Frame Weights
Front suitcase weights can be mounted on the front of
the tractor with a weight hanger. A maximum of 18
suitcase weights at 45 kg (100 lb) each can be installed,
depending on the application, tractor static weight ratio
and soil conditions.
Rear Frame Weights
Suitcase weights can also be mounted on the rear of the
tractor with a weight frame. However, rear suitcase
weights cannot be used if the tractor is equipped with a
three point hitch.
A maximum of 10 suitcase weights (TJ 275-325) or
14 suitcase weights (TJ375-500) at 45 kg (100 lb) each
can be installed depending on implement application,
front mounted equipment, tractor static weight split and
soil conditions.
Assembly weight:
Weight frame = 468 kg (1032 lb)
Frame + 14 suitcase weights = 1166 kg (2571 lb)
The entire weight assembly can be removed from the
tractor by removing 2 bolts and attaching an overhead
hoist to the rear holes on each side of the lifting bracket.
See your dealer for more information.
IMPORTANT: Total static weight of the tractor with all
equipment and ballast must never be more than the
recommended operating weight. See Maximum
Recommended Operating Weight in Operator’s Manual.
23
m/
RIDE, TRACTION & PERhttps://truckmanualshub.co
TG Tractor—Tire Load and Inflation
The inflation pressures are based on cold inflation pressure recommended by the Tire and Rim
Association Inc.
How to Use the Load and Inflation Charts:
1. Determine the ballasted tractor front axle weight and tractor rear axle weight.
Note: If using fully mounted or high vertical drawbar implements, add the weight of the implement
to the rear weight (refer to implement manual for weight).
2. Find the appropriate chart (Front Singles or Duals, Rear Singles, Duals or Triples).
3. Find tire size and correct rating.
4. Follow the row across to the first weight that is above your tractor (front or rear) axle weight.
5. Follow the column up to find the minimum recommended tire inflation pressure.
Note: Never exceed the load capacity for a particular tire. To obtain more load capacity, use duals
or change to a different tire.
Note: Never exceed the inflation pressure for a particular tire. The last number in the chart is the
maximum inflation pressure for that particular tire.
Note: Increase tire pressures 2 to 4 PSI over those stated in the chart for any of the following
conditions:
• If tire pressures are not checked daily
• Sharp turning and or braking will be encountered
• In-Furrow operation (Furrow tire only)
• Side hill operation
24
TJ Tractor
Tire Pressure for Maximum Tire Load at Rated Inflation
To achieve the best tire pressure and load capacity, scale weigh the front and rear axle of the tractor.
1)
Determine proper ballast weight split.
60% Front/40% Rear - Tractor used with hitch mounted implements.
55% Front/45% Rear - Tractor used with drawbar towed high draft implement.
65% Front/35% Rear - Tractor used with high vertical drawbar loads.
See Tractor Ballast information for additional information.
2)
Determine correct static load distribution and tire pressure from chart.
Example: Tractor used with standard drawbar implements, 18.4R-42 dual tires and a full tank of fuel. Desired
weight split = 55% Front/45% Rear.
Front Weight of Tractor = 14,000 lb (6350 kg)
Rear Weight of Tractor = 9392 lb (4260 kg)
Total Weight of Tractor = 23,392 lb (10610 kg)
3)
Determine weight distribution by dividing front and rear weight by total weight.
Tractor Weight Distribution = 59.8% Front Axle
40.2% Rear Axle
4)
Adjust the weight distribution by adding 2000 lb (907 kg) weight to the rear wheels.
Adjusted Weight:
Front weight = 14,000 lb (6350 kg)
Rear weight = 11,392 lb (5167 kg)
Total weight = 25,392 lb (11 517 kg)
Total weight distribution = 55.1% Front Axle
44.9% Rear Axle
5)
Front Static Load - weight divided by number of tires.
14,000 lb/4 = 3500 lb
(6350 kg/4 = 1588 kg)
Front Chart: 18.4R-42 Dual Tires - 3500 lb = 9 PSI
(1588 kg = 62 kPa)
Rear Static Load - weight divided by number of tires.
