Can-Am Defender PRO Series / Traxter PRO Series. OPERATOR’S GUIDE (2024)

OPERATOR’S GUIDE

Covered Models

Defender PRO DPS HD10

Defender PRO Limited HD10

Defender PRO XT HD10

Traxter PRO DPS HD10

In Canada, products are distributed and serviced by Bombardier Recreational

Products Inc. (BRP).

In the USA, products are distributed and serviced by BRP US Inc.

In the European Economic Area (which is comprised of the member states of the

European Union plus the United Kingdom, Norway, Iceland and Liechtenstein),

the Commonwealth of the Independent States (including Ukraine and Turkmeni-

stan) and Turkey, products are distributed and serviced by BRP European Distri-

bution S.A. and other affiliates or subsidiaries of BRP.

For all other countries, products are distributed and serviced by Bombardier Rec-

reational Products Inc. (BRP) or its affiliates.

TABLE OF CONTENTS

GENERAL INFORMATION

Know Before you Go

Safety Messages

About this Operator’s Guide

SAFETY INFORMATION

GENERAL PRECAUTIONS

Avoid Carbon Monoxide Poisoning

Avoid Gasoline Fires and Other Hazards

Avoid Burns from Hot Parts

Accessories and Modifications

SAFE OPERATION - RESPONSIBILITIES

Owner - Be Responsible

Operator - Be Qualified and Responsible

Riding Carefully

Occupant Restraint System

Terrain Condition

PRE-RIDE INSPECTION

Pre-Ride Inspection Check List

PREPARE TO RIDE

Before you Ride

Riding Gear

AVOID ACCIDENTS

Avoid Rollovers and Tipovers

Avoid Collisions

RIDING YOUR VEHICLE

Practice Exercises

Off-Road Operation

General Riding Techniques

MOVING LOADS AND DOING WORK

Working with Your Vehicle

Carrying Loads

Hauling a Load

Pulling a Trailer

IMPORTANT ON-PRODUCT LABELS(CANADA/UNITED STATES)

Safety Hang Tag

Safety Labels

Molded Safety Pictogram

Compliance HangTag

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANA-

DA/UNITED STATES)

Safety Pictogram

Molded Safety Pictogram

TABLE OF CONTENTS

REPORTING SAFETY DEFECTS

VEHICLE INFORMATION

PRIMARY CONTROLS

Steering Wheel

Accelerator Pedal

Brake Pedal

Shift Lever

SECONDARY CONTROLS

Ignition Switch and Keys

2WD/4WD Switch

2WD/4WD/Front Diff Lock Switch

Rear Differential Lock Switch

Keypad

Climate Controls

Horn Switch (On applicable models)

Power-tilt Bed Switch

Winch Switch

Headlight Dimmer Switch

Power Window Switches (If Equipped)

Wiper / Windshield Washer Switch

EQUIPMENT

Tilt Steering

Cup Holders

Passengers Handhold

Storage Compartments

Tool Kit

Footrests

Side Nets

Shoulder Guards

Seat Belts

Driver's Seat

Passenger Seats

Fuel Reservoir Cap

Winch

Cargo Box

Cargo Box Tilt

Tailgate

Side Mirrors (If equipped)

Trailer Hitch

12-Volt Power Outlets

USB Power Outlet

Brake Holding Mechanism

Side Mirrors

Full Doors With Electric Windows

Windshield with Wiper

Climate Control System

Rear Deflector

101

4.5” DIGITAL DISPLAY

102

Multifunction Display

102

Warning Lamps and Indicators

103

TABLE OF CONTENTS

Settings

104

7.6" DIGITAL DISPLAY

106

Multifunction Display

106

Indicator Lamps

107

Settings

108

FUEL

110

Fuel Requirements

110

Vehicle Fueling Procedure

110

BREAK-IN PERIOD

112

Operation During Break-In

112

BASIC PROCEDURES

113

Starting the Engine

113

Operating the Shift Lever

113

Choosing the Correct Range (Low or High)

113

Stopping the Engine and Parking the Vehicle

114

Tips for Maximizing Drive Belt Durability

114

SPECIAL PROCEDURES

115

Fuel Flooded Engine

115

What to do if Water is Suspected to be in the CVT

115

What to do if Battery is Drained Out

115

What to Do if Vehicle Rolled Over

115

What to do if Vehicle is Submerged

116

TUNE YOUR RIDE

117

Suspension Adjustment Guidelines

117

Suspension Factory Settings

117

Suspension Adjustments

117

DPS Function

118

TRANSPORTING THE VEHICLE

119

Using Vehicle Power to Climb Onto Trailering Equipment

120

Using a Winch to Pull Vehicle Onto Trailering Equipment

120

Securing Vehicle for Transport

121

Getting Vehicle Out of Trailer

122

LIFTING AND SUPPORTING THE VEHICLE

123

Front of Vehicle

123

Rear of Vehicle

123

MAINTENANCE

MAINTENANCE SCHEDULE

126

EPA Regulation - Canadian and USA Vehicles

126

Air Filter Maintenance Guideline

126

Severe Duty Use

127

Deep Mud / Water Use

127

Maintenance Schedule

128

Maintenance Records

139

MAINTENANCE PROCEDURES

144

ENGINE AIR FILTER

144

CVT Air Filter

145

Evaporative Emission System Pre-Filter (If Equipped)

146

ENGINE OIL

147

Oil Filter

149

RADIATOR

150

TABLE OF CONTENTS

ENGINE COOLANT

150

Heating/Air Conditioning Air Filter (if equipped)

152

Air Conditioning Compressor Belt

154

EXHAUST SYSTEM

154

GEARBOX

155

FRONT DIFFERENTIAL

156

CVT COVER

158

Drive Belt

159

Drive and Driven Pulleys

160

Spark Plugs

160

Battery

161

Fuses and Fusible Links

162

LIGHTS

165

Drive Shaft Bellow and Protector

165

Wheel Bearing

166

Wheels and Tires

166

Power-tilt Bed

167

Suspensions

167

Brakes

168

SEAT BELTS

169

Doors

169

Cage

169

VEHICLE CARE

171

Vehicle Cleaning and Protection

171

STORAGE AND PRESEASON PREPARATION

172

TECHNICAL INFORMATION

VEHICLE IDENTIFICATION

174

Vehicle Identification Number

174

Engine Identification Number (EIN)

174

Compliance Label

174

Technical Information Label

176

EVAPORATIVE EMISSION CONTROL SYSTEM

180

NOISE EMISSION CONTROL SYSTEM REGULATION

181

NOISE EMISSION AND VIBRATION VALUES (MACHINERY DIRECTIVE

2006/42/EC COMPLIANCE MODELS)

182

DECLARATION OF CONFORMITY

183

EU Declaration of Conformity

183

UK Declaration of Conformity

184

EAC DECLARATION OF CONFORMITY

185

TECHNICAL SPECIFICATIONS

188

TROUBLESHOOTING

TROUBLESHOOTING GUIDELINES

198

CVT Belt Is Slipping

198

“-” Is Displayed On the Gearbox Position Display

198

TABLE OF CONTENTS

Engine Does Not Turn

198

Engine Turns Over But Fails To Start

198

Engine Lacks Acceleration or Power

199

Engine Overheats

200

Engine Misfire

200

The RPM Increases But the Vehicle Does Not Move

200

Partial or No Response From the Accelerator Pedal - Check Engine Is ON

and PPS Fault Message Is Displayed

200

DIGITAL DISPLAY MESSAGES

201

WARRANTY

BRP LIMITED WARRANTY FOR CANADA AND USA: 2024 CAN-AM^®

SSV

204

1) Scope of the Limited Warranty

204

2) Limitations of Liability

204

3) EXCLUSIONS - Are Not Warranted

204

4) Warranty Coverage Period

205

5) Conditions to Have Warranty Coverage

205

6) What to Do to Obtain Warranty Coverage

206

7) What BRP Will Do

206

8) Transfer

206

9) Consumer Assistance

206

US EPA EMISSION - RELATED WARRANTY

207

Emission-Related Warranty Period

207

Components Covered

207

Limited Applicability

208

CALIFORNIA EVAPORATIVE EMISSIONS CONTROL WARRANTY

STATEMENT

210

Your Warranty Rights And Obligations

211

OHRV Manufacturer’s Warranty Coverage

211

Owner’s Warranty Responsibilities

212

BRP LIMITED WARRANTY FOR INTERNATIONAL: 2024 CAN-AM^®

SSV

213

1) Scope of the Limited Warranty

213

2) Limitation of Liability

213

3) EXCLUSIONS - Are Not Warranted

214

4) Warranty Coverage Period

214

5) For Products Sold In Australia Only

215

6) Conditions to Have Warranty Coverage

215

7) What to Do to Obtain Warranty Coverage

216

8) What BRP Will Do

216

9) Transfer

216

10) Consumer Assistance

216

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA,

THE COMMONWEALTH OF THE INDEPENDENT STATES AND TURKEY:

2024 CAN-AM^® SSV

218

1) Scope of the Limited Warranty

218

2) Limitations of Liability

218

3) EXCLUSIONS - Are Not Warranted

219

4) Warranty Coverage Period

220

5) For Products Sold In France Only

220

GENERAL INFORMATION

Congratulations on your purchase of a new Can-Am^® side-by-side vehicle. It's

backed by the BRP limited warranty and a network of authorized Can-Am Off--

road dealers ready to provide the parts, accessories or service you may require.

At delivery, you were informed of the warranty coverage and signed the Pre-de-

livery Check List to ensure your new vehicle was prepared to your entire

satisfaction.

Your dealer is committed to your satisfaction. If you need more information,

please ask your dealer.

Know Before you Go

To learn how to reduce the risk of accident for you or bystanders, read this Oper-

ator's Guide before you operate the vehicle.

Also, read all safety labels on your vehicle and watch the Safety Video located

at:

https://can-am.brp.com/off road/safety

Or use the following QR code.

This vehicle is for off-road use only. It is mainly for general recreational use but it

may also be used for utility purposes.

Failure to follow the warnings contained in this Operator's Guide can result in

SERIOUS INJURY or DEATH.

Safety Messages

The types of safety messages, what they look like and how they are used in this

guide are explained as follows:

The safety alert symbol

indicates a potential injury hazard.

WARNING

Indicates a potential hazard which, if not avoiided, coulld result iin seriious

injury or death.

CAUTION

Indicates a hazardous situatiion which, if not avoided, could resullt iin mi-

nor or moderate injjury.

GENERAL INFORMATION

NOTICE

Indiicates an iinstructiion which, iif not folllowed, could resullt in severely

damaged vehiicle components or other property.

About this Operator’s Guide

This Operator's Guide has been prepared to acquaint the owner/operator of a

new vehicle with the various vehicle controls, maintenance and safe operating in-

structions. It is indispensable for the proper use of the product.

Keep this Operator's Guide in the vehicle as you can refer to it for things such as

maintenance, troubleshooting and instructing others.

Note that this guide is available in several languages. In the event of any discrep-

ancy, the English version shall prevail.

If you want to view and/or print an extra copy of your Operator's Guide, simply

visit the following website:

www.operatorsguiides.brp.com

The information contained in this document is correct at the time of publication.

BRP, however, maintains a policy of continuous improvement of its products

without imposing upon itself any obligation to install them on products previously

manufactured. Due to late changes, some differences between the manufactured

product and the descriptions and/or specifications in this guide may occur. BRP

reserves the right at any time to discontinue or change specifications, designs,

features, models or equipment without incurring any obligation upon itself.

This Operator's Guide should remain with the vehicle when it is sold.

GENERAL PRECAUTIONS

Avoid Carbon Monoxide Poisoning

All engine exhaust contains carbon monoxide, a deadly gas. Breathing carbon

monoxide can cause headaches, dizziness, drowsiness, nausea, confusion and

eventually death.

Carbon monoxide is a colorless, odorless, tasteless gas that may be present

even if you do not see or smell any engine exhaust. Deadly levels of carbon mon-

oxide can collect rapidly, and you can quickly be overcome and unable to save

yourself. Also, deadly levels of carbon monoxide can linger for hours or days in

enclosed or poorly ventilated areas. If you experience any symptoms of carbon

monoxide poisoning, leave the area immediately, get fresh air and seek medical

treatment.

To prevent serious injury or death from carbon monoxide:

- Never run the vehicle in poorly ventilated or partially enclosed areas such as

garages, carports or barns. Even if you try to ventilate engine exhaust with

fans or open windows and doors, carbon monoxide can rapidly reach danger-

ous levels.

- Never run the vehicle outdoors where engine exhaust can be drawn into a

building through openings such as windows and doors.

Avoid Gasoline Fires and Other Hazards

Gasoline is extremely flammable and highly explosive. Fuel vapors can spread

and be ignited by a spark or flame many feet away from the engine. To reduce

the risk of fire or explosion, follow these instructions:

- Use only an approved gasoline container to store fuel.

- Never fill the gasoline container in the vehicle cargo box or on the vehicle - an

electrical static discharge may ignite the fuel.

- Strictly adhere to instructions in Vehicle fueling procedure.

- Never start or operate the engine if the fuel cap is not properly installed.

Gasoline is poisonous and can cause injury or death.

- Never siphon gasoline by mouth.

- If you swallow gasoline, get any in your eye(s), or inhale gasoline vapor, see

a doctor immediately.

If gasoline spills on you, wash with soap and water and change your clothes.

Avoid Burns from Hot Parts

Certain components like brake rotors and exhaust components become hot dur-

ing operation. Avoid contact with those parts during and shortly after operation to

avoid burn wounds.

Accessories and Modifications

Any modifications or addition of accessories approved by BRP may affect the

handling of your vehicle. It is important to take the time to get familiar with the ve-

hicle once modifications are made to understand how to adapt your driving be-

havior accordingly.

SAFETY INFORMATION

GENERAL PRECAUTIONS

Avoid installing equipment not specifically approved by BRP for the vehicle and

avoid unauthorized modifications. These modifications and equipment have not

been tested by BRP and may create hazards. For example, they could:

- Create a loss of control and increase risk of crash

- Cause overheating or short circuits increasing the risk of fire or burn injuries

- Affect the protection features provided by the vehicle.

- Affect the behavior of the trailer when the vehicle is transported

- Cause a risk of losing objects on the road when transported.

Your vehicle may also become illegal to ride.

Ask your authoriized BRP dealler for suiitablle avaiilablle accessoriies for your

vehiiclle.

SAFETY INFORMATION

SAFE OPERATION - RESPONSIBILITIES

This is a high performance off-road vehicle. Operators must be responsible and

use care to avoid rollovers, tipovers, collisions, and other accidents. Even with

vehicle safety features (such as protective structure, seat belts, side nets, doors)

and protective gear (such as a helmet), there is always a risk of injury or death in

these accidents. To reduce the risk of serious injury or death, follow the rules in

this section.

Owner - Be Responsible

Read this Operator's Guide and watch the Safety Video. Refer to the link at the

beginning of the Operator's Guide.

Always inspect and confirm the safe operating condition of your vehicle prior to

ride. Always follow the maintenance schedule described in this Operator's Guide.

Never allow anyone to operate your vehicle unless they are responsible and can

be trusted with a high performance vehicle. Consider supervising new or young

operators and setting rules and limits (e.g., whether they can carry passengers,

what they may do with the vehicle, where they may ride, etc.) for anyone using

your vehicle.

If equipped wiith optional D.E.S.S. keys, select the appropriate key (see Igni-

tion Switch and Keys) based on the operator's experience, vehicle use and

environment.

Discuss the safety information with anyone who will be using the vehicle. Be sure

that all operators and passengers meet the qualifications below and agree to fol-

low the safety information. Help users become familiar with the vehicle.

We encourage you to have an Annual Safety Inspection of your vehicle. Please

contact an authorized BRP dealer for further details. Though not required, it is

recommended that an authorized BRP dealer performs the preseason prepara-

tion of your vehicle. Each visit to your authorized BRP dealer is a great opportu-

nity for your dealer to verify if your vehicle is included in any safety campaign.

We also urge you to visit your authorized BRP dealer in a timely manner if you

become aware of any safety related campaigns.

See an authorized BRP dealer for available accessories you may require.

Operator - Be Qualified and Responsible

Read this Operator's Guide and watch the SAFETY video. Refer to the link at the

beginning of the Operator's Guide.

Become completely familiar with the operational controls and the general opera-

tion of the vehicle.

Take a training course if available (contact an authorized Can-Am dealer to find

out about training course availability as well as on the internet at http://www.roh-

va.org/), and perform the practice exercises in Practice Exercises section. Prac-

tice driving in a suitable area free of hazards and feel the response of each

control. Drive at low speeds. Higher speeds require greater experience, knowl-

edge and suitable riding conditions.

Be at least 16 years of age.

SAFETY INFORMATION

SAFE OPERATION - RESPONSIBILITIES

Be tall enough to be properly seated: back against the backrest with the seat belt

fastened, to hold the steering wheel with both hands and still be able to reach the

full stroke of brake and accelerator pedals with the right foot and to firmly plant

left foot on the footrest.

Have a proper driver's license in accordance with local laws.

Never use this vehicle with drugs or alcohol, or if tired or ill. These slow reaction

time and impair judgment.

Carrying Passengers

Only carry a maximum of two (2) passengers. The passengers must be properly

seated in the cockpit.

The passengers must be tall enough to always be properly seated: back against

the backrest with seat belt fastened, holding the handhold, and feet firmly planted

- for the RH passenger, with right foot on the footrest and the left foot on the ve-

hicle floor and for the central passenger, with both feet firmly planted on the floor.

Never carry passengers who have used drugs or alcohol, or are tired or ill. These

slow reaction time and impair judgment.

Instruct the passengers to read the vehicle’s safety labels.

Never carry passengers if you judge their ability or judgement insufficient to con-

centrate on the terrain conditions and adapt accordingly. More specifically for

side-by-side vehicles, the passenger must also pay constant attention to the ter-

rain ahead and be able to brace for bumps.

Riding Carefully

- This vehicle handles differently from other vehicles. A collision or rollover can

occur quickly, during abrupt maneuvers such as doing sharp turns, accelera-

tion or deceleration and driving on hills or over obstacles, if you fail to take

proper precautions.

- Never operate at excessive speeds. Always go at a speed that is proper for

the terrain, visibility, and operating conditions, and your experience.

- Never attempt jumps, side slides, donuts or any other stunts.

- Never attempt rapid acceleration or deceleration when performing a sharp

turn. This may result in a roll over.

- Never attempt skidding or sliding. If vehicle starts to skid or slide, counter

steer in the direction of skidding or sliding. On extremely slippery surfaces,

such as ice, go slowly and be very cautious in order to reduce the chance of

skidding out of control.

- Always be sure there are no obstacles or people behind the vehicle when you

operate in reverse. Pay attention to blind spots. When it is safe to proceed in

reverse, go slowly.

- Never exceed the stated load limits for this vehicle. Cargo must be properly

secured. Reduce speed, allow for greater braking distance and follow other

instructions in Moving Loads and Doing Work.

- Always remember that this vehicle is heavy! Its pure weight alone may entrap

you should it tip or rollover.

SAFETY INFORMATION

SAFE OPERATION - RESPONSIBILITIES

Occupant Restraint System

- This vehicle is designed to carry one (1) driver and up to two (2) passengers,

all wearing proper protective gears (refer to Riding Gear in this section).

- Doors or side nets must be latches and the seat belts buckled at all times

when vehicle is moving.

Terrain Condition

This vehicle is not designed to ride on paved surfaces; if you must shortly use

the vehicle on such surfaces, avoid abrupt inputs to steering wheel, accelera-

tor and brake pedals.

Always go slowly and be extra careful when operating on unfamiliar terrain.

Always be alert to changing terrain conditions when operating this vehicle.

Take the time to learn how the vehicle performs in different environments.

Never operate on excessively rough, slippery or loose terrain until you have

learned and practiced the skills necessary to control this vehicle on such ter-

rain. Always be especially cautious on these kinds of terrain.

Never operate this vehicle on hills too steep for the vehicle or your abilities.

Practice on small inclines.

Always follow proper procedures for climbing or going down hills as described

in Riding Your Vehicle. Check the terrain carefully before you start up or down

any hill. Never climb or descend hills with excessively slippery or loose surfa-

ces. Never go over the top of any hill at high speed.

Never attempt steep hills or side hilling when pulling a trailer.

–

Always check for obstacles before operating in a new area. Always follow

proper procedures when operating over obstacles as described in Riding

Your Vehicle.

Never operate this vehicle in fast flowing water or in water deeper than speci-

fied in Riding Your Vehicle. Remember that wet brakes may have reduced

stopping ability. Test your brakes after leaving water. If necessary, apply them

several times to let friction dry out the brakes.

Always ensure to properly park the vehicle on the flattest terrain section avail-

able. Put shift lever in PARK, stop engine and remove key before leaving the

vehicle.

If parking on a slope is inevitable, Placing a large rock or similar object behind

a wheel to block it from moving is recommended.

Never assume that the vehicle will go everywhere safely. Sudden changes in

terrain caused by holes, depressions, banks, softer or harder “ground” or oth-

er irregularities may cause the vehicle to topple or become unstable. To avoid

this, slow down and always observe the terrain ahead. If the vehicle does be-

gin to topple or rollover, the best advice is to immediately steer in the direction

of the rollover! Never attempt to prevent a rollover with your arms or legs. You

should keep your limbs inside the cage or ROPS (rollover protective

structure).

SAFETY INFORMATION

PRE-RIDE INSPECTION

Always inspect and confirm the safe operating condition of your vehicle prior to

ride.

Always follow the maintenance schedule described in this Operator's Guide.

WARNING

Perform a pre-riide inspection before each ride to detect any potentiiall

probllem that coulld occur duriing operatiion. The pre-ride inspection can

help you moniitor component wear and deterioratiion before they become

a probllem. Correct any probllem that you discover to reduce the risk of a

breakdown or crash.

Before using this vehicle, the operator should always perform the following pre--

ride inspection check list.

Refer to Maintenance Procedures for details.

Pre-Ride Inspection Check List

What to Do Before Starting the Engiine (Key OFF)

Items to Be

Inspection to Perform

Inspected

Engine oil

Check engine oil level.

(V-Twin engines)

Coolant

Check coolant level.

Brake fluid

Check brake fluid level.

Inspect the engine air filter, clean or replace if

Engine air filter

needed (service more often when riding in dusty

conditions).

Inspect and clean the CVT air filter (when riding in

CVT air filter

dusty conditions).

Heater air filters

Inspect heater air filters, clean if needed (service

(if equipped)

more often when riding in dusty conditions).

Brake holding

Apply brake holding mechanism and check if it

mechanism

operates properly.

(If equipped)

Radiator

Check cleanliness of the radiator.

Front grille

Inspect front grille for cleanliness.

If not already done, clean the area surrounding the

exhaust system, especially if during the last ride the

Exhaust system

vehicle was used in a swamp, bog, hay or dead

leaves.

SAFETY INFORMATION

PRE-RIDE INSPECTION

Items to Be

Inspectiion to Perform

Inspected

Drive shaft

Check drive shaft bellows and protectors condition.

bellows

Check tire pressure and condition. Refer to the Tire

Tires

Pressure Label and adjust according to load.

Check wheels for damage and for abnormal play.

Make sure that lug nuts are tightened. Refer to

Wheels

Wheels and Tires in Maintenance Procedures for

torque specification.

Cargo Load: If you transport a cargo, respect the

maximum loading capacity. Refer to Loading the

Cargo Box. Ensure cargo is properly secured to the

rear cargo box.

Cargo and load

Vehicle Load: Ensure that total load on the vehicle

(including operator, passengers, cargo, tongue

weight and added accessories) does not exceed

specifications. Refer to Carrying Loads.

Check if the cargo box and the tailgate are properly

Rear cargo box

latched.

If you are pulling a trailer or another equipment:

- Check hitch and trailer ball condition.

- Respect the tongue capacity and towing capacity

Hitch

as indicated on the label affixed to the hitch or

refer to Technical Specifications.

- Ensure trailer is properly secured to hitch.

Check underneath vehicle for any debris on chassis

Chassis and

or suspension components (upper and lower arms,

suspension

wheels, shock absorber, springs) and clean them

properly

Check all doors for any damage. Have the doors

Doors

replaced if any damage is found.

Close all doors and confirm that they latch securely.

What to Do Before Startiing the Engine (Key ON)

ITEMS TO BE

INSPECTION TO PERFORM

INSPECTED

Check operation of indicator lamps in digital

display(during first few seconds of key ON).

Digital display

Check for messages in gauge.

SAFETY INFORMATION

PRE-RIDE INSPECTION

ITEMS TO BE

INSPECTION TO PERFORM

INSPECTED

Check operation and cleanliness of:

- Headlights (High and Low)

Lights

- Taillights

- Brake lights.

Check if seats are properly latched.

Seats and seat

belts

Check seat belts for any damage. Fasten seat belts

and confirm that they latch securely.

Check side nets for any damage. Have the nets

replaced if any damage is found.

Fasten both side nets and confirm that they latch

Side nets

securely.

Use the adjustment strap to tighten the net as

required.

Press on the accelerator pedal a few times to ensure

Accelerator pedal

it operates freely and it returns to the rest position

when released.

Press down on the brake pedal and make sure you

Brake pedal

feel firm resistance and that it fully returns to position

when released.

Fuel level

Check the fuel level.

Mirror(s)

Adjust mirror(s) to your preferences.

(if equipped)

Horn

Check horn operation.

(if equipped)

Check operation of heater fan.

Heater fan

Check air flows out of every louver (dash-mounted

(CAB models)

and heater-mounted).

What to Do After the Engine is Started

Items to Be

Inspection to Perform

Inspected

Check if steering wheel operates freely by

Steering

completely turning it from side to side.

Turn the ignition switch to OFF to verify if engine will

Ignition switch

shut down. Restart engine.

Shift lever

Check operation of shift lever (P, R, N, H and L).

SAFETY INFORMATION

PREPARE TO RIDE

Before you Ride

Perform pre-ride inspection to confirm the safe operating condition of your ve-

hicle. Refer to Pre-Ride Inspection.

Driver and passengers must:

- Be properly seated.

- Latch nets or doors.

- Fasten seat belt.

- Wear appropriate riding gear. Refer to Riding Gear.

Riding Gear

It is important that the operator and passengers always wears appropriate pro-

tective clothing and apparel, including:

- An approved helmet

- Eye protection

- Boots

- Gloves

- A long sleeved shirt or jacket

- Long pants.

Depending on conditions, anti-fogging goggles may be required.

RIDING GEAR

1. Approved helmet

2. Eye and face protection

3. Long sleeves shirt or jacket

4. Gloves

5. Long pants

6. Boots (over-the-ankle footwear)

Weather conditions should help you decide how to dress. To maximize comfort

and avoid frostbites in winter, dress for the coldest weather expected. Thermal

underwear next to the skin also provides good insulation.

Never wear any loose clothing that may get entangled in the vehicle or on tree

branches and shrubs.

SAFETY INFORMATION

PREPARE TO RIDE

Helmets and Eye Protection

Helmets protect the head and brain from injury. Even with the vehicle's cage and

side nets, objects can enter the cockpit and strike the head, or the head can

strike the cage itself or objects outside the vehicle. Even the best helmet is no

guarantee against injury, but statistics indicate that helmet use significantly re-

duces the risk of brain injury. So, be safe and always wear a helmet while riding.

Choosing a Hellmet

Helmets should be manufactured to meet the appropriate standard in your state,

province or country and should fit properly.

A helmet with face protection is a better choice as it protects also against frontal

impacts. It can also protect against debris, stones, insects, the elements, etc.

An open-face helmet does not offer the same protection for the face and chin. If

you wear an open-face helmet, you should use a snap-on face shield and/or a

pair of goggles. Ordinary glasses or sunglasses are not sufficient eye protection

for riders. They can shatter or fly off, and they allow wind and airborne objects to

reach the eyes.

For winter riding conditions, a stocking type cap, balaclava and face mask should

always be carried or worn.

Use tinted face shields or goggles in the daytime only; do not use them at night

or in poor illumination. Do not use them if they impair your ability to discern color.

Other Riidiing Gear

Footwear

Always wear closed toe footwear. Sturdy over-the-ankle boots with non-slip soles

offer more protection and allow you to plant your foot properly on footrest.

Avoid long shoelaces that can be tangled in the accelerator or brake pedals.

For winter riding conditions, rubber soled boots with either a nylon or leather

uppers, with removable felt liners are best suited.

Avoid rubber boots. Rubber boots may get trapped behind or between pedals,

impairing the proper operation of brake and accelerator pedals.

Glloves

Full-fingered gloves protect hands from the wind, sun, heat, cold and flying ob-

jects. Gloves that fit snugly will improve grip on the steering wheel and help re-

duce hand fatigue. Sturdy, reinforced motorcycle or ATV gloves help protect

hands better in the event of an accident or a rollover. If gloves are too bulky, it

may be difficult to operate the controls.

For winter riding conditions, hands should be protected by a pair of snowmobile

gloves which have sufficient insulation and allow use of thumbs and fingers for

operation of controls.

Jackets, Pants and Riiding Suiits

Wear a jacket or a long sleeved shirt and long pants, or a full riding suit. Quality

ATV-type protective gear will provide comfort, and it can help you avoid being

SAFETY INFORMATION

PREPARE TO RIDE

distracted by adverse environmental elements. In case of a crash, good quality

protective gear made of sturdy material may prevent or reduce injury.

In cool-weather riding, protect yourself against hypothermia. Hypothermia, a con-

dition of low body temperature, can cause loss of concentration, slowed reac-

tions and loss of smooth, precise muscle movement. In cool conditions, proper

protective gear like a windproof jacket and insulated layers of clothing are essen-

tial. Even while riding at moderate temperatures, you can feel very cold due to

the wind.

Protective gear that is appropriate for cold-weather riding may be too hot when

stopped. Dress in layers so that clothing can be removed as desired. Topping the

protective gear with a windproof outer layer can prevent cold air from reaching

the skin.

Raiin Gear

If you must ride in wet weather, a rain suit or a waterproof riding suit is recom-

mended. On long rides, it is a good idea to carry rain gear. A dry rider will be

much more comfortable and alert.

Hearing Protectiion

Long-term exposure to wind and engine noise when riding can cause permanent

hearing loss. Properly worn hearing protective devices such as earplugs can help

prevent hearing loss. Check local laws before using any hearing protective

devices.

