Can-Am MAVERICK R SERIES. OPERATOR’S GUIDE (2024)

OPERATOR’S GUIDE

Covered Models

Maverick R Base

In Canada, products are distributed and serviced by Bombardier Recreational

Products Inc. (BRP).

In the USA, products are distributed and serviced by BRP US Inc.

In the European Economic Area (which is comprised of the member states of the

European Union plus the United Kingdom, Norway, Iceland and Liechtenstein),

the Commonwealth of the Independent States (including Ukraine and Turkmeni-

stan) and Turkey, products are distributed and serviced by BRP European Distri-

bution S.A. and other affiliates or subsidiaries of BRP.

For all other countries, products are distributed and serviced by Bombardier Rec-

reational Products Inc. (BRP) or its affiliates.

TABLE OF CONTENTS

GENERAL INFORMATION

FOREWORD

Know Before you Go

Safety Messages

About this Operator’s Guide

Respect of the Environment

SAFETY INFORMATION

BEFORE YOU GO

Operating Age and Ability

Drugs and Alcohol

Protective Gear

Required Equipment

GET FAMILIAR WITH THE VEHICLE

Off-Road Operation

Steering

Braking

Programmable D.E.S.S. Key

Vehicle Blind Spots

Carrying Loads

Hauling a Load

Accessories and Modifications

RIDE SAFELY

General Driving Tips

Riding in a Group

Operating in Reverse

Crossing Roads

Riding on Paved Surfaces

Shallow Water Crossing

Riding on Snow or Ice

Riding on Sand

Riding on Gravel, Loose Stones or Other Slippery Surfaces

Crossing Obstacles

Hill Driving Conditions

Avoid Collisions

Avoid Rollovers and Tipovers

Terrain Condition

Avoid Carbon Monoxide Poisoning

Avoid Gasoline Fires and Other Hazards

Avoid Burns from Hot Parts

PRACTICE EXERCISES

Turning Exercises

U Turn Exercises

Braking Exercises

Reverse Exercises

Emergency Engine Stopping Exercise

IMPORTANT ON-PRODUCT LABELS (CANADA/UNITED STATES)

Hang Tag

Safety Labels

TABLE OF CONTENTS

Safety Compliance Hang Tag

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANA-

DA/UNITED STATES)

Safety Pictogram

PRE-RIDE INSPECTION CHECK LIST

What to Do Before Starting the Engine (Key OFF)

What to Do Before Starting the Engine (Key ON)

What to Do After the Engine is Started

REPORTING SAFETY DEFECTS

VEHICLE INFORMATION

PRIMARY CONTROLS

STEERING WHEEL

SHIFT PADDLES

ACCELERATOR PEDAL

BRAKE PEDAL

ELECTRONIC SHIFT LEVER

PARK BUTTON

NEUTRAL BUTTON

LOW RANGE BUTTON

MANUAL MODE BUTTON

SECONDARY CONTROLS

RF D.E.S.S Key and RF D.E.S.S. Post

ENGINE START/STOP BUTTON

HEADLIGHT DIMMER SWITCH

OVERRIDE SWITCH

KEYPAD

EQUIPMENT

TILT STEERING WHEEL

PASSENGER HANDHOLDS

CENTRAL STORAGE COMPARTMENT

GLOVE BOX

TROUBLESHOOTING TOOLS

CENTRAL REARVIEW MIRROR

FOOTRESTS

DOORS

SEAT BELTS

SEATS

FUEL RESERVOIR CAP

CARGO RACK

RECOVERY POINTS

CUP HOLDERS

7.6" DIGITAL DISPLAY

Multifunction Display

Indicator Lamps

Settings

TUNE YOUR RIDE

Engine Mode

4WD Mode

DPS Function

Suspension Adjustment Guidelines

TABLE OF CONTENTS

Suspension Factory Settings

Suspension Adjustments

FUEL

FUEL REQUIREMENTS

VEHICLE FUELING PROCEDURE

BREAK-IN PERIOD

100

Operation During Break-In

100

BASIC PROCEDURES

101

STARTING THE ENGINE

101

WAKING UP THE ELECTRICAL SYSTEM

101

OPERATING THE SHIFT LEVER

101

CHOOSING THE CORRECT RANGE (LOW OR HIGH)

102

STOPPING THE ENGINE AND PARKING THE VEHICLE

102

SPECIAL PROCEDURES

103

PERMANENT NEUTRAL or MECHANICAL NEUTRAL ACTIVATION

103

LIMP HOME MODE

104

DEAD BATTERY

104

ROLLED OVER VEHICLE

106

SUBMERGED VEHICLE

106

TRANSPORTING THE VEHICLE

107

Using Vehicle Power to Climb Onto Trailering Equipment

108

Using a Winch to Pull Vehicle Onto Trailering Equipment

109

Securing Vehicle for Transport

109

Getting Vehicle Out of Trailer

110

LIFTING AND SUPPORTING THE VEHICLE

111

Front of Vehicle

111

Rear of Vehicle

111

MAINTENANCE

MAINTENANCE SCHEDULE

114

EPA Regulation - Canadian and USA Vehicles

114

Air Filter Maintenance Guideline

114

Severe Duty Use

115

Deep Mud / Water Use

115

Maintenance Schedule

116

Maintenance Records

124

MAINTENANCE PROCEDURES

129

ENGINE AIR FILTER

129

FRONT GRILLE

130

EVAPORATIVE EMISSION SYSTEM PRE-FILTER (If Equipped)

131

ENGINE OIL

131

ENGINE OIL FILTER

134

FRONT RADIATOR

135

INTERCOOLER AND REAR RADIATOR

136

ENGINE COOLANT

137

EXHAUST SYSTEM

139

GEARBOX

140

DISCONNECT UNIT

145

FRONT DIFFERENTIAL

146

REAR FINAL DRIVE

148

BATTERY

149

TABLE OF CONTENTS

FUSES

151

LIGHTS

154

SPARK PLUGS

154

DRIVE SHAFT BELLOWS

158

WHEEL BEARING

158

WHEELS AND TIRES

159

SUSPENSION

160

BRAKES

161

SEAT BELTS

162

CAGE

162

VEHICLE CARE

164

Vehicle Cleaning and Protection

164

STORAGE AND PRESEASON PREPARATION

165

TECHNICAL INFORMATION

VEHICLE IDENTIFICATION

168

Vehicle Identification Number

168

Engine Identification Number

168

Transmission Identification Number

168

COMPLIANCE LABELS

169

Emission Control Information

169

ANSI/ROHVA Label

170

NRMM Comformity Label

171

Fuel Ethanol Content

171

TECHNICAL INFORMATION LABELS

172

Verifying the Engine Oil Level

172

Recommended Fuel

173

Air Filter Maintenance

174

RADIO FREQUENCY DIGITALLY ENCODED SECURITY SYSTEM (RF D.

E.S.S. KEY)

175

EVAPORATIVE EMISSION CONTROL SYSTEM

176

NOISE EMISSION CONTROL SYSTEM REGULATION (CANADA AND

UNITED STATES)

177

NOISE EMISSION AND VIBRATION VALUES

178

Machinery Directive 2006/42/EC Compliant Models

178

DECLARATION OF CONFORMITY

179

EU Declaration of Conformity

179

UK Declaration of Conformity

180

EAC DECLARATION OF CONFORMITY

181

TECHNICAL SPECIFICATIONS

184

ENGINE

184

VEHICLE

187

TABLE OF CONTENTS

TROUBLESHOOTING

TROUBLESHOOTING GUIDELINES

194

DIGITAL DISPLAY MESSAGES

197

WARRANTY

BRP LIMITED WARRANTY FOR CANADA AND USA: 2024 CAN-AM^®

SSV

200

1) Scope of the Limited Warranty

200

2) Limitations of Liability

200

3) EXCLUSIONS - Are Not Warranted

200

4) Warranty Coverage Period

201

5) Conditions to Have Warranty Coverage

201

6) What to Do to Obtain Warranty Coverage

202

7) What BRP Will Do

202

8) Transfer

202

9) Consumer Assistance

202

US EPA EMISSION - RELATED WARRANTY

203

Emission-Related Warranty Period

203

Components Covered

203

Limited Applicability

204

CALIFORNIA EVAPORATIVE EMISSIONS CONTROL WARRANTY

STATEMENT

206

Your Warranty Rights And Obligations

207

OHRV Manufacturer’s Warranty Coverage

207

Owner’s Warranty Responsibilities

208

BRP LIMITED WARRANTY FOR INTERNATIONAL: 2024 CAN-AM^®

SSV

209

1) Scope of the Limited Warranty

209

2) Limitation of Liability

209

3) EXCLUSIONS - Are Not Warranted

210

4) Warranty Coverage Period

210

5) For Products Sold In Australia Only

211

6) Conditions to Have Warranty Coverage

211

7) What to Do to Obtain Warranty Coverage

212

8) What BRP Will Do

212

9) Transfer

212

10) Consumer Assistance

212

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA,

THE COMMONWEALTH OF THE INDEPENDENT STATES AND TURKEY:

2024 CAN-AM^® SSV

214

1) Scope of the Limited Warranty

214

2) Limitations of Liability

214

3) EXCLUSIONS - Are Not Warranted

215

4) Warranty Coverage Period

216

5) For Products Sold In France Only

216

6) Conditions to Have Warranty Coverage

216

7) What to Do to Obtain Warranty Coverage

217

8) What BRP Will Do

217

9) Transfer

218

10) Consumer Assistance

218

FOREWORD

Congratulations on your purchase of a new Can-Am^® side-by-side vehicle. It's

backed by the BRP limited warranty and a network of authorized Can-Am Off--

road dealers ready to provide the parts, accessories or service you may require.

Your dealer is committed to your satisfaction. He has taken training to perform

the initial setup and inspection of your side-by-side vehicle as well as completed

the final adjustment before you took possession. If you need more complete

servicing information, please ask your authorized Can-Am Off-road dealer.

At delivery, you were informed of the warranty coverage and signed the Pre-de-

livery Check List to ensure your new vehicle was prepared to your entire

satisfaction.

Know Before you Go

To learn how to reduce the risk of accident for you or bystanders, read this Oper-

ator's Guide before you operate the vehicle.

Also, read all safety labels on your vehicle and watch the Safety Video located

at:

https://can-am.brp.com/off road/safety

Or use the following QR code.

This vehicle is for off-road use only. It is mainly for general recreational use but it

may also be used for utility purposes.

Failure to follow the warnings contained in this Operator's Guide can result in

SERIOUS INJURY or DEATH.

Safety Messages

The types of safety messages, what they look like and how they are used in this

guide are explained as follows:

The safety alert symbol

indicates a potential injury hazard.

WARNING

Indicates a potential hazard which, if not avoiided, coulld result iin seriious

injury or death.

CAUTION

Indicates a hazardous situatiion which, if not avoided, could resullt iin mi-

nor or moderate injjury.

FOREWORD

NOTICE

Indiicates an iinstructiion which, iif not folllowed, could resullt in severely

damaged vehiicle components or other property.

About this Operator’s Guide

This Operator's Guide has been prepared to acquaint the owner/operator of a

new vehicle with the various vehicle controls, maintenance and safe operating in-

structions. It is indispensable for the proper use of the product.

Keep this Operator's Guide in the vehicle as you can refer to it for things such as

maintenance, troubleshooting and instructing others.

Note that this guide is available in several languages. In the event of any discrep-

ancy, the English version shall prevail.

If you want to view and/or print an extra copy of your Operator's Guide, simply

visit the following website:

www.operatorsguiides.brp.com

The information contained in this document is correct at the time of publication.

BRP, however, maintains a policy of continuous improvement of its products

without imposing upon itself any obligation to install them on products previously

manufactured. Due to late changes, some differences between the manufactured

product and the descriptions and/or specifications in this guide may occur. BRP

reserves the right at any time to discontinue or change specifications, designs,

features, models or equipment without incurring any obligation upon itself.

This Operator's Guide should remain with the vehicle when it is sold.

Respect of the Environment

The guidelines that we support are not designed to limit your fun, but to preserve

the beautiful freedom that you can experience only with an off-road vehicle!

These guidelines will keep operators and passengers healthy, happy and able to

introduce others to what they know and enjoy about their favorite pastime. So,

the next time you hit the trails, we ask you to remember that you are paving the

way for the future of our sport. Help us lead it down the right path! From all of us

at BRP, thank you for doing your share.

There is nothing more exhilarating than off-road adventures. Venturing onto trails

that cross wild areas is an exciting and healthy sport. However, as the number of

people using these recreational parks increases, so does the potential for dam-

age to the environment. Abuse of land, facilities and resources inevitably leads to

restrictions and closures of both private and public land.

In essence, the greatest threat to our sport, is all around us. Which leaves us with

one logical choice. We must always ride responsibly.

The vast majority respect the law and the environment. Each of us must set an

example for those who are new to the sport, young and old alike.

FOREWORD

It is in every one's best interest to tread lightly into our recreational areas. Be-

cause, in the long run, to protect the sport we must preserve the environment.

Recognizing the importance of this issue and the need for off-road riders to do

their share in preserving areas that make it possible to enjoy our sport, BRP in-

vite all off-road riders to remember that respecting the environment is not only

critical to the future of our industry but to future generations.

You are a good ambassador for your sport when you follow the principles below.

Become iinformed. Obtain maps, regulations and other information from the

Off-road clubs, the Forest Service or from other public land agencies. Learn the

rules and follow them and that goes for speed limits, too!

Avoid running over young trees, shrubs, and grasses and don't cut wood. On

flatlands or areas where trail riding is popular, it's important to ride only where au-

thorized. Remember, there is a link between protecting your environment and

your own safety.

Respect willdliife and be particularly sensitive of animals that are rearing young

or suffering from food shortage. Stress can sap scarce energy reserves. Refrain

from riding in areas where only animals are intended to tread!

Obey gate closures and regulatory signs and remember, light treaders don't

litter!

Stay out of wilderness areas. They're closed to all vehicles. Know where the

boundaries are.

Obtaiin permiissiion to travel across private land. Respect the rights of land-

owners and other people's privacy. Remember, the technology has lowered the

noise factor considerably, but you still shouldn't rev your engines where quiet “is

the order of the day”.

Off-road riders know all too well the efforts that have been made throughout the

sport's history to enjoy access to areas where people can ride safely and respon-

sibly. This effort continues today, as strong as ever.

Respecting the areas where we ride... wherever they may be... is the principal

way to ensure future enjoyment for all.

Take the opportunity to admire nature and all its wonders, is an experience cher-

ished by off-road riders. Respect the nature and wildlife will help our sport to

grow!

Finally, you don't have to leave big tracks or careen through a virgin forest to

show you can ride. So whether you're driving a high performance BRP off-road

vehicle or any other make or model, show you know what you're doing.

BEFORE YOU GO

WARNING

Diisregarding any of the safety precautions and iinstructiions contained in

this sectiion could cause injury iincludiing the possibillity of death.

Operating Age and Ability

Operators must be qualified.

Make sure the operator is 16 or older. Your state (or province) may have addi-

tional requirements.

Laws regarding the minimum age and licensing requirements vary from one juris-

diction to another. Be sure to contact the local authorities for information regard-

ing the legal operation of an off-road vehicle in the intended jurisdiction of use.

BRP highly recommends that you take a safety riding course. Basic training is re-

quired for the safe operation of any off-road vehicles.

Operation of this vehicle with a disability that impairs vision, reaction time, judg-

ment, or operation of the controls is not recommended.

The safe use of this vehicle depends on many conditions such as visibility,

speed, weather, environment, traffic, vehicle condition and the condition of the

operator.

The performance of this vehicle may significantly exceed that of other off-road

vehicles you have operated. Therefore, use by novice or inexperienced operators

is not recommended.

Each passenger must be tall enough to always be properly seated: back against

the backrest with seat belt fastened, holding both handholds, and feet firmly

planted on the floor.

Drugs and Alcohol

Never ride after consuming alcohol or drugs.

Riding this vehicle requires the operator and passenger(s) to be sober, attentive

and alert.

The use of drugs and alcohol, singly or in combination, decreases reaction time,

impedes judgment, impairs vision, and inhibits your ability to safely ride.

Protective Gear

It is important that the operator and passenger always wears appropriate protec-

tive clothing and apparel, including:

- An approved helmet

- Eye protection

- Boots

- Gloves

- A long sleeved shirt or jacket

- Long pants.

Depending on conditions, anti-fogging goggles may be required.

SAFETY INFORMATION

BEFORE YOU GO

RIDING GEAR

1. Approved helmet

2. Eye and face protection

3. Long sleeves shirt or jacket

4. Gloves

5. Long pants

6. Boots (over-the-ankle footwear)

Weather conditions should help you decide how to dress. To maximize comfort

and avoid frostbites in winter, dress for the coldest weather expected. Thermal

underwear next to the skin also provides good insulation.

Never wear any loose clothing that may get entangled in the vehicle or on tree

branches and shrubs.

Hellmets and Eye Protectiion

Helmets protect the head and brain from injury. Even with the vehicle's cage and

doors, objects can enter the cockpit and strike the head, or the head can strike

the cage itself or objects outside the vehicle. Even the best helmet is no guaran-

tee against injury, but statistics indicate that helmet use significantly reduces the

risk of brain injury. So, be safe and always wear a helmet while riding.

Choosiing a Helmet

Helmets should be manufactured to meet the appropriate standard in your state,

province or country and should fit properly.

A helmet with face protection is a better choice as it protects also against frontal

impacts. It can also protect against debris, stones, insects, the elements, etc.

An open-face helmet does not offer the same protection for the face and chin. If

you wear an open-face helmet, you should use a snap-on face shield and/or a

pair of goggles. Ordinary glasses or sunglasses are not sufficient eye protection

for riders. They can shatter or fly off, and they allow wind and airborne objects to

reach the eyes.

SAFETY INFORMATION

BEFORE YOU GO

For winter riding conditions, a stocking type cap, balaclava and face mask should

always be carried or worn.

Use tinted face shields or goggles in the daytime only; do not use them at night

or in poor illumination. Do not use them if they impair your ability to discern color.

Other Riidiing Gear

Footwear

Always wear closed toe footwear. Sturdy over-the-ankle boots with non-slip soles

offer more protection and allow you to plant your foot properly on footrest.

Avoid long shoelaces that can be tangled in the accelerator or brake pedals.

For winter riding conditions, rubber soled boots with either a nylon or leather

uppers, with removable felt liners are best suited.

Avoid rubber boots. Rubber boots may get trapped behind or between pedals,

impairing the proper operation of brake and accelerator pedals.

Glloves

Full-fingered gloves protect hands from the wind, sun, heat, cold and flying ob-

jects. Gloves that fit snugly will improve grip on the steering wheel and help re-

duce hand fatigue. Sturdy, reinforced motorcycle or ATV gloves help protect

hands better in the event of an accident or a rollover. If gloves are too bulky, it

may be difficult to operate the controls.

For winter riding conditions, hands should be protected by a pair of snowmobile

gloves which have sufficient insulation and allow use of thumbs and fingers for

operation of controls.

Jackets, Pants and Riiding Suiits

Wear a jacket or a long sleeved shirt and long pants, or a full riding suit. Quality

ATV-type protective gear will provide comfort, and it can help you avoid being

distracted by adverse environmental elements. In case of a crash, good quality

protective gear made of sturdy material may prevent or reduce injury.

In cool-weather riding, protect yourself against hypothermia. Hypothermia, a con-

dition of low body temperature, can cause loss of concentration, slowed reac-

tions and loss of smooth, precise muscle movement. In cool conditions, proper

protective gear like a windproof jacket and insulated layers of clothing are essen-

tial. Even while riding at moderate temperatures, you can feel very cold due to

the wind.

Protective gear that is appropriate for cold-weather riding may be too hot when

stopped. Dress in layers so that clothing can be removed as desired. Topping the

protective gear with a windproof outer layer can prevent cold air from reaching

the skin.

Rain Gear

If you must ride in wet weather, a rain suit or a waterproof riding suit is recom-

mended. On long rides, it is a good idea to carry rain gear. A dry rider will be

much more comfortable and alert.

SAFETY INFORMATION

BEFORE YOU GO

Hearing Protectiion

Long-term exposure to wind and engine noise when riding can cause permanent

hearing loss. Properly worn hearing protective devices such as earplugs can help

prevent hearing loss. Check local laws before using any hearing protective

devices.

Required Equipment

As the owner of an off-road vehicle, you are responsible for ensuring that all re-

quired safety equipment is aboard. Check your local regulations about

requirements.

This could include:

- First aid kit

- Sling: to help a defective or stuck vehicle

- Tool kit

- Phone in a watertight compartment designed for this application

- Current local map.

For a long ride, you should also include the following:

- Snack

- Flashlight.

SAFETY INFORMATION

GET FAMILIAR WITH THE VEHICLE

This vehicle may exceed the performance of other vehicles you may have ridden.

Take time to familiarize yourself with your new vehicle.

Inexperienced operators may overlook risks and be surprised by vehicle’s specif-

ic behavior and terrain conditions. Ride slowly. Excessive speed and reckless

driving can kill.

Make sure you read and understand the content of this operator’s guide to be-

come completely familiar with the controls and operation of this vehicle before

embarking on your first trip or taking on a passenger(s).

Take time to practice driving solo in a suitable traffic-free area to become accus-

tomed to the feel and response of each control.

It is very important to inform any operator, regardless of his experience, of the

handling characteristics of this vehicle. The configuration, such as vehicle height,

width, suspension type, tires type, and type vary from a model to another. The

vehicle handling is greatly influenced by these characteristics.

Off-Road Operation

The very nature of off-road operation is dangerous. Any terrain, which has not

been specially prepared to carry vehicles, presents an inherent danger where

terrain substance, shape and steepness are unpredictable. The terrain itself

presents a continual element of danger, which must be knowingly accepted by

anyone venturing over it.

An operator who takes a vehicle off-road should always exercise the utmost care

in selecting the safest path and keeping close watch on the terrain ahead of him.

The vehicle should never be operated by anyone who is not completely familiar

with the driving instructions applicable to the vehicle, nor should it be operated

on steep or treacherous terrain.

The traction of the tires will vary depending on the surface conditions and the

tread pattern.

The traction may be reduced on many surfaces (rock, sand, mud, snow, ice,

etc.). Reduce your speed and allow more space to turn.

WARNING

Never stand behind or near a rotatiing tiire. Debriis could be projected

causiing severe iinjuries.

Steering

The front wheels are steered by the steering wheel.

Steering behavior will vary depending of the grip of the tires on the ground.

The Dynamic Power Steering (DPS) to reduce the effort to turn the steering

wheel.

Riding with passenger (s) or when carrying loads will affect the steering control

and vehicle handling. Pay attention and reduce the speed.

SAFETY INFORMATION

GET FAMILIAR WITH THE VEHICLE

Braking

Braking performances may vary suddenly under certain conditions.

Always remember that the vehicle braking distance may be affected when riding

with passenger(s) and when loaded with cargo at the rear.

Never jam the brakes. Be sure to use restraint in braking to keep from blocking

the wheels in order to avoid surprises that could lead to a loss of control.

Programmable D.E.S.S. Key

The D.E.S.S. key can be programmed to limit the speed of the vehicle and the

engine torque.

Enabling first time users and less experienced operators to learn how to operate

while gaining the necessary confidence and control.

Vehicle Blind Spots

A blind spot is an area outside the driver's field of vision that cannot be seen in

the rear-view mirror or, through the front and side openings.

In general, the taller and longer the vehicle is, the bigger the blind spots are.

For this reason, it is important to familiarize yourself with the blind spots of the ve-

hicle created by its design, especially if it is a new vehicle.

The blind spots are all around the vehicles. The blind spots are located in front,

at the rear and on the sides of the vehicle.

Be mindful about persons around the vehicle, other vehicles or nearby objects

when operating the vehicle in reverse.

Pay attention to the vehicle blind spots when climbing or backing off from the

platform, trailer or flat bed.

IMPORTANT: Even if a vehicle is equipped with mirrors (interior or exterior)

or cameras (front or rear), there will always be remaining blind spots all around

the vehicle.

Driver’s Visibility Areas

The following images illustrate the approximate driver’s visibility areas when he

is well seated and his seat belt properly fasten.

SAFETY INFORMATION

GET FAMILIAR WITH THE VEHICLE

1. Approximate driver's field of vision

2. Approximate rear-view mirror field of vision

Carrying Loads

WARNING

Faiilure to folllow these recommendations when carrying loads could llead

to a loss of control and possibly iin a tiip over.

WARNING

Never carry gasolline container(s) or any dangerous lliquids on the cargo

rack.

Any load carried on the vehicle will affect the handling, stability and braking dis-

tance of the vehicle. Appropriate loading and weight distribution are therefore

important.

Do not exceed the load limits of the vehicle, including the weight of operator, pas-

senger, cargo and accessories.

Always be aware that the cargo may slide or fall off and cause an accident.

When carrying loads it is very important to follow the recommendations:

- Never exceed the maximum cargo capacity. Refer to Important On-Product

Labels or Technical Specifications for the applicable cargo load capacity of

the vehicle.

- When carrying heavy loads on the cargo rack operate the vehicle in low

range.

- When carrying a passenger or heavy loads readjust suspension accordingly

- Always reduce your speed, turn gradually and allow longer braking distance

when carrying loads.

SAFETY INFORMATION

GET FAMILIAR WITH THE VEHICLE

Load cargo as low as possible - a higher load can raise the vehicle’s center of

gravity, which can reduce stability. Position cargo on the rack as evenly distrib-

uted as possible.

Secure the load on the cargo rack. Do not secure cargo to the cage or other part

of the vehicle. If it is not properly secured, a load may slide or fall off, possibly

striking occupants or bystanders; or it may shift during riding, affecting the han-

dling of the vehicle.

Objects that are high may affect visibility for the driver and may act as projectiles

in case of an accident. Loads that protrude sideways can get snagged or caught

in bush, branches or other obstacles.

Avoid covering and obstructing the brake lights with the cargo.

Ensure cargo stays far away from the exhaust outlet.

Ensure no cargo protrudes outside the cargo rack and that cargo will not interfere

with your visibility or control of the vehicle.

Hauling a Load

Never pull a load by attaching it to the cage or any other accessories; this can

cause the vehicle to tip over.

Use only the winch (if installed) to pull the vehicle or a load.

In an emergency situation, use the recovery hook to recover a stuck vehicle.

NOTICE

Never use the front recovery hook or the rear recovery point to pulll a lload.

These poiints must be used to pulll a stuck vehiicle.

When pulling loads with a chain or cable, ensure that there is no slack before

starting and maintain tension while pulling. Brake progressively, the inertia of the

load could lead to an impact.

WARNING

A slack iin the chaiin or cable can cause iit to break and snap back.

When pulling another vehicle, be sure that someone is controlling the pulled ve-

hicle. They must brake and steer to prevent the vehicle from going out of control.

Before pulling loads with a winch, refer to the winch manufacturer’s instructions.

Reduce your speed when hauling a load and turn gradually. Avoid hills and rough

terrain. Never attempt steep hills. Allow more distance for braking, especially on

inclined surfaces and when a passenger is on board. Be careful not to skid or

slide.

SAFETY INFORMATION

GET FAMILIAR WITH THE VEHICLE

Accessories and Modifications

Any modifications or addition of accessories approved by BRP may affect the

handling of your vehicle. It is important to take the time to get familiar with the ve-

hicle once modifications are made to understand how to adapt your driving be-

havior accordingly.

Avoid installing equipment not specifically approved by BRP for the vehicle and

avoid unauthorized modifications. These modifications and equipment have not

been tested by BRP and may create hazards. For example, they could:

- Create a loss of control and increase risk of crash

- Cause overheating or short circuits increasing the risk of fire or burn injuries

- Affect the protection features provided by the vehicle

- Affect the behavior of the trailer when the vehicle is transported

- Cause a risk of losing objects on the road when transported.

Your vehicle may also become illegal to ride.

Ask your authorized BRP dealer for suitable available accessories for your

vehicle.

SAFETY INFORMATION

RIDE SAFELY

This vehicle handles differently from other vehicles. A collision or rollover can oc-

cur quickly, during abrupt maneuvers such as doing sharp turns, acceleration or

deceleration and driving on hills or over obstacles, if you fail to take proper

precautions.

Never operate at excessive speeds. Always go at a speed that is proper for the

terrain, visibility, and operating conditions, and your experience.

Never attempt jumps, side slides, donuts or any other stunts.

Never attempt rapid acceleration or deceleration when performing a sharp turn.

This may result in a roll over.

Never attempt skidding or sliding. If vehicle starts to skid or slide, counter steer in

the direction of skidding or sliding. On extremely slippery surfaces, such as ice,

go slowly and be very cautious in order to reduce the chance of skidding out of

control.

Always be sure there are no obstacles or people behind the vehicle when you op-

erate in reverse. Pay attention to blind spots. When it is safe to proceed in re-

verse, go slowly.

Never exceed the stated load limits for this vehicle.

Always remember that this vehicle is heavy! Its pure weight alone may entrap

you should it tip or rollover.

General Driving Tips

Care, caution, experience and driving skill are the best precautions against the

hazards of vehicle operation.

Whenever there is the slightest doubt that the vehicle can safely negotiate an ob-

stacle or a particular piece of terrain, always choose an alternate route.

In off-road operation, power and traction, not speed, are important. Never drive

faster than visibility and your own ability to select a safe route permit. Always go

slowly and be extra careful when operating on unfamiliar terrain. Always be alert

to changing terrain conditions when operating this vehicle. Be especially cautious

on excessively rough, slippery, icy or loose terrain.