11,392 lb/4 = 2848 lb
(5167 kg/4 = 1292 kg)
From Chart = 18.4R-42 Dual Tires - 2848 lb = 7 PSI
(1292 kg = 48 kPa)
25
m/
RIDE, TRACTION & PERhttps://truckmanualshub.co
Load/Inflation
Chart - Conventional Size Radial Tires
Tire Size
Inflation
6
7
8
9
10
12
14
16
18
20
22
24
Pressure
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
Single lbs.
NR
NR
2680
2830
3080
3420
3740
3960
4300
4540
4800
5080
14.9R46
Dual lbs.
2000
2170
2360
2490
2710
3010
3290
3480
3780
4000
4220
4470
Triple lbs.
1860
2030
2200
2320
2530
2800
3070
3250
3530
3720
3940
4170
Single lbs.
NR
NR
3520
3740
3960
4400
4800
5200
5680
6000
6400
6600
18.4R38
Dual lbs.
2640
2820
3100
3290
3480
3870
4220
4580
5000
5280
5630
5810
Triple lbs.
2460
2620
2890
3070
3250
3610
3940
4260
4660
4920
5250
5410
Single lbs.
NR
NR
3740
3960
4180
4680
5080
5520
6000
6400
6600
6950
18.4R42
Dual lbs.
2710
3010
3290
3480
3680
4120
4470
4860
5280
5630
5810
6120
Triple lbs.
2530
2800
3070
3250
3430
3840
4170
4530
4920
5250
5410
5700
Single lbs.
NR
NR
3860
4180
4400
4940
5360
5840
6150
6600
6950
7400
18.4R46
Dual lbs.
2900
3200
3400
3680
3870
4350
4720
5140
5410
5810
6120
6510
Triple lbs.
2710
2980
3170
3430
3610
4050
4400
4790
5040
5410
5700
6070
Single lbs.
NR
NR
4300
4540
4800
5360
5840
6400
6800
7150
7600
8050
20.8R38
Dual lbs.
3200
3480
3780
4000
4220
4720
5140
5630
5980
6290
6690
7080
Triple lbs.
2980
3250
3530
3720
3940
4400
4790
5250
5580
5860
6230
6600
Single lbs.
NR
NR
4540
4800
5080
5680
6150
6800
7150
7600
8050
8550
20.8R42
Dual lbs.
3290
3680
4000
4220
4470
5000
5410
5980
6290
6690
7080
7520
Triple lbs.
3070
3430
3720
3940
4170
4660
5040
5580
5860
6230
6600
7010
Single lbs.
NR
NR
5080
5520
5840
6400
7150
7600
8250
8800
9100
9650
24.5R32
Dual lbs.
3780
4120
4470
4860
5140
5630
6290
6690
7260
7740
8110
8490
Triple lbs.
3530
3840
4170
4350
4790
5250
5860
6230
6770
7220
7460
7910
Single lbs.
NR
NR
6150
6600
6950
7600
8550
9100
9650
30.5LR32
Dual lbs.
4470
5000
5410
5810
6120
6690
7520
8010
8490
Triple lbs.
4170
4660
5040
5410
5700
6230
7010
7460
7910
Goodyear Tire and Rubber Co.
Load/Inflation Chart - Metric Size Radial Tires
Tire Size
Inflation
6
7
9
10
12
13
15
17
20
23
26
29
Pressure
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
Single lbs.
NR
NR
3300
3640
3860
4180
4400
5080
5520
6150
6400
6800
380/90R46
Dual lbs.
2490
2710
2900
3200
3400
3680
3870
4470
4860
5410
5630
5980
Triple lbs.
2320
2530
2710
2980
3170
3430
3610
4170
4530
5040
5250
5580
Single lbs.
NR
NR
3960
4300
4540
4940
5200
5840
6600
7150
480/80R38
Dual lbs.
2900
3200
3480
3780
4000
4350
4580
5140
5810
6290
Triple lbs.
2710
2980
3250
3530
3720
4050
4260
4790
5410
5860
Single lbs.
NR
NR
4080
4400
4800
5200
5520
6150
6950
7600
480/80R42
Dual lbs.
3010
3290
3590
3870
4220
4580
4860
5410
6120
6690
Triple lbs.