SAFETY INFORMATION

AVOID ACCIDENTS

Avoid Rollovers and Tipovers

Side-by-side vehicles handle differently from other vehicles. Side-by-side ve-

hicles are designed to handle off-road terrain (for example, their wheel base and

track width, ground clearance, suspension, drivetrain, tires, etc.), and, as a result,

can overturn in situations where vehicles designed for use primarily on paved or

smooth terrain may not.

A rollover or other accident can occur quickly during abrupt maneuvers such as

sharp turns or hard acceleration or deceleration when turning, or when driving on

hills or over obstacles. Abrupt maneuvers or aggressive driving can cause roll-

overs or loss of control even in flat open areas. If the vehicle rolls over, any part

of your body (such as arms, legs, or head) outside of the cockpit can be crushed

and trapped by the cage or ROPS or other parts of the vehicle. You can also be

injured by impact with the ground, cockpit or other objects.

To reduce the risk of rollovers:

- Use care when turning.

- Do not turn the steering wheel too far or too fast for your speed and envi-

ronment. Adjust steering inputs according to your speed and environment.

- Slow down before entering a turn. Avoid hard braking during a turn.

- Avoid sudden or hard acceleration when turning, even from a stop or low

speed.

- Never attempt donuts, skids, slides, fishtails, jumps, or other stunts. If vehicle

starts to skid or slide, steer in the direction of the skid or slide. Never slam the

brakes and lock the wheels.

- Avoid paved surfaces. This vehicle is not designed to operate on paved surfa-

ces and is more likely to roll over. If you must drive on pavement, turn gradu-

ally, go slowly, and avoid abrupt acceleration and braking.

This vehicle can roll over sideways or tip over forward or backwards on slopes or

uneven terrain.

- Avoid side hilling (driving along the slope rather than up or down a hill). When

possible, drive straight up and down inclines rather than across them. If you

must side hill, use extreme caution and avoid slippery surfaces, objects, or

depressions. If you feel the vehicle start to rollover or slide sideways, steer

downhill if possible.

- Avoid steep hills and follow procedures in this guide for climbing and de-

scending hills.

- Sudden changes in terrain such as holes, depressions, banks, softer or hard-

er ground or other irregularities may cause the vehicle to tip or become unsta-

ble. Observe the terrain ahead and slow down in areas of uneven terrain.

This vehicle will handle differently when carrying or pulling a load.

- Reduce speed and follow instructions in this manual for carrying cargo or pull-

ing a trailer.

- Avoid hills and rough terrain.

- Allow more distance to stop.

Be Prepared in Case of Rolllover

- Fasten side nets and fasten seat belt to help you avoid sticking out arms or

legs.

SAFETY INFORMATION

AVOID ACCIDENTS

- Never grab the cage or ROPS while riding. Hands can be crushed between

the cage or ROPS and the ground in a rollover. Keep hands on the steering

wheel or handholds.

- Never try to stop a rollover using your arms or legs. If you think that the ve-

hicle may tip or roll, the driver should keep both hands on the steering wheel

and the left foot firmly planted on the footrest. The passengers should keep

both hands on the handhold and both feet firmly planted on the floor.

Avoid Collisions

This vehicle can reach high speeds. At higher speeds, there is an increased risk

of losing control, particularly in challenging off-road conditions, and the risk of in-

jury in a collision is greater. Never operate at excessive speeds. Always go at a

speed that is proper for the terrain, visibility, and operating conditions, and your

experience. Consider reserving use of the performance key for situations in

which full speed and acceleration capability are appropriate.

Never operate this vehicle on any public street, road or highway, even dirt or

gravel ones. Riding your vehicle on roads or highways could result in a collision

with another vehicle. This vehicle is not designed for operation on roads. For ex-

ample, it does not meet motor vehicle safety standards that apply to automobiles.

In many jurisdictions it is not legal to operate this vehicle on public roads.

This vehicle does not have the same kind of protection for collisions as a car; for

example, there are no air bags, the cockpit is not fully enclosed, and it is not de-

signed for collisions with other vehicles. Therefore, it is particularly important to

fasten seat belts and side nets and wear an approved helmet.

SAFETY INFORMATION

RIDING YOUR VEHICLE

Practice Exercises

Before you go out for a ride, it is very important to familiarize yourself with the

handling of your vehicle by practicing in a controlled environment. If possible, it is

also a very good idea to take a more formal training course to sharpen your skills

and increase your knowledge of the vehicle.

Find a suitable area to practice and perform the following exercises. It should be

at least 45 m (150 ft) by 45 m (150 ft) free of obstacles like trees and rocks. Once

you’ve selected a suitable permitted location, proceed with the following

exercises.

Turning Exercises

Turning is one of the most frequent causes of accidents. It is easier for the ve-

hicle to lose traction or rollover if you turn too sharply, or go too fast. Slow down

when you approach a turn.

- First learn how to perform slight right turns at very low speeds. Release the

throttle before turning and slowly reapply the throttle when turning.

- Repeat turning exercise but this time maintain the throttle at the level while

turning.

- Finally, repeat turning exercise while accelerating slowly.

- Practice exercises turning on the other side.

Note how your vehicle reacts in these different exercises. We recommend releas-

ing the throttle before entering a turn to help initiate directional change. You will

feel the lateral force increasing with the speed and with your steering input. The

lateral force should be maintained as low as possible to make sure it does not

cause the vehicle to roll over.

U Turn Exerciises

Practice doing U turns.

- Accelerate slowly and while remaining at low speed, then gradually turn the

steering wheel to the right until you have completed the U turn.

- Repeat U turn exercise with different steering inputs and always at a very low

speed.

- Repeat U turn exercise on the other side.

As mentioned before in this guide, do not ride on paved surfaces as the vehicle

behavior will not be the same, increasing the risk of rollover.

Braking Exercises

Practice braking to get familiar with the brake response.

- Do it at low speed first, then increase the speed.

- Practice braking in straight line at different speeds and different braking force.

- Practice emergency braking; optimal braking is obtained in straight line, with

high force applied, without locking the wheels.

Remember, braking distance depends on vehicle speed, load and the type of

surface. Also, the tires and brakes conditions play a major role.

Reverse Exerciises

The next step involves using the reverse.

SAFETY INFORMATION

RIDING YOUR VEHICLE

- Install 1 cone marker on both sides of the vehicle beside each rear wheel.

Move the vehicle forward until you can see the cone markers, then stop the

vehicle. Acknowledge the distance required to see obstacles behind you.

- Learn how the vehicle handles itself in reverse and reacts with steering

inputs.

- Always perform this reverse exercise at slow speeds.

Emergency Engine Stoppiing Exerciise

Learn how to stop your engine quickly in an emergency situation.

- While running at low speed, simply turn the key to the off position.

This is to familiarize you with the vehicle’s reaction when the engine is turned off

while driving and to develop this reflex.

It is also important to be able to stop and exit the vehicle quickly.

- Immobilize the vehicle.

- Detach the seat belt and the net to exit the vehicle.

Off-Road Operation

The very nature of off-road operation is dangerous. Any terrain, which has not

been specially prepared to carry vehicles, presents an inherent danger where

terrain substance, shape and steepness are unpredictable. The terrain itself

presents a continual element of danger, which must be knowingly accepted by

anyone venturing over it.

An operator who takes a vehicle off-road should always exercise the utmost care

in selecting the safest path and keeping close watch on the terrain ahead of him.

The vehicle should never be operated by anyone who is not completely familiar

with the driving instructions applicable to the vehicle, nor should it be operated

on steep or treacherous terrain.

General Riding Techniques

General Driiviing Tips

Care, caution, experience and driving skill are the best precautions against the

hazards of vehicle operation.

Whenever there is the slightest doubt that the vehicle can safely negotiate an ob-

stacle or a particular piece of terrain, always choose an alternate route.

In off-road operation, power and traction, not speed, are important. Never drive

faster than visibility and your own ability to select a safe route permit. Always go

slowly and be extra careful when operating on unfamiliar terrain. Always be alert

to changing terrain conditions when operating this vehicle. Be especially cautious

on excessively rough, slippery, icy or loose terrain.

Constantly watch the terrain ahead for sudden changes in slopes or obstacles,

such as rocks or stumps, that may cause loss of stability, resulting in tip over or

rollover.

Never operate the vehicle if the controls do not function normally. See an author-

ized Can-Am Off-road dealer.

SAFETY INFORMATION

RIDING YOUR VEHICLE

To maintain proper control it is strongly advised that you keep your hands on the

steering wheel and within easy reach of all controls. The same holds true for your

feet. To minimize the possibility of any leg or foot injury, keep your left foot on the

footrest and right foot on the floor at all times. Staying completely within the cock-

pit will also help keep you from striking objects outside the vehicle.

Watch for and avoid branches and other objects that could enter the passenger

compartment and strike you or your passengers.

Operatiing iin Reverse

When operating in reverse, check that the path behind the vehicle is free of peo-

ple or obstacles. Pay attention to blind spots. When it is safe to proceed in re-

verse, go slowly and avoid sharp turns.

WARNING

Steeriing iinputs in reverse operation increase the riisk of rolllover.

NOTE:

In reverse operation, the engine RPM is limited thus limiting the vehicle reverse

speed.

WARNING

When driiving downhilll iin reverse, graviity can increase the vehiicle speed

above safe reverse speed.

Crossing Roads

If you have to cross a road, ensure to have complete visibility on both sides for in-

coming traffic and decide on exit point on other side of road. Drive in a straight

line toward that point. Do not make sharp direction changes or abrupt accelera-

tions as it may result in a rollover situation. Do not travel on sidewalks or bicycle

trails as they are designated specifically for those uses.

Ridiing on Paved Surfaces

Avoid paved surfaces. This vehicle is not designed to operate on paved surfaces

and is more likely to roll over. If you must drive on pavement, turn gradually, go

slowly, and avoid abrupt acceleration and braking.

Shalllow Water Crossiing

Water can be a unique hazard. If it is too deep the vehicle may “float” and topple.

Check the water depth and current before you attempt to cross any water. Water

depth should not exceed the center of the wheels for vehicle to safely cross the

obstacle. Beware of slippery surfaces such as rocks, grass, logs, etc., both in the

water and on its banks. A loss of traction may occur. Do not attempt to enter the

water at high speed.

Water will affect the braking ability of your vehicle. Make sure you dry the brakes

by applying them several times after the vehicle leaves the water.

SAFETY INFORMATION

RIDING YOUR VEHICLE

Mud or marsh lands may be encountered near water. Be prepared for sudden

“holes” or changes in depth. Similarly so, be watchful of hazards such as rocks,

logs, etc., partially covered by vegetation.

Riiding on Snow or Ice

When performing pre-ride inspection, pay special attention to locations on the ve-

hicle where snow and/or ice accumulations may obstruct visibility of the tail lamp,

clog ventilation openings, block the radiator and fan, and interfere with the move-

ment of controls. Before starting with your vehicle, check the steering, accelera-

tor and brake pedals for interference free operation.

Whenever this vehicle is ridden on a snow covered drive path, the tire grip is gen-

erally reduced causing the vehicle to react differently to control inputs from the

operator. On low grip surfaces, the steering responses are not as crisp and pre-

cise, stopping distances are lengthened and acceleration is also affected. Slow

down and be gentle on the accelerator. This will only result in spinning of the tires

and possibly in an over steering slide of the vehicle. Avoid hard braking. This will

possibly result in a straight line slide of the vehicle. Again, the best advice is to

safely reduce speed in anticipation of a maneuver to give yourself time and dis-

tance in order to keep control of the vehicle.

As you drive your vehicle over a loose snow covered surface, snow dust will be

picked up in the wake turbulence of the moving vehicle and transported to con-

tact and accumulate or melt on some exposed components including rotating

parts like brake discs. Water, snow or ice may affect the response time of the

brake system of your vehicle. Even when not required to reduce vehicle speed

apply brakes frequently to prevent ice or snow accumulation and to dry brake

pads and discs. While doing so in low risk driving situations you will test for grip

level and keep yourself alerted to how the vehicle reacts to your control inputs.

Always keep brake and accelerator pedals and floor boards free of snow and ice.

Frequently wipe snow off seat, steering wheel, headlights and tail lamps.

The depth of the snow cover may hide rocks, tree stumps or other objects and if

it is wet may totally impede the drivability as the vehicle becomes bogged down

or completely looses traction in slushy snow. Look far ahead and always be

watchful of any visible clues that might indicate the presence of such obstacles.

In doubt steer clear. Avoid driving on any frozen waterways before checking that

the ice will safely support the vehicle, its riders and its load of cargo.

At the end of each ride it is a good practice to clean the vehicle and all moving

components (brakes, steering components, drivelines, controls, radiator fan etc.)

from any snow or ice accumulations. Wet snow will turn to ice during the shut

down period and become more difficult to remove at the next pre-ride inspection.

Riiding on Sand

Sand and riding on sand dunes is another unique experience but there are some

basic precautions that should be observed. Wet, deep or fine sand may create a

loss of traction and cause the vehicle to slide, drop off or become “bogged” down.

If this occurs look for a firmer base. Again, the best advice is to slow down and

be watchful of the conditions.

SAFETY INFORMATION

RIDING YOUR VEHICLE

When riding in sand dunes it is advisable to equip the vehicle with an antenna

type safety flag. This will help make your location more visible to others over the

next sand dune. Proceed carefully should you see another safety flag ahead.

Ridiing on Gravell, Loose Stones or Other Sliippery Surfaces

Riding on loose stones or gravel is very similar to riding on ice. They will affect

the steering of vehicle, possibly causing it to slide and tip over especially at high

speeds. In addition, braking distance may be affected. Remember that “gunning”

the throttle or sliding may cause loose stones to be ejected rearwards into the

path of another rider's way. Never do it deliberately.

If you do get into a slide or skid, it may help to turn the steering wheel into the di-

rection of the skid until you regain control. Never jam the brakes and lock the

wheels.

Crossing Obstacles

Use the low range (L) for crossing obstacles.

Obstacles on the “trail” should be traversed with caution. This includes rocks, fall-

en trees, and depressions. You should avoid them whenever possible. Remem-

ber that some obstacles are too large or dangerous to cross and should be

avoided. As a guideline, never attempt to cross an obstacle higher than the

ground clearance of the vehicle. Small rocks or small fallen trees may be safely

crossed - approach obstacle at low speed and as much as possible at a right an-

gle. Adjust speed without losing momentum and do not accelerate abruptly. Pas-

sengers must grasp handhold firmly and brace feet on the floor. Hold steering

firmly without closing your fists around it and proceed. Be aware that the obstacle

may be slippery or may move while crossing.

Hilll Driiviing Condiitions

When driving on hills or slopes, two things are highly important: be prepared for

slippery surfaces or terrain variations and obstacles and brace yourself properly

inside vehicle. If you climb or descend a hill that is too slippery or has too loose a

surface, you can lose control. If you go over the top of a hill at high speed, you

may not have time to prepare for the terrain on the other side. Avoid parking on a

slope. Always put the shift lever in PARK when stopped or parked, especially on

an incline, to avoid rolling. If you must park on a steep incline, block the wheels

using rocks or bricks.

Uphiilll Driving

Use the low range (L) for uphill driving.

Due to its configuration, this vehicle has very good traction even while climbing,

so much so that tip over is possible before traction is lost. For example, it is com-

mon to encounter terrain situations where the top of the hill has eroded to a point

that the hill peak rises very sharply. This vehicle is not designed to negotiate such

a condition. Take an alternate route.

It is also wise to know the terrain condition on the other side of the hill or bank. All

too often there exists a sharp drop-off that is impossible to negotiate or descend.

SAFETY INFORMATION

RIDING YOUR VEHICLE

If you feel that the slope is getting too steep to climb, apply brakes to immobilize

vehicle. Put shift lever in reverse (R), and back down the hill, barely releasing

brakes to remain at low speed. Do not attempt to turn around. Never coast down

hill while vehicle is in neutral. Do not perform hard braking as it increases the risk

of tipover.

Downhiilll Driving

This vehicle can climb steeper slopes than it can descend safely. Therefore, it is

essential to assure that a safe route exists to descend a slope before you climb

it.

Decelerating while negotiating a slippery downhill slope could “toboggan” the ve-

hicle, causing it to slide. Maintain steady speed and/or accelerate slightly to re-

gain control. Never slam brakes and lock the wheels.

Siide Hillliing

Whenever possible, side hilling (driving across a slope rather than up or down it)

should be avoided. If necessary, do so with extreme caution. Side hilling on steep

inclines could result in rollover. In addition, slippery or unfirm surfaces could re-

sult in uncontrollable side sliding. Avoid all objects or depressions that will inten-

sify the raising of one side of the vehicle higher than the other, thus causing

rollover. If you feel the vehicle start to rollover or slide sideways, steer downhill if

possible.

WARNING

Be carefull when loading and transporting liiquiid reservoiirs. They can af-

fect vehiiclle stabillity when side hiillling by pullliing downhiilll and iincreasing

the riisk of a rolllover.

Drop-Offs

This vehicle is not designed to negotiate drop-offs. It will “bottom-out” and usually

stop if either the front or rear wheels are driven over a drop-off. If the drop is

sharp or deep, the vehicle will nose dive and tip over.

Avoid negotiating drop-offs. Reverse and select an alternate route.

Recreatiionall, Group and Distance Riiding

Respect the rights and limitations of others. Stay away from areas designated for

other types of off road use. This includes snowmobile trails, equestrian trails,

cross country ski trails, mountain bike trails, etc. Never assume there are no oth-

er users on the trail. Always stay to the right of the trail and do not zig zag to one

side of the trail then the other. Be prepared to stop or pull off to the side if another

trail user appears in front of you.

Join a local side-by-side vehicle club. It will provide you with a map and advice or

inform you where you can ride. If a club does not exist in your area, help to start

one. Group riding and club activities provide a pleasurable, social experience.

Never use this vehicle with drugs or alcohol, or tired or ill.

Always keep a safe distance from other riders. Your judgment of speed, terrain

conditions, weather, mechanical condition of your vehicle and the “trust in judg-

ment” you have in others around you will help you make a better choice of

SAFETY INFORMATION

RIDING YOUR VEHICLE

appropriate safe distance. This vehicle, like any other motorized vehicle, cannot

stop “on a dime”.

Before you ride, tell someone where you are planning to travel and your expected

time of return.

Depending on the length of your ride, carry additional tools or emergency equip-

ment. Find out where you can get additional gasoline. Be prepared for the possi-

ble conditions you may encounter. An emergency first aid kit should always be a

consideration.

Environment

One of the benefits of this vehicle is that it can take you off the beaten path away

from most communities. However, you should always respect nature and the

rights of others to enjoy it. Do not ride in environmentally sensitive areas. Do not

drive over forest crops or shrubs, nor cut down trees or take down fencing, nor

spin your wheels and destroy the terrain. “Tread Lightly”.

This vehicle can cause OHV wildfires if debris builds up near the exhaust or other

engine hot spots and ignites then falls off into dry grass. Avoid riding in wet

areas, through muskeg or tall grass, where debris can build up. Should you ride

in those areas, inspect and remove all debris from your engine and hot spots. Re-

fer to Vehicle Care for details.

Chasing wildlife is in many areas illegal. Wildlife can die of exhaustion after being

chased by a motorized vehicle. If you encounter animals on the trail, stop and ob-

serve quietly and with caution. It will be one of the better memories of your life.

Observe the rule “what you take in, carry out”. Do not litter. Do not start campfires

unless you have permission to do so, and then only away from dry areas. The

hazards you may create on the trail may cause injury to others or yourself, even

at a later date.

Respect farm lands. Always obtain the permission of the landowner before riding

on private land. Respect crops, farm animals and property lines.

Finally, do not pollute streams, lakes or rivers and do not modify the engine or ex-

haust system, or remove any of its components as it will alter the vehicle

emissions.

SAFETY INFORMATION

MOVING LOADS AND DOING WORK

Working with Your Vehicle

Your vehicle can help you perform a number of different LIGHT tasks ranging

from snow removal to pulling wood or carrying cargo. A variety of accessories

are available from your authorized Can-Am Off-road dealer. To prevent possible

injury, follow the instructions and warnings that accompany the accessory. Al-

ways respect the load limits of the vehicle. Overloading the vehicle can over-

stress the components and cause failure. Avoid overexerting yourself if you lift or

pull heavy loads or manually push the vehicle.

WARNING

Mounted machiinery must be llowered on the ground before leaving the

vehiiclle.

Carrying Loads

WARNING

Make sure alll accessories, cargo and lloose objjects inside the vehicle are

properlly secured, or remove iit to prevent from failling on the road and cre-

ating a hazard for folllowiing vehicles.

Any load carried on the vehicle will affect the handling, stability and braking dis-

tance of the vehicle. Do not exceed the load limits of the vehicle, including the

weight of operator, passengers, cargo, accessories and trailer tongue weight.

Always be aware that the “load” may slide or fall off and cause an accident.

Must use low gear if total payload is greater than 390 kg (860 lb).

Maxiimum Payload Liimit of the Vehiiclle

DPS

712 kg (1,570 lb)

Includes occupants,

cargo, tongue weight

and added accessories

Limited

600 kg (1,320 lb)

The following is an example of suitable total vehicle payload distribution:

Example of suitable payloads

Models with a 712 kg (1,570 lb) load limit, adjust according to your model load

limit.

Operator and

Cargo Box

Tongue

Total Vehicle

Accessories

Passengers

Load

Weight

Payload

220 kg

384 kg

40 kg

68 kg

712 kg (1,570

(485 lb)

(847 lb)

(88 lb)

(150 lb)

lb)

To reduce the risk to lose control or the load carried, follow these

recommendations.

SAFETY INFORMATION

MOVING LOADS AND DOING WORK

Vehiiclle Settiings When Carryiing Load

When carrying heavy loads or passengers, readjust suspension accordingly.

When carrying heavy loads in cargo box or pulling a loaded trailer, operate with

the shift lever in L (low range).

WARNING

Must use LOW GEAR if totall payload is greater than 390 kg (860 lb).

Loadiing the Cargo Box

NOTICE

When loading or unlloadiing, do not exceed the maximum cargo capaciity

on taillgate. Always close taiilgate before operatiing to reduce the riisk of

loss of load.

WARNING

When loading the flat bed, ensure to properly secure the cargo. An unse-

cured load can falll and cause seriious iinjjuries.

When the cargo box is on flat bed position, use these hooks to secure the load.

FLAT BED

Load cargo as low as possible - a higher load can raise the vehicle’s center of

gravity, which can reduce stability. Position cargo toward the front and center of

the cargo box and as evenly distributed as possible.

Secure the load to the tie down hooks inside cargo box. Use only the tie down

hooks on the bottom of the cargo box; do not secure cargo to the cage or other

part of the vehicle. If it is not properly secured, a load may slide or fall off, possi-

bly striking occupants or bystanders; or it may shift during riding, affecting the

handling of the vehicle.

Objects that are higher than the walls of the cargo bed may affect visibility for the

driver and may act as projectiles in case of an accident. Loads that protrude side-

ways can get snagged or caught in bush, branches or other obstacles. Avoid

SAFETY INFORMATION

MOVING LOADS AND DOING WORK

covering and obstructing the brake lights with the cargo. Ensure no cargo pro-

trudes outside the box and that cargo will not interfere with your visibility or con-

trol of the vehicle.

Do not overload cargo box.

WARNING

Do not overlload cargo box. Using the tillt bed on incliined pllane miight

cause risks of tipping the vehicle. Allways use the tillt bed when the vehiclle

is on flat plane.

Close tailgate before operating.

WARNING

Never operate the vehiicle with an open taiilgate.

Model

Maximum Cargo Load

Californian

Evenly distributed

272 kg (600 lb)

models

and safely

secured. Loaded

Cargo box

as low as

possible to

All other models

454 kg (1,000 lb)

reduce height of

center of gravity.

Only while

loading cargo into

All models

Tailgate

113 kg (250 lb)

cargo box. Never

operate with

tailgate open.

Operating Whiile Carryiing a Load

Reduce your speed when carrying cargo and turn gradually. Avoid hills and

rough terrain. Allow more distance for braking. This vehicle may require addition-

al stopping distance if carrying heavy loads, especially on inclined surfaces.

Tillting the Cargo Box

Tillting Usiing the Rellease Handles

The cargo box can be tilted to ease unloading. Use release handles on either

side of cargo box.

SAFETY INFORMATION

MOVING LOADS AND DOING WORK

1. Release handles

NOTICE

Always turn off engiine when tiilting the cargo box.

WARNING

– Allways ensure no one is standing behiind the cargo box before you ac-

tuate the release handle.

– The load weiight may affect the operatiion of the cargo box tillting fea-

ture (tilting or lowering).

– Some accessoriies assemblled on the cargo box may affect his behav-

ior during the opening and closure. Always pay attention during thiis

operation.

Be very careful with the operation of the tailgate and the cargo box as the load

may have moved during transport.

To lower the cargo box, simply push it down into place.

WARNING

– Keep yoursellf and others clear of the cargo box and vehiiclle frame

junctiion when loweriing cargo box.

– Ensure to properlly llatch the cargo box and the taiilgate before riiding.

– Make sure you do not lleave objjects between llifted cargo box and ve-

hicle frame to ensure proper latchiing of the cargo box when lowered.

Tiiltiing Using the Power-Tillt Bed

The cargo box can be tilted with the control switch located in the upper control.

To use the power-tilt bed, park the vehicle on a flat and even area.

If the vehicle can be started safely, let the engine idle while using the power-tilt

bed to avoid draining the battery

SAFETY INFORMATION

MOVING LOADS AND DOING WORK

Intensive use of the power-tilt bed could cause the built-in circuit breakers to mo-

mentarily turn off.

In such case, wait for a few minutes. The built-in breakers will automatically turn

back on once they have cooled down

CAUTION

– The power-tiilt bed iis NOT designed to keep the cargo up for long perii-

ods of tiime even if it iis empty.

WARNING

– Always ensure no one iis standiing behind the cargo box before you ac-

tuate the release handlle.

– The lload weight may affect the operatiion of the cargo box tiiltiing fea-

ture (tilltiing or lloweriing).

– Some accessories assembled on the cargo box may affect hiis behav-

ior duriing the openiing and closure. Allways pay attentiion duriing this

operatiion.

Be very careful with the operation of the tailgate and the cargo box as the load

may have moved during transport.

Hauling a Load

NOTICE

A BRP approved rear hitch must be properly iinstallled on the vehicle for

haulling traillers.

Never pull a load by attaching it to the cage or any other accessories; this can

cause the vehicle to tip over. Use only the trailer hitch (if installed) or winch (if in-

stalled) to pull a load.

In an emergency situation, use the recovery hook to recover a stuck vehicle.

SAFETY INFORMATION

MOVING LOADS AND DOING WORK

When pulling loads with a chain or cable, ensure that there is no slack before

starting and maintain tension while pulling.

When pulling loads with a chain or cable, be sure to brake progressively. The in-

ertia of the load could lead to an impact.

When hauling a load, respect the maximum hauling capacity. See Pulling a

Trailer below.

WARNING

A slack iin the chaiin or cable can cause iit to break and snap back.

When pulling another vehicle, be sure that someone is controlling the pulled ve-

hicle. They must brake and steer to prevent the vehicle from going out of control.

Before pulling loads with a winch, refer to the winch manufacturer’s instructions.

Reduce your speed when hauling a load and turn gradually. Avoid hills and rough

terrain. Never attempt steep hills. Allow more distance for braking, especially on

inclined surfaces and when a passenger is on board. Be careful not to skid or

slide.

Pulling a Trailer

NOTICE

A BRP approved rear hiitch must be properlly installled on the vehiclle for

hauliing traiilers.

Riding this vehicle with a trailer substantially increases the risk of toppling, espe-

cially on inclined slopes. If a trailer is used behind the vehicle make sure that its

hitch is compatible with the one on the vehicle. Make sure the trailer is horizontal

with the vehicle. (In some instances a special extension may have to be installed

on the vehicle hitch). Use security chains or cables to secure the trailer with the

vehicle.

Reduce your speed when pulling a trailer and turn gradually. Avoid hills and

rough terrain. Never attempt steep hills. Allow more distance for braking, espe-

cially on inclined surfaces and when a passenger is on board. Be careful not to

skid or slide.

Improperly loading a trailer may cause loss of control.

Always make sure load is evenly distributed and safely secured on the trailer; an

evenly balanced trailer is easier to control.

Always put the shift lever to L (low range) for hauling a trailer - in addition to pro-

viding more torque, operating in low range helps account for the increased load

on the rear tires.

When stopped or parked, block the vehicle and trailer wheels from possible

movement.

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS

(CANADA/UNITED STATES)

Safety Hang Tag

This vehicle comes with a hang tag and labels containing important safety

information.

Any person who rides this vehicle should read and understand this information

before riding.

THIS VEHICLE IS INTENDED FOR RECREATIONAL USE

AND SECONDARY GENERAL UTILITY APPLICATIONS

Tilt Table

NO OPERATOR UNDER AGE 16

TRAINING COURSES TO TEACH ROV DRIVING

Test Result

ARE AVAILABLE. FOR INFORMATION CONTACT

YOUR DEALER.

Read the Operator's Guide and Safety Labels

and Watch the Safety Video.

Follow All Instructions and Warnings.

BOMBARDIER RECREATIONAL PRODUCTS INC.

VEHICLE MODEL

CHECK WITH YOUR DEALER TO FIND OUT ABOUT

TILT TABLE RESULT

STATE OR LOCAL LAWS REGARDING ROV OPERATION.

Cause Severe Injury or Death

Be Prepared

Measurement of lateral stability, in degrees, of a

• Fasten seat belts and make sure nets or doors

sample, standard condition vehicle (with an

are securely latched in place.

operator and a passenger load - 430 pounds) as

measured by the manufacturer in accordance with

the tilt table lateral stability test in the ANSI/ROHVA

standard for Recreational Off-Highway Vehicles.

completely inside the vehicle.

Vehicle modification, accessories, and loading can

Drive Responsibly

affect lateral stability.

Avoid loss of control and rollovers:

Training courses to teach ROV driving are available.

never do donuts.

For information contact your dealer and/or

rohva.org.

terrain. Avoid paved surfaces.

Check with your dealer to find out about state or

local laws regarding ROV operation.

Rollovers have caused severe injuries and death,

THIS HANG TAG IS NOT TO BE REMOVED BEFORE SALE.

Be Sure Riders Pay Attention and Plan Ahead

If you think or feel the vehicle may tip or roll,

reduce your risk of injury :

VEHICLE MODEL NAME:

and brace yourself.

ENGINE DESCRIPTION:

vehicle for any reason.