Constantly watch the terrain ahead for sudden changes in slopes or obstacles,

such as rocks or stumps, that may cause loss of stability, resulting in tip over or

rollover.

Never operate the vehicle if the controls do not function normally. See an author-

ized Can-Am Off-road dealer.

To maintain proper control it is strongly advised that you keep your hands on the

steering wheel and within easy reach of all controls. The same holds true for your

feet. To minimize the possibility of any leg or foot injury, keep your left foot on the

footrest and right foot on the floor at all times. Staying completely within the cock-

pit will also help keep you from striking objects outside the vehicle.

Watch for and avoid branches and other objects that could enter the passenger

compartment and strike you or your passengers.

SAFETY INFORMATION

RIDE SAFELY

Riding in a Group

Before starting out, designate a “trail boss” to lead the group and another person

to follow-up at the end of the group. Ensure that all members of the group are

aware of the proposed route and destination.

When riding with others, limit your abilities to the experience of others.

Never overtake the trail boss or, for that matter, any other vehicles.

It’s important to keep a safe distance between each vehicle but each one behind

the leader should know the position of the machine ahead.

Operating in Reverse

WARNING

Steering inputs iin reverse operatiion increase the risk of rolllover.

WARNING

When driviing downhiilll in reverse, gravity can iincrease the vehiclle speed

above safe reverse speed.

Always make sure that the rear immediate surrounding of the vehicle is clear to

ensure no one is behind before backing up slowly. Reducing the volume of the

radio or music is also recommended before backing up. Pay attention to blind

spots.

When it is safe to proceed in reverse, go slowly and avoid sharp turns.

In reverse operation, the engine RPM is limited thus limiting the vehicle reverse

speed.

When using the override button in reverse, in case it is needed to get unstuck,

the speed and the torque limitation are increased.

Crossing Roads

If you have to cross a road, ensure to have complete visibility on both sides for in-

coming traffic and decide on exit point on other side of road. Drive in a straight

line toward that point. Do not make sharp direction changes or abrupt accelera-

tions as it may result in a rollover situation. Do not travel on sidewalks or bicycle

trails as they are designated specifically for those uses.

Riding on Paved Surfaces

Avoid paved surfaces. This vehicle is more likely to roll over on pavement be-

cause of the increase tire grip.

If you must drive on pavement, turn gradually, go slowly, and avoid abrupt accel-

eration and braking.

SAFETY INFORMATION

RIDE SAFELY

Shallow Water Crossing

Water can be a unique hazard. If it is too deep the vehicle may “float” and topple.

Check the water depth and current before you attempt to cross any water. Water

depth should not exceed the center of the wheel for vehicle to safely cross the

obstacle. Beware of slippery surfaces such as rocks, grass, logs, etc., both in the

water and on its banks. A loss of traction may occur. Do not attempt to enter the

water at high speed.

Water will affect the braking ability of your vehicle. Make sure you dry the brakes

by applying them several times after the vehicle leaves the water.

Mud or marsh lands may be encountered near water. Be prepared for sudden

“holes” or changes in depth. Similarly so, be watchful of hazards such as rocks,

logs, etc., partially covered by vegetation.

Riding on Snow or Ice

When performing pre-ride inspection, pay special attention to locations on the ve-

hicle where snow and/or ice accumulations may obstruct visibility of the tail lamp,

clog ventilation openings, block the radiator, fan, engine air intake, and interfere

with the movement of controls.

Before starting with your vehicle, check the steering, accelerator and brake pedal

for interference free operation.

Whenever this vehicle is ridden on a snow covered drive path, the tire grip is gen-

erally reduced causing the vehicle to react differently to control inputs from the

operator. On low grip surfaces, the steering responses is not as crisp and pre-

cise, stopping distances are lengthened and acceleration is also affected. Slow

down and be gentle with accelerator input. Too much accelerator input will only

result in spinning of the tires and possibly in an over steering slide of the vehicle.

Avoid hard braking. This will possibly result in a straight line slide of the vehicle

caused by locked wheels. Again, the best advice is to safely reduce speed in an-

ticipation of maneuvers to give yourself time and distance in order to keep control

of the vehicle.

As you drive your vehicle over a loose snow covered surface, snow dust will be

picked up in the wake turbulence of the moving vehicle and transported to con-

tact and accumulate or melt on some exposed components including rotating

parts like brake discs. Water, snow or ice may affect the response time of the

brake system of your vehicle. Even when not required to reduce vehicle speed

apply brakes frequently to prevent ice or snow accumulation and to dry brake

pads and discs. While doing so in low risk driving situations you will test for grip

level and keep yourself alerted to how the vehicle reacts to your control inputs.

Always keep brake and accelerator pedals and floor boards free of snow and ice.

Frequently wipe snow off seat, steering wheel, headlights and tail lamps.

The depth of the snow cover may hide rocks, tree stumps or other objects and if

it is wet may totally impede the drivability as the vehicle becomes bogged down

or completely looses traction in slushy snow. Look far ahead and always be

watchful of any visible clues that might indicate the presence of such obstacles.

In doubt steer clear. Avoid driving on any frozen waterways before checking that

the ice will safely support the vehicle, its riders and its load of cargo.

SAFETY INFORMATION

RIDE SAFELY

At the end of each ride it is a good practice to clean the vehicle and all moving

components (brakes, steering components, drivelines, controls, radiator fan etc.)

from any snow or ice accumulations. Wet snow will turn to ice during the shut

down period and become more difficult to remove at the next pre-ride inspection.

Riding on Sand

Sand and riding on sand dunes is another unique experience but there are some

basic precautions that should be observed. Wet, deep or fine sand may create a

loss of traction and cause the vehicle to slide, drop off or become “bogged” down.

If this occurs look for a firmer base. Again, the best advice is to slow down and

be watchful of the conditions.

When riding in sand dunes it is advisable to equip the vehicle with an antenna

type safety flag. This will help make your location more visible to others over the

next sand dune. Proceed carefully should you see another safety flag ahead.

Riding on Gravel, Loose Stones or Other Slippery Surfaces

Riding on loose stones or gravel is very similar to riding on ice. They will affect

the steering of vehicle, possibly causing it to slide and tip over especially at high

speeds.

In addition, braking distance may be affected.

Remember that rapid accelerations or sliding may cause loose stones to be

ejected rearwards into the path of another rider's way. Never do it deliberately.

During a slide or a skid, counter steer may help to regain the control. Never jam

the brakes and lock the wheels.

Crossing Obstacles

It is a good practice to use the low range (L) when crossing obstacles.

Obstacles on the “trail” should be traversed with caution. This includes rocks, fall-

en trees, and depressions. You should avoid them whenever possible. Remem-

ber that some obstacles are too large or dangerous to cross and should be

avoided. As a guideline, never attempt to cross an obstacle higher than the

ground clearance of the vehicle. Small rocks or small fallen trees may be safely

crossed - approach obstacle at low speed and as much as possible at a right an-

gle. Adjust speed without losing momentum and do not accelerate abruptly. Pas-

senger must grasp both handholds firmly and brace feet on the floor. Hold

steering firmly without closing your fists around it and proceed. Be aware that the

obstacle may be slippery or may move while crossing.

Hill Driving Conditions

When driving on hills or slopes, two things are highly important: be prepared for

slippery surfaces or terrain variations and obstacles and brace yourself properly

inside vehicle.

If you climb or descend a hill that is too slippery or has too loose a surface, you

can lose control.

SAFETY INFORMATION

RIDE SAFELY

If you go over the top of a hill at high speed, you may not have time to prepare for

the terrain on the other side.

Avoid parking on a slope.

Always put the vehicle in PARK when stopped or parked, especially on an in-

cline, to avoid rolling. If you must park on a steep incline, block the wheels using

rocks or bricks.

Uphiilll Driving

It is a good practice to use the low range (L) for uphill driving.

Due to its configuration, this vehicle has very good traction even while climbing,

so much so that tip over is possible before traction is lost. For example, it is com-

mon to encounter terrain situations where the top of the hill has eroded to a point

that the hill peak rises very sharply. This vehicle is not designed to negotiate such

a condition. Take an alternate route.

It is also wise to know the terrain condition on the other side of the hill or bank. All

too often there exists a sharp drop-off that is impossible to negotiate or descend.

If you feel that the slope is getting too steep to climb, apply brakes to immobilize

vehicle. Put the transmission in reverse (R), and back down the hill, barely re-

leasing brakes to remain at low speed. Do not attempt to turn around. Never

coast down hill while vehicle is in neutral. Do not perform hard braking as it in-

creases the risk of tipover.

Downhilll Driiviing

This vehicle can climb steeper slopes than it can descend safely. Therefore, it is

essential to assure that a safe route exists to descend a slope before you climb

it.

Decelerating while negotiating a slippery downhill slope could lock the wheels

causing the vehicle to slide. Maintain steady speed and/or accelerate slightly to

regain control. Never slam brakes and lock the wheels.

Side Hiillling

Whenever possible, side hilling (driving across a slope rather than up or down it)

should be avoided. If necessary, do so with extreme caution. Side hilling on steep

inclines could result in rollover. In addition, slippery or unfirm surfaces could re-

sult in uncontrollable side sliding. Avoid all objects or depressions that will inten-

sify the raising of one side of the vehicle higher than the other, thus causing

rollover. If you feel the vehicle start to rollover or slide sideways, steer downhill if

possible.

WARNING

Be carefull when lloadiing and transporting lliquid reservoirs. They can af-

fect vehicle stabiiliity when side hillliing by pullling downhilll and increasing

the risk of a rolllover.

SAFETY INFORMATION

RIDE SAFELY

Drop-Offs

This vehicle is not designed to negotiate excessive drop-offs.

It will “bottom-out” and usually stop if either the front or rear wheels are driven

over a drop-off.

If the drop is sharp or deep, the vehicle will nose dive and tip over.

Avoid negotiating excessive drop-offs.

Reverse and select an alternate route.

Recreatiionall, Group and Distance Riiding

Respect the rights and limitations of others. Stay away from areas designated for

other types of off road use. This includes snowmobile trails, equestrian trails,

cross country ski trails, mountain bike trails, etc. Never assume there are no oth-

er users on the trail. Always stay to the right of the trail and do not zig zag to one

side of the trail then the other. Be prepared to stop or pull off to the side if another

trail user appears in front of you.

Join a local side-by-side vehicle club. It will provide you with a map and advice or

inform you where you can ride. If a club does not exist in your area, help to start

one. Group riding and club activities provide a pleasurable, social experience.

Never use with drugs or alcohol, or tired or ill.

Always keep a safe distance from other riders. Your judgment of speed, terrain

conditions, weather, mechanical condition of your vehicle and the “trust in judg-

ment” you have in others around you will help you make a better choice of appro-

priate safe distance. This vehicle, like any other motorized vehicle, cannot stop

“on a dime”.

Before you ride, tell someone where you are planning to travel and your expected

time of return.

Depending on the length of your ride, carry additional tools or emergency equip-

ment. Find out where you can get additional gasoline. Be prepared for the possi-

ble conditions you may encounter. An emergency first aid kit should always be a

consideration.

Environment

One of the benefits of this vehicle is that it can take you off the beaten path away

from most communities. However, you should always respect nature and the

rights of others to enjoy it. Do not ride in environmentally sensitive areas. Do not

drive over forest crops or shrubs, nor cut down trees or take down fencing, nor

spin your wheels and destroy the terrain. “Tread Lightly”.

This vehicle can cause OHV wildfires if debris builds up near the exhaust or other

engine hot spots and ignites then falls off into dry grass. Avoid riding in wet

areas, through muskeg or tall grass, where debris can build up. Should you ride

in those areas, inspect and remove all debris from your engine and hot spots. Re-

fer to Vehicle Care for details.

SAFETY INFORMATION

RIDE SAFELY

Chasing wildlife is in many areas illegal. Wildlife can die of exhaustion after being

chased by a motorized vehicle. If you encounter animals on the trail, stop and ob-

serve quietly and with caution. It will be one of the better memories of your life.

Observe the rule “what you take in, carry out”. Do not litter. Do not start campfires

unless you have permission to do so, and then only away from dry areas. The

hazards you may create on the trail may cause injury to others or yourself, even

at a later date.

Respect farm lands. Always obtain the permission of the landowner before riding

on private land. Respect crops, farm animals and property lines.

Finally, do not pollute streams, lakes or rivers and do not modify the engine or ex-

haust system, or remove any of its components as it will alter the vehicle

emissions.

Avoid Collisions

This vehicle can reach high speeds. At higher speeds, there is an increased risk

of losing control, particularly in challenging off-road conditions, and the risk of in-

jury in a collision is greater. Never operate at excessive speeds. Always go at a

speed that is proper for the terrain, visibility, and operating conditions, and your

experience. Consider reserving use of the performance key for situations in

which full speed and acceleration capability are appropriate.

Driving on public street, road or highway, even dirt or gravel ones poses risks

such as collisions and may be illegal in your jurisdiction. Only proceed with cau-

tion on roads and road segments where the usage of your vehicle is permitted.

This vehicle is not designed for operation on roads. For example, it does not

meet motor vehicle safety standards that apply to automobiles. In many jurisdic-

tions it is not legal to operate this vehicle on public roads.

This vehicle does not have the same kind of protection for collisions as a car; for

example, there are no air bags, the cockpit is not fully enclosed, and it is not de-

signed for collisions with other vehicles. Therefore, it is particularly important to

fasten seat belts and close doors and wear an approved helmet.

Avoid Rollovers and Tipovers

Side-by-side vehicles handle differently from other vehicles. Side-by-side ve-

hicles are designed to handle off-road terrain (for example, their wheel base and

track width, ground clearance, suspension, drivetrain, tires, etc.), and, as a result,

can overturn in situations where vehicles designed for use primarily on paved or

smooth terrain may not.

A rollover or other accident can occur quickly during abrupt maneuvers such as

sharp turns or hard acceleration or deceleration when turning, or when driving on

hills or over obstacles. Abrupt maneuvers or aggressive driving can cause roll-

overs or loss of control even in flat open areas. If the vehicle rolls over, any part

of your body (such as arms, legs, or head) outside of the cockpit can be crushed

and trapped by the cage or other parts of the vehicle. You can also be injured by

impact with the ground, cockpit or other objects.

To reduce the risk of rollovers:

- Use care when turning.

SAFETY INFORMATION

RIDE SAFELY

- Do not turn the steering wheel too far or too fast for your speed and envi-

ronment. Adjust steering inputs according to your speed and environment.

- Slow down before entering a turn. Avoid hard braking during a turn.

- Avoid sudden or hard acceleration when turning, even from a stop or low

speed.

- Never attempt donuts, skids, slides, fishtails, jumps, or other stunts. If vehicle

starts to skid or slide, counter steer may help to regain the control. Never jam

the brakes and lock the wheels.

- Avoid paved surfaces. This vehicle is not designed to operate on paved surfa-

ces and is more likely to roll over. If you must drive on pavement, turn gradu-

ally, go slowly, and avoid abrupt acceleration and braking.

This vehicle can roll over sideways or tip over forward or backwards on slopes or

uneven terrain.

- Avoid side hilling (driving along the slope rather than up or down a hill). When

possible, drive straight up and down inclines rather than across them. If you

must side hill, use extreme caution and avoid slippery surfaces, objects, or

depressions. If you feel the vehicle start to rollover or slide sideways, steer

downhill if possible.

- Avoid steep hills and follow procedures in this guide for climbing and de-

scending hills.

- Sudden changes in terrain such as holes, depressions, banks, softer or hard-

er ground or other irregularities may cause the vehicle to tip or become unsta-

ble. Observe the terrain ahead and slow down in areas of uneven terrain.

This vehicle will handle differently when carrying or pulling a load.

- Reduce speed and follow instructions in this manual for carrying cargo.

- Avoid hills and rough terrain.

- Allow more distance to stop.

Be Prepared iin Case of Rolllover

- Close both doors and fasten seat belt to help you avoid sticking out arms or

legs.

- Never grab the cage while riding. Hands can be crushed between the cage

and the ground in a rollover. Keep hands on the steering wheel or handholds.

- Never try to stop a rollover using your arms or legs. If you think that the ve-

hicle may tip or roll, the driver should keep both hands on the steering wheel

and the left foot firmly planted on the footrest. The passenger should keep

both hands on the handholds and both feet firmly planted on the floor.

Terrain Condition

- Driving on public roads poses risks such as collisions and may be illegal in

your jurisdiction. Only proceed with caution on roads and road segments

where the usage of your vehicle is permitted.

- Avoid paved surfaces. This vehicle is more likely to roll over on pavement be-

cause of the increase tire grip. If you must shortly use the vehicle on such sur-

faces, avoid abrupt inputs to steering wheel, accelerator and brake pedal.

- Always go slowly and be extra careful when operating on unfamiliar terrain.

Always be alert to changing terrain conditions when operating this vehicle.

Take the time to learn how the vehicle performs in different environments.

SAFETY INFORMATION

RIDE SAFELY

Never operate on excessively rough, slippery or loose terrain until you have

learned and practiced the skills necessary to control this vehicle on such ter-

rain. Always be especially cautious on these kinds of terrain.

Never operate this vehicle on hills too steep for the vehicle or your abilities.

Practice on small inclines.

Always follow proper procedures for climbing or going down hills as described

in Riding Your Vehicle. Check the terrain carefully before you start up or down

any hill. Never climb or descend hills with excessively slippery or loose surfa-

ces. Never go over the top of any hill at high speed.

Always check for obstacles before operating in a new area. Always follow

proper procedures when operating over obstacles as described in Riding

Your Vehicle.

Never operate this vehicle in fast flowing water or in water deeper than speci-

fied in Riding Your Vehicle. Remember that wet brakes may have reduced

stopping ability. Test your brakes after leaving water. If necessary, apply them

several times to let friction dry out the brakes.

Always ensure to properly park the vehicle on the flattest terrain section avail-

able. Put vehicle in PARK, stop engine and remove key before leaving the

vehicle.

Never assume that the vehicle will go everywhere safely. Sudden changes in

terrain caused by holes, depressions, banks, softer or harder “ground” or oth-

er irregularities may cause the vehicle to topple or become unstable. To avoid

this, slow down and always observe the terrain ahead. If the vehicle does be-

gin to topple or rollover, the best advice is to immediately steer in the direction

of the rollover! Never attempt to prevent a rollover with your arms or legs. You

should keep your limbs inside the cage.

Avoid Carbon Monoxide Poisoning

All engine exhaust contains carbon monoxide, a deadly gas. Breathing carbon

monoxide can cause headaches, dizziness, drowsiness, nausea, confusion and

eventually death.

Carbon monoxide is a colorless, odorless, tasteless gas that may be present

even if you do not see or smell any engine exhaust. Deadly levels of carbon mon-

oxide can collect rapidly, and you can quickly be overcome and unable to save

yourself. Also, deadly levels of carbon monoxide can linger for hours or days in

enclosed or poorly ventilated areas. If you experience any symptoms of carbon

monoxide poisoning, leave the area immediately, get fresh air and seek medical

treatment.

To prevent serious injury or death from carbon monoxide:

- Never run the vehicle in poorly ventilated or partially enclosed areas such as

garages, carports or barns. Even if you try to ventilate engine exhaust with

fans or open windows and doors, carbon monoxide can rapidly reach danger-

ous levels.

- Never run the vehicle outdoors where engine exhaust can be drawn into a

building through openings such as windows and doors.

SAFETY INFORMATION

RIDE SAFELY

Avoid Gasoline Fires and Other Hazards

Gasoline is extremely flammable and highly explosive. Fuel vapors can spread

and be ignited by a spark or flame many feet away from the engine. To reduce

the risk of fire or explosion, follow these instructions:

- Use only an approved gasoline container to store fuel.

- Never fill the gasoline container on the vehicle - an electrical static discharge

may ignite the fuel.

- Never carry gasoline container(s) or any dangerous liquids on the cargo rack.

- Strictly adhere to instructions in Vehicle Fueling Procedure.

- Never start or operate the engine if the fuel cap is not properly installed.

Gasoline is poisonous and can cause injury or death.

- Never siphon gasoline by mouth.

- If you swallow gasoline, get any in your eye(s), or inhale gasoline vapor, see

a doctor immediately.

If gasoline spills on you, wash with soap and water and change your clothes.

Avoid Burns from Hot Parts

Certain components like brake rotors and exhaust components become hot dur-

ing operation. Avoid contact with those parts during and shortly after operation to

avoid burn wounds.

SAFETY INFORMATION

PRACTICE EXERCISES

Before you go out for a ride, it is very important to familiarize yourself with the

handling of your vehicle by practicing in a controlled environment. If possible, it is

also a very good idea to take a more formal training course to sharpen your skills

and increase your knowledge of the vehicle.

Find a suitable area to practice and perform the following exercises. It should be

at least 45 m (150 ft) by 45 m (150 ft) free of obstacles like trees and rocks. Once

you’ve selected a suitable permitted location, proceed with the following

exercises.

Turning Exercises

Turning is one of the most frequent causes of accidents. It is easier for the ve-

hicle to lose traction or rollover if you turn too sharply, or go too fast. Slow down

when you approach a turn.

- First learn how to perform slight right turns at very low speeds. Release the

throttle before turning and slowly reapply the throttle when turning.

- Repeat turning exercise but this time maintain the throttle at the level while

turning.

- Finally, repeat turning exercise while accelerating slowly.

- Practice exercises turning on the other side.

Note how your vehicle reacts in these different exercises. We recommend releas-

ing the throttle before entering a turn to help initiate directional change. You will

feel the lateral force increasing with the speed and with your steering input. The

lateral force should be maintained as low as possible to make sure it does not

cause the vehicle to roll over.

U Turn Exercises

Practice doing U turns.

- Accelerate slowly and while remaining at low speed, then gradually turn the

steering wheel to the right until you have completed the U turn.

- Repeat U turn exercise with different steering inputs and always at a very low

speed.

- Repeat U turn exercise on the other side.

As mentioned before in this guide, avoid paved surfaces. This vehicle is more

likely to roll over on pavement because of the increase tire grip. If you must

shortly use the vehicle on such surfaces, avoid abrupt inputs to steering wheel,

accelerator and brake pedal.

Braking Exercises

Practice braking to get familiar with the brake response.

- Do it at low speed first, then increase the speed.

- Practice braking in straight line at different speeds and different braking force.

- Practice emergency braking; optimal braking is obtained in straight line, with

high force applied, without locking the wheels.

Remember, braking distance depends on vehicle speed, load and the type of

surface. Also, the tires and brakes conditions play a major role.

SAFETY INFORMATION

PRACTICE EXERCISES

Reverse Exercises

The next step involves using the reverse.

- Install 1 cone marker on both sides of the vehicle beside each rear wheel.

Move the vehicle forward until you can see the cone markers, then stop the

vehicle. Acknowledge the distance required to see obstacles behind you.

- Learn how the vehicle handles itself in reverse and reacts with steering

inputs.

- Always perform this reverse exercise at slow speeds.

- Become familiar with the usage of the override function. Do not steer while

using the override as it increases the risks of rollover.

Emergency Engine Stopping Exercise

Learn how to stop your engine quickly in an emergency situation.

- While running at low speed, simply remove the RF D.E.S.S. key from the D.E.

S.S. post.

- The vehicle transmission will automatically put in NEUTRAL.

- Stop the vehicle and put the transmission on PARK

This is to familiarize you with the vehicle’s reaction when the engine is turned off

while driving and to develop this reflex.

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (CANADA/

UNITED STATES)

Hang Tag

Any person who rides this vehicle

should read and understand this infor-

This vehicle comes with a hang tag

mation before riding.

and labels containing important safety

information.

THIS VEHICLE IS INTENDED FOR RECREATIONAL USE

AND SECONDARY GENERAL UTILITY APPLICATIONS

Tilt Table

NO OPERATOR UNDER AGE 16

TRAINING COURSES TO TEACH ROV DRIVING

Test Result

ARE AVAILABLE. FOR INFORMATION CONTACT

YOUR DEALER.

Read the Operator's Guide and Safety Labels

and Watch the Safety Video.

Follow All Instructions and Warnings.

BOMBARDIER RECREATIONAL PRODUCTS INC.

VEHICLE MODEL

CHECK WITH YOUR DEALER TO FIND OUT ABOUT

TILT TABLE RESULT

STATE OR LOCAL LAWS REGARDING ROV OPERATION.

Improper Use of O -Highway Vehicles Can

Cause Severe Injury or Death

Be Prepared

Measurement of lateral stability, in degrees, of a

• Fasten seat belts and make sure nets or doors

sample, standard condition vehicle (with an

are securely latched in place.

operator and a passenger load - 430 pounds) as

•Wear an approved helmet and protective gear.

measured by the manufacturer in accordance with

•Each rider must be able to sit with back against seat, foot at on the

the tilt table lateral stability test in the ANSI/ROHVA

oor or on footrest, and hands on steering wheel or handholds. Stay

standard for Recreational Off-Highway Vehicles.

completely inside the vehicle.

Vehicle modification, accessories, and loading can

Drive Responsibly

affect lateral stability.

Avoid loss of control and rollovers:

•Avoid abrupt maneuvers, sideways sliding, skidding or shtailing, and

Training courses to teach ROV driving are available.

never do donuts.

For information contact your dealer and/or

•Avoid hard acceleration when turning, even from a stop.

rohva.org.

•Slow down before entering a turn.

•Plan for hills, rough terrain, ruts, and other changes in traction and

terrain. Avoid paved surfaces.

Check with your dealer to find out about state or

•Avoid side hilling (riding across slopes).

local laws regarding ROV operation.

Rollovers have caused severe injuries and death,

even on at, open areas.

THIS HANG TAG IS NOT TO BE REMOVED BEFORE SALE.

Be Sure Riders Pay Attention and Plan Ahead

If you think or feel the vehicle may tip or roll,

reduce your risk of injury :

•Keep a rm grip on the steering wheel or handholds

VEHICLE MODEL NAME:

and brace yourself.

•Do not put any part of your body outside of the

ENGINE DESCRIPTION:

vehicle for any reason.

Require Proper Use of Your Vehicle

EPA CERTIFIED

- Do your part to prevent injuries:

•Do not allow careless or reckless driving.

NER (NORMALIZED EMISSION RATE) =

ON 0 TO 10 SCALE, 0 BEING THE CLEANEST.

•Make sure operators are 16 or older with a valid driver's license.

BOMBARDIER RECREATIONAL PRODUCTS INC

•Do not let people drive or ride after using alcohol or drugs.

*NO TO BE REMOVED PRIOR SALE.

•Do not allow operation on public roads (unless designated for

o -highway vehicle access) - collisions with cars and trucks can occur.

•Do not exceed seating capacity: see information on back side of this

card

Vehicle seating capacity:

Occupants

THIS HANG TAG CAN’T BE REMOVED BEFORE SALE.

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (CANADA/UNITED STATES)

Safety Compliance Hang Tag

This vehicle comes with hang tags

containing

important

safety

information.

Any person who rides this vehicle

should read and understand this infor-

mation before riding.

California Proposition

Warning Hang Tag

. Operating, servicing and

WARNING

maintaining an off-road vehicle can expose

you to chemicals including engine exhaust,

carbon monoxide, phthalates, and lead,

which are known to the State of California

to cause cancer and birth defects or other

reproductive harm.

To minimize exposure, avoid breathing

exhaust, do not idle the engine except as

necessary, service your vehicle in a

well-ventilated area and wear gloves or wash

your hands frequently when servicing your

vehicle.

For more information go to

www.P65Warnings.ca.gov/products/

passenger-vehicle

704906872

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/UNITED STATES)

Operator – Warning Label

WARNING

–

Locate and read operator''s guide. Improper vehiclle use can resullt in

SEVERE INJURY or DEATH. Folllow alll instructions and warniings.

–

Fasten seat belts.

–

Allways wear an approved helmet and protective gear.

–

Each rider must be ablle to siit with back agaiinst seat, feet flat on the

floor or on footrests, and hands on steeriing wheell or handholds.

–

Allways fasten seat belts and close doors.

–

Allways wear ear protectiion.

–

Do not exceed seatiing capaciity: 2 occupants.

–

Make sure alll operators are 16 or ollder with a vallid driver’s llicence.

–

In case of tip or rolll, keep a fiirm grip on steering wheell or handhollds

and brace yoursellf.

–

Do not put any part of your body outside of the vehiicle for any reason.

Stay completely inside the vehicle.

–

Rolllovers have caused severe injjuries and death, even on fllat, open

areas.

–

Do not alllow operation on publlic roads (unless designated for off-high-

way vehiicle access), collliision wiith cars and trucks can occur.

–

Never use with drugs or alcoholl.

–

Do not alllow anyone to riide if not able to sit with back against seat, feet

flat on the flloor or on footrests, and hands on the steeriing wheell.

–

Watch the safety viideo before riidiing.

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/UNITED STATES)

Passenger – Warning Label

WARNING

– Allways wear an approved helmet and protective gear.

– Allways wear ear protectiion.

– Fasten seat belts and close doors.

– Rolllovers have caused severe injjuries and death, even on fllat, open

areas.

– Each rider must be ablle to siit with back agaiinst seat, feet flat on the

floor or on footrests, and hands on steeriing wheell or handholds.

– Never use with drugs or alcoholl.

– In case of tip or rolll, keep a fiirm grip on handholds and brace yoursellf.

– Do not put any part of your body outside of the vehiicle for any reason.

Stay completely inside the vehicle.

– Do not alllow anyone to riide if not able to sit with back against seat, feet

flat on the flloor or on footrests, and hands on handholds.