2800
3070
3350
3610
3940
4260
4530
5040
5700
6230
Single lbs.
NR
NR
4300
4680
5080
5360
5680
6400
7150
7850
8250
8550
480/80R46
Dual lbs.
3200
3480
3780
4120
4470
4720
5000
5630
6290
6910
7260
7520
Triple lbs.
2980
3250
3530
3840
4170
4400
4660
5250
5860
6440
6770
7010
Single lbs.
NR
NR
4680
5080
5520
5840
6150
6950
7850
8550
520/85R38
Dual lbs.
3400
3780
4120
4470
4860
5140
5410
6120
6910
7520
Triple lbs.
3170
3530
3840
4170
4530
4790
5040
5700
6440
7010
Single lbs.
NR
NR
4940
5360
5680
6150
6600
7400
8250
9100
520/85R42
Dual lbs.
3590
4000
4350
4720
5000
5410
5810
6510
7260
8010
Triple lbs.
3350
3720
4050
4400
4660
5040
5410
6070
6770
7460
Single lbs.
NR
NR
5080
5520
6000
6400
6800
7600
8550
9350
520/85R46
Dual lbs.
3780
4120
4470
4860
5280
5630
5980
6690
7520
8230
Triple lbs.
3530
3840
4170
4530
4920
5250
5580
6230
7010
7670
Single lbs.
NR
NR
6600
7150
7850
8250
8800
9900
11000
12300
710/70R42
Dual lbs.
4860
5410
5810
6290
6910
7260
7740
8710
9680
10820
Triple lbs.
4530
5040
5410
5860
6440
6770
7220
8120
9020
10090
26
Goodyear Tire and Rubber Co.
Load/Inflation Chart - FWD Tiires
Standard Size
Tire Size
Inflation
6
7
8
9
10
12
14
16
18
20
22
24
Pressure
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
Single lbs.
NR
NR
2150
2270
2470
2680
3000
3200
3420
3640
3860
4080
14.9R30
Dual lbs.
1600
1740
1890
2000
2170
2360
2640
2820
3010
3200
3400
3590
Triple lbs.
1490
1620
1760
1860
2030
2200
2460
2620
2800
2980
3170
3350
Metric Size
Tire Size
Inflation
6
7
9
10
12
13
15
17
20
23
26
29
Pressure
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
PSI
Single lbs.
NR
NR
2600
2830
3000
3200
3420
3860
4300
4800
380/85R30
Dual lbs.
1890
2110
2290
2490
2640
2820
3010
3400
3780
4220
Triple lbs.
1760
1970
2130
2320
2460
2620
2800
3170
3530
3940
Single lbs.
NR
NR
2760
3000
3200
3420
3640
4080
4540
5080
5360
5520
380/85R34
Dual lbs.
2000
2240
2430
2640
2820
3010
3200
3590
4000
4470
4720
4860
Triple lbs.
1860
2080
2260
2460
2620
2800
2980
3350
3720
4170
4400
4530
Single lbs.
NR
NR
3300
3640
3860
4180
4400
4940
5520
6000
6400
6600
480/70R34
Dual lbs.
2430
2710
2900
3200
3400
3680
38970
4350
4860
5280
5630
5810
Triple lbs.
2260
2530
2710
2980
3170
3430
3610
4050
4530
4920
5250
5410
Single lbs.
NR
NR
2760
3000
3200
3420
3640
4180
4540
5080
5360
5520
380/80R38
Dual lbs.
2000
2240
2430
2640
2820
3010
3200
3680
4000
4470
4720
4860
Triple lbs.
1860
2080
2260
2460
2620
2800
2980
3430
3720
4170
4400
4530
Ballasting CD
New Holland offers a variety of
CD based tools to assist in
preparing your tractor for the
field. Contact your dealer for
more information.
CD Rom Order # NH202013
27
m/
RIDE, TRACTION & PERhttps://truckmanualshub.co
Preventing Powerhop
On MFD tractors, powerhop occurs when the front axle attempts to out-pull the
rear axle. On 4WD tractors, powerhop occurs when the rear axle attempts to out-
pull the front axle.