Require Proper Use of Your Vehicle

EPA CERTIFIED

- Do your part to prevent injuries:

NER (NORMALIZED EMISSION RATE) =

ON 0 TO 10 SCALE, 0 BEING THE CLEANEST.

BOMBARDIER RECREATIONAL PRODUCTS INC

*NO TO BE REMOVED PRIOR SALE.

card

Vehicle seating capacity:

Occupants

THIS HANG TAG CAN’T BE REMOVED BEFORE SALE.

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS(CANADA/UNITED STATES)

Safety Labels

Read and understand all the safety labels on your vehicle.

These labels are affixed to the vehicle for the safety of the operator, passengers

or bystanders.

The following labels are on your vehicle, and they should be considered perma-

nent parts of the vehicle. They need to be clean and visible at all times. If missing

or damaged, they need to be replaced. Safety labels are free of charge. See an

authorized Can-Am Off-road dealer.

Upon replacement of parts that have warnings on them, make sure to order (free

of charge) the applicable safety warnings if not already installed on the replace-

ment part.

NOTE:

In the event of any discrepancy between this guide and the vehicle, the safety la-

bels on the vehicle have precedence over the labels in this guide.

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS(CANADA/UNITED STATES)

Generall Operating Warniing Label

Models Without CAB

Be Prepared

• Fasten seat belts and make sure nets or doors are securely latched in place.

Stay completely inside the vehicle.

Drive Responsibly

Avoid loss of control and rollovers:

stop.

changes in traction and terrain.

Avoid paved surfaces.

Models With CAB

Improper Use of O -Highway Vehicles Can Cause

Severe Injury or Death

Be Prepared

• Fasten seat belts and make sure nets or doors are securely latched in place.

• Wear an approved helmet and protective gear.

• Each rider must be able to sit with back against seat, foot at on the oor or

on footrest, and hands on steering wheel or handholds. Stay completely inside

the vehicle.

Drive Responsibly

Avoid loss of control and rollovers:

• Avoid abrupt maneuvers, sideways sliding, skidding or !shtailing, and never do

donuts.

• Avoid hard acceleration when turning, even from a stop.

• Slow down before entering a turn.

• Plan for hills, rough terrain, ruts, and other changes in traction and terrain.

Avoid paved surfaces.

• Avoid side hilling (riding across slopes).

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS(CANADA/UNITED STATES)

Passenger Warning Labell

Models Without CAB

PASSENGER(S)

Improper Use of this Vehicle Can Cause Severe Injury or Death

Be Prepared

• Fasten seat belt and make sure net or door is securely latched in place.

• Wear an approved helmet and protective gear.

and hands on handholds. Stay completely inside the vehicle.

Be Sure Riders Pay Attention and Plan Ahead

If you think or feel the vehicle may tip or roll, reduce your risk of injury:

•

• Do not put any part of your body outside of the vehicle for any reason.

PASSENGER QUALIFICATIONS AND RESPONSIBILITIES

• Do not ride after using drugs or alcohol.

• Ask the operator to slow down or stop if you feel uncomfortable when riding.

Models With CAB

PASSENGER(S)

Improper Use of this Vehicle Can Cause Severe Injury or Death

Be Prepared

• Fasten seat belt and make sure net or door is securely latched

in place.

• Wear an approved helmet and protective gear.

You must be able to sit with back against seat, foot at on the oor or on footrest,

and hands on handholds. Stay completely inside the vehicle.

Be Sure Riders Pay Attention and Plan Ahead

If you think or feel the vehicle may tip or roll, reduce your risk of injury:

• Keep a !rm grip on handholds and brace yourself.

• Do not put any part of your body outside of the vehicle for any reason.

PASSENGER QUALIFICATIONS AND RESPONSIBILITIES

• Do not ride after using drugs or alcohol.

• Ask the operator to slow down or stop if you feel uncomfortable when riding.

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS(CANADA/UNITED STATES)

Rolllover — Warniing Labels

LH side

RH Side

Be prepared in case of

rollover

If the vehicle rolls over,

any part of your body

(such as arms, legs, or

head) outside of the

cockpit can be crushed

by the cage or other

parts of the vehicle.

Fasten seat belt and

make sure net and/or

door is securely latched

in place to help you

avoid sticking out arms

or legs.

hold the

cage while riding.

try to stop

a rollover using

your arm or leg.

9028

9030

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS(CANADA/UNITED STATES)

2WD/4WD Selection — Warning Labell

Put the Shift

Stop the vehicle and

Must use Low Gear if total payload is greater than

Lever to PARK (P)

apply the Brake before

390 kg (860 lb).

before exiting

using the Shift Lever,

vehicle.

the 2WD/4WD Switch

Total payload includes weight of

The vehicle can

operator, passenger, cargo, accessories

roll if not in PARK.

Switch.

and trailer tongue weight if applicable.

8126

Tire Pressure and Maximum Load – Warning Label

WARNING

NEVER carry passenger in cargo box or on gate.

Improper tire pressure or overloading can cause loss of control.

NEVER place gasoline container inside cargo box

Loss of control can result in severe injury or death.

when filling it. This can lead to an explosion.

An underinflated tire can come off the rim.

NEVER exceed the vehicle load capacity (see table),

To reduce the risk of loss of control or loss of load:

including weight of operator, passenger, cargo,

When loading cargo:

When carrying a load:

accessories and trailer tongue weight if applicable.

Position cargo towards

Reduce your speed

NEVER exceed REAR LOAD CAPACITY (Refer to label

front and center ans as

and turn gradually.

below), evenly distributed

low as possible.

Avoid hills and rough terrain.

(including trailer tongue weight if applicable).

Latch tail gate.

Allow more distance to stop.

ALWAYS secure the load.

DEFENDER

6 X 6

PRO

PACKAGE

LTD

OTHERS

LTD

OTHERS

COLD TIRE

FRONT:

kPa

(psi)

124 ( 18 )

103 ( 15 )

110 ( 16 )

138 ( 20 )

PRESSURE

REAR:

kPa

(psi)

124 ( 18 )

103 ( 15 )

110 ( 16 )

145 ( 21 )

152 ( 22 )

MAX LOAD CAPACITY:

( lb )

---

545 (1200)

---

600 ( 1320 )

712 ( 1570 )

CALIFORNIA

MAXIMUM CARGO LOAD:

( lb )

---

272 (600)

---

272 ( 600 )

MAX LOAD CAPACITY:

( lb )

712 ( 1570 )

545 ( 1200 )

771 ( 1700 )

600 ( 1320 )

712 ( 1570 )

OTHERS

MAXIMUM CARGO LOAD: kg ( lb )

454 ( 1000 )

Refer to your Operator’s Guide for more information about cargo box use.

Pullling a Load Using the Cage – Warniing Label

NEVER attach to the cage to pull a load.This can cause the vehicle

to tip over. Use only the trailer hitch to pull a load.

8188

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS(CANADA/UNITED STATES)

Cargo Box Retaining Tool – Warning Label

To reduce the risk of severe injuries, you must use

the designated BRP tool to secure the platform

when you need to disconnect the attachment

from the holding cylinder.

Refer to the shop manual for further informations.

Off–Road Usage – Warning Label

intended for use on public roads

Ce véhicule est conçu pour un

usage hors route et n'est pas

destiné aux voies publiques

7881

Lower Storage Box Use – Warniing Label

NEVER place gasoline, !ammable or dangerous

liquids container in the lower box storage.

This can lead to a "re or explosions.

8378

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS(CANADA/UNITED STATES)

Compliance HangTag

Callifornia Proposiition 65 Warning - Hang Tag

. Operating, servicing and

WARNING

maintaining an off-road vehicle can expose

you to chemicals including engine exhaust,

carbon monoxide, phthalates, and lead,

which are known to the State of California

to cause cancer and birth defects or other

reproductive harm.

To minimize exposure, avoid breathing

exhaust, do not idle the engine except as

necessary, service your vehicle in a

well-ventilated area and wear gloves or wash

your hands frequently when servicing your

vehicle.

For more information go to

www.P65Warnings.ca.gov/products/

passenger-vehicle

704906872

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL

COUNTRIES EXCEPT CANADA/UNITED STATES)

Safety Pictogram

free of charge. See an authorized

Can-Am Off-road dealer.

Read and understand all the safety la-

bels on your vehicle.

Upon replacement of parts that have

warnings on them, make sure to order

These labels are affixed to the vehicle

(free of charge) the applicable safety

for the safety of the operator, passen-

warnings if not already installed on the

gers or bystanders.

replacement part.

The following labels are on your ve-

hicle, and they should be considered

NOTE:

permanent parts of the vehicle. They

In the event of any discrepancy be-

need to be clean and visible at all

tween this guide and the vehicle, the

times. If missing or damaged, they

safety labels on the vehicle have

need to be replaced. Safety labels are

precedence over the labels in this

guide.

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/UNITED STATES)

Operator Warning Labell

WARNING

– Read and understand alll safety labells, llocate and read operator''s

guiide.

– Always wear an approved hellmet and protective gear.

– Fasten seat bellts and make sure net or door iis securelly latched in

pllace.

– Always wear ear protection.

– Each riider must be ablle to sit with back agaiinst seat, feet fllat on the

flloor or on footrest, and hands on steeriing wheell or handholds.

– If you think or feell the vehiicle may tiip or rolll, reduce your riisk of in-

jury : Keep a firm griip on the steering wheel or handhollds and brace

yoursellf. Do not put any part of your body outsiide of the vehicle for

any reason.

– Always stay completelly inside the vehiicle.

7947

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/UNITED STATES)

Generall Warniing Labell

WARNING

– Make sure operators are 16 or ollder wiith a valiid driiver''s license.

– Do not exceed seating capaciity: 3 occupants.

– Do not let peoplle driive or riide after usiing alcohol or drugs.

– Avoid lloss of controll and rolllovers:

– Avoiid abrupt maneuvers, sideways slliding, skiiddiing or fishtaiil-

ing, and never do donuts.

– Avoiid hard acceleration when turniing, even from a stop.

– Slow down before entering a turn.

– Plan for hiillls, rough terrain, ruts, and other changes in tractiion

and terraiin.

– Avoiid paved surfaces.

– Avoiid siide hiillling (ridiing across slopes).

– Rolllovers have caused severe iinjjuries and death, even on fllat, open

areas.

– Do not alllow operatiion on publlic roads (unless designated for off--

highway vehiicle access) – collliisions wiith cars and trucks can occur.

– Watch the safety viideo using the QR code liink or visiit Can-am web

site before operation.

16⁺

max

https://can-am.brp.com/off-road/safety

7949

Patent : www.brp.com/en/about-brp/patents.html

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/UNITED STATES)

Passenger Warning Labell

WARNING

– Always wear an approved hellmet and protective gear.

– Always wear ear protection.

– Fasten seat bellts, and make sure net or door is securely llatched iin

pllace.

– Each riider must be ablle to sit with back agaiinst seat, feet fllat on the

flloor or on footrest, and hands on handholds.

– If you think or feell the vehiicle may tiip or rolll, reduce your riisk of

injury:

– Keep a fiirm grip on the steeriing wheel or handholds and brace

yourself.

– Do not put any part of your body outsiide of the vehiicle for any

reason.

– Always stay completelly inside the vehiicle.

– Do not llet people drive or ride after using alcoholl or drugs.

7951

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/UNITED STATES)

Tiire Pressure and Maxiimum Load – Warning Labell

WARNING

– Locate and read operator''s guide. Improper tiire pressure or over-

loading can cause lloss of controll, resultiing iin SEVERE INJURY or

DEATH.

– Allways maintaiin proper tire pressure as shown.

– NEVER exceed the vehicle lload capacity, iinclluding weiight of opera-

tor, passenger, cargo, accessoriies and traiiler tongue weiight iif

appllicable.

– Do not overlload cargo box.

– NEVER pllace gasolline contaiiner inside cargo box when fiillling it.

This can lead to an expllosiion.

– NEVER carry passenger in cargo box or on taillgate.

NRMM models

227 (500)

kg (lb)

kPa (psi)

< kg (lb)

97 14)

124 (18)

97 (14)

228 (33)

680 (1500)

454 (1000)

XMR

97 14)

179 (26)

97 (14)

179 (26)

390 (860)

kg (lb)

kPa (psi)

PRO

124 (18)

138 (20)

152 (22)

234 (34)

771 (1700)

454 (1000)

152 (22)

165 (24)

234 (34)

680 (1500)

454 (1000)

Other models

< kg (lb)

kPa (psi)

< kg (lb)

97 ( 14 )

124 ( 18 )

680 ( 1500 )

454 ( 1000 )

XMR

97 ( 14 )

179 ( 26 )

680 ( 1500 )

454 ( 1000 )

124 ( 18 )

138 ( 20 )

771 ( 1700 )

454 ( 1000 )

152 ( 22 )

165 ( 24 )

794 ( 1750 )

454 ( 1000 )

INT

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/UNITED STATES)

Cargo Box Retaiiniing Tooll – Warning Piictogram

WARNING

– To reduce the riisk of severe injjuriies, you must use the designated

BRP tool to secure the platform when you need to disconnect the at-

tachment from the hollding cyllinder.

– Refer to the serviice manual for further informatiions.

2WD/4WD Sellection – Warniing Pictogram

WARNING

– Stop the vehiicle and apply the brake before using the shiift lever and

the 2WD/4WD switch.

– When the weight of occupant(s), cargo and tongue iis above 390 kg

(860 lb), set the shift lever to llow gear range (L).

– Put the shift lever to PARK (P) before exiting vehiicle. The vehicle

can rolll iif not in PARK.

STOP

> 390 kg (860 lb)

STOP

8894

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/UNITED STATES)

Towiing and Tongue Weight - Warning Labell

WARNING

– MAXIMUM towiing capaciity: 1134 kg (2500 lb).

– MAXIMUM tongue weiight: 114 kg (250 llb).

– When pullliing a trailler, set the shift lever to low gear range (L).

– Reduce your speed and turn graduallly.

– Avoiid hillls and rough terrain.

– Alllow more diistance to stop.

< 1134 kg (2500 lb) 11121 N

< 114 kg (250 lb) 1112 N

Lower Storage Box Use – Warniing

Cargo Box Piinch Poiint - Warning

Piictogram

Labell

WARNING

NEVER pllace gasolline, fllam-

– Piinch point. Keep clear

mable or dangerous liiquiids con-

when llowering cargo box.

tainer in the lower storage box.

Thiis can lead to a fire or

expllosiions.

7956

SAFETY INFORMATION

IMPORTANT ON-PRODUCT LABELS (ALL COUNTRIES EXCEPT CANADA/UNITED STATES)

Pullliing a Load Using the Cage –

Wiinch Installlatiion - Warning Labell

Warning Label

WARNING

– Never use the frame near

– NEVER attach to the cage to

this llocation to ground any

pulll a load. Thiis can cause

ellectrical component such

the vehicle to tip over. Use

as a wiinch.

only the trailler hiitch or re-

– When in use, the ellectrical

covery hook to pulll a load.

component may induce an

undesiired power steering

siignal resulting iin an unin-

tended steeriing iinput.

– In certain circumstances,

some unintended steering

input coulld lead to a lloss of

vehicle control increasing

the risk of serious INJURY or

DEATH.

7689

SAFETY INFORMATION

REPORTING SAFETY DEFECTS

In Canada, if you believe that your vehicle has a defect which could cause a

crash or could cause injury or death, you should immediately inform Transport

Canada in addition to notifying Bombardier Recreational Products Inc.

If Transport Canada receives similar complaints, it may open an investigation,

and if it finds that a safety defect exists in a group of vehicles, it may order a re-

call and remedy campaign. However, Transport Canada cannot become involved

in any individual problems between you, your dealer or Bombardier Recreational

Products Inc.

To contact Transport Canada:

819-994-3328 (Gatineau-Ottawa area or internationally)

Toll free : 1 800-333-0510 (in Canada)

Transport Canada - ASFAD

330 Sparks Street

Ottawa, ON

K1A 0N5

https://www.tc.gc.ca/recallls

SAFETY INFORMATION

PRIMARY CONTROLS

Steering Wheel

To decrease vehicle speed or to stop

vehicle, press down the brake pedal

The steering wheel is located in front

with your right foot.

of the driver's seat.

The brake pedal is spring loaded and

The steering wheel steers the vehicle

should return to rest position when not

to the left or right.

pressed.

Turn the steering wheel in the direc-

tion you want to go.

Shift Lever

The shift lever is located on the upper

Grip the steering wheel with both

console to the right of steering wheel.

hands, without having thumbs rolled

around the steering wheel.

The shift lever is used to change the

gearbox position.

CAUTION

Under rough traill condiitiions or

when crossing an obstaclle, the

steeriing wheell coulld suddenlly

jerk on one side, causing hand or

wrist injuriies iif the thumbs are

rollled around the steering wheell.

A dynamic power steering (DPS) re-

duces the effort to turn the steering

wheel.

TYPICAL

1. Shift lever

Accelerator Pedal

2. Park

The accelerator pedal is located on

3. Reverse

the right side of the brake pedal.

4. Neutral

5. High range (forward)

The accelerator pedal controls the en-

6. Low range (forward)

gine speed.

The vehicle must be

stopped

and

To increase or maintain vehicle

brakes applied prior to selecting any

speed, press on the accelerator pedal

gear.

with your right foot.

To decrease vehicle speed, release

WARNING

the accelerator pedal.

Thiis gearbox iis not desiigned to

shift whiile vehiicle is moving.

The accelerator pedal is spring loaded

and should return to rest position (idle)

when not pressed.

Park

The park position locks the gearbox to

Brake Pedal

help prevent vehicle movement.

The brake pedal is located on the left

side of the accelerator pedal.

WARNING

The brake pedal function is to slow

Always use the PARK (P) posiitiion

down or stop the vehicle.

when the vehiiclle is not iin opera-

tiion. The vehiiclle can rolll if the

shift lever is not set to P (PARK).

PRIMARY CONTROLS

Reverse

The reverse position allows the ve-

hicle to go backwards.

Depending upon your particular ve-

hicle configuration, a back-up alarm

may be equipped on the vehicle. It

goes on automatically when the re-

verse gear is selected.

NOTE:

In reverse operation, the engine RPM

is limited thus limiting the vehicle re-

verse speed.

WARNING

When driiving downhilll iin reverse,

gravity can iincrease the vehicle

speed above safe reverse speed.

Neutral

The neutral position disengages the

gearbox.

High Range (Forward)

This position selects the high speed

range of the gearbox. It is the normal

driving speed range. It allows the ve-

hicle to reach its maximum speed.

Low Range (Forward)

This position selects the low speed

range of the gearbox. It allows the ve-

hicle to move slowly with maximum

torque at the wheels.

NOTICE

Use the llow speed range to pulll a

trailer, carry heavy cargo, go over

obstacles or drive uphiilll and

downhiilll.

SECONDARY CONTROLS

Ignition Switch and Keys

Keys

The ignition switch is located on the

Basic Key

upper console area.

The vehicle is delivered with 2 basic

key.

Those 2 mechanical keys do not have

speed or torque restrictions.

D.E.S.S. Key (Avaiilable as an

optiion)

For all D.E.S.S. related option, see an

authorized Can-Am Off-road dealer

for information.

Digiitallly Encoded Securiity System

1. OFF

(D.E.S.S.)

2. ON

3. START

The ignition keys contain an electronic

circuit that gives it a unique electronic

OFF

serial number.

The key can be inserted or removed in

The D. E. S. S. system reads the key

this position only.

code and allows engine starting for

In OFF position, the electrical system

keys it recognizes.

of the vehicle is disabled.

This vehicle can be operated using 3

The engine is shut down by turning

different types of key programming:

the ignition switch to OFF position.

- Work

- Normal

- Performance

When the key is turned in this position,

Refer to your dealer for complete

the electrical system of the vehicle is

information.

activated.

NOTE:

The gauge should wake-up.

Additional keys are available from

The vehicle lights are turned on.

your dealer as an accessory.

The engine can be started.

WARNING

START

Rolllovers, tiipovers, colllisions and

loss of control resullting in serious

This position starts the engine.

injury or death are possiible with

NOTE:

the performance or normal key.

If the ignition switch is left ON for more

Using the normal key is not a sub-

than 30 minutes, engine will not start

stitute for the operator being pre-

unless ignition switch is turned OFF,

pared, qualiified, and operating

then ON again.

wiith care.

Performance Key

SECONDARY CONTROLS

The performance key allows the user

to access the full torque of the engine

as well as the top speed of the

vehicle.

This may be useful for riders who pre-

fer crisper throttle response, and for

environments where higher speeds

and greater acceleration are appropri-

ate. For example, in wide-open

straight trails, operators may prefer

the performance key.

Normal Key

Engine Start/Stop Button

The normal key limits the vehicle

speed to 70 km/h (43 MPH) and ap-

The engine start / stop button is lo-

plies a torque reduction.

cated on the upper console, at the

right of the steering wheel.

Work key

The work key allows for usage of

100% of maximum engine torque but

limits vehicle speed to 40 km/h (25

MPH).

WARNING

On steep downhillls, the engine

speed llimiter may not prevent the

vehicle from accelerating beyond

this speed.

This key may be useful for riders who

When pressed and held, it starts the

prefer more gradual acceleration, or

engine.

for riding in environments where full

speed and high acceleration are not

the engine is running, when

desirable. For example, in narrow,

pressed, it stops the engine.

winding trails, operators may prefer a

normal key.

NOTE:

The RF D.E.S.S. key must be installed

RF D.E.S.S. Post

on the RF D. E. S. S. post to allow en-

The D. E. S. S. post is located on the

gine start.

upper console.

To power up the electrical system

without starting the engine, refer to

Waking Up the Electrical System.

D.E.S.S. Fllexiibillity

The D. E. S. S. of your vehicle can be

programmed by your authorized Can--

Am Off-road dealer to accept up to 8

different keys.

SECONDARY CONTROLS

If you have more than one D. E. S. S.

The 2WD/4WD/Front Diff Lock switch

equipped your vehicle, each can be

is located on the upper console.

programmed by your authorized Can--

Am Off-road dealer to accept the other

vehicle D.E.S.S. keys.

2WD/4WD Switch

Modells wiithout Smart-Lok

The 2WD/4WD switch is located on

the upper console.

This switch selects 2 wheel drive or 4

wheel drive mode when the vehicle is

stopped.

Once the vehicle 4WD mode is en-

gaged, the front diff lock can be acti-

vated when the switch is pushed

upwards.

The front diff. lock can be activated on

the fly, no need to stop the vehicle to

engage. To deactivate, push again on

the switch. When the engine is

This switch selects 2 wheel drive, or 4

stopped, the front diff. lock will be

wheel drive mode when the vehicle is

deactivated.

stopped.

NOTICE

The vehicle must be stopped to

The vehiiclle must be stopped to

engage or disengage the 2WD/

engage or disengage 2WD/4WD

4WD switch.

swiitch.

Mechaniicall damage may occur if

switch iis engaged or diisengaged

swiitch iis engaged or disengaged

whille driving.

whiile driiviing.

Always unlock the front diff. be-

fore disengaging 4WD.

The 4WD mode is engaged when the

switch is pushed upwards.

The front differential is fully locked

when the switch is pushed upward. It's

The 2WD mode is engaged when the

a momentary position. When the front

switch is pushed downwards. The ve-

diff. is locked, the switch light will illu-

hicle is then rear wheel drive only.

minate and a message will appear in

the cluster for 2 seconds to say "DIFF

2WD/4WD/Front Diff Lock

LOCK". A padlock pictogram will ap-

Switch

pear inside the 4x4 logo. The light will

turn off when the differential is un-

Modells wiith Smart-Lok

locked and a message in the cluster

will appear and show "SMART-LOK",

SECONDARY CONTROLS

meaning that you are back in the auto-

This switch enables locking of rear

matic mode. For all models with Smar-

differential.

t-Locker, the AUTO pictogram will lit

above the 4x4 logo in the cluster.

NOTICE

The vehiclle must be stopped to

When the front differential is locked,

engage or diisengage the differen-

the effort to turn the steering wheel

tial switch.

might be higher and the response

The vehiclle must be in gear (not

might be slower.

in Park) to proceed

Mechanical damage may occur iif

WARNING

swiitch is engaged or disengaged

Abruptly changiing direction can

whiile driviing.

cause lloss of controll or injjury.

Never engage Front Diff Lock be-

The rear differential is locked when

fore entering a turn or when

the switch is pushed upwards and un-

turning.

locked when the switch is pushed

downwards.

The front differential is locked and the

If the vehicle is in Park and the switch

4WD mode is engaged when the

is pushed downwards, the rear differ-

switch is pushed upwards.

ential will stay locked.

The 4WD mode is engaged when the

switch is in the middle.

Keypad

The 2WD mode is engaged when the

The keypad is used to navigate

switch is pushed downwards. The ve-

through various menus and options

hicle is then rear wheel drive only.

when the

7.6" Digital Display is

installed.

Rear Differential Lock Switch

The keypad is located on the upper

The rear differential lock switch is lo-

console.

cated on the upper console.

Climate Controls

CAB Modells Onlly

The climate controls unit are located

in center of the upper console.

They control the flow and the temper-

ature of the air circulated in the

vehicle.

SECONDARY CONTROLS

Refer to your Winch Guide included

with your vehicle for proper winch

operation.

1. Press the switch to open the

window.

Headlight Dimmer Switch

2. Lift the switch to close the window.

The headlight dimmer switch is lo-

cated on the upper console.

Wiper / Windshield Washer

Switch

The wiper / windshield washer switch

is located overhead, to the left of the

central mirror.

This switch is used to select either the

headlights OFF position, low or high

beams.

Power Window Switches (If

Equipped)

The power window switches are lo-

cated on the door panel. Two switches

This switch is used to select either the

on the driver side and one on the pas-

OFF, wipe or wash-and-wipe

senger side.

positions.

EQUIPMENT

Tilt Steering

Two cup holders are located on each

side of the dash near the side nets at-

The steering wheel height is

tachment points.

adjustable.

Adjust the steering wheel height to

face your chest, not your head.

To adjust steering wheel height:

1. Unlock steering by pulling the tilt

lever toward you.

2. Move steering wheel to the desired

position.

3. Release tilt lever to lock steering

wheel in position.

Alll modells

Two additional cup holders are avail-

able on the back of the central pas-

sengers seat backrest.

To access them, lower the seat

backrest.

WARNING

Never adjust the steering wheel

height whille ridiing. You may lose

control.

Cup Holders

TYPICAL

CAB models

1. Backrest clip locking mechanism

Two cup holders are located on the

central console.

TYPICAL

1. Central passenger backrest cup holder

NOTE:

Alll except CAB models

Do not use cup holders while riding in

rough conditions.

EQUIPMENT

Passengers Handhold

The passengers have access to a

front handhold located in front of their

seats.

Driiver Storage Compartment

A small storage compartment is avail-

able on the driver side.

Adjust the seat position in order to get

Pull on handle to rotate it open.

a solid and comfortable grip on the

handholds. Refer to Passenger’s Seat

for adjustment procedure.

Holding the handhold helps the pas-

sengers brace against the movement

of the vehicle and helps keep hands

and body inside the cockpit in the

event of a rollover.

WARNING

TYPICAL

Never use any part of vehiicle

1. Driver storage compartment

cage as handholds. Hands can be

struck by objjects outside the

Removablle Tooll Box

cockpiit or crushed in a rolllover.

A removable tool box is located on the

upper console in front of the passen-

Storage Compartments

ger’s seat..

The vehicle is equipped with storage

compartments designed to carry light

Opening the Tooll Box Liid

objects.

WARNING

Mulltiifunction Gauge Storage

Before riiding, allways make sure

Compartment

tooll box iis secured to vehicle and

liid is locked.

A storage compartment is available

above the multifunction gauge.

1. Push the lock downwards and lift

the lid.

EQUIPMENT

2. To close the lid, lower it and push

the lock upwards.

TYPICAL

1. Under seat storage box

Removing and Securiing the Tooll

Box

To remove under seat storage box, lift

WARNING

RH passenger seat and remove under

Before riding, always make sure

seat storage box by pulling it upwards.

tooll box iis secured to vehiclle and

lid is llocked.

1. To remove the tool box from the

vehicle, lift its transport handle.

2. To secure the tool box in place, po-

sition it carefully and lower the

transport handle.

TYPICAL

NOTE:

When reinstalling under seat storage

box, make sure to align it properly with

seat tubes and floor emboss so it fits

properly under the seat.

SECURING TOOL BOX IN PLACE

Open Storage Compartments

Under Seat Storage Box

Multiple open storage compartments

A convenient removable under seat

are available in the console.

storage box is available.

WARNING

When riding vehiiclle, make sure

no object stored iin open storage

compartments could cause harm

in the event of a rolll over.

EQUIPMENT

ALL EXCEPT BASE

1. Access panel

Central Passenger Backrest

WARNING

Storage Area

– Always close doors before

When central passenger seat back-

riiding.

rest is pulled down a storage area is

– Never riide when the doors are

available.

removed.

– Do not drive with cargo that ex-

NOTE:

ceeds the diimensiions of the

Always empty storage area before

compartment.

putting central passenger backrest up.

– Always properlly secure the

cargo.

– Always carry only evenlly diis-

tributed llightweiight cargo.

Tool Kit

A tool kit with basic tools is provided.

It is located in the front service center.

TYPICAL

1. Central passenger backrest storage area

Lower Storage Box

A storage area is located under the

cargo box on each side of the vehicle.

Use the lower storage to haul small,

lightweight cargo. Heavier cargo

should be hauled in cargo box.

1. Tool kit

Footrests

The vehicle is equipped with driver

and RH passenger footrests to allow

firmly planting feet on vehicle floor,

which helps to maintain proper body

position while riding.

EQUIPMENT

The footrests help minimize the risk of

leg or foot injury.

Always wear appropriate footwear.

See Riding Gear.

Side Nets

A side net is provided on each side of

the cockpit to help arms, legs or

shoulders stay inside the vehicle, thus

reducing the risk of injuries. Side nets

1. Side net adjustment locations

may also keep bushes or other debris

2. Shoulder guard

out of the cockpit.

Shoulder Guards

WARNING

The vehicle is equipped with shoulder

Never operate the vehiicle unless

guards to help restrain the entire body

both side nets are in place and

of driver and passengers inside

buckled.

vehicle.

Seat Belts

This vehicle is equipped with 3 points

seat belts to help protect driver and

passenger in the event of a collision,

rollover, or tipover. The seat belts can

help keep occupants stay in the pas-

senger compartment.

WARNING

1. Side net

Wear seat bellts properly at alll

tiimes.