SAFETY INFORMATION

PRE-RIDE INSPECTION CHECK LIST

What to Do Before Starting the Engine (Key OFF)

ITEMS TO

INSPECTION TO PERFORM

INSPECT

Coolant

Check coolant level.

Brake fluid

Check brake fluid level.

Engine air filter

Inspect engine air filter and replace if necessary.

Inspect engine air filter housing and clean if

Engine air filter

necessary (when riding in dusty conditions or

housing

sand).

Radiator(s)

Check front and rear radiators for cleanliness.

Front grille

Inspect front grille kit for cleanliness.

Clean area around exhaust system, especially if

Exhaust system

vehicle was used in a swamp, hay field, or in dry

leaves.

Drive shaft

Check drive shaft bellows condition.

bellows

Check tire pressure and condition.

Tires

Refer to Technical Specifications and adjust

according to load.

Check wheels for damage and abnormal play.

Ensure that lug nuts and beadlock screws (if

Wheels

equipped) are tight.

Refer to Wheels and Tires in Maintenance

Procedures for torque specifications.

Cargo Load: If you transport cargo, respect

maximum rear cargo rack capacity.

Refer to Technical Specifications.

Cargo and load

Ensure that total weight of operator, passenger,

cargo, and added accessories does not exceed

total vehicle load allowed.

Refer to Technical Specifications.

Check under vehicle for any debris on chassis or

Chassis and

suspension components (upper and lower arms,

suspension

wheels, shock absorbers, springs), and clean

them properly.

SAFETY INFORMATION

PRE-RIDE INSPECTION CHECK LIST

What to Do Before Starting the Engine (Key ON)

ITEMS TO

INSPECTION TO PERFORM

INSPECT

Check operation of indicator lamps in digital

display (with D.E.S.S. key ON, briefly press

Digital display

ENGINE START/STOP button).

Check for messages on gauge.

Check operation and cleanliness of the following:

- Headlights (high and low)

Lights

- Taillights

- Brake lights

Check seat adjustment and ensure that locking

device is properly engaged before riding.

Check doors for damage. Have doors replaced if

damaged.

Close both doors and confirm that they latch up to

Seats, doors, and

second latch.

seat belts

Check seat belts for any damage (including

retractors, buckles, and semi-cinching tabs).

Fasten seat belts and ensure that they remain

securely fastened and tightened against

occupant’s body.

Press on accelerator pedal a few times. Pedal

Accelerator pedal

should operate freely and return to its rest position

when released.

Press down on brake pedal and make sure that

Brake pedal

you feel firm resistance. Pedal should return fully

to its rest position when released.

Fuel level

Check fuel level.

What to Do After the Engine is Started

ITEMS TO

INSPECTION TO PERFORM

INSPECT

Check if steering operates freely by completely

Steering

turning wheel from side to side.

Adjust steering wheel to a comfortable position.

Check operation of D.E.S.S. post by pulling

RF D.E.S.S. post

D.E.S.S. key from post. Engine must stop.

SAFETY INFORMATION

REPORTING SAFETY DEFECTS

In Canada, if you believe that your vehicle has a defect which could cause a

crash or could cause injury or death, you should immediately inform Transport

Canada in addition to notifying Bombardier Recreational Products Inc.

If Transport Canada receives similar complaints, it may open an investigation,

and if it finds that a safety defect exists in a group of vehicles, it may order a re-

call and remedy campaign. However, Transport Canada cannot become involved

in any individual problems between you, your dealer or Bombardier Recreational

Products Inc.

To contact Transport Canada:

819-994-3328 (Gatineau-Ottawa area or internationally)

Toll free : 1 800-333-0510 (in Canada)

Transport Canada - ASFAD

330 Sparks Street

Ottawa, ON

K1A 0N5

https://www.tc.gc.ca/recallls

SAFETY INFORMATION

PRIMARY CONTROLS

It is important to know the location and

operation of all controls, and to devel-

op and practice smooth and coordi-

nated use of them.

Some vehicle safety labels are not

shown on illustrations. For information

on vehicle safety labels, refer to Im-

portant On-Product Labels.

STEERING WHEEL

1. Tilt lever

The steering wheel is located in front

2. Left shift paddle

of the driver’s seat.

3. Right shift paddle

SHIFT PADDLES

Shift paddle are located behind the

steering wheel.

Pressing the left paddle allows to

downshift gear instead the right pad-

dle upshift gear.

It is used to steer the vehicle to the left

or right. Turn the steering wheel in the

direction you want to go.

Hold the steering wheel firmly with

both hands, without closing your fists

around it and proceed.

CAUTION

LEFT PADDLE — DOWNSHIFT

Under rough traiil conditions or

when crossiing an obstacle, the

steeriing wheel could suddenly

jerk to one siide, causiing hand or

wriist iinjjuries if your fiists are

wrapped around the steering

wheel.

When driving, the Dynamic Power

Steering (DPS) reduces the effort re-

quired to turn the steering wheel.

RIGHT PADDLE — UPSHIFT

The steering wheel also includes

many controls.

The shift paddles must be used to

change gears when the Manual mode

is selected.

Tip In Mode

PRIMARY CONTROLS

When in automatic mode, pressing

one of the shift paddle will activate the

Tip In mode.

Pressing the right (upshift) or the left

(downshift) paddle will select the next

upper gear or the previous gear.

This gear will be held until either up-

shift or downshift RPM are reached.

To get out of the Tip In mode and go

back to full Automatic mode, just hold

one of the paddle for a few seconds.

The brake pedal function is to slow or

stop the vehicle.

ACCELERATOR PEDAL

To decrease vehicle speed or to stop

The accelerator pedal is the right--

the vehicle, press down on the brake

most pedal.

pedal with your right foot.

The brake pedal is spring loaded and

should return to its original position

(released) when not pressed.

ELECTRONIC SHIFT LEVER

The electronic shift lever is located on

the central console, to the right of the

driver’s seat.

The accelerator pedal controls the ve-

hicle speed and acceleration.

To increase or maintain vehicle

speed, press on the accelerator pedal

with your right foot.

To decrease vehicle speed, release

the accelerator pedal.

The lever is used to put the transmis-

The accelerator pedal is spring loaded

sion into REVERSE or DRIVE

and should return to its resting posi-

(Forward).

tion (idle) when not pressed.

To shift into REVERSE:

BRAKE PEDAL

- Press the brake pedal and push

The brake pedal is located to the left

the lever forward until the digital

and is wider than the accelerator

display shows R.

pedal.

- Release the lever. After you

PRIMARY CONTROLS

release the shift lever, it will return

to the center position.

NOTE:

Once in Reverse, if the lever is

pushed forward again and held for a

few seconds, the transmission will tog-

gle between Low and Hi range. This

can also be done using the L button

below the shift lever.

To shift into DRIVE:

This button puts the transmission in

- Press the brake pedal and pull the

PARK.

lever rearward until the digital dis-

play shows D.

The PARK must be engaged each

- Release the lever.

time the driver leaves the vehicle.

NOTE:

A buzzer will sound any time the driv-

Once in Drive, if the lever is pulled

er’s door is opened without the PARK

rearwards again and held for a few

engaged.

seconds, the transmission will toggle

between Low and Hi range. This can

WARNING

also be done using the L button below

Allways select the Park (P) posi-

the shift lever.

tion when the vehiicle is not in mo-

tion to avoid acciidental vehiicle

When the D position is selected after

movements.

restarting the vehicle, the last setting

used will be reused automatically (au-

tomatic, manual, LOW or HI range).

The vehicle will automatically go to

park when it is immobilized and

the

When the transmission is in gear (R or

engine is shutdown.

D), the vehicle can move slowly, or

creep, without any accelerator pedal

NEUTRAL BUTTON

input. Many factors can influence the

creep behavior: Transmission temper-

The Neutral (N) button is located be-

ature, cargo weight, Range (Low or

hind the electronic shift lever.

High), type of terrain and slope, to

name a few. The user should beware

of a potential creeping at all times

when it is in gear.

WARNING

Always apply the brake when

stopped and select Park (P) be-

fore exiiting the vehiicle to avoid

unattended vehicle movement.

PARK BUTTON

The park button (P) is located behind

the electronic shift lever.

PRIMARY CONTROLS

This button puts the transmission in

straight flat section) at constant

neutral.

speed.

NOTICE

The Low range allows the vehicle to

move slowly with the maximum torque

Thiis position must NEVER be

at the wheels.

used to tow the vehicle. Severe

transmiissiion and gearbox dam-

NOTICE

age wiilll occur.

To avoid vehiicle damages, it is a

To tow the vehiclle, refer to Per-

good practice to select the Low

manent Neutral or Mechaniicall

range each time the vehicle goes

Neutral Actiivation in Speciall Pro-

cedures for the compllete

over obstaclles, drives uphilll or

procedure.

downhiilll, or when carrying heavy

cargo.

Neutral is selected by pressing the “N”

button. The N icon appears in the digi-

To select the Low range, press the “L”

button until the L icon appears in the

tal display when the transmission is in

digital display.

neutral.

This button allows also to switch be-

The vehicle will go back to park posi-

tween Low and Hi range by pressing it

tion when it shutdown.

during more than 2 seconds.

If a permanent neutral or a mechani-

It is also possible to toggle between

cal neutral is needed, refer to Perma-

Low and Hi range using the Electronic

nent Neutral and Mechanical Neutral

Shift Lever.

Activation in Special Procedures

section.

MANUAL MODE BUTTON

LOW RANGE BUTTON

The Manual (M) mode button is lo-

cated behind the electronic shift lever.

The Low (L) range button is located

behind the electronic shift lever.

This button engages or disengages

the Manual shifting mode.

This button allows the low-speed

range of the gearbox to be selected.

The Manual mode allows you to

change gears, using the paddles at

This vehicle can switch between low

the steering wheel, on demand in-

and high while moving. There will be a

stead of waiting for the vehicle to

power interruption during the H to L or

decide.

L to H shift, so make sure to perform

the shift in a safe location

(ex. a

SECONDARY CONTROLS

Some vehicle safety labels are not

WARNING

shown in the illustrations.

Rolllovers, tiipovers, colllisions and

For information on vehicle safety la-

loss of control resullting in serious

bels, refer to Important On-Product

injury or death are possiible with

Labels.

the performance or normal key.

Using the normal key is not a sub-

RF D.E.S.S Key and RF D.E.

stitute for the operator being pre-

S.S. Post

pared, qualiified, and operating

wiith care.

RF D.E.S.S. Post

D.E.S.S. Flexibiiliity

The D. E. S. S. post is located on the

upper console.

The D. E. S. S system of the vehicle

can be programmed to recognize up

to 8 different keys.

In this case, if you are the owner of

many vehicles using a D.E.S.S. key, it

is possible to use any of them with this

vehicle.

Refer to your authorized Can-Am Off--

road dealer to program the other D.E.

S.S. keys.

ENGINE START/STOP

RF D.E.S.S. Key

BUTTON

For all D.E.S.S. related option, see an

The ENGINE START/STOP button is

authorized Can-Am dealer for

located on the upper console, to the

information.

right of the steering wheel.

Diigitallly Encoded Security System

(D.E.S.S.)

This vehicle is delivered with 1 D.E.S.

S. key.

The ignition keys contain an electronic

circuit that gives it a unique electronic

serial number.

The D. E. S. S. system reads the key

code and allows engine starting for

keys it recognizes.

This vehicle can be operated using

different types of key programming:

Refer to your dealer for complete

information.

NOTE:

Additional keys are available from

your dealer as an accessory.

SECONDARY CONTROLS

With the D.E.S.S. key inserted, press

The override switch is used for the

and hold the ENGINE START/STOP

following:

button to start the engine.

- To bypass the engine speed limiter

in reverse by allowing maximum

Press the same button to stop the

engine torque. Refer to Entering

engine,

the Override Mode.

To power up the electrical system

- To allow the vehicle to be driven in

without starting the engine, refer to

the event of an accelerator pedal

Waking Up the Electrical System.

failure. Refer to Entering the Man-

ual Limp Home Mode.

- In the case of a transmission fault,

HEADLIGHT DIMMER

a message into the digital display

SWITCH

will appear ''Press override to con-

The headlight dimmer switch is lo-

firm the standstill''. This will allow

cated on the left-hand side of the

select the Park. Then the electrical

dashboard.

system can be completely shut off

and woke up again. In most cases,

this action will be enough to heal

the fault. If not, see an authorized

Can-Am Off-road dealer.

ENTERING THE OVERRIDE

MODE

While in reverse, press and hold the

Override switch to enter the override

(i.e., bypass) mode.

WARNING

This switch is used to select either the

Use the override mode onlly iif the

low or high beams for the headlights.

vehiiclle is caught in mud or other

Press and hold the lower button to

soft terraiin and the llow range is

turn the headlights off. Press the

not suffiiciient iin reverse. Make

same button again to turn the head-

sure that the area iis secure before

lights back on.

usiing the overriide mode. Do not

use the override mode when driv-

ing normallly iin reverse. Thiis

OVERRIDE SWITCH

woulld result in excessive speed.

The override switch is located behind

the electronic shifter.

SECONDARY CONTROLS

Release the Override switch to exit

Depending on the type of failure,

this mode.

pressing and holding the Override

switch will temporarily restore the re-

Enteriing the Manuall Limp Home

sponse of the pedal OR temporarily

Mode

increase the engine speed to allow

the vehicle to be driven.

If one or both of the pedal position

sensor(s) is (are) defective, the accel-

Releasing the Override switch will re-

erator pedal will not respond.

lease the throttle and allow the engine

return to idle speed.

KEYPAD

The keypad is located on the upper console.

The first click will show the current setting.

To change a setting, click again until the desired mode is reached.

On the base model, the keypad is used to navigate through the various menus

and options in the 7.6" Digital Display.

Icon

Use

Application

- Normal

Switch between different

- Sport

engine modes*

- Sport+

Used to navigate

through the various

—

menus of the digital

display

Used to navigate

through the various

—

options of the digital

display

Switch between different

- Min

power steering

- Med

resistances*

- Max

EQUIPMENT

Some vehicle safety labels are not

shown on illustrations. For information

on vehicle safety labels, refer to Im-

portant On-Product Labels.

TILT STEERING WHEEL

WARNING

Do not adjust the steering wheel

posiition whiile driving. This may

cause loss of control.

If the lever cannot be raised to the

Holding the handholds helps the pas-

fixed positiion, adjust the steering

senger brace against the movement

wheell agaiin. Driving without llock-

of the vehicle and helps keep hands

ing the steering wheel iis danger-

and body inside the cockpit in the

ous and may cause the loss of

event of a rollover.

control.

WARNING

Never use any part of vehiicle

cage as handholds. Hands can be

struck by objjects outside the

cockpiit or crushed in a rolllover.

Adjust the seat position in order to get

a solid and comfortable grip on the

handholds. Refer to Seat Forward and

Rearward Adjustment.

1. Adjust the seat position.

CENTRAL STORAGE

2. Move the adjusting lever down.

COMPARTMENT

3. Move the steering wheel to the de-

This compartment is located in the

sired position.

middle of the console.

4. Hold the steering wheel in this po-

sition and raise the adjusting lever

to lock the mechanism in place.

5. Confirm that the steering wheel is

securely locked by attempting to

move it up and down.

PASSENGER HANDHOLDS

There is one passenger handhold on

the console and one in the right-hand

door.

It is designed to hold small articles,

like a cellphone.

This compartment includes the

following:

- A12-voltpoweroutlet

EQUIPMENT

- A dual USB port to charge your

TROUBLESHOOTING

devices

TOOLS

The vehicle comes with basic trouble-

shooting tools to help you in some

situations.

The tools are located in the glove box.

1. Dual USB port

12- volt power outlet

GLOVE BOX

The vehicle is equipped with a closed

glove box, which is intended to carry

light objects.

The following troubleshooting

tools

are included with the vehicle:

NOTICE

Thiis storage compartment can be-

Shift drum rotation tool

come hot during summer and allso

when usiing the vehiclle at slow

Suspension adjustment

speed for a long periiod of time.

tool

Storiing an electroniic device liike a

2-way

celll phone iis not recommended

screwdriv

under these conditions because

er (flat

hot temperatures can cause per-

and

manent damage to the phone and

Phillips)

iits battery.

Pliers

Socket

wrench,

14/16 mm

Tool kit:

Open-end

wrench,

15/17 mm

Open-end

wrench,

10/13 mm

Gllove Box Capacity

Combina

5 kg

tion

Maximum load

(11 lb)

wrench, 8

EQUIPMENT

T30 Torx

key

Pressure

gauge

CENTRAL REARVIEW

MIRROR

This vehicle comes equipped with a

central rearview mirror.

The footrests help minimize the risk of

Be aware that objects in the mirror are

leg or foot injury.

closer than they appear.

Always wear appropriate riding gear.

The mirror can be adjusted to suit driv-

er's preference.

DOORS

To adjust the mirror, loosen the knob

The vehicle is equipped with doors to

located behind the mirror and tighten

help occupants keep their body and

it to secure the mirror in position.

limbs inside the vehicle, reducing the

risk of injury.

The doors can also prevent the intru-

sion of branches and other foreign ob-

jects into the passenger compartment.

WARNING

Never operate vehiicle unless both

doors are closed and secured.

BEHIND THE MIRROR

To open a door, pull on the strap to re-

1. Knob

lease the latch.

WARNING

Do not adjust miirrors whille ridiing.

You coulld lose controll.

FOOTRESTS

The vehicle is equipped with driver

and passenger footrests. This allows

the occupants’ feet to be firmly plant-

ing on the vehicle floor, which helps to

maintain proper body position while

riding.

SEAT BELTS

This vehicle is equipped with seat

belts to help to protect and keep the

driver and passengers inside the

EQUIPMENT

cockpit in the event of a collision, roll-

3-POINT SEAT BELTS

over, or tip-over.

WARNING

Wear seat belts properly at alll

tiimes. Seat bellts reduce the risk

of iinjjury iin a crash and help keep

limbs iinsiide the cockpiit duriing a

rolllover or accident.

If the driver’s seat belt is not fastened:

- When the ignition is turned ON,

the seat belt indicator lamp will

WARNING

flash.

Wear seat belt properlly. Make

- When the engine is started, the ve-

sure iit remaiins securelly fastened

hicle is released from PARK, and

and tiightened against the body.

the shift lever is moved to the “D”

Make sure it is not twisted or

position, the vehicle speed will be

defectiive.

limited to a maximum of approxi-

mately 20 km/h (12 mph) on flat

ground.

The seat belt is equipped with a semi--

cinching tab.

WARNING

This device locks the seat belt in the

The vehicle may reach higher or

adjusted position.

lower speed dependiing on

iincllines.

To remind you to fasten the seat belts,

the multifunction gauge will display

the following message: ENGINE LIMI-

TATION ENGAGED FASTEN SEAT

BELT.

WARNING

There iis no iindiicator liight or mes-

sage for the passenger seat bellt.

The driiver iis responsiblle for the

TYPICAL - LOCKED POSITION

passenger’s safety and should

1. Semi-cinching tab

ensure that the passenger fastens

their seat bellt.

To fasten the seat belt, insert the latch

plate into the buckle, then pull the belt

to ensure it is properly fastened.

Adjust the seat belt tightly against

your body by pulling the shoulder belt

upwards.

EQUIPMENT

frame by pulling it off towards the

rear.

TYPICAL

To detach the seat belt, push on the

2. To install, reverse the removal

red button on the buckle.

procedure.

REMOVING AND INSTALLING A

SEATS

SEAT

ADJUSTING THE SEAT POSITION

1. Remove the seat cushion.

2. Remove all four anchor points.

The seats can be adjusted forward or

backward.

WARNING

Never adjust the seat posiitiion

whiile the vehiclle is moviing.

1. Slide the adjustment lever to the

right side.

SEAT ANCHOR POINTS

1. Front anchor points

2. Rear anchor points

3. Detach seat belt retractors and at-

tachment points from the frame.

2. Move the seat to the desired posi-

tion, then release the lever.

3. Try to move the seat forward and

backward to make sure it is prop-

erly locked in place.

Removing and Installliing the Seat

Cushion

1. Pull up the rear of the cushion,

then free the cushion from the seat

EQUIPMENT

SEAT BELT RETRACTOR - TYPICAL

1. Seat rail

Retractor

2. Upper position hole

Attachment point

3. Lower position hole

4. Seat support

Discard all elastic stop nuts.

Remove the seat from the vehicle.

7. Installation is the reverse of the re-

Before re-installing the seat, select

moval. However, pay attention to

the desired height adjustment.

the following.

The rear height is determined by

WARNING

the presence or absence of the

sleeve.

Use new nuts when iinstallling seat

anchor poiints.

- Install the sleeve for the maxi-

mum height.

- Remove the sleeve to put the

Tighteniing Torque

seat in its lowest height.

Rear anchor

64.5 ± 6.5 Nm

point

(48 ± 5 lbf-ft)

Front anchor

24.5 ± 3.5 Nm

point

(18 ± 3 lbf-ft)

Seat belt

retractor and

64.5 ± 6.5 Nm

attachment

(48 ± 5 lbf-ft)

points

REAR ANCHOR POINT - TYPICAL

FUEL RESERVOIR CAP

1. Seat belt bolt

The fuel reservoir cap is located at

2. Track

front on the right hand side of the

3. Elastic nut

vehicle.

4. Sleeve

To reach it, open the fuel reservoir

The front height is determined by

cap cover.

the position of the seat rails in their

supports.

EQUIPMENT

1. Fuel reservoir cap cover

Always refer to Vehicle Load Capacity

Label and Cargo Warning Label for

load capacity and cargo information.

ANCHORING HOOKS

To help to secure cargo inside the car-

go box, four anchoring hooks are in-

stalled on the floor of the cargo box.

Also, four LinQ™ attachments are in-

cluded to secure any BRP LinQ ac-

cessories. They can be installed in

many configuration depending on

1. Fuel reservoir cap

which accessory is used.

Refer to Fuel for information on fueling

procedure and fuel requirements.

CARGO RACK

The cargo rack is convenient for carry-

ing equipment and various other

cargo.

WARNING

– Never carry a passenger on a

cargo rack.

CARGO BOX - RIGHT SIDE (TYPICAL)

– Cargo must never iinterfere

1. LinQ attachment

wiith the driiver’’s liine of siight or

2. Anchoring hook

affect theiir abiiliity to properlly

steer the vehiiclle.

RECOVERY POINTS

– Do not overload the vehiiclle.

– Always ensure that alll cargo iis

The vehicle is equipped with a front

properly secured and does not

recovery hook and a rear recovery

extend beyond the rack.

point.

– Never carry gasoliine contaiiner

(s) or any dangerous liiquiids on

the cargo rack.

EQUIPMENT

These recovery points must be only

used to recover a stuck vehicle.

NOTICE

Recovery poiints are designed to

recover a stuck vehiiclle onlly.

They shoulld not be used to carry

a lload or to attach a pullley or oth-

er mechaniicall deviice that can

overload the attachment point.

Doing so can cause damage to

the vehiiclle frame.

CUP HOLDERS IN LOWER CONSOLE

Another one is located on the floor, in

front of the passenger’s seat.

FRONT RECOVERY HOOK

FRONT CUP HOLDER

REAR RECOVERY POINT

CUP HOLDERS

Three cup holders are available for

your convenience.

NOTE:

Do not use cup holders while riding in

rough conditions.

Two cup holders are located at the

rear of the lower console.

7.6" DIGITAL DISPLAY

Multifunction Display

WARNING

Do not adjust the diispllay whille

riidiing, you could llose control.

Lower Display

The right lateral display includes:

- Engine Temperature

- Clock

- Speed indicator

The speed indicator in this display is

activated when the central display

shows information other than the

speed. Otherwise it is blank.

May display the following:

- RPM

Central Display

- Speed statistics

- Engine Temperature

- Battery Voltage

- Settings

- Messages

- Active DPS mode

The SPEED STAT display shows the

maximum and the average speed.

Hold MENU or OK button for 1 second

May display the following:

to reset.

- RPM

Left Lateral Display

- Vehicle speed

Transmission

Position

Display

The left lateral display includes:

- Fuel level indicator

- Tripmeter (A - B)

This display shows gears position of

- Odometer

gearbox:

- Vehicle Hour meter

- DPS indicator

- AUTO (Automatic)

- P (Park)

Right Lateral Display

- R (Reverse)

- N (Neutral)

- H (High range)

- L(Lowrange)

7.6" DIGITAL DISPLAY

- (Invalid gear)

Icon

Descriiptiion

Engine Mode Display

2x4 icon

4X4 icon

The engine mode display indicates

the selected mode of operation:

- NORMAL

Front differential

- SPORT

lock

- SPORT+

A message of the selected mode will

Middle Left Display

be displayed on the lower display at

activation and deactivation as follow:

Message at

Drive Mode

Activation

Normal

NORMAL MODE

Sport

SPORT MODE

Sport+

SPORT+ MODE

The middle left lateral

display

includes:

Middle Right Display

- Seat belt reminder

- Maintenance reminder

Indicator Lamps

Warning and Telltale Liights

The middle right display indicates the

WARNING and Tellltalle Liights

selected mode of operation:

2X4

ORANGE - Vehicle

–

4X4

Malfunction

–

Front differential lock (Smart-Lok)

BLUE - High Beam

RED - The engine

temperature is too high.

7.6" DIGITAL DISPLAY

Settings

WARNING and Tellltalle Liights

Setup

GREEN - Neutral

Using the MENU button on the key-

pad, select SETTINGS and hold to

enter setting menu.

RED - Brake lock lever is

engaged or malfunction of

OK button can be pressed instead of

the brake system

holding MENU button.

RED - The battery voltage

Maiintenance Reset

too low or problem with the

electrical system

NOTE:

Only when the maintenance icon is

RED - Low oil pressure

displayed.

Normally ON when engine

is OFF

Using MENU button, select RES

MAINT and hold to reset

maintenance.

ORANGE - Low fuel level

Fault Codes

ORANGE

Available only when at least one code

Turn on: Malfunction of the

is activated.

vehicle emissions control

system

Using MENU button, select CODES

Bliink: Engine problems,

and hold to see active fault codes.

the limp home mode is

Fault codes will be scrolled on the

activated. Have the vehicle

Lower Display.

serviced immediately.

Reset Stats

Icons and Indiicators

Using MENU button, select RESET

STAT and hold to reset.

Icons and Indicators

Denotes SPORT

Unit Selection

mode is selected.

This multifunction gauge is factory

preset in Imperial units but it is possi-

When lit, seat belt

ble to change it to Metric units.

not buckled with

vehicle

Using MENU button, select UNITS

immobilized.

and hold button to change units.

Flashing when

vehicle is moving.

Speed/RPM

When lit, indicates

The speed and RPM display can be

that a maintenance

swapped.

is required. See

Using MENU button, select SPEED/

your authorized

RPM and hold button to invert speed

Can-Am dealer or

and RPM display.

person of your own

choosing for the

maintenance.

7.6" DIGITAL DISPLAY

Setting Clock

All of the following action must be per-

formed using the MENU button.

1. Select CLOCK and hold to change

time.

2. Press the button to select clock

display.

3. Push and hold the button for

second.

4. Press the button to select 12:00

AM PM or 24:00 time base.

5. Push and hold the button or OK

button to acknowledge selection.

6. Press the button to change hours

(hours flash).

7. Push and hold the button or OK

button to acknowledge hour

selection

8. Push the button to switch to mi-

nutes (minutes flash).

9. Push and hold the button to ac-

knowledge minutes selection.

Setting Briightness

The brightness of the LCD display can

be adjusted.

Using MENU button, select BRIGHT-

NESS and hold MENU button to se-

lect the brightness setting.

Using MENU button, adjust brightness

then push and hold MENU button to

acknowledge selection.

Setting Language

The gauge display language can be

changed.

Refer to an authorized Can-Am Off--

road dealer for language availability

and to setup the gauge to your

preference.

DPS Modes

The lower display can show which

DPS mode is active. Refer to Tune

Your ride.

TUNE YOUR RIDE

Engine Mode

4WD Mode

Use this button

on the keypad to

Use this button

on the keypad to

select the Engine modes

setup the differential modes.

The NORMAL setting reduces the fuel

The first press will show the current

consumption and the comfort by limit-

4WD state.

ing throttle response and selecting a

A second press will change the 4WD

higher gear to maintain an optimal

mode to the next one.

cruising setting. Use the NORMAL

mode can also be used on bumpy

The 4WD will mechanically engages

trails to provide smoother ride

only when the engine is running and

conditions.

can be activated on the fly.

The SPORT mode provides a crisper

To engage 4WD with the engine off,

throttle response.

apply full throttle and hear to confirm

for the 4WD solenoid engagement.

The SPORT+ mode provides a crisper

throttle response without turbo lag and

4WD Trail

maintains higher turbo speed t low en-

gine load for an optimal dynamic

This mode must be used during all

response.

normal riding.

The front differential will automatically

NOTE:

synchronize the front wheels as

The transmission behavior is also im-

pacted by the engine mode. The

needed.

SPORT and SPORT+ modes will shift

4WD Trail Active

at higher rpm, downshift sooner and

maintain a lower gear to optimize ac-

This mode is used to increase traction

celeration and response.

on the front drive train.

To change between engine modes,

This will optimize traction while going

press ENGINE MODE button on key-

out of a corner and/or while doing hard

pad to cycle through available modes.

acceleration by the detection of the

engine torque required by the driver.