Regardless of model or manufacturer, under certain
Possible Solutions for
conditions tractors may hop fore and aft or the tires
Powerhopping Problems.
may bounce up and down. You may experience this
type of out-of-phase movement that results in a
If powerhop occurs after following all of the
twisting motion of the tractor. Engineers call this type
guidelines on leveling implement tire size, weight
of movement “powerhopping” but some customers
split, ballast type, and inflation pressures, make the
have termed it “grasshoppering.”
following adjustments to inflation pressures:
This results most commonly in heavy tillage
FWD
operations with pull-type equipment.
Raise front inflation pressure by 2 PSI. If powerhop
is not eliminated, further front tire inflation pressure
What Causes Powerhopping?
increases in 2 PSI increments is advised until hop is
n The tractor is not properly matched to
eliminated. Rear tire inflation pressures should
the implement.
remain at the correct pressures for the load. The
maximum front pressure should not exceed 6 PSI
n Tire pressures are not properly balanced
above the maximum rated pressure for the tire
from front to rear.
(radial or bias.) If the tractor continues to powerhop,
n Improper tire size combinations are installed
take weight off of the front axle.
on the tractor (creating improper lead/lag
ratio on the FWD equipped tractor).
4WD
n The operator is attempting to go too fast
Raise the rear inflation pressure from the correct
for the implement, the operation, or the
inflation by 2 PSI. If powerhop is not eliminated,
operating conditions.
increasing rear tire inflation pressure in 2 PSI
increments is advised until hop is eliminated. The
n Improper front to rear weight ratio on tractor.
maximum pressure should not exceed 6 PSI above
the maximum rated pressure for the tire (radial or
bias.) If raising the rear pressure fails to control hop,
take weight off of the rear of the tractor. On
extremely steep hillside operations, keep the fronts at
the correct pressure for the load and raise the rear
pressures.
28
HYDRAULIC SYSTEM
Hydraulic Productivity
Hydraulic Connection Basics
The more demanding your application, the greater the
Hydraulic circuits must be properly connected to
need to properly manage the tractor hydraulic system.
the tractor to operate correctly.
Proper circuit connection, use of the flow control, and
Implement Raise/Lower Cylinders
removal of unintended circuit restrictions can improve
hydraulic system performance.
Implement raise/lower cylinders should be connected
with the remote valve load check in the raise side of the
A basic hydraulic circuit consists of:
circuit. If the cylinder is not connected in this way, the
n A pump
implement will settle while the control valve is in the
n Control valve(s)
neutral position.
n Hydraulic function
(steering, implement, 3-point hitch, or other).
Larger implements equipped with several lift cylinders
will require more flow to properly lift and lower the
implement. If the flow control is set to deliver the
necessary flow requirement the operator can activate the
circuit and tend to other necessary activities while the
hydraulic circuit completes its cycle.
Valves/Couplers
PUMP
Hydraulic Orbital Motors
n Orbital motors (sprayers, planters, etc.) should be
TANK
connected with the motor supply connected to the
lower side of the circuit.
n Orbital motor supply/return lines should not contain
load checks or other in-line restrictions.
n The return side of the circuit should be connected
to a motor return port. A motor return connection
minimizes restrictions and improves operating
efficiency in the hydraulic circuit.
After connection, operate the circuit and
adjust the flow control dial until the
desired raise/lift time is obtained.
Megaflow Option
The optional megaflow pump adds an additional
hydraulic pump to the system, an additional 29.4 gpm
for a total hydraulic system output of 68 gpm overall.
This is very beneficial when low flow high pressure is
needed at the same time as high flow low pressure.
With the Megaflow option:
n The Megaflow pump supplies oil to remotes 3, 4, and 5.
n The standard pump supplies oil to steering, remotes
1 & 2, three-point hitch, and power beyond.
29
INSTRUMENTATION
A key to efficient tractor operation is knowing what your tractor is doing and understanding what’s going on
internally. The most effective tool for accomplishing this is the tractor’s own instrumentation.
1. Tractor Monitor (Standard)
The Tractor Monitor displays basic tractor operations and
provides an interface for configuration and calibration.
• Engine Oil Pressure
• Engine Coolant Temperature
• Fuel Level
• Operation Indicators (gear, direction, etc.)