Side nets are adjustable and must be

Seat belts reduce the riisk of injury

kept as tight as possible.

in case of a crash and hellp to

keep liimbs iinsiide the cockpiit dur-

To adjust side nets proceed

ing a rolllover or any accidents.

follows:

1. Secure side net with buckle.

If driver's seat belt is not fastened

2. Pull on all adjustment straps

when:

tighten.

- The ignition is turned ON

- The seat belt indicator lamp will

be turned ON.

- The multifunction gauge will

display the message: SEAT

BELT.

- The engine is started and shift lev-

er is moved out of PARK, vehicle

speed will be limited to a maximum

EQUIPMENT

of approximately 20 km/h (12

MPH) on flat ground.

WARNING

The vehicle may reach higher or

lower speed dependiing on

iincllines.

WARNING

There iis no iindiicator liight or mes-

sage for the passengers seat bellt.

TYPICAL

The driiver iis responsiblle for the

passenger safety and should en-

WARNING

sure the passengers bucklle their

Wear seat belt properlly. Make

seat bellt.

sure iit remaiins securelly fastened

and tiightened against the body.

Fasteniing and Adjusting the Seat

Make sure it is not twisted or

Bellt

defectiive.

The seat belt is equipped with a semi--

cinching tab that locks the lap belt

To release the seat belt, push on the

when the webbing is under tension.

red button on the seat belt buckle.

Driver''s Seat

On applicable models, the driver's

seat can be adjusted forward and

backward.

TYPICAL

1. Semi-cinching tab

1. Adjustment lever

To fasten the seat belt, insert the latch

plate into the buckle, then pull the belt

To adjust seat, move the seat lever to

to ensure it is properly fastened.

unlock the seat. Release the lever to

lock the seat into desired position.

Adjust the seat belt tightly against

your body by pulling the shoulder belt

WARNING

upwards.

Never adjjust the seat positiion

whiile driviing.

EQUIPMENT

Passenger Seats

Refer to Fuel section for information

on fueling procedure and fuel

The passenger seats are not

requirements.

adjustable.

The central passenger seat backrest

Winch

can be tilted forward for access to cup

WARNING

holders by releasing the latch located

on top of the backrest.

To avoid severe injjury or death or

important components damages.

– Never use the wiinch cablle/

rope to retaiin a vehicle during

traiileriing.

– Never ride with the winch ca-

ble/rope attached to a load or

another vehiclle.

– Onlly use the wiinch to hellp a

stuck vehicle (snow, mud,

etc.).

– Allways refer to the winch man-

TYPICAL

ufacturer''s instruction before

1. Backrest clip locking mechanism

pullliing loads.

On applicable models, the seats can

Refer to your winch guide included

be lifted to allow access to removable

with your vehicle for proper winch

under seat storage compartment.

operation.

To lift seat, pull on front of seat to un-

The winch can be actuated inside the

clip it and lift until it "clips" in the upper

vehicle using the winch control switch

position.

on the upper console.

Fuel Reservoir Cap

NOTICE

The fuel reservoir cap is located on

Using the winch intensively over a

the right hand side of the vehicle, be-

long period of tiime may diischarge

tween the wheel and the lower stor-

the battery.

age box.

Intensive use of the winch may cause

the built-in circuit breakers to momen-

tarily turn OFF. In such a case, wait a

moment, then continue winching. The

breakers automatically turn ON once

they have cooled down.

The following tips will help to reduce

the risk of discharging the battery:

- Always unreel manually: Unlock

the cable using the handle then

1. Fuel reservoir cap

pull on the hook strap to unreel.

- Let the vehicle run while winching.

Do not stop vehicle immediately

EQUIPMENT

after winching to let battery

recharge.

- Also, when winching for more than

30 seconds, it is recommended to

increase engine RPM in the range

of 3000 RPM to increase charging

power to the battery.

WARNING

Make sure vehicle iis iin NEUTRAL

(N) before iincreasiing engiine

LATCH HANDLE

RPM.

Cargo Box Side Walls

Cargo Box

The side walls can be removed.

The vehicle is equipped with a an in-

1. Open the latch handles and

re-

clinable cargo box. The cargo box

move the tailgate.

may be used for various types of

cargo.

WARNING

To reduce the risk of lloss of con-

trol or lloss of load, use the cargo

box onlly in accordance with Car-

ryiing Loads iin the safety Informa-

tiion sectiion.

The cargo box may be opened with

2. Remove screws.

the tailgate.

1. Screw

1. Latch handle

2. Washer

Lower the tailgate by opening the

3. Slide backward and lift up.

latch handle as illustrated below.

EQUIPMENT

Cargo Box Power-Tillt (If equipped)

The cargo box can be tilted with the

control switch located in the upper

control.

1. Sliding backward

2. Lifting up

Cargo Box Separations

Cargo box can be easily separated in-

to smaller storage compartments to

prevent cargo loads from mixing.

Tailgate

The cargo box can be closed with a

tailgate.

EXAMPLE

CARGO

BOX

SEPARATIONS

Cargo Box Tilt

1. Cargo box

2. Tailgate

Cargo Box Tillt Rellease Handles (If

equiipped)

NOTICE

The latching mechanism of the cargo

Do not exceed 113 kg (250 llb) of

box can be actuated from either side

weight on the taiilgate duriing lload-

of the vehicle through a release

ing or unlloading. Allways cllose

handle.

taillgate before operatiing to re-

duce the risk of lloss of load.

Removiing the Taillgate

1. Open tailgate.

2. Using a flat screwdriver, gently pry

the spring clip past the screw head

on each side.

1. Cargo box release handle

EQUIPMENT

3. Lift the tailgate 45°.

ALL MODELS

4. Lift the RH side off it’s hinge.

12 V power outlets

5. Remove the tailgate by sliding it to

the right.

Remove protective cap to use. Always

6. The installation is the reverse of

reinstall it after use to protect against

the removal procedure.

weather.

Side Mirrors (If equipped)

USB Power Outlet

This vehicle may be equipped with

Some models are equipped with a

side mirrors.

USB port used for charging.

The mirrors can be adjusted to suit

driver preferences.

WARNING

Do not adjust mirrors whiile riiding.

You could llose control.

Trailer Hitch

The vehicle comes equipped with a

50.8 x 50.8 mm (2 x 2 in) standard re-

1. USB charging port

ceiver hitch.

For the proper usage of the hitch sup-

Brake Holding Mechanism

port, refer to Moving Loads and Doing

The brake holding mechanism lever is

Work.

located on the LH side of the steering

wheel, above the brake pedal.

WARNING

To reduce the risk of lloss of con-

trol or lloss of load, allways respect

the maxiimum hauliing capacity.

12-Volt Power Outlets

Convenient for handheld spotlight or

other portable equipment.

EQUIPMENT

WARNING

When the brake holding mecha-

niism is appllied, make sure the ve-

hiiclle stays securelly iin place.

ALWAYS put the shift llever iin

PARK when using the brake hold-

ing mechanism.

To release the brake holding mecha-

TYPICAL

nism, simply apply and hold the brake

1. Brake pedal

pedal, put shift lever in gear then re-

2. Brake holding mechanism lever

lease brake pedal. When released it

should return to the rest position.

The brake holding mechanism func-

Safe usage of the brake holding

tion is to maintain brakes to all wheels

mechanism requires the shift lever to

while shift lever is set to Park.

be set to the Park position. It is not

To engage the brake holding mecha-

recommended to use the brake hold-

nism, proceed as follow:

ing mechanism on its own.

1. Immobilize vehicle,

WARNING

2. Apply and hold the brakes,

Make sure brake holldiing mecha-

3. Put shift lever in Park,

niism is released before operating

4. While holding the brakes, lift lever

the vehiiclle. If the brake holdiing

toward the steering wheel,

mechaniism is lleft ON whille riding,

5. Remove foot from brake pedal, the

it may cause damage to the brake

pedal should stay lowered.

system and lead to lloss of braking

capaciity and/or fire.

Side Mirrors

This vehicle may be equipped with

side mirrors.

The mirrors can be adjusted to suit

driver preferences.

WARNING

Step 1. Apply and hold brake pedal

Step 2. Lift lever

Do not adjust mirrors whiile riidiing.

You could llose control.

NOTE:

Full Doors With Electric

The brake holding mechanism lever

Windows

can be set to several positions.

Some vehicles come equipped with

full doors and electric windows.

EQUIPMENT

Doors can be removed from the ve-

NOTE:

hicle. See an authorized Can-Am Off--

When riding the vehicle with the wind-

road dealer for information.

shield in one of the open position, ad-

just your speed to the terrain. The

WARNING

glass windshield is not as strong when

not seated in its closed position.

Always iinstalll safety nets and

shoulder bars whenever removing

To close windshield, pull on handle

full doors from vehiiclle. See an au-

until it closes.

thorized Can-Am Off-road dealer

for iinstalllatiion iinstructiions.

Fillliing up Windshiield Washer

Open cargo box.

Windshield with Wiper

Some vehicles are equipped with a full

Lift service cover and remove wind-

glass windshield and a wiper.

shield washer bottle cap.

To activate wiper, press activation

switch. The switch is located on the

central panel at the top of the

windshield.

Fill windshield washer bottle.

Climate Control System

1. Wiper activation switch

To activate windshield washer, hold

activation switch up.

Full glass windshield with wiper can

be removed from vehicle. See an au-

thorized Can-Am Off-road dealer for

information.

Windshiield Positiion

MODELS WITH A/C

Windshield can be set to 3 different

1. Windshield air vents

positions.

2. Central air vents

3. Footwell air vents

- Closed

4. Climate control

- Partially opened (second position

on the handle)

Wiindshielld Air Vents

– Fully opened (handle is released)

Located on the top of the dash, they

allow distribute the air flow on the

windshield.

EQUIPMENT

Rotate the external ring of the vent to

orient the air flow in the cockpit.

The air flow may be adjusted using

the central knob.

- Push the knob toward the wind-

1. Molded dot

shield to close the vent.

2. External ring

- Pull it to open the vent.

Footwelll Aiir Vents

Located underneath the dash, each

side of the vehicle, they allow distrib-

ute the air flow at the bottom of the

cockpit.

Push on the molded dot to open the

vent.

Push on vent tabs to close.

CLOSED POSITION SHOWN

Cliimate Controll - Wiith A/C

1. Central knob

This vehicle is equipped with an heat-

ing/air conditioning system.

Consolle Aiir Vents

This system is controlled by a multi-

Located on the center of the console,

function module. This module gives

they allow distribute the air flow inside

access to the following functions:

the cockpit.

- Temperature

- Temperature mode

- Fan speed

- Settings

Push on the molded dot to open the

vent.

1. Power switch

Push on vent tabs to close.

2. Selector knob

3. Display

EQUIPMENT

For an optimal efficiency of the sys-

tem, the supply control of the outside

air is determined automatically by the

climate control module. No operator

2. Turn the selector knob to change

action is required.

the mode.

Temperature

NOTE:

To adjust the temperature, turn the se-

After

5 seconds, the module saves

lector knob to select the desired

your selection and returns automati-

temperature.

cally to the temperature display.

The temperature can be set between

In AUTO mode, the system automati-

13 °C and 28 °C (56 °F and 82 °F) in 1

cally adjusts to heat or cool the cockpit

degree increments.

to obtain the selected temperature as

In position T

° MIN, the system

quickly as possible by adjusting the

switches to continuous cooling.

fan speed automatically.

If an other fan speed is selected while

in AUTO mode, the system will fall in

cool or heat mode depending the am-

bient conditions.

Fan Speed

To adjust the fan speed, press the se-

lector knob until the fan icon

ap-

pears then turn the knob to select the

desired speed.

In T ° MAX, the system

switches

3 settings are available for fan speed:

continuous heating.

- LOW

- MED

- HIGH

NOTE:

After

5 seconds, the module saves

your selection and returns automati-

cally to the temperature display.

Settiing

The following settings can be modified

by the operator.

NOTE:

In either T ° MIN or T ° MAX position,

- Contrast (0% to 100%)

the system can not regulate a stable

- Brightness (0% to 100%)

temperature.

- Unit (°C or °F)

To modify a setting, press the selector

Temperature Mode

knob 2 time to reach the Fan Speed

1. To select the temperature mode,

page.

press the selector knob until one of

the following icon appear.

100

4.5” DIGITAL DISPLAY

Multifunction Display

Icon

Descriiptiion

Lower Display

2x4 icon

4X4 icon

May display the following:

Front differential

- RPM

lock

- Speed statistics

- Engine Temperature

- Battery Voltage

Central Display

- Settings

- Messages

Use LOWER button to change the dis-

played information.

Left Lateral Display

Display the vehicle speed in km/h or

MPH or RPM.

Transmission

Position

Display

The left lateral display includes:

- Fuel level indicator

- Seat belt icon

- Smart-Shox suspension icon

Right Lateral Display

This display shows gear position of

gearbox:

- P (Park)

- R (Reverse)

- N (Neutral)

- H (High Range)

- L (Low Range)

The right lateral display includes:

- Gear 1 to 7

- (Invalid Range)

- Engine Temperature

–

2WD/4WD/Diff lock

Engine Mode Display

102

4.5” DIGITAL DISPLAY

Warning Lamps and

Indicators

The following indicator lamps will alert

you to a vehicle condition that may be-

come serious. Some lamps will illumi-

nate when starting the vehicle to

make sure they work. If any lamps re-

main on after starting the vehicle, refer

The MODE display indicates the se-

to the respective system warning lamp

lected mode of operation:

for further information.

- AUTO mode

- NORMAL

NOTE:

- SPORT

Some warning indicators appear in

- SPORT+

the display of the multifunction gauge

and function the same as an indicator

Message at

Driive Mode

lamp but do not display when starting

Actiivatiion

the vehicle.

Normal

NORMAL MODE

Tellltale Lights - Lower Bar

Sport

SPORT MODE

Sport+

SPORT+ MODE

Warniing and Tellltalle Liights

Trip Display

ORANGE - Vehicle

Malfunction

BLUE - High Beam

RED - The engine

temperature is too high.

This display shows trip information:

GREEN - Neutral

- Cumulative distance odometer

- Trip A

- Trip B

RED - (Blinking)

- Vehicle hour meter

Accelerator pedal and the

- Clock

brake are activated

simultaneously for a certain

time

(a torque limitation is

Use UPPER button to change the dis-

active)

played information.

Hold UPPER button to reset Trip A/B

RED - Low battery.

meters.

103

4.5” DIGITAL DISPLAY

Maintenance Reset

Warniing and Tellltalle Liights

NOTE:

RED - Low oil pressure

Only when the maintenance icon is

(Normally ON at engine

displayed.

OFF)

Using LOWER button, select RES

MAINT and hold to reset

ORANGE - Low fuel level

maintenance.

Faullt Codes

ORANGE - Check engine

Available only when at least one code

is activated.

Icons and Indicators - Multiifunctiion

Using LOWER button, select CODES

Display

and hold to see actives fault codes.

Icons and Indicators

Fault codes will be scrolled on the

Denotes SPORT

Lower Display.

mode is selected.

Reset Stats

When lit, seat belt

Using LOWER button, select RESET

not buckled with

STAT and hold to reset.

vehicle

immobilized.

Unit Sellectiion

Flashing when

vehicle is moving.

This multifunction gauge is factory

preset in Imperial units but it is possi-

ble to change it to Metric units.

Settings

Using LOWER button, select UNITS

The buttons to navigate through me-

and hold button to change units.

nus are located on the left side of the

LCD display.

Settiing Clock

All of the following action must be per-

formed using the LOWER button.

1. Select CLOCK and hold to adjust

clock.

2. Press the button to select clock

display.

3. Push and hold the button for

second.

1. Upper button

4. Press the button to select 12:00

2. Lower button

AM PM or 24:00 time base.

5. Push and hold the button to ac-

Setup

knowledge selection.

Using LOWER button, select SET-

6. Press the button to change hours

TINGS and hold to enter setting

(hours flash).

menu.

7. Push and hold the button to ac-

knowledge hour selection.

8. Press the button to switch to mi-

nutes (minutes flash).

104

7.6" DIGITAL DISPLAY

Multifunction Display

WARNING

Do not adjust the display whiile

riding, you coulld lose controll.

Lower Display

The right lateral display includes:

- Engine Temperature

- Clock

- Speed indicator

The speed indicator in this display is

activated when the central display

shows information other than the

speed. Otherwise it is blank.

May display the following:

- RPM

Central Display

- Speed statistics

- Engine Temperature

- Battery Voltage

- Settings

- Messages

- Active DPS mode

The SPEED STAT display shows the

maximum and the average speed.

Hold MENU or OK button for 1 second

May display the following:

to reset.

- RPM

Left Lateral Display

- Vehicle speed

Transmission

Position

Display

The left lateral display includes:

- Fuel level indicator

- Tripmeter (A - B)

This display shows gears position of

- Odometer

gearbox:

- Vehicle Hour meter

- DPS indicator

- AUTO (Automatic)

- P (Park)

Right Lateral Display

- R (Reverse)

- N (Neutral)

- H (High range)

- L(Lowrange)

106

7.6" DIGITAL DISPLAY

- (Invalid gear)

Icon

Description

Engine Mode Display

2x4 icon

4X4 icon

The engine mode display indicates

the selected mode of operation:

- NORMAL

Front differential

- SPORT

lock

- SPORT+

A message of the selected mode will

Middle Left Display

be displayed on the lower display at

activation and deactivation as follow:

Message at

Driive Mode

Actiivatiion

Normal

NORMAL MODE

Sport

SPORT MODE

Sport+

SPORT+ MODE

The middle left lateral

display

includes:

Middle Right Display

- Seat belt reminder

- Maintenance reminder

Indicator Lamps

Warniing and Tellltale Lights

The middle right display indicates the

WARNING and Tellltale Lights

selected mode of operation:

2X4

ORANGE - Vehicle

–

4X4

Malfunction

–

Front differential lock (Smart-Lok)

BLUE - High Beam

RED - The engine

temperature is too high.

107

7.6" DIGITAL DISPLAY

Settings

WARNING and Tellltale Lights

Setup

GREEN - Neutral

Using the MENU button on the key-

pad, select SETTINGS and hold to

enter setting menu.

RED - Brake lock lever is

engaged or malfunction of

OK button can be pressed instead of

the brake system

holding MENU button.

RED - The battery voltage

Maintenance Reset

too low or problem with the

electrical system

NOTE:

Only when the maintenance icon is

RED - Low oil pressure

displayed.

Normally ON when engine

is OFF

Using MENU button, select RES

MAINT and hold to reset

maintenance.

ORANGE - Low fuel level

Faullt Codes

ORANGE

Available only when at least one code

Turn on: Malfunction of the

is activated.

vehicle emissions control

system

Using MENU button, select CODES

Bllink: Engine problems,

and hold to see active fault codes.

the limp home mode is

Fault codes will be scrolled on the

activated. Have the vehicle

Lower Display.

serviced immediately.

Reset Stats

Icons and Indicators

Using MENU button, select RESET

STAT and hold to reset.

Icons and Indicators

Denotes SPORT

Unit Sellectiion

mode is selected.

This multifunction gauge is factory

preset in Imperial units but it is possi-

When lit, seat belt

ble to change it to Metric units.

not buckled with

vehicle

Using MENU button, select UNITS

immobilized.

and hold button to change units.

Flashing when

vehicle is moving.

Speed/RPM

When lit, indicates

The speed and RPM display can be

that a maintenance

swapped.

is required. See

Using MENU button, select SPEED/

your authorized

RPM and hold button to invert speed

Can-Am dealer or

and RPM display.

person of your own

choosing for the

maintenance.

108

7.6" DIGITAL DISPLAY

Settiing Cllock

All of the following action must be per-

formed using the MENU button.

1. Select CLOCK and hold to change

time.

2. Press the button to select clock

display.

3. Push and hold the button for

second.

4. Press the button to select 12:00

AM PM or 24:00 time base.

5. Push and hold the button or OK

button to acknowledge selection.

6. Press the button to change hours

(hours flash).

7. Push and hold the button or OK

button to acknowledge hour

selection

8. Push the button to switch to mi-

nutes (minutes flash).

9. Push and hold the button to ac-

knowledge minutes selection.

Settiing Brightness

The brightness of the LCD display can

be adjusted.

Using MENU button, select BRIGHT-

NESS and hold MENU button to se-

lect the brightness setting.

Using MENU button, adjust brightness

then push and hold MENU button to

acknowledge selection.

Settiing Language

The gauge display language can be

changed.

Refer to an authorized Can-Am Off--

road dealer for language availability

and to setup the gauge to your

preference.

DPS Modes

The lower display can show which

DPS mode is active. Refer to Tune

Your ride.

109

FUEL

Fuel Requirements

NOTICE

Always use fresh gasoliine. Gaso-

line willl oxidiize; the result is loss

NOTICE

of octane, volatille compounds,

and the production of gum and

Never experiment with other

varnish deposits whiich can dam-

fuells. Engiine or fuell system dam-

age the fuel system.

ages may occur wiith the use of an

inadequate fuel.

Alcohol fuel blending varies by coun-

try and region. Your vehicle has been

NOTICE

designed to operate using the recom-

Do NOT use fuel from fuell pumps

mended fuels, however, be aware of

labeled E85.

the following:

Use of fuel containing alcohol

Use of fuel labeled E15 is prohibited

above the percentage specified by

by U.S. EPA Regulations.

government regulations is not rec-

ommended and can result in the

Vehicle Fueling Procedure

following problems in the fuel sys-

tem components:

WARNING

- Starting and operating

– Fuell is flammable and explo-

difficulties.

sive under certaiin conditions.

- Deterioration of rubber or plas-

tic parts.

– Never use an open fllame to

- Corrosion of metal parts.

check fuell level.

- Damage to internal engine

– Never smoke or alllow fllame or

parts.

spark iin viicinity.

– Always work iin a welll-venti-

Inspect frequently for the presence

llated area.

of fuel leaks or other fuel system

– Vehiiclle must be on a llevell sur-

abnormalities if you suspect the

face to perform fueliing.

presence of alcohol in gasoline ex-

ceeds the current government

regulations.

1. Place vehicle on a level surface.

Alcohol blended fuels attract and

2. Move the shift lever into PARK

hold moisture which may lead to

position.

fuel phase separation and can re-

3. Stop engine.

sult in engine performance prob-

lems or engine damage.

WARNING

Allways stop engine before

Recommended Fuell

refueliing.

The gasoline must have the following

minimum octane requirements:

4. Have occupants get out of vehicle.

Regular unleaded gasoline with an

AKI (R+M)/2 octane rating of 87, or

an RON octane rating of 91

Use unleaded gasoline containing

MAXIMUM 10% ethanol.

110

FUEL

WARNING

Do not alllow anyone to remaiin in

the vehicle whille fueliing. If there

is a fire or expllosiion duriing fuel-

ing, a vehiiclle occupant could be

unablle to quickly leave the area.

5. Slowly unscrew the fuel reservoir

cap counterclockwise to remove it.

WARNING

If a diifferentiial pressure conditiion

is noticed (whistliing sound heard

when lloosening fuel reservoiir

cap) have vehicle iinspected and/

or repaiired before further

operation.

6. Insert the spout into the filler neck.

7. Pour fuel slowly so that air can es-

cape from the tank and prevent

fuel flow back. Be careful not to

spill fuel.

8. Stop filling when the fuel reaches

the bottom of filler neck. Do not

overfiilll.

WARNING

Never top up the fuel tank before

placing the vehicle iin a warm

area. As temperature increases,

fuell expands and may overflow.

9. Fully tighten fuel reservoir cap

clockwise until you hear a clicking

noise.

NOTICE

Allways wiipe off any fuell spiilllage

from the vehiicle.

111

BREAK-IN PERIOD

Operation During Break-In

A break-in period of

operating

hours or 300 km (200 mi) is required

for the vehicle.

Engiine

During the break-in period:

- Avoid full throttle operation.

- Avoid pressing accelerator pedal

more than 3/4 of the stroke.

- Avoid sustained accelerations.

- Avoid prolonged cruising speeds.

- Avoid engine overheating.

However, brief accelerations and

speed variations contribute to a good

break-in.

Brakes

WARNING

New brakes wiilll not operate at

their maximum efficiiency untill

their break-iin is completed. Brak-

ing performance may be reduced,

so use extra cautiion.

Applly moderate braking force for

the 40 to 50 first braking events.

Bellt

A new belt requires a break in period

of 50 km (30 mi).

During the break-in period:

- Avoid strong acceleration and

deceleration.

- Avoid pulling a load.

- Avoid high speed cruising.

112

BASIC PROCEDURES

Starting the Engine

Pay attention to the following:

Press the brake pedal.

Low range

Insert key in ignition switch and turn to

Low range should be used whenever:

the ON position.

Pulling

–

Pushing

NOTE:

–

Hauling a load

If shift lever is not set to PARK (P) or

–

4x4 applications

(N) NEUTRAL, the brake pedal must

–

Mud holes

be pressed to allow engine starting.

–

Water holes

–

Crossing obstacles

Turn the key to the start position and

–

Climbing onto trailer

hold until the engine starts.

–

Hill climbing

NOTE:

It is also recommended to use low

Do not press the accelerator pedal. If

range if driving for prolonged periods

the accelerator pedal is pressed at

at speeds under 24 km/h

least 50%, the engine will not start.

(15 MPH).

Release the engine start position im-

Please refer to Break-in Period for

mediately when the engine has

drive belt break-in information.

started.

High range

NOTICE

High is the default riding range.

If engine does not start after a few

seconds, do not hold the start po-

Ellectronic Drive Belt Protectiion (iif

sition more than 10 seconds. Re-

avaiilable and activated on your

fer to Troubleshooting.

model)

Some vehicles have the electronic

drive

belt

protection

function

Operating the Shift Lever

activated.

Apply brakes and select the desired

shift lever position.

Refer to your authorized Can-Am Off--

road dealer for availability and possi-

Release brakes.

ble activation.

NOTICE

This function is activated when riding

at too slow speed for the hiigh range,

When changiing gear sellection, al-

such as in the following situations:

ways complletelly stop the vehiiclle

and apply the brakes priior to shift-

Pulling

ing. Damage to the gearbox may

–

Pushing

occur.

–

Hauling a load

4x4 applications

–

Mud holes

Choosing the Correct Range

–

Water holes

(Low or High)

–

Crossing obstacles

It is important to limit situations known

–

Climbing onto trailer

to make the drive belt slip excessively.

–

Hill climbing

The main reason the drive belt will slip

In the above mentioned situations the

is if the gearbox is in high range when

electronic drive belt protection will

it should be in low range.

help protect the CVT drive belt from

113

BASIC PROCEDURES

being damaged by activating the en-

Tips for Maximizing Drive

gine torque limiter. The gauge will also

Belt Durability

scroll a LOW GEAR message, sug-

gesting the operator to immobilize the

Riding style and conditions have a di-

vehicle and set to LOW GEAR.

rect impact on drive belt durability.

Your vehicle features a CVT system

Whenever the ellectroniic drive bellt

design that is optimized to offer the

protection is actiivated, you MUST

best performance. The CVT and drive

shift in LOW range. Refer to Operat-

belt have successfully endured thou-

ing the Shift Lever.

sands of miles of durability tests. How-

ever, to maximize drive belt durability

Stopping the Engine and

and to prevent premature failures, it is

important that the operator under-

Parking the Vehicle

stands the limits of a belt driven CVT

system and adapts their riding style

WARNING

and speed accordingly.

Avoiid parking on steep sllope as

the vehiiclle may rolll away.

If riding in any of the conditions listed

below, BRP highly recommends not to

constantly hold the throttle wide open

WARNING

(WOT) for more than five (5) minutes.

Always put the vehiiclle in PARK

- High ambient temperatures (above

when stopped or parked to pre-

30 °C (86 °F)

vent rollliing.

- Heavy loads: Passengers / Heavy

cargo

- Heavy drag: Soft sand / Hill climb-

WARNING

ing / Mud / Using a track kit.

Avoiid parking iin pllaces where hot

After a few minutes at WOT, partially

parts can start a fiire.

release the accelerator and allow the

CVT to cool down.

When stopped or parked always bring

For more tips for maximizing the drive

shift lever to park position. This is es-

belt durability, refer to Choosing the

pecially important when parking on a

Correct Range (Low or High).

slope. On very steep inclines or if the

vehicle is carrying a cargo, the wheels

should be blocked using rocks or

bricks.

Select the flattest terrain available for

parking.

Release accelerator pedal and use

brakes to completely stop the vehicle.

Set shift lever in PARK position.

Turn key in ignition switch to OFF

position.

Remove key from ignition switch.

114

SPECIAL PROCEDURES

NOTE:

NOTICE

Component failures resulting from

these events are not covered by

Stop the engine and draiin the

warranty.

water to avoiid damage to the

CVT.

Fuel Flooded Engine

If the engine does not start and it is

fuel-flooded, the drowned mode can

be activated to prevent fuel injection

and to cut ignition while cranking. Pro-

ceed as follows:

1. Move shift lever in park position.

2. Turn the ignition key in ON

position.

3. Press completely and HOLD ac-

TYPICAL

- LEFT SIDE OF VEHICLE

celerator pedal.

UNDER CARGO BOX

4. Turn the ignition key to the START

1. CVT drain

position and hold in this position

for 10 seconds.

See an authorized Can-Am dealer , a

5. Release the ignition key.

repair shop or person of your choos-

6. Release

accelerator

pedal

ing to have the CVT inspected and

completely.

cleaned.

7. Turn the ignition key to START po-

sition again to allow starting.

What to do if Battery is

If it does not work:

Drained Out

1. Remove the spark plugs. Refer to

The vehicle can be jump started by

Spark Plugs in Maintenance Pro-

using the RED (+) cable to the battery

cedures section.

positive pole and the BLACK (-) cable

2. Crank engine several times.

to the vehicle chassis.

3. Install new spark plugs if possible

or clean and dry spark plugs.

NOTICE

Do not connect any electriicall

If engine does not start, see an au-

source to the steeriing column or

thorized Can-Am Off-road dealer, a

components which are in contact

repair shop, or a person of your own

wiith DPS.

choosing for maintenance, repair, or

replacement.

What to Do if Vehicle Rolled

Please refer to the US EPA Emis-

Over

sion-Related Warranty contained

herein for information about warranty

Abrupt maneuvers, sharp turns, side

claims.

hilling or accident may cause vehicle

to rollover.

What to do if Water is

Should the vehicle be rolled over, it

Suspected to be in the CVT

will be necessary to have it trans-

If water is present in the CVT, the en-

ported to an authorized Can-Am Off--

gine will accelerate but the vehicle will

road dealer for inspection as soon as

remain still.

possible. NEVER START THE

ENGINE!