MODE

Setting

When using this mode, you need to

adjust of your driving style as the front

Low shifting point

drivetrain is going to pull more than

Nor

Idle speed around 1500

usually.

mal

RPM

Use for a smooth ride

4WD Front Diff Lock

Higher shifting point than

This mode locks the front differential.

Normal mode

Idle speed around 1800

The front differential is kept locked un-

Sport

RPM

til the button is pushed again to

Use for a more sportive

unlock.

ride

When using this mode, you need to

Higher shifting point

adjust of your driving style as the front

without boost lag

Sport+

Idle speed around 2500

RPM

Use for the extreme ride

TUNE YOUR RIDE

drivetrain is going to pull more than

Check the multifunction gauge to

usually.

confirm the active DPS mode.

WARNING

The fullly locked optiion of the front

diifferentiial reduces the maneu-

DPS

verabillity of the vehicle iin certain

conditions.

DPS Function

7.6

DIGITAL DISPLAY

The tri-mode Dynamic Power Steering

To change the DPS mode, pro-

(DPS) offers easy steering assistance

ceed as follows:

to the rider. The level of assistance

Press and release the DPS button

adapts automatically according to the

on the keypad.

vehicle’s speed and the rider’s de-

Check the multifunction gauge to

mand, in order to provide maximum

confirm the active DPS mode.

steering power at lower speeds,

Press and hold the DPS button for

where the demand is normally higher.

2 seconds to go to the next setting.

As speed increases, the level of assis-

Release the DPS button.

tance is progressively reduced to

Repeat until the desired setting is

keep maximum precision and steering

obtained.

feel for the rider.

NOTE:

It is possible to choose between three

The DPS adjustment will not be possi-

modes of assistance: Minimum, Me-

ble if the gearbox is set to REVERSE.

dium, and Maximum. These modes

are used to set the level of assistance

Suspension Adjustment

to match each rider’s preferences.

Each mode will continue to adapt au-

Guidelines

tomatically, so it does not need to be

Handling and comfort of the vehicle

changed while riding.

depend

upon

suspension

adjustments.

The following DPS modes are preset

on the vehicle.

WARNING

DPS MODE

Suspension adjustment could af-

fect vehiiclle handliing.

DPS

Maximum steering assist

Allways take tiime to famiiliiariize

MAX.

yourself with the vehiiclle''s behav-

DPS

ior after any suspension adjust-

Medium steering assist

MED.

ment has been made.

DPS

Minimum steering assist

Choice of suspension adjustments

MIN.

vary with vehicle load, personal pref-

erence, riding speed and terrain

To view the active DPS mode, pro-

condition.

ceed as follows:

The best way to set up the suspen-

1. Press and release the DPS button

sion, is to start from factory settings,

on the keypad.

then customize each adjustment one

at a time.

TUNE YOUR RIDE

Front and rear adjustments are inter-

Front Suspension Factory

related. It may be necessary to read-

Settings

just the rear shock absorbers after

adjusting front shock absorbers for

Spring Preload

instance.

Test run the vehicle under the same

44.1 mm

conditions; trail, speed, load, etc.

(1.74 in)

Change one adjustment and retest.

Proceed methodically until you are

Crossover ring position

satisfied.

99.1 mm

Following are guidelines to fine-tune

(3.9 in)

suspension.

SHOCK ADJUSTMENT LOCATION

Compression Damping

Position 2

Rear Suspension Factory

Settings

Spring Preload

283.9 mm

(11.18 in)

TYPICAL - FRONT SUSPENSION

1. Compression damping

Crossover ring position

2. Preload

3. Spring crossover

55.9 mm

(2.2 in)

Compression Damping

Position 2

Suspension Adjustments

Spriing Preload Adjustment

Shorten the spring for a firmer ride

and rough riding conditions, or when

TYPICAL - REAR SUSPENSION

carrying a load.

1. Compression damping

2. Preload

Lengthen the spring for a softer ride

3. Spring crossover

and smooth riding conditions.

Suspension Factory Settings

For adjustment procedures, refer to

Suspension Adjustments.

TUNE YOUR RIDE

WARNING

The lleft and right shock adjust-

ment on front or rear suspension

must always be set to the same

position.

Never adjjust one shock only.

Uneven adjustment can cause

poor handlling and lloss of stabillity,

which coulld lead to an accident.

TYPICAL - CROSSOVER ADJUSTMENT -

Lift the vehicle. The spring length

REAR SHOCK

should be measured without any load

A. Spring preload

on the wheels.

B. Crossover ring position

The spring length should be the same

Compressiion Damping Adjustment

on both sides.

Compression damping

controls how

Adjust by loosening the lock ring and

the shock

absorber

reacts when

turning the adjuster ring as desired.

riding.

Use the tool from the vehicle tool kit.

Result on

Posiition

Settiing

NOTE:

Big Bumps

Factory settings are suitable for al-

most all conditions. Take into consid-

Softer

eration that an increase in ground

compres

Soft

clearance can affect the handling of

sion

the vehicle.

damping

Medium

compres

(factory)

sion

damping

Firmer

compres

Hard

sion

damping

TYPICAL

1. Loosen top locking ring

2. Turn adjusting ring accordingly

3. Tighten top locking ring

Adjjusting Spriing Crossover

Dual compression rate crossover

point can be modified by adjusting the

crossover rings position. See an au-

thorized Can-Am dealer.

FUEL

FUEL REQUIREMENTS

NOTICE

Always use fresh gasoliine. Gaso-

line willl oxidiize; the result is loss

of octane, volatille compounds,

and the production of gum and

NOTICE

varnish deposits whiich can dam-

Never experiment with other

age the fuel system.

fuells. Engiine or fuell system dam-

ages may occur wiith the use of an

inadequate fuel.

Alcohol fuel blending varies by coun-

try and region. Your vehicle has been

designed to operate using the recom-

NOTICE

mended fuels, however, be aware of

the following:

Do NOT use fuel from fuell pumps

labeled E85.

Use of fuel containing alcohol

above the percentage specified by

government regulations is not rec-

Use of fuel labeled E15 is prohibited

ommended and can result in the

by U.S. EPA Regulations.

following problems in the fuel sys-

tem components:

VEHICLE FUELING

- Starting and operating

PROCEDURE

difficulties.

WARNING

- Deterioration of rubber or plas-

tic parts.

– Fuell is flammable and explo-

- Corrosion of metal parts.

sive under certaiin conditions.

- Damage to internal engine

– Never use an open fllame to

parts.

check fuell level.

– Never smoke or alllow fllame or

Inspect frequently for the presence

spark iin viicinity.

of fuel leaks or other fuel system

– Always work iin a welll-venti-

abnormalities if you suspect the

llated area.

presence of alcohol in gasoline ex-

– Vehiiclle must be on a llevell sur-

ceeds the current government

face to perform fueliing.

regulations.

Alcohol blended fuels attract and

hold moisture which may lead to

1. Place vehicle on a level surface.

fuel phase separation and can re-

2. Stop engine.

sult in engine performance prob-

lems or engine damage.

WARNING

Recommended Fuell

Allways stop engine before

refueliing.

Use premium unleaded gasoline with

an AKI (R+M)/2 octane rating of 91, or

an RON octane rating of 95.

3. Have driver and passenger get out

of vehicle.

Use unleaded gasoline containing

MAXIMUM 10% ethanol.

FUEL

fuel flow back. Be careful not to

WARNING

spill fuel.

Do not alllow anyone to remaiin in

8. Stop filling when the fuel reaches

the vehicle whille fueliing. If there

the bottom of filler neck. Do not

is a fire or expllosiion duriing fuel-

overfilll.

ing, a vehiiclle occupant could be

unablle to quickly leave the area.

WARNING

Never top up the fuell tank before

4. Open the fuel reservoir cap cover.

pllaciing the vehiclle in a warm

area. As temperature iincreases,

fuel expands and may overflow.

9. Fully tighten fuel reservoir cap

clockwise until you hear a clicking

noise.

WARNING

Always wipe off any fuel spilllage

from the vehicle.

1. Fuel reservoir cap cover

5. Slowly unscrew the fuel reservoir

cap counterclockwise to remove it.

1. Fuel reservoir cap

WARNING

If a diifferentiial pressure conditiion

is noticed (whistliing sound heard

when lloosening fuel reservoiir

cap) have vehicle iinspected and/

or repaiired before further

operation.

6. Insert the spout into the filler neck.

7. Pour fuel slowly so that air can es-

cape from the tank and prevent

BREAK-IN PERIOD

Operation During Break-In

A break-in period of

operating

hours or 300 km (200 mi) is required

for the vehicle.

Engiine

During the break-in period:

- Avoid full throttle operation.

- Avoid pressing accelerator pedal

more than 3/4 of the stroke.

- Avoid sustained accelerations.

- Avoid prolonged high speeds.

- Avoid engine overheating.

However, brief accelerations and

speed variations contribute to a good

break-in.

Brakes

WARNING

New brakes wiilll not operate at

their maximum efficiiency untill

their break-iin is completed. Brak-

ing performance may be reduced,

so use extra cautiion.

Applly moderate braking force for

the 40 to 50 first braking events.

100

BASIC PROCEDURES

While reading this Operator’s Guide, remember that:

WARNING

Indicates a potential hazard which, if not avoided, could result

in serious injury or death.

STARTING THE ENGINE

WAKING UP THE

ELECTRICAL SYSTEM

WARNING

1. Press and release the START but-

After starting the vehiicle, when

ton for less than half a second and

the engine is not at operatiing tem-

the electrical system will turn ON:

perature, the vehiiclle may move

sliightly when position D or R iis

- For 20 seconds, wiithout

selected.

powering any equipment, if the

To avoiid unattended vehiclle

D.E.S.S. key is NOT installed

movement, always set to park be-

on the D.E.S.S. post.

fore exitiing the vehiclle when the

- For 10 minutes, powering

engiine is runniing.

equipment, if the D.E.S.S. key

is installed on the D.E.S.S.

post. The electrical system will

1. Install D. E. S. S. key on D. E. S. S.

shutdown after 20 seconds if

post.

the D.E.S.S. key is removed.

2. Press the brake pedal.

3. Press the engine start button and

NOTICE

hold until the engine starts.

Waking up the electriicall system

NOTE:

repeatedly or using electriicall

Do not press the accelerator pedal. If

equipment wiilll discharge the bat-

the accelerator pedal is pressed at

tery and you may not be able to

least 20%, the engine will not start.

start the engiine.

4. Release the engine start button

OPERATING THE SHIFT

immediately when the engine has

started.

LEVER

1. Apply brakes (the vehicle must be

NOTICE

completely stopped).

If engine does not start after a few

2. Pull the shifter rearward to select

seconds, do not hold the engine

the D (drive) position or push the

start button more than 10 sec-

shifter forward to select the R (re-

onds. Refer to Troublleshootiing

verse) position.

section.

3. Release brakes.

NOTICE

5. Wait approximately 10 seconds to

let engine oil flow through engine

When changiing gear selectiion, al-

and turbo before driving.

ways completely stop the vehiicle

and applly the brakes prior to shift-

ing. Faiilure to do so may damage

the gearbox.

101

BASIC PROCEDURES

CHOOSING THE CORRECT

Release the accelerator pedal and

use brakes to completely stop the

RANGE (LOW OR HIGH)

vehicle.

High Range

Push the PARK button.

Press the start / stop button to stop

High is the default riding range.

the engine.

Remove the D. E. S. S key from its

Low Range

post.

Block the wheels using rocks or

Low range should be used as needed

bricks if you must park on a steep

whenever:

incline or if the vehicle is carrying

- Pulling or recovery

cargo.

- Pushing

Before stopping the engine and

- Hauling a load

parking the vehicle following a

4x4 applications

more intense ride, let vehicle run

–

Mud holes

idle for a period of 1

2 minutes

–

Water holes

to allow

for

cooling

the

turbo

–

Crossing obstacles

system.

–

Climbing onto trailer

–

Hill climbing

STOPPING THE ENGINE

AND PARKING THE

VEHICLE

WARNING

Avoiid parking on steep sllope as

the vehiiclle may rolll away.

WARNING

Always put the vehiiclle in PARK

when stopped or parked to pre-

vent rollliing.

WARNING

Avoiid parking iin pllaces where hot

parts can start a fiire.

1. When stopped or parked always

put the vehicle in PARK.

This is especially important when

parking on a slope. On very steep

inclines or if the vehicle is carrying

a cargo, the wheels should be

blocked using rocks or bricks.

2. Select the flattest terrain available

for parking.

102

SPECIAL PROCEDURES

PERMANENT NEUTRAL or

2. The message “Permanent Neutral”

will be displayed in the digital

MECHANICAL NEUTRAL

display.

ACTIVATION

3. Turn engine OFF.

The PERMANENT neutral and the

MECHANICAL neutral are different

Mechaniicall Neutrall Activatiion

than the NORMAL neutral (N button).

Select the most flat ground as pos-

sible near the vehicle.

NORMAL neutral:

Ask someone to press and hold

the brake pedal during the entire

This function is selected by

procedure.

pressing the “N” button.

If not possible, block the wheels to

The vehicle will go back to PARK

avoid any unexpected vehicle

position when the engine is

movements using rocks, pieces of

shutdown.

wood or other suitable objects.

The N icon appears in the digital

Remove the transmission actuator

display when the transmission is in

connector.

neutral.

PERMANENT neutral:

This neutral is selected by pressing

the “N” button near the shifter at

least 5 seconds.

The message “Permanent Neutral”

will be displayed in the digital

display.

The vehicle stays on neutral after

Remove the two screws

holding

the engine is shutdown.

the transmission actuator.

The permanent neutral must be

used to tow the vehicle.

MECHANICAL neutral:

This neutral is set up manually by

using the following procedure.

The mechanical neutral must be

used when you experience a dead

battery without possibility to activate

the electrical system using a jump

Remove the transmission actuator.

start or by installing a battery

charger (refer to Dead Battery) or

when a problem occurs with the

shifting actuator.

Permanent Neutral Actiivation

1. Press and hold the NEUTRAL but-

ton at least 5 seconds.

103

SPECIAL PROCEDURES

10. Remove the shift drum rotation

tool.

11. Reinstall it and align the hole of the

tool handle with the upper actuator

threaded hole.

12. Secure the tool in place by using

one of the previously removed

screws.

13. See an authorized Can-Am Off--

road dealer as soon as possible.

6. Insert the neutral activation tool

(located in the glove box) instead

LIMP HOME MODE

of the transmission actuator.

The Limp Mode is activated automati-

cally to restricts engine power but al-

Shiift drum rotatiion

lows you to continue your ride in case

tool

of a components malfunction or under

certain conditions.

(P/N 529000158)

This mode is often caused by engine

overheating, low engine oil conditions,

7. Turn the tool toward the left of the

low battery voltage, or other electrical

vehicle until the tool stops.

or sensor malfunctions.

When the Limp Home mode is acti-

NOTICE

vated, the “Check Engine” icon

Make sure to folllow the iinstructiion

turned ON and the

“LIMP HOME

mollded on the tool.

MODE” message is displayed in the

digital display.

In LIMP HOME, the engine RPM is

limited and therefore the vehicle

speed.

In the event vehicle goes into the

LIMP HOME mode, have the vehicle

transported in your authorized Can--

Am off-road dealer as soon as

possible.

Start turning in the other way for

If you operate the vehicle in LIMP

approximately seven and a quarter

HOME, avoid abrupt maneuvers and

turns.

immediately go to the nearest author-

ized Can-Am Off-road dealer to have

Pay attention during this step, a

your vehicle serviced before riding

slight "click" will be heard when

again.

reaching the neutral position.

Move away from the vehicle and

DEAD BATTERY

check if the vehicle can be moved

by releasing the brake or trying to

If the battery is dead or too weak to

rock the vehicle.

If yes, continue the procedure.

If no, redo the procedure.

104

SPECIAL PROCEDURES

crank the engine, it can be jump

7. Connect the other end of the

started.

BLACK jumper lead to the nega-

tive (-) post of the booster vehicle’s

WARNING

battery.

8. Start the booster vehicle and let it

Connect the jumper cablles as

run to idle.

specifiied iin the jjump start

9. Start your vehicle in the usual way.

procedure.

If the engine does not start, wait a

few minutes before repeating the

Park the booster vehicle close to

attempt in order to protect the

the front of your vehicle.

starter motor and the booster

Open the front fuse compartment

battery.

cover located in the center of the

dash.

NOTE:

Remove the positive post cover

If it still does not start, there might be

and clean any corrosion from the

a problem with the starting system.

battery posts before connecting

Have the vehicle transported

(see

the jumper cables.

Transporting the Vehicle) and re-

paired by an authorized Cam-Am Off--

Road dealer.

10. Once the vehicle has been started,

let both vehicles run at idle for a

few minutes before disconnecting

the jumper cables.

11. Remove the jumper cables in the

reverse order that they were

connected.

Begin by connecting one end of

NOTE:

the RED jumper lead to the posi-

If the engine stops shortly after it has

tive

(+) post of the discharged

been started or when the jumper ca-

battery.

bles are disconnected, there might be

Then connect the other end of the

a problem with the charging system.

RED jumper lead to the positive

Have the vehicle transported

(see

(+) post of the booster vehicle’s

Transporting the Vehicle) and re-

battery.

paired by an authorized Cam-Am Off--

Connect one end of the BLACK

Road dealer.

jumper lead to the negative (-) post

of the discharged battery.

12. Fully recharge the battery with a

battery charger (see Maintenance

Procedures) or have it recharged

by a qualified service station as

soon as possible.

After recharging the battery, have

the vehicle inspected by an author-

ized Can-Am Off-Road dealer.

105

SPECIAL PROCEDURES

ROLLED OVER VEHICLE

Abrupt maneuvers, sharp turns, side

hilling or accident may cause vehicle

to rollover.

Should the vehicle be rolled over, it

will be necessary to have it trans-

ported to an authorized Can-Am Off--

road dealer for inspection as soon as

possible. NEVER START THE

ENGINE!

Points to be verified, including but not

limited to:

- All fluid levels

- Air filter box and air filter for

contamination

- Seat belts, including retractors,

buckles and semi-cinching tabs

- Cage and its attachment points

- Steering system

- Suspension and its attachment

points.

SUBMERGED VEHICLE

Should the vehicle become immersed,

it will be necessary to have it trans-

ported to an authorized Can-Am Off--

road dealer as soon as possible.

NOTICE

Never start the engiine as immer-

siion of the vehicle can cause seri-

ous damage to the engiine if the

correct restart procedure is not

followed.

106

TRANSPORTING THE VEHICLE

When contacting a towing or transporting service, be sure to ask if they have a

flatbed trailer, loading ramp or power ramp to safely lift the vehicle and tie-down

straps. Ensure the vehicle is properly transported as specified in this section.

NOTICE

Do not tow this vehiiclle wiithout engaging the PERMANENT neutral or the

MECHANICAL neutrall — towing can seriously damage the vehicle''s drive

system.

NOTICE

Avoid using chaiins to tiie the vehiicle — they may damage the surface fiin-

ish or plastiic components.

WARNING

To avoiid severe injury or death or important components damages.

– Never use the winch cable/rope to retaiin a vehicle during trailleriing.

– Never riide wiith the wiinch cablle/rope attached to a load or another

vehicle.

– Onlly use the winch to help a stuck vehicle (snow, mud, etc.).

– Always refer to the wiinch manufacturer''s instruction before pullliing

loads.

WARNING

Make sure alll accessories, cargo and lloose objjects inside the vehicle are

properlly secured, or remove iit to prevent from failling on the road and cre-

ating a hazard for folllowiing vehicles.

WARNING

Allways transport the vehicle faciing forward to avoiid damagiing the wiind-

shield or other components. Parts may detach during transport.

WARNING

Before attemptiing to mount vehicle onto a platform or a trailer, make sure

to respect the folllowiing safety precautions.

Safety Precautiions

The carrying item (platform or trailer or flat bed)

must be of appropriate dimensions and

Carrying equipment

capacity to safely support and transport the

vehicle.

Do not exceed vehicle hauling capacity and

Hauling vehicle

specifications. Ensure the trailer or platform is

properly secured to the hauling vehicle hitch.

107

TRANSPORTING THE VEHICLE

Safety Precautions

Ensure you have a good visibility during the

Visibility

entire maneuver.

The hauling vehicle and trailer must be on a

Terrain

leveled surface. Use wheel chocks on trailer

and hauling vehicle to avoid any movement.

Use ramps with proper rating and secure ramps

Ramps

to the trailer or platform. Avoid steep ramps.

Always make sure bystanders are not close to

Bystanders

the vehicle or the trailering equipment while

climbing up.

Make sure all accessories, cargo and loose

objects inside the vehicle are properly secured,

Accessories and cargo

or remove it to prevent from failing on the road

and creating a hazard for following vehicles.

Using Vehicle Power to Climb

acceleration while on ramps to pre-

vent ramps movement.

Onto Trailering Equipment

10. If trailer is inclined towards front,

When vehicle can cliimb on iits own

simply let vehicle roll in without

power, proceed as folllows;

acceleration.

11. Once vehicle is climbed, active the

Wear protective gear.

Park and stop the engine.

Fasten seat belt.

Use the Low range and the 4WD

mode.

WARNING

When driving remain seated at all

When vehiiclle cannot move on its

times.

own power, or in case overshoot-

Ensure proper alignment on rails

ing iis a riisk or if any dangerous

or platform.

conditiion prevents for embarkiing

Start from a sufficient distance

on its own power, proceed using a

from the trailer to align the vehicle

winch.

in a straight line with the ramps.

Never attempt to turn while getting

closer to the ramp. Rear wheels

might not be aligned once you get

to the ramp and vehicle may fall

off.

Slowly climb the front wheels onto

the ramp to verify alignment.

Back off the vehicle, verify ramps

are still secure, then proceed at

proper speed.

Carefully drive the vehicle onto

platform or trailer. Use sufficient

speed to climb without spinning or

abruptly

accelerating.

Avoid

108

TRANSPORTING THE VEHICLE

Using a Winch to Pull Vehicle

4. When loaded, engage the PARK

and attach the vehicle securely.

Onto Trailering Equipment

When vehiclle cannot cllimb on iits

Securing Vehicle for

own power, proceed as folllows;

Transport

WARNING

Have the help of an assistant.

To avoid severe injjury or death or

One person should be in vehiiclle

damage to iimportant components.

to have access to vehiclle steer-

–

Never use the wiinch cablle/

ing, brakes and winch switch,

rope to retaiin a vehicle during

whiile the other person controls

traiileriing.

the environment and safety of the

–

Never ride with the winch ca-

maneuver.

ble/rope attached to a load or

another vehiclle.

WARNING

–

Onlly use the wiinch to hellp a

stuck vehicle (snow, mud,

Ensure the winch hook can be

etc.).

safelly attached to a proper an-

–

Allways refer to the winch man-

choriing poiint. Use proper riiggiing.

ufacturer''s instructions before

pullliing loads.

NOTE:

If vehicle can be started safely, let en-

Ensure the PARK is selected (if

gine idle during winching to avoid

possible).

draining the battery.

Remove the key from the D.E.S.S.

post.

Choice one of the following

Secure the vehicle by using UTV

options:

tire-bonnets so that the vehicle

1. Start the engine and select the

suspension is free to move during

NEUTRAL (N).

transportation.

2. If the engine cannot be started,

use the PERMANENT neutral.

If not possible, secure the rear of

3. If the electrical system cannot

the vehicle on both sides using a

be powered (or boosted) or if

strap around the trailing arm as

the shifting actuator is defec-

close to the wheel as possible.

tive, use the MECHANICAL

neutral.

If the vehicle is equipped with a

winch, use the winch to roll the ve-

hicle on the platform.

If the vehicle is not equipped with a

winch:

1. Attach a strap to the front re-

covery hook.

2. Attach the strap to the winch

cable

the

trailering

equipment.

3. Load the vehicle onto or into

the trailering equipment.

Trailing arm

109

LIFTING AND SUPPORTING THE VEHICLE

Front of Vehicle

1. Place vehicle on a flat non slippery

ground.

2. Block the rear wheels properly to

avoid any unexpected vehicle

movements

3. Install an hydraulic jack under the

rear of the front lower plate.

REAR OF VEHICLE

1. Hydraulic jack position

4. Lift rear of vehicle and install a jack

stand on each side under frame as

shown below.

NOTICE

Make sure to aliign the jack stands

4. Lift front of vehicle and install a

wiith the tubular frame under the

jack stand on each side under

skid plate.

frame as shown below.

NOTICE

Make sure to allign the jjack stands

with the tubullar frame under the

skiid plate.

JACK STAND POSITIONS

- REAR OF

VEHICLE

5. Lower hydraulic lift and ensure ve-

hicle is supported safely onto both

jack stands.

JACK STAND POSITIONS - FRONT OF

VEHICLE

5. Lower hydraulic lift and ensure ve-

hicle is supported safely onto both

jack stands.

Rear of Vehicle

1. Place vehicle on a flat non slippery

ground.

2. Block the front wheels properly to

avoid any unexpected vehicle

movements

3. Install an hydraulic jack under the

vehicle.

111

MAINTENANCE SCHEDULE

Maintenance is very important to keep your vehicle in safe operating condition.

The vehicle should be serviced as per the maintenance schedule.

Proper maintenance is the owner’s responsibility. A warranty claim may be de-

nied if, among other things, the owner or operator caused the problem through

improper maintenance or use.

Perform periodic checks and follow the maintenance schedule. The maiinte-

nance schedule does not exempt the pre-ride inspection.

WARNING

Faiilure to properly maiintain the vehiclle accordiing to the maiintenance

schedulle and procedures can make it unsafe to operate.

EPA Regulation - Canadian and USA Vehicles

A repair shop or person of the owner''s choosing may maiintaiin, replace, or

repair emission control devices and systems. These instructions do not require

components or service by BRP or authorized Can-Am Off-road dealers.

Although an authorized Can-Am Off-road dealer has an in-depth technical knowl-

edge and tools to service your vehicle, the emission-related warranty is not con-

ditioned on the use of an authorized Can-Am Offroad dealer or any other

establishment with which BRP has a commercial relationship.

Proper maintenance is the owner’s responsibility. A warranty claim may be de-

nied if, among other things, the owner or operator caused the problem through

improper maintenance or use.

For emission-related warranty claims, BRP is limiting the diagnosis and repair of

emission-related parts to the authorized Can-Am Offroad dealers. For more infor-

mation, please refer to the US EPA Emission-Related Warranty contained in the

Warranty section.

You must follow the instructions for fuel requirements in the fueling section of this

manual. Even if gasoline containing greater than ten volume percent ethanol is

readily available, the US EPA issued a prohibition against the use of gasoline

containing greater than 10 vol% ethanol that applies to this vehicle. The use of

gasoline containing greater than 10 vol% ethanol with this engine may harm the

emission control system.

Air Filter Maintenance Guideline

Air filter maintenance should be adjusted according to riding conditions.

Air filter maintenance must be increased in frequency when riding on snow, dry

sand, dirt, gravel or similar conditions which have a high dust or particle

dispersion.

Riding in a group in these conditions will require increasing the air filter mainte-

nance frequency further.

NOTE:

Accessory filters and pre-filter are available for such conditions. Contact an au-

thorized Can-Am off-road dealer for details.

114

MAINTENANCE SCHEDULE

Severe Duty Use

If your vehicle is used in the following conditions, refer to the Severe Duty section

of the maintenance schedule.

- Sand dunes riding.

- Driving at excessive speeds for prolonged amount of time.

- Repeated carrying of loads at more than 75% the maximum capacity.

- The increase workload applied to the drive system accelerates the differ-

entials, gearbox/transmission, and engine oil life. This reduces internal

component longevity if not replaced more frequently.

Extreme Cold Condiitiion

An engine that is frequently operated at or below an ambient temperature of -25 °

C (-13 °F) will require an increase in service and maintenance schedule.

Any combustion engine operated at these low ambient temperature will collect

an increased amount of condensation at every startup/warm-up.

Since the engine is not reaching operating temperatures for extended periods of

time, the oil is starting to be strongly diluted with water and gas residue (more

water content).

An engine needs to reach operating temperature, in order to be able to evaporate

condensate out of the oil.

If daily usage (work or leisure driving cycle) is similar to those mentioned below,

BRP strongly recommends changing the oil at least once a month.

Parameters of an increase in service and maintenance schedule:

- Engine not reaching the proper operating temperature during normal daily

usage

- Multiple starts and stops without reaching operating temperature

- Short idle periods

- Low RPM driving cycle in short distances without reaching operating

temperature.

NOTE:

BRP strongly recommends the installation of a block heater to help warm up the

liquids, this will also help to extend the oil lifetime.

Deep Mud / Water Use

This type of usage requires more frequent maintenance and inspections to en-

sure debris has not infiltrated mechanical components.

If you ride in deep mud or water, be sure to perform the following Post Operation

Care for Deep Mud / Water Environment list.

Post Operatiion Care for Deep Mud / Water Environment

- Rinse the vehicle and its components with fresh water.

- Inspect and clean engine air filter and engine air filter housing.

115

MAINTENANCE SCHEDULE

- Clean radiators and intercooler.

- Visually inspect for any water accumulation in the vent hoses (fuel tank, gear-

box, front differential and rear final drive). If there is water, bring the vehicle to

your nearest authorized Can-Am Off-road dealer for inspection and servicing

of main components related to the vents.

- Clean front and rear shock absorbers to prevent seal from damage by dust or

dirt.

- Clean drive shaft bellows and the propeller shaft yokes or bellows.

Maintenance Schedule

Make sure to perform proper maintenance at recommended intervals as indi-

cated in the tables.