• Warning Indicators
1
2. Performance Monitor (Optional)
The Performance Monitor displays performance related
functions including:
• Engine Power (electronic engines only)
• Area Count
• Timer Function
With the optional performance
• Slip Percentage
2
monitor, performance items
• Remote Hydraulic Flows
such as individual remote flow
adjustments, fuel consumption,
• Remote Hydraulic Timers
and more can be monitored on
• Service Reminders
the screen.
• Automatic Engine Shut-down Protection
• Custom Headland Management
Tractor Controls - TG and TJ Tractors
The remote control levers on TG and TJ tractors
electronically activate the remote hydraulic circuits.
The control levers have four positions:
• Raise
• Neutral
• Lower
• Float
Contact your New Holland dealer for a detailed
demonstration on the proper use of the hydraulic controls.
Behind each control lever is a Remote Function
TG console shown.
control.The remote function control has five positions:
• Lock
• No Float
• Full Function
• Loader
• Hydraulic Motor
30
MAINTENANCE PARThttp
MasterGold™ Engine Oil
GR-9 Multipurpose Grease
Your engine takes a tremendous
GR-9 is a general
pounding day in and day out. But
purpose NLGI 2, lithium-
you can protect and preserve it with
soap, extreme-pressure
the best engine oil available —
grease for use in agricultural, construction and
MasterGold.
industrial equipment. GR-9 is for anti-friction and
plain bearings (including non-disc brake wheel
MasterGold is a premium, high-
bearings), universal joints, spline shafts, water pumps
performance diesel engine oil
and general chassis lubrication.
designed to stand up to the toughest operating
conditions. Less susceptible to thermal and chemical
Systemgard® Oil Analysis
breakdown, MasterGold provides excellent oil-
consumption control and maximum engine-wear
Let Systemgard oil
protection.
analysis tell you what’s
really going on inside
Compare before you buy. Use the engine oil
your engine, transmission,
specifically designed for your equipment and field
and hydraulic system.
conditions. Prolong your hard working engine’s life
Detect potential problems
with MasterGold heavy-duty engine oil.
early, spot trends, and keep small, easily fixed
problems from becoming serious ones. See your New
MasterTran™ Fluid
Holland dealer for more information.
Up to 70% of all transmission and
hydraulic system failures are fluid
New Holland
related. So protect and preserve
Maintenance Inspections
your equipment with MasterTran
Everyone agrees that routine inspections by trained
and prevent costly downtime.
technicians are essential to good maintenance.
MasterTran is blended to provide
Inspections not only need to be routine, they need
optimum machine performance and
to be consistent with the needs of the equipment
long life in the most severe operating conditions.
and its owner.
It provides superior wear protection for hydraulic
Our New Holland Maintenance Inspection programs
components, drive train gears, and other
are based upon prearranged inspections at intervals
transmission parts.
consistent with your needs. A professional and
systematic approach to equipment service can:
Controlled frictional characteristics provide safe,
smooth operation of wet brakes and clutches.
• Reduce costly downtime.
• Extend the service life of your equipment.
Excellent filterability provides extra protection against
system contamination.
• Increase machine productivity.
Ask about New Holland Maintenance Inspections today!
Hypoide 140 Gear Lube
Recommended for differential
and planetaries in TG tractors
with FWD axles. This
transmission and gear oil, with
extreme pressure (E.P.)
characteristics, is designed for
hypoid gears and final drives of
agricultural and construction
equipment.
31
MAINTENANCE PARTS
TG Tractors/TJ Tractors
Models TG210/TG230
Models TG255/TG285
Qty. Filter Number
Description
Qty. Filter Number
Description
1
86990980
Engine Oil
1
86990980
Engine Oil
1
in-line 87400496 AND
Fuel
1
86991015 AND
Fuel
1
(primary) 86991002 &
1
in-line 87400496
1
(final) 86991003
1
87413809 AND 87413810
Hydraulic
1
87413809 AND 87413810
Hydraulic
1
451525A1
Air (outer)
1
451525A1
Air (outer)
1
451526A1
Air (inner)
1
451526A1
Air (inner)
1
86994156 AND
Cab
1
86994156 AND
Cab
2
293615A1 (recirculating)
Cab
2
293615A1 (recirculating)
Cab
1
86990977
Coolant
1
86990977
Coolant
Models TJ375/TJ425/TJ450
Models TJ500
Qty. Filter Number
Description
Qty.