115

TUNE YOUR RIDE

Suspension Adjustment

Spriing Preload

Guidelines

Cam position 1 (soft)

Your vehicle handling and comfort de-

pend upon suspension adjustments.

Suspension Adjustments

WARNING

Suspension adjustment coulld af-

Spriing Preload Adjustment

fect vehiiclle handling. Always take

Following are guidelines to fine-tune

time to familiarize yourself with

suspension. Use suspension adjust-

the vehicle''s behavior after any

ment tool provided in the tool kit.

suspensiion adjjustment has been

made.

Choice of suspension adjustments

vary with vehicle load, personal pref-

erence, riding speed and terrain

condition.

The best way to set up the suspen-

sion, is to start from factory settings,

then customize each adjustment one

at a time.

Front and rear adjustments are inter-

The spring preload affects the ground

related. It may be necessary to read-

clearance of the vehicle.

just the rear shock absorbers after

adjusting front shock absorbers for

Shorten the spring for a firmer ride

instance.

and rough riding condition or when

pulling a trailer.

Test run the vehicle under the same

conditions; trail, speed, load, etc.

Lengthen the spring for a softer ride

Change one adjustment and retest.

and smooth riding condition.

Proceed methodically until you are

satisfied.

NOTE:

Factory settings are suitable for al-

Suspension Factory Settings

most all conditions. Take into consid-

eration that an increase in ground

Factory settings are suitable for al-

clearance can affect the handling of

most all conditions.

the vehicle.

Take into consideration that an in-

crease in ground clearance can affect

WARNING

the handling of the vehicle.

The lleft and right shock adjust-

ment on front or rear suspension

Front Suspension

must always be set to the same

position.

Spring Prelload

Never adjust one shock only.

Uneven adjustment can cause

Cam position 1 (soft)

poor handlling and lloss of stability,

which coulld lead to an accident.

Rear Suspension

117

TRANSPORTING THE VEHICLE

When contacting a towing or transporting service, be sure to ask if they have a

flatbed trailer, loading ramp or power ramp to safely lift the vehicle and tie-down

straps. Ensure the vehicle is properly transported as specified in this section.

NOTICE

Do not tow this vehiiclle — towing can seriouslly damage the vehicle''s drive

system.

NOTICE

Avoid using chaiins to tiie the vehiicle — they may damage the surface fiin-

ish or plastiic components.

WARNING

To avoiid severe injury or death or important components damages.

– Never use the winch cable/rope to retaiin a vehicle during trailleriing.

– Never riide wiith the wiinch cablle/rope attached to a load or another

vehicle.

– Onlly use the winch to help a stuck vehicle (snow, mud, etc.).

– Always refer to the wiinch manufacturer''s instruction before pullliing

loads.

WARNING

Make sure alll accessories, cargo and lloose objjects inside the vehicle are

properlly secured, or remove iit to prevent from failling on the road and cre-

ating a hazard for folllowiing vehicles.

WARNING

Allways transport the vehicle faciing forward to avoiid damagiing the wiind-

shield or other components. Parts may detach during transport.

WARNING

Before attemptiing to mount vehicle onto a platform or a trailer, make sure

to respect the folllowiing safety precautions.

Safety Precautiions

The carrying item (platform or trailer or flat bed)

must be of appropriate dimensions and

Carrying equipment

capacity to safely support and transport the

vehicle.

Do not exceed vehicle hauling capacity and

Hauling vehicle

specifications. Ensure the trailer or platform is

properly secured to the hauling vehicle hitch.

119

TRANSPORTING THE VEHICLE

Safety Precautions

Ensure you have a good visibility during the

Visibility

entire maneuver.

The hauling vehicle and trailer must be on a

Terrain

leveled surface. Use wheel chocks on trailer

and hauling vehicle to avoid any movement.

Use ramps with proper rating and secure ramps

Ramps

to the trailer or platform. Avoid steep ramps.

Always make sure bystanders are not close to

Bystanders

the vehicle or the trailering equipment while

climbing up.

Make sure all accessories, cargo and loose

objects inside the vehicle are properly secured,

Accessories and cargo

or remove it to prevent from failing on the road

and creating a hazard for following vehicles.

Using Vehicle Power to Climb Onto Trailering Equipment

When vehicle can cllimb on its own power, proceed as folllows;

1. Wear protective gear.

2. Fasten seat belt.

3. Use low gear only (if equipped).

4. If vehicle has 4WD option, use it.

5. When driving remain seated at all times.

6. Ensure proper alignment on rails or platform.

7. Start from a sufficient distance from the trailer to align the vehicle in a straight

line with the ramps. Never attempt to turn while getting closer to the ramp.

Rear wheels might not be aligned once you get to the ramp and vehicle may

fall off.

8. Slowly climb the front wheels onto the ramp to verify alignment.

9. Back off the vehicle, verify ramps are still secure, then proceed at proper

speed.

10. Carefully drive vehicle onto platform or trailer. Use sufficient speed to climb

without spinning or abruptly accelerating. Avoid acceleration while on ramps

to prevent ramps movement.

11. If trailer is inclined towards front, simply let vehicle roll in without acceleration.

12. Once vehicle is climbed, put shift lever to Park. Apply brake locking mecha-

nism (if equipped).

When vehiicle cannot move on its own power, or iin case overshootiing is

a riisk or iif any dangerous conditiion prevents for embarkiing on its own

power, proceed using a wiinch;

Using a Winch to Pull Vehicle Onto Trailering Equipment

When vehicle cannot cllimb on iits own power, proceed as folllows;

120

TRANSPORTING THE VEHICLE

WARNING

Have the help of an assistant. One person shoulld be iin vehiclle to have

access to vehiiclle steering, brakes and winch switch, whille the other per-

son controlls the enviironment and safety of the maneuver.

WARNING

Ensure the winch hook can be safely attached to a proper anchoring

point. Use proper rigging.

NOTE:

If vehicle can be started safely, let engine idle during winching to avoid draining

the battery.

1. Place shift lever to NEUTRAL (N).

2. If the vehicle is equipped with a winch, use the winch to roll the vehicle on the

platform.

3. If the vehicle is not equipped with a winch, proceed as follows:

1. Attach strap to lower front bumper anchor.

2. Attach the strap to the winch cable of the towing vehicle.

3. Pull the vehicle on the flatbed trailer with the winch.

4. Put shift lever to Park. Apply brake locking mechanism (if equipped).

Securing Vehicle for Transport

WARNING

To avoiid severe injury or death or important components damages.

– Never use the winch cable/rope to retaiin a vehicle during trailleriing.

– Never riide wiith the wiinch cablle/rope attached to a load or another

vehicle.

– Onlly use the winch to help a stuck vehicle (snow, mud, etc.).

– Always refer to the wiinch manufacturer''s instruction before pullliing

loads.

1. Remove the key from the vehicle.

2. At rear, secure the vehicle on both sides using a strap around the suspension

arm as close to the wheel as possible.

3. At front, secure the vehicle on both sides using a strap around the upper sus-

pension arm as close to the wheel as possible and away from the brake line.

121

TRANSPORTING THE VEHICLE

1. Front upper suspension arm

WARNING

Ensure the brake hose is away from the strap.

A pinched brake hose may reduce the braking performance of the vehicle.

4. Strap the rear tires by using tire towing straps.

5. Firmly attach the rear suspension tie-down straps to both sides of the rear of

the trailer with ratchets.

6. Ensure that both the front and rear wheels are firmly attached to the trailer.

Getting Vehicle Out of Trailer

WARNING

Vehiicle may have moved during transport. Ensure vehicle iis properly

alligned wiith ramps before proceediing.

WARNING

Visibiiliity willl be greatlly reduced when backiing off from the traiiler. Have

the hellp of an assiistant to ensure proper allignment and safe

environment.

122

LIFTING AND SUPPORTING THE VEHICLE

Front of Vehicle

1. Place vehicle on a flat non slippery

ground.

2. Ensure vehicle shift lever is set to

PARK.

3. Install an hydraulic jack under the

front skid plate.

4. Lift front of vehicle and install a

jack stand on each side under

frame section.

1. Lifting location under skid plate

2. Frame section to install jack stands

6. Lower hydraulic lift and ensure ve-

hicle is supported safely onto both

jack stands.

1. Front of vehicle

2. Frame section

5. Lower hydraulic lift and ensure ve-

hicle is supported safely onto both

jack stands.

Rear of Vehicle

1. Place vehicle on a flat non slippery

ground.

2. Activate 4WD mode.

3. Ensure vehicle shift lever is set to

PARK.

4. Install an hydraulic jack under the

skid plate.

5. Lift rear of vehicle and install a jack

stand on each side under frame

section in front of rear wheel.

123

MAINTENANCE SCHEDULE

Maintenance is very important to keep your vehicle in safe operating condition.

The vehicle should be serviced as per the maintenance schedule.

Proper maintenance is the owner’s responsibility. A warranty claim may be de-

nied if, among other things, the owner or operator caused the problem through

improper maintenance or use.

Perform periodic checks and follow the maintenance schedule. The maiinte-

nance schedule does not exempt the pre-ride inspection.

WARNING

Faiilure to properly maiintain the vehiclle accordiing to the maiintenance

schedulle and procedures can make it unsafe to operate.

EPA Regulation - Canadian and USA Vehicles

A repair shop or person of the owner''s choosing may maiintaiin, replace, or

repair emission control devices and systems. These instructions do not require

components or service by BRP or authorized Can-Am Off-road dealers.

Although an authorized Can-Am Off-road dealer has an in-depth technical knowl-

edge and tools to service your vehicle, the emission-related warranty is not con-

ditioned on the use of an authorized Can-Am Offroad dealer or any other

establishment with which BRP has a commercial relationship.

Proper maintenance is the owner’s responsibility. A warranty claim may be de-

nied if, among other things, the owner or operator caused the problem through

improper maintenance or use.

For emission-related warranty claims, BRP is limiting the diagnosis and repair of

emission-related parts to the authorized Can-Am Offroad dealers. For more infor-

mation, please refer to the US EPA Emission-Related Warranty contained in the

Warranty section.

You must follow the instructions for fuel requirements in the fueling section of this

manual. Even if gasoline containing greater than ten volume percent ethanol is

readily available, the US EPA issued a prohibition against the use of gasoline

containing greater than 10 vol% ethanol that applies to this vehicle. The use of

gasoline containing greater than 10 vol% ethanol with this engine may harm the

emission control system.

Air Filter Maintenance Guideline

Air filter maintenance should be adjusted according to riding conditions.

Air filter maintenance must be increased in frequency when riding on snow, dry

sand, dirt, gravel or similar conditions which have a high dust or particle

dispersion.

Riding in a group in these conditions will require increasing the air filter mainte-

nance frequency further.

NOTE:

Accessory filters and pre-filter are available for such conditions. Contact an au-

thorized Can-Am off-road dealer for details.

126

MAINTENANCE SCHEDULE

Severe Duty Use

If your vehicle is used in the following conditions, refer to the Severe Duty section

of the maintenance schedule.

- Repeated hauling of loads at more than 75% the maximum capacity.

- The increase workload applied to the drive system accelerates the differ-

entials, gearbox/transmission, and engine oil life. This reduces internal

component longevity if not replaced more frequently.

- Driving at excessive speeds for prolonged amount of time.

Higher than the average utility or commercial use requires more frequent fluid

and wear component replacement than trail, recreational, or occasional utility

purposes.

Extreme Cold Condiitiion

An engine that is frequently operated at or below an ambient temperature of -25 °

C (-13 °F) will require an increase in service and maintenance schedule.

Any combustion engine operated at these low ambient temperature will collect

an increased amount of condensation at every startup/warm-up.

Since the engine is not reaching operating temperatures for extended periods of

time, the oil is starting to be strongly diluted with water and gas residue (more

water content).

An engine needs to reach operating temperature, in order to be able to evaporate

condensate out of the oil.

If daily usage (work or leisure driving cycle) is similar to those mentioned below,

BRP strongly recommends changing the oil at least once a month.

Parameters of an increase in service and maintenance schedule:

- Engine not reaching the proper operating temperature during normal daily

usage

- Multiple starts and stops without reaching operating temperature

- Short idle periods

- Low RPM driving cycle in short distances without reaching operating

temperature.

NOTE:

BRP strongly recommends the installation of a block heater to help warm up the

liquids, this will also help to extend the oil lifetime.

Deep Mud / Water Use

Whether your vehicle is a X mr model or was accessorized for deep mud / water

use, this type of usage requires more frequent maintenance and inspections to

ensure debris has not infiltrated mechanical components.

If you regularly ride in deep mud or water, refer to the Deep Mud / Water section

of the maintenance schedule.

127

MAINTENANCE SCHEDULE

After every ride, be sure to perform the Post Operation Care for Deep Mud /

Water Environment .

Post Operation Care for Deep Mud / Water Enviironment

- Rinse the vehicle and its components with fresh water.

- Clean the CVT air filters.

- Drain the CVT compartment and clean if any water or mud is found.

- Inspect and clean engine air filters and engine air filter housing.

- Clean radiator.

- Visually inspect for any water accumulation in the vent hoses (fuel tank, gear-

box, front differential and rear final drive). If there is water, bring the vehicle to

your nearest authorized Can-Am off-road dealer for inspection and servicing

of main components related to the vents.

- Clean front and rear shock absorbers to prevent seal from damage by dust or

dirt.

- Clean drive shaft bellows and the propeller shaft yokes or boots.

Maintenance Schedule

Make sure to perform proper maintenance at recommended intervals as indi-

cated in the tables.

The maintenance chart intervals are based on 3 factors:

- Calendar time

- Vehicle hours

- Odometer reading.

Take in account whichever comes first to determine the maintenance threshold.

Your driving habits determines the factors you shall adhere too. For example:

- Someone who uses their vehicle every other weekend trail riding with friends

would most likely follow the odometer readiing to determine the maintenance

interval.

- Someone who uses their vehicle seldomly over the year or only on a few oc-

casions (hunting, camping) would most likely follow the callendar time to de-

termine the maintenance interval.

- Someone who uses their vehicle daily / weekly for long periods of time such

as agricultural / work would most likely follow the vehiicle hours to determine

the maintenance interval.

IMPORTANT: The following tables show the appropriate maintenance appli-

cation for the first

3 years. For subsequent years, repeat the same pattern

alternatively.

128

MAINTENANCE SCHEDULE

REGULAR DUTY

A=Adjust

Every year

Every 2 years

C=Clean

I=Inspect

200 hours

400 hours

L=Lubricate

R=Replace

3000 km

6000 km

T=Torque

(1900 mi)

(3700 mi)

Air and Fuel Delivery

Engine air filter

C or R

Air delivery components and function (airbox,

I, C

throttle body, ducts, clamps)*

Fuel components and function (Fuel tank cap,

fuel tank, hoses, clamps, leaks)*

Fuel pump pressure

Body, Chassis and Accessories

Cage fasteners

Seat belts retractors, buckles and

I, C

semi-cinching

Winch

I, C

Windshield hinge screws (if equipped)

Door latches, hinges and key barrels

L, T

Power tilt bed hydraulic cylinder spherical

bearing (If equipped)

Engine and Cooling

Engine oil and filter

I, A

Valve clearance (Regardless of calendar

I, A

(Mono cyl.

time)

(V-twin engines)

engines)

Spark plugs (Regardless of calendar time)

Engine seals and gaskets

Engine cooling components (Concentration,

I, A

level, hoses condition, clamps, leaks)*

Engine coolant

Every 5 years or 12 000 km (7500 mi)

Radiator

Exhaust and Emissions

Exhaust components (gaskets, pipes, muffler

I, C

condition, leaks)*

Fuel tank vent breather filter (Non EVAP

models)

130

MAINTENANCE SCHEDULE

REGULAR DUTY

A=Adjust

Every year

Every 2 years

C=Clean

I=Inspect

200 hours

400 hours

L=Lubricate

R=Replace

3000 km

6000 km

T=Torque

(1900 mi)

(3700 mi)

Canister vent pre-filter (CARB and EVAP

models)

Muffler spark arrester

Debris around exhaust pipe and muffler area

HVAC

Air filter

I, C

Heating and air conditioning components and

I, C

function*

Air conditioning compressor belt

Brake

Brake components and function (Fluid level,

brake pads, brake discs, calipers, lines and

I, C, L, A

master cylinder)*

Brake fluid

Every 2 years

Drive

Replace at first 3000 km (1900 mi) and

Gearbox oil

at 6000 km (3700 mi), then follow the

regular schedule

Gearbox oil

I, A

Front differential oil

I, A

Rear final drive oil (Mono-cyl. engine)

Middle and rear differential oil (6x6 models)

I, A

Tires (Wear, pressure)

I, A

Wheel lug nuts

Beadlock screws (if equipped)

Drive components and function*

Controls

Gearbox lever operation

I, A

Throttle operation

Continuously Variable Transmission (CVT)

CVT components and function*

I, C, L

131

MAINTENANCE SCHEDULE

REGULAR DUTY

A=Adjust

Every year

Every 2 years

C=Clean

I=Inspect

200 hours

400 hours

L=Lubricate

R=Replace

3000 km

6000 km

T=Torque

(1900 mi)

(3700 mi)

Slide shoes in driven pulley (Mono-cyl.

engine)

Electrical

Battery connections and condition

I, C

Modules fault codes and applicable software

updates

Operation of controls switches and lighting*

Vehicle speed sensor (VSS) (Mono-cyl.

engine)

Steering

Steering components and function*

Suspension

Suspension components and function*

I, C, L, T

I, L

Recommended at

Stabilizer bar bushings

every 1000 km

(620 mi)

* For an extensive list of maintenance actions to be performed, refer to your local

dealership.

132

MAINTENANCE SCHEDULE

SEVERE DUTY

A+

Every 6

Every 2

A=Adjust

Every year

months

years

C=Clean

I=Inspect

200 hours

100 hours

400 hours

L=Lubricate

R=Replace

3000 km

1500 km

6000 km

T=Torque

(1900 mi)

(900 mi)

(3700

mi)

Air and Fuel Delivery

Engine air filter

Air delivery components and

function (airbox, throttle body, ducts,

clamps)*

Fuel components and function (Fuel

tank cap, fuel tank, hoses, clamps,

leaks)*

Fuel pump pressure

Body, Chassis and Accessories

Cage fasteners

Seat belts retractors, buckles and

I, C

semi-cinching

Winch

Windshield hinge screws (if

equipped)

Door latches, hinges and key barrels

L, T

Power tilt bed hydraulic cylinder

spherical bearing (If equipped)

Engine and Cooling

Engine oil and filter

I, A

Valve clearance (Regardless of

(V-twin

(Mono cyl.

calendar time)

engines)

Spark plugs (Regardless of calendar

time)

Engine seals and gaskets

Engine cooling components

(Concentration, level, hoses

I, A

condition, clamps, leaks)*

Engine coolant

Every 5

years or 12 000 km (7500 mi)

Radiator

Exhaust and Emissions

133

MAINTENANCE SCHEDULE

SEVERE DUTY

A+

Every 6

Every 2

A=Adjust

Every year

months

years

C=Clean

I=Inspect

200 hours

100 hours

400 hours

L=Lubricate

R=Replace

3000 km

1500 km

6000 km

T=Torque

(1900 mi)

(900 mi)

(3700

mi)

Fuel tank vent breather filter (Non

EVAP models)

Canister vent pre-filter (CARB and

EVAP models)

Exhaust components (gasket, pipes,

I, C

muffler condition, leaks)*

Muffler spark arrester

Debris around exhaust pipe and

muffler area

HVAC

Air filter

I, C

Heating and air conditioning

I, C

components and function*

Air conditioning compressor belt

Brake

Brake components and function

(Fluid level, brake pads, brake discs,

C, L, A

calipers, lines and master cylinder)*

Brake fluid

Every 2 years

Drive

Replace at first

1500 km (900 mi) and at 3000

Gearbox oil and filter

km (1900 mi), then follow the regular schedule

Gearbox oil and filter

I, A

Front differential oil

I, A

Rear final drive oil (Mono-cyl.

I, A

engine)

Middle and rear differential oil (6x6

I, A

models)

Tires (Wear, pressure)

I, A

Wheel lug nuts

Beadlock screws (if equipped)

Drive components and function*

134

MAINTENANCE SCHEDULE

SEVERE DUTY

A+

Every 6

Every 2

A=Adjust

Every year

months

years

C=Clean

I=Inspect

200 hours

100 hours

400 hours

L=Lubricate

R=Replace

3000 km

1500 km

6000 km

T=Torque

(1900 mi)

(900 mi)

(3700

mi)

Controls

Gearbox lever operation

I, A

Throttle operation

Continuously Variable Transmission (CVT)

CVT components and function*

I, C, L

Slide shoes in driven pulley

(Mono-cyl. engine)

Electrical

Battery connections and condition

I, C

Modules fault codes and applicable

software updates

Operation of controls switches and

lighting*

Vehicle speed sensor (VSS)

(Mono-cyl. engine)

Steering

Steering components and function*

Suspension

Suspension components and

C, L

function*

I, L

Recommend-

Stabilizer bar bushings

ed at

every1000 km

(620 mi)

* For an extensive list of maintenance actions to be performed, refer to your local

dealership.

135

MAINTENANCE SCHEDULE

DEEP MUD / WATER

A+

Every 6

Every 2

A=Adjust

Every year

months

years

C=Clean

I=Inspect

200 hours

100 hours

400 hours

L=Lubricate

R=Replace

3000 km

1500 km

6000 km

T=Torque

(1900 mi)

(900 mi)

(3700

mi)

Air and Fuel Delivery

Engine air filter

Air delivery components and

function (airbox, throttle body, ducts,

clamps)*

Fuel components and function (Fuel

tank cap, fuel tank, hoses, clamps,

leaks)*

Fuel pump pressure

Body, Chassis and Accessories

Cage fasteners

Seat belts retractors, buckles and

I, C

semi-cinching

Winch

Windshield hinge screws

Door latches, hinges and key barrels

L, T

Power tilt bed hydraulic cylinder

spherical bearing (If equipped)

Engine and Cooling

Engine oil and filter

I, A

Valve clearance (Regardless of

(V-twin

(Mono cyl.

calendar time)

engines)

Spark plugs (Regardless of calendar

time)

Engine seals and gaskets

Engine cooling components

(Concentration, level, hoses

I, A

condition, clamps, leaks)*

Engine coolant

Every 5

years or 12 000 km (7500 mi)

Radiator

Exhaust and Emissions

136

MAINTENANCE SCHEDULE

DEEP MUD / WATER

A+

Every 6

Every 2

A=Adjust

Every year

months

years

C=Clean

I=Inspect

200 hours

100 hours

400 hours

L=Lubricate

R=Replace

3000 km

1500 km

6000 km

T=Torque

(1900 mi)

(900 mi)

(3700

mi)

Fuel tank vent breather filter (Non

EVAP models)

Canister vent pre-filter (CARB and

EVAP models)

Exhaust components (gasket, pipes,

I, C

muffler condition, leaks)*

Muffler spark arrester

Debris around exhaust pipe and

muffler area

HVAC

Air filter

I, C

Heating and air conditioning

I, C

components and function*

Air conditioning compressor belt

Brake

Brake components and function

(Fluid level, brake pads, brake discs,

C, L, A

calipers, lines and master cylinder)*

Brake fluid

Every 2 years

Drive

Replace at first

1500 km (900 mi) and at 3000

Gearbox oil and filter

km (1900 mi), then follow the regular schedule

Gearbox oil and filter

I, A

Front differential oil

I, A

Rear final drive oil (Mono-cyl.

I, A

engine)

Middle and rear differential oil (6x6

I, A

models)

Tires (Wear, pressure)

I, A

Wheel lug nuts

Beadlock screws (if equipped)

Drive components and function*

137

MAINTENANCE SCHEDULE

DEEP MUD / WATER

A+

Every 6

Every 2

A=Adjust

Every year

months

years

C=Clean

I=Inspect

200 hours

100 hours

400 hours

L=Lubricate

R=Replace

3000 km

1500 km

6000 km

T=Torque

(1900 mi)

(900 mi)

(3700

mi)

Controls

Gearbox lever operation

I, A

Throttle operation

Continuously Variable Transmission (CVT)

CVT components and function*

I, C, L

Slide shoes in driven pulley

(Mono-cyl. engine)

Electrical

Battery connections and condition

I, C

Modules fault codes and applicable

software updates

Operation of controls switches and

lighting*

Vehicle speed sensor (VSS)

(Mono-cyl. engine)

Steering

Steering components and function*

Suspension

Suspension components and

C, L

function*

I, L

Recommend-

Stabilizer bar bushings

ed at every

1000 km (620

mi)

* For an extensive list of maintenance actions to be performed, refer to your local

dealership.

138

MAINTENANCE PROCEDURES

ENGINE AIR FILTER

NOTICE

Never modiify the aiir intake sys-

tem. Otherwise, engine perform-

ance degradatiion or damage can

occur. The engiine is callibrated to

operate speciifiicallly with these

components.

Engiine Air Fiilter Repllacement

1. Air filter cover

Guideliine

2. Latches

Engine air filter inspection and re-

placement frequency should be ad-

The filter fits tightly over the outlet

justed according to riding conditions

tube and there will be some initial re-

as it is critical to ensure proper engine

sistance. Gently move the end of the

performance and life span.

filter back and forth to break the seal,

then rotate while pulling straight out.

Engine air filter inspection and re-

Avoid knocking the filter against the

placement frequency must be in-

housing.

creased for the following severe riding

conditions:

Clleaniing the Engine Aiir Fillter

- Riding on dry sand.

1. Inspect the filter for any signs of

- Riding on dry dirt covered

leaks. A streak of dust on the clean

surfaces.

side of the filter is a telltale sign.

- Riding on dry gravel trails or simi-

Replace filter if there is any dam-

lar conditions.

ages. Eliminate any source of air

- Riding in areas with high concen-

leaks before installing a new filter.

tration of seeds or crop husks.

2. Clean engine air filter by tapping

- Riding in severe snow conditions.

out heavy dust from paper ele-

ment, this will allow dirt and dust to

NOTICE

get out of the paper filter.

When riding iin dusty condiitiions or

sand, the air box needs to be

NOTICE

clleaned before every ride.

It iis not recommended to blow

compressed air on the paper ele-

NOTE:

ment; this coulld damage the pa-

Riding in a group, under these condi-

per fiibers and reduce its fiiltratiion

tions, increases the frequency of the

abiiliity when used in dusty envi-

air filter maintenance.

ronments. If engiine aiir fillter iis too

dirty and cannot be clleaned foll-

Removiing the Engine Aiir Fillter

lowing the recommended proce-

dure, iit shoulld be repllaced.

Tilt the cargo box.

Unlatch air filter cover and remove air

3. Inspect air filter housing for cleanli-

filter.

ness. Clean if necessary.

4. Use a clean damp cloth to wipe

both the filter sealing surface and

the inside of the inlet tube. Ensure

144

MAINTENANCE PROCEDURES

that the inlet tube sealing area is

critical to ensure proper engine per-

undamaged.

formance and life span.

Under the following severe riding con-

Duckbiilll Valve Cleaning

ditions, the inspection and replace-

Visually check and physically squeeze

ment frequency must be increased:

the duckbill valve.

- Riding on dry sand.

- Riding on dry dirt covered

NOTICE

surfaces.

Make sure the duckbill vallve iis

- Riding on dry gravel trails or simi-

flexible and not iinverted, dam-

lar conditions.

aged or plugged.

- Riding in muddy conditions.

- Riding in areas with high concen-

Installliing the Engine Aiir Fiilter

tration of seeds or crop husks.

- Riding in severe snow conditions.

1. Insert the filter carefully.

2. Seat the filter by hand, making cer-

NOTICE

tain it is inserted completely into

the air cleaner housing.

When riding iin dusty condiitiions or

3. Apply pressure by hand at the out-

sand, the aiir fillter needs to be

er rim of the filter, not the flexible

clleaned before every ride.

center.

4. Inspect and carefully clean gasket

NOTE:

in the groove of the cover. Replace

Riding in a group, under these condi-

if damaged.

tions, increases the frequency of the

5. Secure air filter cover with latches.

air filter maintenance.

Removiing the Priimary CVT Air

Fiilter

1. Tilt the cargo box.

2. Press the filter tabs to release it.

1. Air filter cover

2. Latches

6. Install the air filter access door

back in place and secure it with the

quarter-turn screw.

CVT Air Filter

1. Press here

CVT Aiir Fiilter Replacement

3. Remove the CVT air filter.

Guiideline

Removiing the Secondary CVT Aiir

CVT air filter inspection and replace-

Fiilter (If equipped)

ment frequency should be adjusted

according to riding conditions as it is

1. Tilt the cargo box.

145

MAINTENANCE PROCEDURES

2. Remove the primary CVT filter.

Refer to Removing the Primary

CVT Air Filter.

6. Remove the CVT air filter.

Inspecting and Cleaning the CVT

Air Fillter

Loosen the clamp.

1. Inspect filter and replace if

damaged.

2. Clean filter using a solution of soft

soap and water, then rinse.

3. Gently shake off excess water and

allow filter to dry at room

temperature.

4. Clean inside the CVT air inlet with

a vacuum cleaner.

Installliing the Priimary CVT Air Fillter

1. Reinstall the primary CVT air filter.

Remove

filter

housing

from

the

2. Lower and lock the cargo box.

vehicle.

Installliing the Secondary CVT Aiir

Fillter

1. The installation is the reverse of

the removal procedure. However

pay attention to the following.

Tightening Torque

2 ± 0.3 Nm

Gear clamp

(17 ± 3 lbf-in)

Press the filter tabs to release it.

Evaporative Emission

System Pre-Filter (If

Equipped)

Evaporative Emission System

Pre-Fillter Replacement

1. Tilt the cargo box.

2. Remove the hose clamps.

3. Remove the retaining screws.

146

MAINTENANCE PROCEDURES

Remove the pre-filter assembly.

If the recommended XPS engine oil is

not available:

- Use a 4-stroke SAE engine syn-

thetic or synthetic blend oil meet-

ing or exceeding the following

lubricant industry specifications.

- Always check the API service label

certification on the oil container, it

must contain at least one of the in-

dicated standards.

- API service cllassifiication

SN, or

- JASO MA2

Pre-Filter

Retaining screw

Veriifyiing the Engine Oill Level

Clamps

(V-Twiin)

Install a new pre-filter assembly.

NOTICE

Operatiing the engiine wiith an im-

Tiightening Torque

proper level may severely dam-

Pre-filter

age engiine.