The maintenance chart intervals are based on 3 factors:

- Calendar time

- Vehicle hours

- Odometer reading.

Take in account whichever comes first to determine the maintenance threshold.

Your driving habits determines the factors you shall adhere too. For example:

- Someone who uses their vehicle every other weekend trail riding with friends

would most likely follow the odometer readiing to determine the maintenance

interval.

- Someone who uses their vehicle seldomly over the year or only on a few oc-

casions (hunting, camping) would most likely follow the callendar time to de-

termine the maintenance interval.

- Someone who uses their vehicle daily / weekly for long periods of time such

as agricultural / work would most likely follow the vehiicle hours to determine

the maintenance interval.

IMPORTANT: The following tables show the appropriate maintenance appli-

cation for the first

3 years. For subsequent years, repeat the same pattern

alternatively.

Regular Maintenance Overview

Calendar

Vehicle Hours

Odometer

Regular Duty

Years

3000 km

100

(1900 mi)

6000 km

200

A+B

(3700 mi)

9000 km

300

(5600 mi)

116

MAINTENANCE SCHEDULE

REGULAR DUTY

A=Adjust

Every year

Every 2 years

C=Clean

I=Inspect

100 hours

200 hours

L=Lubricate

R=Replace

3000 km

6000 km

T=Torque

(1900 mi)

(3700 mi)

Air and Fuel Delivery

Engine air filter

I, C, R

Air delivery components and function (airbox,

I, C

throttle body, ducts, clamps)*

Fuel components and function (Fuel tank cap,

fuel tank, hoses, clamps, leaks)*

Fuel pump pressure

Body and Chassis

Cage fasteners

Seat belts retractors, buckles and

I, C

semi-cinching

Engine and Cooling

Engine oil and filter

Engine cooling components (coolant specific

gravity, coolant level, hoses condition,

I, C, A

clamps, leaks)*

Coolant

Every 5 years or 12 000 km (7500 mi)

As per vehicle

Spark plugs

hours and

odometer only,

Not calendar time

Radiators

Engine seals and gaskets

Exhaust and Emissions

Fuel tank vent breather filter (except EVAP

models)

Canister vent pre-filter (EVAP models)

Exhaust components (gaskets, pipes, muffler

condition, leaks)*

Exhaust clamping rings

Muffler spark arrester

Debris around exhaust pipe and muffler area

118

MAINTENANCE SCHEDULE

REGULAR DUTY

A=Adjust

Every year

Every 2 years

C=Clean

I=Inspect

100 hours

200 hours

L=Lubricate

R=Replace

3000 km

6000 km

T=Torque

(1900 mi)

(3700 mi)

Brake

Brake components and function (brake pads,

brake discs, calipers, brake lines, master

I, C, L

cylinder)*

Brake fluid

Every 2 years

Drive

Replace at first 3000 km (1900 mi) and

Gearbox oil and filter

at 6000 km (3700 mi), then follow the

regular schedule

Gearbox oil and filter

I, A

Drive components (drive shaft (bellows,

joints, seals), propeller shaft U-joint, wheel

bearing)*

Front differential oil

Replace at first 3000 km (1900 mi) and

Final drive oil

6000 km (3700 mi), then follow the

regular schedule

Final drive oil

Disconnect unit oil

Tires (wear and pressure)

I, A

Wheel beadlock screws (if equipped)

Wheel lug nuts

Rear wheel scrappers and rock deflectors

I, C

Electrical

Battery connections and condition

I, C

Operation of control switches and lighting

Electronic modules (Fault codes and

applicable software updates)

Steering

Steering components and function (rack and

pinion, steering column, tie-rod)*

Suspension

Suspension components and function (shock

C, L, T

absorber, spherical bearings, ball joints,

119

MAINTENANCE SCHEDULE

SEVERE DUTY

A+

Every 6

A=Adjust

Every year

Every 2 years

months

C=Clean

I=Inspect

100 hours

200 hours

50 hours

L=Lubricate

R=Replace

3000 km

6000 km

1500 km

T=Torque

(1900 mi)

(3700

mi)

(900 mi)

Air and Fuel Delivery

Engine air filter

I, C

Air delivery components and

function (airbox, throttle body,

I, C

ducts, clamps)*

Fuel components and function

(Fuel tank cap, fuel tank, hoses,

clamps, leaks)*

Fuel pump pressure

Body and Chassis

Cage fasteners

Seat belts retractors, buckles

I, C

and semi-cinching

Engine and Cooling

Engine oil and filter

Engine cooling components

(coolant specific gravity, coolant

I, C, A

level, hoses condition, clamps,

leaks)*

Coolant

Every 5

years or 12 000 km (7500 mi)

As per vehicle

hours and

Spark plugs

odometer only,

Not calendar

time

Radiators

Engine seals and gaskets

Exhaust and Emissions

Fuel tank vent breather filter

(except EVAP models)

Canister vent pre-filter (EVAP

models)

121

MAINTENANCE SCHEDULE

SEVERE DUTY

A+

Every 6

A=Adjust

Every year

Every 2 years

months

C=Clean

I=Inspect

100 hours

200 hours

50 hours

L=Lubricate

R=Replace

3000 km

6000 km

1500 km

T=Torque

(1900 mi)

(3700 mi)

(900 mi)

Exhaust components (gaskets,

pipes, muffler condition, leaks)*

Exhaust clamping rings

Muffler spark arrester

Debris around exhaust pipe and

muffler area

Brake

Brake components and function

(brake pads, brake discs,

I, C, L

calipers, brake lines, master

cylinder)*

Brake fluid

Every 2 years

Drive

Replace at first

1500 km (900 mi) and at 3000 km

Gearbox oil and filter

1900 mi), then follow the regular schedule

Gearbox oil and filter

I, A

Drive components (drive shaft

(bellows, joints, seals), propeller

shaft U-joint, wheel bearing)*

Front differential oil

Replace at first 1500 km (900 mi) and at 3000 km

Final drive oil

1900 mi), then follow the regular schedule

Final drive oil

Disconnect unit oil

Tires (wear and pressure)

I, A

Wheel beadlock screws (if

equipped)

Wheel lug nuts

Rear wheel scrappers and rock

I, C

deflectors

Electrical

Battery connections and

I, C

condition

122

MAINTENANCE SCHEDULE

SEVERE DUTY

A+

Every 6

A=Adjust

Every year

Every 2 years

months

C=Clean

I=Inspect

100 hours

200 hours

50 hours

L=Lubricate

R=Replace

3000 km

6000 km

1500 km

T=Torque

(1900 mi)

(3700

mi)

(900 mi)

Operation of control switches

and lighting

Electronic modules (Fault codes

and applicable software

updates)

Steering

Steering components and

function (rack and pinion,

steering column, tie-rod)*

Suspension

Suspension components and

function (shock absorber,

spherical bearings, ball joints,

I, C, L, T

suspension arms, stabilizer bar

links and clamps)*

Stabilizer bar bushings

Recommended

lubrication

every 1000 km

(620 mi)

*For an extensive list of maintenance actions to be performed, refer to your local

Can-Am Off-road dealer.

123

MAINTENANCE PROCEDURES

This section includes instructions for

- Riding on dry gravel trails or simi-

basic maintenance procedures.

lar conditions.

- Riding in areas with high concen-

Due to the complexity of some of the

tration of seeds or crop husks.

maintenance procedures, good me-

- Riding in severe snow conditions.

chanical skills are required. If you are

not comfortable with these proce-

NOTICE

dures, do not hesitate to contact an

authorized Can-Am off-road dealer,

When riding iin dusty condiitiions or

repair shop or person of your own

sand, the aiir box needs to be

choosing.

clleaned before every ride.

WARNING

NOTE:

Riding in a group, under these condi-

Unlless otherwise indiicated, al-

tions, increases the frequency of the

ways remove D.E.S.S. key from

air filter maintenance.

the D.E.S.S. post before perform-

ing any maintenance and remove

Removiing the Engine Aiir Fillter

key.

1. From the left-rear wheel well, open

the four retaining clips on the air fil-

WARNING

ter cover.

Should removall of a llockiing de-

vice be required (e.g. llock tab,

self-lockiing fastener, etc.) , all-

ways replace iit wiith a new one.

ENGINE AIR FILTER

NOTICE

Never modify the air intake sys-

tem. Otherwiise, engiine perform-

ance degradation or damage can

occur. The engiine iis caliibrated to

RETAINING CLIP - TYPICAL

operate specificallly wiith these

2. Remove the air filter element from

components.

its housing.

Engine Aiir Fillter Replacement

Guiideline

Engine air filter inspection and re-

placement frequency should be ad-

justed according to riding conditions

as it is critical to ensure proper engine

performance and life span.

Engine air filter inspection and re-

placement frequency must be in-

creased for the following severe riding

conditions:

Cleaning the Engiine Air Fiilter

- Riding on dry sand.

1. Inspect the filter for any signs of

- Riding on dry dirt covered

leaks. A streak of dust on the clean

surfaces.

129

MAINTENANCE PROCEDURES

side of the filter is a telltale sign.

Replace filter if there is any dam-

ages. Eliminate any source of air

leaks before installing a new filter.

2. Clean engine air filter by tapping

out heavy dust from paper ele-

ment, this will allow dirt and dust to

get out of the paper filter.

NOTICE

It is not recommended to blow

Ensure that the element is properly

compressed air on the paper elle-

seated.

ment; thiis could damage the pa-

Position the air filter cover on the

per fibers and reduce iits filltratiion

housing and secure it using

the

abiiliity when used iin dusty envi-

four retaining clips.

ronments. If engine air fiilter is too

diirty and cannot be cleaned fol-

lowiing the recommended proce-

dure, it shoulld be replaced.

3. Use a clean damp cloth to wipe

both the filter sealing surface and

the inside of the outlet tube. En-

sure that the outlet tube sealing

area is undamaged.

4. Inspect air filter housing for

cleanliness.

RETAINING CLIP - TYPICAL

Cleaning the Engiine Air Fiilter

Housiing

FRONT GRILLE

1. Inspect air filter housing for

cleanliness.

Removing the Front Grillle

The front grille is located in fascia.

NOTICE

If sand or other particles are

found iin air fillter housing, cllean iit

using a vacuum cleaner.

Installling the Engiine Air Fillter

1. Insert the new engine air filter ele-

ment into its housing.

1. Press down the upper section of

the grille.

2. Carefully pull the grille forward to

release its four tabs from the

spring clips in the fascia.

130

MAINTENANCE PROCEDURES

Installliing the Front Griillle

1. Carefully press the grille into the

fascia so that its four tabs engage

the spring clips.

2. Verify that the grille is properly

clipped.

EVAPORATIVE EMISSION

SYSTEM PRE-FILTER (If

Equipped)

Remove the pre-filter assembly.

Replacing the Evaporatiive

Secure the new pre-filter on frame.

Emiissiion System Pre-Fillter

Tightening Torque

The pre-filter is located under the

right-rear fender.

Pre-filter

2.5 ± 0.5 Nm

screws

(22 ± 4 lbf-in)

Connect the inlet and outlet hoses

to the pre-filter.

Secure the hoses using new Oe-

tiker clamps.

ENGINE OIL

Recommended Engiine Oiil

NOTICE

Remove the Oetiker clamps that

Do not fill the engiine oiil iinto the

secure the inlet and outlet hoses to

gearbox. The gearbox requires

the pre-filter.

DCT oill and gear oill.

Rotax^® engines were developed and

validated using the XPS^® oil. BRP rec-

ommends the use of its XPS engine

oil or an equivalent at all time. Dam-

ages caused by the use of an oil not

suitable for the engine may not be

covered by the BRP Limited Warranty.

2. Disconnect the hoses from the

pre-filter

3. Remove both retaining screws.

131

MAINTENANCE PROCEDURES

XPS Recommended Engiine Oiil

NOTICE

The engiine oiil llevel verifiication

General

5W40 Synthetic oil

must be performed within 1 mi-

purpose

nute after engine shutdown.

Cold

tempera

0W40 Synthetic oil

Through the right-rear wheel well,

ture

unscrew the dipstick. Then remove

it and wipe it clean.

Warm

tempera

10W50 Synthetic oil

ture

If the recommended XPS engine oil is

not available:

- Use a 4-stroke SAE engine syn-

thetic oil meeting or exceeding the

following lubricant industry

specifications

- Always check the API service label

certification on the oil container, it

must contain the indicated

Reinsert the dipstick and screw it

in completely.

standards.

Remove the dipstick and check the

- API service cllassifiication SN

oil level. It should be at or near the

and JASO MA2

upper (MAX) mark.

Veriifyiing the Engine Oill Level

NOTICE

Operatiing the engiine wiith an im-

proper oill level may severely dam-

age the engine.

The engine oil level must be checked

at normal operating temperature, ei-

ther after riding or after letting the en-

gine idle for at least 10 min.

MAX

NOTE:

MIN

The engine is at normal operating

Operating range

temperature when the temperature in-

dicator on the right lateral display

If oil needs to be added, insert a

shows 5 bars.

funnel into the dipstick tube.

To avoid overfilling, add a small

1. Place the vehicle on a level

amount of recommended engine

surface.

oil then recheck the oil level. Refer

2. Engage the PARK.

to Recommended Engine Oil.

3. Start the engine and let it idle for at

least 20 seconds.

4. Stop the engine.

132

MAINTENANCE PROCEDURES

7. To avoid spillage, install a funnel

Oil Quantity Between MIN and

between the drain holes and the

MAX Marks

skid plate.

600 ml

(20.3 fl oz (US))

Funnel

10. Repeat the previous step until the

oil level reaches the upper (MAX)

(P/N 529000155)

mark on the dipstick.

8. Place a drain pan under both en-

NOTICE

gine drain plugs.

Do not overfilll.

9. Unscrew both magnetic drain

plugs. Discard the gasket rings

and O-ring.

11. Install the dipstick and tighten it

properly.

12. Wipe off any spillage.

Changing the Engiine Oiil

The engine oil and filter must be

changed at the same time, with a

warm engine.

CAUTION

The engiine oiil can be very hot. Al-

1. Magnetic drain plug (magneto cover)

low iit to cooll sufficiently before

2. O-ring

you begin.

3. Magnetic drain plug (oil tank cover)

4. Gasket ring

5. O-ring

Place the vehicle on a level

surface.

10. Allow the oil to drain completely

Put the vehicle on PARK.

from the crankcase.

Start the engine and let it run at

11. Clean the magnetic drain plugs of

idle for at least 2 minutes.

metal shavings and residue. The

Stop the engine.

presence of debris gives an indica-

Remove the dipstick.

tion of internal engine damage.

Clean the area around the drain

12. Install new gasket rings and

plugs.

O-rings on the magnetic drain

plugs.

NOTICE

Never re-use gasket riings or

O-riings.

Always replace them with NEW

ones.

A missing or damaged O-ring willl

cause a lloss of oiil pressure and

possiible engiine damage.

Magnetic drain plug (magneto cover)

Magnetic drain plug (oil tank cover)

133

MAINTENANCE PROCEDURES

13. Tighten the magnetic drain plugs

to specification.

Tighteniing Torque

Magnetic drain

30 ± 3 Nm

plugs

(22 ± 2 lbf-ft)

14. Replace the oil filter. Refer to Re-

placing the Engine Oil Filter.

15. Refill the engine with the recom-

Remove the oil filter cover. Discard

mended engine oil. Refer to Rec-

the O-ring.

ommended Engine Oil

Remove and discard the oil filter.

Check and clean the oil filter inlet/

Engiine Oiil Capacity

outlet area for dirt and other

contaminations.

Engine oil and

2.8 l

engine oil filter

(2.96 qt

replacement

(liq.,US))

16. After filling, start the engine and

check the oil level, refer to Verify-

ing the Oil Level.

17. Wipe off any spillage.

18. Dispose of the used oil and filter

per

local

environmental

regulations.

Oil inlet orifice from the oil pressure pump

Oil outlet orifice to the engine lubrication

ENGINE OIL FILTER

system

Oil filter housing

Engiine Oiil Fiilter Location

The oil filter is located on the right side

Wet a NEW O-ring with engine oil

of the engine.

and slip it onto the oil filter cover.

Install a NEW engine oil filter into

the oil filter cover.

Apply engine oil to the seal on the

open end of the oil filter.

Repllaciing The Engiine Oiil Fillter

1. Clean the oil filter area.

APPLY ENGINE OIL HERE

8. Install the new filter into its

housing.

134

MAINTENANCE PROCEDURES

NOTICE

CAUTION

Engine oill fillter and gearbox oiil fiil-

Before proceeding, wait for the ra-

ter are simillar, do not miix them.

diiator to cool.

The engiine oiil fiilter has a closed

end whille the gearbox oill filter iis

2. Inspect the radiator hoses for

opened on both ends and the

leaks or damage. Replace if

word gearbox iis allso marked on iit.

necessary.

Engine Oil

Gearbox Oil

Filter

1. Opened

end (relief

1. Closed

valve)

end

LOWER RADIATOR HOSE

2. Gearbox

1. Radiator

indication

2. Hose clamp

9. Tighten oil filter cover screws to

3. Lower radiator hose

specification.

NOTICE

Pay attentiion to avoiid pinchiing

the O-riing duriing fillter and cover

installatiion.

Tiightening Torque

Oil filter cover

9 ± 1 Nm

screws

(80 ± 9 lbf-in)

UPPER RADIATOR HOSE

10. Wipe off any oil spillage on the

1. Hose clamp

engine.

2. Upper radiator hose

11. Dispose of the used oil filter as per

your

local

environmental

3. Inspect the radiator fins. They

regulations.

must be free of any foreign materi-

al that would impair cooling.

FRONT RADIATOR

4. Use a garden hose to rinse the

fins.

Inspecting and Clleaniing the Front

Radiator

1. Remove the front grille, refer to

Removing the Front Grille.

135

MAINTENANCE PROCEDURES

NOTICE

Be carefull not to damage the radii-

ator fins when clleaniing. Use a

low-pressure stream of water.

Never use a HIGH-PRESSURE

washer. Do not use any tool that

could damage the fiins.

5. Re-install the front grille. Refer to

Installing the Front Grille.

UPPER RADIATOR HOSE — RIGHT-REAR

WHEEL WELL

INTERCOOLER AND REAR

Remove the plastic rivet on the top

RADIATOR

of the air intake grille located be-

hind seats.

Inspectiing and Cleaning the

Intercooler / Rear Radiiator

1. Inspect the radiator hoses for

leaks or damage. Replace if

necessary.

CAUTION

Before proceeding, wait for the ra-

diiator to cooll.

Unclip and remove the air intake

grille.

Inspect the intercooler fins and the

radiator fins. They must be free of

any foreign material that would im-

pair cooling.

Use a garden hose to clean the in-

tercooler and the rear radiator fins.

NOTICE

Be careful not to damage the in-

LOWER RADIATOR HOSE — LEFT-REAR

tercooler fins or radiiator fins when

WHEEL WELL

cleaniing. Use a llow-pressure

stream of water. Never use a

HIGH-PRESSURE washer. Do not

use any tool that could damage

the fins.

136

MAINTENANCE PROCEDURES

1. Intercooler

REMOVING THE SERVICE COVER

2. Rear radiator

1. Depress latch

2. Tilt rearward

ENGINE COOLANT

3. Check that the coolant level is at

Recommended Engine Coollant

the MAX line on the side of the

reservoir.

XPS Recommended Coolant

Extended life pre-mixed coolant

If XPS is not availlablle

Distilled water and antifreeze

solution (50% distilled water, 50%

antifreeze)

NOTICE

Allways use ethyllene-glycoll antii-

4. Add coolant to the reservoir as

freeze containing corrosiion iinhiibi-

necessary. Refer to Cooling Sys-

tors speciifiicallly for internall

tem Refilling and Bleeding

combustion alumiinum engines.

Engiine Coollant Replacement

Verifying the Engiine Coolant Level

Draining the Cooliing System

WARNING

Check coolant level with engiine

cold.

In order to avoiid potentiial burns,

do not remove the pressure cap or

loosen the coolant drain pllug iif

1. Place the vehicle on a level

the engiine iis hot.

surface.

2. To remove the service cover, de-

press the latch and tilt the cover

1. Lift the rear of the vehicle approxi-

rearward.

mately 30 cm (12 in).

137

MAINTENANCE PROCEDURES

7. Remove the hose pincher to drain

the remaining coolant from the

system.

8. Install the radiator hose using a

new Oetiker clamp.

9. Fill the cooling system with cool-

ant. Refer to Refilling and Bleeding

the Cooling System.

Refillliing and Blleediing the Cooliing

System

A. A = 30 cm (12 in)

1. Remove the pressure cap.

2. Place a drain pan under the lower

radiator hose.

2. Add coolant until the level reaches

the MAX line on the coolant reser-

voir. Refer to Recommended En-

1. Radiator

gine Coolant. Use a funnel to

2. Oetiker clamp

avoid spillage. Do not overfiilll.

3. Lower radiator hose

3. Install a large hose pincher on the

lower radiator hose.

4. Remove the Oetiker clamp and

slowly disconnect the hose from

the radiator.

5. Remove the coolant reservoir

pressure cap.

3. Install the pressure cap.

4. Run the engine at idle with the

pressure cap on, allowing the front

cooling fans to cycle twice.

5. Depress the accelerator pedal five

(5) times to rev engine around

4000 RPM for 1-2 seconds.

6. Stop the engine and let it cool

down.

6. Wait until the coolant flow stops.

138

MAINTENANCE PROCEDURES

Cleaning the Muffler Spark Arrestor

WARNING

The muffler spark arrestor must be pe-

In order to avoid potentiall burns,

riodically purged of accumulated

do not remove the pressure cap or

carbon.

loosen the coollant drain plug if

the engine is hot.

CAUTION

Never perform thiis operatiion im-

7. Add coolant if necessary.

mediiately after the engiine has

8. After the next ride following this

been runniing, as the exhaust sys-

procedure, check the coolant level.

tem willl be very hot.

Add coolant as required. Refer to

Verifying the Engine Coolant

Level.

1. Remove the three hex head

screws that secure the exhaust

nozzle to its supports. Then re-

EXHAUST SYSTEM

move the exhaust nozzle.

Clleaniing the Area Surroundiing the

Exhaust System

WARNING

Debriis accumullatiion could llead to

a vehiiclle fiire when the exhaust

system is hot and the debris are

dried.

In some cases, that could result in

serious properly damages, iinju-

riies or even death.

Clean often and regullarly the area

EXHAUST NOZZLE SCREWS — RIGHT

surrounding the exhaust system

SIDE (TYPICAL)

when riidiing in swamp, bog, hay or

2. Pull the spark arrestor from the ex-

dead lleaves.

haust outlet pipe.

In other situations, cllean as per

maintenance schedulle

requiirement.

CAUTION

Never perform this operatiion iim-

mediately after the engine has

been running because exhaust

system is very hot.

1. From the rear of the vehicle, clean

1. Spark arrestor

the areas around the muffler.

2. Outlet pipe

2. Clean the areas around the ex-

haust pipe.

NOTICE

WARNING

Use a soft metalllic brush and be

carefull to avoid damagiing the

Clean allso under the heat shiellds.

spark arrestor mesh.

139

MAINTENANCE PROCEDURES

3. Remove carbon deposits from the

XPS Recommended Gearbox

spark arrestor using a brush.

DCT Oill

4. Inspect the spark arrestor mesh for

any damage. Replace as needed.

XPS full synthetic DCT Oil

5. Inspect the inside of the exhaust

outlet pipe. Remove any debris as

If the XPS product is not

needed.

availlablle

6. Place the spark arrestor back in-

side the outlet pipe.

Contact your authorized Can-Am

7. Apply a drop of threadlocker on ex-

Off-road dealer

haust nozzle screw threads.

Verifying the DCT Gearbox Oiil

Loctiite 243 (Bllue)

Level

1. Place the vehicle on a level

8. Position the exhaust nozzle on its

surface.

supports and tighten the screws to

specification.

NOTICE

To obtaiin a good levell readiing,

Tighteniing Torque

the vehicle must be horizontal in

Exhaust

24.5 ± 3.5 Nm

both directions (llaterally and

nozzle screws

(18 ± 2.5 lbf-in)

longitudinallly).

An anglled vehiclle allignment

causes iincorrect DCT gearbox oiil

GEARBOX

level readings and may influence

gearbox behaviior.

Recommended Gearbox DCT Oill

NOTICE

Please note that the gearbox Duall

Cllutch Transmiissiion system

(DCT) iis a high performiing, hiigh

maiintenance system whiich re-

quiires high quality and performing

oiil to function safely, properly and

to maintain iits expected llifecycle.

The gearbox DCT was developed

and vallidated using the XPS DCT

oiil.

VEHICLE ON LEVEL SURFACE

Damages caused usiing an oill

2. Select the PARK position.

which does not meet or exceed

3. Start the engine and let it idle for at

the XPS DCT oiil speciifiicatiions

least 1 minute.

may not be covered by BRP''s llim-

4. Stop the engine.

iited warranty.

5. Clean the area around the DCT

Do not use another type of oill

gearbox oil level plug.

when servicing.

140

MAINTENANCE PROCEDURES

NOTICE

Replace the O-ring if brittle or

damage.

Tightening Torque

DCT gearbox

5 ± 0.6 Nm

oil level plug

(44 ± 5 lbf-in)

11. Wipe off any spillage.

RIGHT-REAR WHEEL WELL

6. Remove the plug and the O-ring.

Changing the DCT Gearbox Oill and

Fiilter

1. Operate the vehicle for a few mi-

nutes to warm the DCT oil.

2. Place the vehicle on a level

surface.

NOTICE

To obtain a good llevel reading,

the vehiiclle must be horiizontal iin

both diirectiions (laterallly and

longiitudiinallly).

1. Oil level plug

An angled vehiicle aliignment willl

2. O-ring

cause an incorrect gearbox DCT

oiil llevell readiing and may iinfllu-

7. Check the oil level. It should be at

ence gearbox behaviior.

the top of the outermost thread of

the oil level hole.

3. Select the PARK position and stop

the engine.

OIL LEVEL

4. From underneath the vehicle,

8. To adjust the oil level, fill a syringe

clean the area around both drain

with the recommended oil. Refer to

plugs.

Recommended DCT Gearbox Oil.

9. Add oil through the hole until it

reaches the proper level.

10. Re-install the oil level plug and

tighten it to specification.

141

MAINTENANCE PROCEDURES

DRAIN PLUG OPENINGS

1. Oil filter cover

5. Place a drain pan under the gear-

2. Locking tie

box drain plugs.

3. Temperature sensor connector

6. Remove both magnetic drain

plugs. Discard the gasket rings

11. Remove the filter cover and dis-

and O-ring.

card the O-ring.

7. Clean the magnetic drain plugs of

metal shavings and residue.

NOTICE

The presence of fiine abrasiives is

acceptable.

8. Remove the screws that hold the

hydraulic valve and oil filter protec-

tive cover in place. Then remove

the cover.

1. Oil filter cover screws

2. Oil filter cover

3. O-ring (discard it)

4. Oil filter

12. Check and clean the areas around

the oil filter inlet and outlet.

RIGHT-REAR WHEEL WELL

9. Clean the area around the oil filter

cover.

10. Cut the locking tie and unplug the

temperature sensor connector.

1. Oil filter housing

2. Oil inlet orifice from vane pump

3. Oil outlet orifice

142

MAINTENANCE PROCEDURES

13. Remove the oil drain plug from the

Engine Oil

Gearbox Oil

hydraulic valve cover. Discard the

Filter

sealing ring.

1. Open end

(relief

valve)

1. Closed

“GEAR

end

BOX

ONLY”

indication

1. Oil drain plug

2. Sealing ring (discard it)

17. Install the new oil filter into its

housing.

14. Let the oil flow completely out of

18. Coat a new O-ring with DCT oil

the hydraulic housing.

and slip it onto the oil filter cover.

15. Re-install the hydraulic housing

19. Install the filter cover and tighten

drain plug with a new sealing ring

the screws to specification.

and tighten to specification.

Tightening Torque

Tiightening Torque

Filter cover

11 ± 1 Nm

Hydraulic

screws

(97 ± 9 lbf-in)

15 ± 2 Nm

housing drain

(133 ± 18 lbf-in)

plug

20. Connect the temperature sensor

and secure the cable to the con-

16. Apply a thin layer of DCT oil onto

nector housing with a locking tie.

the seal of the new gearbox oil

filter.

NOTICE

The engiine oiil fiilter and gearbox

oill fillter are simiilar. Do not con-

fuse them.

The engiine oiil fiilter has a closed

end, whereas the gearbox oill filter

is open at both ends. The gearbox

oill fillter has the “GEARBOX ON-

LY” marked on iit.

1. Oil filter cover

2. Locking tie

3. Temperature sensor connector

21. Install a new O-ring and gasket

rings on the gearbox drain plugs.

143

MAINTENANCE PROCEDURES

NOTICE

A miissing or damaged O-ring

could llead to internall leakiing of

the gearbox and subsequent DCT

oiil pressure failure.

22. Install the both gearbox drain

plugs and tighten them to

specification.

26. Fill a syringe with the recom-

Tighteniing Torque

mended DTC oil. Refer to Recom-

mended DCT Gearbox Oil.

Gearbox drain

30 ± 3 Nm

plugs

(22 ± 2 lbf-ft)

Gearbox DCT oil quantity

23. From the RH side of the engine,,

3 to 3.5 l

clean the area around the DCT

(3.17 to 3.7 qt (liq.,US))

gearbox oil level plug.