Filter Number
Description
1
441700A1
Engine Oil
1
441700A1
Engine Oil
1
441701A1
Fuel
1
441701A1
Fuel
1
(near batt. compartment) 86018758
Hydraulic
1
(near batt. compartment) 86018758
Hydraulic
AND EITHER
AND EITHER
2
435140A1 (std hyd.) OR
2
435140A1 (std hyd.) OR
3
435140A1 (mega-flow)
3
435140A1 (mega-flow)
1
87408712
Air (outer)
1
87417042
Air (outer)
1
87408713
Air (inner)
1
87417043
Air (inner)
1
259288A1 AND 386751A1
Cab
1
259288A1 AND 386751A1
Cab
1
441702A1
Coolant
1
441702A1
Coolant
Models TJ275/TJ325
Qty. Filter Number
Description
1
441703A1
Engine Oil
1
448545A1 AND (in-line) 87400496
Fuel
1
(near batt. compartment) 86018758
Hydraulic
AND EITHER
2
435140A1 (std hyd.) OR
3
435140A1 (mega-flow)
1
87408704
Air (outer)
1
87408705
Air (inner)
1
259288A1 AND 386751A1
Cab
1
9672301
Coolant
Protect your equipment with genuine
New Holland filters and lubricants.
32
MAINTENANCE PARThttp
TG Tractors/TJ Tractors
Oil/Filter Change Intervals & Capacities
Hours/Yrs.
Capacity w/ Filter
Engine Oil/Filter
300
5.5G (21L)
Fuel Filters
600
—
Engine Coolant Filter
600
—
FWD Differential Oil*
- Standard/TerraGlide - 10-Bolt Axle
1200 / 1 Yr
13Qts (12.3L)
- Standard/TerraGlide - 12-Bolt Axle
12.5Qts (11.8L)
- SuperSteer
14Qts (13.2L)
FWD Planetary Oil (Each)
- 10-Bolt Axle
1200 / 1 Yr
3 Pints (1.4L)
- 12-Bolt Axle
7 Pints (3.3L)
Transmission Oil, Filter(s) & Breather
1500
45.5G (172L)
Engine Coolant & Coolant Conditioner - TG210/230
2100
6G (22.7L)
- TG255/285
6.5G (24.6L)
Engine Primary & Secondary Air Filters
as required
—
Cab Air & Recirculation Filters
as required
—
* When changing FWD differential oil, also add 1 pint New Holland Limited Slip Additive (B96606).
NOTE: See your operator manual for complete information.
Oil/Filter Change Intervals & Capacities
Hours/Yrs.
Capacity w/ Filter
Engine Oil/Filter
- TJ275
500 / 6 mos.
6.3G (24L)
- TJ325
7.3G (28L)
- TJ375/425/450
13G (49L)
Fuel Filter
500 / 6 mos.
—
Engine Coolant Filter
1500 / 1 Yr.
—
Engine Air Filters - Primary & Secondary
1500 / 1 Yr.
—
Axle/Hydraulic Oil - TJ275/325
1500 / 1 Yr.
63G (238L)*
- TJ375/425/450
69G (261L)*
Axle Lube Filter
1500 / 1 Yr.
—
Hydraulic Oil Filter
1500 / 1 Yr.
—
Megaflow Oil Filter (Option)
1500 / 1 Yr.
—
Transmission Oil
- with PTO
1500 / 1 Yr.
13.5G (51.1L)
- without PTO
13G (49.2L)
Transmission Oil Filter
1500 / 1 Yr.
—
Cab Air Filter
1500 / 1 Yr.
—
Engine Coolant & Coolant Conditioner - TJ275
6000 / 2 Yr.
11.4G (43L)
- TJ325
12.4G (47L)
- TJ375/425/450
21.2G (80L)
* Total Axle System Capacity includes filters, front and rear axle and reservoir. If TPH equipped add 5G (19L).
NOTE: More frequent changes may be signaled by service monitor. Operator manual has complete information.
33