2.5 ± 0.5 Nm

retaining

(22 ± 4 lbf-in)

screw

NOTICE

Secure hoses with clamps.

Check the oiil llevell when the en-

Install all other removed parts.

giine iis COLD.

ENGINE OIL

Place vehicle on a level surface.

Recommended Engine Oill

Clean around dipstick to avoid for-

eign particles falling down the

Rotax^® engines were developed and

tube.

validated using the XPS^® oil.

BRP recommends the use of its XPS

engine oil or an equivalent at all time.

Damage caused by the use of an oil

not suitable for the engine may not be

covered by the BRP Limited Warranty.

XPS Recommended Engine Oil

General

5W40 synthetic blend

purpose

Unscrew dipstick then remove it

oil

and wipe clean.

Cold

Reinstall dipstick, screw in it

temperature

0W40 synthetic oil

completely.

Remove dipstick and check oil lev-

Warm

el. It should be near or equal to the

temperature

10W50 synthetic oil

upper mark.

147

MAINTENANCE PROCEDURES

1. MIN

2. MAX

If the level is between marks, rein-

stall the dipstick.

If the level is below the lower mark,

add oil as follow:

1. Gasket ring (discard)

2. Drain plug

- Place a funnel into the dipstick

hole.

7. Allow oil to drain completely from

- Add a small amount of recom-

the crankcase.

mended oil and recheck oil

8. Clean the magnetic drain plug

level.

from metal shavings and residue.

- Continue to add oil until the lev-

el reaches the upper mark.

NOTE: Presence of debris gives an

indication of internal engine damage.

NOTICE

Do not overfiilll. Wiipe off any

9. Install a NEW gasket ring on the

spilllage.

drain plug.

Changiing the Engine Oil

NOTICE

Never use the gasket riing a sec-

NOTICE

ond tiime. Always replace with a

Engiine oiil and oill fiilter must be re-

new one.

pllaced at the same tiime.

10. Install and tighten drain plug to the

Oil change and oil filter replacement

recommended specification.

should be done with a warm engine.

Tighteniing Torque

CAUTION

30 ± 2 Nm

Drain plug

The engine oill can be very hot.

(22 ± 1 lbf-ft)

Wait untill engine oill iis warm.

11. Replace oil filter, refer to Oil Filter.

12. Refill engine, refer to Recom-

1. Place the vehicle on a level

mended Engine Oil.

surface.

2. Clean the dipstick area.

NOTE: For engine oil capacity, refer

3. Remove the dipstick.

to Technical Specifications.

4. Place a drain pan under the engine

drain plug area.

13. Start engine and let it idle for a 60

5. Clean the drain plug area.

seconds.

6. Unscrew drain plug and discard

14. Stop engine.

the gasket ring.

15. Check the oil level immediately, re-

fer to Verifying the Engine Oil

Level.

148

MAINTENANCE PROCEDURES

16. Refill as necessary.

17. Ensure oil filter and drain plug

areas are not leaking.

18. Dispose oil and filter as per your

local environmental regulations.

Oil Filter

Removing the Oiil Fiilter

1. Tilt the cargo box.

NOTE:

The oil filter cover can also be

Inlet bore from the oil pump to the oil filter

reached by removing the passenger

Outlet bore to the engine oil providing

seats and the engine service cover.

system

2. Clean oil filter area.

3. Remove oil filter cover.

Wet a NEW O-ring with engine oil

4. Remove and discard oil filter.

and slip onto oil filter cover.

Install the new filter into the cover.

Apply engine oil to the seal on the

open end of the oil filter.

TYPICAL

1. Oil filter screw

2. Oil filter cover

3. O-ring

4. Oil filter

1. Slightly oil

Installliing the Oill Fiilter

2. Slightly oil

1. Check and clean the oil filter inlet

and outlet area for dirt and other

NOTICE

contaminations.

Pay attention to avoid pinching

the O-ring duriing fiilter and cover

installlatiion.

5. Install the cover on the engine.

6. Tighten oil filter cover screws to

recommended specification.

149

MAINTENANCE PROCEDURES

Tighteniing Torque

NOTICE

Be careful not to damage the radi-

Oil filter cover

10 ± 1 Nm

ator fins when cleaning. Do not

screws

(89 ± 9 lbf-in)

use any objject/tool that could

7. Wipe off any oil spillage on engine.

damage the fiins. When hosiing,

use llow pressure onlly. Never use

a HIGH PRESSURE washer.

RADIATOR

Inspectiing and Cleaning the

4. To install the front grille, insert the

Radiiator

upper tabs first and push bottom of

grille in the front fascia.

Periodically check the radiator area

for cleanliness.

1. Insert upper tabs

2. Push and lock lower tabs in fascia

1. To access radiator, pull the lower

part of the front grille and slide it

ENGINE COOLANT

down.

2. Inspect radiator and hoses for

Recommended Engine Coollant

leaks or any damage.

3. Inspect radiator fins. They must be

1. XPS recommended coolant

clean, free of mud, dirt, leaves or

any other deposit that would pre-

XPS Extended liife pre-mixed

vent air from passing freely trough

coolant

the radiator.

If available, use a garden hose to

Alternative, or if the XPS product is

rinse the radiator fins.

not available.

- Distilled water and antifreeze

CAUTION

solution (50% distilled water,

Never cllean radiator wiith your

50% antifreeze)

hands when it iis hot. Let the radia-

tor cooll down before cleaning.

NOTICE

Allways use ethylene-glycoll antii-

freeze containing corrosion iinhiibi-

tors speciifiicallly for internal

combustiion alluminum engines.

150

MAINTENANCE PROCEDURES

Verifying the Engiine Coolant Level

4. Close the cargo box.

NOTICE

NOTE:

Check coolant level with engiine

A cooling system that frequently re-

cold.

quires addition of coolant is an indica-

tion of leaks or engine problems.

1. Place vehicle on a level surface.

Repllaciing the Engine Coollant

2. Open the cargo box.

3. Remove the pressure cap

WARNING

In order to avoiid potentiial burns,

WARNING

do not remove the pressure cap or

In order to avoid potentiall burns,

loosen the coolant drain pllug iif

do not remove the pressure cap or

the engiine iis hot.

loosen the coollant drain plug if

the engine is hot.

1. Remove the cooling system pres-

sure cap.

2. Unscrew coolant drain plug parti-

ally to drain the coolant into a suit-

able container.

4. Ensure cooling system is full up to

the Max line.

V-TWIN ENGINE

1. Oil filter cover

2. Water pump cover

3. Coolant drain plug

3. Disconnect the lower radiator hose

from the water pump cover and

drain the remaining coolant into a

suitable container.

4. Tighten the coolant drain plug to

specification.

Adding Coollant

Tightening Torque

1. Remove the coolant tank pressure

cap.

Coolant drain

10 ± 1 Nm

2. Using a funnel to avoid spillage,

plug

(89 ± 9 lbf-in)

add coolant in system as neces-

5. Reinstall radiator hose.

sary. Do not overfiilll.

3. Properly reinstall pressure cap on

cooling tank.

151

MAINTENANCE PROCEDURES

6. Fill cooling system with coolant, re-

Heating/Air Conditioning Air

fer to Bleeding the Cooling System

Filter (if equipped)

procedure.

NOTICE

Bleediing the Coolling System

The clleaniing of the fiilters must be

1. On models equiipped with heater

performed more often than recom-

or HVAC: Put the fan speed to

mended when riiding in dusty con-

MAX and raise the temperature

ditions or sand.

control to the maximum.

2. Remove the pressure cap.

Fresh Aiir Fiilter

3. Fill coolant system until it is full up

to the Max line on the coolant tank.

Open hood to access fresh air filter.

4. Install pressure cap.

Lift and slide filter to remove.

5. Run engine at idle with the pres-

sure cap ON until the cooling fan

cycles on for a second time.

6. Stop the engine and let it cool

down.

WARNING

In order to avoiid potentiial burns,

do not remove the pressure cap iif

the engiine iis hot.

1. Lift

7. When the engine is cool, remove

2. Slide

pressure cap and add coolant if

required.

Inspect the filter for any signs of leaks.

8. Install pressure cap.

A streak of dust on the clean side of

9. After the next ride, following this

the filter is a telltale sign. Replace filter

procedure, check coolant level.

if there is any damages. Eliminate any

Add coolant as required. Refer to

source of air leaks before installing a

Verifying the Engine Coolant

new filter.

Level.

Clean air filter by tapping out heavy

dust from paper element, this will al-

low dirt and dust to get out of the pa-

per filter.

152

MAINTENANCE PROCEDURES

NOTICE

It is not recommended to bllow

compressed aiir on the paper ele-

ment; this coulld damage the pa-

per fiibers and reduce its fiiltration

abillity when used in dusty envii-

ronments. If air fiilter is too diirty

and cannot be cleaned folllowing

the recommended procedure, iit

shoulld be replaced.

Use a clean damp cloth to wipe both

the filter sealing surface and the inside

of the outlet tube. Ensure that the out-

let tube sealing area is undamaged.

The installation is the reverse of the

removal procedure.

Cockpiit Air fiilters

Cockpit air filters are located at the

bottom of the center console. There

Clean air filter by washing it in luke-

are 3 filters:

warm water with mild soap. Remove

excess water and air dry before

- One at the front of the unit

installation.

- One on each side of the unit.

Before installing the filter, clean the in-

side of the heating/air conditioning

unit and the evaporator coil using vac-

uum and a soft brush.

NOTICE

Be carefull when brushiing to avoiid

damaging the evaporator coiil fins.

1. Front cockpit air filter

2. Lateral cockpit air filter - passenger side

3. Lateral cockpit air filter - driver side

Front Cockpit Air Fiilter

To remove this filter, lift the grille tabs

and pull up.

1. Evaporator

The installation is the reverse of the

removal procedure.

153

MAINTENANCE PROCEDURES

Laterall Cockpiit Air Fillters

EXHAUST SYSTEM

To remove these filters, grab the grille

tab and pull.

Clleaniing the Area Surrounding the

Exhaust System

WARNING

Debriis accumullatiion could llead to

a vehiclle fiire when the exhaust

system is hot and the debriis are

dried.

In some cases, that could resullt in

seriious properlly damages, iinju-

ries or even death.

Clean often and regullarly the area

1. Grille tab

surrounding the exhaust system

when ridiing iin swamp, bog, hay or

Clean air filters by washing them in

dead lleaves.

lukewarm water with mild soap. Re-

In other siituations, cllean as per

move excess water and air dry before

maintenance schedulle

installation.

requiirement.

The installation is the reverse of the

removal procedure.

CAUTION

Never perform this operation iim-

Air Conditioning Compressor

mediatelly after the engine has

Belt

been running because exhaust

system is very hot.

Visually inspect the compressor belt

for wear.

1. From the rear of the vehicle, clean

Hairline cracks do not require the re-

the areas around the muffler.

placement of the belt, but must be

2. Clean the areas around the ex-

monitored closely. Damage to the

haust pipe.

center of the belt will eventually re-

quire belt replacement, but when

WARNING

cracks extend to the edge of the belt,

the belt failure is imminent.

Clean allso under the heat shields.

The compressor belt tension verifica-

Inspecting and Cleaning the

tion and belt replacement should be

Muffler Spark Arrester

performed by an authorized Can-Am

Off-Road dealer according to the

CAUTION

Maintenance Schedule.

Never perform this operation iim-

mediatelly after the engine has

been running as exhaust system

is very hot.

1. Remove and discard the tail pipe

retaining screws.

154

MAINTENANCE PROCEDURES

GEARBOX

Recommended Gearbox Oiil

The XPS oil is specially formulated to

meet the lubrication requirements of

this gearbox. BRP strongly recom-

mends the use of its XPS oil.

NOTICE

Do not use another type of oill

when servicing.

Remove exhaust tail pipe, gasket

(discard) and spark arrester.

XPS Recommended Gearbox Oiil

75W140 Synthetic gear oil

Allternatiive, or if not availlable

75W 140 API GL-5 Synthetic gear

oil

Veriifyiing the Gearbox Oiil Levell

TYPICAL

(V-Twiin)

1. Tail pipe

Place the vehicle on a level

2. Gasket (discard)

surface.

3. Spark arrester

Select PARK position.

3. Remove carbon deposits from the

Clean dipstick area.

spark arrester using a brush.

Remove the gearbox oil dipstick.

NOTICE

Use a metalllic soft brush and be

careful to avoiid damaging spark

arrester mesh.

4. Inspect mesh of spark arrester for

any damage. Replace as required.

5. Inspect spark arrester chamber in

muffler. Remove any debris as

required.

Wipe and reinstall the dipstick.

6. Reinstall the muffler spark arrester

Remove dipstick again and check

in the reverse of the removal

oil level. It should be near or equal

procedure.

to the upper mark.

7. Tighten the tail pipe screws to

specification.

Tiightening Torque

Tail pipe

32 ± 2 Nm

screws

(24 ± 1 lbf-ft)

155

MAINTENANCE PROCEDURES

- Dipstick area.

4. Remove the dipstick.

5. Remove the drain plug.

6. Let oil completely drain from

gearbox.

7. Clean drain plug from any metallic

1. MIN.

particles.

2. MAX.

8. Install the drain plug.

3. Operating range

Tighteniing Torque

7. Add oil (if required):

20 ± 2 Nm

1. Place a funnel into the dipstick

Drain plug

(15 ± 1 lbf-ft)

hole.

2. Add a small amount of recom-

9. Refill gearbox.

mended oil.

3. Recheck oil level often.

NOTE: The oil should be level with

4. Repeat the above procedures

the bottom of the oil level orifice.

until oil level reaches the dip-

stick's upper mark.

NOTICE

Use ONLY the recommended type

NOTICE

of oiil.

Operatiing the gearbox wiith an iim-

proper oill level may severely dam-

10. Reinstall dipstick.

age gearbox.

11. Wipe off any spillage.

NOTE:

FRONT DIFFERENTIAL

Do not overfiilll. Wipe off any

spilllage.

Verifying the Front Diifferentiial Oiil

Level

8. Properly tighten oil dipstick.

1. Place the vehicle on a level

surface.

Changiing the Gearbox Oiil

2. Clean filler plug area prior to

1. Place the vehicle on a level

checking oil level.

surface.

2. Place a drain pan underneath the

The filler plug is located on the

oil drain plug area.

right side of the front differential.

1. Gearbox drain plug area

3. Clean the following areas.

VISCO-LOK

DIFFERENTIAL

(NO

– Drain plug area

ACTUATOR)

156

MAINTENANCE PROCEDURES

4. Place a drain pan under the rear

SMART-LOK

differential.

3. Remove the filler plug.

5. Remove drain plug.

4. Check oil level. The oil should

6. Unscrew filler plug.

reach the lower edge.

5. Reinstall the filler plug.

Tiightening Torque

16.5 ± 2.5 Nm

Filler plug

(146 ± 22 lbf-in)

Recommended Front Diifferentiial

Oill

The XPS oil is specially formulated to

meet the lubrication requirements of

VISCO-LOK

DIFFERENTIAL

(NO

this differential. BRP strongly recom-

ACTUATOR)

mends the use of its XPS oil.

NOTICE

Do not use another type of oil

when serviiciing.

XPS Recommended Front

Diifferentiial Oiil

75W90 Synthetic gear oil

Allternative if XPS Product iis not

SMART-LOK

Avaiilable

7. Let oil drip completely.

75W90 (API GL-5) synthetic gear oil

8. Install drain plug.

Tightening Torque

Changing the Front Diifferentiial Oiil

2.5 ± 0.5 Nm

1. Place vehicle on a level surface.

Drain plug

(24 ± 4 lbf-in)

2. Set gearbox in park position.

3. From underneath the vehicle,

9. Refill differential with recom-

clean the drain plug area.

mended

oil

for

optimal

performance.

157

MAINTENANCE PROCEDURES

10. For the differential oil capacity, re-

Removing the CVT Cover

fer to Technical Specifications.

1. Place the vehicle on a level

11. Reinstall filler plug.

surface.

2. If equipped, detach all CVT cooling

Tighteniing Torque

ducts from the CVT cover.

3. Manually, remove all CVT cover

16.5 ± 2.5 Nm

Filler plug

retaining screws.

(146 ± 22 lbf-in)

NOTICE

CVT COVER

Do not use an impact tool to re-

move CVT cover screws.

For a better understanding, some il-

lustrations are taken with engine out

of vehicle. To perform the following in-

NOTE:

structions, it is not necessary to re-

Remove the center top screw last to

move engine.

support the cover during removal.

4. Remove the CVT cover and

its

WARNING

gasket.

Never touch CVT whille engiine iis

running.

Never driive vehicle when CVT

cover is removed.

CAUTION

Engiine must be cool before cover

is removed.

NOTICE

Thiis CVT is llubriication free.

1. CVT cover

Never llubricate any components

2. CVT cover screws

except drive pullley beariing.

Installliing the CVT Cover

Accessing the CVT Cover

1. Install the center top screw of first.

1. Tilt the cargo box.

2. Tighten the CVT cover screws as

2. Remove the LH rear deflector by

per following sequence.

removing the plastic rivets.

158

MAINTENANCE PROCEDURES

Tiightening Torque

CVT cover

7 ± 0.8 Nm

screws

(62 ± 7 lbf-in)

3. Reconnect all CVT cooling ducts.

Drive Belt

Fixed sheave of driven pulley

Removing the Drive Bellt (Twiin

Adaptor

Cyllinder Engiine)

Puller/locking tool

Wrench

NOTICE

In case of a drive belt faiilure, the

To remove belt, slip the belt over

CVT, cover and aiir outllet must be

the top edge of fixed sheave, as

cleaned.

shown.

Please refer to Tips for Maximizing

Drive Belt Durability in Basic Proce-

dures for some important information.

1. Remove the CVT Cover.

2. Install the adaptor in the threaded

hole of the driven pulley.

Driven pullley adapter

(P/N 708200720)

Installling the Drive Bellt

3. Screw the puller/locking tool in the

threaded hole of the adaptor.

For installation, reverse the removal

procedure. Pay attention to following

details.

Pulller/lockiing tool

The maximum drive belt life span is

obtained when the drive belt has the

(P/N 529000088)

proper rotation direction.

4. Tighten to open the pulley.

1. Install it so that the arrow printed

on belt is pointing towards front of

the vehicle, viewed from top.

159

MAINTENANCE PROCEDURES

Driiven Pullley

Inspect the bushings of the cam and

of the sliding sheave of the driven pul-

ley, replace worn parts.

V-Twin only

Inspect rollers on fixed sheave.

Mono cyl. onlly

Inspect sliders on fixed sheave.

1. Arrow printed on belt

2. Drive pulley (front)

3. Driven pulley (rear)

4. Rotation direction

2. Turn the driven pulley until the low-

est portion of the cogs on the ex-

ternal surface of the drive belt is

even with the driven pulley edge.

Spark Plugs

Removing the Spark Pllug

1. Unplug spark plug cable.

2. Clean spark plug area with pres-

surized air before removing spark

plug.

1. Lowest portion of cogs even with driven pul-

3. Unscrew spark plug completely us-

ley edge

ing a spark plug socket, then re-

move it.

Drive and Driven Pulleys

Installliing the Spark Plugs

Inspectiing Driive and Driiven

1. Prior to installation make sure that

Pullleys

the contact surface of cylinder

head and spark plug is free of

This inspection must be performed by

grime.

an authorized Can-Am Off-road deal-

2. Using a feeler gauge, set the spark

er, repair shop, or person of your own

plug gap.

choosing for maintenance, repair, or

replacement.

Spark Plug Gap

Drive Pulley

0.8 to 0.9 mm

Inspect the bushings and rollers of the

(.031 to .035 in)

sliding sheave of the drive pulley, re-

place worn parts.

3. Coat spark plug threads with the

following anti-seize lubricant.

160

MAINTENANCE PROCEDURES

Copper-based anti-seize

lubricant

4. Screw spark plug into cylinder

heads by hand and tighten with a

torque wrench and a proper

socket.

NOTICE

Do not overtighten spark pllugs,

engiine damage can occur.

Remove battery cover by unscrewing

the two 1/4 turn fasteners.

Tiightening Torque

11 Nm

Spark plug

(97 lbf-in)

Battery

Battery Maintenance

NOTICE

1. Battery cover

Never charge a battery whille in-

stallled in vehicle.

Disconnect BLACK (-) cable first then

RED (+) cable.

These vehicles are equipped with a

VRLA battery (Valve Regulated Lead

Remove battery

holder

retaining

Acid). It is a maintenance-free type

screw(s).

battery, there is no need to add water

to adjust electrolyte level.

NOTICE

Never remove the battery sealiing

cap.

Removing the Battery

The battery is located into the cargo

box storage.

TYPICAL

Open the access panel of the RH side

1. Battery holder

of the vehicle.

2. Battery

3. Battery holder retaining screw(s)

Remove battery holder.

Remove battery.

161

MAINTENANCE PROCEDURES

Installling the Battery

Battery installation is the reverse of

the removal procedure.

NOTICE

Improper oriientation of the battery

cables (reverse pollarity) wiilll re-

sult iin damage to the volltage

regulator.

PULLING ON FRONT

SERVICE

COVER

EDGE.

NOTICE

Always connect RED (+) cablle

Lift service cover.

fiirst then BLACK (-) cablle.

Fuses and Fusible Links

Fuse Replacement

If a fuse is burnt, replace it by one of

the same rating.

NOTICE

Do not use a hiigher rated fuse as

LIFTING FRONT SERVICE COVER EDGE.

this can cause severe damage.

Fuse Box Locatiion

The vehicle is equipped with multiple

fuse boxes. The rear fuse box and the

voltage regulator fuse are located in-

side the right rear service box, near

the battery and the other fuses are lo-

cated in the front service center.

Two fuse links inside the electric har-

ness complete the system protection.

FUSE BOX SUPPORT

To open front service cover, pull on

front edges of service cover to unlock

mechanism

FUSE BOX SUPPORT

The rear fuse box is located into the

cargo box storage

162

MAINTENANCE PROCEDURES

Open the access panel of the RH side

Fuse Box Descriiptiion

of the vehicle.

Fuses – Inside Front Service

Center

NOTE:

Door can be easily removed for ac-

Inside the front storage center, the

cess. You need to remove retaining

fuse box number is molded in the

cable from the vehicle and snap off

support.

the door (no tool required).

Inside Front Serviice Center

Descrip

Rating

tiion

Master

PF1

—

fuse box

PF3

DPS

40 A

Accesso

PF4

30 A

ries

1. Access panel

Air

Condition

PF5

—

Remove the battery cover to access

ing (if

the rear fuse box by removing the both

equipped)

1/4-turn fasteners.

Smar

PF7

t-Lok™ (if

20 A

equipped)

Master Fuse Box (PF1)– In-

side Front Service Center

CAB Modells

Descriiptiion

Ratiing

F11

Headlamps

20 A

Battery cover

DC1 (12V

F12

acc outlet)/

10 A

DC3

F14

USB outlet

10 A

F16

Tail lamps

10 A

DC5 /

Power-tilt

F18

20 A

bed

(if equipped)

Rear fuse box

163

MAINTENANCE PROCEDURES

CAB Modells

Secondary Fuse Box

(Under passenger seat)

Descriiptiion

Ratiing

Descrip

Ratiing

Accessory/

tion

12V acc

—

outlet

Cluster/

10 A

relays

Brake lights

—

Ignition/

Accessory

injection/

10 A

post 12V /

—

fuel pump

USB outlet

Engine

R10

A/C clutch

—

Control

10 A

Module

Alll Other Models

(ECM)

Descriiptiion

Ratiing

Wheel

drive

10 A

Headlamps

20 A

F11

actuator

DC1 (12V

Ignition

F12

acc outlet)/

10 A

switch

10 A

DC3

Clock

F14

USB outlet

10 A

Cooling

25 A

fan

F16

Tail lamps

10 A

Oxygen

Heater

sensor

F17

F18

10 A

(if equipped)

Emission

control

DC5 /

Power-tilt

Rear

F18

20 A

F28

10 A

bed

outlet

(if equipped)

Cooling

—

fan

Accessory/

12V acc

—

Main

—

outlet

Brake lights

—

Fuse Links

Accessory

Descrip

Fuse link

Rating

post 12V /

—

tion

USB outlet

Main

18 awg

Secondary Fuse Box (PF2)–

Accessory

14 awg

Under passenger seat

post

Regulator Fuse

164

MAINTENANCE PROCEDURES

Headllight Beam Aiming

Descrip

Rating

tion

Turn adjustment screw to adjust beam

height to your convenience.

—

Regulator

50 A

NOTE:

Adjust headlights evenly.

LIGHTS

Headliight Bullb Replacement

NOTICE

Never touch glass portion of a hal-

ogen bulb with bare fiingers, it

shortens iits operatiing llife. If glass

is touched, cllean iit with iisopropyll

alcoholl whiich wiilll not leave a fiilm

on the bulb.

1. Adjustment screw

Unplug connector from bulb.

Taiilllight Bulbs Replacement

The taillights are built with LEDs (light

emitting diode) and this technology

proved to be reliable. In the unlikely

event they do not work, have them

checked by an authorized Can-Am

dealer, a repair shop or person of your

choosing.

Drive Shaft Bellow and

TYPICAL

Protector

Rotate bulb.

Inspectiing Driive Shaft Belllows and

Protector

1. Visually inspect drive shaft protec-

tors and bellows condition.

2. Check protectors for damage or

rubbing against shafts.

3. Check bellows for cracks, tears,

leaking grease, etc.

4. Repair or replace damaged parts

as necessary.

TYPICAL

Pull out bulb.

Properly reinstall removed parts in the

reverse order of their removal.

Validate headlights operation.

165

MAINTENANCE PROCEDURES

Installliing a Wheell

1. Inspect studs threads and lug nuts.

Replace if needed.

2. Install the wheel.

NOTE: The tires are unidirectional

and their rotation must be kept in a

specific direction for proper operation.

1. Drive shaft bellow - differential side

2. Drive shaft bellow - wheel side

3. Install all lug nuts by hand.

Wheel Bearing

NOTICE

Allways use the recommended

Inspectiing a Wheell Bearing

wheel llug nuts for the type of

1. Lift and support vehicle. Refer to

wheel. Usiing a diifferent llug nut

Lifting and Supporting the Vehicle.

coulld cause damages to the riim

2. Push and pull the wheels from the

or studs.

upper edge to feel the play.

3. See an authorized Can-Am Off--

4. Tighten wheel lug nuts in accord-

road dealer, a repair shop or a per-

ance with the following illustration.

son of your choosing if there is

excessive play.

Tighteniing Torque

Wheel lug

100 ± 10 Nm

nuts

(74 ± 7 lbf-ft)

TYPICAL

Wheels and Tires

Removiing a Wheell

TIGHTENING SEQUENCE

1. Place the vehicle on a level

surface.

2. Place shift lever on PARK position.

3. Loosen the wheel lug nuts.

4. Lift and support vehicle. Refer to

Lifting and Supporting Vehicle

section

5. Remove lug nuts and wheel.

166

MAINTENANCE PROCEDURES

Tire Pressure

WARNING

Replace tiires only with the same

Tiire pressure greatlly affects ve-

type and size as origiinall tires.

hicle handliing and stabillity.

For uniidiirectiional tread pattern,

Insuffiicient pressure may cause

ensure that the tires are iinstallled

tire to defllate and rotate on wheel.

in the correct directiion of rotatiion.

Overpressure may burst the tire.

Tires should be repllaced, by an

Allways folllow recommended

experienced person, in accord-

pressure.

ance wiith tire iindustry standards

NEVER set tiire pressure below

and toolls.

miinimum. It could cause the tire to

dislodge from the rim.

Power-tilt Bed

Check pressure when tires are cold

Lubricatiing the Power-tiilt Bed

before using the vehicle. Tire pressure

1. Lift the cargo box.

changes with temperature and alti-

2. Support the cargo box securely by

tude. Recheck pressure if one of

using the procedure in Securing

these conditions has changed.

the Long Cargo Box

3. Detach the power-tilt bed shock

Refer to the Tires Pressure and Maxi-

from the vehicle.

mum Load Label on your vehicle for

4. Lubricate the upper spherical ball

applicable pressure.

joint of the power-tilt bed shock

and the lower joint.

NOTE:

Although the tires are specifically de-

signed for off-road use, a flat may still

XPS suspension synthetic

occur. Therefore, it is recommended

grease

to carry a tire gauge, tire pump and a

repair kit.

Suspensions

Tire Inspection

Check tire for damage and wear. Re-

Lubricatiing the Front Suspensiion

place if necessary.

Lubricate front arms and stabilizer bar

bushings (if equipped).

WARNING

Do not rotate tires. The front and

XPS synthetic suspension grease

rear tiires have a diifferent siize.

The left and riight tires have differ-

There are two grease fittings on each

ent uniidiirectional tread patterns.

arm oriented upwards.

There is one grease fitting on each

Tire Replacement

stabilizer bar pivot bushing.

Tire replacement should be performed

by an authorized Can-Am Off-road

dealer, a repair shop or a person of

your choosing.

167

MAINTENANCE PROCEDURES

Suspensiion Inspection

See an authorized Can-Am Off-road

dealer, a repair shop or person of your

choosing if any problem is detected.

Shock Absorbers

Inspect shock absorber for leaks,

bump stop wear out or other dam-

ages. Verify fasteners are still well

tightened.

1. A-arm grease fittings

Front Suspensiion Arms

2. Stabilizer bar bushings grease fittings

(if

equipped)

Check suspension arms for cracks,

bending or other signs of excessive

Lubricatiing the Rear Suspension

wear or damage.

Lubricate rear suspension arms (two

Rear Suspension Arms

grease fittings on each arm) and rear

Check suspension arms for cracks,

stabilizer bar bushing.

bending or other signs of excessive

wear or damage.

XPS synthetic suspension grease

Brakes

Brake Flluid Reservoir Levell

Verification

With vehicle on a level surface, check

brake fluid in reservoir for proper level.

Brake fluid level should be between

MIN. and MAX. marks.

TYPICAL

1. Rear suspension arm grease fittings

1. Brake fluid reservoirs

2. MAX

3. MIN

NOTE:

TYPICAL

A low level may indicate leaks or worn

1. Rear stabilizer bar bushing grease fitting

brake pads.

168

MAINTENANCE PROCEDURES

Adding Brake Fluiid

SEAT BELTS

1. Clean both reservoir covers and

the surrounding area.

Cleaning Seat Belt

2. Add enough new brake fluid to in-

To clean dirt and debris from the seat

crease the level near the MAX

belts, sponge the straps with mild

mark.

soap and water.