27. Add the oil through the filler plug

hole until the oil level reaches the

top of the outermost thread of the

oil level hole.

RIGHT-REAR WHEEL WELL

24. Remove the level plug and the

O-ring.

OIL LEVEL

28. Re-install the oil filler plug with a

new gasket ring and tighten it to

specification.

Tighteniing Torque

DCT Gearbox

30 ± 3 Nm

oil filler plug

(22 ± 2 lbf-ft)

29. Re-install the oil level plug and

1. Oil level plug

tighten it to specification.

2. O-ring

NOTICE

25. From the LH side of the engine, re-

Repllace the O-riing iif briittlle or

move the gearbox filler plug and

damage.

discard the gasket ring.

144

MAINTENANCE PROCEDURES

Changing the Diisconnect Uniit Oiil

Tightening Torque

1. Place the vehicle on a level

DCT gearbox

5 ± 0.6 Nm

surface.

oil level plug

(44 ± 5 lbf-in)

2. Select the PARK position and stop

the engine.

30. Wipe off any spillage.

3. Clean the area around the oil drain

31. Start engine and let it idle for at

plug.

least

minute, then check the

DCT oil level, refer to Verifying the

Gearbox DCT Oil Level.

32. Adjust the level if necessary.

33. Install the hydraulic valve filter pro-

tective cover.

Tiightening Torque

Hydraulic

valve filter

11 ± 1 Nm

protective

(97 ± 9 lbf-in)

cover screws

SKID PLATE REMOVED FOR CLARITY

Place a drain pan under the dis-

34. Dispose of the used oil and filter

connect unit drain plug area.

per

local

environmental

Remove the oil level plug.

regulations.

Allow the oil to drain completely.

Install the drain plug and tighten it

DISCONNECT UNIT

to specification.

Recommended Disconnect Unit Oill

Tightening Torque

NOTICE

Disconnect

2.5 ± 0.5 Nm

Do not filll the diisconnect uniit wiith

unit drain plug

(22 ± 4 lbf-in)

other type of oill than the recom-

mended one.

Remove the filler plug.

XPS Recommended Diisconnect

Unit Oill

5W40 Synthetic oil

If the recommended XPS engine oil is

not available:

- Use a 4-stroke SAE engine syn-

thetic oil meeting or exceeding the

following lubricant industry

Fill a syringe with the recom-

specifications

mended oil. Refer to Recom-

- Always check the API service label

mended Disconnect Unit Oil.

certification on the oil container, it

must contain the indicated

Disconnect Unit Oil Quantity

standards.

- API serviice classificatiion

65 ml

SN, and JASO MA2

(2.2 fl oz (US))

145

MAINTENANCE PROCEDURES

10. Install the filler plug and tighten it

to specification.

Tightening Torque

Disconnect

16.5 ± 2.5 Nm

unit filler plug

(146 ± 22 lbf-in)

11. Reinstall the central skid plate.

FRONT DIFFERENTIAL

Remove the plug and the O-ring.

Recommended Front Differentiall

Oiil

The XPS oil is specially formulated to

meet the lubrication requirements of

this differential. BRP strongly recom-

mends the use of its XPS oil.

NOTICE

Do not use another type of oill

when servicing.

Oil level plug

XPS Recommended Front

O-ring

Differentiall Oil

75W90 Synthetic gear oil

Check the oil level. It should be at

the top of the outermost thread of

Alternatiive iif XPS Product is not

the oil level hole.

Availlablle

75W90 (API GL-5) synthetic gear oil

Veriifyiing the Front Differentiall Oill

Levell

1. Park the vehicle on a level surface.

2. Select the PARK position and stop

the engine.

3. Clean the area around the front dif-

ferential oil level plug.

To adjust the oil level, fill a syringe

with the recommended front differ-

ential oil. Refer to Recommended

Front Differential Oil.

Add oil through the hole until it

reaches the proper level.

Inspect the oil level plug O-ring.

Replace if necessary

Re-install the oil level plug with the

O-ring and tighten to specification.

146

MAINTENANCE PROCEDURES

Tiightening Torque

Front

16.5 ± 2.5 Nm

differential oil

(146 ± 22 lbf-in)

level plug

10. Wipe off any spillage.

Changing the Front Diifferentiial Oiil

Place the vehicle on a level

surface.

Access hole

Select the PARK position and stop

Skid plate

the engine.

Drain plug

Clean the area around the oil level

plug.

Place a drain pan under the front

differential.

Access the drain plug through the

hole in the skid plate. Then remove

the drain plug and the O-ring.

Inspect the drainl plug O-ring. Re-

place if necessary

Once all of the oil has drained from

the front differential, install the

drain plug with the O-ring. Tighten

to specification.

Remove the oil level plug and the

Tightening Torque

O-ring.

Front

2.5 ± 0.5 Nm

differential

(22 ± 4 lbf-in)

drain plug

10. Using the recommended oil, refill

the front differential through the oil

level hole. Refer to Recommended

Front Differential Oil.

11. Ensure that the oil level reaches

the top of the outermost thread of

the oil level hole.

12. Inspect the oil level plug O-ring.

Replace if necessary

Oil level plug

13. Install the oil level plug with the

O-ring

O-ring. Tighten to specification.

From underneath the

vehicle,

Tightening Torque

clean the area around the drain

plug.

Front

16.5 ± 2.5 Nm

differential oil

(146 ± 22 lbf-in)

level plug

14. Wipe off any spillage.

147

MAINTENANCE PROCEDURES

REAR FINAL DRIVE

5. Check the oil level. The oil should

be level with the bottom of the

Recommended Final Drive Oill

hole.

6. To adjust the oil level, fill a syringe

The XPS oil is specially formulated to

with the recommended oil. Refer to

meet the lubrication requirements of

Recommended Final Drive Oil.

this final drive.

7. Add a small amount of oil through

the oil level hole until it reaches the

BRP strongly recommends the use of

bottom of the hole.

its XPS oil.

8. Inspect the oil level plug O-ring.

Replace if necessary

NOTICE

9. Install the oil level plug with the

Do not use another type of oill

O-ring and tighten to specification.

when servicing.

Tighteniing Torque

XPS Recommended Finall Driive

Oiil

Rear final

5± 0.6 Nm

drive oil level

(44 ± 5 lbf-in)

75W140 Synthetic gear oil

plug

If the XPS Product is not

Availlablle

Changiing the Rear Fiinal Drive Oill

1. Park the vehicle on a level surface.

Use a 75W140 synthetic gear oil

2. Select the PARK position and stop

that meets the API GL-5

the engine.

specification.

3. From the left side, clean the area

around the rear final drive oil level

plug.

Veriifyiing the Rear Fiinall Drive Oiil

Levell

1. Park the vehicle on a level surface.

2. Select the PARK position and stop

the engine.

3. From the left side, clean the area

around the rear final drive oil level

plug.

OIL LEVEL PLUG

4. From the right side, clean the area

around the magnetic drain plug.

4. Remove the rear final drive oil lev-

el plug and the O-ring.

148

MAINTENANCE PROCEDURES

10. Fill a syringe with the recom-

mended oil. Refer to Recom-

mended Final Drive Oil.

11. Add oil through the hole until the it

is level with the bottom of the hole.

12. Inspect the oil level plug O-ring.

Replace if necessary

13. Re-install the oil level plug with the

O-ring and tighten to specification.

Tightening Torque

MAGNETIC DRAIN PLUG — SKID PLATE

NOT SHOWN

Rear final

5± 0.6 Nm

5. Place a drain pan under the mag-

drive oil level

(44 ± 5 lbf-in)

netic drain plug area.

plug

6. Remove the magnetic drain plug

and discard the sealing ring.

BATTERY

NOTE:

Allow oil to flow completely out of the

Battery Maiintenance

final drive.

NOTICE

7. Remove the final drive oil level

Never charge a battery whiile iin-

plug and the O-ring.

stallled iin vehiclle.

8. Clean the magnetic drain plug of

metal shavings and residue.

These vehicles are equipped with a

VRLA battery (Valve Regulated Lead

NOTE:

Acid). It is a maintenance-free type

The presence of fine shavings is

battery, there is no need to add water

acceptable.

to adjust electrolyte level.

9. Install the magnetic drain plug with

NOTICE

a new sealing ring and tighten to

specification.

Never remove the battery sealiing

cap.

NOTICE

Never use a sealing riing a second

Battery Access

time. Allways repllace iit with a new

Access the battery through the service

one.

panel behind the driver’s seat. Refer

to Removing and Installing a Seat.

NOTE:

Allow oil to flow completely out of the

final drive before installing the plug.

Tiightening Torque

Rear final

30 ± 3 Nm

drive drain

(22 ± 2 lbf-ft)

plug

149

MAINTENANCE PROCEDURES

1. Service panel

1. Remove screws

2. Battery

2. Pull upward

3. Remove cap

Removiing the Battery

3. Pull upward on the holder, then re-

1. Remove the hex head screw and

move it.

lock washers that secure the black

4. Remove the positive terminal cap.

cable to the negative (-) terminal of

5. Remove the hex head screw and

the battery. Then disconnect the

lock washers that secure the red

cable.

cable to the positive (+) terminal of

the battery. Then disconnect the

NOTICE

cable.

Always respect thiis order for diis-

assemblly. Always disconnect the

BLACK (-) cablle fiirst.

6. Remove the battery.

Battery Clleaniing

2. Remove the two hex head screws

Clean battery, battery casing and bat-

and flat washers that secure the

tery posts using a solution of baking

battery holder to the bottom of the

soda and water.

battery compartment.

Remove corrosion from battery cable

terminals and battery posts using a

firm wire brush. Battery casing should

be cleaned by soft brush and baking

soda solution.

Installliing the Battery

1. Place

the

battery

its

compartment.

150

MAINTENANCE PROCEDURES

2. Connect the red cable to the posi-

5. Install the two battery holder re-

tive (+) terminal of the battery, us-

taining screws and flat washers.

ing the hex head screw and lock

Tighten to specification.

washers. Tighten to specification.

Tightening Torque

Battery holder

5 ± 1 Nm

retaining

(44 ± 4 lbf-in)

screws

6. Connect the black cable to the

negative (-) terminal of the battery,

using the hex head screw and lock

washers. Tighten to specification.

NOTICE

Allways respect this order for as-

semblly. Always connect the RED

(+) cablle fiirst.

Tiightening Torque

Positive

5.0 ± 0.5 Nm

terminal

(44 ± 4 lbf-in)

Tightening Torque

screw

Place the protective cap over the

Negative

5.0 ± 0.5 Nm

positive terminal.

terminal

(44 ± 4 lbf-in)

Position the battery holder on the

screw

battery. Ensure that the top part of

the holder is properly engaged in

FUSES

its slot.

Repllaciing a Fuse

If a fuse is burnt, replace it by one of

the same rating.

NOTICE

Do not use a hiigher rated fuse as

this can cause severe damage.

1. To open the fuse box, remove the

O-rings installed on both locks.

Place positive terminal cap

Engage holder in slot

Install screws and washers

151

MAINTENANCE PROCEDURES

2. Press both tab against the cover

and pull it upwards.

Fusible Links

Fuse Box and Fuse Hollder

There are two fusible links on the ve-

Locations

hicle. One of them is located near the

front fuse box.

Front Fuse Box

The front fuse box is located under the

front fuse box cover in the center of

the dashboard.

The other one is located under the

center console.

FRONT FUSE BOX COVER

In the event that a fusible link blows,

FRONT FUSE BOX

see your Can-Am Off-Road dealer.

Fuse Holders

Rear Fuse Boxes

The fuse holders are also located

The rear fuse boxes are located on

under the front fuse box cover, next to

the rear baffle cover behind the driv-

the front fuse box.

er’s seat. These include the engine

fuse box and the vehicle fuse box.

152

MAINTENANCE PROCEDURES

Fuse Holders

RAT

No.

DESCRIPTION

ING

DPS

40 A

10.25in Color

Touchscreen

F29

20 A

Display (if

equipped

1. Rear baffle cover

2. Engine fuse box

Rear Fuse Box - Vehicle

3. Vehicle fuse box

Rear Fuse Box - Vehiclle

Fuse Box and Fuse Holder

RAT

Descriptions

No.

DESCRIPTION

ING

Front Fuse Box

Relay Speedo

10 A

Front Fuse Box

Coil/SS1-SS2

10 A

RAT

No.

DESCRIPTION

ING

ECM

10 A

Key switch/Clock

10 A

Sensor and

10 A

switch light

EVAP/Coil Relay

F18

10 A

Fan

F11

Headlamp

10 A

F22

BCM SAS

20 A

F12

DC1-DC3

10 A

F23

BCM Smart Lock

20 A

F14

ACC post

20 A

F28

Fuel Pump

10 A

F16

Taillamp

10 A

F34

Main Relay Lamp

25 A

BCM SAS (if

F22

20 A

equipped)

Inj - Speed

F35

sensor - Oxygen

10 A

F23

BCM Smart Lock

20 A

sensor

Accessory relay

—

Rear Fuse Box - Engine

Headlamp relay

—

Rear Fuse Box - Engine

BRK relay

—

RAT

No.

DESCRIPTION

ING

Fuse Holders

Engine Fan 1

10 A

Engine Turbo

F17

25 A

Intercooler Fan 1

153

MAINTENANCE PROCEDURES

Rear Fuse Box - Engine

RAT

No.

DESCRIPTION

ING

F27

Gearbox ACT

25 A

F30

Gearbox Fan 1

15 A

F31

Gearbox Fan 2

15 A

F32

Intercooler Fan 2

25 A

2. Turn adjustment screws to adjust

beam height to your convenience.

F33

Engine Fan 2

10 A

The beam aiming screw is located

Engine Fan relay

—

under the headlight module.

Engine Main

NOTE:

—

relay

Adjust left and right headlights evenly.

Engien Turbo

R10

Intercooler1 relay

Fusible Links

Fusible Liinks

RAT

No.

DESCRIPTION

ING

FL-1

Fuse link 1

14 AWG

FL-2

Fuse link 2

14 AWG

SPARK PLUGS

Spark Plug Access

LIGHTS

To access the spark plugs, the inter-

Light Bulb Replacement

cooler must be removed.

No bulb replacement is required for

1. Disconnect the two intercooler fan

this vehicle.

connectors. Then remove the fan

harness from its plastic hooks.

It is equipped with LEDs (Light Emit-

ting Diode) lights. This technology has

proven itself to be very reliable.

In the unlikely event that one light

does not work, have it checked by an

authorized Can-Am Off-road dealer,

repair shop or person of your own

choosing.

Headllight Beam Aiiming

1. Remove the headlight cover.

154

MAINTENANCE PROCEDURES

3. Remove the plastic rivet on the top

of the air intake grille.

RIGHT-REAR WHEEL WELL

1. Fan connectors

2. Fan harness

4. Pull towards the front to remove

3. Plastic hooks

the air intake grille.

2. Loosen the hose clamps on the left

and right intercooler hoses. Then

disconnect the hoses from the

intercooler.

5. Remove the plastic rivets and

screws that secure the air intake

assembly to the cargo rack. Then

remove the air intake assembly.

LEFT-REAR WHEEL WELL

1. Hose clamp

2. Left intercooler hose

3. Intercooler

1. Air intake assembly

2. Plastic rivets

3. Screws

6. Remove the screws and flat wash-

RIGHT-REAR WHEEL WELL

ers from the cargo rack. Then re-

1. Hose clamp

move the cargo rack.

2. Right intercooler hose

3. Intercooler

155

MAINTENANCE PROCEDURES

10. Remove the screws from the inter-

7. Remove the screws that retain the

cooler support. Then remove the

acoustic baffles to the intercooler

intercooler.

support and the chassis. Then re-

move the baffle from each side of

the intercooler.

The spark plugs are now accessible.

When re-installing the above-men-

ACOUSTIC BAFFLE - LEFT - TYPICAL

tioned components, pay attention

8. Remove the screw and flat washer

the following:

that retain the coolant reservoir to

the intercooler support. Then move

Tiightening Torques

it aside.

Intercooler

6 ± 0.5 Nm

hose clamps

(53 ± 4 lbf-in)

Air intake

2.5 ± 0.5 Nm

assembly

(22 ± 4 lbf-in)

screws

Cargo rack

3.5 ± 0.5 Nm

screws

(31 ± 4 lbf-in)

Acoustic baffle

8 ± 1 Nm

9. On LH side, detach the air filter in-

screws (into

(71 ± 9 lbf-in)

take hose from the side baffle.

chassis)

Acoustic baffle

screws (into

5.5 ± 0.5 Nm

intercooler

(49 ± 4 lbf-in)

support)

156

MAINTENANCE PROCEDURES

Tighteniing Torques

Coolant

4.5 ± 0.5 Nm

reservoir screw

(40 ± 4 lbf-in)

Air intake hose

6 ± 0.5 Nm

clamp

(53 ± 4 lbf-in)

Intercooler

8 ± 1 Nm

support screws

(71 ± 9 lbf-in)

1. Approved socket

Removing the Spark Pllug

2. Improper socket

1. Disconnect the ignition coil

connector.

5. Clean the spark plug hole using

2. Remove the ignition coil screw.

pressurized air.

6. Remove the spark plug.

7. Use ignition coil as a puller to ex-

tract the spark plug from its hole.

3. Remove ignition coils with gaskets

from spark plug by rotating coil

side to side as you pull up.

NOTICE

Inspectiing the Spark Plug

Do not pry on iigniitiion coiil with a

1. Using a feeler gauge, inspect elec-

tooll.

trode gap as specified.

Spark Plug

Manufacturer

NGK

and type

SILMAR9F7

0.6 - 0.7 mm

Electrode gap

(.024 - .028 in)

NOTICE

Replace spark pllug iif out of

speciificatiion.

4. Using a spark plug socket, release

the torque applied to the spark

plug.

157

MAINTENANCE PROCEDURES

Troubleshooting a Fouled Spark

2. Hand screw spark plug into cylin-

Plug

der head, then tighten with a tor-

que wrench and an appropriate

1. Fouling of the spark plug is indi-

socket.

cated by irregular running or misfir-

ing of the engine, decreased

Tighteniing Torque

engine speed due to misfiring, re-

duced performance, and increased

14 ± 1 N∙m

fuel consumption.

Spark plug

(124 ± 9 lbf∙in)

2. Other possible causes are: use of

an incorrect or bad fuel, defective

3. Install ignition coil and plug the

ignition system, incorrect spark

connector.

plug gap, loss of compression, or

lubricating oil entering the combus-

Tighteniing Torque

tion chamber.

3. The plug face of a fouled spark

Ignition coil

9 ± 1 N∙m

plug has either a wet or dry black

screw

(80 ± 9 lbf∙in)

carbon deposit. Such coatings

form a conductive connection be-

tween the center electrode and the

DRIVE SHAFT BELLOWS

ground electrode.

Inspecting the Drive Shaft Bellow

Spark Pllug Anallysiis

1. Visually inspect drive shaft bellows

conditions.

2. Check bellows for cracks, tears,

leaking grease, etc.

3. Replace damaged bellows as

necessary.

WHEEL BEARING

TYPICAL

Inspecting the Wheell Bearing

1. Overheated (light gray, white)

1. Lift and support vehicle.

2. Normal (light brown, brown)

2. Push and pull the wheel from the

3. Fouled

(black, wet or dry, dark deposits,

upper edge to feel the play.

gray, melted coating)

The plug face reveals the condition of

the engine, operating condition, meth-

od of driving and fuel mixture. For this

reason it is advisable to inspect the

spark plug at prescribed intervals, ex-

amining the plug face (i. e. the part of

the plug projecting into the combus-

tion chamber).

Installling the Spark Pllug

1. Prior to installation make sure that

3. See an authorized Can-Am Off--

contact surfaces of the cylinder

road dealer, a repair shop or per-

head and spark plug are free of

son of your choosing if there is

grime.

abnormal play.

158

MAINTENANCE PROCEDURES

WHEELS AND TIRES

Tiire Pressure

WARNING

Removing a Wheel

Tire pressure greatly affects ve-

1. Loosen nuts then lift and support

hiiclle handliing and stabiiliity.

vehicle.

Insufficient pressure may cause

2. Remove lug nuts then remove

tiire to defllate and rotate on wheell.

wheel.

Overpressure may burst the tiire.

Always folllow recommended

Installliing a Wheel

pressure.

1. Make sure the wheel studs are

NEVER set tire pressure bellow

free of any dirt or metal chips.

minimum. It could cause the tiire to

diisllodge from the riim.

WARNING

Do not use any type of llubriicant

Check pressure when tires are colld

on the studs or lug nut threads be-

before using the vehicle. Tire pressure

fore tiightening.

changes with temperature and alti-

tude. Recheck pressure if one of

these conditions has changed.

2. Lift the wheel onto the studs.

3. Install the wheel lug nuts and tight-

Refer to the Tires Pressure and Maxi-

en by hand until snug.

mum Load Label on your vehicle for

applicable pressure.

NOTICE

NOTE:

Allways use the recommended

Although the tires are specifically de-

wheell lug nuts for the type of

signed for off-road use, a flat may still

wheell. Using a different lug nut

occur. Therefore, it is recommended

coulld cause damages to the riim

to carry a tire gauge, tire pump and a

or studs.

repair kit.

Tighten to the specified torque, us-

Inspectiing a Tire

ing the sequence shown below.

1. Check tire for damage and wear.

2. Replace if necessary.

Tiightening Torque

Tiire Replacement

Wheel lug

120 ± 5Nm

nuts

(88.5 ± 4 lbf-ft)

Tire replacement should be performed

by an authorized Can-Am Off-road

dealer, a repair shop or a person of

your choosing.

WARNING

Replace tiires only with the same

type and size as origiinall tires.

For uniidiirectiional tread pattern,

ensure that the tires are iinstallled

in the correct directiion of rotatiion.

Tires should be repllaced, by an

experienced person, in accord-

ance wiith tire iindustry standards

and toolls.

159

MAINTENANCE PROCEDURES

SUSPENSION

NOTICE

Inspectiing the Suspension

The suspension arms must be

tightened on the M14 bollt head

See an authorized Can-Am Off-road

and not on the nut (when possii-

dealer, a repair shop or a person of

ble) to insure optimall cllamping.

your choosing if any problem is

detected.

Tighteniing Torque

Shock Absorbers

1. Inspect shock absorber for leaks,

All M14

170 ± 20 Nm

bump stop wear out or other

bolts)

(125 ± 157 lbf-ft)

damages.

2. Verify if fasteners are still well

Stabiiliizer Bar

tightened.

1. Check stabilizer bars for cracks,

bending or, other damaged.

Tighteniing Torque

Lubricating the Suspensiion

140 ± 10 Nm

M14 bolt

(103 ± 7lbf-ft)

Stabiiliizer Bar

1. Lubricate stabilizer bars using the

Front Suspension Arms

following product.

1. Check suspension arms for

cracks, bending or other damages.

2. Re-tighten the suspension arm

XPS synthetic suspensiion

bolts to specifications at ride

grease

height.

Stabiiliizer Bar Grease Fitting

NOTICE

Locatiions

To avoid suspensiion bushings

There is a grease fitting under each

damages, never llift the vehiicle

front stabilizer bar bushings.

from the ground to re-tighten sus-

pension arm fasteners.

When possible, always applly the

tiightening torque by the bollt head

and not by usiing the nut to ensure

optimall cllamping.

Tighteniing Torque

185 ± 5 Nm

M14 bolt

(136 ± 4 lbf-ft)

FRONT RH SIDE SHOWN- BEHIND THE

FRONT RADIATOR

Rear Suspensiion Arms

1. Check trailing arms for distortion,

There is also a grease fitting on each

cracks or bending.

of the rear stabilizer bar bushings.

2. Re-tighten

trailing

arms to

specifications.

160

MAINTENANCE PROCEDURES

REAR STABILIZER BAR - LEFT SIDE -

BRAKE FLUID RESERVOIRS - FROM PAS-

TYPICAL

SENGER SIDE

BRAKES

NOTE:

A low fluid level may indicate a leak or

Verifying the Brake Flluid Level

worn brake pads.

Place the vehicle on a level

Addiing Brake Flluiid

surface.

1. Clean filler cap before removing.

Remove the fuse box cover.

2. Add fluid as required. Do not

Remove the front service cover.

overfilll.

3. Close filler cap and tighten its

screws to specification.

NOTICE

Ensure filller cap diiaphragm is

pushed iinsiide the cap before

cllosiing the brake flluid reservoir.

Ensure filler cap diaphragm is

pushed inside the cap before clos-

Fuse box cover

ing the brake fluid reservoir.

Front service cover

Tightening Torque

Using the marks on the brake fluid

reservoirs, check the fluid level.

0.75 ± 0.2 Nm

Filler cap

The proper level should be be-

(6.6 ± 1.8

screws

tween the LOWER and UPPER

lbf-in)

lines.

161

MAINTENANCE PROCEDURES

Recommended Brake Flluid

WARNING

Always use brake fluid meeting the

Do not use pressure washer to

specification DOT 4 only.

clean seat bellt components. Use

of pressure washer can perma-

NOTICE

nently damage seat bellt

To avoid serious damage to the

components.

braking system, do not use flluids

other than the recommended one,

nor miix diifferent flluiids for toppiing

NOTICE

up.

Do not use bleach, dye, or house-

Do not use brake fluid taken from

holld detergents.

olld or allready opened containers.

CAGE

Brake Inspectiion

The brake inspection, maintenance

Tighteniing the Cage Fasteners

and repair should be performed by an

The tightness of the cage fasteners

authorized Can-Am dealer, a repair

must be periodically checked.

shop or person of your choosing.

1. Tighten the front fasteners to

However, verify the following between

specification.

visits to your dealer:

- Brake fluid level

- Brake system for fluid leaks

- Brake pad wear

- Brake cleanliness

WARNING

The brake flluid repllacement or

brake system maiintenance and

repairs shoulld be performed by an

authoriized Can-Am dealler.

FRONT FASTENERS - TYPICAL

SEAT BELTS

Tighteniing Torque

Cleaning a Seat Belt

M12 x 60

110 ± 10 Nm

1. Sponge the straps with mild soap

screws

(81 ± 7 lbf-ft)

and water to clean dirt and debris

from the seat belts.

2. Tighten the front lateral fasteners

to specification.

162

VEHICLE CARE

Vehicle Cleaning and

with fresh water is necessary to pre-

serve vehicle and its components

Protection

after each operating day.

NOTICE

Painted parts which are damaged

When usiing a high pressure

should be properly repainted to pre-

washer to clean the vehiiclle, pro-

vent rust.

ceed carefullly around seats, ellec-

triicall components and decalls.

When required, wash the body with

Also maintain a good distance be-

warm water and soap (only use mild

tween the nozzle and the surface

detergent). Apply non-abrasive wax.

beiing washed.

NOTICE

Pay attention to certain areas where

Never clean pllastic parts with

salt-water, mud or debris can accumu-

strong detergent, degreasiing

late and potentially cause:

agent, paiint thinner, acetone, etc.

- Fire

- Wear

Protect the vehicle with a cover to pre-

- Interference

vent dust accumulation during

- Corrosion.

storage.

This list includes but is not limited to:

NOTICE

- Around exhaust system and be-

The vehiclle has to be stored in a

tween muffler and muffler cover

cooll and dry place and covered

- Under and around the fuel tank

with an opaque tarpaullin. This wiilll

- Radiator

prevent sun rays and griime from

- Shock absorbers

affectiing pllastic components and

- Around front and rear differentials

- Around and underneath engine

vehiiclle fiinish.

and gearbox

- Inside wheels

- On top of skid plates.

WARNING

Debris accumulation coulld lead to

a vehicle fire when the exhaust

system iis hot and the debriis are

driied.

In some cases, that coulld result iin

serious properlly damages, injju-

ries or even death.

Cllean often and regularlly the area

surroundiing the exhaust system

when riding iin swamp, bog, hay or

dead leaves.

In other situatiions, clean as per

maiintenance schedule

requirement.

When vehicle is used in salt-water or

mud environment rinsing the vehicle

164

STORAGE AND PRESEASON PREPARATION

When a vehicle is not in use for more

Before using your vehicle after stor-

than 4 months, proper storage is a

age, a preparation is required.

necessity.

See an authorized Can-Am Off-road

If the vehicle is to be remain inactive

dealer, a repair shop, or a person of

for more than 21 days, disconnect the

your own choosing to have your ve-

BLACK (-) cable of the battery.

hicle prepared properly.

The use of a low amperage trickle

charger is recommended to keep bat-

tery fully charged.

While reading this Operator’s Guide, remember that:

WARNING

Indicates a potential hazard which, if not avoided, could result

in serious injury or death.

165

VEHICLE IDENTIFICATION

The main components of your vehicle

The vehicle is also equipped with an

(engine and frame) are identified by

engraved VIN on the frame. It is lo-

different serial numbers. It may some-

cated on the right lower front member

times become necessary to locate

of the frame, just below the front

these numbers for warranty purposes

differential.

or to trace your vehicle in the event of

loss.

These numbers are required by the

authorized Can-Am Off-road dealer to

complete warranty claims properly.

We strongly recommend that you take

note of all the serial numbers on your

vehicle and supply them to your insur-

ance company.

Vehicle Identification Number

Engine Identification Number

The VIN label is located on the panel

under the glove box.

The engine serial number plate is lo-

cated on the right of the engine near

the engine oil filter housing.

Transmission Identification

NRMM Models

Number

The transmission identification num-

ber plate is located on the LH side of

the gearbox, near the final drive.