NOTICE

WARNING

Do not overfilll.

To avoid damagiing the seat belt

components, never use a pres-

WARNING

sure washer to clean them.

Ensure diiaphragm iis pushed back

inside the cover before installliing

NOTICE

it.

Do not use blleach, dye, or house-

holld detergents.

Recommended Brake Fluiid

Always use brake fluid meeting the

Doors

specification DOT 4 only.

Lubricatiing Door Latch Mechanism

NOTICE

1. Lubricate door latch mechanisms

To avoiid seriious damage to the

(lock and hinges) periodically us-

brakiing system, do not use flluiids

ing a silicone based lubricant.

other than the recommended one,

nor mix different fluiids for topping

NOTICE

up.

Do not use brake flluiid taken from

Never apply any type of grease on

old or already opened contaiiners.

door lock mechanism.

Inspecting Brake System

Cage

The brake inspection, maintenance

Cage Fasteners

and repair should be performed by an

authorized Can-Am dealer, a repair

Remove trim to get access to the

shop or person of your choosing.

fasteners.

However, verify the following between

visits to your dealer:

- Brake fluid level

- Brake system for fluid leaks

- Brake pad wear

- Brake cleanliness

WARNING

The brake fluiid repllacement or

brake system maintenance and

1. Front fender

repaiirs should be performed by an

2. Side cage cover

authorized Can-Am dealer.

169

VEHICLE CARE

Vehicle Cleaning and

fresh water is necessary to preserve

vehicle and its components after each

Protection

operating day.

NOTICE

Metallic parts lubrication is highly

Never use a hiigh pressure washer

recommended.

to cllean the vehiclle. USE LOW

PRESSURE ONLY (llike a garden

Use anti-corrosive lubricant or an

hose).

equivalent.

High pressure can cause damage

to ellectriicall or mechanical

XPS Lubricant and anti-corrosive

components.

Painted parts which are damaged

Pay attention to certain areas where

should be properly repainted to pre-

salt-water, mud or debris can accumu-

vent rust.

late and potentially cause:

When required, wash the body with

- Fire

warm water and soap (only use mild

- Wear

detergent). Apply non-abrasive wax.

- Interference

- Corrosion.

NOTICE

This list includes but is not limited to:

Never cllean plastic parts wiith

- Around exhaust system and be-

strong detergent, degreasing

tween muffler and muffler cover

agent, paint thiinner, acetone, etc.

- Under and around the fuel tank

- Radiator

Protect the vehicle with a cover to pre-

- Shock absorbers

vent dust accumulation during

- Around front and rear differentials

storage.

- Around and underneath engine

and gearbox

NOTICE

- Inside wheels

- On top of skid plates.

The vehicle has to be stored in a

cool and dry pllace and covered

wiith an opaque tarpauliin. Thiis will

WARNING

prevent sun rays and grime from

Debriis accumullatiion could llead to

affecting plastiic components and

a vehiiclle fiire when the exhaust

vehicle finiish.

system is hot and the debris are

dried.

In some cases, that could result in

serious properly damages, iinju-

riies or even death.

Clean often and regullarly the area

surrounding the exhaust system

when riidiing in swamp, bog, hay or

dead lleaves.

In other situations, cllean as per

maintenance schedulle

requiirement.

When vehicle is used in salt-water en-

vironment rinsing the vehicle with

171

VEHICLE IDENTIFICATION

The main components of your vehicle

Engine Identification Number

(engine and frame) are identified by

(EIN)

different serial numbers. It may some-

times become necessary to locate

these numbers for warranty purposes

or to trace your vehicle in the event of

loss. These numbers are required by

the authorized Can-Am Off-road deal-

er to complete warranty claims prop-

erly. We strongly recommend that you

take note of all the serial numbers on

your vehicle and supply them to your

insurance company.

Vehicle Identification Number

The VIN decal is located inside the

TYPICAL

cockpit, on the right wall under the

1. EIN (Engine Identification Number)

glove box.

Compliance Label

Regulation (EU) 2016/1628

Applicable for Non-Road Mobille

Machineriies

VIN LABEL - EUROPEAN COUNTRIES

Vehicles who comply to Regulation

(EU) 2016/1628 (NRMM) are identi-

fied on the engine valve cover as well

as on the vehicle, near the VIN label.

Bombardier Recreational Products Inc.

TYPE: SbS Made in Mexico

565 de la Montagne, Valcourt, QC

BRP-Rotax GmbH Co. KG

Canada, J0E 2L0

Rotaxstrasse 1

Gunskirchen, A-4623, Austria

VIN LABEL - OTHER COUNTRIES

TYPICAL

TYPICAL - VIN LABEL LOCATION

174

VEHICLE IDENTIFICATION

ROHVA Complliance Label

This label is located inside the cockpit, on the longitudinal cage tube, above the

driver seat.

BRP Certi es that this ROV complies with the American National Standard for

This roll over protective structure meets the performance requirements of ISO 3471:

Recreational O-Highway Vehicles, ANSI / ROHVA 1 - 2016 Standard.

2008 and OSHA requirements of 29 CFR § 1928.53 (Tested at GVWR).

BRP certi e que ce véhicule récréatif hors-route est conforme à la norme ‘’ American

Cette structure de protection contre le retournement respecte les requis de

National Standard for Recreational O-Highway Vehicles’’, ANSI / ROHVA 1 - 2016.

performance de la norme ISO 3471: 2008 et de OSHA 29 CFR § 1928.53 (Testé au

PNBV).

704906981

Technical Information Label

Miiddlle Seat Opening Piictogram

This pictogram is located near the locking tab of the middle seat.

HVAC Information Labell

This decal is located on the inner side of the front service cover.

176

EVAPORATIVE EMISSION CONTROL SYSTEM

Caliifornia Models with Evaporative Emiissiion Control System

Beginning with the 2018 model-year vehicles, some California models are certi-

fied to meet the CARB (California Air Resources Board) TP-933. These models

are equipped with an evaporative emission control system consisting of a low

permeation fuel tank (LPFT), low permeation fuel lines (LPFL) and an actively

purged carbon canister.

The following statement is required by the CCR (California Code of Regulation):

An add-on or modified part must be compliant with applicable ARB evaporative

emission control standards. A violation of this requirement is punishable by civil

and/or criminal punishment.

180

NOISE EMISSION CONTROL SYSTEM

REGULATION

USA and Canada Only

Tampering wiith Noise Control System Is Prohibiited!

U.S. Federal law and Canadian provincial laws may prohibit the following acts or

the causing there of:

1. The removal or rendering inoperative by any person other than for purposes

of maintenance, repair or replacement of any device or element of design in-

corporated into any new vehicle for the purpose of noise control prior to its

sale or delivery to the ultimate purchaser or while it is in use or

2. The use of the vehicle after such device or element of design has been re-

moved or rendered inoperative by any person.

Among those Acts Presumed to Constiitute Tampering Are the Acts Listed

Below:

1. Removal or alteration or the puncturing of the muffler or any engine compo-

nent which conducts removal of engine exhaust gases.

2. Removal or alteration or the puncturing of any part of the intake system.

3. Replacing any moving parts of the vehicle or parts of the exhaust or intake

system, with parts other than those specified by the manufacturer.

4. Lack of proper maintenance.

181

TECHNICAL SPECIFICATIONS

Engiine

ROTAX Twin cylinder.

4-stroke, Single Over

Engine type

Head Camshaft

(SOHC), liquid cooled

Number of cylinders

8 valves (mechanical

Number of valves

adjustment)

0.08 to 0.12 mm

Intake valve clearance

(.0031 to .0047 in)

0.13 to 0.17 mm

Exhaust valve clearance

(.0051 to .0067 in)

91 mm

Bore

(3.58 in)

75 mm

Stroke

(2.95 in)

976 cm³

Displacement

(59.56 in³)

Exhaust system

Catalyst

Air filter

Synthetic paper filter

Lubricatiion System

Type

Wet sump

Replaceable cartridge

Oil filter

oil filter (paper type)

Without

HVAC

(2.1 qt (liq.,US))

Capacity

2.1 l

With HVAC

(2.22 qt (liq.,US))

Engine oil

General

5W40 Synthetic blend

purpose

oil

Recom

mended

Cold

XPS oil

tempera

0W40 Synthetic oil

ture

188

TECHNICAL SPECIFICATIONS

Lubriication System

Warm

tempera

10W50 Synthetic oil

ture

If not available, use a

5W40 or 10W50 motor

Alternate if XPS

oil that meets the

products are not

requirements for API

available

service classification SN

or JASO MA2

Coolling System

Recommended XPS

Extended life pre-mixed

coolant

Ethylene glycol / water

mix (50/50).

Alternate if XPS product

or coolant specifically

is not available

designed for aluminum

Coolant

engines

Without

6.8 l

HVAC

(1.80 gal (liq.,US))

Capacity

7.5 l

With HVAC

(1.98 gal (liq.,US))

Transmissiion

CVT (Continuously

Type

Variable Transmission)

Engagement

2000 ± 100 RPM

Gearbox

Dual range (HI-LO) with

Type

PARK, neutral and

reverse

1.25 l

Capacity

(1.321 qt (liq.,US))

Recommended XPS

XPS 75W140 Synthetic

Gearbox oil

gearbox oil

gear oil

Alternate if XPS product

75W 140 API GL-5

is not available

189

TECHNICAL SPECIFICATIONS

Electriicall System

HVAC

850 W @ 6000 RPM

models

Magneto generator output

All other

650 W @ 6000 RPM

models

IDI (Inductive Discharge

Ignition system type

Ignition)

Quantity

Make and type

NGK LMAR8C-9

Spark plug

0.8 to 0.9 mm

Gap

(.031 to .035 in)

Maintenance free —SLA

Type

(Sealed Lead Acid)

Voltage

12 volts

Battery

Nominal

DPS

18 A•h

rating

All other

30 A•h

Power starter output

750 W

Headlight

4 x 35W (H8)

Taillight

LED

Signature lights

Limited

LED

Refer to Fuses in the

Fuses

Maintenance section

Fuell System

Electronic fuel injection

Fuel delivery

(EFI) with iTC

Throttle body

54 mm with ETA

Fuel pump

Electric (in fuel tank)

1350 ± 100 RPM

Idle speed

(1500 ± 100 RPM when

HVAC is ON)

Type

Regular unleaded

Fuel

gasoline

190

TECHNICAL SPECIFICATIONS

Fuel System

North

87 AKI (R+M)/2

America

Minimum

Octane

Outside

rating

North

91 RON

America

± 40 l

Fuel tank capacity

(10.6 gal (liq.,US))

± 8.5 l

Fuel remaining when low fuel light turns ON

(2.2 gal (liq.,US))

Drive System

Drive system type

Selectable 2WD/4WD

400 ml

Capacity

(14 fl oz (US))

Recommended XPS

XPS 75W90 Synthetic

Front differential oil

differential oil

gear oil

Alternate oil if XPS

Synthetic gear oil

products is not available

75W90 API GL-5

Selectable 2WD / 4WD

with Smart-Lok

Limited

electronic control locking

front differential, spiral

gears

Front drive

Selectable 2WD / 4WD

with Visco-Lok

All other models

auto-locking front

differential, spiral gears

Front drive ratio

3.6:1

Rear drive

Lockable differential

Rear drive ratio

3.43:1

CV joint grease

XPS CV joint grease

Spline's propeller shaft grease (grease applied to

XPS Propeller shaft

spline connections)

grease or equivalent

191

TECHNICAL SPECIFICATIONS

Steering

Type

Rack and pinion

Steering wheel

Adjustable tilt steering

Front Suspension

DPS

Double arched

suspension arms

Suspension type

Double arched

Limited

suspension arms with

stabilizer bar

DPS

279 mm

(11 in)

Suspension travel

305 mm

Limited

(12 in)

Quantity

Shock absorber

Type

Gas charged

Preload adjustment

5 positions cam

Rear Suspension

Double arched TTA with

Suspension type

stabilizer bar

DPS

279 mm

(11 in)

Suspension travel

305 mm

Limited

(12 in)

Quantity

Shock absorber

Type

Gas charged

Preload adjustment

5 positions cam

Brakes

Qty

Front brake

220 mm (8.7 in)

Type

ventilated brake disc

192

TECHNICAL SPECIFICATIONS

Tires

Recommended tire

inflation pressure is

found on the Tire Label.

Pressure

Refer to appropriate

Important On-Product

Labels section for its

location.

762 x 229 x 356 mm

Limited

(30 x 9R14 in)

Front

Other

711 x 229 x 356 mm

models

(27 x 9R14 in)

Tire size

762 x 254 x 356 mm

Limited

(30 x 10R14 in)

Rear

Other

711 x 279 x 356 mm

models

(27 x 11R14 in)

3 mm

Minimum tire thread depth

(.118 in)

Wheells

Type

Cast aluminum

35.6 x 18 cm

Front

(14 x 7 in)

35.6 x 18 cm

Rim size

Limited

(14 x 7 in)

Rear

Other

35.6 x 20.3 cm

models

(14 x 8.5 in)

100 ± 10 Nm

Wheel lug nuts torque

(74 ± 7 lbf-ft)

41.2 mm

Front

(1.6 in)

41.2 mm

Wheel Offset

Limited

(1.6 in)

Rear

Other

51 mm

models

(2 in)

194

TECHNICAL SPECIFICATIONS

Loading Capaciity and Weiight

881 kg

(1,942 lb)

1 047 kg

Limited

(2,309 lb)

Weight distribution (front/rear)

44/56

Californian

272 kg

models

(600 lb)

Cargo box capacity

All other

454 kg

models

(1,000 lb)

113 kg

Tailgate capacity

(250 lb)

Defender

PRO DPS

712 kg

Defender

(1,570 lb)

Total vehicle payload allowed

PRO XT

(including driver, passengers, all

other loads and added

Defender

600 kg

accessories)

PRO Limited

(1,320 lb)

Traxter PRO

771 kg

DPS

(1,700 lb)

1 637 kg

DPS

(3,609 lb)

1 694 kg

Gross vehicle weight rating

(3,735 lb)

1 688 kg

Limited

(3,721 lb)

1 134 kg

Towing capacity

(2,500 lb)

114 kg

Tongue capacity

(250 lb)

50.8 x 50.8 mm

Receiver Hitch

(2 x 2 in)

196

TROUBLESHOOTING GUIDELINES

CVT Belt Is Slipping

1. Water has entered in the CVT.

- Refer to Special Procedures.

“–” Is Displayed On the Gearbox Position Display

1. Shift lever is between 2 positions.

- Properly position the shift lever in the desired position.

2. Shift lever is not properly adjusted.

- Contact an authorized Can-Am Off-road dealer.

3. Electrical communication error.

- Contact an authorized Can-Am Off-road dealer.

Engine Does Not Turn

1. Starting procedure not performed correctly.

- Refer to Starting the Engine.

2. Shift lever is not set on PARK.

- Set shift lever to either in PARK or press the brake pedal.

3. Burnt fuse.

- Check fuses.

4. Weak battery or loose connections.

- Check charging system fuse.

- Check fault message in cluster.

- Check battery connections and terminals condition.

- Have the battery checked by an authorized Can-Am Off-road dealer.

5. Defective starter solenoid.

- Contact an authorized Can-Am Off-road dealer.

Engine Turns Over But Fails To Start

1. Flooded engine

- Active the drowned mode to start the engine. Refer to Flooded Engine in Spe-

cial Procedures section.

2. No fuel to the engine (spark plug dry when removed).

- Check fuel tank level.

- Check fuel pump fuse.

- Obstructed fuel pump pre-filter or fuel pump failure.

198

TROUBLESHOOTING GUIDELINES

See an authorized Can-Am Off-road dealer, a repair shop, or a person of your

own choosing for maintenance, repair, or replacement.

Please refer to the US EPA Emission-Related Warranty contained herein for

information about warranty claims.

3. Spark plug/ignition (no spark).

- Check ignition fuse.

- Remove spark plug then reconnect to ignition coil.

- Start engine with spark plug grounded to the engine away from spark plug

hole. If no spark appears, replace spark plug.

If trouble persists, see an authorized Can-Am Off-road dealer, a repair shop,

or a person of your own choosing for maintenance, repair, or replacement.

Please refer to the US EPA Emission-Related Warranty contained herein for

information about warranty claims.

Engine Lacks Acceleration or Power

1. Seat belt not buckled properly. Check cluster message.

Buckle up seat belt.

2. Fouled or damaged spark plug.

Replace spark plugs.

3. Engine air filter plugged or dirty.

Check air filter and replace if necessary.

–

Check deposits in engine air filter housing.

4. Water in CVT

Drain water from CVT. Refer to Special Procedures section.

5. CVT dirty or worn-out.

Contact an authorized Can-Am Off-road dealer.

6. Lack of fuel

Dirty or clogged fuel pump pre-filter. See an authorized Can-Am Off-road

dealer, a repair shop, or a person of your own choosing for maintenance, re-

pair, or replacement. Please refer to the US EPA Emission-Related Warranty

contained herein for information about warranty claims.

7. Engine is in Torque Limitation mode (if equipped).

Engine torque is gradually limited for protection when coolant temperature is

too high. Check multifunction gauge display for engine temperature.

Let engine cool down.

8. Engine is in limp home mode.

199

TROUBLESHOOTING GUIDELINES

- Multifunction gauge CHECK ENGINE indicator lamp is on and display shows

LIMP HOME. See an authorized Can-Am Off-road dealer, a repair shop, or a

person of your own choosing for maintenance, repair, or replacement. Please

refer to the US EPA Emission-Related Warranty contained herein for informa-

tion about warranty claims.

Engine Overheats

1. Low coolant level in cooling system.

- Check coolant level and refill. See Maintenance Procedures. Seek service

from an authorized Can-Am Off-road dealer, a repair shop, or a person of

your own choosing for maintenance, repair, or replacement. Please refer to

the US EPA Emission-related warranty contained herein for information about

warranty claims.

2. Cooling fan is not working.

- Ensure cooling fan is not jammed and working properly.

- Check fan fuse. See Fuses and Fusible Links in the Maintenance

Procedures.

3. Dirty radiators fins.

- Check and clean radiator fins. See Maintenance Procedures.

Engine Misfire

1. Fouled/damaged/worn spark plug.

- Replace spark plugs as required.

2. Water in fuel.

- Drain fuel system and refill with fresh fuel.

The RPM Increases But the Vehicle Does Not Move

1. Water in the CVT.

- Drain water from CVT. See Special Procedures section.

2. CVT dirty or worn-out or belt failure.

- Contact an authorized Can-Am Off-road dealer.

Partial or No Response From the Accelerator Pedal - Check

Engine Is ON and PPS Fault Message Is Displayed

1. Partial failure of the accelerator pedal sensors (PPS).

- Contact an authorized Can-Am Off-road dealer.

2. Total failure of the accelerator pedal sensors (PPS).

- Contact an authorized Can-Am Off-road dealer.

200

DIGITAL DISPLAY MESSAGES

If an abnormal engine condition occurs, the following messages can be com-

bined with a pilot lamp.

Message

Description

D.E.S.S. KEY

NOT

D.E.S.S. key requires cleaning. If message still displayed

after cleaning, See an authorized Can-Am Off-road dealer.

RECOGNIZED

Indicates that you have used the wrong D.E.S.S. key, use

BAD KEY

the proper key for this vehicle.

All active or previously activated faults that require

CHECK ENGINE

attention.

No engine limitation engaged.

Critical faults requiring diagnostic as soon as possible.

LIMP HOME

An engine limitation is engaged and/or the engine behavior

is modified.

TPS FAULT

Throttle body fault, generally followed by a Limp Home

message.

BRAKE SWITCH

FAULT

Brake signal fault.

Check engine pilot light on. Indicates that the DPS

CHECK DPS

(Dynamic Power Steering) does not work properly. See an

authorized Can-Am Off-road dealer.

PPS FAULT

Faulty Pedal Position Sensor(s) (PPS). See an authorized

Can-Am Off-road dealer.

FUEL SENSOR

When the fuel sender resistor value is out of range the

FAULT

digital display module will detect it and display the

message.

CHECK

Check engine pilot light on. Indicates that the Smart-Lok

SMART-LOK

does not work properly. See an authorized Can-Am

Off-road dealer.

201

BRP LIMITED WARRANTY FOR CANADA AND USA:

2024 CAN-AM® SSV

1) Scope of the Limited Warranty

Bombardier Recreational Products Inc. ("BRP") warrants its 2024 Can-Am SSV

(“Product (s)”) sold by authorized BRP Dealers (as hereinafter defined) in the

United States of America ("USA") and in Canada from defects in material or

workmanship for the period and under the conditions described below.

This limited warranty will become null and void if:

1. the Product was used for racing or any other competitive activity, at any point,

even by a previous owner; or

2. the Product has been altered or modified in such a way so as to adversely af-

fect its operation, performance or durability, or has been altered or modified

to change its intended use.

Non-factory installed parts and accessories are not covered under this limited

warranty. Please refer to the applicable parts and accessories limited warranty

text.

2) Limitations of Liability

TO THE EXTEND PERMITTED BY LAW, THIS WARRANTY IS EX-

PRESSLY GIVEN AND ACCEPTED IN LIEU OF ANY AND ALL OTHER

WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMI-

TATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. TO THE EXTENT THAT THEY CANNOT BE

DISCLAIMED, THE IMPLIED WARRANTIES ARE LIMITED IN DURATION

TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND CON-

SEQUENTIAL DAMAGES ARE EXCLUDED FROM COVERAGE UNDER

THIS WARRANTY. SOME STATES/PROVINCES DO NOT ALLOW FOR

THE DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED

ABOVE. AS A RESULT, THEY MAY NOT APPLY TO YOU. THIS WAR-

RANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE

OTHER LEGAL RIGHTS WHICH MAY VARY FROM STATE TO STATE,

OR PROVINCE TO PROVINCE.

Neither the distributor, any BRP dealer nor any other person has been authorized

to make any affirmation, representation or warranty regarding the product, other

than those contained in this limited warranty, and if made, shall not be enforce-

able against BRP.

BRP reserves the right to modify this limited warranty at any time, being under-

stood that such modification will not alter the warranty conditions applicable to

the Products sold while this warranty is in effect.

3) EXCLUSIONS – Are Not Warranted

The following are not warranted under any circumstances:

- Normal wear and tear;

- Routine maintenance items, tune ups, adjustments;

- Damage caused by negligence or failure to provide proper maintenance and/

or storage, as described in the Operator's Guide;

- Damage resulting from removal of parts, improper repairs, service, mainte-

nance, modifications or use of parts not manufactured or approved by BRP or

204

BRP LIMITED WARRANTY FOR CANADA AND USA: 2024 CAN-AM^® SSV

resulting from repairs done by a person that is not an authorized servicing

BRP dealer;

- Damage caused by abuse, abnormal use, neglect or operation of the product

in a manner inconsistent with the recommended operation described in the

Product’s Operator’s Guide;

- Damage resulting from accident, submersion, fire, theft, vandalism or any act

of God;

- Operation with fuels, oils or lubricants which are not suitable for use with the

Product (see the Operator’s Guide);

- Damages from rust, corrosion or exposure to the elements;

- Damage resulting from water or snow ingestion;

- Incidental or consequential damages, or damages of any kind including with-

out limitation transportation expenses, towing, storage, telephone, rental, taxi,

inconvenience, insurance coverage, loan payments, loss of time, loss of in-

come or time missed for downtime experience due to service work.

4) Warranty Coverage Period

This limited warranty will be in effect from (1) the date of delivery to the first retail

consumer, or (2) the date the product is first put into use, whichever occurs first

and for the applicable period below:

1. TWELVE (12) consecutive months, for private use or commercial use owners

2. For emiission-related components, please also refer to the US EPA Emis-

sion-Related Warranty.

3. For evaporative emission-rellated components of Callifornia models

equipped wiith evaporatiive emission control system produced by BRP

for sale in the State of California that are originally sold to a resident or

subsequently warranty registered to a resident in the State of California, also

refer to the California Evaporative Emissions Control Warranty Statement.

The repair or replacement of parts or the performance of service under this war-

ranty does not extend the life of this limited warranty beyond its original expiration

date.

5) Conditions to Have Warranty Coverage

This warranty coverage is available only if each of the following conditions has

been fulfilled:

1. The Product must be purchased as new and unused by its first owner from a

Dealer authorized to sell the Products in the country in which the sale oc-

curred (“Dealer”);

2. The BRP specified pre-delivery inspection process must be completed, docu-

mented and signed by the purchaser;

3. The Product must have undergone proper registration by an authorized

Dealer;

4. The Product must be purchased in the country in which the purchaser

resides;

5. Routine maintenance outlined in the Operator’s Guide must be timely per-

formed in order to maintain warranty coverage. BRP reserves the right to

make warranty coverage contingent upon proof of proper maintenance.

205

BRP LIMITED WARRANTY FOR CANADA AND USA: 2024 CAN-AM^® SSV

BRP will not honor this limited warranty to any private use owner or commercial

use owner if one of the preceding conditions has not been met. Such limitations

are necessary in order to allow BRP to preserve both the safety of its products,

and also that of its consumers and the general public.

6) What to Do to Obtain Warranty Coverage

The customer must cease using the Product upon the appearance of an anom-

aly, notify a servicing BRP dealer within three (3) days of the appearance of the

anomaly and provide the Dealer with reasonable access to the Product and rea-

sonable opportunity to repair it.

The customer must also present to the Dealer, proof of purchase of the Product

and must sign the repair/work order prior to starting the repair in order to validate

the warranty repair.

All parts replaced under this limited warranty become the property of BRP.

7) What BRP Will Do

BRP’s obligations under this warranty are limited to, at its sole discretion, repair-

ing or replacing parts found defective under normal use, maintenance and serv-

ice without charge for parts and labor, at any authorized BRP dealer during the

warranty coverage period under the conditions described herein. No claim of

breach of warranty shall be cause for cancellation or rescission of the sale of the

Product to the owner.

In the event that service is required outside of the country of original sale, the

owner will bear responsibility for any additional charges due to local practices

and conditions, such as, but not limited to, freight, insurance, taxes, license fees,

import duties, and any and all other financial charges, including those levied by

governments, states, territories and their respective agencies.

BRP reserves the right to improve or modify products from time to time without

assuming any obligation to modify products previously manufactured.

8) Transfer

If the ownership of a Product is transferred during the warranty coverage period,

this limited warranty, subject to its terms and conditions, shall also be transferred

and be valid for the remaining coverage period provided BRP or an authorized

Product Distributor/Dealer receives a proof that the former owner agreed to the

transfer of ownership, in addition to the coordinates of the new owner.

9) Consumer Assistance

In the event of a controversy or a dispute in connection with this limited warranty,

BRP suggests that you try to resolve the issue at the dealership level. We recom-

mend discussing the issue with the authorized dealer's service manager or

owner.

If the matter still remains unresolved, contact BRP by filling out the customer con-

tact form at www.brp.com or contact BRP by mail at one of the addresses listed

under the Contact Us section of this guide.

206

US EPA EMISSION - RELATED WARRANTY

Bombardier Recreational Products Inc. (“BRP”) warrants to the ultimate purchas-

er and each subsequent purchaser that this new vehicle, including all parts of its

exhaust emission control system and its evaporative emission control system,

meets two conditions:

1. It is designed, built, and equipped so it conforms at the time of sale to the ulti-

mate purchaser with the requirements of 40 CFR 1051 and 40 CFR 1060.

2. It is free from defects in materials and workmanship that may keep it from

meeting the requirements of 40 CFR 1051 and 40 CFR 1060.

Where a warrantable condition exists, BRP will repair or replace, as it elects, any

part or component with a defect in materials or workmanship that would increase

the engine’s emissions of any regulated pollutant within the stated warranty peri-

od at no cost to the owner, including expenses related to diagnosing and repair-

ing or replacing emission-related parts. All defective parts replaced under this

warranty become the property of BRP.

For all emission-related warranty claims, BRP is limiting the diagnosis and repair

of emission-related parts to the authorized Can-Am dealers, unless for emer-

gency repairs as required by item 2 of the following list.

As a certifying manufacturer, BRP will not deny emission-related warranty claims

based on any of the following:

1. Maintenance or other service BRP or BRP's authorized facilities performed.

2. Engine/equipment repair work that an operator performed to correct an un-

safe, emergency condition attributable to BRP as long as the operator tries to

restore the engine/equipment to its proper configuration as soon as possible.

3. Any action or inaction by the operator unrelated to the warranty claim.

4. Maintenance that was performed more frequently than BRP specify.

5. Anything that is BRP fault or responsibility.

6. The use of any fuel that is commonly available where the equipment operates

unless BRP written maintenance instructions state that this fuel would harm

the equipment’s emission control system and operators can readily find the

proper fuel. See maintenance information section and fuel requirements of fu-

eling section.

Emission-Related Warranty Period

The emission-related warranty is valid for the following period whichever comes

first.

HOURS

MONTHS

KILOMETERS

Exhaust emission-related

500

5000

components

Evaporative emission-related

N/A

components

Components Covered

The emission-related warranty covers all components whose failure would in-

crease an engine’s emissions of any regulated pollutant, including the following

listed components:

207

US EPA EMISSION - RELATED WARRANTY

For exhaust emissions, emission-related components include any engine

parts related to the following systems:

- Air-induction system

- Fuel system

- Ignition system

- Exhaust gas recirculation systems.

The following parts are also considered emission-related components for ex-

haust emissions:

- After treatment devices

- Crankcase ventilation valves

- Sensors

- Electronic control units.

The following parts are considered emission-related components for evapora-

tive emissions:

- Fuel tank

- Fuel cap

- Fuel line

- Fuel line fittings

- Clamps*

- Pressure relief valves*

- Control valves*

- Control solenoids*

- Electronic controls*

- Vacuum control diaphragms*

- Control cables*

- Control linkages*

- Purge valves

- Vapor hoses

- Liquid/vapor separator

- Carbon canister

- Canister mounting brackets

- Carburetor purge port connector.

NOTE: *As related to the evaporative emission control system.

4. Emission-related components also include any other part whose only purpose

is to reduce emissions or whose failure will increase emissions without signifi-

cantly degrading engine/equipment performance.

Limited Applicability

As a certifying manufacturer, BRP may deny emission-related warranty claims

for failures that have been caused by the owner’s or operator’s improper mainte-

nance or use, by accidents for which the manufacturer has no responsibility, or

by acts of God. For example, an emission-related warranty claim need not be

honored for failures that have been directly caused by the operator’s abuse of

the engine/equipment or the operator’s use of the engine/equipment in a manner

for which it was not designed and are not attributable to the manufacturer in

anyway.

208

CALIFORNIA EVAPORATIVE EMISSIONS

CONTROL WARRANTY STATEMENT

The warranty periods begin on the date the new Off-Highway Recreational Ve-

hicle (“OHRV”) is delivered to an ultimate purchaser.

Bombardier Recreational Products Inc. (“BRP”) warrants to the ultimate purchas-

er and each subsequent purchaser that the OHRV is:

1. Designed, built, and equipped so as to conform, at the time of sale, with all

applicable laws, rules and regulations; and

2. Free from defects in materials and workmanship that may cause the failure of

a warranted part. All replacement parts must be identical in all material re-

spects to that part as described in BRP’s Executive Order of Certification

application.

The warranty on emissions-related parts function as follows:

Repair or replacement of any warranted part must be performed at no charge

to the OHRV owner, at a warranty station, except in the case of a temporary

repair when a warranted part or a warranty station is not reasonably available

to the OHRV owner. In the event a temporary repair is permitted, repairs may

be performed at any available service establishment, or by the owner, using

any replacement part. BRP must reimburse the owner for his or her expenses

including diagnostic charges for such temporary repair or replacement, not to

exceed BRP's suggested retail price for all warranted parts replaced and la-

bor charges based on BRP's recommended time allowance for the warranty

repair and the geographically appropriate hourly labor rate.

The lack of availability of warranted parts or the incompleteness of repairs

within a reasonable time period, not to exceed 30 days from the time the

OHRV is initially presented to the warranty station for repair, will qualify the

need for a temporary repair.

Any warranted part which is not scheduled for replacement as part of mainte-

nance in the written instructions must be warranted for the warranty period

defined below. If any such part fails during the warranty period, it must be re-

paired or replaced by BRP. Any such part repaired or replaced under war-

ranty must be fully warranted.

Any warranted part which is scheduled only for regular inspection in the writ-

ten instructions must be warranted for the warranty period defined below. A

statement in such written instructions to the effect of “repair or replace as nec-

essary” does not reduce the period of warranty coverage. Any such part re-

paired or replaced under warranty is warranted for the remaining warranty

period.

Any warranted part which is scheduled for replacement as part of mainte-

nance in the written instructions is warranted for the period of time prior to the

first scheduled replacement point for that part. If the part fails before the first

scheduled replacement point, the part will be repaired or replaced by BRP.

Any such part repaired or replaced under warranty is warranted for the re-

mainder of the period prior to the first scheduled replacement point for the

part.

Warranty services or repairs are provided at all manufacturer dealerships that

are owned by the manufacturer or franchised to service the subject OHRVs.

The OHRV owner will not be charged for diagnostic labor which leads to the

determination that a warranted part is, in fact, defective, provided that such di-

agnostic work is performed at a warranty station.

210

CALIFORNIA EVAPORATIVE EMISSIONS CONTROL WARRANTY STATEMENT

8. BRP is liable for damages to other vehicle components proximately caused

by a failure, under warranty, of any warranted part.

9. Any replacement part designated by BRP may be used in warranty repairs

provided without charge to the OHRV owner. Such use will not reduce the

warranty obligations of BRP, except that BRP will not be liable for repair or re-

placement of any replacement part which is not a warranted part.

10. Any add-on or modified part exempted by the Air Resources Board from the

prohibitions of section 27156 of the California Vehicle Code may be used on

an OHRV. Such use, in and of itself, will not be grounds for disallowing a war-

ranty claim. BRP is not liable to warrant failures of warranted parts caused by

the use of an add-on or modified part (s) unless such part (s) are also

warranted.

Conditions and exclusions:

- BRP may deny you warranty coverage if your OHRV or a part has failed di-

rectly due to abuse, neglect, improper maintenance or unapproved

modifications.

Your Warranty Rights And Obligations

The California Air Resources Board is pleased to explain the evaporative emis-

sions control system warranty on your 2024 Off-Road Sport Vehicle. In Califor-

nia, new off-highway recreational vehicles must be designed, built, and equipped

to meet the State’s stringent anti-smog standards. BRP must warrant the evapo-

rative emissions control system on your Off-Road Sport Vehicle for the periods of

time listed below provided there has been no abuse, neglect, improper mainte-

nance, or unapproved modification of your Off-Road Sport Vehicle.

Your evaporative emissions control system may include parts such as the carbu-

retor or fuel-injection system, fuel tank, fuel hoses, carbon canister, and engine

computer. Also included may be hoses, belts, connectors and other evaporative

emissions-related assemblies. Where a warrantable condition exists, Bombardier

Recreational Products Inc. will repair your Off-Road Sport Vehicle at no cost to

you including diagnosis, parts and labor.

OHRV Manufacturer’s Warranty Coverage

The warranty period for this OHRV is 60 months, or 5000 miles, or 500 hours,

whichever comes first.

Parts covered:

1. Canister Mounting Bracket(s)

2. Carbon Canister

3. Purge Port Connector

4. Clamp(s)*

5. Electronic Control*

6. Fuel Cap

7. Filler Neck

8. Filler Neck Hose

9. Fuel Line(s)

10. Fuel Line Fitting(s)

11. Fuel Tank

12. Pressure Relief Valve(s)*

211

CALIFORNIA EVAPORATIVE EMISSIONS CONTROL WARRANTY STATEMENT

13. Purge Valve(s)

14. Check Valve(s)*

15. Vapor Hose(s)

16. Flow Reducer

17. Filter(s)*

18. Fuel pump

19. All other parts not listed that may affect the evaporative emissions control

system

NOTE: *As related to the evaporative emission control system.

If any evaporative emissions-related part on your Off-Road Sport Vehicle is de-

fective the part will be repaired or replaced by Bombardier Recreational Products

Inc.

Owner’s Warranty Responsibilities

As the Off-Road Sport Vehicle owner you are responsible for the performance of

the required maintenance listed in your owner’s manual. Bombardier Recreation-

al Products Inc. recommends that you retain all receipts covering maintenance

on your Off-Road Sport Vehicle, but Bombardier Recreational Products Inc. can-

not deny warranty solely for the lack of receipts or for failure to ensure the per-

formance of a scheduled maintenance.

As an owner you are responsible for presenting your Off-Road Sport Vehicle to a

Bombardier Recreational Products Inc. dealer as soon as a problem exists. The

warranty repairs should be completed in a reasonable time, not to exceed 30

days.

As an Off-Road Sport Vehicle owner, you should also be aware that Bombardier

Recreational Products Inc. may deny you warranty coverage if your Off-Road

Sport Vehicle or a part has failed due to abuse, neglect, improper maintenance

or unapproved modifications.

If you have any questions regarding your warranty rights and responsibilities, you

should contact:

- Bombardier Recreational Products Inc. at 1-888-272-9222, or

- The California Air Resources Board at 4001 Iowa Avenue, Riverside, CA

92507.

212

BRP LIMITED WARRANTY FOR INTERNATIONAL:

2024 CAN-AM® SSV

1) Scope of the Limited Warranty

Bombardier Recreational Products Inc. ("BRP") warrants its 2024 Can-Am SSV

(“Product(s)”) sold by distributors or dealers authorized by BRP to distribute the

Products outside of the United States of America ("USA"), Canada, member

states of the European Economic Area (which is comprised of the states of the

European Union plus the United Kingdom, Norway, Iceland and Liechtenstein)

("EEA"), Turkey, member states of the Commonwealth of the Independent States

(including Ukraine and Turkmenistan) ("CIS") from defects in material or work-

manship for the period and under the conditions described below.

This limited warranty will become null and void if:

1. the Product was used for racing or any other competitive activity, at any

point, even by a previous owner; or

2. the Product has been altered or modified in such a way so as to adversely af-

fect its operation, performance or durability, or has been altered or modified

to change its intended use.

Non-factory installed parts and accessories are not covered under this limited

warranty. Please refer to the applicable parts and accessories limited warranty

text.

2) Limitation of Liability

TO THE EXTEND PERMITTED BY LAW, THIS WARRANTY IS EX-

PRESSLY GIVEN AND ACCEPTED IN LIEU OF ANY AND ALL OTHER

WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMI-

TATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. TO THE EXTENT THAT THEY CANNOT BE

DISCLAIMED, THE IMPLIED WARRANTIES ARE LIMITED IN DURATION

TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND CON-

SEQUENTIAL DAMAGES ARE EXCLUDED FROM COVERAGE UNDER

THIS WARRANTY. SOME STATES/PROVINCES DO NOT ALLOW FOR

THE DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED

ABOVE. AS A RESULT, THEY MAY NOT APPLY TO YOU. THIS WAR-

RANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE

OTHER LEGAL RIGHTS WHICH MAY VARY FROM COUNTRY TO COUN-

TRY. BRP SHALL NOT BE HELD LIABLE IF PRODUCTS OR WARRANTY

PARTS ARE NOT AVAILABLE IN CERTAIN COUNTRIES FOR REASONS

OUTSIDE OF BRP’S CONTROL.

For Products purchased in Australia, refer to the Australia-specific section below.

Neither the distributor, any BRP Distributor/Dealer nor any other person has

been authorized to make any affirmation, representation or warranty regarding

the product, other than those contained in this limited warranty, and if made, shall

not be enforceable against BRP.

BRP reserves the right to modify this limited warranty at any time, being under-

stood that such modification will not alter the warranty conditions applicable to

the Products sold while this warranty is in effect.

213

BRP LIMITED WARRANTY FOR INTERNATIONAL: 2024 CAN-AM^® SSV

3) EXCLUSIONS – Are Not Warranted

The following are not warranted under any circumstances:

- Normal wear and tear;

- Routine maintenance items, tune ups, adjustments;

- Damage caused by negligence or failure to provide proper maintenance and/

or storage, as described in the Operator's Guide;

- Damage resulting from removal of parts, improper repairs, service, mainte-

nance, modifications or use of parts not manufactured or approved by BRP or

resulting from repairs done by a person that is not an authorized servicing

BRP Distributor/Dealer;

- Damage caused by abuse, abnormal use, neglect or operation of the product

in a manner inconsistent with the recommended operation described in the

Product’s Operator’s Guide;

- Damage resulting from accident, submersion, fire, theft, vandalism or any act

of God;

- Operation with fuels, oils or lubricants which are not suitable for use with the

Product (see the Operator’s Guide);

- Damages from rust, corrosion or exposure to the elements;

- Damage resulting from water or snow ingestion;

- Incidental or consequential damages, or damages of any kind including with-

out limitation transportation expenses, towing, storage, telephone, rental, taxi,

inconvenience, insurance coverage, loan payments, loss of time, loss of in-

come or time missed for downtime experience due to service work.

The following list includes, without limitation, items that are considered wear

items and that are not covered under BRP's limited warranty unless failure is a di-

rect result of a defect in material or workmanship:

- Batteries

- Brake pads

- Brake disks and drums

- Clutch plates / pads

- Clutch sliders

- Clutch springs

- Clutch replaceable bushings

- Drive belts

- Filters

- Finished and unfinished surfaces

- Fuses

- Light bulbs / sealed

- Lubricants

- Spark plugs

- Suspension bushings

- Suspension slider shoes

- Suspension springs

- Tires

4) Warranty Coverage Period

This limited warranty will be in effect from (1) the date of delivery to the first retail

consumer, or (2) the date the product is first put into use, whichever occurs first

and for the applicable period below:

214

BRP LIMITED WARRANTY FOR INTERNATIONAL: 2024 CAN-AM^® SSV

1. SIX (6) consecutive months, for private use or commercial use owners

In AUSTRALIA and NEW ZEALAND only, this warranty will be in effect from (1)

the date of delivery to the first retail consumer or (2) the date the product is first

put into use, whichever occurs first, and for a period of TWELVE (12) CONSEC-

UTIVE MONTHS and THIRTY SIX (36) CONSECUTIVE MONTHS for Power-

train Engine and Transmission systems only, for private use or commercial use.

The repair or replacement of parts or the performance of service under this war-

ranty does not extend the life of this warranty beyond its original expiration date.

The warranty coverage period identified above are a minimal limited warranty pe-

riod which can be extended by any applicable warranty promotional program, as

the case may be.

Note that the duration and any other modalities of the warranty coverage are sub-

ject to the applicable national or local legislation in the customer's country.

5) For Products Sold In Australia Only

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law.

You are entitled to a replacement or refund for a major failure and for compensa-

tion for any other reasonably foreseeable loss or damage.

You are also entitled to have the goods repaired or replaced if the goods fail to

be of acceptable quality and the failure does not amount to a major failure.

Nothing in these Warranty terms and conditions should be taken to exclude, re-

strict or modify the application of any condition, warranty, guarantee, right or rem-

edy conferred or implied under the Competition and Consumer Act 2010 (Cth),

including the Australian Consumer Law or any other law, where to do so would

contravene that law, or cause any part of these terms and conditions to be void.

The benefits given to you under this limited warranty are in addition to other rights

and remedies that you have under Australian law.

6) Conditions to Have Warranty Coverage

This warranty coverage is available only if each of the following conditions has

been fulfilled:

1. The Product must be purchased as new and unused by its first owner from a

Distributor/Dealer authorized to distribute Products in the country in which the

sale occurred (“Distributor/Dealer”);

2. The BRP specified pre-delivery inspection process must be completed, docu-

mented and signed by the purchaser;

3. The Product must have undergone proper registration by an authorized Dis-

tributor/Dealer;

4. The Product must be purchased in the country in which the purchaser

resides;

5. Routine maintenance outlined in the Operator’s Guide must be timely per-

formed in order to maintain warranty coverage. BRP reserves the right to

make warranty coverage contingent upon proof of proper maintenance.

215

BRP LIMITED WARRANTY FOR INTERNATIONAL: 2024 CAN-AM^® SSV

BRP will not honor this limited warranty to any private use owner or commercial

use owner if one of the preceding conditions has not been met. Such limitations

are necessary in order to allow BRP to preserve both the safety of its products,

and also that of its consumers and the general public.

7) What to Do to Obtain Warranty Coverage

The customer must cease using the Product upon the appearance of an anom-

aly, notify a servicing BRP Distributor/Dealer within two (2) months of the appear-

ance of the anomaly and provide the Distributor/Dealer with reasonable access

to the Product and reasonable opportunity to repair it.

The notification period is subject to the applicable national or local legislation in

customer's country.

The customer must also present to the Distributor/Dealer, proof of purchase of

the Product and must sign the repair/work order prior to starting the repair in or-

der to validate the warranty repair.

All parts replaced under this limited warranty become the property of BRP.

8) What BRP Will Do

To the extent permitted by law, BRP’s obligations under this warranty are limited

to, at its sole discretion, repairing or replacing parts found defective under normal

use, maintenance and service without charge for parts and labor, at any author-

ized BRP Distributor/Dealer during the warranty coverage period under the con-

ditions described herein. No claim of breach of warranty shall be cause for

cancellation or rescission of the sale of the Product to the owner. You may have

other legal rights which may vary from country to country.

In the event that service is required outside of the country of original sale, the

owner will bear responsibility for any additional charges due to local practices

and conditions, such as, but not limited to, freight, insurance, taxes, license fees,

import duties, and any and all other financial charges, including those levied by

governments, states, territories and their respective agencies.

BRP reserves the right to improve or modify products from time to time without

assuming any obligation to modify products previously manufactured.

9) Transfer

If the ownership of a Product is transferred during the warranty coverage period,

this limited warranty, subject to its terms and conditions, shall also be transferred

and be valid for the remaining coverage period provided BRP or an authorized

Product Distributor/Dealer receives a proof that the former owner agreed to the

transfer of ownership, in addition to the coordinates of the new owner.

10) Consumer Assistance

In the event of a controversy or a dispute in connection with this limited warranty,

BRP suggests that you try to resolve the issue at the dealership level. We recom-

mend discussing the issue with the authorized Distributor/Dealer's service man-

ager or owner.

216

BRP LIMITED WARRANTY FOR THE EUROPEAN

ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024

CAN-AM® SSV

1) Scope of the Limited Warranty

Bombardier Recreational Products Inc. ("BRP") warrants its 2024 Can-Am SSV

(“Product(s)”) sold by distributors or dealers authorized by BRP to distribute the

Products in member states of the European Economic Area (which is comprised

of the states of the European Union plus the United Kingdom, Norway, Iceland

and Liechtenstein) ("EEA"), Turkey, member states of the Commonwealth of the

Independent States (including Ukraine and Turkmenistan) ("CIS") (“Distributor/

Dealer”) from defects in material or workmanship for the period and under the

conditions described below.

This limited warranty will become null and void if:

1. the Product was used for racing or any other competitive activity, at any point,

even by a previous owner; or

2. the Product has been altered or modified in such a way so as to adversely af-

fect its operation, performance or durability, or has been altered or modified

to change its intended use.

Non-factory installed parts and accessories are not covered under this limited

warranty. Please refer to the applicable parts and accessories limited warranty

text.

2) Limitations of Liability

TO THE EXTEND PERMITTED BY LAW, THIS WARRANTY IS EX-

PRESSLY GIVEN AND ACCEPTED IN LIEU OF ANY AND ALL OTHER

WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMI-

TATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. TO THE EXTENT THAT THEY CANNOT BE

DISCLAIMED, THE IMPLIED WARRANTIES ARE LIMITED IN DURATION

TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND CON-

SEQUENTIAL DAMAGES ARE EXCLUDED FROM COVERAGE UNDER

THIS WARRANTY. SOME STATES/PROVINCES DO NOT ALLOW FOR

THE DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED

ABOVE. AS A RESULT, THEY MAY NOT APPLY TO YOU. THIS WAR-

RANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE

OTHER LEGAL RIGHTS WHICH MAY VARY FROM STATE TO STATE,

OR PROVINCE TO PROVINCE. BRP SHALL NOT BE HELD LIABLE IF

PRODUCTS OR WARRANTY PARTS ARE NOT AVAILABLE IN CERTAIN

COUNTRIES FOR REASONS OUTSIDE OF BRP’S CONTROL.

For Products purchased in France, refer to the France-specific section below.

Neither the distributor, any BRP Distributor/Dealer nor any other person has

been authorized to make any affirmation, representation or warranty regarding

the product, other than those contained in this limited warranty, and if made, shall

not be enforceable against BRP.

218

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024 CAN-AM^® SSV

BRP reserves the right to modify this limited warranty at any time, being under-

stood that such modification will not alter the warranty conditions applicable to

the Products sold while this warranty is in effect.

3) EXCLUSIONS – Are Not Warranted

The following are not warranted under any circumstances:

- Normal wear and tear;

- Routine maintenance items, tune ups, adjustments;

- Damage caused by negligence or failure to provide proper maintenance and/

or storage, as described in the Operator's Guide;

- Damage resulting from removal of parts, improper repairs, service, mainte-

nance, modifications or use of parts not manufactured or approved by BRP or

resulting from repairs done by a person that is not an authorized servicing

BRP Distributor/Dealer;

- Damage caused by abuse, abnormal use, neglect or operation of the product

in a manner inconsistent with the recommended operation described in the

Product’s Operator’s Guide;

- Damage resulting from accident, submersion, fire, theft, vandalism or any act

of God;

- Operation with fuels, oils or lubricants which are not suitable for use with the

Product (see the Operator’s Guide);

- Damages from rust, corrosion or exposure to the elements;

- Damage resulting from water or snow ingestion;

- Incidental or consequential damages, or damages of any kind including with-

out limitation transportation expenses, towing, storage, telephone, rental, taxi,

inconvenience, insurance coverage, loan payments, loss of time, loss of in-

come or time missed for downtime experience due to service work.

The following list includes, without limitation, items that are considered wear

items and that are not covered under BRP's limited warranty unless failure is a di-

rect result of a defect in material or workmanship:

- Batteries

- Brake pads

- Brake disks and drums

- Clutch plates / pads

- Clutch sliders

- Clutch springs

- Clutch replaceable bushings

- Drive belts

- Filters

- Finished and unfinished surfaces

- Fuses

- Light bulbs / sealed

- Lubricants

- Spark plugs

- Suspension bushings

- Suspension slider shoes

- Suspension springs

- Tires

219

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024 CAN-AM^® SSV

4) Warranty Coverage Period

This limited warranty will be in effect from (1) the date of delivery to the first retail

consumer, or (2) the date the product is first put into use, whichever occurs first

and for the applicable period below:

1. TWENTY-FOUR (24) consecutive months, for private use owners.

2. SIX (6) consecutive months, for commercial use owners.

A Product is used commercially when it is used in connection with any work or

employment that generates income during any part of the warranty period. A

Product is also used commercially when, at any point during the warranty period,

it is licensed for commercial use.

The repair or replacement of parts or the performance of service under this war-

ranty does not extend the life of this warranty beyond its original expiration date.

The warranty coverage period identified above are a minimal limited warranty pe-

riod which can be extended by any applicable warranty promotional program, as

the case may be.

Note that the duration and any other modalities of the warranty coverage are sub-

ject to the applicable national or local legislation in the customer's country.

5) For Products Sold In France Only

The seller shall deliver goods that are complying with the contract and shall be

responsible for defects existing upon delivery. The seller shall also be responsi-

ble for defects resulting from packaging, assembling instructions or the installa-

tion when it is its responsibility per the contract or if accomplished under its

responsibility. To be compliant with the contract, the good shall:

1. Be fit for normal use for goods similar thereto and, if applicable:

- Correspond to the description provided by the seller and have the qualities

presented to the buyer though sample or model;

- Have the qualities that a buyer may legitimately expect considering the

public declarations of the seller, the manufacturer of its representative, in-

cluding in advertising or labeling; or

2. Have the characteristics mutually agreed upon as between the parties or be

fit for the specific use intended by the buyer and brought to the attention of

the seller and which accepted.

The action for failure to comply is prescribed after two years after delivery of the

goods. The seller is responsible for the warranty for hidden defects of the good

sold if such hidden defects are rendering the good unfit for the intended use, or if

they diminish its use in such a way that the buyer would not have acquired the

good or would have given a lesser price, had he known. The action for such hid-

den defects shall be taken by the buyer within 2 years of the discovery of the

defect.

6) Conditions to Have Warranty Coverage

This warranty coverage is available onlly if each of the following conditions has

been fulfilled:

220

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024 CAN-AM^® SSV

1. The Product must be purchased as new and unused by its first owner from a

Distributor/Dealer authorized to distribute Products in the country (or in the

case of the EEA, union of countries) in which the sale occurred (“Distributor/

Dealer”);

2. The BRP specified pre-delivery inspection process must be completed, docu-

mented and signed by the purchaser;

3. The Product must have undergone proper registration by an authorized Dis-

tributor/Dealer;

4. The Product must be purchased in the country (or in the case of the EEA,

union of countries) in which the purchaser resides;

5. Routine maintenance outlined in the Operator’s Guide must be timely per-

formed in order to maintain warranty coverage. BRP reserves the right to

make warranty coverage contingent upon proof of proper maintenance.

BRP will not honor this limited warranty to any private use owner or commercial

use owner if one of the preceding conditions has not been met. Such limitations

are necessary in order to allow BRP to preserve both the safety of its products,

and also that of its consumers and the general public.

7) What to Do to Obtain Warranty Coverage

The customer must cease using the Product upon the appearance of an anom-

aly, notify a servicing BRP Distributor/Dealer within two (2) months of the appear-

ance of the anomaly and provide the Distributor/Dealer with reasonable access

to the Product and reasonable opportunity to repair it.

The notification period is subject to the applicable national or local legislation in

customer's country.

The customer must also present to the Distributor/Dealer, proof of purchase of

the Product and must sign the repair/work order prior to starting the repair in or-

der to validate the warranty repair.

All parts replaced under this limited warranty become the property of BRP.

8) What BRP Will Do

To the extent permitted by law, BRP’s obligations under this warranty are limited

to, at its sole discretion, repairing or replacing parts found defective under normal

use, maintenance and service without charge for parts and labor, at any author-

ized BRP Distributor/Dealer during the warranty coverage period under the con-

ditions described herein. No claim of breach of warranty shall be cause for

cancellation or rescission of the sale of the Product to the owner. You may have

other legal rights which may vary from country to country.

In the event that service is required outside of the country of original sale, or for

EEA residents, if service is required outside of the EEA, the owner will bear re-

sponsibility for any additional charges due to local practices and conditions, such

as, but not limited to, freight, insurance, taxes, license fees, import duties, and

any and all other financial charges, including those levied by governments,

states, territories and their respective agencies.

BRP reserves the right to improve or modify products from time to time without

assuming any obligation to modify products previously manufactured.

221

BRP LIMITED WARRANTY FOR THE EUROPEAN ECONOMIC AREA, THE COMMONWEALTH OF THE

INDEPENDENT STATES AND TURKEY: 2024 CAN-AM^® SSV

9) Transfer

If the ownership of a Product is transferred during the warranty coverage period,

this limited warranty, subject to its terms and conditions, shall also be transferred

and be valid for the remaining coverage period provided BRP or an authorized

Product Distributor/Dealer receives a proof that the former owner agreed to the

transfer of ownership, in addition to the coordinates of the new owner.

10) Consumer Assistance

In the event of a controversy or a dispute in connection with this limited warranty,

BRP suggests that you try to resolve the issue at the dealership level. We recom-

mend discussing the issue with the authorized Distributor/Dealer's service man-

ager or owner.

If the matter still remains unresolved, contact BRP by filling out the customer con-

tact form at www.brp.com or contact BRP by mail at one of the addresses listed

under the Contact Us section of this guide.

222

DATA PRIVACY INFORMATION

Bombardier Recreational Products inc., its affiliates and subsidiaries (“BRP”) is

committed to protecting your privacy and support a general policy of openness

about how we collect, use and disclose your personal information in the course

of managing our relationship with you. More detaiils can be found by visiting

BRP’’s Priivacy Poliicy at:

https://brp.com/en/privacy-poliicy.htmll or by scanniing the QR Code below.

Please be assured that we have appropriate security measures in place to en-

sure that your personal information is protected against loss and unauthorized

access.

Your personal information that may be collected by BRP, directly from you or

from authorized dealers or authorized third parties, includes:

- Contact, Demographiic & Registratiion Informatiion (e.g., name, full ad-

dress, phone number, email, gender, ownership history, language of

communication)

- Vehicle Information (e.g., serial number, purchase and delivery date, unit

usage, vehicle location and movements)

- Third Party Informatiion (e.g., information received from BRP partners, join-

t-marketing activities information, social media)

- Technological Information (e.g., IP address, type of device, operating sys-

tem, browser type, webpages you view, cookies and similar technologies

when you use BRP or dealers’ websites or mobile application)

- Interaction with BRP Information (e.g., information collected when you call

BRP’s in-house sales representatives, buy items on a BRP web Site, sign up

for BRP emails, participate in BRP-sponsored contests and sweepstakes or

attend BRP-sponsored events)

- Transactiionall Informatiion (e.g., information necessary to handle returns,

payment information when you purchase our products or services through

our websites or mobile applications and other issues related to your purchase

of BRP products)

This information may be used and processed for the following purposes:

- Safety & Security

- Customer Support for Sales & After Sales (e.g., complete or follow up with

you about your purchase or maintenance)

- Registration & Warranty

- Communication (e.g., sending you a BRP satisfaction survey)

- Online Behavioural Advertising, Profiling and Location-Based Services

(e.g., offer customized experience)

- Compliance & Dispute Resolution

- Marketing & Advertising

- Assistance (e.g., help with any delivery issues, handle returns, and other is-

sues related to your purchase of BRP products).

We also may use personal information to generate aggregated or statistical data

that no longer identifies you personally.

Your personal informatiion may be disclosed to the folllowiing: BRP, BRP’s

authoriized deallerships, diistriibutors, serviice proviiders, advertising & mar-

ket research partners and other authoriized third partiies.

We may receive information about you from diverse sources, including third par-

ties, such as BRP’s authorized dealerships and partners, with whom we offer

224

DATA PRIVACY INFORMATION

services or engage in joint-marketing activities. We may also receive information

about you from social media platforms such as Facebook and Twitter, when you

interact with us on those platforms.

Depending on the circumstances, your personal information may be communi-

cated outside the region where you reside. Your personal information is retained

only for as long as necessary for the purpose for which we obtained it and ac-

cording to our retention policies.

To exercise your data privacy rights (e.g. right of access, right of rectification), to

withdraw your consent in order to be removed from the address list for marketing

purposes or for the satisfaction survey or for general data privacy questions,

please contact BRP’s Data Protection Officer at or by mail at privacyoffii-

cer@brp.com or by mail at:

BRP Legal Service, 726 St-Joseph, Valcourt, Quebec, Canada, J0E 2L0.

When BRP processes your personall iinformation, they do so in complliance

wiith its Privacy Pollicy avaiilable at: https://www.brp.com/en/privacy-poliicy.

htmll or by using the folllowiing

QR Code.

225

www.brp.com

Asia Pacific

Australia

Level 26

477 Pitt Street

Sydney, NSW 2020

China

上海市徐汇区衡山路10号6号楼301

Rm 301, Building 6,

No.10 Heng Shan Rd,

Shanghai, China

Japan

21F Shinagawa East One Tower

2-16-1 Konan, Minato-ku-ku,

Tokyo 108-0075

New Zealland

Suite 1.6, 2-8 Osborne Street,

Newmarket, Auckland 2013

Europe, Middle East and Africa

Bellgium

Oktrooiplein 1

9000 Gent

Czech Republiic

Stefanikova 43a

Prague 5

150 00

Germany

Itterpark 11

40724 Hilden

Fiinland

Isoaavantie 7

PL 8040

96101 Rovaniemi

France

Arteparc Bâtiment B

Route de la côte d'Azur,

13 590 Meyreuil

Norway

Ingvald Ystgaardsvei 15

N-7484 Trondheim

226

CHANGE OF ADDRESS AND OWNERSHIP

If your address has changed or if you are the new owner of the vehicle, be sure

to notify BRP by either:

- Notifying an authorized Can-Am dealer.

- North America Only: calling at 1 888 272-9222.

- Mailing one of the change of address cards on the following pages at one of

the BRP addresses indicated in the Contact Us section of this guide.

In case of change of ownership, please join a proof that the former owner agreed

to the transfer.

Notifying BRP, even after the expiration of the limited warranty, is very important

as it enables BRP to reach the vehicle owner if necessary, like when safety re-

calls are initiated. It is the owner’s responsibility to notify BRP.

STOLEN UNITS: If your personal vehicle is stolen, you should notify BRP or an

authorized Can-Am dealer. We will ask you to provide your name, address,

phone number, the vehicle identification number and the date it was stolen.

228