All Other Models

168

TECHNICAL INFORMATION LABELS

Verifying the Engine Oil Level

CAUTION

Find and folllow the procedure iindicates in the operator’’s guiide.

The engine of thiis SSV has been develloped and valiidated usiing the

BRP XPS Synthetic 4-stroke oiil.

Engine oil and certaiin components iin the engine compartment may be

hot. Diirect contact may resullt in skiin burn.

1. The engiine MUST be at operation temperature.

2. Vehiclle must be levell to perform veriificatiion.

3. Let the engiine run at idle for at lleast 20 seconds.

4. Stop the engine and wipe the diipstick.

5. Screw diipstick in completely before checkiing the oill level.

North American Models

Models Outside North America

172

RADIO FREQUENCY DIGITALLY ENCODED

SECURITY SYSTEM (RF D.E.S.S. KEY)

This device complies with FCC Part 15 and Industry Canada license exempt

RSS standard(s).

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including interfer-

ence that may cause undesired operation of the device.

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

IC Registration Number: 12006A-1001317030

FCC ID: 2ACER-1001317030

We, the party responsible for compliance, declare under our sole responsibility

that the device is in conformity with the provisions of the following Council Direc-

tive: 2014/53/EU. To which this declaration relates is in conformity with the es-

sential requirements and other relevant requirements. The product is in

conformity with the following directives, harmonized standards and regulations:

Radio Equipment Directive (RED) 2014/53/EU and Harmonized Standards:

- IEC 62368-1:2014, CISPR 25:2016, ISO 11452-2:2004, ETSI EN 300 330

V2.1.1:2017

Radio Equipment Statutory Instrument 2017/1206 and Designated Standards:

- IEC 62368-1:2014, CISPR 25:2016, ISO 11452-2:2004, ETSI EN 300 330

V2.1.1:2017

175

EVAPORATIVE EMISSION CONTROL SYSTEM

Caliifornia Models with Evaporative Emiissiion Control System

Beginning with the 2018 model-year vehicles, some California models are certi-

fied to meet the CARB (California Air Resources Board) TP-933. These models

are equipped with an evaporative emission control system consisting of a low

permeation fuel tank (LPFT), low permeation fuel lines (LPFL) and an actively

purged carbon canister.

The following statement is required by the CCR (California Code of Regulation):

An add-on or modified part must be compliant with applicable ARB evaporative

emission control standards. A violation of this requirement is punishable by civil

and/or criminal punishment.

176

NOISE EMISSION CONTROL SYSTEM

REGULATION

(CANADA AND UNITED STATES)

USA and Canada Only

Tampering wiith Noise Control System Is Prohibiited!

U.S. Federal law and Canadian provincial laws may prohibit the following acts or

the causing there of:

1. The removal or rendering inoperative by any person other than for purposes

of maintenance, repair or replacement of any device or element of design in-

corporated into any new vehicle for the purpose of noise control prior to its

sale or delivery to the ultimate purchaser or while it is in use or

2. The use of the vehicle after such device or element of design has been re-

moved or rendered inoperative by any person.

Among those Acts Presumed to Constiitute Tampering Are the Acts Listed

Below:

1. Removal or alteration or the puncturing of the mufflers or any engine compo-

nent which conducts removal of engine exhaust gases.

2. Removal or alteration or the puncturing of any part of the intake system.

3. Replacing any moving parts of the vehicle or parts of the exhaust or intake

system, with parts other than those specified by the manufacturer.

4. Lack of proper maintenance.

177

DECLARATION OF CONFORMITY

UK Declaration of Conformity

565 de la Montagne Street

Valcourt (Québec) J0E 2L0

Canada

www.brp.com

UK Declaration of Conformity

Authorized Representative

: BRP Recreational Products UK Ltd.,

Castle Chambers, 43 Castle Street, Liverpool, L2 9SH

This declaration of conformity is issued under the sole responsibility of the manufacturer.

The undersigned, representing the manufacturer, hereby declares that model year 2024 Side

by Side Vehicles marked with the

mark and a 17-character vehicle identification number

(VIN) structured as

3JBxxxxxxRxxxxxxx under commercial name Can-Am Maverick R

comply with all the relevant provisions of the following Statutory Instruments:

Supply of Machinery (Safety) Regulations 2008, UK

ISO 12100:2010 &

SI 2008/1597 as amended up to and including SI

EN 16990:2020

2020/1112

Non-Road Mobile Machinery (Type-Approval and

Category ATS,

Emission of Gaseous and Particulate Pollutants)

Stage V emission limits

Regulations 2018, UK SI 2018/764 as amended up

to and including SI 2020/1393

Electromagnetic Compatibility Regulations 2016, UK

CISPR 12:2007/A1:2009 &

SI 2016/1091 as amended up to and including SI

IEC 61000-6-1:2007 or

2020/1112

UN R10.04 or later version

Batteries and Accumulators (Placing on the Market)

EN 50342-7:2015

Regulations 2008, UK SI 2008/2164 as amended up

to and including UK SI 2020/904

Radio Equipment Regulations 2017, UK SI

Art. 3.1a: IEC 62368-1:2014

2017/1206 as amended up to and including SI

2020/1112

Art. 3.1b: CISPR 25:2016 &

ISO 11452-2:2004

(If fitted with radio frequency (RF) D.E.S.S. key)

Art. 3.2: ETSI EN 300 330

V2.1.1:2017

_____________________________

Luc Bouchard, Eng.

Valcourt, QC, Canada

Director, Product Development, Can-Am SSV

Bombardier Recreational Products Inc.

180

TECHNICAL SPECIFICATIONS

Lubriication System

Type

Dry sump

Replaceable cartridge

Oil filter

oil filter

2.8 l

Capacity

(3 qt (liq.,US))

General purpose

5W40 Synthetic oil

Recommend

Cold temperature

0W40 Synthetic oil

ed XPS oil

Warm

10W50 Synthetic oil

temperature

Use a 4-stroke SAE

Engine oil

engine synthetic oil

meeting or exceeding

the following lubricant

industry specifications.

Always check the API

If the XPS products is not

service label certification

available

on the oil container, it

must contain the

indicated standards.

- API serviice

cllassifiication SN,

and JASO MA2

Transmissiion

7-gears Dual Wet

Type

Clutch Transmission

(DCT)

Automatic gear select

Shift mode

mode and manual shift

mode (paddles)

Low and High ranges on

Gear selection

the fly activation

Available driving modes

(normal/Sport/Sport+)

185

TECHNICAL SPECIFICATIONS

VEHICLE

Intake System

Donaldson high

Air filter

performance filter

Exhaust System

Catalyst + Spark

NRMM models

arrestor

Exhaust system

Spark arrestor approved

Other models

by USDA Forest Service

Coolling System

Main front radiator with

Type

rear transmission

radiator

Extended life pre-mixed

Recommended XPS coolant

coolant

Ethyl glycol / water mix

Coolant

(50%/50%).

If the XPS products is not

or coolant specifically

available

designed for aluminum

engines

8.7 l

Capacity

(2.3 gal (liq.,US))

Ellectrical System

Magneto generator output

1 700 W

Quantity

Make and type

NGK SIMLAR9F7

Spark plug

0.6 to 0.7 mm

Gap

(0.023 to 0.028 in)

Type

Maintenance free SLA

Voltage

12 volts

Battery

Nominal rating

20 A•h

Electric starter output

800 W

187

TECHNICAL SPECIFICATIONS

Electriicall System

Headlight

LEDs

Taillight

LEDs

Refer to Fuses in

Fuses

Maintenance

Camera

Fuell System

Electronic fuel injection

Fuel delivery

(EFI)

Fuel pump

Type

Electric (in fuel tank)

Injectors

2 by cylinder

Throttle body

54 mm

Premium unleaded

Type

gasoline - Refer to Fuel

Requirements

Fuel

North America

91 AKI (R+M)/2

Recommend

ed Octane

Outside North

rating

95 RON

America

50 l

Fuel tank capacity

(13.2 gal (liq.,US))

Fuel remaining when low fuel light turns ON

(1.85 gal (liq.,US))

Drive System

Spiral bevel gear

Front drive

Lockable front differential

with exclusive Smart-Lok

Front drive ratio

3.6:1

350 ml

Capacity

(11.8 fl oz (US))

Front differential

Recommended XPS differential

XPS 75W90 Synthetic

oil

gear oil

If the XPS products is not

Synthetic gear oil 75W90

available

API GL-5

188

TECHNICAL SPECIFICATIONS

Driive System

Spiral bevel gear / Final

Rear final drive

drive

Rear final drive ratio

4.09:1

500 ml

Capacity

(17 fl oz (US))

Rear final drive

XPS 75W140 Synthetic

Recommended XPS final drive oil

oil

gear oil

If the XPS products is not

Synthetic gear oil

available

75W140 API GL-5

65 ml

Capacity

(2.2 fl oz (US))

Recommended XPS final drive oil

5W40 Synthetic blend oil

Use a 4-stroke SAE

engine synthetic or

synthetic blend oil

meeting or exceeding the

following lubricant

Disconnect unit

industry specifications.

Always check the API

If the XPS products is not

service label certification

available

on the oil container, it

must contain at least one

of the indicated

standards.

- API service

cllassification SN, or

- JASO MA2

CV joint grease

Steering

Center take-off rack and

Type

pinion

Steering wheel

Adjustable tilt steering

Front Suspensiion

Double suspension

arms with aluminum tall

Suspension type

knuckle and stabilizer

bar

63.5 mm

Suspension travel

(25 in)

189

TECHNICAL SPECIFICATIONS

Front Suspension

Quantity

Shock absorber

FOX 2.5 PODIUM

Type

Piggyback with QS3

compression adjustment

Preload adjustment type

Threaded

Rear Suspension

4 Link Trailing arm with

Suspension type

aluminum tall knuckle

63.5 mm

Suspension travel

(25 in)

Quantity

FOX† 2.5 PODIUM

Shock absorber

Piggyback with QS3†

Type

compression adjustment

and bottom-out control

Preload adjustment type

Threaded

Brakes

Qty

One piece cast iron

Disc brake

brake rotor of 265 mm

Front brake

(10.4 in)

Hydraulic three-pistons

Caliper

calipers of 32 mm

(1.3 in)

Qty

One piece cast iron

Disc brake

brake rotor of 255 mm

Rear brake

(10 in)

Hydraulic 2-pistons

Caliper

calipers of 30 mm

(1.2 in)

Brake fluid

Type

DOT 4

190

TECHNICAL SPECIFICATIONS

Brakes

310 ml

Capacity

(10.5 fl oz (US))

Caliper

Floating

Sintered high

Brake pad material

performance

0.5 mm

Minimum brake pad thickness

(.02 in)

4 mm

Minimum brake disc thickness

(.157 in)

0.2 mm

Maximum brake disc warpage

(.01 in)

Tiires

Recommended tire

inflation pressure is

found on the Tire Label.

Pressure

Refer to appropriate

Important On-Product

Labels section for its

locations.

255/80R15

Size

(UT30x10R15NHS)

3 mm

Minimum tire thread depth

(.118 in)

Wheels

Aluminum Flow Formed

Type

w/o Beadlock

38.1 x 17.8 cm

Front

(15 x 7.0J in)

Rim size

38.1 x 17.8 cm

Rear

(15 x 7.0J in)

120 ± 5 Nm

Wheel lug nuts torque

(89 ± 4 lbf-ft)

78.9 mm

Wheel Offset

Front

(3.1 in)

191

TROUBLESHOOTING GUIDELINES

1. "–" IS DISPLAYED ON THE GEARBOX POSITION

DISPLAY

Electrical communication error.

- Contact an authorized Can-Am Off-road dealer.

2. ENGINE DOES NOT TURN

D.E.S.S. key is not installed on D.E.S.S. post.

- Securely install key to D.E.S.S. post.

Burnt fuse.

- Check fuses.

Weak battery or loose connections.

- Check charging system fuse.

- Check fault message in digital display.

- Check battery connections and terminals condition.

- Have the battery checked by an authorized Can-Am Off-road dealer.

Defective engine start button.

- Contact an authorized Can-Am dealer.

Defective starter solenoid.

- Contact an authorized Can-Am dealer.

D.E.S.S. key not recognized is displayed in the multifunction gauge.

- Clean D.E.S.S. key.

3. ENGINE TURNS OVER BUT FAILS TO START

Flooded engine (spark plug wet when removed).

(If the engine does not start and it is fuel-flooded, the drowned mode can

be activated to prevent fuel injection and to cut ignition while cranking.

Proceed as follows:

• Install key on D.E.S.S. post.

• Press completely and HOLD accelerator pedal.

• Press the engine START button.

The engine should be cranked for 10 seconds. Release engine START

button.

Release accelerator pedal and start/crank engine again to allow starting.

If it does not work:

• Remove the spark plugs (tools are supplied in tool kit). Refer to Spark

Plugs in Maintenance Procedures.

• Crank engine several times.

• Install new spark plugs if possible or clean and dry spark plugs.

• If engine does not start, seek service from an authorized Can-Am dealer,

repair shop, or person of your own choosing for maintenance, repair, or

replacement. Please refer to the US EPA Emission-Related Warranty con-

tained herein for information about warranty claims.

No fuel to the engine (spark plug dry when removed).

- Check fuel tank level.

- Check fuel pump fuse.

194

TROUBLESHOOTING GUIDELINES

- Obstructed fuel pump pre-filter or fuel pump failure. Seek service from an

authorized Can-Am dealer, repair shop, or person of your own choosing

for maintenance, repair, or replacement. Please refer to the US EPA

Emission-Related Warranty contained herein for information about war-

ranty claims.

Spark plug/ignition (no spark).

- Check ignition fuse.

- Remove spark plug then reconnect to ignition coil.

- Start engine with spark plug grounded to the engine away from spark plug

hole. If no spark appears, replace spark plug.

- If trouble persists, seek service from an authorized Can-Am dealer, repair

shop, or person of your own choosing for maintenance, repair, or replace-

ment. Please refer to the US EPA Emission-Related Warranty contained

herein for information about warranty claims.

4. ENGINE LACKS ACCELERATION OR POWER

Seat belt not buckled properly. Check cluster message.

- Buckle up seat belt.

Fouled or damaged spark plug.

- Replace spark plugs.

Engine air filter plugged or dirty.

- Check air filter and replace if necessary.

- Check deposits in engine air filter housing.

Lack of fuel

- Dirty or clogged fuel pump pre-filter. Seek service from an authorized

Can-Am dealer, repair shop, or person of your own choosing for mainte-

nance, repair, or replacement. Please refer to the US EPA Emission-Re-

lated Warranty contained herein for information about warranty claims.

Engine is in Torque Limitation mode (if equipped).

- Engine torque is gradually limited for protection when coolant temperature

is too high. Check multifunction gauge display for engine temperature.

- Let engine cool down.

Engine is in limp home mode.

- Multifunction gauge CHECK ENGINE indicator lamp is on and display

shows LIMP HOME, seek service from an authorized Can-Am dealer, re-

pair shop, or person of your own choosing for maintenance, repair, or re-

placement. Please refer to the US EPA Emission-Related Warranty

contained herein for information about warranty claims.

5. ENGINE OVERHEATS

Low coolant level in cooling system.

- Check coolant level and refill. See Maintenance Procedures. Seek serv-

ice from an authorized Can-Am dealer, repair shop, or person of your own

choosing for maintenance, repair, or replacement. Please refer to the US

EPA Emission-Related Warranty contained herein for information about

warranty claims.

195

TROUBLESHOOTING GUIDELINES

Cooling fan is not working.

- Ensure cooling fans (at front and rear radiators) are not jammed and work-

ing properly.

- Check fan fuse. See Fuses in the Maintenance Procedures.

Dirty radiators fins.

- Check and clean radiator fins. See Maintenance Procedures.

6. ENGINE MISFIRE

Fouled/damaged/worn spark plug.

- Replace spark plugs as required.

Water in fuel.

- Drain fuel system and refill with fresh fuel.

7. PARTIAL OR NO RESPONSE FROM THE ACCELERA-

TOR PEDAL INPUTS (CHECK ENGINE IS ON AND PPS

FAULT MESSAGE IS DISPLAYED)

Partial failure of the accelerator pedal sensors (PPS).

- Use the override switch to retrieve accelerator pedal operation. Contact

an authorized Can-Am dealer.

Total failure of the accelerator pedal sensors (PPS).

- Use the override switch to bypass the accelerator pedal and increase the

engine speed in order to move vehicle. Contact an authorized Can-Am

dealer.

8. SHOCK ICON IS BLINKING FAST WHILE VEHICLE MAL-

FUNCTION TELLTALE IS ON

Partial failure of Smart-Shox system: Front or rear shock absorbers become

full stiff (Sport+ like).

- Change Smart-Shox mode to Sport+ to have a similar setting at front and

rear. The vehicle remains rideable. Contact an authorized Can-Am dealer.

Total failure of Smart-Shox system: Front and rear shock absorbers become

full stiff (Sport+ like).

- The vehicle remains rideable. Contact an authorized Can-Am dealer.

196

DIGITAL DISPLAY MESSAGES

If an abnormal engine condition occurs, the following messages can be com-

bined with a pilot lamp.

Message

Description

D.E.S.S. KEY

NOT

D.E.S.S. key requires cleaning.

RECOGNIZED

Indicates that you have used the wrong D.E.S.S. key, use

BAD KEY

the proper key for this vehicle.

All active or previously activated faults that require

CHECK ENGINE

attention.

No engine limitation engaged.

Critical faults requiring diagnostic as soon as possible.

LIMP HOME

An engine limitation is engaged and/or the engine behavior

is modified.

Throttle body fault, generally followed by a Limp Home

TPS FAULT

message.

BRAKE SWITCH

Brake signal fault.

FAULT

Check engine pilot light on (

CHECK DPS

Indicates that the DPS (Dynamic Power Steering) does not

work properly. See an authorized Can-Am dealer.

Faulty Pedal Position Sensor(s) (PPS). Refer to Override

PPS FAULT

Switch in Secondary Controls to drive the vehicle in the

limp home mode.

MANUAL LIMP

Confirms the Manual Limp Home is engaged using the

HOME

Override Switch in case of a PPS fault.

When the fuel sender resistor value is out of range the

FUEL SENSOR

multifunction gauge (analog/digital) will detect it and display

FAULT

the message.

The warning exclamation point light on (

CHECK

Indicates that the Smart-Lok does not work properly. See

SMART-LOK

an authorized Can-Am dealer.

197

BRP LIMITED WARRANTY FOR CANADA AND USA:

2024 CAN-AM® SSV

1) Scope of the Limited Warranty

Bombardier Recreational Products Inc. ("BRP") warrants its 2024 Can-Am SSV

(“Product (s)”) sold by authorized BRP Dealers (as hereinafter defined) in the

United States of America ("USA") and in Canada from defects in material or

workmanship for the period and under the conditions described below.

This limited warranty will become null and void if:

1. the Product was used for racing or any other competitive activity, at any point,

even by a previous owner; or

2. the Product has been altered or modified in such a way so as to adversely af-

fect its operation, performance or durability, or has been altered or modified

to change its intended use.

Non-factory installed parts and accessories are not covered under this limited

warranty. Please refer to the applicable parts and accessories limited warranty

text.

2) Limitations of Liability

TO THE EXTEND PERMITTED BY LAW, THIS WARRANTY IS EX-

PRESSLY GIVEN AND ACCEPTED IN LIEU OF ANY AND ALL OTHER

WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMI-

TATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. TO THE EXTENT THAT THEY CANNOT BE

DISCLAIMED, THE IMPLIED WARRANTIES ARE LIMITED IN DURATION

TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND CON-

SEQUENTIAL DAMAGES ARE EXCLUDED FROM COVERAGE UNDER

THIS WARRANTY. SOME STATES/PROVINCES DO NOT ALLOW FOR

THE DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED

ABOVE. AS A RESULT, THEY MAY NOT APPLY TO YOU. THIS WAR-

RANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE

OTHER LEGAL RIGHTS WHICH MAY VARY FROM STATE TO STATE,

OR PROVINCE TO PROVINCE.

Neither the distributor, any BRP dealer nor any other person has been authorized

to make any affirmation, representation or warranty regarding the product, other

than those contained in this limited warranty, and if made, shall not be enforce-

able against BRP.

BRP reserves the right to modify this limited warranty at any time, being under-

stood that such modification will not alter the warranty conditions applicable to

the Products sold while this warranty is in effect.

3) EXCLUSIONS – Are Not Warranted

The following are not warranted under any circumstances:

- Normal wear and tear;

- Routine maintenance items, tune ups, adjustments;

- Damage caused by negligence or failure to provide proper maintenance and/

or storage, as described in the Operator's Guide;

- Damage resulting from removal of parts, improper repairs, service, mainte-

nance, modifications or use of parts not manufactured or approved by BRP or

200

BRP LIMITED WARRANTY FOR CANADA AND USA: 2024 CAN-AM^® SSV

resulting from repairs done by a person that is not an authorized servicing

BRP dealer;

- Damage caused by abuse, abnormal use, neglect or operation of the product

in a manner inconsistent with the recommended operation described in the

Product’s Operator’s Guide;

- Damage resulting from accident, submersion, fire, theft, vandalism or any act

of God;

- Operation with fuels, oils or lubricants which are not suitable for use with the

Product (see the Operator’s Guide);

- Damages from rust, corrosion or exposure to the elements;

- Damage resulting from water or snow ingestion;

- Incidental or consequential damages, or damages of any kind including with-

out limitation transportation expenses, towing, storage, telephone, rental, taxi,

inconvenience, insurance coverage, loan payments, loss of time, loss of in-

come or time missed for downtime experience due to service work.

4) Warranty Coverage Period

This limited warranty will be in effect from (1) the date of delivery to the first retail

consumer, or (2) the date the product is first put into use, whichever occurs first

and for the applicable period below:

1. SIX (6) consecutive months, for private use or commercial use owners

2. For emiission-related components, please also refer to the US EPA Emis-

sion-Related Warranty.

3. For evaporative emission-rellated components of Callifornia models

equipped wiith evaporatiive emission control system produced by BRP

for sale in the State of California that are originally sold to a resident or

subsequently warranty registered to a resident in the State of California, also

refer to the California Evaporative Emissions Control Warranty Statement.

The repair or replacement of parts or the performance of service under this war-

ranty does not extend the life of this limited warranty beyond its original expiration

date.

5) Conditions to Have Warranty Coverage

This warranty coverage is available only if each of the following conditions has

been fulfilled:

1. The Product must be purchased as new and unused by its first owner from a

Dealer authorized to sell the Products in the country in which the sale oc-

curred (“Dealer”);

2. The BRP specified pre-delivery inspection process must be completed, docu-

mented and signed by the purchaser;

3. The Product must have undergone proper registration by an authorized

Dealer;

4. The Product must be purchased in the country in which the purchaser

resides;

5. Routine maintenance outlined in the Operator’s Guide must be timely per-

formed in order to maintain warranty coverage. BRP reserves the right to

make warranty coverage contingent upon proof of proper maintenance.

201

BRP LIMITED WARRANTY FOR CANADA AND USA: 2024 CAN-AM^® SSV

BRP will not honor this limited warranty to any private use owner or commercial

use owner if one of the preceding conditions has not been met. Such limitations

are necessary in order to allow BRP to preserve both the safety of its products,

and also that of its consumers and the general public.

6) What to Do to Obtain Warranty Coverage

The customer must cease using the Product upon the appearance of an anom-

aly, notify a servicing BRP dealer within three (3) days of the appearance of the

anomaly and provide the Dealer with reasonable access to the Product and rea-

sonable opportunity to repair it.

The customer must also present to the Dealer, proof of purchase of the Product

and must sign the repair/work order prior to starting the repair in order to validate

the warranty repair.

All parts replaced under this limited warranty become the property of BRP.

7) What BRP Will Do

BRP’s obligations under this warranty are limited to, at its sole discretion, repair-

ing or replacing parts found defective under normal use, maintenance and serv-

ice without charge for parts and labor, at any authorized BRP dealer during the

warranty coverage period under the conditions described herein. No claim of

breach of warranty shall be cause for cancellation or rescission of the sale of the

Product to the owner.

In the event that service is required outside of the country of original sale, the

owner will bear responsibility for any additional charges due to local practices

and conditions, such as, but not limited to, freight, insurance, taxes, license fees,

import duties, and any and all other financial charges, including those levied by

governments, states, territories and their respective agencies.

BRP reserves the right to improve or modify products from time to time without

assuming any obligation to modify products previously manufactured.

8) Transfer

If the ownership of a Product is transferred during the warranty coverage period,

this limited warranty, subject to its terms and conditions, shall also be transferred

and be valid for the remaining coverage period provided BRP or an authorized

Product Distributor/Dealer receives a proof that the former owner agreed to the

transfer of ownership, in addition to the coordinates of the new owner.

9) Consumer Assistance

In the event of a controversy or a dispute in connection with this limited warranty,

BRP suggests that you try to resolve the issue at the dealership level. We recom-

mend discussing the issue with the authorized dealer's service manager or

owner.

If the matter still remains unresolved, contact BRP by filling out the customer con-

tact form at www.brp.com or contact BRP by mail at one of the addresses listed

under the Contact Us section of this guide.

202

US EPA EMISSION - RELATED WARRANTY

Bombardier Recreational Products Inc. (“BRP”) warrants to the ultimate purchas-

er and each subsequent purchaser that this new vehicle, including all parts of its

exhaust emission control system and its evaporative emission control system,

meets two conditions:

1. It is designed, built, and equipped so it conforms at the time of sale to the ulti-

mate purchaser with the requirements of 40 CFR 1051 and 40 CFR 1060.

2. It is free from defects in materials and workmanship that may keep it from

meeting the requirements of 40 CFR 1051 and 40 CFR 1060.

Where a warrantable condition exists, BRP will repair or replace, as it elects, any

part or component with a defect in materials or workmanship that would increase

the engine’s emissions of any regulated pollutant within the stated warranty peri-

od at no cost to the owner, including expenses related to diagnosing and repair-

ing or replacing emission-related parts. All defective parts replaced under this

warranty become the property of BRP.

For all emission-related warranty claims, BRP is limiting the diagnosis and repair

of emission-related parts to the authorized Can-Am dealers, unless for emer-

gency repairs as required by item 2 of the following list.

As a certifying manufacturer, BRP will not deny emission-related warranty claims

based on any of the following:

1. Maintenance or other service BRP or BRP's authorized facilities performed.

2. Engine/equipment repair work that an operator performed to correct an un-

safe, emergency condition attributable to BRP as long as the operator tries to

restore the engine/equipment to its proper configuration as soon as possible.

3. Any action or inaction by the operator unrelated to the warranty claim.

4. Maintenance that was performed more frequently than BRP specify.

5. Anything that is BRP fault or responsibility.

6. The use of any fuel that is commonly available where the equipment operates

unless BRP written maintenance instructions state that this fuel would harm

the equipment’s emission control system and operators can readily find the

proper fuel. See maintenance information section and fuel requirements of fu-

eling section.

Emission-Related Warranty Period

The emission-related warranty is valid for the following period whichever comes

first.

HOURS

MONTHS

KILOMETERS

Exhaust emission-related

500

5000

components

Evaporative emission-related

N/A

components

Components Covered

The emission-related warranty covers all components whose failure would in-

crease an engine’s emissions of any regulated pollutant, including the following

listed components:

203

US EPA EMISSION - RELATED WARRANTY

For exhaust emissions, emission-related components include any engine

parts related to the following systems:

- Air-induction system

- Fuel system

- Ignition system

- Exhaust gas recirculation systems.

The following parts are also considered emission-related components for ex-

haust emissions:

- After treatment devices

- Crankcase ventilation valves

- Sensors

- Electronic control units.

The following parts are considered emission-related components for evapora-

tive emissions:

- Fuel tank

- Fuel cap

- Fuel line

- Fuel line fittings

- Clamps*

- Pressure relief valves*

- Control valves*

- Control solenoids*

- Electronic controls*

- Vacuum control diaphragms*

- Control cables*

- Control linkages*

- Purge valves

- Vapor hoses

- Liquid/vapor separator

- Carbon canister

- Canister mounting brackets

- Carburetor purge port connector.

NOTE: *As related to the evaporative emission control system.

4. Emission-related components also include any other part whose only purpose

is to reduce emissions or whose failure will increase emissions without signifi-

cantly degrading engine/equipment performance.

Limited Applicability

As a certifying manufacturer, BRP may deny emission-related warranty claims

for failures that have been caused by the owner’s or operator’s improper mainte-

nance or use, by accidents for which the manufacturer has no responsibility, or

by acts of God. For example, an emission-related warranty claim need not be

honored for failures that have been directly caused by the operator’s abuse of

the engine/equipment or the operator’s use of the engine/equipment in a manner

for which it was not designed and are not attributable to the manufacturer in

anyway.

204

CALIFORNIA EVAPORATIVE EMISSIONS

CONTROL WARRANTY STATEMENT

The warranty periods begin on the date the new Off-Highway Recreational Ve-

hicle (“OHRV”) is delivered to an ultimate purchaser.

Bombardier Recreational Products Inc. (“BRP”) warrants to the ultimate purchas-

er and each subsequent purchaser that the OHRV is:

1. Designed, built, and equipped so as to conform, at the time of sale, with all

applicable laws, rules and regulations; and

2. Free from defects in materials and workmanship that may cause the failure of

a warranted part. All replacement parts must be identical in all material re-

spects to that part as described in BRP’s Executive Order of Certification

application.

The warranty on emissions-related parts function as follows:

Repair or replacement of any warranted part must be performed at no charge

to the OHRV owner, at a warranty station, except in the case of a temporary

repair when a warranted part or a warranty station is not reasonably available

to the OHRV owner. In the event a temporary repair is permitted, repairs may

be performed at any available service establishment, or by the owner, using

any replacement part. BRP must reimburse the owner for his or her expenses

including diagnostic charges for such temporary repair or replacement, not to

exceed BRP's suggested retail price for all warranted parts replaced and la-

bor charges based on BRP's recommended time allowance for the warranty

repair and the geographically appropriate hourly labor rate.

The lack of availability of warranted parts or the incompleteness of repairs

within a reasonable time period, not to exceed 30 days from the time the

OHRV is initially presented to the warranty station for repair, will qualify the

need for a temporary repair.

Any warranted part which is not scheduled for replacement as part of mainte-

nance in the written instructions must be warranted for the warranty period

defined below. If any such part fails during the warranty period, it must be re-

paired or replaced by BRP. Any such part repaired or replaced under war-

ranty must be fully warranted.

Any warranted part which is scheduled only for regular inspection in the writ-

ten instructions must be warranted for the warranty period defined below. A

statement in such written instructions to the effect of “repair or replace as nec-

essary” does not reduce the period of warranty coverage. Any such part re-

paired or replaced under warranty is warranted for the remaining warranty

period.

Any warranted part which is scheduled for replacement as part of mainte-

nance in the written instructions is warranted for the period of time prior to the

first scheduled replacement point for that part. If the part fails before the first

scheduled replacement point, the part will be repaired or replaced by BRP.

Any such part repaired or replaced under warranty is warranted for the re-

mainder of the period prior to the first scheduled replacement point for the

part.

Warranty services or repairs are provided at all manufacturer dealerships that

are owned by the manufacturer or franchised to service the subject OHRVs.

The OHRV owner will not be charged for diagnostic labor which leads to the

determination that a warranted part is, in fact, defective, provided that such di-

agnostic work is performed at a warranty station.

206

CALIFORNIA EVAPORATIVE EMISSIONS CONTROL WARRANTY STATEMENT

8. BRP is liable for damages to other vehicle components proximately caused

by a failure, under warranty, of any warranted part.

9. Any replacement part designated by BRP may be used in warranty repairs

provided without charge to the OHRV owner. Such use will not reduce the

warranty obligations of BRP, except that BRP will not be liable for repair or re-

placement of any replacement part which is not a warranted part.

10. Any add-on or modified part exempted by the Air Resources Board from the

prohibitions of section 27156 of the California Vehicle Code may be used on

an OHRV. Such use, in and of itself, will not be grounds for disallowing a war-

ranty claim. BRP is not liable to warrant failures of warranted parts caused by

the use of an add-on or modified part (s) unless such part (s) are also

warranted.

Conditions and exclusions:

- BRP may deny you warranty coverage if your OHRV or a part has failed di-

rectly due to abuse, neglect, improper maintenance or unapproved

modifications.

Your Warranty Rights And Obligations

The California Air Resources Board is pleased to explain the evaporative emis-

sions control system warranty on your 2024 Off-Road Sport Vehicle. In Califor-

nia, new off-highway recreational vehicles must be designed, built, and equipped

to meet the State’s stringent anti-smog standards. BRP must warrant the evapo-

rative emissions control system on your Off-Road Sport Vehicle for the periods of

time listed below provided there has been no abuse, neglect, improper mainte-

nance, or unapproved modification of your Off-Road Sport Vehicle.

Your evaporative emissions control system may include parts such as the carbu-

retor or fuel-injection system, fuel tank, fuel hoses, carbon canister, and engine

computer. Also included may be hoses, belts, connectors and other evaporative

emissions-related assemblies. Where a warrantable condition exists, Bombardier

Recreational Products Inc. will repair your Off-Road Sport Vehicle at no cost to

you including diagnosis, parts and labor.

OHRV Manufacturer’s Warranty Coverage

The warranty period for this OHRV is 60 months, or 5000 miles, or 500 hours,

whichever comes first.

Parts covered:

1. Canister Mounting Bracket(s)

2. Carbon Canister

3. Purge Port Connector

4. Clamp(s)*

5. Electronic Control*

6. Fuel Cap

7. Filler Neck

8. Filler Neck Hose

9. Fuel Line(s)

10. Fuel Line Fitting(s)

11. Fuel Tank

12. Pressure Relief Valve(s)*

207

CALIFORNIA EVAPORATIVE EMISSIONS CONTROL WARRANTY STATEMENT

13. Purge Valve(s)

14. Check Valve(s)*

15. Vapor Hose(s)

16. Flow Reducer

17. Filter(s)*

18. Fuel pump

19. All other parts not listed that may affect the evaporative emissions control

system

NOTE: *As related to the evaporative emission control system.

If any evaporative emissions-related part on your Off-Road Sport Vehicle is de-

fective the part will be repaired or replaced by Bombardier Recreational Products

Inc.

Owner’s Warranty Responsibilities

As the Off-Road Sport Vehicle owner you are responsible for the performance of

the required maintenance listed in your owner’s manual. Bombardier Recreation-

al Products Inc. recommends that you retain all receipts covering maintenance

on your Off-Road Sport Vehicle, but Bombardier Recreational Products Inc. can-

not deny warranty solely for the lack of receipts or for failure to ensure the per-

formance of a scheduled maintenance.

As an owner you are responsible for presenting your Off-Road Sport Vehicle to a

Bombardier Recreational Products Inc. dealer as soon as a problem exists. The

warranty repairs should be completed in a reasonable time, not to exceed 30

days.

As an Off-Road Sport Vehicle owner, you should also be aware that Bombardier

Recreational Products Inc. may deny you warranty coverage if your Off-Road

Sport Vehicle or a part has failed due to abuse, neglect, improper maintenance

or unapproved modifications.

If you have any questions regarding your warranty rights and responsibilities, you

should contact:

- Bombardier Recreational Products Inc. at 1-888-272-9222, or

- The California Air Resources Board at 4001 Iowa Avenue, Riverside, CA

92507.

208

BRP LIMITED WARRANTY FOR INTERNATIONAL:

2024 CAN-AM® SSV

1) Scope of the Limited Warranty

Bombardier Recreational Products Inc. ("BRP") warrants its 2024 Can-Am SSV

(“Product(s)”) sold by distributors or dealers authorized by BRP to distribute the

Products outside of the United States of America ("USA"), Canada, member

states of the European Economic Area (which is comprised of the states of the

European Union plus the United Kingdom, Norway, Iceland and Liechtenstein)

("EEA"), Turkey, member states of the Commonwealth of the Independent States

(including Ukraine and Turkmenistan) ("CIS") from defects in material or work-

manship for the period and under the conditions described below.

This limited warranty will become null and void if:

1. the Product was used for racing or any other competitive activity, at any

point, even by a previous owner; or

2. the Product has been altered or modified in such a way so as to adversely af-

fect its operation, performance or durability, or has been altered or modified

to change its intended use.

Non-factory installed parts and accessories are not covered under this limited

warranty. Please refer to the applicable parts and accessories limited warranty

text.

2) Limitation of Liability

TO THE EXTEND PERMITTED BY LAW, THIS WARRANTY IS EX-

PRESSLY GIVEN AND ACCEPTED IN LIEU OF ANY AND ALL OTHER

WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMI-

TATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. TO THE EXTENT THAT THEY CANNOT BE

DISCLAIMED, THE IMPLIED WARRANTIES ARE LIMITED IN DURATION

TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND CON-

SEQUENTIAL DAMAGES ARE EXCLUDED FROM COVERAGE UNDER

THIS WARRANTY. SOME STATES/PROVINCES DO NOT ALLOW FOR

THE DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED

ABOVE. AS A RESULT, THEY MAY NOT APPLY TO YOU. THIS WAR-

RANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE

OTHER LEGAL RIGHTS WHICH MAY VARY FROM COUNTRY TO COUN-

TRY. BRP SHALL NOT BE HELD LIABLE IF PRODUCTS OR WARRANTY

PARTS ARE NOT AVAILABLE IN CERTAIN COUNTRIES FOR REASONS

OUTSIDE OF BRP’S CONTROL.

For Products purchased in Australia, refer to the Australia-specific section below.

Neither the distributor, any BRP Distributor/Dealer nor any other person has

been authorized to make any affirmation, representation or warranty regarding

the product, other than those contained in this limited warranty, and if made, shall

not be enforceable against BRP.

BRP reserves the right to modify this limited warranty at any time, being under-

stood that such modification will not alter the warranty conditions applicable to

the Products sold while this warranty is in effect.

209

BRP LIMITED WARRANTY FOR INTERNATIONAL: 2024 CAN-AM^® SSV

3) EXCLUSIONS – Are Not Warranted

The following are not warranted under any circumstances:

- Normal wear and tear;

- Routine maintenance items, tune ups, adjustments;

- Damage caused by negligence or failure to provide proper maintenance and/

or storage, as described in the Operator's Guide;

- Damage resulting from removal of parts, improper repairs, service, mainte-

nance, modifications or use of parts not manufactured or approved by BRP or

resulting from repairs done by a person that is not an authorized servicing

BRP Distributor/Dealer;

- Damage caused by abuse, abnormal use, neglect or operation of the product

in a manner inconsistent with the recommended operation described in the

Product’s Operator’s Guide;

- Damage resulting from accident, submersion, fire, theft, vandalism or any act

of God;

- Operation with fuels, oils or lubricants which are not suitable for use with the

Product (see the Operator’s Guide);

- Damages from rust, corrosion or exposure to the elements;

- Damage resulting from water or snow ingestion;

- Incidental or consequential damages, or damages of any kind including with-

out limitation transportation expenses, towing, storage, telephone, rental, taxi,

inconvenience, insurance coverage, loan payments, loss of time, loss of in-

come or time missed for downtime experience due to service work.

The following list includes, without limitation, items that are considered wear

items and that are not covered under BRP's limited warranty unless failure is a di-

rect result of a defect in material or workmanship:

- Batteries

- Brake pads

- Brake disks and drums

- Clutch plates / pads

- Clutch sliders

- Clutch springs

- Clutch replaceable bushings

- Drive belts

- Filters

- Finished and unfinished surfaces

- Fuses

- Light bulbs / sealed

- Lubricants

- Spark plugs

- Suspension bushings

- Suspension slider shoes

- Suspension springs

- Tires

4) Warranty Coverage Period

This limited warranty will be in effect from (1) the date of delivery to the first retail

consumer, or (2) the date the product is first put into use, whichever occurs first

and for the applicable period below:

210

BRP LIMITED WARRANTY FOR INTERNATIONAL: 2024 CAN-AM^® SSV

1. SIX (6) consecutive months, for private use or commercial use owners

In AUSTRALIA and NEW ZEALAND only, this warranty will be in effect from (1)

the date of delivery to the first retail consumer or (2) the date the product is first

put into use, whichever occurs first, and for a period of TWELVE (12) CONSEC-

UTIVE MONTHS and THIRTY SIX (36) CONSECUTIVE MONTHS for Power-

train Engine and Transmission systems only, for private use or commercial use.

The repair or replacement of parts or the performance of service under this war-

ranty does not extend the life of this warranty beyond its original expiration date.

The warranty coverage period identified above are a minimal limited warranty pe-

riod which can be extended by any applicable warranty promotional program, as

the case may be.

Note that the duration and any other modalities of the warranty coverage are sub-

ject to the applicable national or local legislation in the customer's country.

5) For Products Sold In Australia Only

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law.

You are entitled to a replacement or refund for a major failure and for compensa-

tion for any other reasonably foreseeable loss or damage.

You are also entitled to have the goods repaired or replaced if the goods fail to

be of acceptable quality and the failure does not amount to a major failure.

Nothing in these Warranty terms and conditions should be taken to exclude, re-

strict or modify the application of any condition, warranty, guarantee, right or rem-

edy conferred or implied under the Competition and Consumer Act 2010 (Cth),

including the Australian Consumer Law or any other law, where to do so would

contravene that law, or cause any part of these terms and conditions to be void.

The benefits given to you under this limited warranty are in addition to other rights

and remedies that you have under Australian law.

6) Conditions to Have Warranty Coverage

This warranty coverage is available only if each of the following conditions has

been fulfilled:

1. The Product must be purchased as new and unused by its first owner from a

Distributor/Dealer authorized to distribute Products in the country in which the

sale occurred (“Distributor/Dealer”);

2. The BRP specified pre-delivery inspection process must be completed, docu-

mented and signed by the purchaser;

3. The Product must have undergone proper registration by an authorized Dis-

tributor/Dealer;

4. The Product must be purchased in the country in which the purchaser

resides;

5. Routine maintenance outlined in the Operator’s Guide must be timely per-

formed in order to maintain warranty coverage. BRP reserves the right to

make warranty coverage contingent upon proof of proper maintenance.

211

BRP LIMITED WARRANTY FOR INTERNATIONAL: 2024 CAN-AM^® SSV

BRP will not honor this limited warranty to any private use owner or commercial

use owner if one of the preceding conditions has not been met. Such limitations

are necessary in order to allow BRP to preserve both the safety of its products,

and also that of its consumers and the general public.

7) What to Do to Obtain Warranty Coverage

The customer must cease using the Product upon the appearance of an anom-

aly, notify a servicing BRP Distributor/Dealer within two (2) months of the appear-

ance of the anomaly and provide the Distributor/Dealer with reasonable access

to the Product and reasonable opportunity to repair it.

The notification period is subject to the applicable national or local legislation in

customer's country.

The customer must also present to the Distributor/Dealer, proof of purchase of

the Product and must sign the repair/work order prior to starting the repair in or-

der to validate the warranty repair.

All parts replaced under this limited warranty become the property of BRP.

8) What BRP Will Do

To the extent permitted by law, BRP’s obligations under this warranty are limited

to, at its sole discretion, repairing or replacing parts found defective under normal

use, maintenance and service without charge for parts and labor, at any author-

ized BRP Distributor/Dealer during the warranty coverage period under the con-

ditions described herein. No claim of breach of warranty shall be cause for

cancellation or rescission of the sale of the Product to the owner. You may have

other legal rights which may vary from country to country.

In the event that service is required outside of the country of original sale, the

owner will bear responsibility for any additional charges due to local practices

and conditions, such as, but not limited to, freight, insurance, taxes, license fees,

import duties, and any and all other financial charges, including those levied by

governments, states, territories and their respective agencies.

BRP reserves the right to improve or modify products from time to time without

assuming any obligation to modify products previously manufactured.

9) Transfer

If the ownership of a Product is transferred during the warranty coverage period,

this limited warranty, subject to its terms and conditions, shall also be transferred

and be valid for the remaining coverage period provided BRP or an authorized

Product Distributor/Dealer receives a proof that the former owner agreed to the

transfer of ownership, in addition to the coordinates of the new owner.

10) Consumer Assistance

In the event of a controversy or a dispute in connection with this limited warranty,

BRP suggests that you try to resolve the issue at the dealership level. We recom-

mend discussing the issue with the authorized Distributor/Dealer's service man-

ager or owner.

212

BRP LIMITED WARRANTY FOR THE EUROPEAN

ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024

CAN-AM® SSV

1) Scope of the Limited Warranty

Bombardier Recreational Products Inc. ("BRP") warrants its 2024 Can-Am SSV

(“Product(s)”) sold by distributors or dealers authorized by BRP to distribute the

Products in member states of the European Economic Area (which is comprised

of the states of the European Union plus the United Kingdom, Norway, Iceland

and Liechtenstein) ("EEA"), Turkey, member states of the Commonwealth of the

Independent States (including Ukraine and Turkmenistan) ("CIS") (“Distributor/

Dealer”) from defects in material or workmanship for the period and under the

conditions described below.

This limited warranty will become null and void if:

1. the Product was used for racing or any other competitive activity, at any point,

even by a previous owner; or

2. the Product has been altered or modified in such a way so as to adversely af-

fect its operation, performance or durability, or has been altered or modified

to change its intended use.

Non-factory installed parts and accessories are not covered under this limited

warranty. Please refer to the applicable parts and accessories limited warranty

text.

2) Limitations of Liability

TO THE EXTEND PERMITTED BY LAW, THIS WARRANTY IS EX-

PRESSLY GIVEN AND ACCEPTED IN LIEU OF ANY AND ALL OTHER

WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMI-

TATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. TO THE EXTENT THAT THEY CANNOT BE

DISCLAIMED, THE IMPLIED WARRANTIES ARE LIMITED IN DURATION

TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND CON-

SEQUENTIAL DAMAGES ARE EXCLUDED FROM COVERAGE UNDER

THIS WARRANTY. SOME STATES/PROVINCES DO NOT ALLOW FOR

THE DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED

ABOVE. AS A RESULT, THEY MAY NOT APPLY TO YOU. THIS WAR-

RANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE

OTHER LEGAL RIGHTS WHICH MAY VARY FROM STATE TO STATE,

OR PROVINCE TO PROVINCE. BRP SHALL NOT BE HELD LIABLE IF

PRODUCTS OR WARRANTY PARTS ARE NOT AVAILABLE IN CERTAIN

COUNTRIES FOR REASONS OUTSIDE OF BRP’S CONTROL.

For Products purchased in France, refer to the France-specific section below.

Neither the distributor, any BRP Distributor/Dealer nor any other person has

been authorized to make any affirmation, representation or warranty regarding

the product, other than those contained in this limited warranty, and if made, shall

not be enforceable against BRP.

214

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024 CAN-AM^® SSV

BRP reserves the right to modify this limited warranty at any time, being under-

stood that such modification will not alter the warranty conditions applicable to

the Products sold while this warranty is in effect.

3) EXCLUSIONS – Are Not Warranted

The following are not warranted under any circumstances:

- Normal wear and tear;

- Routine maintenance items, tune ups, adjustments;

- Damage caused by negligence or failure to provide proper maintenance and/

or storage, as described in the Operator's Guide;

- Damage resulting from removal of parts, improper repairs, service, mainte-

nance, modifications or use of parts not manufactured or approved by BRP or

resulting from repairs done by a person that is not an authorized servicing

BRP Distributor/Dealer;

- Damage caused by abuse, abnormal use, neglect or operation of the product

in a manner inconsistent with the recommended operation described in the

Product’s Operator’s Guide;

- Damage resulting from accident, submersion, fire, theft, vandalism or any act

of God;

- Operation with fuels, oils or lubricants which are not suitable for use with the

Product (see the Operator’s Guide);

- Damages from rust, corrosion or exposure to the elements;

- Damage resulting from water or snow ingestion;

- Incidental or consequential damages, or damages of any kind including with-

out limitation transportation expenses, towing, storage, telephone, rental, taxi,

inconvenience, insurance coverage, loan payments, loss of time, loss of in-

come or time missed for downtime experience due to service work.

The following list includes, without limitation, items that are considered wear

items and that are not covered under BRP's limited warranty unless failure is a di-

rect result of a defect in material or workmanship:

- Batteries

- Brake pads

- Brake disks and drums

- Clutch plates / pads

- Clutch sliders

- Clutch springs

- Clutch replaceable bushings

- Drive belts

- Filters

- Finished and unfinished surfaces

- Fuses

- Light bulbs / sealed

- Lubricants

- Spark plugs

- Suspension bushings

- Suspension slider shoes

- Suspension springs

- Tires

215

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024 CAN-AM^® SSV

4) Warranty Coverage Period

This limited warranty will be in effect from (1) the date of delivery to the first retail

consumer, or (2) the date the product is first put into use, whichever occurs first

and for the applicable period below:

1. TWENTY-FOUR (24) consecutive months, for private use owners.

2. SIX (6) consecutive months, for commercial use owners.

A Product is used commercially when it is used in connection with any work or

employment that generates income during any part of the warranty period. A

Product is also used commercially when, at any point during the warranty period,

it is licensed for commercial use.

The repair or replacement of parts or the performance of service under this war-

ranty does not extend the life of this warranty beyond its original expiration date.

The warranty coverage period identified above are a minimal limited warranty pe-

riod which can be extended by any applicable warranty promotional program, as

the case may be.

Note that the duration and any other modalities of the warranty coverage are sub-

ject to the applicable national or local legislation in the customer's country.

5) For Products Sold In France Only

The seller shall deliver goods that are complying with the contract and shall be

responsible for defects existing upon delivery. The seller shall also be responsi-

ble for defects resulting from packaging, assembling instructions or the installa-

tion when it is its responsibility per the contract or if accomplished under its

responsibility. To be compliant with the contract, the good shall:

1. Be fit for normal use for goods similar thereto and, if applicable:

- Correspond to the description provided by the seller and have the qualities

presented to the buyer though sample or model;

- Have the qualities that a buyer may legitimately expect considering the

public declarations of the seller, the manufacturer of its representative, in-

cluding in advertising or labeling; or

2. Have the characteristics mutually agreed upon as between the parties or be

fit for the specific use intended by the buyer and brought to the attention of

the seller and which accepted.

The action for failure to comply is prescribed after two years after delivery of the

goods. The seller is responsible for the warranty for hidden defects of the good

sold if such hidden defects are rendering the good unfit for the intended use, or if

they diminish its use in such a way that the buyer would not have acquired the

good or would have given a lesser price, had he known. The action for such hid-

den defects shall be taken by the buyer within 2 years of the discovery of the

defect.

6) Conditions to Have Warranty Coverage

This warranty coverage is available onlly if each of the following conditions has

been fulfilled:

216

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024 CAN-AM^® SSV

1. The Product must be purchased as new and unused by its first owner from a

Distributor/Dealer authorized to distribute Products in the country (or in the

case of the EEA, union of countries) in which the sale occurred (“Distributor/

Dealer”);

2. The BRP specified pre-delivery inspection process must be completed, docu-

mented and signed by the purchaser;

3. The Product must have undergone proper registration by an authorized Dis-

tributor/Dealer;

4. The Product must be purchased in the country (or in the case of the EEA,

union of countries) in which the purchaser resides;

5. Routine maintenance outlined in the Operator’s Guide must be timely per-

formed in order to maintain warranty coverage. BRP reserves the right to

make warranty coverage contingent upon proof of proper maintenance.

BRP will not honor this limited warranty to any private use owner or commercial

use owner if one of the preceding conditions has not been met. Such limitations

are necessary in order to allow BRP to preserve both the safety of its products,

and also that of its consumers and the general public.

7) What to Do to Obtain Warranty Coverage

The customer must cease using the Product upon the appearance of an anom-

aly, notify a servicing BRP Distributor/Dealer within two (2) months of the appear-

ance of the anomaly and provide the Distributor/Dealer with reasonable access

to the Product and reasonable opportunity to repair it.

The notification period is subject to the applicable national or local legislation in

customer's country.

The customer must also present to the Distributor/Dealer, proof of purchase of

the Product and must sign the repair/work order prior to starting the repair in or-

der to validate the warranty repair.

All parts replaced under this limited warranty become the property of BRP.

8) What BRP Will Do

To the extent permitted by law, BRP’s obligations under this warranty are limited

to, at its sole discretion, repairing or replacing parts found defective under normal

use, maintenance and service without charge for parts and labor, at any author-

ized BRP Distributor/Dealer during the warranty coverage period under the con-

ditions described herein. No claim of breach of warranty shall be cause for

cancellation or rescission of the sale of the Product to the owner. You may have

other legal rights which may vary from country to country.

In the event that service is required outside of the country of original sale, or for

EEA residents, if service is required outside of the EEA, the owner will bear re-

sponsibility for any additional charges due to local practices and conditions, such

as, but not limited to, freight, insurance, taxes, license fees, import duties, and

any and all other financial charges, including those levied by governments,

states, territories and their respective agencies.

BRP reserves the right to improve or modify products from time to time without

assuming any obligation to modify products previously manufactured.

217

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024 CAN-AM^® SSV

9) Transfer

If the ownership of a Product is transferred during the warranty coverage period,

this limited warranty, subject to its terms and conditions, shall also be transferred

and be valid for the remaining coverage period provided BRP or an authorized

Product Distributor/Dealer receives a proof that the former owner agreed to the

transfer of ownership, in addition to the coordinates of the new owner.

10) Consumer Assistance

In the event of a controversy or a dispute in connection with this limited warranty,

BRP suggests that you try to resolve the issue at the dealership level. We recom-

mend discussing the issue with the authorized Distributor/Dealer's service man-

ager or owner.

If the matter still remains unresolved, contact BRP by filling out the customer con-

tact form at www.brp.com or contact BRP by mail at one of the addresses listed

under the Contact Us section of this guide.

218

DATA PRIVACY INFORMATION

Bombardier Recreational Products inc., its affiliates and subsidiaries (“BRP”) is

committed to protecting your privacy and support a general policy of openness

about how we collect, use and disclose your personal information in the course

of managing our relationship with you. More detaiils can be found by visiting

BRP’’s Priivacy Poliicy at:

https://brp.com/en/privacy-poliicy.htmll or by scanniing the QR Code below.

Please be assured that we have appropriate security measures in place to en-

sure that your personal information is protected against loss and unauthorized

access.

Your personal information that may be collected by BRP, directly from you or

from authorized dealers or authorized third parties, includes:

- Contact, Demographiic & Registratiion Informatiion (e.g., name, full ad-

dress, phone number, email, gender, ownership history, language of

communication)

- Vehicle Information (e.g., serial number, purchase and delivery date, unit

usage, vehicle location and movements)

- Third Party Informatiion (e.g., information received from BRP partners, join-

t-marketing activities information, social media)

- Technological Information (e.g., IP address, type of device, operating sys-

tem, browser type, webpages you view, cookies and similar technologies

when you use BRP or dealers’ websites or mobile application)

- Interaction with BRP Information (e.g., information collected when you call

BRP’s in-house sales representatives, buy items on a BRP web Site, sign up

for BRP emails, participate in BRP-sponsored contests and sweepstakes or

attend BRP-sponsored events)

- Transactiionall Informatiion (e.g., information necessary to handle returns,

payment information when you purchase our products or services through

our websites or mobile applications and other issues related to your purchase

of BRP products)

This information may be used and processed for the following purposes:

- Safety & Security

- Customer Support for Sales & After Sales (e.g., complete or follow up with

you about your purchase or maintenance)

- Registration & Warranty

- Communication (e.g., sending you a BRP satisfaction survey)

- Online Behavioural Advertising, Profiling and Location-Based Services

(e.g., offer customized experience)

- Compliance & Dispute Resolution

- Marketing & Advertising

- Assistance (e.g., help with any delivery issues, handle returns, and other is-

sues related to your purchase of BRP products).

We also may use personal information to generate aggregated or statistical data

that no longer identifies you personally.

Your personal informatiion may be disclosed to the folllowiing: BRP, BRP’s

authoriized deallerships, diistriibutors, serviice proviiders, advertising & mar-

ket research partners and other authoriized third partiies.

We may receive information about you from diverse sources, including third par-

ties, such as BRP’s authorized dealerships and partners, with whom we offer

220

DATA PRIVACY INFORMATION

services or engage in joint-marketing activities. We may also receive information

about you from social media platforms such as Facebook and Twitter, when you

interact with us on those platforms.

Depending on the circumstances, your personal information may be communi-

cated outside the region where you reside. Your personal information is retained

only for as long as necessary for the purpose for which we obtained it and ac-

cording to our retention policies.

To exercise your data privacy rights (e.g. right of access, right of rectification), to

withdraw your consent in order to be removed from the address list for marketing

purposes or for the satisfaction survey or for general data privacy questions,

please contact BRP’s Data Protection Officer at or by mail at privacyoffii-

cer@brp.com or by mail at:

BRP Legal Service, 726 St-Joseph, Valcourt, Quebec, Canada, J0E 2L0.

When BRP processes your personall iinformation, they do so in complliance

wiith its Privacy Pollicy avaiilable at: https://www.brp.com/en/privacy-poliicy.

htmll or by using the folllowiing

QR Code.

221

www.brp.com

Asia Pacific

Australia

Level 26

477 Pitt Street

Sydney, NSW 2020

China

上海市徐汇区衡山路10号6号楼301

Rm 301, Building 6,

No.10 Heng Shan Rd,

Shanghai, China

Japan

21F Shinagawa East One Tower

2-16-1 Konan, Minato-ku-ku,

Tokyo 108-0075

New Zealland

Suite 1.6, 2-8 Osborne Street,

Newmarket, Auckland 2013

Europe, Middle East and Africa

Bellgium

Oktrooiplein 1

9000 Gent

Czech Republiic

Stefanikova 43a

Prague 5

150 00

Germany

Itterpark 11

40724 Hilden

Fiinland

Isoaavantie 7

PL 8040

96101 Rovaniemi

France

Arteparc Bâtiment B

Route de la côte d'Azur,

13 590 Meyreuil

Norway

Ingvald Ystgaardsvei 15

N-7484 Trondheim

222

CHANGE OF ADDRESS AND OWNERSHIP

If your address has changed or if you are the new owner of the vehicle, be sure

to notify BRP by either:

- Notifying an authorized Can-Am dealer.

- North America Only: calling at 1 888 272-9222.

- Mailing one of the change of address cards on the following pages at one of

the BRP addresses indicated in the Contact Us section of this guide.

In case of change of ownership, please join a proof that the former owner agreed

to the transfer.

Notifying BRP, even after the expiration of the limited warranty, is very important

as it enables BRP to reach the vehicle owner if necessary, like when safety re-

calls are initiated. It is the owner’s responsibility to notify BRP.

STOLEN UNITS: If your personal vehicle is stolen, you should notify BRP or an

authorized Can-Am dealer. We will ask you to provide your name, address,

phone number, the vehicle identification number and the date it was stolen.

224
